�PBoff
TRACKER DISSASSEMBLER
~~~~~~~~~~~~~~~~~~~~~
By Richard Dimond
This is the dissassembler that I use for all my machine coding and I find
it very useful. Now that I have a Master, I found that it needed some
small modifications to make it work satisfactorily.
The first thing was to set up CHR$255 using VDU23 as needed on the Master
and this was done by changing line 1000. The program set up the character
by simply setting up the bytes CF8 - CFF which can be done with the Elk.
The inversion of the colours of the flags was done by EORing the bytes of
CF8 - CFF. I have modified the line 210 to use the COLOUR command.
The code is written to &72C0 and thus occupies the lower half of the MODE
6 screen. This can be avoided by switching on your MRB if you have this
or using MODE 134 on th Master.
To use the program, you must enter MODE 6 (or MODE 134) first to clear the
screen before running the program as it will not work if the screen has
scrolled. The program can then be run by *TRACKER.
The keys to use are -
A - to enter a new address (in hex)
F - to move forward 256 bytes
B - to move Backward 256 bytes
J - to toggle JSR on/off
M - to toggle JMP on/off
P - to toggle the printer on/off
Any other key will advance to the next op code
ESCAPE will break out of the program but you can start up again by the
command *GO. This uses a vector change so, if you are finished with the
program, there is a command *RID for resetting the vectors to normal.
If you want to start the program at a certain address, you can set D% to
this address before calling the program.
I have found that, when using the printer, you need a buffer large enough
to hold all the coding you wish to print and, when this is loaded into the
buffer, you then need to press BREAK to start the printer.
**************************************************************************
