DIAGRAM
The main problems with a disk based magazine are illustratiions and
diagrams. This is a shame because computers especially the Elk are quite
good at drawing if you can get a program.
I have written this program to do just that. Now I would like to be able
to say that I am an experienced programmer and I knocked this up in the
commercial break during Blakes 7but it wouldn't be true. In fact this is
the biggest thing I have ever done.
I make no apologies for its limitations. It was designed to be simple.
It will draw vertical horizontal and diagonal lines. The angle of the
diagonals can be varied.
It also has a facility for text input.
The keys are:
Up / Down / Left / Right : Arrow keys.
Diagonals: Up Left : FUNC O
Up Right : FUNC P
Down Left : FUNC K
Down Right : FUNC L
Text : FUNC T
LOAD : FUNC <
SAVE : FUNC >
PRINT : FUNC /
Vary Angle : + FUNC A
: - FUNC Z
Vary Speed : + FUNC S
: - FUNC X
The keys needed to use the program are written at the bottom of the
screen as are indicators of the angle, the pen position and if it is up
or down.
The drawing can be saved and reloaded again to do further work.
The indicator of speed and angle are initially both set at 5. For speed
this indicated the number of individual pixels drawn with each keypress.
In the case of the size of the angle this should be considered an
arbitory figure mainly to compare with any changes you set. When you
alter the speed with FUNC S / X the figure for angle also increases at
the same rate but the angle drawn will remain the same unless you vary
the angle itself with FUNC A / Z. This is a problem with the maths in
the program. to correct this will slow the program down. You will soon
get use to it.
It does not use different colours mainly because these can be difficult
to print on paper even with a colour printer.
When I started I set a number of criteria.
1. It should be simple to use. Some programs have manuals which can take
hours to digest. Diagram should be understood by almost anyone in a few
minutes.
2. It must have a clear programming style to enable users to adapt or
improve it easily. This meant using procedures wherever possible. Each
procedure clearly labled, each function using one procedure.
3. It must be able to draw fine detail. I have used mode 0 and the speed
of the cursor movement; and therefore the length of each keypress can be
varied as I said before.
4. It must be possible to reLOAD a file for further work.
5. It must be possible to load a file independent of Diagram. This can be
done by switching to MODE0 and *LOADing the file.
ie 10 MODE0
20 *LOAD <file>
Addresses are not important.
Some problems for you to work on:
There is no facility to delete lines once they are drawn. This should be
quite easy to setup.
If you try to load or save a file with a name preceeded by any spaces the
program will crash. I have turned on the cursor during LOADing, SAVEing
and Text to indicate if any spaces might be likely. If so delete them
before entering a file name. The spaces occur because the auto repeat has
been reset with *FX11,20.
The pen is always up after text input. This is necessary because a line
is drawn otherwise before the end of the procedure.
The size of the angle is indicated by 5 = 45 degrees and so on.
If someone could devise a cursor which would be seen even when the pen
is up the program would be easier to use.
Some enhancments needed:
Printer dumps. I am working on a printer dump for my Star LC10 printer.
It should work with any Epsom FX80 compatable but other printers may need
different dumps. This is definitely over to you. If you have a dump for
your printer SEND IT IN
Icons: Sets of icons might be very useful. These might be programmed
using VDU codes but in mode0 will be very small.Other larger icons might
be more useful, say furniture outlines to allow diagrams of a room
layout to be made, electronic symbols would suit those of us into
electronics, some fancy letters. These can be put into the numeric
function keys or the spare letter keys which have all been reset with
*FX226 and *FX227. See page 283 of the Elk User Guide.
The purpose of Diagram is for you to illustrate your submissions to EUG.
Diagram is ready for use now. Use it. It will seem a little fiddely and
slow, certainly not like a pen and paper. But do use it. Draw a diagram
of the layout of your computer setup, any problems you may have. Draw
something for the practical ideas section, if there needs to be a lot of
text write your text on your word processor making reference to the
diagram, then draw your diagram. Send in both files. My wife has just
suggested drawing a cartoon joke. Most of us could do with a laugh and
since few of you are ever likely to see my car a cartoon would be the
next best thing.
SEND IT IN
I have drawn a cartoon called Cartoon. You can load it into Diagram or
move to MODE0 and *LOAD it. I first sketched the outline onto paper. then
as I drew each line I noted the X and Y positions at the start and end of
each line drawn. This helped with correctly joining up lines as required.
And remember a file can be re-LOADed and further work done on it so you
don't need to spend ages trying to finish. Start something now and save
it again for later.
SEND IT IN.
