Electron User Guide Errata
-----------------------------------------------------------------------------
For your information the example on page 34 should read:
VDU 19,2,RND(3)+1,0,0,0
The example on page 59 should read:
10 A$ = "J"
20 PRINT A$; A$; A$
30 PRINT A$; A$; A$
40 PRINT A$' A$' A$
> RUN
The example on page 60 should read:
10 X = 6
20 A$ = "J"
30 PRINT X,X,X' A$, A$, A$
> RUN
On page 95 the following statements should read:
40 VDU 23,1,0;0;0;0'
VDU 23,1,1;0;0;0
On page 100 the FX phrases on lines 1 and 9 should be replaced by OSWORD.
On page 114 please read Mode 7 as Mode 6 - due the fact that Mode 7 is not
available on the Electron.
--------------------------------------------------------------------------
*FX/Osbyte features not documented in the BBC Micro User Guide
-----------------------------------------------------------------------------
&0D (13)
Two undocumented parameters may be supplied in X to disable events:
X = 7 disable RS423 receive error event
X = 8 disable service/network error event
&0E (14)
As above, two undocumented parameters may be supplied in X to enable events:
X = 7 enable RS423 receive error event
X = 8 enable service/network error event
Events are explained on p465 of the User Guide.
&76 (117)
This call returns the VDU status byte (which contains various status flags)
in the X register.
BIT 0 - set if VDU2 sent, cleared by VDU3
BIT 2 - set if PAGED MODE ON, cleared if PAGED MODE OFF
BIT 3 - set if software scrolling, cleared if hardware scrolling
Software scrolling is used when text windows have been defined whereas
hardware scrolls are used when the whole screen scrolls.
BIT 5 - set when cursors joined by VDU5
BIT 7 - set if VDU disabled
&76 (118)
Returns with the carry bit if the CTRL key is pressed, and with the Negative
bit set if the SHIFT key is pressed. Machine code routines may branch on
these conditions. This feature is invalid when called from a Second
Processor.
&7B (123)
This call is used by the User Print Routine to indicate to the MOS that it
has finished its task. (CF *FX 5.3 command). This feature should not
normally be called from a Second Processor.
&8A (138)
This call has been expanded to allow a character to be inserted into any
buffer. X must contain the buffer number, and Y the character to be
inserted. A list of buffer numbers appears with *FX 21 on p428 of the User
Guide.
&8D (141)
This command is exactly equivalent to the *ROM command.
&98 (152)
This call examines a buffer. The buffer number must be in X, and the call
returns as follows:
Carry bit set if buffer empty
Carry bit clear indicates character(s) present in buffer.
Note that no character has been removed from the buffer.
&99 (153)
The call inserts a character into an INPUT buffer handling the interrupt
character, and generating an escape condition if necessary.
Valid only for X = 0 or 1
Y must contain character to be inserted
&9C (156)
Change 6850 control register. The 6859 register is altered to: (Old value
AND Y) EOR X. (See User Guide page 438).
Refer to the 6850 Data Sheet for details of the 6850 control register.
&9E (158) / &9F (159)
These calls respectively read and write to the Speech Processor chip. Refer
to the Speech System User Guide.
&E9 (233)
As for &E7 (see User Guide page 441) but affects the system 6522. The system
6522 is used extensively in the normal operation of the machine and
consequently this call should be used with extreme care.
00000000 45 6c 65 63 74 72 6f 6e 20 55 73 65 72 20 47 75 |Electron User Gu| 00000010 69 64 65 20 45 72 72 61 74 61 0d 2d 2d 2d 2d 2d |ide Errata.-----| 00000020 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d |----------------| * 00000060 2d 2d 2d 2d 2d 2d 2d 2d 0d 0d 46 6f 72 20 79 6f |--------..For yo| 00000070 75 72 20 69 6e 66 6f 72 6d 61 74 69 6f 6e 20 74 |ur information t| 00000080 68 65 20 65 78 61 6d 70 6c 65 20 6f 6e 20 70 61 |he example on pa| 00000090 67 65 20 33 34 20 73 68 6f 75 6c 64 20 72 65 61 |ge 34 should rea| 000000a0 64 3a 0d 0d 20 20 20 20 20 20 20 20 56 44 55 20 |d:.. VDU | 000000b0 31 39 2c 32 2c 52 4e 44 28 33 29 2b 31 2c 30 2c |19,2,RND(3)+1,0,| 000000c0 30 2c 30 0d 0d 54 68 65 20 65 78 61 6d 70 6c 65 |0,0..The example| 000000d0 20 6f 6e 20 70 61 67 65 20 35 39 20 73 68 6f 75 | on page 59 shou| 000000e0 6c 64 20 72 65 61 64 3a 0d 0d 20 20 20 20 20 20 |ld read:.. | 000000f0 20 20 31 30 20 20 20 20 41 24 20 3d 20 22 4a 22 | 10 A$ = "J"| 00000100 0d 20 20 20 20 20 20 20 20 32 30 20 20 20 20 50 |. 20 P| 00000110 52 49 4e 54 20 41 24 3b 20 41 24 3b 20 41 24 0d |RINT A$; A$; A$.| 00000120 20 20 20 20 20 20 20 20 33 30 20 20 20 20 50 52 | 30 PR| 00000130 49 4e 54 20 41 24 3b 20 41 24 3b 20 41 24 20 0d |INT A$; A$; A$ .| 00000140 20 20 20 20 20 20 20 20 34 30 20 20 20 20 50 52 | 40 PR| 00000150 49 4e 54 20 41 24 27 20 41 24 27 20 41 24 0d 20 |INT A$' A$' A$. | 00000160 20 20 20 20 20 20 20 3e 20 20 20 20 20 20 52 55 | > RU| 00000170 4e 0d 0d 54 68 65 20 65 78 61 6d 70 6c 65 20 6f |N..The example o| 00000180 6e 20 70 61 67 65 20 36 30 20 73 68 6f 75 6c 64 |n page 60 should| 00000190 20 72 65 61 64 3a 0d 0d 20 20 20 20 20 20 20 20 | read:.. | 000001a0 31 30 20 20 20 58 20 3d 20 36 0d 20 20 20 20 20 |10 X = 6. | 000001b0 20 20 20 32 30 20 20 20 41 24 20 3d 20 22 4a 22 | 20 A$ = "J"| 000001c0 0d 20 20 20 20 20 20 20 20 33 30 20 20 20 50 52 |. 30 PR| 000001d0 49 4e 54 20 58 2c 58 2c 58 27 20 41 24 2c 20 41 |INT X,X,X' A$, A| 000001e0 24 2c 20 41 24 0d 20 20 20 20 20 20 20 20 3e 20 |$, A$. > | 000001f0 20 20 20 52 55 4e 0d 0d 4f 6e 20 70 61 67 65 20 | RUN..On page | 00000200 39 35 20 74 68 65 20 66 6f 6c 6c 6f 77 69 6e 67 |95 the following| 00000210 20 73 74 61 74 65 6d 65 6e 74 73 20 73 68 6f 75 | statements shou| 00000220 6c 64 20 72 65 61 64 3a 0d 0d 20 20 20 20 20 20 |ld read:.. | 00000230 20 20 34 30 20 56 44 55 20 32 33 2c 31 2c 30 3b | 40 VDU 23,1,0;| 00000240 30 3b 30 3b 30 27 0d 0d 20 20 20 20 20 20 20 20 |0;0;0'.. | 00000250 56 44 55 20 32 33 2c 31 2c 31 3b 30 3b 30 3b 30 |VDU 23,1,1;0;0;0| 00000260 0d 0d 4f 6e 20 70 61 67 65 20 31 30 30 20 74 68 |..On page 100 th| 00000270 65 20 46 58 20 70 68 72 61 73 65 73 20 6f 6e 20 |e FX phrases on | 00000280 6c 69 6e 65 73 20 31 20 61 6e 64 20 39 20 73 68 |lines 1 and 9 sh| 00000290 6f 75 6c 64 20 62 65 20 72 65 70 6c 61 63 65 64 |ould be replaced| 000002a0 20 62 79 20 4f 53 57 4f 52 44 2e 0d 0d 4f 6e 20 | by OSWORD...On | 000002b0 70 61 67 65 20 31 31 34 20 70 6c 65 61 73 65 20 |page 114 please | 000002c0 72 65 61 64 20 4d 6f 64 65 20 37 20 61 73 20 4d |read Mode 7 as M| 000002d0 6f 64 65 20 36 20 2d 20 64 75 65 20 74 68 65 20 |ode 6 - due the | 000002e0 66 61 63 74 20 74 68 61 74 20 4d 6f 64 65 20 37 |fact that Mode 7| 000002f0 20 69 73 20 6e 6f 74 0d 61 76 61 69 6c 61 62 6c | is not.availabl| 00000300 65 20 6f 6e 20 74 68 65 20 45 6c 65 63 74 72 6f |e on the Electro| 00000310 6e 2e 0d 0d 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d |n...------------| 00000320 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d |----------------| * 00000350 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d 0d 2a |--------------.*| 00000360 46 58 2f 4f 73 62 79 74 65 20 66 65 61 74 75 72 |FX/Osbyte featur| 00000370 65 73 20 6e 6f 74 20 64 6f 63 75 6d 65 6e 74 65 |es not documente| 00000380 64 20 69 6e 20 74 68 65 20 42 42 43 20 4d 69 63 |d in the BBC Mic| 00000390 72 6f 20 55 73 65 72 20 47 75 69 64 65 0d 2d 2d |ro User Guide.--| 000003a0 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d |----------------| * 000003e0 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d 0d 0d 26 30 44 |-----------..&0D| 000003f0 20 20 28 31 33 29 0d 54 77 6f 20 75 6e 64 6f 63 | (13).Two undoc| 00000400 75 6d 65 6e 74 65 64 20 70 61 72 61 6d 65 74 65 |umented paramete| 00000410 72 73 20 6d 61 79 20 62 65 20 73 75 70 70 6c 69 |rs may be suppli| 00000420 65 64 20 69 6e 20 58 20 74 6f 20 64 69 73 61 62 |ed in X to disab| 00000430 6c 65 20 65 76 65 6e 74 73 3a 0d 0d 20 20 20 20 |le events:.. | 00000440 20 20 20 20 58 20 3d 20 37 20 20 64 69 73 61 62 | X = 7 disab| 00000450 6c 65 20 52 53 34 32 33 20 72 65 63 65 69 76 65 |le RS423 receive| 00000460 20 65 72 72 6f 72 20 65 76 65 6e 74 0d 20 20 20 | error event. | 00000470 20 20 20 20 20 58 20 3d 20 38 20 20 64 69 73 61 | X = 8 disa| 00000480 62 6c 65 20 73 65 72 76 69 63 65 2f 6e 65 74 77 |ble service/netw| 00000490 6f 72 6b 20 65 72 72 6f 72 20 65 76 65 6e 74 0d |ork error event.| 000004a0 0d 0d 26 30 45 20 20 28 31 34 29 0d 41 73 20 61 |..&0E (14).As a| 000004b0 62 6f 76 65 2c 20 74 77 6f 20 75 6e 64 6f 63 75 |bove, two undocu| 000004c0 6d 65 6e 74 65 64 20 70 61 72 61 6d 65 74 65 72 |mented parameter| 000004d0 73 20 6d 61 79 20 62 65 20 73 75 70 70 6c 69 65 |s may be supplie| 000004e0 64 20 69 6e 20 58 20 74 6f 20 65 6e 61 62 6c 65 |d in X to enable| 000004f0 20 65 76 65 6e 74 73 3a 0d 0d 20 20 20 20 20 20 | events:.. | 00000500 20 20 58 20 3d 20 37 20 20 65 6e 61 62 6c 65 20 | X = 7 enable | 00000510 52 53 34 32 33 20 72 65 63 65 69 76 65 20 65 72 |RS423 receive er| 00000520 72 6f 72 20 65 76 65 6e 74 0d 20 20 20 20 20 20 |ror event. | 00000530 20 20 58 20 3d 20 38 20 20 65 6e 61 62 6c 65 20 | X = 8 enable | 00000540 73 65 72 76 69 63 65 2f 6e 65 74 77 6f 72 6b 20 |service/network | 00000550 65 72 72 6f 72 20 65 76 65 6e 74 0d 0d 45 76 65 |error event..Eve| 00000560 6e 74 73 20 61 72 65 20 65 78 70 6c 61 69 6e 65 |nts are explaine| 00000570 64 20 6f 6e 20 70 34 36 35 20 6f 66 20 74 68 65 |d on p465 of the| 00000580 20 55 73 65 72 20 47 75 69 64 65 2e 0d 0d 0d 26 | User Guide....&| 00000590 37 36 20 20 28 31 31 37 29 0d 54 68 69 73 20 63 |76 (117).This c| 000005a0 61 6c 6c 20 72 65 74 75 72 6e 73 20 74 68 65 20 |all returns the | 000005b0 56 44 55 20 73 74 61 74 75 73 20 62 79 74 65 20 |VDU status byte | 000005c0 28 77 68 69 63 68 20 63 6f 6e 74 61 69 6e 73 20 |(which contains | 000005d0 76 61 72 69 6f 75 73 20 73 74 61 74 75 73 20 66 |various status f| 000005e0 6c 61 67 73 29 0d 69 6e 20 74 68 65 20 58 20 72 |lags).in the X r| 000005f0 65 67 69 73 74 65 72 2e 20 0d 0d 20 20 20 20 20 |egister. .. | 00000600 20 20 20 42 49 54 20 30 20 2d 20 73 65 74 20 69 | BIT 0 - set i| 00000610 66 20 56 44 55 32 20 73 65 6e 74 2c 20 63 6c 65 |f VDU2 sent, cle| 00000620 61 72 65 64 20 62 79 20 56 44 55 33 0d 20 20 20 |ared by VDU3. | 00000630 20 20 20 20 20 42 49 54 20 32 20 2d 20 73 65 74 | BIT 2 - set| 00000640 20 69 66 20 50 41 47 45 44 20 4d 4f 44 45 20 4f | if PAGED MODE O| 00000650 4e 2c 20 20 63 6c 65 61 72 65 64 20 69 66 20 50 |N, cleared if P| 00000660 41 47 45 44 20 4d 4f 44 45 20 4f 46 46 0d 20 20 |AGED MODE OFF. | 00000670 20 20 20 20 20 20 42 49 54 20 33 20 2d 20 73 65 | BIT 3 - se| 00000680 74 20 69 66 20 73 6f 66 74 77 61 72 65 20 73 63 |t if software sc| 00000690 72 6f 6c 6c 69 6e 67 2c 20 63 6c 65 61 72 65 64 |rolling, cleared| 000006a0 20 69 66 20 68 61 72 64 77 61 72 65 20 73 63 72 | if hardware scr| 000006b0 6f 6c 6c 69 6e 67 0d 0d 53 6f 66 74 77 61 72 65 |olling..Software| 000006c0 20 73 63 72 6f 6c 6c 69 6e 67 20 69 73 20 75 73 | scrolling is us| 000006d0 65 64 20 77 68 65 6e 20 74 65 78 74 20 77 69 6e |ed when text win| 000006e0 64 6f 77 73 20 68 61 76 65 20 62 65 65 6e 20 64 |dows have been d| 000006f0 65 66 69 6e 65 64 20 77 68 65 72 65 61 73 0d 68 |efined whereas.h| 00000700 61 72 64 77 61 72 65 20 73 63 72 6f 6c 6c 73 20 |ardware scrolls | 00000710 61 72 65 20 75 73 65 64 20 77 68 65 6e 20 74 68 |are used when th| 00000720 65 20 77 68 6f 6c 65 20 73 63 72 65 65 6e 20 73 |e whole screen s| 00000730 63 72 6f 6c 6c 73 2e 20 0d 0d 20 20 20 20 20 20 |crolls. .. | 00000740 20 20 42 49 54 20 35 20 2d 20 73 65 74 20 77 68 | BIT 5 - set wh| 00000750 65 6e 20 63 75 72 73 6f 72 73 20 6a 6f 69 6e 65 |en cursors joine| 00000760 64 20 62 79 20 56 44 55 35 0d 20 20 20 20 20 20 |d by VDU5. | 00000770 20 20 42 49 54 20 37 20 2d 20 73 65 74 20 69 66 | BIT 7 - set if| 00000780 20 56 44 55 20 64 69 73 61 62 6c 65 64 0d 0d 0d | VDU disabled...| 00000790 26 37 36 20 20 28 31 31 38 29 0d 52 65 74 75 72 |&76 (118).Retur| 000007a0 6e 73 20 77 69 74 68 20 74 68 65 20 63 61 72 72 |ns with the carr| 000007b0 79 20 62 69 74 20 69 66 20 74 68 65 20 43 54 52 |y bit if the CTR| 000007c0 4c 20 6b 65 79 20 69 73 20 70 72 65 73 73 65 64 |L key is pressed| 000007d0 2c 20 61 6e 64 20 77 69 74 68 20 74 68 65 20 4e |, and with the N| 000007e0 65 67 61 74 69 76 65 0d 62 69 74 20 73 65 74 20 |egative.bit set | 000007f0 69 66 20 74 68 65 20 53 48 49 46 54 20 6b 65 79 |if the SHIFT key| 00000800 20 69 73 20 70 72 65 73 73 65 64 2e 20 4d 61 63 | is pressed. Mac| 00000810 68 69 6e 65 20 63 6f 64 65 20 72 6f 75 74 69 6e |hine code routin| 00000820 65 73 20 6d 61 79 20 62 72 61 6e 63 68 20 6f 6e |es may branch on| 00000830 0d 74 68 65 73 65 20 63 6f 6e 64 69 74 69 6f 6e |.these condition| 00000840 73 2e 20 20 54 68 69 73 20 66 65 61 74 75 72 65 |s. This feature| 00000850 20 69 73 20 69 6e 76 61 6c 69 64 20 77 68 65 6e | is invalid when| 00000860 20 63 61 6c 6c 65 64 20 66 72 6f 6d 20 61 20 53 | called from a S| 00000870 65 63 6f 6e 64 0d 50 72 6f 63 65 73 73 6f 72 2e |econd.Processor.| 00000880 0d 0d 0d 26 37 42 20 20 28 31 32 33 29 0d 54 68 |...&7B (123).Th| 00000890 69 73 20 63 61 6c 6c 20 69 73 20 75 73 65 64 20 |is call is used | 000008a0 62 79 20 74 68 65 20 55 73 65 72 20 50 72 69 6e |by the User Prin| 000008b0 74 20 52 6f 75 74 69 6e 65 20 74 6f 20 69 6e 64 |t Routine to ind| 000008c0 69 63 61 74 65 20 74 6f 20 74 68 65 20 4d 4f 53 |icate to the MOS| 000008d0 20 74 68 61 74 20 69 74 0d 68 61 73 20 66 69 6e | that it.has fin| 000008e0 69 73 68 65 64 20 69 74 73 20 74 61 73 6b 2e 20 |ished its task. | 000008f0 20 28 43 46 20 2a 46 58 20 35 2e 33 20 63 6f 6d | (CF *FX 5.3 com| 00000900 6d 61 6e 64 29 2e 20 54 68 69 73 20 66 65 61 74 |mand). This feat| 00000910 75 72 65 20 73 68 6f 75 6c 64 20 6e 6f 74 0d 6e |ure should not.n| 00000920 6f 72 6d 61 6c 6c 79 20 62 65 20 63 61 6c 6c 65 |ormally be calle| 00000930 64 20 66 72 6f 6d 20 61 20 53 65 63 6f 6e 64 20 |d from a Second | 00000940 50 72 6f 63 65 73 73 6f 72 2e 0d 0d 0d 26 38 41 |Processor....&8A| 00000950 20 20 28 31 33 38 29 0d 54 68 69 73 20 63 61 6c | (138).This cal| 00000960 6c 20 68 61 73 20 62 65 65 6e 20 65 78 70 61 6e |l has been expan| 00000970 64 65 64 20 74 6f 20 61 6c 6c 6f 77 20 61 20 63 |ded to allow a c| 00000980 68 61 72 61 63 74 65 72 20 74 6f 20 62 65 20 69 |haracter to be i| 00000990 6e 73 65 72 74 65 64 20 69 6e 74 6f 20 61 6e 79 |nserted into any| 000009a0 0d 62 75 66 66 65 72 2e 20 20 58 20 6d 75 73 74 |.buffer. X must| 000009b0 20 63 6f 6e 74 61 69 6e 20 74 68 65 20 62 75 66 | contain the buf| 000009c0 66 65 72 20 6e 75 6d 62 65 72 2c 20 61 6e 64 20 |fer number, and | 000009d0 59 20 74 68 65 20 63 68 61 72 61 63 74 65 72 20 |Y the character | 000009e0 74 6f 20 62 65 0d 69 6e 73 65 72 74 65 64 2e 20 |to be.inserted. | 000009f0 41 20 6c 69 73 74 20 6f 66 20 62 75 66 66 65 72 |A list of buffer| 00000a00 20 6e 75 6d 62 65 72 73 20 61 70 70 65 61 72 73 | numbers appears| 00000a10 20 77 69 74 68 20 2a 46 58 20 32 31 20 6f 6e 20 | with *FX 21 on | 00000a20 70 34 32 38 20 6f 66 20 74 68 65 20 55 73 65 72 |p428 of the User| 00000a30 0d 47 75 69 64 65 2e 0d 0d 0d 26 38 44 20 20 28 |.Guide....&8D (| 00000a40 31 34 31 29 0d 54 68 69 73 20 63 6f 6d 6d 61 6e |141).This comman| 00000a50 64 20 69 73 20 65 78 61 63 74 6c 79 20 65 71 75 |d is exactly equ| 00000a60 69 76 61 6c 65 6e 74 20 74 6f 20 74 68 65 20 2a |ivalent to the *| 00000a70 52 4f 4d 20 63 6f 6d 6d 61 6e 64 2e 0d 0d 0d 26 |ROM command....&| 00000a80 39 38 20 20 28 31 35 32 29 0d 54 68 69 73 20 63 |98 (152).This c| 00000a90 61 6c 6c 20 65 78 61 6d 69 6e 65 73 20 61 20 62 |all examines a b| 00000aa0 75 66 66 65 72 2e 20 54 68 65 20 62 75 66 66 65 |uffer. The buffe| 00000ab0 72 20 6e 75 6d 62 65 72 20 6d 75 73 74 20 62 65 |r number must be| 00000ac0 20 69 6e 20 58 2c 20 61 6e 64 20 74 68 65 20 63 | in X, and the c| 00000ad0 61 6c 6c 0d 72 65 74 75 72 6e 73 20 61 73 20 66 |all.returns as f| 00000ae0 6f 6c 6c 6f 77 73 3a 0d 0d 20 20 20 20 20 20 20 |ollows:.. | 00000af0 20 43 61 72 72 79 20 62 69 74 20 73 65 74 20 69 | Carry bit set i| 00000b00 66 20 62 75 66 66 65 72 20 65 6d 70 74 79 0d 20 |f buffer empty. | 00000b10 20 20 20 20 20 20 20 43 61 72 72 79 20 62 69 74 | Carry bit| 00000b20 20 63 6c 65 61 72 20 69 6e 64 69 63 61 74 65 73 | clear indicates| 00000b30 20 63 68 61 72 61 63 74 65 72 28 73 29 20 70 72 | character(s) pr| 00000b40 65 73 65 6e 74 20 69 6e 20 62 75 66 66 65 72 2e |esent in buffer.| 00000b50 0d 0d 4e 6f 74 65 20 74 68 61 74 20 6e 6f 20 63 |..Note that no c| 00000b60 68 61 72 61 63 74 65 72 20 68 61 73 20 62 65 65 |haracter has bee| 00000b70 6e 20 72 65 6d 6f 76 65 64 20 66 72 6f 6d 20 74 |n removed from t| 00000b80 68 65 20 62 75 66 66 65 72 2e 0d 0d 0d 26 39 39 |he buffer....&99| 00000b90 20 20 28 31 35 33 29 0d 54 68 65 20 63 61 6c 6c | (153).The call| 00000ba0 20 69 6e 73 65 72 74 73 20 61 20 63 68 61 72 61 | inserts a chara| 00000bb0 63 74 65 72 20 69 6e 74 6f 20 61 6e 20 49 4e 50 |cter into an INP| 00000bc0 55 54 20 62 75 66 66 65 72 20 68 61 6e 64 6c 69 |UT buffer handli| 00000bd0 6e 67 20 74 68 65 20 69 6e 74 65 72 72 75 70 74 |ng the interrupt| 00000be0 0d 63 68 61 72 61 63 74 65 72 2c 20 61 6e 64 20 |.character, and | 00000bf0 67 65 6e 65 72 61 74 69 6e 67 20 61 6e 20 65 73 |generating an es| 00000c00 63 61 70 65 20 63 6f 6e 64 69 74 69 6f 6e 20 69 |cape condition i| 00000c10 66 20 6e 65 63 65 73 73 61 72 79 2e 20 0d 0d 20 |f necessary. .. | 00000c20 20 20 20 20 20 20 20 56 61 6c 69 64 20 6f 6e 6c | Valid onl| 00000c30 79 20 66 6f 72 20 58 20 3d 20 30 20 6f 72 20 31 |y for X = 0 or 1| 00000c40 0d 20 20 20 20 20 20 20 20 59 20 6d 75 73 74 20 |. Y must | 00000c50 63 6f 6e 74 61 69 6e 20 63 68 61 72 61 63 74 65 |contain characte| 00000c60 72 20 74 6f 20 62 65 20 69 6e 73 65 72 74 65 64 |r to be inserted| 00000c70 0d 0d 0d 26 39 43 20 20 28 31 35 36 29 0d 43 68 |...&9C (156).Ch| 00000c80 61 6e 67 65 20 36 38 35 30 20 63 6f 6e 74 72 6f |ange 6850 contro| 00000c90 6c 20 72 65 67 69 73 74 65 72 2e 20 54 68 65 20 |l register. The | 00000ca0 36 38 35 39 20 72 65 67 69 73 74 65 72 20 69 73 |6859 register is| 00000cb0 20 61 6c 74 65 72 65 64 20 74 6f 3a 20 20 28 4f | altered to: (O| 00000cc0 6c 64 20 76 61 6c 75 65 0d 41 4e 44 20 59 29 20 |ld value.AND Y) | 00000cd0 45 4f 52 20 58 2e 20 20 28 53 65 65 20 55 73 65 |EOR X. (See Use| 00000ce0 72 20 47 75 69 64 65 20 70 61 67 65 20 34 33 38 |r Guide page 438| 00000cf0 29 2e 0d 0d 52 65 66 65 72 20 74 6f 20 74 68 65 |)...Refer to the| 00000d00 20 36 38 35 30 20 44 61 74 61 20 53 68 65 65 74 | 6850 Data Sheet| 00000d10 20 66 6f 72 20 64 65 74 61 69 6c 73 20 6f 66 20 | for details of | 00000d20 74 68 65 20 36 38 35 30 20 63 6f 6e 74 72 6f 6c |the 6850 control| 00000d30 20 72 65 67 69 73 74 65 72 2e 0d 0d 0d 26 39 45 | register....&9E| 00000d40 20 20 28 31 35 38 29 20 2f 20 26 39 46 20 28 31 | (158) / &9F (1| 00000d50 35 39 29 0d 54 68 65 73 65 20 63 61 6c 6c 73 20 |59).These calls | 00000d60 72 65 73 70 65 63 74 69 76 65 6c 79 20 72 65 61 |respectively rea| 00000d70 64 20 61 6e 64 20 77 72 69 74 65 20 74 6f 20 74 |d and write to t| 00000d80 68 65 20 53 70 65 65 63 68 20 50 72 6f 63 65 73 |he Speech Proces| 00000d90 73 6f 72 20 63 68 69 70 2e 20 52 65 66 65 72 0d |sor chip. Refer.| 00000da0 74 6f 20 74 68 65 20 53 70 65 65 63 68 20 53 79 |to the Speech Sy| 00000db0 73 74 65 6d 20 55 73 65 72 20 47 75 69 64 65 2e |stem User Guide.| 00000dc0 0d 0d 0d 26 45 39 20 20 28 32 33 33 29 0d 41 73 |...&E9 (233).As| 00000dd0 20 66 6f 72 20 26 45 37 20 28 73 65 65 20 55 73 | for &E7 (see Us| 00000de0 65 72 20 47 75 69 64 65 20 70 61 67 65 20 34 34 |er Guide page 44| 00000df0 31 29 20 62 75 74 20 61 66 66 65 63 74 73 20 74 |1) but affects t| 00000e00 68 65 20 73 79 73 74 65 6d 20 36 35 32 32 2e 20 |he system 6522. | 00000e10 54 68 65 20 73 79 73 74 65 6d 0d 36 35 32 32 20 |The system.6522 | 00000e20 69 73 20 75 73 65 64 20 65 78 74 65 6e 73 69 76 |is used extensiv| 00000e30 65 6c 79 20 69 6e 20 74 68 65 20 6e 6f 72 6d 61 |ely in the norma| 00000e40 6c 20 6f 70 65 72 61 74 69 6f 6e 20 6f 66 20 74 |l operation of t| 00000e50 68 65 20 6d 61 63 68 69 6e 65 20 61 6e 64 0d 63 |he machine and.c| 00000e60 6f 6e 73 65 71 75 65 6e 74 6c 79 20 74 68 69 73 |onsequently this| 00000e70 20 63 61 6c 6c 20 73 68 6f 75 6c 64 20 62 65 20 | call should be | 00000e80 75 73 65 64 20 77 69 74 68 20 65 78 74 72 65 6d |used with extrem| 00000e90 65 20 63 61 72 65 2e 0d 0d |e care...| 00000e99
F/+HINT1.m0
