section "EXMP3"
get "exmphdr"
// This section of EXAMPLE contains the procedure to
// display the voltages of the four analogue inputs.
manifest $( col.red = 0 // logical colours used
col.white = 1
col.blue = 2
col.cyan = 3
$)
// VOLTMETER displays the voltages read from the four analogue input channels
// as vertical bars.
let voltmeter() be
$( let prevpos = vec 4 // previous position of top of bar
// Select screen mode 5.
unless mode(5) then
$( let endt = time() + 500 // show message for 5 seconds
if endt < 0 then endt := endt + #X8000
// allow for wrap-round
wrbin(12) // clear screen
writes("Cannot select mode 5.*N")
writes("When '!' appears type:*n")
writes("*x88SHUFFLE*x89*nand press*x88RETURN*n")
writes("then re-run this program.*n")
until time() = endt loop
stop(0) // exit
$)
// Define logical colours.
vdu("19,%,1;0;", col.red)
vdu("19,%,7;0;", col.white)
vdu("19,%,4;0;", col.blue)
vdu("19,%,6;0;", col.cyan)
// Display fixed text etc.
dofixed()
for i=1 to 4 do prevpos!i := 224 // initialise to 0v.
// Loop round each channel in turn, reading the value and
// updating the display.
$( for i = 1 to 4 do
// Value is read as number between 0 (=0v) and 65520 (=1.8v).
// Convert it to y co-ord of top of bar (224=0v; 685=1.8v).
// When converting shift value right to avoid values > 32767
// being treated as negative.
$( let endpos = 224 + muldiv(adval(i) >> 1, 462, 32760)
let xpos = 256*i + 132 // 'x' for left of bar
// If new bar is same length as before do nothing. If new bar is
// shorter then erase top of existing bar by drawing it in the
// background colour. If new bar is longer draw the extra bit only.
unless endpos = prevpos!i do
drawbar(xpos, endpos, prevpos!i,
(endpos < prevpos!i -> col.blue, col.cyan)
)
prevpos!i := endpos // remember new position
// See if DELETE was pressed and return if so. (*FX129 with
// -ve parameter checks if specied key is pressed.)
if opsys(129, -90, #xFF) ~= 0 return
$)
$) repeat
$)
// DOFIXED sets up the fixed part of the display.
and dofixed() be
$( hidecursor()
// Set up a red background then define a graphics window and
// initialise it to blue.
colour(128+col.red)
wrbin(12) // clear text screen
vdu("24,256;224;1279;1023;")
gcol(0, 128+col.blue)
wrbin(16) // clear graphics area
colour(col.white) // write text in white
txtcursor(6, 0); writes("VOLTMETER")
txtcursor(1, 2); wrch('V')
for i = 0 to 5 do
$( txtcursor(0, 24-4*i) // write scale in format x.x
writef("%i1.%i1", (5*i)/10, (5*i) rem 10)
$)
txtcursor(0, 27); writes("CHN: 1 2 3 4")
txtcursor(1, 31); writes("Hit DELETE to exit")
plotgrid()
$)
// DRAWBAR draws or deletes a bar. Comments assume XPOS is
// the x co-ord of the left of the bar ,YLOW is the y co-ord
// of the bottom, YHI is the y co-ord of the top and COL is
// the colour. In fact YLOW and YHI may be reversed.
and drawbar(xpos, ylow, yhi, col) be
$( gcol(0, col) // select colour
plot(4, xpos, ylow) // move to bottom left
plot(5, xpos+64, ylow) // draw to bottom right
plot(85, xpos+64, yhi) // fill triangle to top right
plot(5, xpos, yhi) // draw to top left
plot(85, xpos, ylow) // fill triangle to bottom left
plotgrid() // redraw grid in case lines were overwritten
$)
// PLOTGRID plots the horizontal lines every 0.5 volots.
and plotgrid() be
$( gcol(0, col.white) // write graphics in white
for i = 0 to 5 do
$( plot(4, 256, 224+i*128) // move to left endpoint
plot(17, 1024, 0) // draw dotted to right endpoint
$)
$)
.
