10REM Software Scroller
20REM by Paul Bedworth
30REM (c) The Micro User
40REM Save this program before
50REM running it.
60cheat=&84
70?cheat=FALSE
80*TV 255
90MapDepth=6
100MapWidth=7
110MapTopGap=1
120MapLeftGap=1
130SprWidth=4
140SprDepth=32
150IncNr=&140*SprWidth
160IncNc=8*SprWidth
170osbyte=&FFF4
180oswrch=&FFEE
190:
200AL1=MapTopGap*IncNr
210AL2=MapLeftGap*IncNc
220ALIGN=AL1+AL2
230:
240REM screen start addresses
250REM - screen 1 must be lower
260REM than screen 2 -
270screen1=&3000
280screen2=&5800
290:
300REM zero page pointers
310addr=&80
320topaddr=&82
330data=&76
340:
350FOR P=0 TO 2 STEP 2
360P%=&1100
370[OPT P
380 JMP scroll
390.xydata
400 OPT FNxydata
410.calc LDY y:LDA xydata,Y
420 STA a:LDA xydata+32,Y
430 STA a+1
440 LDA x:BEQ endit:TAY
450.cl LDA a:CLC:ADC #8:STA a
460 LDA a+1:ADC #0:STA a+1:DEY:BNE cl
470.endit
480 LDA sn:CMP #2:BNE endit2
490 LDA a:SEC:SBC #&2800 MOD 256
500 STA a
510 LDA a+1:SBC #&2800 DIV 256
520 STA a+1
530.endit2
540 RTS
550.demo
560 LDA cheat
570 BNE cheaton
580 LDA deathflag
590 BNE dead
600.cheaton
610 LDX #&9E:JSR key
620 BNE notleft
630 LDA x:CMP #5:BCC notleft
640 DEC x
650.notleft
660 LDX #&BD:JSR key
670 BNE notright
680 LDA x:CMP #24:BCS notright
690 INC x
700.notright
710 LDX #&97:JSR key
720 BNE notdown
730 LDA y:CMP #25:BCS notdown
740 INC y
750.notdown
760 LDX #&B7:JSR key
770 BNE notup
780 LDA y:CMP #5:BCC notup
790 DEC y
800.notup
810 LDA #ASC("P")
820 JSR schoose
830 JSR calc
840 LDA #4:STA cols
850 JSR plot
860 RTS
870.dead
880 LDA deathflag:CMP #1:BNE novdus
890 LDY #255
900.vl
910 LDX #2
920.v19l
930 LDA #19:JSR oswrch
940 LDA #0:JSR oswrch
950 TXA:JSR oswrch
960 LDA #0:JSR oswrch
970 JSR oswrch:JSR oswrch
980 DEX
990 BNE v19l
1000 DEY:BNE vl
1010.novdus
1020 INC deathflag
1030 JSR wait
1040 RTS
1050.key
1060 LDA #129
1070 LDY #255
1080 JSR osbyte
1090 CPY #255
1100 RTS
1110.welldone
1120 JSR wait
1130 LDX #0
1140.msg
1150 LDA text,X
1160 JSR oswrch
1170 INX
1180 CMP #0
1190 BNE msg
1200 LDA #21
1210 LDX #0
1220 JSR osbyte
1230 RTS
1240.wait
1250 LDX #255
1260.w1 LDY #255
1270.w2 NOP:NOP:NOP:NOP:NOP:NOP
1280 DEY
1290 BNE w2
1300 DEX
1310 BNE w1
1320 RTS
1330.text
1340 OPT FNequb(22)
1350 OPT FNequb(5)
1360 OPT FNequb(31)
1370 OPT FNequb(2)
1380 OPT FNequb(4)
1390 OPT FNequs("Well Done!")
1400 OPT FNequb(31)
1410 OPT FNequb(2)
1420 OPT FNequb(6)
1430 OPT FNequs("Level 1 Completed!")
1440 BRK
1450.plot LDA addr:PHA:LDA addr+1:PHA
1460 LDA a:STA addr:LDA a+1:STA addr+1
1470 JSR eorsplot
1480 PLA:STA addr+1:PLA STA addr
1490 RTS
1500.splot \ plot sprite
1510 LDA addr
1520 PHA
1530 STA tcaddr
1540 LDA addr+1
1550 PHA
1560 STA tcaddr+1
1570.l1
1580 LDY #0
1590 LDX #4
1600.l2
1610 LDA (data),Y \ This is not
1620 STA (addr),Y \ bad programming!
1630 INY \ Makes it faster
1640 LDA (data),Y
1650 STA (addr),Y
1660 INY
1670 LDA (data),Y
1680 STA (addr),Y
1690 INY
1700 LDA (data),Y
1710 STA (addr),Y
1720 INY
1730 LDA (data),Y
1740 STA (addr),Y
1750 INY
1760 LDA (data),Y
1770 STA (addr),Y
1780 INY
1790 LDA (data),Y
1800 STA (addr),Y
1810 INY
1820 LDA (data),Y
1830 STA (addr),Y
1840 INY
1850 LDA addr
1860 CLC
1870 ADC #&38
1880 STA addr
1890 LDA addr+1
1900 ADC #1
1910 STA addr+1
1920 DEX
1930 BNE l2
1940 LDA data
1950 CLC
1960 ADC #SprDepth
1970 STA data
1980 LDA data+1
1990 ADC #0
2000 STA data+1
2010 LDA tcaddr
2020 ADC #8
2030 STA addr
2040 STA tcaddr
2050 LDA tcaddr+1
2060 ADC #0
2070 STA tcaddr+1
2080 STA addr+1
2090 DEC cols
2100 BNE l1
2110 PLA
2120 STA addr+1
2130 PLA
2140 STA addr
2150 RTS
2160.splot2 \ to enable
2170 LDA #SprWidth \ reverse
2180 SEC \ sprite-clipping
2190 SBC cols
2200 TAY
2210 BEQ dosplot
2220.s2l
2230 LDA data
2240 CLC
2250 ADC #SprDepth
2260 STA data
2270 LDA data+1
2280 ADC #0
2290 STA data+1
2300 DEY
2310 BNE s2l
2320.dosplot
2330 JMP splot
2340.eorsplot
2350 LDA addr
2360 PHA
2370 STA tcaddr
2380 LDA addr+1
2390 PHA
2400 STA tcaddr+1
2410.el1
2420 LDY #0
2430 LDX #4:STX cd
2440.eel2 LDX #8
2450.el2
2460 LDA (data),Y:BEQ black
2470 PHA:LDA (addr),Y:BEQ nohit
2480 LDA #1:STA deathflag
2490.nohit
2500 PLA
2510.black
2520 EOR (addr),Y:STA (addr),Y:INY
2530 DEX:BNE el2
2540 LDA addr:CLC:ADC #&38:STA addr
2550 LDA addr+1:ADC #1:STA addr+1
2560 DEC cd
2570 BNE eel2
2580 LDA data
2590 CLC:ADC #SprDepth:STA data
2600 LDA data+1:ADC #0:STA data+1
2610 LDA tcaddr:ADC #8:STA addr
2620 STA tcaddr
2630 LDA tcaddr+1:ADC #0:STA tcaddr+1
2640 STA addr+1
2650 DEC cols
2660 BNE el1
2670 PLA:STA addr+1
2680 PLA:STA addr
2690 RTS
2700.switch1 \ change screen
2710 LDA #19 \ start address
2720 JSR osbyte \ to screen 1
2730 LDA #13
2740 STA &FE00
2750 LDA #(screen1 MOD 2048 DIV 8)
2760 STA &FE01
2770 LDA #12
2780 STA &FE00
2790 LDA #(screen1 DIV 2048)
2800 STA &FE01
2810 LDA #1:STA sn
2820 RTS
2830.switch2
2840 LDA #19 \ change screen
2850 JSR osbyte \ start address
2860 LDA #13 \ to screen 2
2870 STA &FE00
2880 LDA #(screen2 MOD 2048 DIV 8)
2890 STA &FE01
2900 LDA #12
2910 STA &FE00
2920 LDA #(screen2 DIV 2048)
2930 STA &FE01
2940 LDA #2:STA sn
2950 RTS
2960.scroll
2970 LDA #22
2980 JSR oswrch
2990 LDA #5
3000 JSR oswrch
3010 LDA #23:JSR oswrch
3020 LDA #0:JSR oswrch
3030 LDA #10:JSR oswrch
3040 LDA #32:JSR oswrch
3050 LDA #0:JSR oswrch:JSR oswrch
3060 JSR oswrch:JSR oswrch
3070 JSR oswrch:JSR oswrch
3080 LDA #0 \ clear break flag
3090 STA &FF
3100 STA deathflag
3110 LDY #0
3120 LDA #&3000 MOD 256
3130 STA &90
3140 LDA #&3000 DIV 256
3150 STA &91
3160.bloop
3170 LDA #0
3180 STA (&90),Y \ clear both
3190 LDA &90 \ of the screens
3200 CLC \ -NB- this will
3210 ADC #1 \ clear from the
3220 STA &90 \ start of screen1
3230 BCC nc \ all the way to
3240 INC &91 \ &7FFF
3250.nc
3260 LDA &90
3270 CMP #&8000 MOD 256
3280 BNE bloop
3290 LDA &91
3300 CMP #&8000 DIV 256
3310 BNE bloop
3320 LDA #map MOD 256 \ initialise
3330 STA &70 \ pointers to
3340 LDA #map DIV 256 \ map data
3350 STA &71
3360.scrloop \ control loop
3370 JSR demo
3380 JSR switch1 \ switch to screen 1
3390 CMP #&EA
3400 LDA #screen2 MOD 256
3410 CLC
3420 ADC #ALIGN MOD 256
3430 STA maptop
3440 LDA #screen2 DIV 256
3450 ADC #ALIGN DIV 256
3460 STA maptop+1
3470 JSR plotmap \ plot map over scr 2
3480 CMP #&EA
3490 BNE cont1
3500 JSR welldone
3510 RTS
3520.cont1
3530 JSR demo
3540 JSR switch2 \ reveal map on scr 2
3550 LDA #screen1 MOD 256
3560 CLC
3570 ADC #ALIGN MOD 256
3580 STA maptop
3590 LDA #screen1 DIV 256
3600 ADC #ALIGN DIV 256
3610 STA maptop+1
3620 JSR plotmap \ plot map over scr 1
3630 CMP #&EA
3640 BNE cont2
3650 JSR welldone
3660 RTS
3670.cont2
3680 LDA deathflag
3690 CMP #2
3700 BCC notdeadyet
3710 JMP scroll
3720.notdeadyet
3730 BIT &FF \ test for break
3740 BEQ scrloop
3750 BRK
3760 OPT FNequb(27)
3770 OPT FNequs("Escape")
3780 BRK
3790.plotmap \ plot a screen
3800 INC counter \ from the map data
3810 LDA &70
3820 STA old70
3830 LDA &71
3840 STA old70+1
3850 LDY #0
3860 STY mcol
3870 LDA maptop
3880 STA addr
3890 LDA maptop+1
3900 STA addr+1
3910.ml
3920 LDY #0
3930 LDA addr
3940 STA topaddr
3950 LDA addr+1
3960 STA topaddr+1
3970.pml
3980 LDA (&70),Y \ load map symbol
3990 CMP #&EA
4000 BNE noteod
4010 RTS
4020.noteod
4030 JSR schoose \ and choose the
4040 LDA mcol \ corresponding
4050 BEQ doclip \ sprite
4060 LDA #SprWidth
4070 STA cols
4080 JMP overdoclip
4090.doclip
4100 LDA ncols \ only print
4110 STA cols \ 'ncols' columns
4120.overdoclip \ of the sprite
4130 STY ystore
4140 LDA mcol \ if not last
4150 CMP #MapWidth-1 \ column then do
4160 BNE dosplot2 \ a reverse clip
4170 LDA #SprWidth
4180 SEC
4190 SBC ncols
4200 BNE goon
4210 LDA #SprWidth
4220.goon STA cols
4230 JSR splot \ do the clip the
4240 JMP oversplot2 \ other way around
4250.dosplot2
4260 JSR splot2
4270.oversplot2
4280 LDY ystore \ go on to next
4290 LDA addr \ map row
4300 CLC
4310 ADC #IncNr MOD 256
4320 STA addr
4330 LDA addr+1
4340 ADC #IncNr DIV 256
4350 STA addr+1
4360 INY
4370 CPY #MapDepth
4380 BNE pml
4390 LDA mcol
4400 BNE ok
4410 LDA #4
4420 SEC
4430 SBC ncols
4440 BEQ ndec
4450 TAY
4460.decl
4470 LDA topaddr
4480 SEC
4490 SBC #8
4500 STA topaddr
4510 LDA topaddr+1
4520 SBC #0
4530 STA topaddr+1
4540 DEY
4550 BNE decl
4560.ndec
4570 DEC ncols
4580 BNE ok
4590 LDA #SprWidth
4600 STA ncols
4610.ok
4620 INC mcol
4630 LDA &70
4640 CLC
4650 ADC #MapDepth
4660 STA &70
4670 LDA &71
4680 ADC #0
4690 STA &71
4700 LDA topaddr \ go on to
4710 CLC \ next map
4720 ADC #IncNc MOD 256 \ column
4730 STA addr
4740 LDA topaddr+1
4750 ADC #IncNc DIV 256
4760 STA addr+1
4770 LDA mcol
4780 CMP #MapWidth
4790 BEQ nml
4800 JMP ml
4810.nml
4820 LDA counter \ decide whether
4830 CMP #4 \ to go onto next
4840 BNE notc4 \ column of data
4850 LDA old70 \ or to keep
4860 CLC \ scrolling
4870 ADC #MapDepth \ current data
4880 STA &70
4890 LDA old70+1
4900 ADC #0
4910 STA &71
4920 LDA #0
4930 STA counter
4940 JMP overnotc4
4950.notc4
4960 LDA old70
4970 STA &70
4980 LDA old70+1
4990 STA &71
5000.overnotc4
5010 RTS
5020 :
5030.schoose
5040 STA symbol
5050 STY ystore
5060 LDY #0
5070.searchl
5080 LDA sptable,Y
5090 BEQ notfound
5100 CMP symbol
5110 BEQ foundit
5120 INY:INY
5130 INY
5140 JMP searchl
5150.foundit
5160 LDA sptable+1,Y
5170 STA data
5180 LDA sptable+2,Y
5190 STA data+1
5200 LDY ystore
5210 RTS
5220.notfound
5230 LDA sptable+1
5240 STA data
5250 LDA sptable+2
5260 STA data+1
5270 LDY ystore
5280 RTS
5290.cols BRK
5300.tcaddr BRK:BRK
5310.maptop BRK:BRK
5320.ncols OPT FNequb(SprWidth)
5330.ystore BRK
5340.mcol BRK
5350.counter BRK
5360.old70 BRK:BRK
5370.symbol BRK
5380.sn OPT FNequb(1)
5390.cd BRK
5400.deathflag BRK
5410.x OPT FNequb(10)
5420.y OPT FNequb(10)
5430.a BRK:BRK
5440.map
5450 OPT FNequs("0 ")
5460 OPT FNequs("0 ")
5470 OPT FNequs("0 ")
5480 OPT FNequs("0 ")
5490 OPT FNequs("0 ")
5500 OPT FNequs("0 ")
5510 OPT FNequs("0000 0")
5520 OPT FNequs("0000 0")
5530 OPT FNequs("0000 0")
5540 OPT FNequs("0000 0")
5550 OPT FNequs("0000 0")
5560 OPT FNequs("0000 0")
5570 OPT FNequs("000 0")
5580 OPT FNequs("0 0")
5590 OPT FNequs("0 000")
5600 OPT FNequs("0 0 ")
5610 OPT FNequs("0 0000")
5620 OPT FNequs("0 0")
5630 OPT FNequs("0 0")
5640 OPT FNequs("0000 0")
5650 OPT FNequs("0000 0")
5660 OPT FNequs("00 0")
5670 OPT FNequs("00 00")
5680 OPT FNequs("0 000")
5690 OPT FNequs("0 000")
5700 OPT FNequs("00 00")
5710 OPT FNequs("00 0")
5720 OPT FNequs("0000 0")
5730 OPT FNequs("0000 0")
5740 OPT FNequs("0 0")
5750 OPT FNequs("0 00 0")
5760 OPT FNequs("0 00 0")
5770 OPT FNequs("0 00 0")
5780 OPT FNequs("0 00 0")
5790 OPT FNequs("0 00 0")
5800 OPT FNequs(" 00 ")
5810 OPT FNequs(" 00 ")
5820 OPT FNequs(" 0000 ")
5830 OPT FNequs(" ")
5840 OPT FNequs("00 00")
5850 OPT FNequs("00 00")
5860 OPT FNequs(" ")
5870 OPT FNequs(" ")
5880 OPT FNequs(" ")
5890 NOP
5900.sptable
5910 OPT FNequs(" ")
5920 OPT FNequw(blankdata)
5930 OPT FNequs("P")
5940 OPT FNequw(blockdata)
5950 OPT FNequs("0")
5960 OPT FNequw(blockdata+32*4)
5970 BRK
5980.blockdata
5990 OPT FNsdata
6000.blankdata
6010 OPT FNequs(STRING$(4*32,CHR$(0)))
6020]:NEXT
6030PROCexecute
6040END
6050:
6060DEFFNsdata
6070RESTORE
6080FOR I%=1 TO ((SprWidth*SprDepth)/4)*2
6090READ d$
6100[OPT P:OPT FNequd(EVAL("&"+d$))
6110]:NEXT:=P
6120:
6130DEFFNxydata
6140RESTORE 6240
6150FOR I%=1 TO 64/4
6160READ d$
6170[OPT P:OPT FNequd(EVAL("&"+d$)):]
6180NEXT:=P
6190:
6200DATA 0,E0C0C08,F0F0F0E,10100206,3030,0,0,0,0,0,F0F00,C0E0F0F0,80,0,0,0,0,E0600000,70E0F00,383,0,0,0,0,0,0,3060C00,F0F,0,0,0,0
6210DATA 3C7F7FFF,2C3C1C2C,1C2C3C1C,3C1C2C3C,2C3C1C2C,1C2C3C1C,3C1C2C3C,F0F0F2C,60FFFFFF,D060B0D0,B0D060B0,60B0D060,D060B0D0,B0D060B0,60B0D060,F0F0FD0,D0FFFFFF,B0D060B0,60B0D060,D060B0D0,B0D060B0,60B0D060,D060B0D0,F0F0FB0,B3FFFFFF
6220DATA73B3F373,F373B3F3,B3F373B3,73B3F373,F373B3F3,B3F373B3,1F1F3F73
6230:
6240DATA C0804000,C0804000,C0804000,C0804000,C0804000,C0804000,C0804000,C0804000,5B5A5958,605F5E5D,65646362,6A696867,6F6E6D6C,74737271,79787776,7E7D7C7B
6250:
6260DEFFNequs(s$)$P%=s$:P%=P%+LENs$:=P
6270DEFFNequb(B%)?P%=B%:P%=P%+1:=P
6280DEFFNequw(W%)!P%=W%:P%=P%+2:=P
6290DEFFNequd(D%)!P%=D%:P%=P%+4:=P
6300:
6310DEFPROCexecute
6320s$="CALL scroll"+CHR$(13)
6330FOR L=1 TO LEN(s$)
6340X%=0:Y%=ASCMID$(s$,L)
6350A%=138:CALL osbyte
6360NEXT:ENDPROC
� Software Scroller
� by Paul Bedworth
� (c) The Micro User
( � Save this program before
2� running it.
<
cheat=&84
F ?cheat=�
P *TV 255
ZMapDepth=6
dMapWidth=7
nMapTopGap=1
xMapLeftGap=1
�SprWidth=4
�SprDepth=32
�IncNr=&140*SprWidth
�IncNc=8*SprWidth
�osbyte=&FFF4
�oswrch=&FFEE
�:
�AL1=MapTopGap*IncNr
�AL2=MapLeftGap*IncNc
�ALIGN=AL1+AL2
�:
� � screen start addresses
� � - screen 1 must be lower
� than screen 2 -
screen1=&3000
screen2=&5800
":
,� zero page pointers
6 addr=&80
@topaddr=&82
J data=&76
T:
^� P=0 � 2 � 2
h P%=&1100
r
[OPT P
| JMP scroll
� .xydata
� OPT �xydata
� .calc LDY y:LDA xydata,Y
� STA a:LDA xydata+32,Y
� STA a+1
� LDA x:BEQ endit:TAY
� .cl LDA a:CLC:ADC #8:STA a
�& LDA a+1:ADC #0:STA a+1:DEY:BNE cl
�
.endit
� LDA sn:CMP #2:BNE endit2
� LDA a:SEC:SBC #&2800 � 256
�
STA a
� LDA a+1:SBC #&2800 � 256
STA a+1
.endit2
RTS
& .demo
0 LDA cheat
: BNE cheaton
D LDA deathflag
N
BNE dead
X .cheaton
b LDX #&9E:JSR key
l BNE notleft
v LDA x:CMP #5:BCC notleft
�
DEC x
� .notleft
� LDX #&BD:JSR key
� BNE notright
� LDA x:CMP #24:BCS notright
�
INC x
�
.notright
� LDX #&97:JSR key
� BNE notdown
� LDA y:CMP #25:BCS notdown
�
INC y
� .notdown
� LDX #&B7:JSR key
BNE notup
LDA y:CMP #5:BCC notup
DEC y
.notup
* LDA #�("P")
4 JSR schoose
>
JSR calc
H LDA #4:STA cols
R
JSR plot
\ RTS
f .dead
p$ LDA deathflag:CMP #1:BNE novdus
z
LDY #255
�.vl
� LDX #2
� .v19l
� LDA #19:JSR oswrch
� LDA #0:JSR oswrch
� TXA:JSR oswrch
� LDA #0:JSR oswrch
� JSR oswrch:JSR oswrch
� DEX
�
BNE v19l
� DEY:BNE vl
� .novdus
� INC deathflag
JSR wait
RTS
.key
$
LDA #129
.
LDY #255
8 JSR osbyte
B
CPY #255
L RTS
V
.welldone
`
JSR wait
j LDX #0
t.msg
~ LDA text,X
� JSR oswrch
� INX
� CMP #0
� BNE msg
� LDA #21
� LDX #0
� JSR osbyte
� RTS
� .wait
�
LDX #255
�.w1 LDY #255
� .w2 NOP:NOP:NOP:NOP:NOP:NOP
DEY
BNE w2
DEX
BNE w1
( RTS
2 .text
< OPT �equb(22)
F OPT �equb(5)
P OPT �equb(31)
Z OPT �equb(2)
d OPT �equb(4)
n OPT �equs("Well Done!")
x OPT �equb(31)
� OPT �equb(2)
� OPT �equb(6)
�$ OPT �equs("Level 1 Completed!")
� BRK
�%.plot LDA addr:PHA:LDA addr+1:PHA
�& LDA a:STA addr:LDA a+1:STA addr+1
� JSR eorsplot
� PLA:STA addr+1:PLA STA addr
� RTS
� .splot \ plot sprite
�
LDA addr
� PHA
� STA tcaddr
LDA addr+1
PHA
STA tcaddr+1
".l1
, LDY #0
6 LDX #4
@.l2
J LDA (data),Y \ This is not
T$ STA (addr),Y \ bad programming!
^# INY \ Makes it faster
h LDA (data),Y
r STA (addr),Y
| INY
� LDA (data),Y
� STA (addr),Y
� INY
� LDA (data),Y
� STA (addr),Y
� INY
� LDA (data),Y
� STA (addr),Y
� INY
� LDA (data),Y
� STA (addr),Y
� INY
� LDA (data),Y
STA (addr),Y
INY
LDA (data),Y
& STA (addr),Y
0 INY
:
LDA addr
D CLC
N
ADC #&38
X
STA addr
b LDA addr+1
l ADC #1
v STA addr+1
� DEX
� BNE l2
�
LDA data
� CLC
� ADC #SprDepth
�
STA data
� LDA data+1
� ADC #0
� STA data+1
� LDA tcaddr
� ADC #8
�
STA addr
� STA tcaddr
LDA tcaddr+1
ADC #0
STA tcaddr+1
STA addr+1
*
DEC cols
4 BNE l1
> PLA
H STA addr+1
R PLA
\
STA addr
f RTS
p .splot2 \ to enable
z LDA #SprWidth \ reverse
�$ SEC \ sprite-clipping
�
SBC cols
� TAY
� BEQ dosplot
�.s2l
�
LDA data
� CLC
� ADC #SprDepth
�
STA data
� LDA data+1
� ADC #0
� STA data+1
� DEY
BNE s2l
.dosplot
JMP splot
$
.eorsplot
.
LDA addr
8 PHA
B STA tcaddr
L LDA addr+1
V PHA
` STA tcaddr+1
j.el1
t LDY #0
~ LDX #4:STX cd
�.eel2 LDX #8
�.el2
� LDA (data),Y:BEQ black
� PHA:LDA (addr),Y:BEQ nohit
� LDA #1:STA deathflag
�
.nohit
� PLA
�
.black
� � (addr),Y:STA (addr),Y:INY
� DEX:BNE el2
�# LDA addr:CLC:ADC #&38:STA addr
�! LDA addr+1:ADC #1:STA addr+1
DEC cd
BNE eel2
LDA data
CLC:ADC #SprDepth:STA data
(! LDA data+1:ADC #0:STA data+1
2 LDA tcaddr:ADC #8:STA addr
< STA tcaddr
F% LDA tcaddr+1:ADC #0:STA tcaddr+1
P STA addr+1
Z
DEC cols
d BNE el1
n PLA:STA addr+1
x PLA:STA addr
� RTS
� .switch1 \ change screen
� LDA #19 \ start address
� JSR osbyte \ to screen 1
� LDA #13
� STA &FE00
� LDA #(screen1 � 2048 � 8)
� STA &FE01
� LDA #12
� STA &FE00
� LDA #(screen1 � 2048)
� STA &FE01
� LDA #1:STA sn
RTS
.switch2
LDA #19 \ change screen
" JSR osbyte \ start address
, LDA #13 \ to screen 2
6 STA &FE00
@ LDA #(screen2 � 2048 � 8)
J STA &FE01
T LDA #12
^ STA &FE00
h LDA #(screen2 � 2048)
r STA &FE01
| LDA #2:STA sn
� RTS
� .scroll
� LDA #22
� JSR oswrch
� LDA #5
� JSR oswrch
� LDA #23:JSR oswrch
� LDA #0:JSR oswrch
� LDA #10:JSR oswrch
� LDA #32:JSR oswrch
�! LDA #0:JSR oswrch:JSR oswrch
� JSR oswrch:JSR oswrch
� JSR oswrch:JSR oswrch
LDA #0 \ clear break flag
STA &FF
STA deathflag
& LDY #0
0 LDA #&3000 � 256
: STA &90
D LDA #&3000 � 256
N STA &91
X
.bloop
b LDA #0
l STA (&90),Y \ clear both
v! LDA &90 \ of the screens
�! CLC \ -NB- this will
�! ADC #1 \ clear from the
�# STA &90 \ start of screen1
�! BCC nc \ all the way to
� INC &91 \ &7FFF
�.nc
� LDA &90
� CMP #&8000 � 256
� BNE bloop
� LDA &91
� CMP #&8000 � 256
� BNE bloop
� LDA #map � 256 \ initialise
# STA &70 \ pointers to
LDA #map � 256 \ map data
STA &71
.scrloop \ control loop
*
JSR demo
4& JSR switch1 \ switch to screen 1
>
CMP #&EA
H LDA #screen2 � 256
R CLC
\ ADC #ALIGN � 256
f STA maptop
p LDA #screen2 � 256
z ADC #ALIGN � 256
� STA maptop+1
�& JSR plotmap \ plot map over scr 2
�
CMP #&EA
� BNE cont1
� JSR welldone
� RTS
�
.cont1
�
JSR demo
�& JSR switch2 \ reveal map on scr 2
� LDA #screen1 � 256
� CLC
� ADC #ALIGN � 256
� STA maptop
LDA #screen1 � 256
ADC #ALIGN � 256
STA maptop+1
$& JSR plotmap \ plot map over scr 1
.
CMP #&EA
8 BNE cont2
B JSR welldone
L RTS
V
.cont2
` LDA deathflag
j CMP #2
t BCC notdeadyet
~ JMP scroll
�.notdeadyet
�! BIT &FF \ test for break
� BEQ scrloop
� BRK
� OPT �equb(27)
� OPT �equs("Escape")
� BRK
�!.plotmap \ plot a screen
�% INC counter \ from the map data
� LDA &70
� STA old70
� LDA &71
STA old70+1
LDY #0
STY mcol
LDA maptop
(
STA addr
2 LDA maptop+1
< STA addr+1
F.ml
P LDY #0
Z
LDA addr
d STA topaddr
n LDA addr+1
x STA topaddr+1
�.pml
�$ LDA (&70),Y \ load map symbol
�
CMP #&EA
� BNE noteod
� RTS
� .noteod
�$ JSR schoose \ and choose the
�" LDA mcol \ corresponding
� BEQ doclip \ sprite
� LDA #SprWidth
�
STA cols
� JMP overdoclip
�.doclip
LDA ncols \ only print
$ STA cols \ 'ncols' columns
".overdoclip \ of the sprite
" STY ystore
," LDA mcol \ if not last
6% CMP #MapWidth-1 \ column then do
@% BNE dosplot2 \ a reverse clip
J LDA #SprWidth
T SEC
^ SBC ncols
h
BNE goon
r LDA #SprWidth
|.goon STA cols
�& JSR splot \ do the clip the
�& JMP oversplot2 \ other way around
�
.dosplot2
� JSR splot2
�.oversplot2
�# LDY ystore \ go on to next
� LDA addr \ map row
� CLC
� ADC #IncNr � 256
�
STA addr
� LDA addr+1
� ADC #IncNr � 256
� STA addr+1
INY
CPY #MapDepth
BNE pml
&
LDA mcol
0 BNE ok
: LDA #4
D SEC
N SBC ncols
X
BEQ ndec
b TAY
l .decl
v LDA topaddr
� SEC
� SBC #8
� STA topaddr
� LDA topaddr+1
� SBC #0
� STA topaddr+1
� DEY
�
BNE decl
� .ndec
� DEC ncols
� BNE ok
� LDA #SprWidth
� STA ncols
.ok
INC mcol
LDA &70
CLC
* ADC #MapDepth
4 STA &70
> LDA &71
H ADC #0
R STA &71
\# LDA topaddr \ go on to
f# CLC \ next map
p ADC #IncNc � 256 \ column
z
STA addr
� LDA topaddr+1
� ADC #IncNc � 256
� STA addr+1
�
LDA mcol
� CMP #MapWidth
� BEQ nml
� JMP ml
�.nml
�$ LDA counter \ decide whether
�% CMP #4 \ to go onto next
�$ BNE notc4 \ column of data
� LDA old70 \ or to keep
� CLC \ scrolling
" ADC #MapDepth \ current data
STA &70
LDA old70+1
$ ADC #0
. STA &71
8 LDA #0
B STA counter
L JMP overnotc4
V
.notc4
` LDA old70
j STA &70
t LDA old70+1
~ STA &71
�.overnotc4
� RTS
� :
� .schoose
� STA symbol
� STY ystore
� LDY #0
� .searchl
� LDA sptable,Y
� BEQ notfound
� CMP symbol
� BEQ foundit
INY:INY
INY
JMP searchl
.foundit
( LDA sptable+1,Y
2
STA data
< LDA sptable+2,Y
F STA data+1
P LDY ystore
Z RTS
d
.notfound
n LDA sptable+1
x
STA data
� LDA sptable+2
� STA data+1
� LDY ystore
� RTS
�.cols BRK
�.tcaddr BRK:BRK
�.maptop BRK:BRK
�".ncols OPT �equb(SprWidth)
�.ystore BRK
�.mcol BRK
�.counter BRK
�.old70 BRK:BRK
�.symbol BRK
.sn OPT �equb(1)
.cd BRK
.deathflag BRK
".x OPT �equb(10)
,.y OPT �equb(10)
6.a BRK:BRK
@.map
J OPT �equs("0 ")
T OPT �equs("0 ")
^ OPT �equs("0 ")
h OPT �equs("0 ")
r OPT �equs("0 ")
| OPT �equs("0 ")
� OPT �equs("0000 0")
� OPT �equs("0000 0")
� OPT �equs("0000 0")
� OPT �equs("0000 0")
� OPT �equs("0000 0")
� OPT �equs("0000 0")
� OPT �equs("000 0")
� OPT �equs("0 0")
� OPT �equs("0 000")
� OPT �equs("0 0 ")
� OPT �equs("0 0000")
� OPT �equs("0 0")
� OPT �equs("0 0")
OPT �equs("0000 0")
OPT �equs("0000 0")
OPT �equs("00 0")
& OPT �equs("00 00")
0 OPT �equs("0 000")
: OPT �equs("0 000")
D OPT �equs("00 00")
N OPT �equs("00 0")
X OPT �equs("0000 0")
b OPT �equs("0000 0")
l OPT �equs("0 0")
v OPT �equs("0 00 0")
� OPT �equs("0 00 0")
� OPT �equs("0 00 0")
� OPT �equs("0 00 0")
� OPT �equs("0 00 0")
� OPT �equs(" 00 ")
� OPT �equs(" 00 ")
� OPT �equs(" 0000 ")
� OPT �equs(" ")
� OPT �equs("00 00")
� OPT �equs("00 00")
� OPT �equs(" ")
� OPT �equs(" ")
� OPT �equs(" ")
NOP
.sptable
OPT �equs(" ")
OPT �equw(blankdata)
* OPT �equs("P")
4 OPT �equw(blockdata)
> OPT �equs("0")
H OPT �equw(blockdata+32*4)
R BRK
\.blockdata
f OPT �sdata
p.blankdata
z OPT �equs(�4*32,�(0)))
�]:�
� �execute
��
�:
� ݤsdata
��
�&� I%=1 � ((SprWidth*SprDepth)/4)*2
�� d$
� [OPT P:OPT �equd(�("&"+d$))
�
]:�:=P
�:
� ݤxydata
�
� �D`X
� I%=1 � 64/4
� d$
![OPT P:OPT �equd(�("&"+d$)):]
$�:=P
.:
8~� 0,E0C0C08,F0F0F0E,10100206,3030,0,0,0,0,0,F0F00,C0E0F0F0,80,0,0,0,0,E0600000,70E0F00,383,0,0,0,0,0,0,3060C00,F0F,0,0,0,0
B�� 3C7F7FFF,2C3C1C2C,1C2C3C1C,3C1C2C3C,2C3C1C2C,1C2C3C1C,3C1C2C3C,F0F0F2C,60FFFFFF,D060B0D0,B0D060B0,60B0D060,D060B0D0,B0D060B0,60B0D060,F0F0FD0,D0FFFFFF,B0D060B0,60B0D060,D060B0D0,B0D060B0,60B0D060,D060B0D0,F0F0FB0,B3FFFFFF
LC�73B3F373,F373B3F3,B3F373B3,73B3F373,F373B3F3,B3F373B3,1F1F3F73
V:
`�� C0804000,C0804000,C0804000,C0804000,C0804000,C0804000,C0804000,C0804000,5B5A5958,605F5E5D,65646362,6A696867,6F6E6D6C,74737271,79787776,7E7D7C7B
j:
t!ݤequs(s$)$P%=s$:P%=P%+�s$:=P
~ ݤequb(B%)?P%=B%:P%=P%+1:=P
� ݤequw(W%)!P%=W%:P%=P%+2:=P
� ݤequd(D%)!P%=D%:P%=P%+4:=P
�:
�
��execute
�s$="CALL scroll"+�(13)
�� L=1 � �(s$)
�X%=0:Y%=��s$,L)
�A%=138:� osbyte
��:�
� 00000000 0d 00 0a 17 f4 20 53 6f 66 74 77 61 72 65 20 53 |..... Software S|
00000010 63 72 6f 6c 6c 65 72 0d 00 14 16 f4 20 62 79 20 |croller..... by |
00000020 50 61 75 6c 20 42 65 64 77 6f 72 74 68 0d 00 1e |Paul Bedworth...|
00000030 18 f4 20 28 63 29 20 54 68 65 20 4d 69 63 72 6f |.. (c) The Micro|
00000040 20 55 73 65 72 0d 00 28 1e f4 20 53 61 76 65 20 | User..(.. Save |
00000050 74 68 69 73 20 70 72 6f 67 72 61 6d 20 62 65 66 |this program bef|
00000060 6f 72 65 0d 00 32 11 f4 20 72 75 6e 6e 69 6e 67 |ore..2.. running|
00000070 20 69 74 2e 0d 00 3c 0d 63 68 65 61 74 3d 26 38 | it...<.cheat=&8|
00000080 34 0d 00 46 0c 3f 63 68 65 61 74 3d a3 0d 00 50 |4..F.?cheat=...P|
00000090 0b 2a 54 56 20 32 35 35 0d 00 5a 0e 4d 61 70 44 |.*TV 255..Z.MapD|
000000a0 65 70 74 68 3d 36 0d 00 64 0e 4d 61 70 57 69 64 |epth=6..d.MapWid|
000000b0 74 68 3d 37 0d 00 6e 0f 4d 61 70 54 6f 70 47 61 |th=7..n.MapTopGa|
000000c0 70 3d 31 0d 00 78 10 4d 61 70 4c 65 66 74 47 61 |p=1..x.MapLeftGa|
000000d0 70 3d 31 0d 00 82 0e 53 70 72 57 69 64 74 68 3d |p=1....SprWidth=|
000000e0 34 0d 00 8c 0f 53 70 72 44 65 70 74 68 3d 33 32 |4....SprDepth=32|
000000f0 0d 00 96 17 49 6e 63 4e 72 3d 26 31 34 30 2a 53 |....IncNr=&140*S|
00000100 70 72 57 69 64 74 68 0d 00 a0 14 49 6e 63 4e 63 |prWidth....IncNc|
00000110 3d 38 2a 53 70 72 57 69 64 74 68 0d 00 aa 10 6f |=8*SprWidth....o|
00000120 73 62 79 74 65 3d 26 46 46 46 34 0d 00 b4 10 6f |sbyte=&FFF4....o|
00000130 73 77 72 63 68 3d 26 46 46 45 45 0d 00 be 05 3a |swrch=&FFEE....:|
00000140 0d 00 c8 17 41 4c 31 3d 4d 61 70 54 6f 70 47 61 |....AL1=MapTopGa|
00000150 70 2a 49 6e 63 4e 72 0d 00 d2 18 41 4c 32 3d 4d |p*IncNr....AL2=M|
00000160 61 70 4c 65 66 74 47 61 70 2a 49 6e 63 4e 63 0d |apLeftGap*IncNc.|
00000170 00 dc 11 41 4c 49 47 4e 3d 41 4c 31 2b 41 4c 32 |...ALIGN=AL1+AL2|
00000180 0d 00 e6 05 3a 0d 00 f0 1c f4 20 73 63 72 65 65 |....:..... scree|
00000190 6e 20 73 74 61 72 74 20 61 64 64 72 65 73 73 65 |n start addresse|
000001a0 73 0d 00 fa 1e f4 20 2d 20 73 63 72 65 65 6e 20 |s..... - screen |
000001b0 31 20 6d 75 73 74 20 62 65 20 6c 6f 77 65 72 0d |1 must be lower.|
000001c0 01 04 15 f4 20 74 68 61 6e 20 73 63 72 65 65 6e |.... than screen|
000001d0 20 32 20 2d 0d 01 0e 11 73 63 72 65 65 6e 31 3d | 2 -....screen1=|
000001e0 26 33 30 30 30 0d 01 18 11 73 63 72 65 65 6e 32 |&3000....screen2|
000001f0 3d 26 35 38 30 30 0d 01 22 05 3a 0d 01 2c 18 f4 |=&5800..".:..,..|
00000200 20 7a 65 72 6f 20 70 61 67 65 20 70 6f 69 6e 74 | zero page point|
00000210 65 72 73 0d 01 36 0c 61 64 64 72 3d 26 38 30 0d |ers..6.addr=&80.|
00000220 01 40 0f 74 6f 70 61 64 64 72 3d 26 38 32 0d 01 |.@.topaddr=&82..|
00000230 4a 0c 64 61 74 61 3d 26 37 36 0d 01 54 05 3a 0d |J.data=&76..T.:.|
00000240 01 5e 11 e3 20 50 3d 30 20 b8 20 32 20 88 20 32 |.^.. P=0 . 2 . 2|
00000250 0d 01 68 0c 50 25 3d 26 31 31 30 30 0d 01 72 0a |..h.P%=&1100..r.|
00000260 5b 4f 50 54 20 50 0d 01 7c 0f 20 4a 4d 50 20 73 |[OPT P..|. JMP s|
00000270 63 72 6f 6c 6c 0d 01 86 0b 2e 78 79 64 61 74 61 |croll.....xydata|
00000280 0d 01 90 10 20 4f 50 54 20 a4 78 79 64 61 74 61 |.... OPT .xydata|
00000290 0d 01 9a 1c 2e 63 61 6c 63 20 4c 44 59 20 79 3a |.....calc LDY y:|
000002a0 4c 44 41 20 78 79 64 61 74 61 2c 59 0d 01 a4 1a |LDA xydata,Y....|
000002b0 20 53 54 41 20 61 3a 4c 44 41 20 78 79 64 61 74 | STA a:LDA xydat|
000002c0 61 2b 33 32 2c 59 0d 01 ae 0c 20 53 54 41 20 61 |a+32,Y.... STA a|
000002d0 2b 31 0d 01 b8 18 20 4c 44 41 20 78 3a 42 45 51 |+1.... LDA x:BEQ|
000002e0 20 65 6e 64 69 74 3a 54 41 59 0d 01 c2 1e 2e 63 | endit:TAY.....c|
000002f0 6c 20 4c 44 41 20 61 3a 43 4c 43 3a 41 44 43 20 |l LDA a:CLC:ADC |
00000300 23 38 3a 53 54 41 20 61 0d 01 cc 26 20 4c 44 41 |#8:STA a...& LDA|
00000310 20 61 2b 31 3a 41 44 43 20 23 30 3a 53 54 41 20 | a+1:ADC #0:STA |
00000320 61 2b 31 3a 44 45 59 3a 42 4e 45 20 63 6c 0d 01 |a+1:DEY:BNE cl..|
00000330 d6 0a 2e 65 6e 64 69 74 0d 01 e0 1d 20 4c 44 41 |...endit.... LDA|
00000340 20 73 6e 3a 43 4d 50 20 23 32 3a 42 4e 45 20 65 | sn:CMP #2:BNE e|
00000350 6e 64 69 74 32 0d 01 ea 1f 20 4c 44 41 20 61 3a |ndit2.... LDA a:|
00000360 53 45 43 3a 53 42 43 20 23 26 32 38 30 30 20 83 |SEC:SBC #&2800 .|
00000370 20 32 35 36 0d 01 f4 0a 20 53 54 41 20 61 0d 01 | 256.... STA a..|
00000380 fe 1d 20 4c 44 41 20 61 2b 31 3a 53 42 43 20 23 |.. LDA a+1:SBC #|
00000390 26 32 38 30 30 20 81 20 32 35 36 0d 02 08 0c 20 |&2800 . 256.... |
000003a0 53 54 41 20 61 2b 31 0d 02 12 0b 2e 65 6e 64 69 |STA a+1.....endi|
000003b0 74 32 0d 02 1c 08 20 52 54 53 0d 02 26 09 2e 64 |t2.... RTS..&..d|
000003c0 65 6d 6f 0d 02 30 0e 20 4c 44 41 20 63 68 65 61 |emo..0. LDA chea|
000003d0 74 0d 02 3a 10 20 42 4e 45 20 63 68 65 61 74 6f |t..:. BNE cheato|
000003e0 6e 0d 02 44 12 20 4c 44 41 20 64 65 61 74 68 66 |n..D. LDA deathf|
000003f0 6c 61 67 0d 02 4e 0d 20 42 4e 45 20 64 65 61 64 |lag..N. BNE dead|
00000400 0d 02 58 0c 2e 63 68 65 61 74 6f 6e 0d 02 62 15 |..X..cheaton..b.|
00000410 20 4c 44 58 20 23 26 39 45 3a 4a 53 52 20 6b 65 | LDX #&9E:JSR ke|
00000420 79 0d 02 6c 10 20 42 4e 45 20 6e 6f 74 6c 65 66 |y..l. BNE notlef|
00000430 74 0d 02 76 1d 20 4c 44 41 20 78 3a 43 4d 50 20 |t..v. LDA x:CMP |
00000440 23 35 3a 42 43 43 20 6e 6f 74 6c 65 66 74 0d 02 |#5:BCC notleft..|
00000450 80 0a 20 44 45 43 20 78 0d 02 8a 0c 2e 6e 6f 74 |.. DEC x.....not|
00000460 6c 65 66 74 0d 02 94 15 20 4c 44 58 20 23 26 42 |left.... LDX #&B|
00000470 44 3a 4a 53 52 20 6b 65 79 0d 02 9e 11 20 42 4e |D:JSR key.... BN|
00000480 45 20 6e 6f 74 72 69 67 68 74 0d 02 a8 1f 20 4c |E notright.... L|
00000490 44 41 20 78 3a 43 4d 50 20 23 32 34 3a 42 43 53 |DA x:CMP #24:BCS|
000004a0 20 6e 6f 74 72 69 67 68 74 0d 02 b2 0a 20 49 4e | notright.... IN|
000004b0 43 20 78 0d 02 bc 0d 2e 6e 6f 74 72 69 67 68 74 |C x.....notright|
000004c0 0d 02 c6 15 20 4c 44 58 20 23 26 39 37 3a 4a 53 |.... LDX #&97:JS|
000004d0 52 20 6b 65 79 0d 02 d0 10 20 42 4e 45 20 6e 6f |R key.... BNE no|
000004e0 74 64 6f 77 6e 0d 02 da 1e 20 4c 44 41 20 79 3a |tdown.... LDA y:|
000004f0 43 4d 50 20 23 32 35 3a 42 43 53 20 6e 6f 74 64 |CMP #25:BCS notd|
00000500 6f 77 6e 0d 02 e4 0a 20 49 4e 43 20 79 0d 02 ee |own.... INC y...|
00000510 0c 2e 6e 6f 74 64 6f 77 6e 0d 02 f8 15 20 4c 44 |..notdown.... LD|
00000520 58 20 23 26 42 37 3a 4a 53 52 20 6b 65 79 0d 03 |X #&B7:JSR key..|
00000530 02 0e 20 42 4e 45 20 6e 6f 74 75 70 0d 03 0c 1b |.. BNE notup....|
00000540 20 4c 44 41 20 79 3a 43 4d 50 20 23 35 3a 42 43 | LDA y:CMP #5:BC|
00000550 43 20 6e 6f 74 75 70 0d 03 16 0a 20 44 45 43 20 |C notup.... DEC |
00000560 79 0d 03 20 0a 2e 6e 6f 74 75 70 0d 03 2a 10 20 |y.. ..notup..*. |
00000570 4c 44 41 20 23 97 28 22 50 22 29 0d 03 34 10 20 |LDA #.("P")..4. |
00000580 4a 53 52 20 73 63 68 6f 6f 73 65 0d 03 3e 0d 20 |JSR schoose..>. |
00000590 4a 53 52 20 63 61 6c 63 0d 03 48 14 20 4c 44 41 |JSR calc..H. LDA|
000005a0 20 23 34 3a 53 54 41 20 63 6f 6c 73 0d 03 52 0d | #4:STA cols..R.|
000005b0 20 4a 53 52 20 70 6c 6f 74 0d 03 5c 08 20 52 54 | JSR plot..\. RT|
000005c0 53 0d 03 66 09 2e 64 65 61 64 0d 03 70 24 20 4c |S..f..dead..p$ L|
000005d0 44 41 20 64 65 61 74 68 66 6c 61 67 3a 43 4d 50 |DA deathflag:CMP|
000005e0 20 23 31 3a 42 4e 45 20 6e 6f 76 64 75 73 0d 03 | #1:BNE novdus..|
000005f0 7a 0d 20 4c 44 59 20 23 32 35 35 0d 03 84 07 2e |z. LDY #255.....|
00000600 76 6c 0d 03 8e 0b 20 4c 44 58 20 23 32 0d 03 98 |vl.... LDX #2...|
00000610 09 2e 76 31 39 6c 0d 03 a2 17 20 4c 44 41 20 23 |..v19l.... LDA #|
00000620 31 39 3a 4a 53 52 20 6f 73 77 72 63 68 0d 03 ac |19:JSR oswrch...|
00000630 16 20 4c 44 41 20 23 30 3a 4a 53 52 20 6f 73 77 |. LDA #0:JSR osw|
00000640 72 63 68 0d 03 b6 13 20 54 58 41 3a 4a 53 52 20 |rch.... TXA:JSR |
00000650 6f 73 77 72 63 68 0d 03 c0 16 20 4c 44 41 20 23 |oswrch.... LDA #|
00000660 30 3a 4a 53 52 20 6f 73 77 72 63 68 0d 03 ca 1a |0:JSR oswrch....|
00000670 20 4a 53 52 20 6f 73 77 72 63 68 3a 4a 53 52 20 | JSR oswrch:JSR |
00000680 6f 73 77 72 63 68 0d 03 d4 08 20 44 45 58 0d 03 |oswrch.... DEX..|
00000690 de 0d 20 42 4e 45 20 76 31 39 6c 0d 03 e8 0f 20 |.. BNE v19l.... |
000006a0 44 45 59 3a 42 4e 45 20 76 6c 0d 03 f2 0b 2e 6e |DEY:BNE vl.....n|
000006b0 6f 76 64 75 73 0d 03 fc 12 20 49 4e 43 20 64 65 |ovdus.... INC de|
000006c0 61 74 68 66 6c 61 67 0d 04 06 0d 20 4a 53 52 20 |athflag.... JSR |
000006d0 77 61 69 74 0d 04 10 08 20 52 54 53 0d 04 1a 08 |wait.... RTS....|
000006e0 2e 6b 65 79 0d 04 24 0d 20 4c 44 41 20 23 31 32 |.key..$. LDA #12|
000006f0 39 0d 04 2e 0d 20 4c 44 59 20 23 32 35 35 0d 04 |9.... LDY #255..|
00000700 38 0f 20 4a 53 52 20 6f 73 62 79 74 65 0d 04 42 |8. JSR osbyte..B|
00000710 0d 20 43 50 59 20 23 32 35 35 0d 04 4c 08 20 52 |. CPY #255..L. R|
00000720 54 53 0d 04 56 0d 2e 77 65 6c 6c 64 6f 6e 65 0d |TS..V..welldone.|
00000730 04 60 0d 20 4a 53 52 20 77 61 69 74 0d 04 6a 0b |.`. JSR wait..j.|
00000740 20 4c 44 58 20 23 30 0d 04 74 08 2e 6d 73 67 0d | LDX #0..t..msg.|
00000750 04 7e 0f 20 4c 44 41 20 74 65 78 74 2c 58 0d 04 |.~. LDA text,X..|
00000760 88 0f 20 4a 53 52 20 6f 73 77 72 63 68 0d 04 92 |.. JSR oswrch...|
00000770 08 20 49 4e 58 0d 04 9c 0b 20 43 4d 50 20 23 30 |. INX.... CMP #0|
00000780 0d 04 a6 0c 20 42 4e 45 20 6d 73 67 0d 04 b0 0c |.... BNE msg....|
00000790 20 4c 44 41 20 23 32 31 0d 04 ba 0b 20 4c 44 58 | LDA #21.... LDX|
000007a0 20 23 30 0d 04 c4 0f 20 4a 53 52 20 6f 73 62 79 | #0.... JSR osby|
000007b0 74 65 0d 04 ce 08 20 52 54 53 0d 04 d8 09 2e 77 |te.... RTS.....w|
000007c0 61 69 74 0d 04 e2 0d 20 4c 44 58 20 23 32 35 35 |ait.... LDX #255|
000007d0 0d 04 ec 10 2e 77 31 20 4c 44 59 20 23 32 35 35 |.....w1 LDY #255|
000007e0 0d 04 f6 1f 2e 77 32 20 4e 4f 50 3a 4e 4f 50 3a |.....w2 NOP:NOP:|
000007f0 4e 4f 50 3a 4e 4f 50 3a 4e 4f 50 3a 4e 4f 50 0d |NOP:NOP:NOP:NOP.|
00000800 05 00 08 20 44 45 59 0d 05 0a 0b 20 42 4e 45 20 |... DEY.... BNE |
00000810 77 32 0d 05 14 08 20 44 45 58 0d 05 1e 0b 20 42 |w2.... DEX.... B|
00000820 4e 45 20 77 31 0d 05 28 08 20 52 54 53 0d 05 32 |NE w1..(. RTS..2|
00000830 09 2e 74 65 78 74 0d 05 3c 12 20 4f 50 54 20 a4 |..text..<. OPT .|
00000840 65 71 75 62 28 32 32 29 0d 05 46 11 20 4f 50 54 |equb(22)..F. OPT|
00000850 20 a4 65 71 75 62 28 35 29 0d 05 50 12 20 4f 50 | .equb(5)..P. OP|
00000860 54 20 a4 65 71 75 62 28 33 31 29 0d 05 5a 11 20 |T .equb(31)..Z. |
00000870 4f 50 54 20 a4 65 71 75 62 28 32 29 0d 05 64 11 |OPT .equb(2)..d.|
00000880 20 4f 50 54 20 a4 65 71 75 62 28 34 29 0d 05 6e | OPT .equb(4)..n|
00000890 1c 20 4f 50 54 20 a4 65 71 75 73 28 22 57 65 6c |. OPT .equs("Wel|
000008a0 6c 20 44 6f 6e 65 21 22 29 0d 05 78 12 20 4f 50 |l Done!")..x. OP|
000008b0 54 20 a4 65 71 75 62 28 33 31 29 0d 05 82 11 20 |T .equb(31).... |
000008c0 4f 50 54 20 a4 65 71 75 62 28 32 29 0d 05 8c 11 |OPT .equb(2)....|
000008d0 20 4f 50 54 20 a4 65 71 75 62 28 36 29 0d 05 96 | OPT .equb(6)...|
000008e0 24 20 4f 50 54 20 a4 65 71 75 73 28 22 4c 65 76 |$ OPT .equs("Lev|
000008f0 65 6c 20 31 20 43 6f 6d 70 6c 65 74 65 64 21 22 |el 1 Completed!"|
00000900 29 0d 05 a0 08 20 42 52 4b 0d 05 aa 25 2e 70 6c |).... BRK...%.pl|
00000910 6f 74 20 4c 44 41 20 61 64 64 72 3a 50 48 41 3a |ot LDA addr:PHA:|
00000920 4c 44 41 20 61 64 64 72 2b 31 3a 50 48 41 0d 05 |LDA addr+1:PHA..|
00000930 b4 26 20 4c 44 41 20 61 3a 53 54 41 20 61 64 64 |.& LDA a:STA add|
00000940 72 3a 4c 44 41 20 61 2b 31 3a 53 54 41 20 61 64 |r:LDA a+1:STA ad|
00000950 64 72 2b 31 0d 05 be 11 20 4a 53 52 20 65 6f 72 |dr+1.... JSR eor|
00000960 73 70 6c 6f 74 0d 05 c8 20 20 50 4c 41 3a 53 54 |splot... PLA:ST|
00000970 41 20 61 64 64 72 2b 31 3a 50 4c 41 20 53 54 41 |A addr+1:PLA STA|
00000980 20 61 64 64 72 0d 05 d2 08 20 52 54 53 0d 05 dc | addr.... RTS...|
00000990 1e 2e 73 70 6c 6f 74 20 20 20 20 20 20 20 5c 20 |..splot \ |
000009a0 70 6c 6f 74 20 73 70 72 69 74 65 0d 05 e6 0d 20 |plot sprite.... |
000009b0 4c 44 41 20 61 64 64 72 0d 05 f0 08 20 50 48 41 |LDA addr.... PHA|
000009c0 0d 05 fa 0f 20 53 54 41 20 74 63 61 64 64 72 0d |.... STA tcaddr.|
000009d0 06 04 0f 20 4c 44 41 20 61 64 64 72 2b 31 0d 06 |... LDA addr+1..|
000009e0 0e 08 20 50 48 41 0d 06 18 11 20 53 54 41 20 74 |.. PHA.... STA t|
000009f0 63 61 64 64 72 2b 31 0d 06 22 07 2e 6c 31 0d 06 |caddr+1.."..l1..|
00000a00 2c 0b 20 4c 44 59 20 23 30 0d 06 36 0b 20 4c 44 |,. LDY #0..6. LD|
00000a10 58 20 23 34 0d 06 40 07 2e 6c 32 0d 06 4a 1f 20 |X #4..@..l2..J. |
00000a20 4c 44 41 20 28 64 61 74 61 29 2c 59 20 5c 20 54 |LDA (data),Y \ T|
00000a30 68 69 73 20 69 73 20 6e 6f 74 0d 06 54 24 20 53 |his is not..T$ S|
00000a40 54 41 20 28 61 64 64 72 29 2c 59 20 5c 20 62 61 |TA (addr),Y \ ba|
00000a50 64 20 70 72 6f 67 72 61 6d 6d 69 6e 67 21 0d 06 |d programming!..|
00000a60 5e 23 20 49 4e 59 20 20 20 20 20 20 20 20 20 20 |^# INY |
00000a70 5c 20 4d 61 6b 65 73 20 69 74 20 66 61 73 74 65 |\ Makes it faste|
00000a80 72 0d 06 68 11 20 4c 44 41 20 28 64 61 74 61 29 |r..h. LDA (data)|
00000a90 2c 59 0d 06 72 11 20 53 54 41 20 28 61 64 64 72 |,Y..r. STA (addr|
00000aa0 29 2c 59 0d 06 7c 08 20 49 4e 59 0d 06 86 11 20 |),Y..|. INY.... |
00000ab0 4c 44 41 20 28 64 61 74 61 29 2c 59 0d 06 90 11 |LDA (data),Y....|
00000ac0 20 53 54 41 20 28 61 64 64 72 29 2c 59 0d 06 9a | STA (addr),Y...|
00000ad0 08 20 49 4e 59 0d 06 a4 11 20 4c 44 41 20 28 64 |. INY.... LDA (d|
00000ae0 61 74 61 29 2c 59 0d 06 ae 11 20 53 54 41 20 28 |ata),Y.... STA (|
00000af0 61 64 64 72 29 2c 59 0d 06 b8 08 20 49 4e 59 0d |addr),Y.... INY.|
00000b00 06 c2 11 20 4c 44 41 20 28 64 61 74 61 29 2c 59 |... LDA (data),Y|
00000b10 0d 06 cc 11 20 53 54 41 20 28 61 64 64 72 29 2c |.... STA (addr),|
00000b20 59 0d 06 d6 08 20 49 4e 59 0d 06 e0 11 20 4c 44 |Y.... INY.... LD|
00000b30 41 20 28 64 61 74 61 29 2c 59 0d 06 ea 11 20 53 |A (data),Y.... S|
00000b40 54 41 20 28 61 64 64 72 29 2c 59 0d 06 f4 08 20 |TA (addr),Y.... |
00000b50 49 4e 59 0d 06 fe 11 20 4c 44 41 20 28 64 61 74 |INY.... LDA (dat|
00000b60 61 29 2c 59 0d 07 08 11 20 53 54 41 20 28 61 64 |a),Y.... STA (ad|
00000b70 64 72 29 2c 59 0d 07 12 08 20 49 4e 59 0d 07 1c |dr),Y.... INY...|
00000b80 11 20 4c 44 41 20 28 64 61 74 61 29 2c 59 0d 07 |. LDA (data),Y..|
00000b90 26 11 20 53 54 41 20 28 61 64 64 72 29 2c 59 0d |&. STA (addr),Y.|
00000ba0 07 30 08 20 49 4e 59 0d 07 3a 0d 20 4c 44 41 20 |.0. INY..:. LDA |
00000bb0 61 64 64 72 0d 07 44 08 20 43 4c 43 0d 07 4e 0d |addr..D. CLC..N.|
00000bc0 20 41 44 43 20 23 26 33 38 0d 07 58 0d 20 53 54 | ADC #&38..X. ST|
00000bd0 41 20 61 64 64 72 0d 07 62 0f 20 4c 44 41 20 61 |A addr..b. LDA a|
00000be0 64 64 72 2b 31 0d 07 6c 0b 20 41 44 43 20 23 31 |ddr+1..l. ADC #1|
00000bf0 0d 07 76 0f 20 53 54 41 20 61 64 64 72 2b 31 0d |..v. STA addr+1.|
00000c00 07 80 08 20 44 45 58 0d 07 8a 0b 20 42 4e 45 20 |... DEX.... BNE |
00000c10 6c 32 0d 07 94 0d 20 4c 44 41 20 64 61 74 61 0d |l2.... LDA data.|
00000c20 07 9e 08 20 43 4c 43 0d 07 a8 12 20 41 44 43 20 |... CLC.... ADC |
00000c30 23 53 70 72 44 65 70 74 68 0d 07 b2 0d 20 53 54 |#SprDepth.... ST|
00000c40 41 20 64 61 74 61 0d 07 bc 0f 20 4c 44 41 20 64 |A data.... LDA d|
00000c50 61 74 61 2b 31 0d 07 c6 0b 20 41 44 43 20 23 30 |ata+1.... ADC #0|
00000c60 0d 07 d0 0f 20 53 54 41 20 64 61 74 61 2b 31 0d |.... STA data+1.|
00000c70 07 da 0f 20 4c 44 41 20 74 63 61 64 64 72 0d 07 |... LDA tcaddr..|
00000c80 e4 0b 20 41 44 43 20 23 38 0d 07 ee 0d 20 53 54 |.. ADC #8.... ST|
00000c90 41 20 61 64 64 72 0d 07 f8 0f 20 53 54 41 20 74 |A addr.... STA t|
00000ca0 63 61 64 64 72 0d 08 02 11 20 4c 44 41 20 74 63 |caddr.... LDA tc|
00000cb0 61 64 64 72 2b 31 0d 08 0c 0b 20 41 44 43 20 23 |addr+1.... ADC #|
00000cc0 30 0d 08 16 11 20 53 54 41 20 74 63 61 64 64 72 |0.... STA tcaddr|
00000cd0 2b 31 0d 08 20 0f 20 53 54 41 20 61 64 64 72 2b |+1.. . STA addr+|
00000ce0 31 0d 08 2a 0d 20 44 45 43 20 63 6f 6c 73 0d 08 |1..*. DEC cols..|
00000cf0 34 0b 20 42 4e 45 20 6c 31 0d 08 3e 08 20 50 4c |4. BNE l1..>. PL|
00000d00 41 0d 08 48 0f 20 53 54 41 20 61 64 64 72 2b 31 |A..H. STA addr+1|
00000d10 0d 08 52 08 20 50 4c 41 0d 08 5c 0d 20 53 54 41 |..R. PLA..\. STA|
00000d20 20 61 64 64 72 0d 08 66 08 20 52 54 53 0d 08 70 | addr..f. RTS..p|
00000d30 1e 2e 73 70 6c 6f 74 32 20 20 20 20 20 20 20 20 |..splot2 |
00000d40 5c 20 74 6f 20 65 6e 61 62 6c 65 0d 08 7a 1c 20 |\ to enable..z. |
00000d50 4c 44 41 20 23 53 70 72 57 69 64 74 68 20 5c 20 |LDA #SprWidth \ |
00000d60 72 65 76 65 72 73 65 0d 08 84 24 20 53 45 43 20 |reverse...$ SEC |
00000d70 20 20 20 20 20 20 20 20 20 20 5c 20 73 70 72 69 | \ spri|
00000d80 74 65 2d 63 6c 69 70 70 69 6e 67 0d 08 8e 0d 20 |te-clipping.... |
00000d90 53 42 43 20 63 6f 6c 73 0d 08 98 08 20 54 41 59 |SBC cols.... TAY|
00000da0 0d 08 a2 10 20 42 45 51 20 64 6f 73 70 6c 6f 74 |.... BEQ dosplot|
00000db0 0d 08 ac 08 2e 73 32 6c 0d 08 b6 0d 20 4c 44 41 |.....s2l.... LDA|
00000dc0 20 64 61 74 61 0d 08 c0 08 20 43 4c 43 0d 08 ca | data.... CLC...|
00000dd0 12 20 41 44 43 20 23 53 70 72 44 65 70 74 68 0d |. ADC #SprDepth.|
00000de0 08 d4 0d 20 53 54 41 20 64 61 74 61 0d 08 de 0f |... STA data....|
00000df0 20 4c 44 41 20 64 61 74 61 2b 31 0d 08 e8 0b 20 | LDA data+1.... |
00000e00 41 44 43 20 23 30 0d 08 f2 0f 20 53 54 41 20 64 |ADC #0.... STA d|
00000e10 61 74 61 2b 31 0d 08 fc 08 20 44 45 59 0d 09 06 |ata+1.... DEY...|
00000e20 0c 20 42 4e 45 20 73 32 6c 0d 09 10 0c 2e 64 6f |. BNE s2l.....do|
00000e30 73 70 6c 6f 74 0d 09 1a 0e 20 4a 4d 50 20 73 70 |splot.... JMP sp|
00000e40 6c 6f 74 0d 09 24 0d 2e 65 6f 72 73 70 6c 6f 74 |lot..$..eorsplot|
00000e50 0d 09 2e 0d 20 4c 44 41 20 61 64 64 72 0d 09 38 |.... LDA addr..8|
00000e60 08 20 50 48 41 0d 09 42 0f 20 53 54 41 20 74 63 |. PHA..B. STA tc|
00000e70 61 64 64 72 0d 09 4c 0f 20 4c 44 41 20 61 64 64 |addr..L. LDA add|
00000e80 72 2b 31 0d 09 56 08 20 50 48 41 0d 09 60 11 20 |r+1..V. PHA..`. |
00000e90 53 54 41 20 74 63 61 64 64 72 2b 31 0d 09 6a 08 |STA tcaddr+1..j.|
00000ea0 2e 65 6c 31 0d 09 74 0b 20 4c 44 59 20 23 30 0d |.el1..t. LDY #0.|
00000eb0 09 7e 12 20 4c 44 58 20 23 34 3a 53 54 58 20 63 |.~. LDX #4:STX c|
00000ec0 64 0d 09 88 10 2e 65 65 6c 32 20 4c 44 58 20 23 |d.....eel2 LDX #|
00000ed0 38 0d 09 92 08 2e 65 6c 32 0d 09 9c 1b 20 4c 44 |8.....el2.... LD|
00000ee0 41 20 28 64 61 74 61 29 2c 59 3a 42 45 51 20 62 |A (data),Y:BEQ b|
00000ef0 6c 61 63 6b 0d 09 a6 1f 20 50 48 41 3a 4c 44 41 |lack.... PHA:LDA|
00000f00 20 28 61 64 64 72 29 2c 59 3a 42 45 51 20 6e 6f | (addr),Y:BEQ no|
00000f10 68 69 74 0d 09 b0 19 20 4c 44 41 20 23 31 3a 53 |hit.... LDA #1:S|
00000f20 54 41 20 64 65 61 74 68 66 6c 61 67 0d 09 ba 0a |TA deathflag....|
00000f30 2e 6e 6f 68 69 74 0d 09 c4 08 20 50 4c 41 0d 09 |.nohit.... PLA..|
00000f40 ce 0a 2e 62 6c 61 63 6b 0d 09 d8 20 20 82 20 28 |...black... . (|
00000f50 61 64 64 72 29 2c 59 3a 53 54 41 20 28 61 64 64 |addr),Y:STA (add|
00000f60 72 29 2c 59 3a 49 4e 59 0d 09 e2 10 20 44 45 58 |r),Y:INY.... DEX|
00000f70 3a 42 4e 45 20 65 6c 32 0d 09 ec 23 20 4c 44 41 |:BNE el2...# LDA|
00000f80 20 61 64 64 72 3a 43 4c 43 3a 41 44 43 20 23 26 | addr:CLC:ADC #&|
00000f90 33 38 3a 53 54 41 20 61 64 64 72 0d 09 f6 21 20 |38:STA addr...! |
00000fa0 4c 44 41 20 61 64 64 72 2b 31 3a 41 44 43 20 23 |LDA addr+1:ADC #|
00000fb0 31 3a 53 54 41 20 61 64 64 72 2b 31 0d 0a 00 0b |1:STA addr+1....|
00000fc0 20 44 45 43 20 63 64 0d 0a 0a 0d 20 42 4e 45 20 | DEC cd.... BNE |
00000fd0 65 65 6c 32 0d 0a 14 0d 20 4c 44 41 20 64 61 74 |eel2.... LDA dat|
00000fe0 61 0d 0a 1e 1f 20 43 4c 43 3a 41 44 43 20 23 53 |a.... CLC:ADC #S|
00000ff0 70 72 44 65 70 74 68 3a 53 54 41 20 64 61 74 61 |prDepth:STA data|
00001000 0d 0a 28 21 20 4c 44 41 20 64 61 74 61 2b 31 3a |..(! LDA data+1:|
00001010 41 44 43 20 23 30 3a 53 54 41 20 64 61 74 61 2b |ADC #0:STA data+|
00001020 31 0d 0a 32 1f 20 4c 44 41 20 74 63 61 64 64 72 |1..2. LDA tcaddr|
00001030 3a 41 44 43 20 23 38 3a 53 54 41 20 61 64 64 72 |:ADC #8:STA addr|
00001040 0d 0a 3c 0f 20 53 54 41 20 74 63 61 64 64 72 0d |..<. STA tcaddr.|
00001050 0a 46 25 20 4c 44 41 20 74 63 61 64 64 72 2b 31 |.F% LDA tcaddr+1|
00001060 3a 41 44 43 20 23 30 3a 53 54 41 20 74 63 61 64 |:ADC #0:STA tcad|
00001070 64 72 2b 31 0d 0a 50 0f 20 53 54 41 20 61 64 64 |dr+1..P. STA add|
00001080 72 2b 31 0d 0a 5a 0d 20 44 45 43 20 63 6f 6c 73 |r+1..Z. DEC cols|
00001090 0d 0a 64 0c 20 42 4e 45 20 65 6c 31 0d 0a 6e 13 |..d. BNE el1..n.|
000010a0 20 50 4c 41 3a 53 54 41 20 61 64 64 72 2b 31 0d | PLA:STA addr+1.|
000010b0 0a 78 11 20 50 4c 41 3a 53 54 41 20 61 64 64 72 |.x. PLA:STA addr|
000010c0 0d 0a 82 08 20 52 54 53 0d 0a 8c 20 2e 73 77 69 |.... RTS... .swi|
000010d0 74 63 68 31 20 20 20 20 5c 20 63 68 61 6e 67 65 |tch1 \ change|
000010e0 20 73 63 72 65 65 6e 20 0d 0a 96 1f 20 4c 44 41 | screen .... LDA|
000010f0 20 23 31 39 20 20 20 20 5c 20 73 74 61 72 74 20 | #19 \ start |
00001100 61 64 64 72 65 73 73 0d 0a a0 1d 20 4a 53 52 20 |address.... JSR |
00001110 6f 73 62 79 74 65 20 5c 20 74 6f 20 73 63 72 65 |osbyte \ to scre|
00001120 65 6e 20 31 0d 0a aa 0c 20 4c 44 41 20 23 31 33 |en 1.... LDA #13|
00001130 0d 0a b4 0e 20 53 54 41 20 26 46 45 30 30 0d 0a |.... STA &FE00..|
00001140 be 1e 20 4c 44 41 20 23 28 73 63 72 65 65 6e 31 |.. LDA #(screen1|
00001150 20 83 20 32 30 34 38 20 81 20 38 29 0d 0a c8 0e | . 2048 . 8)....|
00001160 20 53 54 41 20 26 46 45 30 31 0d 0a d2 0c 20 4c | STA &FE01.... L|
00001170 44 41 20 23 31 32 0d 0a dc 0e 20 53 54 41 20 26 |DA #12.... STA &|
00001180 46 45 30 30 0d 0a e6 1a 20 4c 44 41 20 23 28 73 |FE00.... LDA #(s|
00001190 63 72 65 65 6e 31 20 81 20 32 30 34 38 29 0d 0a |creen1 . 2048)..|
000011a0 f0 0e 20 53 54 41 20 26 46 45 30 31 0d 0a fa 12 |.. STA &FE01....|
000011b0 20 4c 44 41 20 23 31 3a 53 54 41 20 73 6e 0d 0b | LDA #1:STA sn..|
000011c0 04 08 20 52 54 53 0d 0b 0e 0c 2e 73 77 69 74 63 |.. RTS.....switc|
000011d0 68 32 0d 0b 18 1f 20 4c 44 41 20 23 31 39 20 20 |h2.... LDA #19 |
000011e0 20 20 5c 20 63 68 61 6e 67 65 20 73 63 72 65 65 | \ change scree|
000011f0 6e 0d 0b 22 1f 20 4a 53 52 20 6f 73 62 79 74 65 |n..". JSR osbyte|
00001200 20 5c 20 73 74 61 72 74 20 61 64 64 72 65 73 73 | \ start address|
00001210 0d 0b 2c 1d 20 4c 44 41 20 23 31 33 20 20 20 20 |..,. LDA #13 |
00001220 5c 20 74 6f 20 73 63 72 65 65 6e 20 32 0d 0b 36 |\ to screen 2..6|
00001230 0e 20 53 54 41 20 26 46 45 30 30 0d 0b 40 1e 20 |. STA &FE00..@. |
00001240 4c 44 41 20 23 28 73 63 72 65 65 6e 32 20 83 20 |LDA #(screen2 . |
00001250 32 30 34 38 20 81 20 38 29 0d 0b 4a 0e 20 53 54 |2048 . 8)..J. ST|
00001260 41 20 26 46 45 30 31 0d 0b 54 0c 20 4c 44 41 20 |A &FE01..T. LDA |
00001270 23 31 32 0d 0b 5e 0e 20 53 54 41 20 26 46 45 30 |#12..^. STA &FE0|
00001280 30 0d 0b 68 1a 20 4c 44 41 20 23 28 73 63 72 65 |0..h. LDA #(scre|
00001290 65 6e 32 20 81 20 32 30 34 38 29 0d 0b 72 0e 20 |en2 . 2048)..r. |
000012a0 53 54 41 20 26 46 45 30 31 0d 0b 7c 12 20 4c 44 |STA &FE01..|. LD|
000012b0 41 20 23 32 3a 53 54 41 20 73 6e 0d 0b 86 08 20 |A #2:STA sn.... |
000012c0 52 54 53 0d 0b 90 0b 2e 73 63 72 6f 6c 6c 0d 0b |RTS.....scroll..|
000012d0 9a 0c 20 4c 44 41 20 23 32 32 0d 0b a4 0f 20 4a |.. LDA #22.... J|
000012e0 53 52 20 6f 73 77 72 63 68 0d 0b ae 0b 20 4c 44 |SR oswrch.... LD|
000012f0 41 20 23 35 0d 0b b8 0f 20 4a 53 52 20 6f 73 77 |A #5.... JSR osw|
00001300 72 63 68 0d 0b c2 17 20 4c 44 41 20 23 32 33 3a |rch.... LDA #23:|
00001310 4a 53 52 20 6f 73 77 72 63 68 0d 0b cc 16 20 4c |JSR oswrch.... L|
00001320 44 41 20 23 30 3a 4a 53 52 20 6f 73 77 72 63 68 |DA #0:JSR oswrch|
00001330 0d 0b d6 17 20 4c 44 41 20 23 31 30 3a 4a 53 52 |.... LDA #10:JSR|
00001340 20 6f 73 77 72 63 68 0d 0b e0 17 20 4c 44 41 20 | oswrch.... LDA |
00001350 23 33 32 3a 4a 53 52 20 6f 73 77 72 63 68 0d 0b |#32:JSR oswrch..|
00001360 ea 21 20 4c 44 41 20 23 30 3a 4a 53 52 20 6f 73 |.! LDA #0:JSR os|
00001370 77 72 63 68 3a 4a 53 52 20 6f 73 77 72 63 68 0d |wrch:JSR oswrch.|
00001380 0b f4 1a 20 4a 53 52 20 6f 73 77 72 63 68 3a 4a |... JSR oswrch:J|
00001390 53 52 20 6f 73 77 72 63 68 0d 0b fe 1a 20 4a 53 |SR oswrch.... JS|
000013a0 52 20 6f 73 77 72 63 68 3a 4a 53 52 20 6f 73 77 |R oswrch:JSR osw|
000013b0 72 63 68 0d 0c 08 1f 20 4c 44 41 20 23 30 20 20 |rch.... LDA #0 |
000013c0 5c 20 63 6c 65 61 72 20 62 72 65 61 6b 20 66 6c |\ clear break fl|
000013d0 61 67 0d 0c 12 0c 20 53 54 41 20 26 46 46 0d 0c |ag.... STA &FF..|
000013e0 1c 12 20 53 54 41 20 64 65 61 74 68 66 6c 61 67 |.. STA deathflag|
000013f0 0d 0c 26 0b 20 4c 44 59 20 23 30 0d 0c 30 15 20 |..&. LDY #0..0. |
00001400 4c 44 41 20 23 26 33 30 30 30 20 83 20 32 35 36 |LDA #&3000 . 256|
00001410 0d 0c 3a 0c 20 53 54 41 20 26 39 30 0d 0c 44 15 |..:. STA &90..D.|
00001420 20 4c 44 41 20 23 26 33 30 30 30 20 81 20 32 35 | LDA #&3000 . 25|
00001430 36 0d 0c 4e 0c 20 53 54 41 20 26 39 31 0d 0c 58 |6..N. STA &91..X|
00001440 0a 2e 62 6c 6f 6f 70 0d 0c 62 0b 20 4c 44 41 20 |..bloop..b. LDA |
00001450 23 30 0d 0c 6c 1d 20 53 54 41 20 28 26 39 30 29 |#0..l. STA (&90)|
00001460 2c 59 20 5c 20 63 6c 65 61 72 20 62 6f 74 68 0d |,Y \ clear both.|
00001470 0c 76 21 20 4c 44 41 20 26 39 30 20 20 20 20 20 |.v! LDA &90 |
00001480 5c 20 6f 66 20 74 68 65 20 73 63 72 65 65 6e 73 |\ of the screens|
00001490 0d 0c 80 21 20 43 4c 43 20 20 20 20 20 20 20 20 |...! CLC |
000014a0 20 5c 20 2d 4e 42 2d 20 74 68 69 73 20 77 69 6c | \ -NB- this wil|
000014b0 6c 0d 0c 8a 21 20 41 44 43 20 23 31 20 20 20 20 |l...! ADC #1 |
000014c0 20 20 5c 20 63 6c 65 61 72 20 66 72 6f 6d 20 74 | \ clear from t|
000014d0 68 65 0d 0c 94 23 20 53 54 41 20 26 39 30 20 20 |he...# STA &90 |
000014e0 20 20 20 5c 20 73 74 61 72 74 20 6f 66 20 73 63 | \ start of sc|
000014f0 72 65 65 6e 31 0d 0c 9e 21 20 42 43 43 20 6e 63 |reen1...! BCC nc|
00001500 20 20 20 20 20 20 5c 20 61 6c 6c 20 74 68 65 20 | \ all the |
00001510 77 61 79 20 74 6f 0d 0c a8 18 20 49 4e 43 20 26 |way to.... INC &|
00001520 39 31 20 20 20 20 20 5c 20 26 37 46 46 46 0d 0c |91 \ &7FFF..|
00001530 b2 07 2e 6e 63 0d 0c bc 0c 20 4c 44 41 20 26 39 |...nc.... LDA &9|
00001540 30 0d 0c c6 15 20 43 4d 50 20 23 26 38 30 30 30 |0.... CMP #&8000|
00001550 20 83 20 32 35 36 0d 0c d0 0e 20 42 4e 45 20 62 | . 256.... BNE b|
00001560 6c 6f 6f 70 0d 0c da 0c 20 4c 44 41 20 26 39 31 |loop.... LDA &91|
00001570 0d 0c e4 15 20 43 4d 50 20 23 26 38 30 30 30 20 |.... CMP #&8000 |
00001580 81 20 32 35 36 0d 0c ee 0e 20 42 4e 45 20 62 6c |. 256.... BNE bl|
00001590 6f 6f 70 0d 0c f8 20 20 4c 44 41 20 23 6d 61 70 |oop... LDA #map|
000015a0 20 83 20 32 35 36 20 5c 20 69 6e 69 74 69 61 6c | . 256 \ initial|
000015b0 69 73 65 0d 0d 02 23 20 53 54 41 20 26 37 30 20 |ise...# STA &70 |
000015c0 20 20 20 20 20 20 20 20 20 5c 20 70 6f 69 6e 74 | \ point|
000015d0 65 72 73 20 74 6f 0d 0d 0c 1e 20 4c 44 41 20 23 |ers to.... LDA #|
000015e0 6d 61 70 20 81 20 32 35 36 20 5c 20 6d 61 70 20 |map . 256 \ map |
000015f0 64 61 74 61 0d 0d 16 0c 20 53 54 41 20 26 37 31 |data.... STA &71|
00001600 0d 0d 20 20 2e 73 63 72 6c 6f 6f 70 20 20 20 20 |.. .scrloop |
00001610 20 20 5c 20 63 6f 6e 74 72 6f 6c 20 6c 6f 6f 70 | \ control loop|
00001620 0d 0d 2a 0d 20 4a 53 52 20 64 65 6d 6f 0d 0d 34 |..*. JSR demo..4|
00001630 26 20 4a 53 52 20 73 77 69 74 63 68 31 20 20 5c |& JSR switch1 \|
00001640 20 73 77 69 74 63 68 20 74 6f 20 73 63 72 65 65 | switch to scree|
00001650 6e 20 31 0d 0d 3e 0d 20 43 4d 50 20 23 26 45 41 |n 1..>. CMP #&EA|
00001660 0d 0d 48 17 20 4c 44 41 20 23 73 63 72 65 65 6e |..H. LDA #screen|
00001670 32 20 83 20 32 35 36 0d 0d 52 08 20 43 4c 43 0d |2 . 256..R. CLC.|
00001680 0d 5c 15 20 41 44 43 20 23 41 4c 49 47 4e 20 83 |.\. ADC #ALIGN .|
00001690 20 32 35 36 0d 0d 66 0f 20 53 54 41 20 6d 61 70 | 256..f. STA map|
000016a0 74 6f 70 0d 0d 70 17 20 4c 44 41 20 23 73 63 72 |top..p. LDA #scr|
000016b0 65 65 6e 32 20 81 20 32 35 36 0d 0d 7a 15 20 41 |een2 . 256..z. A|
000016c0 44 43 20 23 41 4c 49 47 4e 20 81 20 32 35 36 0d |DC #ALIGN . 256.|
000016d0 0d 84 11 20 53 54 41 20 6d 61 70 74 6f 70 2b 31 |... STA maptop+1|
000016e0 0d 0d 8e 26 20 4a 53 52 20 70 6c 6f 74 6d 61 70 |...& JSR plotmap|
000016f0 20 5c 20 70 6c 6f 74 20 6d 61 70 20 6f 76 65 72 | \ plot map over|
00001700 20 73 63 72 20 32 0d 0d 98 0d 20 43 4d 50 20 23 | scr 2.... CMP #|
00001710 26 45 41 0d 0d a2 0e 20 42 4e 45 20 63 6f 6e 74 |&EA.... BNE cont|
00001720 31 0d 0d ac 11 20 4a 53 52 20 77 65 6c 6c 64 6f |1.... JSR welldo|
00001730 6e 65 0d 0d b6 08 20 52 54 53 0d 0d c0 0a 2e 63 |ne.... RTS.....c|
00001740 6f 6e 74 31 0d 0d ca 0d 20 4a 53 52 20 64 65 6d |ont1.... JSR dem|
00001750 6f 0d 0d d4 26 20 4a 53 52 20 73 77 69 74 63 68 |o...& JSR switch|
00001760 32 20 5c 20 72 65 76 65 61 6c 20 6d 61 70 20 6f |2 \ reveal map o|
00001770 6e 20 73 63 72 20 32 0d 0d de 17 20 4c 44 41 20 |n scr 2.... LDA |
00001780 23 73 63 72 65 65 6e 31 20 83 20 32 35 36 0d 0d |#screen1 . 256..|
00001790 e8 08 20 43 4c 43 0d 0d f2 15 20 41 44 43 20 23 |.. CLC.... ADC #|
000017a0 41 4c 49 47 4e 20 83 20 32 35 36 0d 0d fc 0f 20 |ALIGN . 256.... |
000017b0 53 54 41 20 6d 61 70 74 6f 70 0d 0e 06 17 20 4c |STA maptop.... L|
000017c0 44 41 20 23 73 63 72 65 65 6e 31 20 81 20 32 35 |DA #screen1 . 25|
000017d0 36 0d 0e 10 15 20 41 44 43 20 23 41 4c 49 47 4e |6.... ADC #ALIGN|
000017e0 20 81 20 32 35 36 0d 0e 1a 11 20 53 54 41 20 6d | . 256.... STA m|
000017f0 61 70 74 6f 70 2b 31 0d 0e 24 26 20 4a 53 52 20 |aptop+1..$& JSR |
00001800 70 6c 6f 74 6d 61 70 20 5c 20 70 6c 6f 74 20 6d |plotmap \ plot m|
00001810 61 70 20 6f 76 65 72 20 73 63 72 20 31 0d 0e 2e |ap over scr 1...|
00001820 0d 20 43 4d 50 20 23 26 45 41 0d 0e 38 0e 20 42 |. CMP #&EA..8. B|
00001830 4e 45 20 63 6f 6e 74 32 0d 0e 42 11 20 4a 53 52 |NE cont2..B. JSR|
00001840 20 77 65 6c 6c 64 6f 6e 65 0d 0e 4c 08 20 52 54 | welldone..L. RT|
00001850 53 0d 0e 56 0a 2e 63 6f 6e 74 32 0d 0e 60 12 20 |S..V..cont2..`. |
00001860 4c 44 41 20 64 65 61 74 68 66 6c 61 67 0d 0e 6a |LDA deathflag..j|
00001870 0b 20 43 4d 50 20 23 32 0d 0e 74 13 20 42 43 43 |. CMP #2..t. BCC|
00001880 20 6e 6f 74 64 65 61 64 79 65 74 0d 0e 7e 0f 20 | notdeadyet..~. |
00001890 4a 4d 50 20 73 63 72 6f 6c 6c 0d 0e 88 0f 2e 6e |JMP scroll.....n|
000018a0 6f 74 64 65 61 64 79 65 74 0d 0e 92 21 20 42 49 |otdeadyet...! BI|
000018b0 54 20 26 46 46 20 20 20 20 20 5c 20 74 65 73 74 |T &FF \ test|
000018c0 20 66 6f 72 20 62 72 65 61 6b 0d 0e 9c 10 20 42 | for break.... B|
000018d0 45 51 20 73 63 72 6c 6f 6f 70 0d 0e a6 08 20 42 |EQ scrloop.... B|
000018e0 52 4b 0d 0e b0 12 20 4f 50 54 20 a4 65 71 75 62 |RK.... OPT .equb|
000018f0 28 32 37 29 0d 0e ba 18 20 4f 50 54 20 a4 65 71 |(27).... OPT .eq|
00001900 75 73 28 22 45 73 63 61 70 65 22 29 0d 0e c4 08 |us("Escape")....|
00001910 20 42 52 4b 0d 0e ce 21 2e 70 6c 6f 74 6d 61 70 | BRK...!.plotmap|
00001920 20 20 20 20 20 20 5c 20 70 6c 6f 74 20 61 20 73 | \ plot a s|
00001930 63 72 65 65 6e 0d 0e d8 25 20 49 4e 43 20 63 6f |creen...% INC co|
00001940 75 6e 74 65 72 20 20 5c 20 66 72 6f 6d 20 74 68 |unter \ from th|
00001950 65 20 6d 61 70 20 64 61 74 61 0d 0e e2 0c 20 4c |e map data.... L|
00001960 44 41 20 26 37 30 0d 0e ec 0e 20 53 54 41 20 6f |DA &70.... STA o|
00001970 6c 64 37 30 0d 0e f6 0c 20 4c 44 41 20 26 37 31 |ld70.... LDA &71|
00001980 0d 0f 00 10 20 53 54 41 20 6f 6c 64 37 30 2b 31 |.... STA old70+1|
00001990 0d 0f 0a 0b 20 4c 44 59 20 23 30 0d 0f 14 0d 20 |.... LDY #0.... |
000019a0 53 54 59 20 6d 63 6f 6c 0d 0f 1e 0f 20 4c 44 41 |STY mcol.... LDA|
000019b0 20 6d 61 70 74 6f 70 0d 0f 28 0d 20 53 54 41 20 | maptop..(. STA |
000019c0 61 64 64 72 0d 0f 32 11 20 4c 44 41 20 6d 61 70 |addr..2. LDA map|
000019d0 74 6f 70 2b 31 0d 0f 3c 0f 20 53 54 41 20 61 64 |top+1..<. STA ad|
000019e0 64 72 2b 31 0d 0f 46 07 2e 6d 6c 0d 0f 50 0b 20 |dr+1..F..ml..P. |
000019f0 4c 44 59 20 23 30 0d 0f 5a 0d 20 4c 44 41 20 61 |LDY #0..Z. LDA a|
00001a00 64 64 72 0d 0f 64 10 20 53 54 41 20 74 6f 70 61 |ddr..d. STA topa|
00001a10 64 64 72 0d 0f 6e 0f 20 4c 44 41 20 61 64 64 72 |ddr..n. LDA addr|
00001a20 2b 31 0d 0f 78 12 20 53 54 41 20 74 6f 70 61 64 |+1..x. STA topad|
00001a30 64 72 2b 31 0d 0f 82 08 2e 70 6d 6c 0d 0f 8c 24 |dr+1.....pml...$|
00001a40 20 4c 44 41 20 28 26 37 30 29 2c 59 20 20 20 5c | LDA (&70),Y \|
00001a50 20 6c 6f 61 64 20 6d 61 70 20 73 79 6d 62 6f 6c | load map symbol|
00001a60 0d 0f 96 0d 20 43 4d 50 20 23 26 45 41 0d 0f a0 |.... CMP #&EA...|
00001a70 0f 20 42 4e 45 20 6e 6f 74 65 6f 64 0d 0f aa 08 |. BNE noteod....|
00001a80 20 52 54 53 0d 0f b4 0b 2e 6e 6f 74 65 6f 64 0d | RTS.....noteod.|
00001a90 0f be 24 20 4a 53 52 20 73 63 68 6f 6f 73 65 20 |..$ JSR schoose |
00001aa0 20 20 5c 20 61 6e 64 20 63 68 6f 6f 73 65 20 74 | \ and choose t|
00001ab0 68 65 20 0d 0f c8 22 20 4c 44 41 20 6d 63 6f 6c |he ..." LDA mcol|
00001ac0 20 20 20 20 20 20 5c 20 63 6f 72 72 65 73 70 6f | \ correspo|
00001ad0 6e 64 69 6e 67 0d 0f d2 1b 20 42 45 51 20 64 6f |nding.... BEQ do|
00001ae0 63 6c 69 70 20 20 20 20 5c 20 73 70 72 69 74 65 |clip \ sprite|
00001af0 0d 0f dc 12 20 4c 44 41 20 23 53 70 72 57 69 64 |.... LDA #SprWid|
00001b00 74 68 0d 0f e6 0d 20 53 54 41 20 63 6f 6c 73 0d |th.... STA cols.|
00001b10 0f f0 13 20 4a 4d 50 20 6f 76 65 72 64 6f 63 6c |... JMP overdocl|
00001b20 69 70 0d 0f fa 13 2e 64 6f 63 6c 69 70 20 20 20 |ip.....doclip |
00001b30 20 20 20 20 20 0d 10 04 1f 20 4c 44 41 20 6e 63 | .... LDA nc|
00001b40 6f 6c 73 20 20 20 20 20 5c 20 6f 6e 6c 79 20 70 |ols \ only p|
00001b50 72 69 6e 74 0d 10 0e 24 20 53 54 41 20 63 6f 6c |rint...$ STA col|
00001b60 73 20 20 20 20 20 20 5c 20 27 6e 63 6f 6c 73 27 |s \ 'ncols'|
00001b70 20 63 6f 6c 75 6d 6e 73 0d 10 18 22 2e 6f 76 65 | columns...".ove|
00001b80 72 64 6f 63 6c 69 70 20 20 20 20 5c 20 6f 66 20 |rdoclip \ of |
00001b90 74 68 65 20 73 70 72 69 74 65 0d 10 22 0f 20 53 |the sprite..". S|
00001ba0 54 59 20 79 73 74 6f 72 65 0d 10 2c 22 20 4c 44 |TY ystore..," LD|
00001bb0 41 20 6d 63 6f 6c 20 20 20 20 20 20 20 20 5c 20 |A mcol \ |
00001bc0 69 66 20 6e 6f 74 20 6c 61 73 74 0d 10 36 25 20 |if not last..6% |
00001bd0 43 4d 50 20 23 4d 61 70 57 69 64 74 68 2d 31 20 |CMP #MapWidth-1 |
00001be0 5c 20 63 6f 6c 75 6d 6e 20 74 68 65 6e 20 64 6f |\ column then do|
00001bf0 0d 10 40 25 20 42 4e 45 20 64 6f 73 70 6c 6f 74 |..@% BNE dosplot|
00001c00 32 20 20 20 20 5c 20 61 20 72 65 76 65 72 73 65 |2 \ a reverse|
00001c10 20 63 6c 69 70 0d 10 4a 12 20 4c 44 41 20 23 53 | clip..J. LDA #S|
00001c20 70 72 57 69 64 74 68 0d 10 54 08 20 53 45 43 0d |prWidth..T. SEC.|
00001c30 10 5e 0e 20 53 42 43 20 6e 63 6f 6c 73 0d 10 68 |.^. SBC ncols..h|
00001c40 0d 20 42 4e 45 20 67 6f 6f 6e 0d 10 72 12 20 4c |. BNE goon..r. L|
00001c50 44 41 20 23 53 70 72 57 69 64 74 68 0d 10 7c 12 |DA #SprWidth..|.|
00001c60 2e 67 6f 6f 6e 20 53 54 41 20 63 6f 6c 73 0d 10 |.goon STA cols..|
00001c70 86 26 20 4a 53 52 20 73 70 6c 6f 74 20 20 20 20 |.& JSR splot |
00001c80 20 20 5c 20 64 6f 20 74 68 65 20 63 6c 69 70 20 | \ do the clip |
00001c90 74 68 65 20 0d 10 90 26 20 4a 4d 50 20 6f 76 65 |the ...& JMP ove|
00001ca0 72 73 70 6c 6f 74 32 20 5c 20 6f 74 68 65 72 20 |rsplot2 \ other |
00001cb0 77 61 79 20 61 72 6f 75 6e 64 0d 10 9a 0d 2e 64 |way around.....d|
00001cc0 6f 73 70 6c 6f 74 32 0d 10 a4 0f 20 4a 53 52 20 |osplot2.... JSR |
00001cd0 73 70 6c 6f 74 32 0d 10 ae 0f 2e 6f 76 65 72 73 |splot2.....overs|
00001ce0 70 6c 6f 74 32 0d 10 b8 23 20 4c 44 59 20 79 73 |plot2...# LDY ys|
00001cf0 74 6f 72 65 20 20 20 20 20 5c 20 67 6f 20 6f 6e |tore \ go on|
00001d00 20 74 6f 20 6e 65 78 74 0d 10 c2 1d 20 4c 44 41 | to next.... LDA|
00001d10 20 61 64 64 72 20 20 20 20 20 20 20 5c 20 6d 61 | addr \ ma|
00001d20 70 20 72 6f 77 0d 10 cc 08 20 43 4c 43 0d 10 d6 |p row.... CLC...|
00001d30 15 20 41 44 43 20 23 49 6e 63 4e 72 20 83 20 32 |. ADC #IncNr . 2|
00001d40 35 36 0d 10 e0 0d 20 53 54 41 20 61 64 64 72 0d |56.... STA addr.|
00001d50 10 ea 0f 20 4c 44 41 20 61 64 64 72 2b 31 0d 10 |... LDA addr+1..|
00001d60 f4 15 20 41 44 43 20 23 49 6e 63 4e 72 20 81 20 |.. ADC #IncNr . |
00001d70 32 35 36 0d 10 fe 0f 20 53 54 41 20 61 64 64 72 |256.... STA addr|
00001d80 2b 31 0d 11 08 08 20 49 4e 59 0d 11 12 12 20 43 |+1.... INY.... C|
00001d90 50 59 20 23 4d 61 70 44 65 70 74 68 0d 11 1c 0c |PY #MapDepth....|
00001da0 20 42 4e 45 20 70 6d 6c 0d 11 26 0d 20 4c 44 41 | BNE pml..&. LDA|
00001db0 20 6d 63 6f 6c 0d 11 30 0b 20 42 4e 45 20 6f 6b | mcol..0. BNE ok|
00001dc0 0d 11 3a 0b 20 4c 44 41 20 23 34 0d 11 44 08 20 |..:. LDA #4..D. |
00001dd0 53 45 43 0d 11 4e 0e 20 53 42 43 20 6e 63 6f 6c |SEC..N. SBC ncol|
00001de0 73 0d 11 58 0d 20 42 45 51 20 6e 64 65 63 0d 11 |s..X. BEQ ndec..|
00001df0 62 08 20 54 41 59 0d 11 6c 09 2e 64 65 63 6c 0d |b. TAY..l..decl.|
00001e00 11 76 10 20 4c 44 41 20 74 6f 70 61 64 64 72 0d |.v. LDA topaddr.|
00001e10 11 80 08 20 53 45 43 0d 11 8a 0b 20 53 42 43 20 |... SEC.... SBC |
00001e20 23 38 0d 11 94 10 20 53 54 41 20 74 6f 70 61 64 |#8.... STA topad|
00001e30 64 72 0d 11 9e 12 20 4c 44 41 20 74 6f 70 61 64 |dr.... LDA topad|
00001e40 64 72 2b 31 0d 11 a8 0b 20 53 42 43 20 23 30 0d |dr+1.... SBC #0.|
00001e50 11 b2 12 20 53 54 41 20 74 6f 70 61 64 64 72 2b |... STA topaddr+|
00001e60 31 0d 11 bc 08 20 44 45 59 0d 11 c6 0d 20 42 4e |1.... DEY.... BN|
00001e70 45 20 64 65 63 6c 0d 11 d0 09 2e 6e 64 65 63 0d |E decl.....ndec.|
00001e80 11 da 0e 20 44 45 43 20 6e 63 6f 6c 73 0d 11 e4 |... DEC ncols...|
00001e90 0b 20 42 4e 45 20 6f 6b 0d 11 ee 12 20 4c 44 41 |. BNE ok.... LDA|
00001ea0 20 23 53 70 72 57 69 64 74 68 0d 11 f8 0e 20 53 | #SprWidth.... S|
00001eb0 54 41 20 6e 63 6f 6c 73 0d 12 02 07 2e 6f 6b 0d |TA ncols.....ok.|
00001ec0 12 0c 0d 20 49 4e 43 20 6d 63 6f 6c 0d 12 16 0c |... INC mcol....|
00001ed0 20 4c 44 41 20 26 37 30 0d 12 20 08 20 43 4c 43 | LDA &70.. . CLC|
00001ee0 0d 12 2a 12 20 41 44 43 20 23 4d 61 70 44 65 70 |..*. ADC #MapDep|
00001ef0 74 68 0d 12 34 0c 20 53 54 41 20 26 37 30 0d 12 |th..4. STA &70..|
00001f00 3e 0c 20 4c 44 41 20 26 37 31 0d 12 48 0b 20 41 |>. LDA &71..H. A|
00001f10 44 43 20 23 30 0d 12 52 0c 20 53 54 41 20 26 37 |DC #0..R. STA &7|
00001f20 31 0d 12 5c 23 20 4c 44 41 20 74 6f 70 61 64 64 |1..\# LDA topadd|
00001f30 72 20 20 20 20 20 20 20 20 20 5c 20 67 6f 20 6f |r \ go o|
00001f40 6e 20 74 6f 0d 12 66 23 20 43 4c 43 20 20 20 20 |n to..f# CLC |
00001f50 20 20 20 20 20 20 20 20 20 20 20 20 20 5c 20 6e | \ n|
00001f60 65 78 74 20 6d 61 70 0d 12 70 1f 20 41 44 43 20 |ext map..p. ADC |
00001f70 23 49 6e 63 4e 63 20 83 20 32 35 36 20 20 5c 20 |#IncNc . 256 \ |
00001f80 63 6f 6c 75 6d 6e 0d 12 7a 0d 20 53 54 41 20 61 |column..z. STA a|
00001f90 64 64 72 0d 12 84 12 20 4c 44 41 20 74 6f 70 61 |ddr.... LDA topa|
00001fa0 64 64 72 2b 31 0d 12 8e 15 20 41 44 43 20 23 49 |ddr+1.... ADC #I|
00001fb0 6e 63 4e 63 20 81 20 32 35 36 0d 12 98 0f 20 53 |ncNc . 256.... S|
00001fc0 54 41 20 61 64 64 72 2b 31 0d 12 a2 0d 20 4c 44 |TA addr+1.... LD|
00001fd0 41 20 6d 63 6f 6c 0d 12 ac 12 20 43 4d 50 20 23 |A mcol.... CMP #|
00001fe0 4d 61 70 57 69 64 74 68 0d 12 b6 0c 20 42 45 51 |MapWidth.... BEQ|
00001ff0 20 6e 6d 6c 0d 12 c0 0b 20 4a 4d 50 20 6d 6c 0d | nml.... JMP ml.|
00002000 12 ca 08 2e 6e 6d 6c 0d 12 d4 24 20 4c 44 41 20 |....nml...$ LDA |
00002010 63 6f 75 6e 74 65 72 20 20 20 20 5c 20 64 65 63 |counter \ dec|
00002020 69 64 65 20 77 68 65 74 68 65 72 0d 12 de 25 20 |ide whether...% |
00002030 43 4d 50 20 23 34 20 20 20 20 20 20 20 20 20 5c |CMP #4 \|
00002040 20 74 6f 20 67 6f 20 6f 6e 74 6f 20 6e 65 78 74 | to go onto next|
00002050 0d 12 e8 24 20 42 4e 45 20 6e 6f 74 63 34 20 20 |...$ BNE notc4 |
00002060 20 20 20 20 5c 20 63 6f 6c 75 6d 6e 20 6f 66 20 | \ column of |
00002070 64 61 74 61 0d 12 f2 20 20 4c 44 41 20 6f 6c 64 |data... LDA old|
00002080 37 30 20 20 20 20 20 20 5c 20 6f 72 20 74 6f 20 |70 \ or to |
00002090 6b 65 65 70 0d 12 fc 1f 20 43 4c 43 20 20 20 20 |keep.... CLC |
000020a0 20 20 20 20 20 20 20 20 5c 20 73 63 72 6f 6c 6c | \ scroll|
000020b0 69 6e 67 0d 13 06 22 20 41 44 43 20 23 4d 61 70 |ing..." ADC #Map|
000020c0 44 65 70 74 68 20 20 5c 20 63 75 72 72 65 6e 74 |Depth \ current|
000020d0 20 64 61 74 61 0d 13 10 0c 20 53 54 41 20 26 37 | data.... STA &7|
000020e0 30 0d 13 1a 10 20 4c 44 41 20 6f 6c 64 37 30 2b |0.... LDA old70+|
000020f0 31 0d 13 24 0b 20 41 44 43 20 23 30 0d 13 2e 0c |1..$. ADC #0....|
00002100 20 53 54 41 20 26 37 31 0d 13 38 0b 20 4c 44 41 | STA &71..8. LDA|
00002110 20 23 30 0d 13 42 10 20 53 54 41 20 63 6f 75 6e | #0..B. STA coun|
00002120 74 65 72 0d 13 4c 12 20 4a 4d 50 20 6f 76 65 72 |ter..L. JMP over|
00002130 6e 6f 74 63 34 0d 13 56 0a 2e 6e 6f 74 63 34 0d |notc4..V..notc4.|
00002140 13 60 0e 20 4c 44 41 20 6f 6c 64 37 30 0d 13 6a |.`. LDA old70..j|
00002150 0c 20 53 54 41 20 26 37 30 0d 13 74 10 20 4c 44 |. STA &70..t. LD|
00002160 41 20 6f 6c 64 37 30 2b 31 0d 13 7e 0c 20 53 54 |A old70+1..~. ST|
00002170 41 20 26 37 31 0d 13 88 0e 2e 6f 76 65 72 6e 6f |A &71.....overno|
00002180 74 63 34 0d 13 92 08 20 52 54 53 0d 13 9c 06 20 |tc4.... RTS.... |
00002190 3a 0d 13 a6 0c 2e 73 63 68 6f 6f 73 65 0d 13 b0 |:.....schoose...|
000021a0 0f 20 53 54 41 20 73 79 6d 62 6f 6c 0d 13 ba 0f |. STA symbol....|
000021b0 20 53 54 59 20 79 73 74 6f 72 65 0d 13 c4 0b 20 | STY ystore.... |
000021c0 4c 44 59 20 23 30 0d 13 ce 0c 2e 73 65 61 72 63 |LDY #0.....searc|
000021d0 68 6c 0d 13 d8 12 20 4c 44 41 20 73 70 74 61 62 |hl.... LDA sptab|
000021e0 6c 65 2c 59 0d 13 e2 11 20 42 45 51 20 6e 6f 74 |le,Y.... BEQ not|
000021f0 66 6f 75 6e 64 0d 13 ec 0f 20 43 4d 50 20 73 79 |found.... CMP sy|
00002200 6d 62 6f 6c 0d 13 f6 10 20 42 45 51 20 66 6f 75 |mbol.... BEQ fou|
00002210 6e 64 69 74 0d 14 00 0c 20 49 4e 59 3a 49 4e 59 |ndit.... INY:INY|
00002220 0d 14 0a 08 20 49 4e 59 0d 14 14 10 20 4a 4d 50 |.... INY.... JMP|
00002230 20 73 65 61 72 63 68 6c 0d 14 1e 0c 2e 66 6f 75 | searchl.....fou|
00002240 6e 64 69 74 0d 14 28 14 20 4c 44 41 20 73 70 74 |ndit..(. LDA spt|
00002250 61 62 6c 65 2b 31 2c 59 0d 14 32 0d 20 53 54 41 |able+1,Y..2. STA|
00002260 20 64 61 74 61 0d 14 3c 14 20 4c 44 41 20 73 70 | data..<. LDA sp|
00002270 74 61 62 6c 65 2b 32 2c 59 0d 14 46 0f 20 53 54 |table+2,Y..F. ST|
00002280 41 20 64 61 74 61 2b 31 0d 14 50 0f 20 4c 44 59 |A data+1..P. LDY|
00002290 20 79 73 74 6f 72 65 0d 14 5a 08 20 52 54 53 0d | ystore..Z. RTS.|
000022a0 14 64 0d 2e 6e 6f 74 66 6f 75 6e 64 0d 14 6e 12 |.d..notfound..n.|
000022b0 20 4c 44 41 20 73 70 74 61 62 6c 65 2b 31 0d 14 | LDA sptable+1..|
000022c0 78 0d 20 53 54 41 20 64 61 74 61 0d 14 82 12 20 |x. STA data.... |
000022d0 4c 44 41 20 73 70 74 61 62 6c 65 2b 32 0d 14 8c |LDA sptable+2...|
000022e0 0f 20 53 54 41 20 64 61 74 61 2b 31 0d 14 96 0f |. STA data+1....|
000022f0 20 4c 44 59 20 79 73 74 6f 72 65 0d 14 a0 08 20 | LDY ystore.... |
00002300 52 54 53 0d 14 aa 12 2e 63 6f 6c 73 20 20 20 20 |RTS.....cols |
00002310 20 20 42 52 4b 0d 14 b4 16 2e 74 63 61 64 64 72 | BRK.....tcaddr|
00002320 20 20 20 20 42 52 4b 3a 42 52 4b 0d 14 be 16 2e | BRK:BRK.....|
00002330 6d 61 70 74 6f 70 20 20 20 20 42 52 4b 3a 42 52 |maptop BRK:BR|
00002340 4b 0d 14 c8 22 2e 6e 63 6f 6c 73 20 20 20 20 20 |K...".ncols |
00002350 4f 50 54 20 a4 65 71 75 62 28 53 70 72 57 69 64 |OPT .equb(SprWid|
00002360 74 68 29 0d 14 d2 12 2e 79 73 74 6f 72 65 20 20 |th).....ystore |
00002370 20 20 42 52 4b 0d 14 dc 12 2e 6d 63 6f 6c 20 20 | BRK.....mcol |
00002380 20 20 20 20 42 52 4b 0d 14 e6 12 2e 63 6f 75 6e | BRK.....coun|
00002390 74 65 72 20 20 20 42 52 4b 0d 14 f0 16 2e 6f 6c |ter BRK.....ol|
000023a0 64 37 30 20 20 20 20 20 42 52 4b 3a 42 52 4b 0d |d70 BRK:BRK.|
000023b0 14 fa 12 2e 73 79 6d 62 6f 6c 20 20 20 20 42 52 |....symbol BR|
000023c0 4b 0d 15 04 1b 2e 73 6e 20 20 20 20 20 20 20 20 |K.....sn |
000023d0 4f 50 54 20 a4 65 71 75 62 28 31 29 0d 15 0e 12 |OPT .equb(1)....|
000023e0 2e 63 64 20 20 20 20 20 20 20 20 42 52 4b 0d 15 |.cd BRK..|
000023f0 18 12 2e 64 65 61 74 68 66 6c 61 67 20 42 52 4b |...deathflag BRK|
00002400 0d 15 22 14 2e 78 20 4f 50 54 20 a4 65 71 75 62 |.."..x OPT .equb|
00002410 28 31 30 29 0d 15 2c 14 2e 79 20 4f 50 54 20 a4 |(10)..,..y OPT .|
00002420 65 71 75 62 28 31 30 29 0d 15 36 0e 2e 61 20 42 |equb(10)..6..a B|
00002430 52 4b 3a 42 52 4b 0d 15 40 08 2e 6d 61 70 0d 15 |RK:BRK..@..map..|
00002440 4a 18 20 4f 50 54 20 a4 65 71 75 73 28 22 30 20 |J. OPT .equs("0 |
00002450 20 20 20 20 22 29 0d 15 54 18 20 4f 50 54 20 a4 | ")..T. OPT .|
00002460 65 71 75 73 28 22 30 20 20 20 20 20 22 29 0d 15 |equs("0 ")..|
00002470 5e 18 20 4f 50 54 20 a4 65 71 75 73 28 22 30 20 |^. OPT .equs("0 |
00002480 20 20 20 20 22 29 0d 15 68 18 20 4f 50 54 20 a4 | ")..h. OPT .|
00002490 65 71 75 73 28 22 30 20 20 20 20 20 22 29 0d 15 |equs("0 ")..|
000024a0 72 18 20 4f 50 54 20 a4 65 71 75 73 28 22 30 20 |r. OPT .equs("0 |
000024b0 20 20 20 20 22 29 0d 15 7c 18 20 4f 50 54 20 a4 | ")..|. OPT .|
000024c0 65 71 75 73 28 22 30 20 20 20 20 20 22 29 0d 15 |equs("0 ")..|
000024d0 86 18 20 4f 50 54 20 a4 65 71 75 73 28 22 30 30 |.. OPT .equs("00|
000024e0 30 30 20 30 22 29 0d 15 90 18 20 4f 50 54 20 a4 |00 0").... OPT .|
000024f0 65 71 75 73 28 22 30 30 30 30 20 30 22 29 0d 15 |equs("0000 0")..|
00002500 9a 18 20 4f 50 54 20 a4 65 71 75 73 28 22 30 30 |.. OPT .equs("00|
00002510 30 30 20 30 22 29 0d 15 a4 18 20 4f 50 54 20 a4 |00 0").... OPT .|
00002520 65 71 75 73 28 22 30 30 30 30 20 30 22 29 0d 15 |equs("0000 0")..|
00002530 ae 18 20 4f 50 54 20 a4 65 71 75 73 28 22 30 30 |.. OPT .equs("00|
00002540 30 30 20 30 22 29 0d 15 b8 18 20 4f 50 54 20 a4 |00 0").... OPT .|
00002550 65 71 75 73 28 22 30 30 30 30 20 30 22 29 0d 15 |equs("0000 0")..|
00002560 c2 18 20 4f 50 54 20 a4 65 71 75 73 28 22 30 30 |.. OPT .equs("00|
00002570 30 20 20 30 22 29 0d 15 cc 18 20 4f 50 54 20 a4 |0 0").... OPT .|
00002580 65 71 75 73 28 22 30 20 20 20 20 30 22 29 0d 15 |equs("0 0")..|
00002590 d6 18 20 4f 50 54 20 a4 65 71 75 73 28 22 30 20 |.. OPT .equs("0 |
000025a0 20 30 30 30 22 29 0d 15 e0 18 20 4f 50 54 20 a4 | 000").... OPT .|
000025b0 65 71 75 73 28 22 30 20 30 20 20 20 22 29 0d 15 |equs("0 0 ")..|
000025c0 ea 18 20 4f 50 54 20 a4 65 71 75 73 28 22 30 20 |.. OPT .equs("0 |
000025d0 30 30 30 30 22 29 0d 15 f4 18 20 4f 50 54 20 a4 |0000").... OPT .|
000025e0 65 71 75 73 28 22 30 20 20 20 20 30 22 29 0d 15 |equs("0 0")..|
000025f0 fe 18 20 4f 50 54 20 a4 65 71 75 73 28 22 30 20 |.. OPT .equs("0 |
00002600 20 20 20 30 22 29 0d 16 08 18 20 4f 50 54 20 a4 | 0").... OPT .|
00002610 65 71 75 73 28 22 30 30 30 30 20 30 22 29 0d 16 |equs("0000 0")..|
00002620 12 18 20 4f 50 54 20 a4 65 71 75 73 28 22 30 30 |.. OPT .equs("00|
00002630 30 30 20 30 22 29 0d 16 1c 18 20 4f 50 54 20 a4 |00 0").... OPT .|
00002640 65 71 75 73 28 22 30 30 20 20 20 30 22 29 0d 16 |equs("00 0")..|
00002650 26 18 20 4f 50 54 20 a4 65 71 75 73 28 22 30 30 |&. OPT .equs("00|
00002660 20 20 30 30 22 29 0d 16 30 18 20 4f 50 54 20 a4 | 00")..0. OPT .|
00002670 65 71 75 73 28 22 30 20 20 30 30 30 22 29 0d 16 |equs("0 000")..|
00002680 3a 18 20 4f 50 54 20 a4 65 71 75 73 28 22 30 20 |:. OPT .equs("0 |
00002690 20 30 30 30 22 29 0d 16 44 18 20 4f 50 54 20 a4 | 000")..D. OPT .|
000026a0 65 71 75 73 28 22 30 30 20 20 30 30 22 29 0d 16 |equs("00 00")..|
000026b0 4e 18 20 4f 50 54 20 a4 65 71 75 73 28 22 30 30 |N. OPT .equs("00|
000026c0 20 20 20 30 22 29 0d 16 58 18 20 4f 50 54 20 a4 | 0")..X. OPT .|
000026d0 65 71 75 73 28 22 30 30 30 30 20 30 22 29 0d 16 |equs("0000 0")..|
000026e0 62 18 20 4f 50 54 20 a4 65 71 75 73 28 22 30 30 |b. OPT .equs("00|
000026f0 30 30 20 30 22 29 0d 16 6c 18 20 4f 50 54 20 a4 |00 0")..l. OPT .|
00002700 65 71 75 73 28 22 30 20 20 20 20 30 22 29 0d 16 |equs("0 0")..|
00002710 76 18 20 4f 50 54 20 a4 65 71 75 73 28 22 30 20 |v. OPT .equs("0 |
00002720 30 30 20 30 22 29 0d 16 80 18 20 4f 50 54 20 a4 |00 0").... OPT .|
00002730 65 71 75 73 28 22 30 20 30 30 20 30 22 29 0d 16 |equs("0 00 0")..|
00002740 8a 18 20 4f 50 54 20 a4 65 71 75 73 28 22 30 20 |.. OPT .equs("0 |
00002750 30 30 20 30 22 29 0d 16 94 18 20 4f 50 54 20 a4 |00 0").... OPT .|
00002760 65 71 75 73 28 22 30 20 30 30 20 30 22 29 0d 16 |equs("0 00 0")..|
00002770 9e 18 20 4f 50 54 20 a4 65 71 75 73 28 22 30 20 |.. OPT .equs("0 |
00002780 30 30 20 30 22 29 0d 16 a8 18 20 4f 50 54 20 a4 |00 0").... OPT .|
00002790 65 71 75 73 28 22 20 20 30 30 20 20 22 29 0d 16 |equs(" 00 ")..|
000027a0 b2 18 20 4f 50 54 20 a4 65 71 75 73 28 22 20 20 |.. OPT .equs(" |
000027b0 30 30 20 20 22 29 0d 16 bc 18 20 4f 50 54 20 a4 |00 ").... OPT .|
000027c0 65 71 75 73 28 22 20 30 30 30 30 20 22 29 0d 16 |equs(" 0000 ")..|
000027d0 c6 18 20 4f 50 54 20 a4 65 71 75 73 28 22 20 20 |.. OPT .equs(" |
000027e0 20 20 20 20 22 29 0d 16 d0 18 20 4f 50 54 20 a4 | ").... OPT .|
000027f0 65 71 75 73 28 22 30 30 20 20 30 30 22 29 0d 16 |equs("00 00")..|
00002800 da 18 20 4f 50 54 20 a4 65 71 75 73 28 22 30 30 |.. OPT .equs("00|
00002810 20 20 30 30 22 29 0d 16 e4 18 20 4f 50 54 20 a4 | 00").... OPT .|
00002820 65 71 75 73 28 22 20 20 20 20 20 20 22 29 0d 16 |equs(" ")..|
00002830 ee 18 20 4f 50 54 20 a4 65 71 75 73 28 22 20 20 |.. OPT .equs(" |
00002840 20 20 20 20 22 29 0d 16 f8 18 20 4f 50 54 20 a4 | ").... OPT .|
00002850 65 71 75 73 28 22 20 20 20 20 20 20 22 29 0d 17 |equs(" ")..|
00002860 02 08 20 4e 4f 50 0d 17 0c 0c 2e 73 70 74 61 62 |.. NOP.....sptab|
00002870 6c 65 0d 17 16 13 20 4f 50 54 20 a4 65 71 75 73 |le.... OPT .equs|
00002880 28 22 20 22 29 0d 17 20 19 20 4f 50 54 20 a4 65 |(" ").. . OPT .e|
00002890 71 75 77 28 62 6c 61 6e 6b 64 61 74 61 29 0d 17 |quw(blankdata)..|
000028a0 2a 13 20 4f 50 54 20 a4 65 71 75 73 28 22 50 22 |*. OPT .equs("P"|
000028b0 29 0d 17 34 19 20 4f 50 54 20 a4 65 71 75 77 28 |)..4. OPT .equw(|
000028c0 62 6c 6f 63 6b 64 61 74 61 29 0d 17 3e 13 20 4f |blockdata)..>. O|
000028d0 50 54 20 a4 65 71 75 73 28 22 30 22 29 0d 17 48 |PT .equs("0")..H|
000028e0 1e 20 4f 50 54 20 a4 65 71 75 77 28 62 6c 6f 63 |. OPT .equw(bloc|
000028f0 6b 64 61 74 61 2b 33 32 2a 34 29 0d 17 52 08 20 |kdata+32*4)..R. |
00002900 42 52 4b 0d 17 5c 0e 2e 62 6c 6f 63 6b 64 61 74 |BRK..\..blockdat|
00002910 61 0d 17 66 0f 20 4f 50 54 20 a4 73 64 61 74 61 |a..f. OPT .sdata|
00002920 0d 17 70 0e 2e 62 6c 61 6e 6b 64 61 74 61 0d 17 |..p..blankdata..|
00002930 7a 1b 20 4f 50 54 20 a4 65 71 75 73 28 c4 34 2a |z. OPT .equs(.4*|
00002940 33 32 2c bd 28 30 29 29 29 0d 17 84 07 5d 3a ed |32,.(0)))....]:.|
00002950 0d 17 8e 0c f2 65 78 65 63 75 74 65 0d 17 98 05 |.....execute....|
00002960 e0 0d 17 a2 05 3a 0d 17 ac 0b dd a4 73 64 61 74 |.....:......sdat|
00002970 61 0d 17 b6 05 f7 0d 17 c0 26 e3 20 49 25 3d 31 |a........&. I%=1|
00002980 20 b8 20 28 28 53 70 72 57 69 64 74 68 2a 53 70 | . ((SprWidth*Sp|
00002990 72 44 65 70 74 68 29 2f 34 29 2a 32 0d 17 ca 08 |rDepth)/4)*2....|
000029a0 f3 20 64 24 0d 17 d4 1f 5b 4f 50 54 20 50 3a 4f |. d$....[OPT P:O|
000029b0 50 54 20 a4 65 71 75 64 28 a0 28 22 26 22 2b 64 |PT .equd(.("&"+d|
000029c0 24 29 29 0d 17 de 0a 5d 3a ed 3a 3d 50 0d 17 e8 |$))....]:.:=P...|
000029d0 05 3a 0d 17 f2 0c dd a4 78 79 64 61 74 61 0d 17 |.:......xydata..|
000029e0 fc 0a f7 20 8d 44 60 58 0d 18 06 11 e3 20 49 25 |... .D`X..... I%|
000029f0 3d 31 20 b8 20 36 34 2f 34 0d 18 10 08 f3 20 64 |=1 . 64/4..... d|
00002a00 24 0d 18 1a 21 5b 4f 50 54 20 50 3a 4f 50 54 20 |$...![OPT P:OPT |
00002a10 a4 65 71 75 64 28 a0 28 22 26 22 2b 64 24 29 29 |.equd(.("&"+d$))|
00002a20 3a 5d 0d 18 24 08 ed 3a 3d 50 0d 18 2e 05 3a 0d |:]..$..:=P....:.|
00002a30 18 38 7e dc 20 30 2c 45 30 43 30 43 30 38 2c 46 |.8~. 0,E0C0C08,F|
00002a40 30 46 30 46 30 45 2c 31 30 31 30 30 32 30 36 2c |0F0F0E,10100206,|
00002a50 33 30 33 30 2c 30 2c 30 2c 30 2c 30 2c 30 2c 46 |3030,0,0,0,0,0,F|
00002a60 30 46 30 30 2c 43 30 45 30 46 30 46 30 2c 38 30 |0F00,C0E0F0F0,80|
00002a70 2c 30 2c 30 2c 30 2c 30 2c 45 30 36 30 30 30 30 |,0,0,0,0,E060000|
00002a80 30 2c 37 30 45 30 46 30 30 2c 33 38 33 2c 30 2c |0,70E0F00,383,0,|
00002a90 30 2c 30 2c 30 2c 30 2c 30 2c 33 30 36 30 43 30 |0,0,0,0,0,3060C0|
00002aa0 30 2c 46 30 46 2c 30 2c 30 2c 30 2c 30 0d 18 42 |0,F0F,0,0,0,0..B|
00002ab0 e3 dc 20 33 43 37 46 37 46 46 46 2c 32 43 33 43 |.. 3C7F7FFF,2C3C|
00002ac0 31 43 32 43 2c 31 43 32 43 33 43 31 43 2c 33 43 |1C2C,1C2C3C1C,3C|
00002ad0 31 43 32 43 33 43 2c 32 43 33 43 31 43 32 43 2c |1C2C3C,2C3C1C2C,|
00002ae0 31 43 32 43 33 43 31 43 2c 33 43 31 43 32 43 33 |1C2C3C1C,3C1C2C3|
00002af0 43 2c 46 30 46 30 46 32 43 2c 36 30 46 46 46 46 |C,F0F0F2C,60FFFF|
00002b00 46 46 2c 44 30 36 30 42 30 44 30 2c 42 30 44 30 |FF,D060B0D0,B0D0|
00002b10 36 30 42 30 2c 36 30 42 30 44 30 36 30 2c 44 30 |60B0,60B0D060,D0|
00002b20 36 30 42 30 44 30 2c 42 30 44 30 36 30 42 30 2c |60B0D0,B0D060B0,|
00002b30 36 30 42 30 44 30 36 30 2c 46 30 46 30 46 44 30 |60B0D060,F0F0FD0|
00002b40 2c 44 30 46 46 46 46 46 46 2c 42 30 44 30 36 30 |,D0FFFFFF,B0D060|
00002b50 42 30 2c 36 30 42 30 44 30 36 30 2c 44 30 36 30 |B0,60B0D060,D060|
00002b60 42 30 44 30 2c 42 30 44 30 36 30 42 30 2c 36 30 |B0D0,B0D060B0,60|
00002b70 42 30 44 30 36 30 2c 44 30 36 30 42 30 44 30 2c |B0D060,D060B0D0,|
00002b80 46 30 46 30 46 42 30 2c 42 33 46 46 46 46 46 46 |F0F0FB0,B3FFFFFF|
00002b90 0d 18 4c 43 dc 37 33 42 33 46 33 37 33 2c 46 33 |..LC.73B3F373,F3|
00002ba0 37 33 42 33 46 33 2c 42 33 46 33 37 33 42 33 2c |73B3F3,B3F373B3,|
00002bb0 37 33 42 33 46 33 37 33 2c 46 33 37 33 42 33 46 |73B3F373,F373B3F|
00002bc0 33 2c 42 33 46 33 37 33 42 33 2c 31 46 31 46 33 |3,B3F373B3,1F1F3|
00002bd0 46 37 33 0d 18 56 05 3a 0d 18 60 95 dc 20 43 30 |F73..V.:..`.. C0|
00002be0 38 30 34 30 30 30 2c 43 30 38 30 34 30 30 30 2c |804000,C0804000,|
00002bf0 43 30 38 30 34 30 30 30 2c 43 30 38 30 34 30 30 |C0804000,C080400|
00002c00 30 2c 43 30 38 30 34 30 30 30 2c 43 30 38 30 34 |0,C0804000,C0804|
00002c10 30 30 30 2c 43 30 38 30 34 30 30 30 2c 43 30 38 |000,C0804000,C08|
00002c20 30 34 30 30 30 2c 35 42 35 41 35 39 35 38 2c 36 |04000,5B5A5958,6|
00002c30 30 35 46 35 45 35 44 2c 36 35 36 34 36 33 36 32 |05F5E5D,65646362|
00002c40 2c 36 41 36 39 36 38 36 37 2c 36 46 36 45 36 44 |,6A696867,6F6E6D|
00002c50 36 43 2c 37 34 37 33 37 32 37 31 2c 37 39 37 38 |6C,74737271,7978|
00002c60 37 37 37 36 2c 37 45 37 44 37 43 37 42 0d 18 6a |7776,7E7D7C7B..j|
00002c70 05 3a 0d 18 74 21 dd a4 65 71 75 73 28 73 24 29 |.:..t!..equs(s$)|
00002c80 24 50 25 3d 73 24 3a 50 25 3d 50 25 2b a9 73 24 |$P%=s$:P%=P%+.s$|
00002c90 3a 3d 50 0d 18 7e 1f dd a4 65 71 75 62 28 42 25 |:=P..~...equb(B%|
00002ca0 29 3f 50 25 3d 42 25 3a 50 25 3d 50 25 2b 31 3a |)?P%=B%:P%=P%+1:|
00002cb0 3d 50 0d 18 88 1f dd a4 65 71 75 77 28 57 25 29 |=P......equw(W%)|
00002cc0 21 50 25 3d 57 25 3a 50 25 3d 50 25 2b 32 3a 3d |!P%=W%:P%=P%+2:=|
00002cd0 50 0d 18 92 1f dd a4 65 71 75 64 28 44 25 29 21 |P......equd(D%)!|
00002ce0 50 25 3d 44 25 3a 50 25 3d 50 25 2b 34 3a 3d 50 |P%=D%:P%=P%+4:=P|
00002cf0 0d 18 9c 05 3a 0d 18 a6 0d dd f2 65 78 65 63 75 |....:......execu|
00002d00 74 65 0d 18 b0 1a 73 24 3d 22 43 41 4c 4c 20 73 |te....s$="CALL s|
00002d10 63 72 6f 6c 6c 22 2b bd 28 31 33 29 0d 18 ba 11 |croll"+.(13)....|
00002d20 e3 20 4c 3d 31 20 b8 20 a9 28 73 24 29 0d 18 c4 |. L=1 . .(s$)...|
00002d30 13 58 25 3d 30 3a 59 25 3d 97 c1 73 24 2c 4c 29 |.X%=0:Y%=..s$,L)|
00002d40 0d 18 ce 13 41 25 3d 31 33 38 3a d6 20 6f 73 62 |....A%=138:. osb|
00002d50 79 74 65 0d 18 d8 07 ed 3a e1 0d ff |yte.....:...|
00002d5c
ScrSoft.m0
ScrSoft.m1
ScrSoft.m2
ScrSoft.m4
ScrSoft.m5
.
