   10MODE4
   20HIMEM=&52FF
   30DIM CODE% &100
   40PRINT TAB(0,5);"THE BEEB BODY BUILDING COURSE"
   50PRINT
   60PRINT:PRINT
   70PRINT"By Mike Cook"
   80PRINT
   90PRINT
  100PRINT"Sound Sampler Oscilloscope"
  110PRINT
  120PRINT"PRESS ANY KEY TO START"
  130A$=GET$
  140PRINT
  150PRINT"INITIALISING"
  160?&FE62=6
  170?&FE6C=(?&FE6C AND &F) OR &B0
  180?&86=&80:?&80=00:?&81=00
  190?&FE6E=&90
  200M%=&5600
  210FOR A%=0 TO 31
  220FOR B%=0 TO 7
  230T%=A%*&140+B%+&5800
  240?M%=T% MOD 256
  250M%?&100=T% DIV 256
  260M%=M%+1
  270NEXT
  280NEXT
  290FOR I%=0 TO 3 STEP 3
  300P%=CODE%
  310[
  320OPT I%
  330.START SEI
  340LDA &81  \GET TRIGGER VALUE
  350CMP #0
  360BEQ NTRIG      \TO NO TRIGGER POINT
  370\WAIT FOR A POSITIVE TRANSITION OF THE TRIGGER POINT
  380.TLOW JSR SGET  \LOOP TILL BELOW TRIGGER
  390CMP &81
  400BCS TLOW
  410.THI JSR SGET   \LOOP TILL ABOVE TRIGGER
  420CMP &81
  430BCC THI
  440.NTRIG LDY #0
  450\READ IN 256 SAMPLES
  460.SAMP JSR SGET
  470STA &5300,Y
  480INY
  490BNE SAMP
  500CLI
  510\DISPLAY SAMPLES
  520.SLINE LDX #0
  530STX &87
  540.LOOP LDX &80
  550\GET ADDRESS OF POINT TO ERASE
  560LDA &5400,X   \GET LSB OF ERASE POINT
  570STA &82
  580LDA &5500,X    \GET MSB OF ERASE POINT
  590STA &83
  600LDA &5300,X    \GET VALUE TO PLOT
  610EOR #&FF     \INVERT TO COMPENSATE
  620TAY
  630LDA &5600,Y  \LOOK UP LSB OF FIRST COLUM
  640CLC
  650ADC &87     \ADD X VALUE
  660STA &84     \STORE MSB OF PLOT ADDRESS
  670STA &5400,X \STORE ERASE ADDRESS
  680LDA &5700,Y  \LOOK UP MSB OF FIRST COLUM
  690ADC #0      \ADD X VALUE
  700STA &85   \STORE MSB OF PLOT ADDRESS
  710STA &5500,X \STORE ERASE ADDRESS
  720LDX #0
  730\REMOVE OLD POINT
  740LDA (&82,X)   \GET ENDCASE DISPLAY BYTE
  750EOR &86       \INVERT APPROPRIATE BIT
  760STA (&82,X)   \WRITE TO SCREEN
  770\PLOT OF POINT ON THE SCREEN
  780LDA (&84,X)   \GET DISPLAY BYTE
  790ORA &86       \SET APPROPRIATE BIT
  800STA (&84,X)   \WRITE TO SCREEN
  810\MOVE POINTERS TO NEXT X POSITION
  820INC &80  \X POINTER
  830ROR &86  \PIXEL MASK
  840BCC LOOP
  850LDA #&80      \RESTORE MASK BIT
  860STA &86
  870LDA #7   \ADD 8 TO X VALUE
  880ADC &87 \IT IS 8 AS CARRY IS SET
  890STA &87
  900BNE LOOP  \LOOP IF NOT FINISHED ALL POINTS
  910LDA #129
  920LDX #&9D
  930LDY #&FF   \TEST FOR SPACE BAR
  940JSR &FFF4
  950TXA
  960CMP #&FF
  970BNE START
  980RTS        \FINISH WHEN SPACE PRESSED
  990.SGET
 1000LDX #10:LDA #0
 1010STA &FE60 \ CS & CK =0
 1020.SLOOP
 1030LDA &FE60 \ GET DATA
 1040LSR A:ROL &7A \ INTO MEM
 1050LDA #2:STA &FE60 \ CK = 1
 1060LDA #0:STA &FE60 \ CK = 0
 1070DEX : BNE SLOOP
 1080LDA #6:STA &FE60
 1090LDA &7A
 1100RTS
 1110]
 1120NEXT
 1130CLS
 1140VDU 24,0;0;1023;1023;
 1150VDU 28,32,31,39,0
 1160CLG
 1170PROC_SETUP
 1180PRINT"Expand"
 1190PRINT"Trigger"
 1200PRINT"Run"
 1210PRINT"?";
 1220A$=GET$
 1230IF A$="R" THEN PROC_WIPE:PROC_SETUP:PRINT"RUNNING":CALL CODE%:PRINT:PRINT"NOW:-":GOTO1180
 1240IF A$="T" THEN PRINT:INPUT"VALUE",T%:?&81=T%:GOTO 1180
 1250IF A$<> "E" THEN 1220
 1260PRINT
 1270PRINT"SCALE"
 1280INPUT S%
 1290IF S%<1 OR S%> 100 THEN PRINT"TOO MUCH":GOTO 1270
 1300PRINT"JOINED ?"
 1310A$=GET$
 1320IF A$="Y" THEN J%=5 ELSE J%=69
 1330P%=&5300
 1340CLG
 1350X%=-S%*4
 1360MOVE 0,?P%*4
 1370REPEAT
 1380X%=X%+S%*4
 1390PLOT J%,X%,?P%*4
 1400P%=P%+1
 1410UNTIL X%>1019
 1420GOTO 1180
 1430DEF PROC_WIPE
 1440CLG
 1450FOR A%=&5400 TO &55FF
 1460?A%=&C0
 1470NEXT
 1480ENDPROC
 1490DEF PROC_SETUP
 1500CLS
 1510PRINT
 1520PRINT" SCOPE "
 1530PRINT
 1540PRINT"TRIG ";?&81
 1550PRINT
 1560PRINT"SPACE TO";
 1570PRINT" FREEZE"
 1580PRINT" TRACE"
 1590PRINT
 1600ENDPROC
