Filename: Q.SfEcho
Read OK:
File size: 0C76 bytes
Load address: FFFF1900
Exec address: FFFF801F
Duplicates

There are 3 duplicate copies of this file in the archive:

File contents
   10PRINT"BEEB BODY BUILDING COURSE"
   20PRINT"Serial Sound Sampler"
   30PRINT"Echo Chamber"
   40PRINT:PRINT"Using Internal Sound Chip"
   50PRINT"By Mike Cook"
   60PRINT
   70PRINT"Calculating look up table"
   80V=15/LOG(255)
   90P%=&900
  100FOR A%=1 TO 255
  110?P%=15-INT(LOG(A%)*V)
  120P%=P%+1
  130NEXT
  140?&900=15
  150MODE 1
  160*KEY10 OLD|M RUN|M
  170FOR PASS=0 TO 2 STEP 2
  180P%=&A00
  190[
  200OPT PASS
  210.SETUP \ INITILISE
  220SEI \ DISABLE INTERRUPTS
  230LDA #&40
  240LDY #0
  250LDX #&30
  260STA &FE6B \ ENABLE TIMER 1
  270LDA #&C0
  280STA &FE6E \ ENABLE INTERRUPT
  290LDA #0
  300STA &FE65 \ START IT OFF
  310RTS
  320.ECHO
  330JSR SETUP:JSR INIT
  340.LOOP
  350LDA (&72),Y \ GET VALUE TO OUTPUT
  360JSR SND1 \ OUTPUT IT
  370.HOLD
  380LDA &FE6D \ GET INTERRUPT FLAG
  390BPL HOLD \ LOOP UNTIL TIME OUT
  400STA &FE6D \ CLEAR INTERRUPT
  410JSR sin
  420STA (&72),Y
  430INY \ MOVE POINTER ON
  440BNE LOOP \ LOOP FOR ANOTHER
  450INC &73 \ MOVE INPUT POINTER
  460LDA &70 \ GET LIMIT
  470CMP &73 \ HAS INPUT POINTER REACHED IT
  480BNE LOOP \ BRANCH IF NOT
  490LDX #&30
  500STX &73 \ RESET IT
  510JMP LOOP
  520.sin \ SAMPLE IN
  530LDX #10:LDA #0
  540STA &FE60 \ CS AND CLOCK LOW
  550.SLOOP
  560LDA &FE60 \ GET DATA
  570LSR A:ROL &80 \ MOVE INTO MEMORY
  580LDA #2:STA &FE60 \ CLOCK HIGH
  590LDA #0:STA &FE60 \ CLOCK LOW
  600DEX : BNE SLOOP
  610LDA #6: STA &FE60
  620LDA &80 \ GET SAMPLE
  630RTS
  640.BACK
  650JSR SETUP:JSR INIT
  660.LOOPB
  670LDA (&74),Y \ GET VALUE TO OUTPUT
  680JSR SND1 \ OUTPUT IT
  690DEC &74 \ REDUCE OUTPUT POINTER
  700LDA #&FF
  710CMP &74 \ TEST FOR WRAP AROUND
  720BNE SKIP1 \ BRANCH IF NOT OVER PAGE
  730DEC &75 \ DECREMENT PAGE
  740LDA #&30 \ SEE IF IT HAS REACHED THE END
  750CMP &75
  760BNE SKIP1 \ BRANCH IF IT HAS NOT
  770LDA &70 \ GET LIMIT
  780STA &75 \ MAKE OUTPUT POINTER LIMIT
  790.SKIP1
  800JSR sin \ GET INPUT SAMPLE
  810STA (&72),Y
  820INC &72 \ MOVE ON INPUT POINTER
  830BNE SKIP2
  840INC &73 \ MOVE ON PAGE
  850LDA &70 \ GET LIMIT
  860CMP &73 \ HAS INPUT POINTER REACHED IT
  870BNE SKIP2 \ BRANCH IF NOT
  880LDA #&30 \ PUT POINTER BACK TO START
  890STA &73
  900.SKIP2
  910LDA &FE6D \ GET INTERRUPT FLAG
  920BPL SKIP2 \ LOOP UNTIL TIME OUT
  930STA &FE6D \ CLEAR INTERRUPT
  940JMP LOOPB
  950.INIT \ INITILISE SOUND CHIP
  960LDA #&FF:STA &FE43
  970LDA #&84:JSR SND
  980LDA #&00:JSR SND
  990LDA #&A4:JSR SND
 1000LDA #&00:JSR SND
 1010LDA #&C4:JSR SND
 1020LDA #&00:JSR SND
 1030LDY #0
 1040RTS
 1050.SND
 1060STA &FE4F
 1070LDX #&00:STX &FE40
 1080NOP:NOP:NOP:NOP:NOP:NOP
 1090LDX #&08:STX &FE40
 1100RTS
 1110.SND1
 1120TAX
 1130LDA &900,X \ CONVERT TO LOG
 1140ORA #&90:JSR SND
 1150ORA #&20:JSR SND
 1160EOR #&60:JSR SND
 1170RTS
 1180]
 1190NEXT
 1200CLS
 1210PROC_INSTRUCTIONS
 1220IF R%=0 THEN R%=180
 1230?&FE66=R%
 1240?&FE62=6
 1250?&72=&00:?&74=&00
 1260?&73=&30:?&75=&30
 1270REPEAT
 1280PROC_UPDATE
 1290A$=GET$
 1300IF A$="B" THEN ?&70=F%+&30:?&75=?&70:CALL BACK
 1310IF A$="E" THEN ?&70=F%+&30:CALL ECHO
 1320IF A$="R" THEN INPUT"Sample Rate ",R%:?&FE66=R%
 1330IF A$="L" THEN PROC_BLEN
 1340UNTIL FALSE
 1350DEF PROC_BLEN
 1360REPEAT
 1370INPUT"Buffer length in pages (1 to 80) ",L%
 1380UNTIL L%>0 AND L%<81
 1390IF L%=80 THEN L%=0
 1400ENDPROC
 1410DEF PROC_UPDATE
 1420PRINT TAB(0,14)
 1430PRINT "Sample rate delay :- ";R%
 1440PRINT
 1450 IF L%=0 THEN F%=80 ELSE F%=L%
 1460PRINT "Buffer length ";F%/4;"K bytes"
 1470PRINT TAB(0,20);SPC(40)
 1480PRINT TAB(0,19)
 1490ENDPROC
 1500DEF PROC_INSTRUCTIONS
 1510PRINT
 1520PRINT"BEEB BODY BUILDING COURSE"
 1530 PRINT"Echo Chamber"
 1540PRINT:PRINT"Using Internal Sound Chip"
 1550PRINT"By Mike Cook"
 1560PRINT
 1570PRINT"Options are:-"
 1580PRINT"E  - Enter the echo chamber"
 1590PRINT"B  - Backwards echo"
 1600PRINT"R  - Rate of digitising"
 1610PRINT"L  - Length of buffer"
 1620PRINT"Break to return"
 1630ENDPROC
