6 Bollinbrook road,
MACCLESFIELD,
Cheshire.
SK10 3DJ.
MOUSEY
======
Following my article in response to a
member's question about serial mice
for a BBC I have plodded on in my
quest for success...
It turns out that the reason why my
BASIC driver only returned 00 01 and
FF in hex was not because BASIC
couldn't keep up but because the light
sensors had got bent out of place in
the mouse casing!
That aside,the next task is to get
some machine code going.The new
program on this disk ("MOUSEY") may be
*RUN having set up your Mouse Systems
compatible mouse (NB not Microsoft).
The packets of 5 bytes will be printed
on the screen as and when there is
mouse or button movement.
This software operates in the
background as per a finished version
would have to so you can carry on
doing other things at the same time.
I haven't tested it while accessing
the disk - the DFS or ADFS hogs
interrupts so its results are
undetermined.Try it and report back to
me how it responded.
If the screen is in scroll lock mode
then the OS's IRQ handling becomes
dodgy.Likewise during background
printing or using SEI for prolonged
periods in assembler.
My driver takes this into account,and
if some of the mouse's bytes are lost
while the BBC is doing long interrupts
then it will resync itself to the
start of the next 5 byte packet.You
are informed of this by RR appearing
on screen.
Now all that remains (he says) is to
get some sort of a pointer on the
screen.I know what the 5 bytes
received mean in terms of relative
positions,but these will need scaling
depending on which mode is in use.
Pop the result in a ROM,package it up
and we can all have mice - simple.
Happy computing,
R.P.Sprowson.
SORRY THAT I ASCRIBED YOUR EXCELLENT ARTICLE
IN EUG27 ON THIS SUBJECT TO MARK BELLIS.
SORRY ALSO TO MARK BELLIS.
