FUNCTION KEY STRIP MAKER
~~~~~~~~~~~~~~~~~~~~~~~~
By Richard Dimond
As I had not got the Function Key Strip for View with my Master, I
borrowed a friend's strip so that I could make a copy. There was a
program published in Micro User for doing this but this was too long to
work on the Electron as it worked in MODE1. It also used the characters
on the computer and I thought it would be better to use the graphics
characters of the printer to give an improved strip.
Another reason I decided to write this program was that my printer will
only print a width of 8 inhes and the strip needed to be shortened by
about a quarter of an inch. This has meant that the leftmost section can
only be for 4 Elite characters so Control and Shift are abbreviated to
CTL> and SHT>. The remaining sections are able to contain up to 14
characters in Condensed Elite on each of two lines and these are arranged
for the text to centred.
The menus in the program are based on those used on the discs and the main
menu gives the following options -
1. Enter key details
2. Print key strip
3. Load file
4. Save file
5. Quit program
6. Clear memory
*. Enter * command
I will comment on these in turn -
1. On selecting this option, a second menu is shown. This gives options
for entering each of the six lines for the key selected by pressing
keys 1 to 6. Pressing N cycles the keys 0 to 9 and M returns to the
main menu.
On selecting a line number, you are given a cue for entering the
details for the key number and line number. This should not be more
than 14 characters or you will get the meesage 'Too long'. When an
entry is entered, you are returned to the menu and the entry is shown
in the box.
When entering is completed, you can then return to the main menu to
save the file or print it.
PROCct enters the string input to the correct position in the array
S$. K% being the key number and L% the line number minus 1. Line 600
of the program ensures that the string is not too long and lines 610 &
620 add the necessary spaces to centralise the text and make up the
string to 14 characters. This is needed to for the printing to line
up.
2. This option (and the remaining ones) first asks if you want to
continue or not so that you can return to the menu.
The print routine is rather involved but each line to be printed is of
a similar form though some program lines became too long and had to
be split.
Line 1050 expands the character set for the graphics characters.
Elite printing is selected at line 1060 and1/8 inch line spaicing at
line 1070.
Each line is similar in that they are made up as follows -
PROCcoff - turns off the condensed printing for the first section
to be printed - 4 elite characters between the division
characters.
PROCcon - turns on the condensed printing for the remainder of the
line - 14 condensed elite characters plus a division character for
each section.
3 & 4 Load and save the array in the usual way using nested FOR/NEXT
loops.
5. Ends the program or returns to the menu.
6. Enters strings of 14 zero characters into each section of the array
to clear memory.
*. This lets you use * commands for changing discs or *. for cataloguing
the disc. I have narrowed the window for this so that it will appear
as single column.
**************************************************************************
