�CEThe Discovery of the Electron

	In 1897, ....

	The experimental work that led Thomson to this discovery was to
investigate the passage of electric current through gases at very low
pressures. It is thought that the first experiments on this complicated
and controversial subject were carried out by Hauksbee in 1709. He
evacuated a glass vessel to the lowest pressure available, then set up a
high electric field in the vessel using bodies charged by friction. He
noticed a coloured glow passing through the gas as the electrodes were
discharged. This occurred with a much lower electric field, and quite
different colours from those observed in sparks at atmospheric pressure.
This kind of phenomenon is now used in fluorescent lighting and in "neon"
signs.
	As time moved on, the quality of vacuum pumps improved, with the
development of the Topler pump and Sprengel pump in the mid-19th century
for example. Such apparatus allowed the coductivity of gases to be
investigated over a much wider range of pressures. As the pressure was
slowly decreased from that used in Hauksbee's experiments to around
0.05mmHg (7 Pa), the coloured glow in the discharge tube   started to
divide into "striations" with characteristic dark spaces near the  cathode.
When the pressure fell further, to around 0.01mmHg (1 Pa), the dark space
closest to the cathode, called the Crookes dark space, extended to fill
the entire tube, and a green fluorescence was seen on the walls of the
tube.
	This kind of discharge was first observed and investigated in 1859
by Julius Plucker. It was his pupil Hittorf who had the ingenious idea of
using tube with a large anode in the shape of a Maltese cross, and a small
disc-shaped cathode. When a potential difference was applied across the
high vacuum in the tube, he found that the green fluorescence was spread
almost uniformly across the end of the tube, except for a well-defined
shadow left by the Maltese cross. This suggested to Hittorf that the
fluorescence was caused by an interaction between the glass and some kind
of rays, which emanated from the cathode and travelled in straight lines
until their path was blocked. He continued the experiments by using
different shapes and materials in place of the Maltese cross, and found in
every case that the rays were blocked by the object, and a shadow was
formed on the glass.
	This famous experiment was taken up again and extended in 1876 by
Goldstein, who first gave these rays the modern name of "cathode rays".
Instead of Hittorf's small cathode and large Maltese  cross, Goldstein
used a large cathode with a small object blocking the rays. If the rays
behaved like light, we would expect a blurred shadow in this case, with a
large penumbra but no umbra. This would be analogous to the image seen by
a human eye focussing on a distant landscape while a small pin is held in
front of the eye - the image of the pin is blurred over the landscape as
light passes into the lens either side of it.
	However, he found the shadow in this case to be just as sharp as in
Hittorf's experiment. This suggested that the rays were not being emitted
in every direction from each part of the cathode, like the photons emitted
from an incandescent object or the light arriving at the surface of a
human eye. Instead they were emitted normally (perpendicular to the
surface of the cathode) from each point, so that the rays striking each
part of the Maltese cross were all travelling in the same direction.
Goldstein was himself unable to use this clue as to the nature of the
cathode rays. His view was that the rays were waves propagating like light, through
the aether - a medium thought to exist as a absolute rest
frame, through which all electric and magnetic fields were conveyed. It
was later proven by Michelson and Morley's experiment of 1887, and
justified by Einstein's special theory of relativity in 1905, that such a
medium does not exist. However, until the nature of the rays was finally
proven beyond doubt, most German physicists supported Goldstein's view.
	At the same time a completely different theory was being developed
by a number of British physicists to explain the properties of the cathode
rays. They thought that the rays were streams of some kind of particle,
though the nature of the particle was unknown. This theory had an
immediate advantage over that of Goldstein, in that the laws governing
particles were well known, while the properties of the aetherial waves
were a complete mystery. This enabled supporters of the particle thoery to
make predictions about the rays and to test the properties of the
particles.
	The first such experiment was carried out by Sir William Crookes,
who attempted  to detect any momentum carried by them. He placed an
extremely light wind vane in the path of the rays, and found that the vane
started to turn slowly as if bombarded by particles. It is now known that
this rotation was caused by the rays heating the surface of the vane, and
thus increasing the pressure of the gas next to it. This has little to do
with the particulate nature of the rays, but by  coincidence Crooke's
result steered him in the direction of a correct theory. This result, and
others which followed, were published in the Philosophical Transactions,
1879.
	Crookes's next, more important, observation has already been
mentioned. As the pressure in a gas discharge tube is decreased from
atmospheric pressure, we first find a glow coming from gas itself. This
glow recedes away from the cathode leaving a dark space (called the
Crookes dark space), which at very low pressure fills the entire tube. In
this state, only the walls of the tube will phosphoresce, not the gas.
Crookes suggested that the phosphorescence was caused by colliions between
the cathode ray particles and the gas molecules in the tube. The end of
the dark space would then represent the place where the rays are likely to
have their first collision with a gas molecule. That is, the length of the
dark space is a measure of the mean free path of a cathode ray particle
travelling through the gas concerned. This idea fitted well with the
pressure-variation of the dark space, and suggested to Crookes that the
rays could be some kind of molecules, whose motion conformed to the
kinetic theory of gases. As we now know, the rays are not composed of
molecules, but Crookes again provided vital evidence for the particle
theory.
	Crookes also noticed that the rays could be deflected by a magnetic
field - he inferred this from the displacement of the phosphorescent patch
on the walls of the tube. This suggested that the rays may be carrying
some electric current, but he was unable to find any precise law relating the
deflection to the applied field. Furthermore, he suggested that if the
rays were carrying currents of charged particles, their path should be
strongly influenced by the position and shape of the anode. His
experiments showed that this was not the case, so the nature of the rays
was thrown into question once again.
