*    0060.25 GST 298/0.01
*
*****************************************************************
*                                                               *
*                                                               *
*                                                               *
*                  MATRIX PRINTER CONFIGURATION                 *
*                  ============================                 *
*                                                               *
*                                                               *
*    This file contains configuration details for the printers  *
*    described below.  To modify the printer configuration,     *
*    you must:                                                  *
*                                                               *
*    (a)  Read the chapter PRINTER CONFIGURATION in your User   *
*         Manual - THOROUGHLY!                                  *
*                                                               *
*    (b)  Edit this file using 1st Word Plus to make the        *
*         required changes (all values are HEXADECIMAL).        *
*                                                               *
*    (c)  Run the !1stConvrt program to install the new driver. *
*                                                               *
*    Consult your User Manual for details of how to load your   *
*    custom driver from the 1st Word Plus desktop, and how to   *
*    make it your default printer.                              *
*                                                               *
*    Copyright (C) 1986, 1987, 1988, GST Holdings Ltd           *
*    Copyright (C) 1989, GST Holdings plc                       *
*****************************************************************


*    Printer name
*    ============
*
*    For display on the 1st Word Plus desktop keypad
*    and 1st Mail Printer Configuration form
*    (max 32 characters)
*
*
*    Select one of the following:
*
*    Epson FX/RX (9-pin matrix)
*    Epson JX/EX (9-pin color)
*    Epson LX/GX/FX (9-pin NLQ)
*    Epson LQ/SQ series (24-pin)


Epson FX/RX (9-pin matrix)


*    Configuration variables
*    =======================
*
*    These six variables define certain printer
*    configuration details required by 1st Word Plus:
*
*    (1)  1 for microspacing daisywheel, else 0
*    (2)  Character width in printer units (daisy)
*    (3)  Linefeed height in printer units
*    (4)  Mid-carriage (daisy) pixels/inch (matrix)
*    (5)  Bold offset in printer units (daisy)
*    (6)  1 to pause printing between pages, else 0
*
*    Select one of the following:
*
*    0,0,C,48,0,0   (FX/JX/LX)
*    0,0,A,3C,0,0   (LQ/SQ)
*    0,2,C,50,0,0   (SMM804)


0,0,C,48,0,0


*    Printer characteristics
*    =======================
*
*    This table defines values to be sent to the
*    printer by 1st Word Plus to control its operation.
*
*    An entry consists of:
*
*    (1)  Function number (these must be kept in order)
*    (2)  Command bytes (hex commands and placeholders)
*
*    A placeholder has the top bit set and is substituted
*    by an actual value by 1st Word Plus when printing.
*
*    Lines preceded by an asterisk are commented out.
*
*    For NLQ printers, if the NLQ print style command is the same
*    as the draft style command, you can omit the NLQ command.
*    This does NOT apply to pitch changes.
*
*    Epson FX commands are the basis for this table, alternate
*    commands for specific printers are shown by printer model
*    letters in the comments.
*
*    Select the commands for your specific printer and comment
*    out the remainder, as shown.

* 0                           *    Character width
1,   D,A                      *    Carriage return line feed
* 2                           *    Forward print
* 3                           *    Reverse print
4,   1B,42,80,0,B             *    Vertical tab to line
* 4                           * SM No vertical tab!
* 5                           *    Absolute horizontal tab
6,   1B,47                    *    Draft bold on
7,   1B,48                    *    Draft bold off
* 6, 1B,45                    * LQ Draft bold on
* 7, 1B,46                    * LQ Draft bold off
* 8, 1B,45                    * LX NLQ bold on
* 9, 1B,46                    * LX NLQ bold off
A,   1B,34                    *    Draft italic on
B,   1B,35                    *    Draft italic off
* C, 1B,78,0,1B,34,1B,47      * LX NLQ italic on (double draft!)
* D, 1B,48,1B,35,1B,78,1      * LX NLQ italic off
* E, 1B,72,5                  * JX Draft light on (red)
* F, 1B,72,0                  * JX Draft light off (black)
* 10,1B,78,0                  * LX NLQ light on
* 11,1B,78,1                  * LX NLQ light off
* 10,1B,78,0                  * LQ NLQ light on
* 11,1B,78,1                  * LQ NLQ light off
12,  1B,53,0                  *    Draft superscript on
13,  1B,54                    *    Draft superscript off
* 14,1B,78,0,1B,53,0          * LX NLQ superscript on
* 15,1B,54,1B,78,1            * LX NLQ superscript off
16,  1B,53,1                  *    Draft subscript on
17,  1B,54                    *    Draft subscript off
* 18,1B,78,0,1B,53,1          * LX NLQ subscript on
* 19,1B,54,1B,78,1            * LX NLQ subscript off
1A,  1B,2D,1                  *    Draft underline on
1B,  1B,2D,0                  *    Draft underline off
* 1C                          *    NLQ underline on
* 1D                          *    NLQ underline off
1E,  C                        *    Formfeed
1F,  12                       *    Horizontal initialization
20,  1B,52,0                  *    Vertical initialization
* 20                          * SM Vertical initialisation
21,  1B,40                    *    Termination: printer reset
22,  8                        *    Backspace
23,  D                        *    Carriage return
24,  1B,43,80                 *    Form length in lines
25,  1B,41,80                 *    Set line feed to N units
26,  1B,2A,5                  *    Start graphics (mode 5)
* 26,1B,2A,0                  * LQ Start graphics (mode 0)
* 26,1B,59                    * SM Start graphics
* 27                          *    Reserved
28,  12,1B,57,0,1B,50         *    Draft Pica      (10   cpi)
* 29                          *    NLQ   Pica      (10   cpi)
2A,  12,1B,57,0,1B,4D         *    Draft Elite     (12   cpi)
* 2B                          *    NLQ   Elite     (12   cpi)
2C,  1B,57,0,1B,50,F          *    Draft Condensed (17.2 cpi)
* 2D                          *    NLQ   Condensed (17.2 cpi)
2E,  12,1B,4D,1B,57,1         *    Draft Expanded  ( 6   cpi)
* 2F                          *    NLQ   Expanded  ( 6   cpi)
* 28,1B,78,0,12,1B,57,0,1B,50 * LX Draft Pica      (10   cpi)
* 29,12,1B,57,0,1B,50,1B,78,1 * LX NLQ   Pica      (10   cpi)
* 2A,1B,78,0,12,1B,57,0,1B,4D * LX Draft Elite     (12   cpi)
* 2B                          * LX NLQ   Elite     (12   cpi)
* 2C,1B,78,0,1B,57,0,1B,50,F  * LX Draft Condensed (17.2 cpi)
* 2D                          * LX NLQ   Condensed (17.2 cpi)
* 2E,1B,78,0,12,1B,4D,1B,57,1 * LX Draft Expanded  ( 6   cpi)
* 2F                          * LX NLQ   Expanded  ( 6   cpi)
* 28,1B,78,0,12,1B,57,0,1B,50 * LQ Draft Pica      (10   cpi)
* 29,12,1B,57,0,1B,50,1B,78,1 * LQ NLQ   Pica      (10   cpi)
* 2A,1B,78,0,12,1B,57,0,1B,4D * LQ Draft Elite     (12   cpi)
* 2B,12,1B,57,0,1B,4D,1B,78,1 * LQ NLQ   Elite     (12   cpi)
* 2C,1B,78,0,1B,57,0,1B,50,F  * LQ Draft Condensed (17.2 cpi)
* 2D,1B,57,0,1B,50,F,1B,78,1  * LQ NLQ   Condensed (17.2 cpi)
* 2E,1B,78,0,12,1B,4D,1B,57,1 * LQ Draft Expanded  ( 6   cpi)
* 2F,12,1B,4D,1B,57,1,1B,78,1 * LQ NLQ   Expanded  ( 6   cpi)
* 30,1B,72,0                  * JX Black   ink
* 31,1B,72,1                  * JX Magenta ink
* 32,1B,72,2                  * JX Cyan    ink
* 33,1B,72,4                  * JX Yellow  ink
0                             *    NULL termination byte


*    Translation Table (Epson Printers)
*    ==================================
*
*    This table is used to translate the Archimedes
*    character codes for output to the printer.
*
*    Each entry consists of:
*
*    (1)  Archimedes character code (these must be in order)
*    (2)  The (possibly null) byte string to be output
*
*    Archimedes character codes with a NULL translation
*    string are printed as spaces.
*
*    Archimedes character codes NOT in the table are sent
*    directly to the printer without translation.

A0
A1, 1B, 52, 7, 5B, 1B, 52, 0  * � - Spanish
A2, 1B, 52, 4, 7C, 1B, 52, 0  * � - Danish 1
A3, 1B, 52, 3, 23, 1B, 52, 0  * � - UK
A4
A5, 1B, 52, 4, 5C, 1B, 52, 0  * � - Danish 1
A6
A7                            * � - N/A
A8, 1B, 52, 1, 7E, 1B, 52, 0  * � - French
A9                            * � - N/A
AA, 61, 8, 5F                 * � - a BS _
AB                            * � - N/A
AC                            * � - N/A
AD
AE                            * � - N/A
AF
B0, 1B, 52, 1, 5B, 1B, 52, 0  * � - French
B1, 2B, 8, 5F                 * � - + BS _
B2                            * � - N/A
B3                            * � - N/A
B4                            * � - N/A
B5                            * � - N/A
B6                            * � - N/A
B7
B8
B9
BA, 6F, 8, 5F                 * � - o BS _
BB                            * � - N/A
BC                            * � - N/A
BD                            * � - N/A
BE
BF, 1B, 52, 7, 5D, 1B, 52, 0  * � - Spanish
C0                            * � - N/A
C1
C2
C3                            * � - N/A
C4, 1B, 52, 2, 5B, 1B, 52, 0  * � - German
C5, 1B, 52, 4, 5D, 1B, 52, 0  * � - Danish 1
C6, 1B, 52, 4, 5B, 1B, 52, 0  * � - Danish 1
C7                            * � - N/A
C8
C9, 1B, 52, 9, 40, 1B, 52, 0  * � - Norwegian
CA
CB
CC
CD
CE
CF
D0
D1, 1B, 52, 7, 5C, 1B, 52, 0  * � - Spanish
D2
D3
D4
D5                            * � - N/A
D6, 1B, 52, 2, 5C, 1B, 52, 0  * � - German
D7
D8, 1B, 52, 8, 5C, 1B, 52, 0  * � - Japanese
D9
DA
DB
DC, 1B, 52, 2, 5D, 1B, 52, 0  * � - German
DD
DE
DF
E0, 1B, 52, 1, 40, 1B, 52, 0  * � - French
E1                            * � - N/A
E2, 61, 8, 5E                 * � - a BS ^
E3, 61, 8, 7E                 * � - a BS ~
E4, 1B, 52, 2, 7B, 1B, 52, 0  * � - German
E5, 1B, 52, 4, 7D, 1B, 52, 0  * � - Danish 1
E6, 1B, 52, 4, 7B, 1B, 52, 0  * � - Danish 1
E7, 1B, 52, 1, 5C, 1B, 52, 0  * � - French
E8, 1B, 52, 1, 7D, 1B, 52, 0  * � - French
E9, 1B, 52, 1, 7B, 1B, 52, 0  * � - French
EA, 65, 8, 5E                 * � - e BS ^
EB, 65, 8,1B,52,1,7E,1B,52,0  * � - e BS French �
EC, 1B, 52, 6, 7E, 1B, 52, 0  * � - Italian
ED                            * � - N/A
EE                            * � - N/A
EF                            * � - N/A
F0
F1, 1B, 52, 7, 7C, 1B, 52, 0  * � - Spanish
F2, 1B, 52, 6, 7C, 1B, 52, 0  * � - Italian
F3                            * � - N/A
F4, 6F, 8, 5E                 * � - o BS ^
F5, 6F, 8, 7E                 * � - o BS ~
F6, 1B, 52, 2, 7C, 1B, 52, 0  * � - German
F7                            * � - N/A
F8                            * � - N/A
F9, 1B, 52, 1, 7C, 1B, 52, 0  * � - French
FA                            * � - N/A
FB, 75, 8, 5E                 * � - u BS ^
FC, 1B, 52, 2, 7D, 1B, 52, 0  * � - German
FD
FE
FF, 79, 8,1B,52,1,7E,1B,52,0  * � - y BS French �


0                             * NULL terminator


00000000  2a 20 20 20 20 30 30 36  30 2e 32 35 20 47 53 54  |*    0060.25 GST|
00000010  20 32 39 38 2f 30 2e 30  31 0a 2a 0a 2a 2a 2a 2a  | 298/0.01.*.****|
00000020  2a 2a 2a 2a 2a 2a 2a 2a  2a 2a 2a 2a 2a 2a 2a 2a  |****************|
*
00000050  2a 2a 2a 2a 2a 2a 2a 2a  2a 2a 2a 2a 2a 0a 2a 20  |*************.* |
00000060  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
*
00000090  20 20 20 20 20 20 20 20  20 20 20 20 20 20 2a 0a  |              *.|
000000a0  2a 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |*               |
000000b0  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
*
000000e0  2a 0a 2a 20 20 20 20 20  20 20 20 20 20 20 20 20  |*.*             |
000000f0  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
*
00000120  20 20 2a 0a 2a 20 20 20  20 20 20 20 20 20 20 20  |  *.*           |
00000130  20 20 20 20 20 20 20 4d  41 54 52 49 58 20 50 52  |       MATRIX PR|
00000140  49 4e 54 45 52 20 43 4f  4e 46 49 47 55 52 41 54  |INTER CONFIGURAT|
00000150  49 4f 4e 20 20 20 20 20  20 20 20 20 20 20 20 20  |ION             |
00000160  20 20 20 20 2a 0a 2a 20  20 20 20 20 20 20 20 20  |    *.*         |
00000170  20 20 20 20 20 20 20 20  20 3d 3d 3d 3d 3d 3d 3d  |         =======|
00000180  3d 3d 3d 3d 3d 3d 3d 3d  3d 3d 3d 3d 3d 3d 3d 3d  |================|
00000190  3d 3d 3d 3d 3d 20 20 20  20 20 20 20 20 20 20 20  |=====           |
000001a0  20 20 20 20 20 20 2a 0a  2a 20 20 20 20 20 20 20  |      *.*       |
000001b0  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
*
000001e0  20 20 20 20 20 20 20 20  2a 0a 2a 20 20 20 20 20  |        *.*     |
000001f0  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
*
00000220  20 20 20 20 20 20 20 20  20 20 2a 0a 2a 20 20 20  |          *.*   |
00000230  20 54 68 69 73 20 66 69  6c 65 20 63 6f 6e 74 61  | This file conta|
00000240  69 6e 73 20 63 6f 6e 66  69 67 75 72 61 74 69 6f  |ins configuratio|
00000250  6e 20 64 65 74 61 69 6c  73 20 66 6f 72 20 74 68  |n details for th|
00000260  65 20 70 72 69 6e 74 65  72 73 20 20 2a 0a 2a 20  |e printers  *.* |
00000270  20 20 20 64 65 73 63 72  69 62 65 64 20 62 65 6c  |   described bel|
00000280  6f 77 2e 20 20 54 6f 20  6d 6f 64 69 66 79 20 74  |ow.  To modify t|
00000290  68 65 20 70 72 69 6e 74  65 72 20 63 6f 6e 66 69  |he printer confi|
000002a0  67 75 72 61 74 69 6f 6e  2c 20 20 20 20 20 2a 0a  |guration,     *.|
000002b0  2a 20 20 20 20 79 6f 75  20 6d 75 73 74 3a 20 20  |*    you must:  |
000002c0  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
*
000002f0  2a 0a 2a 20 20 20 20 20  20 20 20 20 20 20 20 20  |*.*             |
00000300  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
*
00000330  20 20 2a 0a 2a 20 20 20  20 28 61 29 20 20 52 65  |  *.*    (a)  Re|
00000340  61 64 20 74 68 65 20 63  68 61 70 74 65 72 20 50  |ad the chapter P|
00000350  52 49 4e 54 45 52 20 43  4f 4e 46 49 47 55 52 41  |RINTER CONFIGURA|
00000360  54 49 4f 4e 20 69 6e 20  79 6f 75 72 20 55 73 65  |TION in your Use|
00000370  72 20 20 20 2a 0a 2a 20  20 20 20 20 20 20 20 20  |r   *.*         |
00000380  4d 61 6e 75 61 6c 20 2d  20 54 48 4f 52 4f 55 47  |Manual - THOROUG|
00000390  48 4c 59 21 20 20 20 20  20 20 20 20 20 20 20 20  |HLY!            |
000003a0  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
000003b0  20 20 20 20 20 20 2a 0a  2a 20 20 20 20 20 20 20  |      *.*       |
000003c0  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
*
000003f0  20 20 20 20 20 20 20 20  2a 0a 2a 20 20 20 20 28  |        *.*    (|
00000400  62 29 20 20 45 64 69 74  20 74 68 69 73 20 66 69  |b)  Edit this fi|
00000410  6c 65 20 75 73 69 6e 67  20 31 73 74 20 57 6f 72  |le using 1st Wor|
00000420  64 20 50 6c 75 73 20 74  6f 20 6d 61 6b 65 20 74  |d Plus to make t|
00000430  68 65 20 20 20 20 20 20  20 20 2a 0a 2a 20 20 20  |he        *.*   |
00000440  20 20 20 20 20 20 72 65  71 75 69 72 65 64 20 63  |      required c|
00000450  68 61 6e 67 65 73 20 28  61 6c 6c 20 76 61 6c 75  |hanges (all valu|
00000460  65 73 20 61 72 65 20 48  45 58 41 44 45 43 49 4d  |es are HEXADECIM|
00000470  41 4c 29 2e 20 20 20 20  20 20 20 20 2a 0a 2a 20  |AL).        *.* |
00000480  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
*
000004b0  20 20 20 20 20 20 20 20  20 20 20 20 20 20 2a 0a  |              *.|
000004c0  2a 20 20 20 20 28 63 29  20 20 52 75 6e 20 74 68  |*    (c)  Run th|
000004d0  65 20 21 31 73 74 43 6f  6e 76 72 74 20 70 72 6f  |e !1stConvrt pro|
000004e0  67 72 61 6d 20 74 6f 20  69 6e 73 74 61 6c 6c 20  |gram to install |
000004f0  74 68 65 20 6e 65 77 20  64 72 69 76 65 72 2e 20  |the new driver. |
00000500  2a 0a 2a 20 20 20 20 20  20 20 20 20 20 20 20 20  |*.*             |
00000510  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
*
00000540  20 20 2a 0a 2a 20 20 20  20 43 6f 6e 73 75 6c 74  |  *.*    Consult|
00000550  20 79 6f 75 72 20 55 73  65 72 20 4d 61 6e 75 61  | your User Manua|
00000560  6c 20 66 6f 72 20 64 65  74 61 69 6c 73 20 6f 66  |l for details of|
00000570  20 68 6f 77 20 74 6f 20  6c 6f 61 64 20 79 6f 75  | how to load you|
00000580  72 20 20 20 2a 0a 2a 20  20 20 20 63 75 73 74 6f  |r   *.*    custo|
00000590  6d 20 64 72 69 76 65 72  20 66 72 6f 6d 20 74 68  |m driver from th|
000005a0  65 20 31 73 74 20 57 6f  72 64 20 50 6c 75 73 20  |e 1st Word Plus |
000005b0  64 65 73 6b 74 6f 70 2c  20 61 6e 64 20 68 6f 77  |desktop, and how|
000005c0  20 74 6f 20 20 20 2a 0a  2a 20 20 20 20 6d 61 6b  | to   *.*    mak|
000005d0  65 20 69 74 20 79 6f 75  72 20 64 65 66 61 75 6c  |e it your defaul|
000005e0  74 20 70 72 69 6e 74 65  72 2e 20 20 20 20 20 20  |t printer.      |
000005f0  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
00000600  20 20 20 20 20 20 20 20  2a 0a 2a 20 20 20 20 20  |        *.*     |
00000610  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
*
00000640  20 20 20 20 20 20 20 20  20 20 2a 0a 2a 20 20 20  |          *.*   |
00000650  20 43 6f 70 79 72 69 67  68 74 20 28 43 29 20 31  | Copyright (C) 1|
00000660  39 38 36 2c 20 31 39 38  37 2c 20 31 39 38 38 2c  |986, 1987, 1988,|
00000670  20 47 53 54 20 48 6f 6c  64 69 6e 67 73 20 4c 74  | GST Holdings Lt|
00000680  64 20 20 20 20 20 20 20  20 20 20 20 2a 0a 2a 20  |d           *.* |
00000690  20 20 20 43 6f 70 79 72  69 67 68 74 20 28 43 29  |   Copyright (C)|
000006a0  20 31 39 38 39 2c 20 47  53 54 20 48 6f 6c 64 69  | 1989, GST Holdi|
000006b0  6e 67 73 20 70 6c 63 20  20 20 20 20 20 20 20 20  |ngs plc         |
000006c0  20 20 20 20 20 20 20 20  20 20 20 20 20 20 2a 0a  |              *.|
000006d0  2a 2a 2a 2a 2a 2a 2a 2a  2a 2a 2a 2a 2a 2a 2a 2a  |****************|
*
00000710  2a 0a 0a 0a 2a 20 20 20  20 50 72 69 6e 74 65 72  |*...*    Printer|
00000720  20 6e 61 6d 65 0a 2a 20  20 20 20 3d 3d 3d 3d 3d  | name.*    =====|
00000730  3d 3d 3d 3d 3d 3d 3d 0a  2a 0a 2a 20 20 20 20 46  |=======.*.*    F|
00000740  6f 72 20 64 69 73 70 6c  61 79 20 6f 6e 20 74 68  |or display on th|
00000750  65 20 31 73 74 20 57 6f  72 64 20 50 6c 75 73 20  |e 1st Word Plus |
00000760  64 65 73 6b 74 6f 70 20  6b 65 79 70 61 64 20 0a  |desktop keypad .|
00000770  2a 20 20 20 20 61 6e 64  20 31 73 74 20 4d 61 69  |*    and 1st Mai|
00000780  6c 20 50 72 69 6e 74 65  72 20 43 6f 6e 66 69 67  |l Printer Config|
00000790  75 72 61 74 69 6f 6e 20  66 6f 72 6d 0a 2a 20 20  |uration form.*  |
000007a0  20 20 28 6d 61 78 20 33  32 20 63 68 61 72 61 63  |  (max 32 charac|
000007b0  74 65 72 73 29 20 0a 2a  0a 2a 0a 2a 20 20 20 20  |ters) .*.*.*    |
000007c0  53 65 6c 65 63 74 20 6f  6e 65 20 6f 66 20 74 68  |Select one of th|
000007d0  65 20 66 6f 6c 6c 6f 77  69 6e 67 3a 0a 2a 0a 2a  |e following:.*.*|
000007e0  20 20 20 20 45 70 73 6f  6e 20 46 58 2f 52 58 20  |    Epson FX/RX |
000007f0  28 39 2d 70 69 6e 20 6d  61 74 72 69 78 29 0a 2a  |(9-pin matrix).*|
00000800  20 20 20 20 45 70 73 6f  6e 20 4a 58 2f 45 58 20  |    Epson JX/EX |
00000810  28 39 2d 70 69 6e 20 63  6f 6c 6f 72 29 0a 2a 20  |(9-pin color).* |
00000820  20 20 20 45 70 73 6f 6e  20 4c 58 2f 47 58 2f 46  |   Epson LX/GX/F|
00000830  58 20 28 39 2d 70 69 6e  20 4e 4c 51 29 0a 2a 20  |X (9-pin NLQ).* |
00000840  20 20 20 45 70 73 6f 6e  20 4c 51 2f 53 51 20 73  |   Epson LQ/SQ s|
00000850  65 72 69 65 73 20 28 32  34 2d 70 69 6e 29 0a 0a  |eries (24-pin)..|
00000860  0a 45 70 73 6f 6e 20 46  58 2f 52 58 20 28 39 2d  |.Epson FX/RX (9-|
00000870  70 69 6e 20 6d 61 74 72  69 78 29 0a 0a 0a 2a 20  |pin matrix)...* |
00000880  20 20 20 43 6f 6e 66 69  67 75 72 61 74 69 6f 6e  |   Configuration|
00000890  20 76 61 72 69 61 62 6c  65 73 0a 2a 20 20 20 20  | variables.*    |
000008a0  3d 3d 3d 3d 3d 3d 3d 3d  3d 3d 3d 3d 3d 3d 3d 3d  |================|
000008b0  3d 3d 3d 3d 3d 3d 3d 0a  2a 0a 2a 20 20 20 20 54  |=======.*.*    T|
000008c0  68 65 73 65 20 73 69 78  20 76 61 72 69 61 62 6c  |hese six variabl|
000008d0  65 73 20 64 65 66 69 6e  65 20 63 65 72 74 61 69  |es define certai|
000008e0  6e 20 70 72 69 6e 74 65  72 0a 2a 20 20 20 20 63  |n printer.*    c|
000008f0  6f 6e 66 69 67 75 72 61  74 69 6f 6e 20 64 65 74  |onfiguration det|
00000900  61 69 6c 73 20 72 65 71  75 69 72 65 64 20 62 79  |ails required by|
00000910  20 31 73 74 20 57 6f 72  64 20 50 6c 75 73 3a 0a  | 1st Word Plus:.|
00000920  2a 0a 2a 20 20 20 20 28  31 29 20 20 31 20 66 6f  |*.*    (1)  1 fo|
00000930  72 20 6d 69 63 72 6f 73  70 61 63 69 6e 67 20 64  |r microspacing d|
00000940  61 69 73 79 77 68 65 65  6c 2c 20 65 6c 73 65 20  |aisywheel, else |
00000950  30 0a 2a 20 20 20 20 28  32 29 20 20 43 68 61 72  |0.*    (2)  Char|
00000960  61 63 74 65 72 20 77 69  64 74 68 20 69 6e 20 70  |acter width in p|
00000970  72 69 6e 74 65 72 20 75  6e 69 74 73 20 28 64 61  |rinter units (da|
00000980  69 73 79 29 0a 2a 20 20  20 20 28 33 29 20 20 4c  |isy).*    (3)  L|
00000990  69 6e 65 66 65 65 64 20  68 65 69 67 68 74 20 69  |inefeed height i|
000009a0  6e 20 70 72 69 6e 74 65  72 20 75 6e 69 74 73 0a  |n printer units.|
000009b0  2a 20 20 20 20 28 34 29  20 20 4d 69 64 2d 63 61  |*    (4)  Mid-ca|
000009c0  72 72 69 61 67 65 20 28  64 61 69 73 79 29 20 70  |rriage (daisy) p|
000009d0  69 78 65 6c 73 2f 69 6e  63 68 20 28 6d 61 74 72  |ixels/inch (matr|
000009e0  69 78 29 0a 2a 20 20 20  20 28 35 29 20 20 42 6f  |ix).*    (5)  Bo|
000009f0  6c 64 20 6f 66 66 73 65  74 20 69 6e 20 70 72 69  |ld offset in pri|
00000a00  6e 74 65 72 20 75 6e 69  74 73 20 28 64 61 69 73  |nter units (dais|
00000a10  79 29 0a 2a 20 20 20 20  28 36 29 20 20 31 20 74  |y).*    (6)  1 t|
00000a20  6f 20 70 61 75 73 65 20  70 72 69 6e 74 69 6e 67  |o pause printing|
00000a30  20 62 65 74 77 65 65 6e  20 70 61 67 65 73 2c 20  | between pages, |
00000a40  65 6c 73 65 20 30 0a 2a  0a 2a 20 20 20 20 53 65  |else 0.*.*    Se|
00000a50  6c 65 63 74 20 6f 6e 65  20 6f 66 20 74 68 65 20  |lect one of the |
00000a60  66 6f 6c 6c 6f 77 69 6e  67 3a 0a 2a 0a 2a 20 20  |following:.*.*  |
00000a70  20 20 30 2c 30 2c 43 2c  34 38 2c 30 2c 30 20 20  |  0,0,C,48,0,0  |
00000a80  20 28 46 58 2f 4a 58 2f  4c 58 29 0a 2a 20 20 20  | (FX/JX/LX).*   |
00000a90  20 30 2c 30 2c 41 2c 33  43 2c 30 2c 30 20 20 20  | 0,0,A,3C,0,0   |
00000aa0  28 4c 51 2f 53 51 29 0a  2a 20 20 20 20 30 2c 32  |(LQ/SQ).*    0,2|
00000ab0  2c 43 2c 35 30 2c 30 2c  30 20 20 20 28 53 4d 4d  |,C,50,0,0   (SMM|
00000ac0  38 30 34 29 0a 0a 0a 30  2c 30 2c 43 2c 34 38 2c  |804)...0,0,C,48,|
00000ad0  30 2c 30 0a 0a 0a 2a 20  20 20 20 50 72 69 6e 74  |0,0...*    Print|
00000ae0  65 72 20 63 68 61 72 61  63 74 65 72 69 73 74 69  |er characteristi|
00000af0  63 73 0a 2a 20 20 20 20  3d 3d 3d 3d 3d 3d 3d 3d  |cs.*    ========|
00000b00  3d 3d 3d 3d 3d 3d 3d 3d  3d 3d 3d 3d 3d 3d 3d 0a  |===============.|
00000b10  2a 0a 2a 20 20 20 20 54  68 69 73 20 74 61 62 6c  |*.*    This tabl|
00000b20  65 20 64 65 66 69 6e 65  73 20 76 61 6c 75 65 73  |e defines values|
00000b30  20 74 6f 20 62 65 20 73  65 6e 74 20 74 6f 20 74  | to be sent to t|
00000b40  68 65 0a 2a 20 20 20 20  70 72 69 6e 74 65 72 20  |he.*    printer |
00000b50  62 79 20 31 73 74 20 57  6f 72 64 20 50 6c 75 73  |by 1st Word Plus|
00000b60  20 74 6f 20 63 6f 6e 74  72 6f 6c 20 69 74 73 20  | to control its |
00000b70  6f 70 65 72 61 74 69 6f  6e 2e 0a 2a 0a 2a 20 20  |operation..*.*  |
00000b80  20 20 41 6e 20 65 6e 74  72 79 20 63 6f 6e 73 69  |  An entry consi|
00000b90  73 74 73 20 6f 66 3a 0a  2a 0a 2a 20 20 20 20 28  |sts of:.*.*    (|
00000ba0  31 29 20 20 46 75 6e 63  74 69 6f 6e 20 6e 75 6d  |1)  Function num|
00000bb0  62 65 72 20 28 74 68 65  73 65 20 6d 75 73 74 20  |ber (these must |
00000bc0  62 65 20 6b 65 70 74 20  69 6e 20 6f 72 64 65 72  |be kept in order|
00000bd0  29 0a 2a 20 20 20 20 28  32 29 20 20 43 6f 6d 6d  |).*    (2)  Comm|
00000be0  61 6e 64 20 62 79 74 65  73 20 28 68 65 78 20 63  |and bytes (hex c|
00000bf0  6f 6d 6d 61 6e 64 73 20  61 6e 64 20 70 6c 61 63  |ommands and plac|
00000c00  65 68 6f 6c 64 65 72 73  29 0a 2a 0a 2a 20 20 20  |eholders).*.*   |
00000c10  20 41 20 70 6c 61 63 65  68 6f 6c 64 65 72 20 68  | A placeholder h|
00000c20  61 73 20 74 68 65 20 74  6f 70 20 62 69 74 20 73  |as the top bit s|
00000c30  65 74 20 61 6e 64 20 69  73 20 73 75 62 73 74 69  |et and is substi|
00000c40  74 75 74 65 64 0a 2a 20  20 20 20 62 79 20 61 6e  |tuted.*    by an|
00000c50  20 61 63 74 75 61 6c 20  76 61 6c 75 65 20 62 79  | actual value by|
00000c60  20 31 73 74 20 57 6f 72  64 20 50 6c 75 73 20 77  | 1st Word Plus w|
00000c70  68 65 6e 20 70 72 69 6e  74 69 6e 67 2e 0a 2a 0a  |hen printing..*.|
00000c80  2a 20 20 20 20 4c 69 6e  65 73 20 70 72 65 63 65  |*    Lines prece|
00000c90  64 65 64 20 62 79 20 61  6e 20 61 73 74 65 72 69  |ded by an asteri|
00000ca0  73 6b 20 61 72 65 20 63  6f 6d 6d 65 6e 74 65 64  |sk are commented|
00000cb0  20 6f 75 74 2e 0a 2a 0a  2a 20 20 20 20 46 6f 72  | out..*.*    For|
00000cc0  20 4e 4c 51 20 70 72 69  6e 74 65 72 73 2c 20 69  | NLQ printers, i|
00000cd0  66 20 74 68 65 20 4e 4c  51 20 70 72 69 6e 74 20  |f the NLQ print |
00000ce0  73 74 79 6c 65 20 63 6f  6d 6d 61 6e 64 20 69 73  |style command is|
00000cf0  20 74 68 65 20 73 61 6d  65 0a 2a 20 20 20 20 61  | the same.*    a|
00000d00  73 20 74 68 65 20 64 72  61 66 74 20 73 74 79 6c  |s the draft styl|
00000d10  65 20 63 6f 6d 6d 61 6e  64 2c 20 79 6f 75 20 63  |e command, you c|
00000d20  61 6e 20 6f 6d 69 74 20  74 68 65 20 4e 4c 51 20  |an omit the NLQ |
00000d30  63 6f 6d 6d 61 6e 64 2e  0a 2a 20 20 20 20 54 68  |command..*    Th|
00000d40  69 73 20 64 6f 65 73 20  4e 4f 54 20 61 70 70 6c  |is does NOT appl|
00000d50  79 20 74 6f 20 70 69 74  63 68 20 63 68 61 6e 67  |y to pitch chang|
00000d60  65 73 2e 0a 2a 0a 2a 20  20 20 20 45 70 73 6f 6e  |es..*.*    Epson|
00000d70  20 46 58 20 63 6f 6d 6d  61 6e 64 73 20 61 72 65  | FX commands are|
00000d80  20 74 68 65 20 62 61 73  69 73 20 66 6f 72 20 74  | the basis for t|
00000d90  68 69 73 20 74 61 62 6c  65 2c 20 61 6c 74 65 72  |his table, alter|
00000da0  6e 61 74 65 0a 2a 20 20  20 20 63 6f 6d 6d 61 6e  |nate.*    comman|
00000db0  64 73 20 66 6f 72 20 73  70 65 63 69 66 69 63 20  |ds for specific |
00000dc0  70 72 69 6e 74 65 72 73  20 61 72 65 20 73 68 6f  |printers are sho|
00000dd0  77 6e 20 62 79 20 70 72  69 6e 74 65 72 20 6d 6f  |wn by printer mo|
00000de0  64 65 6c 0a 2a 20 20 20  20 6c 65 74 74 65 72 73  |del.*    letters|
00000df0  20 69 6e 20 74 68 65 20  63 6f 6d 6d 65 6e 74 73  | in the comments|
00000e00  2e 0a 2a 0a 2a 20 20 20  20 53 65 6c 65 63 74 20  |..*.*    Select |
00000e10  74 68 65 20 63 6f 6d 6d  61 6e 64 73 20 66 6f 72  |the commands for|
00000e20  20 79 6f 75 72 20 73 70  65 63 69 66 69 63 20 70  | your specific p|
00000e30  72 69 6e 74 65 72 20 61  6e 64 20 63 6f 6d 6d 65  |rinter and comme|
00000e40  6e 74 0a 2a 20 20 20 20  6f 75 74 20 74 68 65 20  |nt.*    out the |
00000e50  72 65 6d 61 69 6e 64 65  72 2c 20 61 73 20 73 68  |remainder, as sh|
00000e60  6f 77 6e 2e 0a 0a 2a 20  30 20 20 20 20 20 20 20  |own...* 0       |
00000e70  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
00000e80  20 20 20 20 2a 20 20 20  20 43 68 61 72 61 63 74  |    *    Charact|
00000e90  65 72 20 77 69 64 74 68  0a 31 2c 20 20 20 44 2c  |er width.1,   D,|
00000ea0  41 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |A               |
00000eb0  20 20 20 20 20 20 20 2a  20 20 20 20 43 61 72 72  |       *    Carr|
00000ec0  69 61 67 65 20 72 65 74  75 72 6e 20 6c 69 6e 65  |iage return line|
00000ed0  20 66 65 65 64 0a 2a 20  32 20 20 20 20 20 20 20  | feed.* 2       |
00000ee0  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
00000ef0  20 20 20 20 2a 20 20 20  20 46 6f 72 77 61 72 64  |    *    Forward|
00000f00  20 70 72 69 6e 74 0a 2a  20 33 20 20 20 20 20 20  | print.* 3      |
00000f10  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
00000f20  20 20 20 20 20 2a 20 20  20 20 52 65 76 65 72 73  |     *    Revers|
00000f30  65 20 70 72 69 6e 74 0a  34 2c 20 20 20 31 42 2c  |e print.4,   1B,|
00000f40  34 32 2c 38 30 2c 30 2c  42 20 20 20 20 20 20 20  |42,80,0,B       |
00000f50  20 20 20 20 20 20 2a 20  20 20 20 56 65 72 74 69  |      *    Verti|
00000f60  63 61 6c 20 74 61 62 20  74 6f 20 6c 69 6e 65 0a  |cal tab to line.|
00000f70  2a 20 34 20 20 20 20 20  20 20 20 20 20 20 20 20  |* 4             |
00000f80  20 20 20 20 20 20 20 20  20 20 20 20 20 20 2a 20  |              * |
00000f90  53 4d 20 4e 6f 20 76 65  72 74 69 63 61 6c 20 74  |SM No vertical t|
00000fa0  61 62 21 0a 2a 20 35 20  20 20 20 20 20 20 20 20  |ab!.* 5         |
00000fb0  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
00000fc0  20 20 2a 20 20 20 20 41  62 73 6f 6c 75 74 65 20  |  *    Absolute |
00000fd0  68 6f 72 69 7a 6f 6e 74  61 6c 20 74 61 62 20 0a  |horizontal tab .|
00000fe0  36 2c 20 20 20 31 42 2c  34 37 20 20 20 20 20 20  |6,   1B,47      |
00000ff0  20 20 20 20 20 20 20 20  20 20 20 20 20 20 2a 20  |              * |
00001000  20 20 20 44 72 61 66 74  20 62 6f 6c 64 20 6f 6e  |   Draft bold on|
00001010  0a 37 2c 20 20 20 31 42  2c 34 38 20 20 20 20 20  |.7,   1B,48     |
00001020  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 2a  |               *|
00001030  20 20 20 20 44 72 61 66  74 20 62 6f 6c 64 20 6f  |    Draft bold o|
00001040  66 66 0a 2a 20 36 2c 20  31 42 2c 34 35 20 20 20  |ff.* 6, 1B,45   |
00001050  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
00001060  20 2a 20 4c 51 20 44 72  61 66 74 20 62 6f 6c 64  | * LQ Draft bold|
00001070  20 6f 6e 0a 2a 20 37 2c  20 31 42 2c 34 36 20 20  | on.* 7, 1B,46  |
00001080  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
00001090  20 20 2a 20 4c 51 20 44  72 61 66 74 20 62 6f 6c  |  * LQ Draft bol|
000010a0  64 20 6f 66 66 0a 2a 20  38 2c 20 31 42 2c 34 35  |d off.* 8, 1B,45|
000010b0  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
000010c0  20 20 20 20 2a 20 4c 58  20 4e 4c 51 20 62 6f 6c  |    * LX NLQ bol|
000010d0  64 20 6f 6e 0a 2a 20 39  2c 20 31 42 2c 34 36 20  |d on.* 9, 1B,46 |
000010e0  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
000010f0  20 20 20 2a 20 4c 58 20  4e 4c 51 20 62 6f 6c 64  |   * LX NLQ bold|
00001100  20 6f 66 66 0a 41 2c 20  20 20 31 42 2c 33 34 20  | off.A,   1B,34 |
00001110  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
00001120  20 20 20 2a 20 20 20 20  44 72 61 66 74 20 69 74  |   *    Draft it|
00001130  61 6c 69 63 20 6f 6e 0a  42 2c 20 20 20 31 42 2c  |alic on.B,   1B,|
00001140  33 35 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |35              |
00001150  20 20 20 20 20 20 2a 20  20 20 20 44 72 61 66 74  |      *    Draft|
00001160  20 69 74 61 6c 69 63 20  6f 66 66 0a 2a 20 43 2c  | italic off.* C,|
00001170  20 31 42 2c 37 38 2c 30  2c 31 42 2c 33 34 2c 31  | 1B,78,0,1B,34,1|
00001180  42 2c 34 37 20 20 20 20  20 20 2a 20 4c 58 20 4e  |B,47      * LX N|
00001190  4c 51 20 69 74 61 6c 69  63 20 6f 6e 20 28 64 6f  |LQ italic on (do|
000011a0  75 62 6c 65 20 64 72 61  66 74 21 29 0a 2a 20 44  |uble draft!).* D|
000011b0  2c 20 31 42 2c 34 38 2c  31 42 2c 33 35 2c 31 42  |, 1B,48,1B,35,1B|
000011c0  2c 37 38 2c 31 20 20 20  20 20 20 2a 20 4c 58 20  |,78,1      * LX |
000011d0  4e 4c 51 20 69 74 61 6c  69 63 20 6f 66 66 0a 2a  |NLQ italic off.*|
000011e0  20 45 2c 20 31 42 2c 37  32 2c 35 20 20 20 20 20  | E, 1B,72,5     |
000011f0  20 20 20 20 20 20 20 20  20 20 20 20 20 2a 20 4a  |             * J|
00001200  58 20 44 72 61 66 74 20  6c 69 67 68 74 20 6f 6e  |X Draft light on|
00001210  20 28 72 65 64 29 0a 2a  20 46 2c 20 31 42 2c 37  | (red).* F, 1B,7|
00001220  32 2c 30 20 20 20 20 20  20 20 20 20 20 20 20 20  |2,0             |
00001230  20 20 20 20 20 2a 20 4a  58 20 44 72 61 66 74 20  |     * JX Draft |
00001240  6c 69 67 68 74 20 6f 66  66 20 28 62 6c 61 63 6b  |light off (black|
00001250  29 0a 2a 20 31 30 2c 31  42 2c 37 38 2c 30 20 20  |).* 10,1B,78,0  |
00001260  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
00001270  2a 20 4c 58 20 4e 4c 51  20 6c 69 67 68 74 20 6f  |* LX NLQ light o|
00001280  6e 0a 2a 20 31 31 2c 31  42 2c 37 38 2c 31 20 20  |n.* 11,1B,78,1  |
00001290  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
000012a0  2a 20 4c 58 20 4e 4c 51  20 6c 69 67 68 74 20 6f  |* LX NLQ light o|
000012b0  66 66 0a 2a 20 31 30 2c  31 42 2c 37 38 2c 30 20  |ff.* 10,1B,78,0 |
000012c0  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
000012d0  20 2a 20 4c 51 20 4e 4c  51 20 6c 69 67 68 74 20  | * LQ NLQ light |
000012e0  6f 6e 0a 2a 20 31 31 2c  31 42 2c 37 38 2c 31 20  |on.* 11,1B,78,1 |
000012f0  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
00001300  20 2a 20 4c 51 20 4e 4c  51 20 6c 69 67 68 74 20  | * LQ NLQ light |
00001310  6f 66 66 0a 31 32 2c 20  20 31 42 2c 35 33 2c 30  |off.12,  1B,53,0|
00001320  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
00001330  20 20 2a 20 20 20 20 44  72 61 66 74 20 73 75 70  |  *    Draft sup|
00001340  65 72 73 63 72 69 70 74  20 6f 6e 0a 31 33 2c 20  |erscript on.13, |
00001350  20 31 42 2c 35 34 20 20  20 20 20 20 20 20 20 20  | 1B,54          |
00001360  20 20 20 20 20 20 20 20  20 20 2a 20 20 20 20 44  |          *    D|
00001370  72 61 66 74 20 73 75 70  65 72 73 63 72 69 70 74  |raft superscript|
00001380  20 6f 66 66 0a 2a 20 31  34 2c 31 42 2c 37 38 2c  | off.* 14,1B,78,|
00001390  30 2c 31 42 2c 35 33 2c  30 20 20 20 20 20 20 20  |0,1B,53,0       |
000013a0  20 20 20 2a 20 4c 58 20  4e 4c 51 20 73 75 70 65  |   * LX NLQ supe|
000013b0  72 73 63 72 69 70 74 20  6f 6e 0a 2a 20 31 35 2c  |rscript on.* 15,|
000013c0  31 42 2c 35 34 2c 31 42  2c 37 38 2c 31 20 20 20  |1B,54,1B,78,1   |
000013d0  20 20 20 20 20 20 20 20  20 2a 20 4c 58 20 4e 4c  |         * LX NL|
000013e0  51 20 73 75 70 65 72 73  63 72 69 70 74 20 6f 66  |Q superscript of|
000013f0  66 0a 31 36 2c 20 20 31  42 2c 35 33 2c 31 20 20  |f.16,  1B,53,1  |
00001400  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
00001410  2a 20 20 20 20 44 72 61  66 74 20 73 75 62 73 63  |*    Draft subsc|
00001420  72 69 70 74 20 6f 6e 0a  31 37 2c 20 20 31 42 2c  |ript on.17,  1B,|
00001430  35 34 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |54              |
00001440  20 20 20 20 20 20 2a 20  20 20 20 44 72 61 66 74  |      *    Draft|
00001450  20 73 75 62 73 63 72 69  70 74 20 6f 66 66 0a 2a  | subscript off.*|
00001460  20 31 38 2c 31 42 2c 37  38 2c 30 2c 31 42 2c 35  | 18,1B,78,0,1B,5|
00001470  33 2c 31 20 20 20 20 20  20 20 20 20 20 2a 20 4c  |3,1          * L|
00001480  58 20 4e 4c 51 20 73 75  62 73 63 72 69 70 74 20  |X NLQ subscript |
00001490  6f 6e 0a 2a 20 31 39 2c  31 42 2c 35 34 2c 31 42  |on.* 19,1B,54,1B|
000014a0  2c 37 38 2c 31 20 20 20  20 20 20 20 20 20 20 20  |,78,1           |
000014b0  20 2a 20 4c 58 20 4e 4c  51 20 73 75 62 73 63 72  | * LX NLQ subscr|
000014c0  69 70 74 20 6f 66 66 0a  31 41 2c 20 20 31 42 2c  |ipt off.1A,  1B,|
000014d0  32 44 2c 31 20 20 20 20  20 20 20 20 20 20 20 20  |2D,1            |
000014e0  20 20 20 20 20 20 2a 20  20 20 20 44 72 61 66 74  |      *    Draft|
000014f0  20 75 6e 64 65 72 6c 69  6e 65 20 6f 6e 0a 31 42  | underline on.1B|
00001500  2c 20 20 31 42 2c 32 44  2c 30 20 20 20 20 20 20  |,  1B,2D,0      |
00001510  20 20 20 20 20 20 20 20  20 20 20 20 2a 20 20 20  |            *   |
00001520  20 44 72 61 66 74 20 75  6e 64 65 72 6c 69 6e 65  | Draft underline|
00001530  20 6f 66 66 0a 2a 20 31  43 20 20 20 20 20 20 20  | off.* 1C       |
00001540  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
00001550  20 20 20 2a 20 20 20 20  4e 4c 51 20 75 6e 64 65  |   *    NLQ unde|
00001560  72 6c 69 6e 65 20 6f 6e  0a 2a 20 31 44 20 20 20  |rline on.* 1D   |
00001570  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
00001580  20 20 20 20 20 20 20 2a  20 20 20 20 4e 4c 51 20  |       *    NLQ |
00001590  75 6e 64 65 72 6c 69 6e  65 20 6f 66 66 0a 31 45  |underline off.1E|
000015a0  2c 20 20 43 20 20 20 20  20 20 20 20 20 20 20 20  |,  C            |
000015b0  20 20 20 20 20 20 20 20  20 20 20 20 2a 20 20 20  |            *   |
000015c0  20 46 6f 72 6d 66 65 65  64 0a 31 46 2c 20 20 31  | Formfeed.1F,  1|
000015d0  32 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |2               |
000015e0  20 20 20 20 20 20 20 20  2a 20 20 20 20 48 6f 72  |        *    Hor|
000015f0  69 7a 6f 6e 74 61 6c 20  69 6e 69 74 69 61 6c 69  |izontal initiali|
00001600  7a 61 74 69 6f 6e 0a 32  30 2c 20 20 31 42 2c 35  |zation.20,  1B,5|
00001610  32 2c 30 20 20 20 20 20  20 20 20 20 20 20 20 20  |2,0             |
00001620  20 20 20 20 20 2a 20 20  20 20 56 65 72 74 69 63  |     *    Vertic|
00001630  61 6c 20 69 6e 69 74 69  61 6c 69 7a 61 74 69 6f  |al initializatio|
00001640  6e 0a 2a 20 32 30 20 20  20 20 20 20 20 20 20 20  |n.* 20          |
00001650  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
00001660  2a 20 53 4d 20 56 65 72  74 69 63 61 6c 20 69 6e  |* SM Vertical in|
00001670  69 74 69 61 6c 69 73 61  74 69 6f 6e 0a 32 31 2c  |itialisation.21,|
00001680  20 20 31 42 2c 34 30 20  20 20 20 20 20 20 20 20  |  1B,40         |
00001690  20 20 20 20 20 20 20 20  20 20 20 2a 20 20 20 20  |           *    |
000016a0  54 65 72 6d 69 6e 61 74  69 6f 6e 3a 20 70 72 69  |Termination: pri|
000016b0  6e 74 65 72 20 72 65 73  65 74 0a 32 32 2c 20 20  |nter reset.22,  |
000016c0  38 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |8               |
000016d0  20 20 20 20 20 20 20 20  20 2a 20 20 20 20 42 61  |         *    Ba|
000016e0  63 6b 73 70 61 63 65 0a  32 33 2c 20 20 44 20 20  |ckspace.23,  D  |
000016f0  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
00001700  20 20 20 20 20 20 2a 20  20 20 20 43 61 72 72 69  |      *    Carri|
00001710  61 67 65 20 72 65 74 75  72 6e 0a 32 34 2c 20 20  |age return.24,  |
00001720  31 42 2c 34 33 2c 38 30  20 20 20 20 20 20 20 20  |1B,43,80        |
00001730  20 20 20 20 20 20 20 20  20 2a 20 20 20 20 46 6f  |         *    Fo|
00001740  72 6d 20 6c 65 6e 67 74  68 20 69 6e 20 6c 69 6e  |rm length in lin|
00001750  65 73 0a 32 35 2c 20 20  31 42 2c 34 31 2c 38 30  |es.25,  1B,41,80|
00001760  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
00001770  20 2a 20 20 20 20 53 65  74 20 6c 69 6e 65 20 66  | *    Set line f|
00001780  65 65 64 20 74 6f 20 4e  20 75 6e 69 74 73 0a 32  |eed to N units.2|
00001790  36 2c 20 20 31 42 2c 32  41 2c 35 20 20 20 20 20  |6,  1B,2A,5     |
000017a0  20 20 20 20 20 20 20 20  20 20 20 20 20 2a 20 20  |             *  |
000017b0  20 20 53 74 61 72 74 20  67 72 61 70 68 69 63 73  |  Start graphics|
000017c0  20 28 6d 6f 64 65 20 35  29 0a 2a 20 32 36 2c 31  | (mode 5).* 26,1|
000017d0  42 2c 32 41 2c 30 20 20  20 20 20 20 20 20 20 20  |B,2A,0          |
000017e0  20 20 20 20 20 20 20 20  2a 20 4c 51 20 53 74 61  |        * LQ Sta|
000017f0  72 74 20 67 72 61 70 68  69 63 73 20 28 6d 6f 64  |rt graphics (mod|
00001800  65 20 30 29 0a 2a 20 32  36 2c 31 42 2c 35 39 20  |e 0).* 26,1B,59 |
00001810  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
00001820  20 20 20 2a 20 53 4d 20  53 74 61 72 74 20 67 72  |   * SM Start gr|
00001830  61 70 68 69 63 73 0a 2a  20 32 37 20 20 20 20 20  |aphics.* 27     |
00001840  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
00001850  20 20 20 20 20 2a 20 20  20 20 52 65 73 65 72 76  |     *    Reserv|
00001860  65 64 0a 32 38 2c 20 20  31 32 2c 31 42 2c 35 37  |ed.28,  12,1B,57|
00001870  2c 30 2c 31 42 2c 35 30  20 20 20 20 20 20 20 20  |,0,1B,50        |
00001880  20 2a 20 20 20 20 44 72  61 66 74 20 50 69 63 61  | *    Draft Pica|
00001890  20 20 20 20 20 20 28 31  30 20 20 20 63 70 69 29  |      (10   cpi)|
000018a0  0a 2a 20 32 39 20 20 20  20 20 20 20 20 20 20 20  |.* 29           |
000018b0  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 2a  |               *|
000018c0  20 20 20 20 4e 4c 51 20  20 20 50 69 63 61 20 20  |    NLQ   Pica  |
000018d0  20 20 20 20 28 31 30 20  20 20 63 70 69 29 0a 32  |    (10   cpi).2|
000018e0  41 2c 20 20 31 32 2c 31  42 2c 35 37 2c 30 2c 31  |A,  12,1B,57,0,1|
000018f0  42 2c 34 44 20 20 20 20  20 20 20 20 20 2a 20 20  |B,4D         *  |
00001900  20 20 44 72 61 66 74 20  45 6c 69 74 65 20 20 20  |  Draft Elite   |
00001910  20 20 28 31 32 20 20 20  63 70 69 29 0a 2a 20 32  |  (12   cpi).* 2|
00001920  42 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |B               |
00001930  20 20 20 20 20 20 20 20  20 20 20 2a 20 20 20 20  |           *    |
00001940  4e 4c 51 20 20 20 45 6c  69 74 65 20 20 20 20 20  |NLQ   Elite     |
00001950  28 31 32 20 20 20 63 70  69 29 0a 32 43 2c 20 20  |(12   cpi).2C,  |
00001960  31 42 2c 35 37 2c 30 2c  31 42 2c 35 30 2c 46 20  |1B,57,0,1B,50,F |
00001970  20 20 20 20 20 20 20 20  20 2a 20 20 20 20 44 72  |         *    Dr|
00001980  61 66 74 20 43 6f 6e 64  65 6e 73 65 64 20 28 31  |aft Condensed (1|
00001990  37 2e 32 20 63 70 69 29  0a 2a 20 32 44 20 20 20  |7.2 cpi).* 2D   |
000019a0  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
000019b0  20 20 20 20 20 20 20 2a  20 20 20 20 4e 4c 51 20  |       *    NLQ |
000019c0  20 20 43 6f 6e 64 65 6e  73 65 64 20 28 31 37 2e  |  Condensed (17.|
000019d0  32 20 63 70 69 29 0a 32  45 2c 20 20 31 32 2c 31  |2 cpi).2E,  12,1|
000019e0  42 2c 34 44 2c 31 42 2c  35 37 2c 31 20 20 20 20  |B,4D,1B,57,1    |
000019f0  20 20 20 20 20 2a 20 20  20 20 44 72 61 66 74 20  |     *    Draft |
00001a00  45 78 70 61 6e 64 65 64  20 20 28 20 36 20 20 20  |Expanded  ( 6   |
00001a10  63 70 69 29 0a 2a 20 32  46 20 20 20 20 20 20 20  |cpi).* 2F       |
00001a20  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
00001a30  20 20 20 2a 20 20 20 20  4e 4c 51 20 20 20 45 78  |   *    NLQ   Ex|
00001a40  70 61 6e 64 65 64 20 20  28 20 36 20 20 20 63 70  |panded  ( 6   cp|
00001a50  69 29 0a 2a 20 32 38 2c  31 42 2c 37 38 2c 30 2c  |i).* 28,1B,78,0,|
00001a60  31 32 2c 31 42 2c 35 37  2c 30 2c 31 42 2c 35 30  |12,1B,57,0,1B,50|
00001a70  20 2a 20 4c 58 20 44 72  61 66 74 20 50 69 63 61  | * LX Draft Pica|
00001a80  20 20 20 20 20 20 28 31  30 20 20 20 63 70 69 29  |      (10   cpi)|
00001a90  0a 2a 20 32 39 2c 31 32  2c 31 42 2c 35 37 2c 30  |.* 29,12,1B,57,0|
00001aa0  2c 31 42 2c 35 30 2c 31  42 2c 37 38 2c 31 20 2a  |,1B,50,1B,78,1 *|
00001ab0  20 4c 58 20 4e 4c 51 20  20 20 50 69 63 61 20 20  | LX NLQ   Pica  |
00001ac0  20 20 20 20 28 31 30 20  20 20 63 70 69 29 0a 2a  |    (10   cpi).*|
00001ad0  20 32 41 2c 31 42 2c 37  38 2c 30 2c 31 32 2c 31  | 2A,1B,78,0,12,1|
00001ae0  42 2c 35 37 2c 30 2c 31  42 2c 34 44 20 2a 20 4c  |B,57,0,1B,4D * L|
00001af0  58 20 44 72 61 66 74 20  45 6c 69 74 65 20 20 20  |X Draft Elite   |
00001b00  20 20 28 31 32 20 20 20  63 70 69 29 0a 2a 20 32  |  (12   cpi).* 2|
00001b10  42 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |B               |
00001b20  20 20 20 20 20 20 20 20  20 20 20 2a 20 4c 58 20  |           * LX |
00001b30  4e 4c 51 20 20 20 45 6c  69 74 65 20 20 20 20 20  |NLQ   Elite     |
00001b40  28 31 32 20 20 20 63 70  69 29 0a 2a 20 32 43 2c  |(12   cpi).* 2C,|
00001b50  31 42 2c 37 38 2c 30 2c  31 42 2c 35 37 2c 30 2c  |1B,78,0,1B,57,0,|
00001b60  31 42 2c 35 30 2c 46 20  20 2a 20 4c 58 20 44 72  |1B,50,F  * LX Dr|
00001b70  61 66 74 20 43 6f 6e 64  65 6e 73 65 64 20 28 31  |aft Condensed (1|
00001b80  37 2e 32 20 63 70 69 29  0a 2a 20 32 44 20 20 20  |7.2 cpi).* 2D   |
00001b90  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
00001ba0  20 20 20 20 20 20 20 2a  20 4c 58 20 4e 4c 51 20  |       * LX NLQ |
00001bb0  20 20 43 6f 6e 64 65 6e  73 65 64 20 28 31 37 2e  |  Condensed (17.|
00001bc0  32 20 63 70 69 29 0a 2a  20 32 45 2c 31 42 2c 37  |2 cpi).* 2E,1B,7|
00001bd0  38 2c 30 2c 31 32 2c 31  42 2c 34 44 2c 31 42 2c  |8,0,12,1B,4D,1B,|
00001be0  35 37 2c 31 20 2a 20 4c  58 20 44 72 61 66 74 20  |57,1 * LX Draft |
00001bf0  45 78 70 61 6e 64 65 64  20 20 28 20 36 20 20 20  |Expanded  ( 6   |
00001c00  63 70 69 29 0a 2a 20 32  46 20 20 20 20 20 20 20  |cpi).* 2F       |
00001c10  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
00001c20  20 20 20 2a 20 4c 58 20  4e 4c 51 20 20 20 45 78  |   * LX NLQ   Ex|
00001c30  70 61 6e 64 65 64 20 20  28 20 36 20 20 20 63 70  |panded  ( 6   cp|
00001c40  69 29 0a 2a 20 32 38 2c  31 42 2c 37 38 2c 30 2c  |i).* 28,1B,78,0,|
00001c50  31 32 2c 31 42 2c 35 37  2c 30 2c 31 42 2c 35 30  |12,1B,57,0,1B,50|
00001c60  20 2a 20 4c 51 20 44 72  61 66 74 20 50 69 63 61  | * LQ Draft Pica|
00001c70  20 20 20 20 20 20 28 31  30 20 20 20 63 70 69 29  |      (10   cpi)|
00001c80  0a 2a 20 32 39 2c 31 32  2c 31 42 2c 35 37 2c 30  |.* 29,12,1B,57,0|
00001c90  2c 31 42 2c 35 30 2c 31  42 2c 37 38 2c 31 20 2a  |,1B,50,1B,78,1 *|
00001ca0  20 4c 51 20 4e 4c 51 20  20 20 50 69 63 61 20 20  | LQ NLQ   Pica  |
00001cb0  20 20 20 20 28 31 30 20  20 20 63 70 69 29 0a 2a  |    (10   cpi).*|
00001cc0  20 32 41 2c 31 42 2c 37  38 2c 30 2c 31 32 2c 31  | 2A,1B,78,0,12,1|
00001cd0  42 2c 35 37 2c 30 2c 31  42 2c 34 44 20 2a 20 4c  |B,57,0,1B,4D * L|
00001ce0  51 20 44 72 61 66 74 20  45 6c 69 74 65 20 20 20  |Q Draft Elite   |
00001cf0  20 20 28 31 32 20 20 20  63 70 69 29 0a 2a 20 32  |  (12   cpi).* 2|
00001d00  42 2c 31 32 2c 31 42 2c  35 37 2c 30 2c 31 42 2c  |B,12,1B,57,0,1B,|
00001d10  34 44 2c 31 42 2c 37 38  2c 31 20 2a 20 4c 51 20  |4D,1B,78,1 * LQ |
00001d20  4e 4c 51 20 20 20 45 6c  69 74 65 20 20 20 20 20  |NLQ   Elite     |
00001d30  28 31 32 20 20 20 63 70  69 29 0a 2a 20 32 43 2c  |(12   cpi).* 2C,|
00001d40  31 42 2c 37 38 2c 30 2c  31 42 2c 35 37 2c 30 2c  |1B,78,0,1B,57,0,|
00001d50  31 42 2c 35 30 2c 46 20  20 2a 20 4c 51 20 44 72  |1B,50,F  * LQ Dr|
00001d60  61 66 74 20 43 6f 6e 64  65 6e 73 65 64 20 28 31  |aft Condensed (1|
00001d70  37 2e 32 20 63 70 69 29  0a 2a 20 32 44 2c 31 42  |7.2 cpi).* 2D,1B|
00001d80  2c 35 37 2c 30 2c 31 42  2c 35 30 2c 46 2c 31 42  |,57,0,1B,50,F,1B|
00001d90  2c 37 38 2c 31 20 20 2a  20 4c 51 20 4e 4c 51 20  |,78,1  * LQ NLQ |
00001da0  20 20 43 6f 6e 64 65 6e  73 65 64 20 28 31 37 2e  |  Condensed (17.|
00001db0  32 20 63 70 69 29 0a 2a  20 32 45 2c 31 42 2c 37  |2 cpi).* 2E,1B,7|
00001dc0  38 2c 30 2c 31 32 2c 31  42 2c 34 44 2c 31 42 2c  |8,0,12,1B,4D,1B,|
00001dd0  35 37 2c 31 20 2a 20 4c  51 20 44 72 61 66 74 20  |57,1 * LQ Draft |
00001de0  45 78 70 61 6e 64 65 64  20 20 28 20 36 20 20 20  |Expanded  ( 6   |
00001df0  63 70 69 29 0a 2a 20 32  46 2c 31 32 2c 31 42 2c  |cpi).* 2F,12,1B,|
00001e00  34 44 2c 31 42 2c 35 37  2c 31 2c 31 42 2c 37 38  |4D,1B,57,1,1B,78|
00001e10  2c 31 20 2a 20 4c 51 20  4e 4c 51 20 20 20 45 78  |,1 * LQ NLQ   Ex|
00001e20  70 61 6e 64 65 64 20 20  28 20 36 20 20 20 63 70  |panded  ( 6   cp|
00001e30  69 29 0a 2a 20 33 30 2c  31 42 2c 37 32 2c 30 20  |i).* 30,1B,72,0 |
00001e40  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
00001e50  20 2a 20 4a 58 20 42 6c  61 63 6b 20 20 20 69 6e  | * JX Black   in|
00001e60  6b 0a 2a 20 33 31 2c 31  42 2c 37 32 2c 31 20 20  |k.* 31,1B,72,1  |
00001e70  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
00001e80  2a 20 4a 58 20 4d 61 67  65 6e 74 61 20 69 6e 6b  |* JX Magenta ink|
00001e90  0a 2a 20 33 32 2c 31 42  2c 37 32 2c 32 20 20 20  |.* 32,1B,72,2   |
00001ea0  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 2a  |               *|
00001eb0  20 4a 58 20 43 79 61 6e  20 20 20 20 69 6e 6b 0a  | JX Cyan    ink.|
00001ec0  2a 20 33 33 2c 31 42 2c  37 32 2c 34 20 20 20 20  |* 33,1B,72,4    |
00001ed0  20 20 20 20 20 20 20 20  20 20 20 20 20 20 2a 20  |              * |
00001ee0  4a 58 20 59 65 6c 6c 6f  77 20 20 69 6e 6b 0a 30  |JX Yellow  ink.0|
00001ef0  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
00001f00  20 20 20 20 20 20 20 20  20 20 20 20 20 2a 20 20  |             *  |
00001f10  20 20 4e 55 4c 4c 20 74  65 72 6d 69 6e 61 74 69  |  NULL terminati|
00001f20  6f 6e 20 62 79 74 65 0a  0a 0a 2a 20 20 20 20 54  |on byte...*    T|
00001f30  72 61 6e 73 6c 61 74 69  6f 6e 20 54 61 62 6c 65  |ranslation Table|
00001f40  20 28 45 70 73 6f 6e 20  50 72 69 6e 74 65 72 73  | (Epson Printers|
00001f50  29 0a 2a 20 20 20 20 3d  3d 3d 3d 3d 3d 3d 3d 3d  |).*    =========|
00001f60  3d 3d 3d 3d 3d 3d 3d 3d  3d 3d 3d 3d 3d 3d 3d 3d  |================|
00001f70  3d 3d 3d 3d 3d 3d 3d 3d  3d 0a 2a 0a 2a 20 20 20  |=========.*.*   |
00001f80  20 54 68 69 73 20 74 61  62 6c 65 20 69 73 20 75  | This table is u|
00001f90  73 65 64 20 74 6f 20 74  72 61 6e 73 6c 61 74 65  |sed to translate|
00001fa0  20 74 68 65 20 41 72 63  68 69 6d 65 64 65 73 0a  | the Archimedes.|
00001fb0  2a 20 20 20 20 63 68 61  72 61 63 74 65 72 20 63  |*    character c|
00001fc0  6f 64 65 73 20 66 6f 72  20 6f 75 74 70 75 74 20  |odes for output |
00001fd0  74 6f 20 74 68 65 20 70  72 69 6e 74 65 72 2e 0a  |to the printer..|
00001fe0  2a 0a 2a 20 20 20 20 45  61 63 68 20 65 6e 74 72  |*.*    Each entr|
00001ff0  79 20 63 6f 6e 73 69 73  74 73 20 6f 66 3a 0a 2a  |y consists of:.*|
00002000  0a 2a 20 20 20 20 28 31  29 20 20 41 72 63 68 69  |.*    (1)  Archi|
00002010  6d 65 64 65 73 20 63 68  61 72 61 63 74 65 72 20  |medes character |
00002020  63 6f 64 65 20 28 74 68  65 73 65 20 6d 75 73 74  |code (these must|
00002030  20 62 65 20 69 6e 20 6f  72 64 65 72 29 0a 2a 20  | be in order).* |
00002040  20 20 20 28 32 29 20 20  54 68 65 20 28 70 6f 73  |   (2)  The (pos|
00002050  73 69 62 6c 79 20 6e 75  6c 6c 29 20 62 79 74 65  |sibly null) byte|
00002060  20 73 74 72 69 6e 67 20  74 6f 20 62 65 20 6f 75  | string to be ou|
00002070  74 70 75 74 0a 2a 0a 2a  20 20 20 20 41 72 63 68  |tput.*.*    Arch|
00002080  69 6d 65 64 65 73 20 63  68 61 72 61 63 74 65 72  |imedes character|
00002090  20 63 6f 64 65 73 20 77  69 74 68 20 61 20 4e 55  | codes with a NU|
000020a0  4c 4c 20 74 72 61 6e 73  6c 61 74 69 6f 6e 0a 2a  |LL translation.*|
000020b0  20 20 20 20 73 74 72 69  6e 67 20 61 72 65 20 70  |    string are p|
000020c0  72 69 6e 74 65 64 20 61  73 20 73 70 61 63 65 73  |rinted as spaces|
000020d0  2e 0a 2a 0a 2a 20 20 20  20 41 72 63 68 69 6d 65  |..*.*    Archime|
000020e0  64 65 73 20 63 68 61 72  61 63 74 65 72 20 63 6f  |des character co|
000020f0  64 65 73 20 4e 4f 54 20  69 6e 20 74 68 65 20 74  |des NOT in the t|
00002100  61 62 6c 65 20 61 72 65  20 73 65 6e 74 0a 2a 20  |able are sent.* |
00002110  20 20 20 64 69 72 65 63  74 6c 79 20 74 6f 20 74  |   directly to t|
00002120  68 65 20 70 72 69 6e 74  65 72 20 77 69 74 68 6f  |he printer witho|
00002130  75 74 20 74 72 61 6e 73  6c 61 74 69 6f 6e 2e 0a  |ut translation..|
00002140  0a 41 30 0a 41 31 2c 20  31 42 2c 20 35 32 2c 20  |.A0.A1, 1B, 52, |
00002150  37 2c 20 35 42 2c 20 31  42 2c 20 35 32 2c 20 30  |7, 5B, 1B, 52, 0|
00002160  20 20 2a 20 a1 20 2d 20  53 70 61 6e 69 73 68 0a  |  * . - Spanish.|
00002170  41 32 2c 20 31 42 2c 20  35 32 2c 20 34 2c 20 37  |A2, 1B, 52, 4, 7|
00002180  43 2c 20 31 42 2c 20 35  32 2c 20 30 20 20 2a 20  |C, 1B, 52, 0  * |
00002190  a2 20 2d 20 44 61 6e 69  73 68 20 31 0a 41 33 2c  |. - Danish 1.A3,|
000021a0  20 31 42 2c 20 35 32 2c  20 33 2c 20 32 33 2c 20  | 1B, 52, 3, 23, |
000021b0  31 42 2c 20 35 32 2c 20  30 20 20 2a 20 a3 20 2d  |1B, 52, 0  * . -|
000021c0  20 55 4b 0a 41 34 0a 41  35 2c 20 31 42 2c 20 35  | UK.A4.A5, 1B, 5|
000021d0  32 2c 20 34 2c 20 35 43  2c 20 31 42 2c 20 35 32  |2, 4, 5C, 1B, 52|
000021e0  2c 20 30 20 20 2a 20 a5  20 2d 20 44 61 6e 69 73  |, 0  * . - Danis|
000021f0  68 20 31 0a 41 36 0a 41  37 20 20 20 20 20 20 20  |h 1.A6.A7       |
00002200  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
00002210  20 20 20 20 20 2a 20 a7  20 2d 20 4e 2f 41 0a 41  |     * . - N/A.A|
00002220  38 2c 20 31 42 2c 20 35  32 2c 20 31 2c 20 37 45  |8, 1B, 52, 1, 7E|
00002230  2c 20 31 42 2c 20 35 32  2c 20 30 20 20 2a 20 a8  |, 1B, 52, 0  * .|
00002240  20 2d 20 46 72 65 6e 63  68 0a 41 39 20 20 20 20  | - French.A9    |
00002250  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
00002260  20 20 20 20 20 20 20 20  2a 20 a9 20 2d 20 4e 2f  |        * . - N/|
00002270  41 0a 41 41 2c 20 36 31  2c 20 38 2c 20 35 46 20  |A.AA, 61, 8, 5F |
00002280  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
00002290  2a 20 aa 20 2d 20 61 20  42 53 20 5f 0a 41 42 20  |* . - a BS _.AB |
000022a0  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
000022b0  20 20 20 20 20 20 20 20  20 20 20 2a 20 ab 20 2d  |           * . -|
000022c0  20 4e 2f 41 0a 41 43 20  20 20 20 20 20 20 20 20  | N/A.AC         |
000022d0  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
000022e0  20 20 20 2a 20 ac 20 2d  20 4e 2f 41 0a 41 44 0a  |   * . - N/A.AD.|
000022f0  41 45 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |AE              |
00002300  20 20 20 20 20 20 20 20  20 20 20 20 20 20 2a 20  |              * |
00002310  ae 20 2d 20 4e 2f 41 0a  41 46 0a 42 30 2c 20 31  |. - N/A.AF.B0, 1|
00002320  42 2c 20 35 32 2c 20 31  2c 20 35 42 2c 20 31 42  |B, 52, 1, 5B, 1B|
00002330  2c 20 35 32 2c 20 30 20  20 2a 20 b0 20 2d 20 46  |, 52, 0  * . - F|
00002340  72 65 6e 63 68 0a 42 31  2c 20 32 42 2c 20 38 2c  |rench.B1, 2B, 8,|
00002350  20 35 46 20 20 20 20 20  20 20 20 20 20 20 20 20  | 5F             |
00002360  20 20 20 20 2a 20 b1 20  2d 20 2b 20 42 53 20 5f  |    * . - + BS _|
00002370  0a 42 32 20 20 20 20 20  20 20 20 20 20 20 20 20  |.B2             |
00002380  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 2a  |               *|
00002390  20 b2 20 2d 20 4e 2f 41  0a 42 33 20 20 20 20 20  | . - N/A.B3     |
000023a0  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
000023b0  20 20 20 20 20 20 20 2a  20 b3 20 2d 20 4e 2f 41  |       * . - N/A|
000023c0  0a 42 34 20 20 20 20 20  20 20 20 20 20 20 20 20  |.B4             |
000023d0  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 2a  |               *|
000023e0  20 b4 20 2d 20 4e 2f 41  0a 42 35 20 20 20 20 20  | . - N/A.B5     |
000023f0  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
00002400  20 20 20 20 20 20 20 2a  20 b5 20 2d 20 4e 2f 41  |       * . - N/A|
00002410  0a 42 36 20 20 20 20 20  20 20 20 20 20 20 20 20  |.B6             |
00002420  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 2a  |               *|
00002430  20 b6 20 2d 20 4e 2f 41  0a 42 37 0a 42 38 0a 42  | . - N/A.B7.B8.B|
00002440  39 0a 42 41 2c 20 36 46  2c 20 38 2c 20 35 46 20  |9.BA, 6F, 8, 5F |
00002450  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
00002460  2a 20 ba 20 2d 20 6f 20  42 53 20 5f 0a 42 42 20  |* . - o BS _.BB |
00002470  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
00002480  20 20 20 20 20 20 20 20  20 20 20 2a 20 bb 20 2d  |           * . -|
00002490  20 4e 2f 41 0a 42 43 20  20 20 20 20 20 20 20 20  | N/A.BC         |
000024a0  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
000024b0  20 20 20 2a 20 bc 20 2d  20 4e 2f 41 0a 42 44 20  |   * . - N/A.BD |
000024c0  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
000024d0  20 20 20 20 20 20 20 20  20 20 20 2a 20 bd 20 2d  |           * . -|
000024e0  20 4e 2f 41 0a 42 45 0a  42 46 2c 20 31 42 2c 20  | N/A.BE.BF, 1B, |
000024f0  35 32 2c 20 37 2c 20 35  44 2c 20 31 42 2c 20 35  |52, 7, 5D, 1B, 5|
00002500  32 2c 20 30 20 20 2a 20  bf 20 2d 20 53 70 61 6e  |2, 0  * . - Span|
00002510  69 73 68 0a 43 30 20 20  20 20 20 20 20 20 20 20  |ish.C0          |
00002520  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
00002530  20 20 2a 20 c0 20 2d 20  4e 2f 41 0a 43 31 0a 43  |  * . - N/A.C1.C|
00002540  32 0a 43 33 20 20 20 20  20 20 20 20 20 20 20 20  |2.C3            |
00002550  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
00002560  2a 20 c3 20 2d 20 4e 2f  41 0a 43 34 2c 20 31 42  |* . - N/A.C4, 1B|
00002570  2c 20 35 32 2c 20 32 2c  20 35 42 2c 20 31 42 2c  |, 52, 2, 5B, 1B,|
00002580  20 35 32 2c 20 30 20 20  2a 20 c4 20 2d 20 47 65  | 52, 0  * . - Ge|
00002590  72 6d 61 6e 0a 43 35 2c  20 31 42 2c 20 35 32 2c  |rman.C5, 1B, 52,|
000025a0  20 34 2c 20 35 44 2c 20  31 42 2c 20 35 32 2c 20  | 4, 5D, 1B, 52, |
000025b0  30 20 20 2a 20 c5 20 2d  20 44 61 6e 69 73 68 20  |0  * . - Danish |
000025c0  31 0a 43 36 2c 20 31 42  2c 20 35 32 2c 20 34 2c  |1.C6, 1B, 52, 4,|
000025d0  20 35 42 2c 20 31 42 2c  20 35 32 2c 20 30 20 20  | 5B, 1B, 52, 0  |
000025e0  2a 20 c6 20 2d 20 44 61  6e 69 73 68 20 31 0a 43  |* . - Danish 1.C|
000025f0  37 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |7               |
00002600  20 20 20 20 20 20 20 20  20 20 20 20 20 2a 20 c7  |             * .|
00002610  20 2d 20 4e 2f 41 0a 43  38 0a 43 39 2c 20 31 42  | - N/A.C8.C9, 1B|
00002620  2c 20 35 32 2c 20 39 2c  20 34 30 2c 20 31 42 2c  |, 52, 9, 40, 1B,|
00002630  20 35 32 2c 20 30 20 20  2a 20 c9 20 2d 20 4e 6f  | 52, 0  * . - No|
00002640  72 77 65 67 69 61 6e 0a  43 41 0a 43 42 0a 43 43  |rwegian.CA.CB.CC|
00002650  0a 43 44 0a 43 45 0a 43  46 0a 44 30 0a 44 31 2c  |.CD.CE.CF.D0.D1,|
00002660  20 31 42 2c 20 35 32 2c  20 37 2c 20 35 43 2c 20  | 1B, 52, 7, 5C, |
00002670  31 42 2c 20 35 32 2c 20  30 20 20 2a 20 d1 20 2d  |1B, 52, 0  * . -|
00002680  20 53 70 61 6e 69 73 68  0a 44 32 0a 44 33 0a 44  | Spanish.D2.D3.D|
00002690  34 0a 44 35 20 20 20 20  20 20 20 20 20 20 20 20  |4.D5            |
000026a0  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
000026b0  2a 20 d5 20 2d 20 4e 2f  41 0a 44 36 2c 20 31 42  |* . - N/A.D6, 1B|
000026c0  2c 20 35 32 2c 20 32 2c  20 35 43 2c 20 31 42 2c  |, 52, 2, 5C, 1B,|
000026d0  20 35 32 2c 20 30 20 20  2a 20 d6 20 2d 20 47 65  | 52, 0  * . - Ge|
000026e0  72 6d 61 6e 0a 44 37 0a  44 38 2c 20 31 42 2c 20  |rman.D7.D8, 1B, |
000026f0  35 32 2c 20 38 2c 20 35  43 2c 20 31 42 2c 20 35  |52, 8, 5C, 1B, 5|
00002700  32 2c 20 30 20 20 2a 20  d8 20 2d 20 4a 61 70 61  |2, 0  * . - Japa|
00002710  6e 65 73 65 0a 44 39 0a  44 41 0a 44 42 0a 44 43  |nese.D9.DA.DB.DC|
00002720  2c 20 31 42 2c 20 35 32  2c 20 32 2c 20 35 44 2c  |, 1B, 52, 2, 5D,|
00002730  20 31 42 2c 20 35 32 2c  20 30 20 20 2a 20 dc 20  | 1B, 52, 0  * . |
00002740  2d 20 47 65 72 6d 61 6e  0a 44 44 0a 44 45 0a 44  |- German.DD.DE.D|
00002750  46 0a 45 30 2c 20 31 42  2c 20 35 32 2c 20 31 2c  |F.E0, 1B, 52, 1,|
00002760  20 34 30 2c 20 31 42 2c  20 35 32 2c 20 30 20 20  | 40, 1B, 52, 0  |
00002770  2a 20 e0 20 2d 20 46 72  65 6e 63 68 0a 45 31 20  |* . - French.E1 |
00002780  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
00002790  20 20 20 20 20 20 20 20  20 20 20 2a 20 e1 20 2d  |           * . -|
000027a0  20 4e 2f 41 0a 45 32 2c  20 36 31 2c 20 38 2c 20  | N/A.E2, 61, 8, |
000027b0  35 45 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |5E              |
000027c0  20 20 20 2a 20 e2 20 2d  20 61 20 42 53 20 5e 0a  |   * . - a BS ^.|
000027d0  45 33 2c 20 36 31 2c 20  38 2c 20 37 45 20 20 20  |E3, 61, 8, 7E   |
000027e0  20 20 20 20 20 20 20 20  20 20 20 20 20 20 2a 20  |              * |
000027f0  e3 20 2d 20 61 20 42 53  20 7e 0a 45 34 2c 20 31  |. - a BS ~.E4, 1|
00002800  42 2c 20 35 32 2c 20 32  2c 20 37 42 2c 20 31 42  |B, 52, 2, 7B, 1B|
00002810  2c 20 35 32 2c 20 30 20  20 2a 20 e4 20 2d 20 47  |, 52, 0  * . - G|
00002820  65 72 6d 61 6e 0a 45 35  2c 20 31 42 2c 20 35 32  |erman.E5, 1B, 52|
00002830  2c 20 34 2c 20 37 44 2c  20 31 42 2c 20 35 32 2c  |, 4, 7D, 1B, 52,|
00002840  20 30 20 20 2a 20 e5 20  2d 20 44 61 6e 69 73 68  | 0  * . - Danish|
00002850  20 31 0a 45 36 2c 20 31  42 2c 20 35 32 2c 20 34  | 1.E6, 1B, 52, 4|
00002860  2c 20 37 42 2c 20 31 42  2c 20 35 32 2c 20 30 20  |, 7B, 1B, 52, 0 |
00002870  20 2a 20 e6 20 2d 20 44  61 6e 69 73 68 20 31 0a  | * . - Danish 1.|
00002880  45 37 2c 20 31 42 2c 20  35 32 2c 20 31 2c 20 35  |E7, 1B, 52, 1, 5|
00002890  43 2c 20 31 42 2c 20 35  32 2c 20 30 20 20 2a 20  |C, 1B, 52, 0  * |
000028a0  e7 20 2d 20 46 72 65 6e  63 68 0a 45 38 2c 20 31  |. - French.E8, 1|
000028b0  42 2c 20 35 32 2c 20 31  2c 20 37 44 2c 20 31 42  |B, 52, 1, 7D, 1B|
000028c0  2c 20 35 32 2c 20 30 20  20 2a 20 e8 20 2d 20 46  |, 52, 0  * . - F|
000028d0  72 65 6e 63 68 0a 45 39  2c 20 31 42 2c 20 35 32  |rench.E9, 1B, 52|
000028e0  2c 20 31 2c 20 37 42 2c  20 31 42 2c 20 35 32 2c  |, 1, 7B, 1B, 52,|
000028f0  20 30 20 20 2a 20 e9 20  2d 20 46 72 65 6e 63 68  | 0  * . - French|
00002900  0a 45 41 2c 20 36 35 2c  20 38 2c 20 35 45 20 20  |.EA, 65, 8, 5E  |
00002910  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 2a  |               *|
00002920  20 ea 20 2d 20 65 20 42  53 20 5e 0a 45 42 2c 20  | . - e BS ^.EB, |
00002930  36 35 2c 20 38 2c 31 42  2c 35 32 2c 31 2c 37 45  |65, 8,1B,52,1,7E|
00002940  2c 31 42 2c 35 32 2c 30  20 20 2a 20 eb 20 2d 20  |,1B,52,0  * . - |
00002950  65 20 42 53 20 46 72 65  6e 63 68 20 a8 0a 45 43  |e BS French ..EC|
00002960  2c 20 31 42 2c 20 35 32  2c 20 36 2c 20 37 45 2c  |, 1B, 52, 6, 7E,|
00002970  20 31 42 2c 20 35 32 2c  20 30 20 20 2a 20 ec 20  | 1B, 52, 0  * . |
00002980  2d 20 49 74 61 6c 69 61  6e 0a 45 44 20 20 20 20  |- Italian.ED    |
00002990  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
000029a0  20 20 20 20 20 20 20 20  2a 20 ed 20 2d 20 4e 2f  |        * . - N/|
000029b0  41 0a 45 45 20 20 20 20  20 20 20 20 20 20 20 20  |A.EE            |
000029c0  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
000029d0  2a 20 ee 20 2d 20 4e 2f  41 0a 45 46 20 20 20 20  |* . - N/A.EF    |
000029e0  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
000029f0  20 20 20 20 20 20 20 20  2a 20 ef 20 2d 20 4e 2f  |        * . - N/|
00002a00  41 0a 46 30 0a 46 31 2c  20 31 42 2c 20 35 32 2c  |A.F0.F1, 1B, 52,|
00002a10  20 37 2c 20 37 43 2c 20  31 42 2c 20 35 32 2c 20  | 7, 7C, 1B, 52, |
00002a20  30 20 20 2a 20 f1 20 2d  20 53 70 61 6e 69 73 68  |0  * . - Spanish|
00002a30  0a 46 32 2c 20 31 42 2c  20 35 32 2c 20 36 2c 20  |.F2, 1B, 52, 6, |
00002a40  37 43 2c 20 31 42 2c 20  35 32 2c 20 30 20 20 2a  |7C, 1B, 52, 0  *|
00002a50  20 f2 20 2d 20 49 74 61  6c 69 61 6e 0a 46 33 20  | . - Italian.F3 |
00002a60  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
00002a70  20 20 20 20 20 20 20 20  20 20 20 2a 20 f3 20 2d  |           * . -|
00002a80  20 4e 2f 41 0a 46 34 2c  20 36 46 2c 20 38 2c 20  | N/A.F4, 6F, 8, |
00002a90  35 45 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |5E              |
00002aa0  20 20 20 2a 20 f4 20 2d  20 6f 20 42 53 20 5e 0a  |   * . - o BS ^.|
00002ab0  46 35 2c 20 36 46 2c 20  38 2c 20 37 45 20 20 20  |F5, 6F, 8, 7E   |
00002ac0  20 20 20 20 20 20 20 20  20 20 20 20 20 20 2a 20  |              * |
00002ad0  f5 20 2d 20 6f 20 42 53  20 7e 0a 46 36 2c 20 31  |. - o BS ~.F6, 1|
00002ae0  42 2c 20 35 32 2c 20 32  2c 20 37 43 2c 20 31 42  |B, 52, 2, 7C, 1B|
00002af0  2c 20 35 32 2c 20 30 20  20 2a 20 f6 20 2d 20 47  |, 52, 0  * . - G|
00002b00  65 72 6d 61 6e 0a 46 37  20 20 20 20 20 20 20 20  |erman.F7        |
00002b10  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
00002b20  20 20 20 20 2a 20 f7 20  2d 20 4e 2f 41 0a 46 38  |    * . - N/A.F8|
00002b30  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
00002b40  20 20 20 20 20 20 20 20  20 20 20 20 2a 20 f8 20  |            * . |
00002b50  2d 20 4e 2f 41 0a 46 39  2c 20 31 42 2c 20 35 32  |- N/A.F9, 1B, 52|
00002b60  2c 20 31 2c 20 37 43 2c  20 31 42 2c 20 35 32 2c  |, 1, 7C, 1B, 52,|
00002b70  20 30 20 20 2a 20 f9 20  2d 20 46 72 65 6e 63 68  | 0  * . - French|
00002b80  0a 46 41 20 20 20 20 20  20 20 20 20 20 20 20 20  |.FA             |
00002b90  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 2a  |               *|
00002ba0  20 fa 20 2d 20 4e 2f 41  0a 46 42 2c 20 37 35 2c  | . - N/A.FB, 75,|
00002bb0  20 38 2c 20 35 45 20 20  20 20 20 20 20 20 20 20  | 8, 5E          |
00002bc0  20 20 20 20 20 20 20 2a  20 fb 20 2d 20 75 20 42  |       * . - u B|
00002bd0  53 20 5e 0a 46 43 2c 20  31 42 2c 20 35 32 2c 20  |S ^.FC, 1B, 52, |
00002be0  32 2c 20 37 44 2c 20 31  42 2c 20 35 32 2c 20 30  |2, 7D, 1B, 52, 0|
00002bf0  20 20 2a 20 fc 20 2d 20  47 65 72 6d 61 6e 0a 46  |  * . - German.F|
00002c00  44 0a 46 45 0a 46 46 2c  20 37 39 2c 20 38 2c 31  |D.FE.FF, 79, 8,1|
00002c10  42 2c 35 32 2c 31 2c 37  45 2c 31 42 2c 35 32 2c  |B,52,1,7E,1B,52,|
00002c20  30 20 20 2a 20 ff 20 2d  20 79 20 42 53 20 46 72  |0  * . - y BS Fr|
00002c30  65 6e 63 68 20 a8 0a 0a  0a 30 20 20 20 20 20 20  |ench ....0      |
00002c40  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
00002c50  20 20 20 20 20 20 20 2a  20 4e 55 4c 4c 20 74 65  |       * NULL te|
00002c60  72 6d 69 6e 61 74 6f 72  0a 0a                    |rminator..|
00002c6a
1WP_Print/Sources/matrix.m0
1WP_Print/Sources/matrix.m1
1WP_Print/Sources/matrix.m2
1WP_Print/Sources/matrix.m4
1WP_Print/Sources/matrix.m5

© Dominic Ford 2021–2024.

Our privacy policy is here.
Last updated: 28 Jul 2024, 23:31 UTC
Website designed by .
