Server1/!Mandel/!RunImage

Home » Personal collection » Acorn ADFS disks » Archimedes » IJJOBS21.ADF » Server1/!Mandel/!RunImage

This website contains an archive of files for the Acorn Electron, BBC Micro, Acorn Archimedes, Commodore 16 and Commodore 64 computers, which Dominic Ford has rescued from his private collection of floppy disks and cassettes.

Some of these files were originally commercial releases in the 1980s and 1990s, but they are now widely available online. I assume that copyright over them is no longer being asserted. If you own the copyright and would like files to be removed, please contact me.

Tape/disk:	Home » Personal collection » Acorn ADFS disks » Archimedes » IJJOBS21.ADF
Filename:	Server1/!Mandel/!RunImage
Read OK:	✔
File size:	197B bytes
Load address:	FFFFFB46
Exec address:	E7F8086E

Duplicates

There are 2 duplicate copies of this file in the archive:

Personal collection » Acorn ADFS disks » Archimedes » IJJOBS21.ADF » Server1/!Mandel/!RunImage
Personal collection » Acorn ADFS disks » Greaseweazled » adfs_IJJOBS21.adf » Server1/!Mandel/!RunImage
Personal collection » Acorn hard disk » misc » dcfprogs » Server1/!Mandel/!RunImage

File contents

   10REM Mandelbrot Set Plotter
   20REM By Dominic Ford
   30:
   40ON ERROR PROCerror:END
   50PROCassemble:CALLsetup
   60SYS "OS_ChangeDynamicArea",3,&8000
   70SYS "OS_ChangeDynamicArea",5,&30000
   80*SLOAD <Obey$Dir>.!Sprites
   90*RAM
  100*CDIR MandelWorks
  110*DIR MandelWorks
  120xpix=1024:ypix=1024:maxiters=25:cornster=1
  130XMIN=-2:XMAX=2:YMIN=-2:YMAX=2
  140DIM q% 256
  150SYS "Wimp_Initialise",200,&4B534154,"MandelPlot" TO,task_handle%
  160DIM sp% 256 , err% 256
  170!err%=0:$(err%+4)="WARNING: MandelPlot requires a RAM disc to function. DO NOT delete or alter its contents!"+CHR$0
  180SYS "Wimp_ReportError",err%,3,"MandelPlot" TO result%
  190!sp%=-1
  200sp%!4=0
  210sp%!8=0
  220sp%!12=100
  230sp%!16=68
  240sp%!20=%00010001000000000011000000101010
  250REM                     ^  ^
  260$(sp%+24)="!mandel"+CHR$0
  270SYS "Wimp_CreateIcon",,sp% TO ic%
  280REPEAT
  290SYS "Wimp_Poll",0,q% TO act%
  300CASE act% OF
  310WHEN 17,18
  320 IF q%!16=0 END
  330WHEN 6
  340 IF q%!12=-2 AND q%!16=ic% THEN
  350   PROCmandelplot
  360   SYS "Wimp_ForceRedraw",-1,0,0,1280,1024
  370   IF (result% AND 1) =1 THEN END
  380   IF ACTION=2 THEN END
  390 ENDIF
  400ENDCASE
  410UNTIL FALSE
  420:
  430DEFPROCmandelplot
  440MODE 15
  450REPEAT
  460MOUSE X,Y,C
  470UNTIL C=0
  480TERMINATE=FALSE:ACTION=FALSE
  490REPEAT
  500PROCplotter
  510IF ACTION=3 THEN PROCreposac
  520UNTIL ACTION=1 OR ACTION=2
  530ENDPROC
  540:
  550DEFPROCplotter
  560PROCscreen
  570xpixs=xpix:ypixs=ypix:XMINs=XMIN:YMINs=YMIN
  580X3=(XMAX-XMIN)/xpixs:X4=(YMAX-YMIN)/ypixs
  590stx=xpix:sty=ypix
  600REPEAT
  610stx=stx/2:sty=sty/2
  620FORB%=0TOxpixs STEP stx
  630FORC%=0TOypixs STEP sty
  640PROCcheckclick
  650IF((B%/stx) MOD 2)=0AND((C%/sty) MOD 2)=0THENNEXT,:UNTILTERMINATE=TRUE:ENDPROC
  660GCOL0,USR(mandpix)
  670MOVE B%+282,C%:MOVE B%+280+stx,C%
  680PLOT 85,B%+282,C%+sty-2:PLOT 85,B%+280+stx,C%+sty-2
  690IF TERMINATE=TRUE THEN B%=xpixs:C%=ypixs
  700NEXT,
  710UNTIL TERMINATE=TRUE
  720ENDPROC
  730:
  740DEFPROCerror
  750ON ERROR OFF
  760REPORT:PRINT" at line ";ERL
  770ENDPROC
  780:
  790DEFPROCsetp
  800PROCcheckclick
  810XB=XMINs+(X3*X)
  820YB=YMINs+(X4*Y)
  830C=0:U=XB:V=YB
  840REPEAT
  850US=U^2:VS=V^2
  860UN=US-VS+XB
  870VN=2*U*V+YB
  880U=UN:V=VN
  890C=C+1
  900UNTIL US+VS>4 OR C=maxiters
  910IFC=255THENC=0
  920GCOL0,C
  930ENDPROC
  940:
  950DEFPROCscreen
  960MOUSE ON
  970CLS
  980VDU 23,1,0;0;0;
  990GCOL 0,255:MOVE 280,0:DRAW 280,1024
 1000*SCHOOSE logo
 1010PLOT &ED,0,775
 1020COLOUR 128+127:COLOUR 0
 1030PRINTTAB(0,10);"Resize Plot Area "
 1040PRINTTAB(0,12);"Colour Cycling   "
 1050PRINTTAB(0,14);"Exit Program     "
 1060PRINTTAB(0,16);"Change Iterations"
 1070PRINTTAB(0,18);"Reposition       "
 1080ENDPROC
 1090:
 1100DEFPROCcheckclick
 1110MOUSE XMO,YMO,COL
 1120PRINTTAB(0,0);"        "
 1130IF XMO>282 THEN PROCboxout:ENDPROC
 1140IF COL=0 OR XMO>272 OR YMO>700 THEN ENDPROC
 1150ACTION=(700-YMO)/32
 1160IF (ACTION MOD 2)=1 THEN ENDPROC
 1170ACTION=INT(ACTION/2)
 1180IF ACTION=0 THEN PROCresize:ENDPROC
 1190IF ACTION=1 THEN PROCcolcycle:ENDPROC
 1200IF ACTION=2 THEN PROCexit:ENDPROC
 1210IF ACTION=3 THEN PROCchaniter:ENDPROC
 1220IF ACTION=4 THEN PROCrepos:ENDPROC
 1230ENDPROC
 1240:
 1250DEFPROCresize
 1260*SCREENSAVE screen
 1270MODE 15
 1280REPEAT
 1290REPEAT
 1300INPUT"X Screen Width (1-1024)";xpix
 1310IF xpix<0 OR xpix>1024 THEN PRINT"Out of range!"':UNTIL FALSE
 1320UNTIL TRUE
 1330REPEAT
 1340INPUT"Y Screen Width (1-1024)";ypix
 1350IF ypix<0 OR ypix>1024 THEN PRINT"Out of range!"':UNTIL FALSE
 1360UNTIL TRUE
 1370PRINT"Resize future plots to ";xpix;" X ";ypix;" ? (Y/N)"
 1380PROCask
 1390UNTIL ans=TRUE
 1400*SCREENLOAD screen
 1410MOUSE ON
 1420ENDPROC
 1430:
 1440DEFPROCcolcycle
 1450*SCREENSAVE screen
 1460speed=100:cno=0
 1470tn=TIME+speed
 1480REPEAT
 1490IF TIME>=tn THEN PROCcycle
 1500MOUSE X,Y,C
 1510UNTIL C<>0
 1520*<Obey$Dir>.!Palette
 1530*SCREENLOAD screen
 1540ENDPROC
 1550:
 1560DEFPROCcycle
 1570tn=TIME+speed
 1580cno=(cno+1) MOD maxiters
 1590FORc=0TOmaxiters
 1600VDU 19,c,(c+cno) MOD maxiters,0;0;
 1610NEXT
 1620ENDPROC
 1630:
 1640DEFPROCexit
 1650*SCREENSAVE screen
 1660MODE 15
 1670PRINT"Quit: Are you sure? (Y/N)"
 1680PROCask
 1690TERMINATE=ans
 1700IF ans=TRUE THEN PRINT"Exit task? (Y/N)":PROCask:IF ans=TRUE THEN ACTION=2 ELSE ACTION=1
 1710*SCREENLOAD screen
 1720MOUSE ON
 1730ENDPROC
 1740:
 1750DEFPROCchaniter
 1760*SCREENSAVE screen
 1770MODE 15
 1780PRINT"Maximum re-iterations at current:";maxiters'
 1790REPEAT
 1800INPUT"New maximum";maxiters
 1810REM IF maxiters<1 OR maxiters>127 THEN PRINT"Out of Range":UNTIL FALSE
 1820UNTIL TRUE
 1830!(maxit)=maxiters
 1840*SCREENLOAD screen
 1850MOUSE ON
 1860ENDPROC
 1870:
 1880DEFPROCask
 1890REPEAT
 1900K$=GET$
 1910IF K$="Y" OR K$="y" THEN ans=TRUE:UNTIL TRUE:ENDPROC
 1920IF K$="N" OR K$="n" THEN ans=FALSE:UNTIL TRUE:ENDPROC
 1930UNTIL FALSE
 1940ENDPROC
 1950:
 1960DEFPROCrepos
 1970*SCREENSAVE screen
 1980MODE 15
 1990PRINT"Reposition MandelPlot ? (Y/N)":PROCask
 2000IF ans=TRUE THEN TERMINATE=TRUE:ACTION=3:ENDPROC
 2010*SCREENLOAD screen
 2020MOUSE ON
 2030ENDPROC
 2040:
 2050DEFPROCreposac
 2060INPUT''"X Minimum";XMIN
 2070INPUT"X Maximum";XMAX
 2080INPUT'"Y Minimum";YMIN
 2090INPUT"Y Maximum";YMAX
 2100*SCREENLOAD screen
 2110MOUSE ON
 2120ACTION=FALSE:TERMINATE=FALSE
 2130ENDPROC
 2140:
 2150DEFPROCboxout
 2160IF Y>ypix OR Y>(xpix+282) THEN ENDPROC
 2170cornster=cornster EOR 1
 2180ENDPROC
 2190:
 2200DEFPROCassemble
 2210DIM space 1024
 2220:
 2230FOR p=0 TO 2 STEP 2
 2240P%=space
 2250[OPT p
 2260\ MANDELBROT SET CALCULATION
 2270\ R1=x |R2=y
 2280:
 2290\ F0=xpos
 2300\ F1=ypos
 2310\ F2=u
 2320\ F3=v
 2330:
 2340.mandpix         STMFD R13!,{R14}
 2350                 MOV R11,#0
 2360                 ADR R0,xmin                    \ Get X co-ordinate
 2370EQUD &ECF00100 \ LDFE F0,[R0]
 2380                 ADR R0,xstep
 2390EQUD &ECF01100 \ LDFE F1,[R0]
 2400EQUD &EE0711D7 \ FLTE F7,R1
 2410EQUD &EE192107 \ MLFE F2,F1,F7
 2420EQUD &EE080102 \ ADFE F0,F0,F2
 2430:
 2440                 ADR R0,ymin                    \ Get Y co-ordinate
 2450EQUD &ECF01100 \ LDFE F1,[R0]
 2460                 ADR R0,ystep
 2470EQUD &ECF02100 \ LDFE F2,[R0]
 2480EQUD &EE0721D7 \ FLTE F7,R2
 2490EQUD &EE1A3107 \ MLFE F3,F2,F7
 2500EQUD &EE091103 \ ADFE F1,F1,F3
 2510:
 2520EQUD &EE08A100 \ MVFE F2,F0
 2530EQUD &EE08B101\  MVFE F3,F1
 2540.pixloop
 2550EQUD &EE1A4102 \ MLFE F4,F2,F2        \ Finished?
 2560EQUD &EE1B5103 \ MLFE F5,F3,F3
 2570EQUD &EE0C6105 \ ADFE F6,F4,F5
 2580EQUD &EED6F11C \ CMFE F6,#4           \ u^2+v^2>4 ?
 2590                 BCS found
 2600                 ADD R11,R11,#1
 2610                 ADR R3,maxit
 2620                 LDR R10,[R3]
 2630                 CMP R11,R10
 2640                 BEQ found
 2650EQUD &EE2C6105 \ SBFE F6,F4,F5                \ u=u^2-v^2+x
 2660EQUD &EE0E6100 \ ADFE F6,F6,F0
 2670EQUD &EE1A4103 \ MLFE F4,F2,F3                \ v=2uv+y
 2680EQUD &EE0C4104 \ ADFE F4,F4,F4
 2690EQUD &EE0C4101 \ ADFE F4,F4,F1
 2700EQUD &EE08A106 \ MVFE F2,F6
 2710EQUD &EE08B104 \ MVFE F3,F4
 2720                 B pixloop
 2730:
 2740.found
 2750MOV R0,R11
 2760LDMFD R13!,{PC}
 2770:
 2780.setup
 2790EQUD &EE088108 \ MVFE F0,#0
 2800EQUD &EE28010A \ SBFE F0,F0,#2
 2810                 ADR R0,xmin
 2820EQUD &ECE00100 \ STFE F0,[R0]
 2830                 ADR R0,ymin
 2840EQUD &ECE00100 \ STFE F0,[R0]
 2850EQUD &EE08910A \ MVFE F0,#2
 2860EQUD &EE49010C \ DVFE F0,F0,#4
 2870EQUD &EE48110C \ DVFE F0,F0,#4
 2880EQUD &EE49010C \ DVFE F0,F0,#4
 2890EQUD &EE48110C \ DVFE F0,F0,#4
 2900EQUD &EE49010A \ DVFE F0,F0,#2
 2910                 ADR R0,ystep
 2920EQUD &ECE00100 \ STFE F0,[R0]
 2930                 ADR R0,xstep
 2940EQUD &ECE00100 \ STFE F0,[R0]
 2950                 MOV PC,R14
 2960.xmin EQUD 0:EQUD0:EQUD0
 2970.ymin EQUD 0:EQUD0:EQUD0
 2980.xstep EQUD 0:EQUD0:EQUD0
 2990.ystep EQUD 0:EQUD0:EQUD0
 3000.maxit EQUD 25:EQUD0:EQUD0
 3010.stack
 3020]
 3030NEXT
 3040REM OSCLI ("MEMORYI "+STR$~space+" + 100"):END
 3050ENDPROC
