READY MADE RAMFS BOARDS
HAVING released both the RAMFS software and circuit diagrams to EUG to
build an 8M RAM disk over the past few EUG issues, anyone who still
hasn't had the nerve to built it on strip board can now order the board
ready made!
The next few paragraphs describe the board's features so if you're
not really that bothered about the ins and outs skip straight to the
bottom line...
As I hinted in the original article, you can eliminate three chips by
replacing the read buffer and write latches (74LS373 and 74LS241) with
read back latches, in particular the 74ALS990 is suitable.
By choosing surface mounted components instead of through hole DIL
parts the board size can be further reduced to just 3" by 3.5" which in-
cludes a full Megabyte of RAM. The filing system supports up to 8 Mega-
bytes and a fully decoded address signal is available on a 21 way header
should you need it.
Optional terminating resistors may be fitted if there are no other
devices plugged into the 1MHz bus, or these can be omitted and the
integral loop through connector used to "daisy chain" the other 1MHz bus
devices together.
A 1.3mm power plug supplies the board with +5v, though there are
tracks for an optional voltage regulator if some other supply (eg. +12v)
is closer to hand.
Two 32 pin sockets to use either 1x4Mbit, 1x1Mbit, 2x4Mbit or 2x1Mbit
chips depending on how much RAM is around 130mA average during RAM
accesses.
Building the board is simply a matter of placing the parts as detail-
ed in the article in this issue, though confidence with surface mount
parts is essential!
---------------------------------
The bottom line
---------------------------------
THESE boards are available now, and you'll find a photo of both my
stripboard prototype and the finished PCB online at www.sprow.co.uk/bbc
Pricing:
OPTION 1: The blank PCB, you source the components (Maplin, Farnell,
etc), you build the board as per the article on this disk, plug it in
and away you go: 18.00 GBP + 0.54 P&P
OPTION 2: The blank PCB plus all of the components, you build the board
as per the article on this disk, plug it in and away you go: 40.00 GBP
+ 0.81 P&P. With the 128k byte option, add 8.00 GBP. With the 256k byte
option, add 16.00 GBP. With the 512k byte option, add 22.00 GBP. With
the 1Mbyte option, add 44.00 GBP.
OPTION 3: The blank PCB plus the 74ALS990 latches, in case you find the
latches hard to find. You source the remaining components (Maplin, Far-
nell, etc), you build the board as per the article, plug it in and away
you go: 27.00 GBP + 0.54 GBP P&P.
OPTION 4: Buy the finished board. The option if you're not happy work-
ing with surface mount. Receive a built and tested board, plug it in
and away you go. 64.00 GBP + 0.81 GBP P&P. With the 128k byte option,
add 8.00 GBP. With the 256k byte option, add 16.00 GBP. With the 512k
byte option, add 22.00 GBP. With the 1Mbyte option, add 44.00 GBP.
Kits of parts and finished boards contain everything except the cost of
the RAM, the optional voltage regulator, and the one optional address
decoder chip.
Unfortunately the economies of scale don't really help here, so
unless someone buys about twenty of these the price will be quite high -
the PCB alone has to recoup the one off tooling charges. For most I
think the 256k option is enough (a Beeb disk only holds 200k anyway!).
Component prices are based on Farnell 'one off' prices. I'm quite
sure the resourceful among you can find parts cheaper - so feel free to
use option 3 if you think you can...
In any case, get your orders in quickety quick!
Robert Sprowson
6 Bollinbrook Road, Macclesfield, CHESHIRE SK10 3DJ
EUG #56
