Filename: P/Edit2
Read OK: ✔
File size: 1863 bytes
Load address: 45204556
Exec address: 32746964
File contents
mode 0 screen editor comments
Variables:

 M$ current message,DOTX & DOTY current cursor position,STRTX & STRTY
start cursor position before dragging (BRX,BRY) & (TLX,TLY) are bottom
right and top left x and y coordinates of the original box that was saved

A is internal counter and inkey and general pass parameters thingy. F is
always used as the file#.

OVR is the isolated bit taken from the clipboard file as viewed in the
order that it was saved and  the order it is being loaded in  in.FLG is
set 0 if the chosen bit (see OVR) wasn't set and vice versa

PASS is a counting loop used in the MODE5 module and also when drawing a
box (hence will always be a mutliple of 2)

SCRN is used in the MODE5 module,and is initially set to &140 less that
the bottom of the screen memory (as in the genric section th at follows
&140 is added back on) for the mode.LOC is the current byte in
question,being poked

SVTLX is used in the two versions of the loadin routine (see MODE5 module
and around line 700) to keep the original value saved whil e the actual
value is incremented

TMPX and TMPY are used to provide compatibilty between routines - ie.to
pass parameters and count things in loops

CNSTY and CNSTX are used when dragging out a box and effectively set the
stp of the FOR...NEXT loop to enable the box the be dragged from any
corner

HINDX and EINDX are used for when the appropriate whole selected bytes are
to be saved.Home index is how many bits in from the MSB o f the byte the
cursor is at and End index is how many bits in from the MSB too
23,0,10,12... is used to disable the cursor.If there are any suspicious
+1's anywhere it is usually because natural numbers start an d 1 but the
co-ordinate system starts at 0,0

Filenames:

EDIT is the startup and load in part ; EDITTMP is used internally as a
temporary file when the move option is chosen and will be del eted ;

EDITCRE the core program which is where almost all execution time is spent

EDITENL contains the pixel by pixel editor ; EDITCLP is the clipboard file
in the format (strtx,strty)(dotx,doty)(bytes...  To avoid the can't extend
error ensure the disk is *compacted.No it won't run accross the tube as it
pokes memory addresses

Errors:

within the core program only ; 'SIZE?' means that the selected area to
zoom in on was greater than 30x40 ; 'WIDTH?' and 'DEPTH?' mea ns that the
selected area didn't enclose any pixels ; 'CANNOT' is given by the paste
command if there is no clipboard file on the di sk

Blow by blow:

EDIT>>>

FX3,4 restores output to the screen when re-entering fron 'editenl' as it
is turned off in that program to jab keys into the keyboar d buffer ;
FX4,1 makes the cursors ASCii ; HIMEM is dropped as the message area is
stored here later FX12,8 slows the keyboard repeat to prevent delays while
the pixel-pointer catches up with the keyboard buffer EDITCRE>>>

Is made up of many gosubs each of which are used by the command table
right at te beginning.In order of appearance they are Keypresses are
detected and if cursor keys then the pixel-pointer is move else check is
it is one of the reserved words  Save what was in the message area (eight
letters each taking 8 bytes) just below screen memory then print the
message using MOVE and

 VDU5 then restore those bytHighlight the cursor with a 2x2 box by
starting (x-2,y-2) from the current cursor position the increasin g the
co-ordinates.If the point is off the screen then nothing is plotted to
avoid half the box appearing on the other side of the s creen  mass
calculation to locate any pixel on the screen using true (x,y)
co-ordinates measured from top left (0,0) to bottom right (639,2 55)

Expand a box by seeing which of the cursors was pressed and adding or
subtracting from DOTn.CNSTX and CNSTY allow the box to be drag ged
starting at any corner,although on pressing chrs(135) they are sorted into
size order so that STRTn is  top left and DOTn is bottom right.If the box
has no depth or width then the user will be alerted of this

Move box by adding to BOTH STRTn and DOTn instead of just DOTn as above.On
pressing chrs(135) it returns

Save boxed area to nearest whole byte (the individual bits required from
each end is calculated later)

Loadin by getting a byte from the file,ANDing it with a mask,and then
checking whether the chosen bit is set.Then get byte from scre en
memory,AND it with a negative mask to ensure the selected bit is set 0.Or
the two together

Clear the area temporarily renames the clipboard file,then creates its own
by saving a load of VAL(M$),using M$ to save variable nam es.Load in that
file,and restore the clipboard.255=white;0=black,170=(10101010) therefore
grey

Select black,grey,or white.No default,if the question is not answered it
is asked again.

Get co-ordinates of the area last selected in the clipboard file.If not
exist then print 'CANNOT' in the message area

One pass version of the draw a pulsing box.This is only used by the box
drawer so that the box is permanently left on the screen

Enter text (delete and copy are disabled).Pressing RETURN puts it in
columns.Ex-or's it so that if crossing a black/white boundary i t appears
50:50

Procedit drags a box,saves the area,saves the entire screen to
$.OUTPUT,then chains the mode5 extention module  EDITENL>>>

Openin the file,to get co-ordinates,remove the cursor with VDU23,define
variables and those with I want to save unaltered for later

As with loadin above,except that is flag is set then a whole square is
coloured in with a for...next poking 255 into the screen memo ry  Print
current pixel position,which can be increased up to the limit of the
screen (29,39).

If tab pressed then ex-or whatever was there with 255 but if pressed
chrs(135) then stop the editor and save Reverse of loadin except that if
TLX~8 isn't zero then some blank bits must be saved in the byte before the
'pixels' (squares on the screen) can be evaluated otherwise the file would
be ((HINDX+(8-EINDX))*Y too short

Print 'reloading' then emulate what '$.EDIT' does (loads in the
screen,turn on the first pixel at TLHC) then insert 'P' into the key b
buffer and run '$.EDITCRE' which then jumps to 'paste' mode to insert the
new version

R.Sprowson 3/9/95
