Filename: BioBot/BB3
Read OK:
File size: 1876 bytes
Load address: FFFFFB45
Exec address: ABC07728
Duplicates

There are 2 duplicate copies of this file in the archive:

File contents
    0 REM DELETE 1535,1725,1481-1484
   10 REM BallBot V1.0
   20 REM (C) Dominic Ford 1997
   30:
   40 REM Setup variables
   50 VOICE 1,"StringLib-Soft":*STEREO 1 0
   60 VOICE 2,"StringLib-Soft":*STEREO 2 -127
   70 VOICE 3,"StringLib-Soft":*STEREO 3 127
   80 DIMball(4,1):PROCsetupbb
   90 :
  100 REM Start main loop
  110 REPEAT
  120 PROCsense
  130 mov=FNai(freqa,freqb,freqc)
  140 fwd=(mov AND 1)<>0
  150 reverse=(mov AND 2)<>0
  160 left=(mov AND 4)<>0
  170 right=(mov AND 8)<>0
  180 PROCmoveit
  190 UNTIL FALSE
  200 :
  210 REM Graphic interface
  220 DEFPROCdrawfull
  230 MODE0:GCOL0,1:RECTANGLE0,0,1279,1023
  240 MOVE 640,100:DRAW 640,924
  250 PROCdrawmini
  260 ENDPROC
  270 :
  280 REM Draw ballbot and balls
  290 DEFPROCdrawmini
  300 GCOL3,1:FORb=0TO4
  310 IF ball(b,0)<>0 OR ball(b,1)<>0 THEN POINT ball(b,0),ball(b,1)
  320 NEXT
  330 GCOL3,1:POINTbbx,bby
  340 ENDPROC
  350 :
  360 REM Reset to test a new biobot
  370 DEFPROCrestart
  380 stage=0:bbx=640:bby=950:dir=270
  390 FORr=0TO4:REPEAT:ball(r,0)=100+RND(1000):ball(r,1)=100+RND(800)
  400 IF ball(r,0)<670 AND ball(r,1)>620 THEN UNTIL FALSE
  410 UNTIL TRUE:NEXT
  420 PROCdrawfull
  430 ENDPROC
  440 :
  450 REM Calculate ballbot's new position
  460 DEFPROCmoveit
  470 IF left THEN dir=dir-5
  480 IF right THEN dir=dir+5
  490 fr=0:IF fwd THEN fr=fr+1
  500 IF reverse THEN fr=fr-1
  510 PROCdrawmini:bbx=bbx+5*SIN(PI*dir/180)*fr
  520 bby=bby+5*COS(PI*dir/180)*fr:PROCdrawmini
  530 ENDPROC
  540 :
  550 REM Calculate ballbot's background echo reading (-balls)
  560 DEFFNback(x,y,freq)
  570 REM Calculate Angle of net as seen by Ballbot
  580 LOCAL freqa
  590 netlow=(FNangle(640,923,x,y)-dir) MOD 360
  600 IF netlow<0 THEN netlow=netlow+360
  610 IF netlow>180 THEN netlow=netlow-360
  620 nethi=(FNangle(640,100,x,y)-dir) MOD 360
  630 IF nethi<0 THEN nethi=nethi+360
  640 IF nethi>180 THEN nethi=nethi-360
  650 :
  660 REM Calculate reading
  670 freqa=freq+RND(6)-3
  680 IF ABS(SIN(PI*dir/180))>0.01 THEN IF ((netlow<0 AND nethi>0) OR (nethi<0 AND netlow>0)) AND (640-x)/SIN(PI*dir/180)>0 THEN freqa=(640-x)/SIN(PI*dir/180)
  690 =freqa
  700 :
  710 REM Calculate Ballbot's readings (MAIN ROUTINE)
  720 :
  730 DEFPROCsense
  740 REM Get background readings from FNback
  750 freq=RND(250)+1500
  760 freqa=FNback(bbx,bby,freq)
  770 dir=dir-5:freqb=FNback(bbx,bby,freq)
  780 dir=dir+10:freqc=FNback(bbx,bby,freq):dir=dir-5
  790 :
  800 REM Add any relevant balls to readings (using hairy trigonometry)
  810 :
  820 FORball=0TO4
  830 d%=SQR((ball(ball,0)-bbx)^2+(ball(ball,1)-bby)^2)
  840 IF ball(ball,0)=0 THEN d%=9999
  850 a%=FNangle(ball(ball,0),ball(ball,1),bbx,bby)-dir
  860 IF ABS(a%)<5 AND freqa>d% THEN freqa=d%
  870 IF a%>-16 AND a%<-5 AND freqb>d% THEN freqb=d%
  880 IF a%>5 AND a%<16 AND freqc>d% THEN freqc=d%
  890 NEXT
  900 :
  910 REM Update user displays
  920 :
  930 PRINTTAB(0,31)bbno,gen,tryno,counter;
  940 SOUND 1,-10,freqa/4,5:SOUND 2,-10,freqb/4,5:SOUND 3,-10,freqc/4,5
  950 ENDPROC
  960:
  970 REM Calculate bearing of B from A
  980 DEFFNangle(x1,y1,x2,y2)
  990 ang=180*ATN((x2-x1)/(y2-y1))/PI
 1000 IF (y2>y1) THEN ang=ang+180
 1010 =ang MOD 360
 1020 :
 1030 REM General maintainence and refereeing (no going THROUGH the net!)
 1040 :
 1050 DEFPROCreferee
 1060 IF bbx>630 AND bbx<650 AND bby>100 AND bby<923 THEN idle=TRUE:REM Death penalty!
 1070 IF bbx<0 OR bbx>1280 THEN idle=TRUE
 1080 IF bby<0 OR bby>1024 THEN idle=TRUE
 1090 FORball=0TO4
 1100 IF ABS(bbx-ball(ball,0))<10 AND ABS(bby-ball(ball,1))<10 THEN PROCdrawmini:ball(ball,0)=0:PROCdrawmini
 1110 NEXT
 1120 ENDPROC
 1130 :
 1140 REM Give ballbot a score at the end of a run
 1150 :
 1160 DEFFNscr
 1170 score=0:IF ball(0,0)=0 THEN score=score+20
 1180 IF ball(1,0)=0 THEN score=score+20
 1190 IF ball(2,0)=0 THEN score=score+20
 1200 IF ball(3,0)=0 THEN score=score+20
 1210 IF ball(4,0)=0 THEN score=score+20
 1220 =score
 1230 :
 1240 REM BioBot Evolutionary Learning Routine
 1250 :
 1260 REM Main AI system
 1270 :
 1280 DEFFNai(A1,A2,A3)
 1290 REM Artificial intelligence routines (ie. What Next??)
 1300 counter=counter+1:IF counter=1000 OR idle=TRUE THEN PROCnext(FNscr):=0
 1310 :
 1320 n%(1)=(A1<40):n%(2)=(A1-o1)>40:n%(3)=(A1-o1)<-40
 1330 n%(4)=(A2<40):n%(5)=(A2-o2)>40:n%(6)=(A2-o2)<-40
 1340 n%(7)=(A3<40):n%(8)=(A3-o3)>40:n%(9)=(A3-o3)<-40
 1350 FORl=0TO1:FORma=0TOlinks-1
 1360 IFm%(bbno,ma,0)=1 AND n%(m%(bbno,ma,1))<>0 AND n%(m%(bbno,ma,2))<>0 THEN n%(m%(bbno,ma,3))=1
 1370 IFm%(bbno,ma,0)=2 AND (n%(m%(bbno,ma,1))<>0 OR n%(m%(bbno,ma,2))<>0) THEN n%(m%(bbno,ma,3))=1
 1380 IFm%(bbno,ma,0)=3 AND n%(m%(bbno,ma,1))=0 THEN n%(m%(bbno,ma,3))=1
 1390 IFm%(bbno,ma,0)=4 AND (n%(m%(bbno,ma,1))<>0 EOR n%(m%(bbno,ma,2))<>0) THEN n%(m%(bbno,ma,3))=1
 1400 IFm%(bbno,ma,0)=5 AND n%(m%(bbno,ma,1))<>0 THEN n%(m%(bbno,ma,3))=1
 1410 NEXT,
 1420 REM Calculate outputs
 1430 o1=A1:o2=A2:o3=A3:PROCreferee
 1440 R%=0:FORz=1TOtotalout:R%=2*R%-(n%(no%-totalout+z)<>0):NEXT
 1450 REM R%=ABS(INKEY(-71)+2*INKEY(-102)+4*INKEY(-98)+8*INKEY(-67))
 1460 REM If biobot is doing nothing, give up.
 1470 IF tns%=0 AND R%=0 THEN idle=TRUE
 1480 tns%=R%
 1481 :
 1482 IF bbx=olx AND bby=oly THEN idle=TRUE
 1483 olx=bbx:oly=bby
 1484 :
 1490 =R%
 1500 :
 1510 REM Next attempt by this biobot (each has ten)
 1520 :
 1530 DEFPROCnext(score)
 1535 olx=1:oly=1
 1540 PROCuser:PROCrestart
 1550 s%(bbno)=s%(bbno)+score/attempts:counter=0:idle=FALSE
 1560 FORc=0TOno%:n%(no%)=0:NEXT:tns%=1
 1570 tryno=tryno+1:IF tryno<attempts THEN ENDPROC
 1580 tryno=0:bbno=bbno+1:IF bbno=10 THEN PROCgeneration
 1590 PROCnewbb
 1600 ENDPROC
 1610 :
 1620 REM Test next biobot
 1630 :
 1640 DEFPROCnewbb
 1650 o1=0:o2=0:o3=0:tns%=1
 1660 idle=FALSE:scr=0:tryno=0
 1670 PROCrestart:counter=0
 1680 ENDPROC
 1690 :
 1700 REM Setup BioBot system (for the first time)
 1710 :
 1720 DEFPROCsetupbb
 1725 olx=1:oly=1
 1730 bbno=0:gen=0:PROCnewbb
 1740 totalin=9:analogues=3:switches=0:totalout=4:mem=8:attempts=5
 1750 no%=totalin+totalout+mem:links=12
 1760 DIMm%(10,links-1,3):DIMn%(no%):DIMs%(9)
 1770 s%(1)=1:m%(1,1,0)=3:m%(1,1,1)=1:m%(1,1,3)=no%:m%(1,2,0)=5:m%(1,2,1)=1:m%(1,2,3)=no%-1:PROCgeneration
 1780 ENDPROC
 1790 :
 1800 REM Select best biobot of generation
 1810 :
 1820 DEFPROCgeneration
 1830 winner=0:score=s%(0)
 1840 FORs=0TO9:IF s%(s)>score THEN score=s%(s):winner=s
 1850 NEXT
 1860 :
 1870 REM Breed more biobots from best one
 1880 :
 1890 FORx=0TOlinks-1:FORy=0TO3:m%(10,x,y)=m%(winner,x,y):NEXT,
 1900 FORz=0TO9:FORx=0TOlinks-1:FORy=0TO3:m%(z,x,y)=m%(10,x,y):NEXT,,
 1910 :
 1920 REM Add a bit of variation
 1930 :
 1940 FORn=0TO100-score:z=RND(10)-1:x=RND(links)-1:m%(z,x,0)=RND(6)-1:m%(z,x,1)=RND(no%):m%(z,x,2)=RND(no%):m%(z,x,3)=RND(no%):NEXT
 1950 :
 1960 REM Initialise ready for generation test
 1970 bbno=0:gen=gen+1
 1980 FORs=0TO9:s%(s)=0:NEXT
 1990 ENDPROC
 2000:
 2010 REM User interface for BioBot system
 2020 :
 2030 DEFPROCuser
 2040 f$=INKEY$(0)
 2050 IF f$="D" THEN PROCdisp
 2060 IF f$="S" THEN PROCsave
 2070 ENDPROC
 2080 REM Display best biobot's genetic information
 2090 DEFPROCdisp
 2100 CLS:FORz=0TOlinks-2:PRINTz+1,m%(10,z,0),m%(10,z,1),m%(10,z,2),m%(10,z,3):NEXT
 2110 PRINTlinks,m%(10,links-1,0),m%(10,links-1,1),m%(10,links-1,2),m%(10,links-1,3);
 2120 VDU 7:REPEAT UNTIL INKEY$(0)=""
 2130 REPEAT UNTIL INKEY$(0)<>""
 2140 ENDPROC
 2150 REM Save best biobot to disc
 2160 DEFPROCsave
 2170 file=OPENOUT"BBF"
 2180 FORz=0TOlinks-1:PRINT#file,z+1,m%(10,z,0),m%(10,z,1),m%(10,z,2),m%(10,z,3):NEXT
 2190 CLOSE#file
 2200 ENDPROC
