6. Cables, you will need the following cables:
1. 50 way to 50 way IDC to go from the host adaptor to
the disk controller (typically 6")
2. 34 way to 34 way IDC to go from the BBC's 1MHz bus to
host adaptor (typically 3')
3. 34 way IDC to 34 way edge connector for drive control
signals to controller card (typically 12")
If you are using a WD 1002 controller this is an edge
to edge connector lead
4. 20 way IDC to 20 way edge connector for drive data
signals to controller card (typically 12")
Using a Winchester on the Beeb has absolutely nothing to do with any
floppy disk controller that you may have fitted be it 8271, 1770 or any
other. If you have something other than a 1770 controller then you might
consider changing to one but it is not necessary. The BBC B+ and Master
have the 1770 fitted (or the 1772 which is similar), for the BBC B you can
fit the Acorn 1770 board or the Solidisk DDFS or DFDC boards (Issue 2).
The advantage of using the 1770 is that ADFS can work with it on floppies
as well as with the Winchester controller. For compatibility with the
older DFS's Acorn's 1770-DFS, or Solidisk's STL-DFS 2.2 can be used.
The layout of "drive numbers" under ADFS is as follows (when a Winchester
is fitted):
Drive Drive Handled Description
Number Letter by
0 A Controller 1st SASI device (LUN=0), 1st Winny
1 B Controller 2nd SASI device (LUN=1), 2nd Winny
2 C Controller 3rd SASI device
3 D Controller 4th SASI device
4 E 1770 First floppy
5 F 1770 Second floppy
6 G -
7 H -
(note a floppy drive under ADFS is a unit, not a surface like DFS, a drive
can have 1 or two sides and 40 or 80 tracks).
Basically references to "drive numbers" of 4 or higher are passed to code
within ADFS which uses the 1770/1772 controller chip in the Beeb/Master
and pretends to be a SASI compatible controller, while "drive numbers" of
0 to 3 are used to generate requests for I/O to a SASI device responding
to the equivalent LUN on one of the controller(s) connected (see
discussion of LUNs above).
The BBC micro/Master computers support Acorn's Winchester disk units,
which are connected via the 1MHz bus. The Advanced User Guide shows that
memory locations $FC40 to $FC47 are set aside for Winchester disk units
(these are located in page FRED).
A host adaptor on these machines requires 4 bytes of memory space, as 8
bytes are reserved it is believed that two controllers can be mapped on
to the system.
Two winchester drives have been used successfully on one controller, and
as expected they appear as drive 0 and 1. Unfortunately ADFS 1.30 on the
BBC B/B+ doesn't support a second host adaptor, probably because there was
not sufficient space in the ROM for the extra code, we can only hope that
Acorn will implement the extra code one day??? Note Sun,19 Apr 1987 :
Rumour has it Acorn are doing just that !
The memory map looks like this:
Controller Address Read Write
0 FC40 Data Data
FC41 Status -
FC42 - Select
FC43 - Interrupt latch
1 FC44 Data Data
FC45 Status -
FC46 - Select
FC47 - Interrupt latch
Providing you have your power supply, winchester drive, ADFS ROM,
controller card and cables, the sticking point is the host adaptor - the
host adaptor connects the standard SASI controller to the BBC, it sorts
out the addressing, buffering and inverts the data bus (SASI uses negative
logic).
Acorn do not sell parts of their Winchester disk system - you cannot buy
just the host adaptor. A number of other companies now sell complete
Winchester disk systems (Amcon, Viglen, Technomatic, Midwich etc.) they
have had to design and manufacture their own host adaptors, it is just
possible that they might sell the host adaptor separately. If they do
then it should cost you around, say, `50 maximum - any more would be
scandalous.
If you can't buy a host adaptor then you have to resort to building one...
the next part of this note deals with building a Host Adaptor. Fig. 1 is
the circuit diagram of a modified version of Acorn's host adaptor, it can
be built for around `35. Double sided PCBs are available from the author
for `15.00 plus `1.00 P&P, these boards are being made in small quantities
only, by hand, hence the price.
How it works
IC5 (74LS245), IC6 (74LS138) and IC7 (74LS138) perform the address line
buffering and decoding, S1 provides a link selectable setting for
controller 0 or controller 1 (base address FC40 or FC44). The output of
the address decoder provides eight lines (active low), four for read and
four for write (shown for controller 0 on the diagram).
IC1 (74LS245) buffers the data bus continuously, IC2 (73LS373) is used to
latch data that is written to the controller. Write data is inverted by
IC13/14 when enabled by the I/O control signal from the controller card.
IC13/14 (7438) are open collector output devices that drive the SASI data
port (pins 2 to 16).
Data is read from the controller card, inverted and buffered by IC3
(74LS240). Controller status is inverted by individual Schmitt inverters
in IC15 (7414) and latched and buffered by IC4 (74LS373). Acknowledge
(ACK) signals are provided automatically after a Request from the
controller when a read or write to the data port is performed. Select
(SEL) is driven automatically by the Busy (BSY) status from the
controller.
An unusual interrupt generating arrangement is also incorporated, a set
reset flip flop, IC12, is set every time a Request (REQ) is received from
the controller, and is cleared when a "1" is written to bit of the
interrupt latch, half of IC10. This allows interupts from the controller
to be ignored during block read/write operations but to be enabled during
byte read/write and provide the necessary handshaking between the host and
the controller.
The host adaptor connects to the 1MHz bus via a length of 34 way ribbon
cable and to the host adaptor via a length of 50 ribbon cable. IDC
connectors or cheaper pin headers (available from Farnell) may be used. A
power connector (similar to those used on floppy drives) is provided for
connection of +5v (no 12v supply is required). The power rails are
decoupled at every chip by small 0.1uF capacitors.
