BALLBOT ARTIFICIAL INTELLIGENCE SIMULATION
Archimedes Version
Documentation

Welcome to the BallBot artificial intelligence development simulation - used by the authors to test and develop the software used to control the tennis ball-seeking robot. The simulation's program consists of two main blocks of code: the simulation itself, and the artificial intelligence algorithm. The simulation passes data to the artificial intelligence module which relates to the data which would be recieved by the robot's sonar, and then waits for the artificial intelligence module to process the data. It then takes the control data which it recieves back from the artificial intelligence system, and uses it to update the robot's position on the tennis court. The cycle then repeats.

First download the attached file, and run it on an Archimedes. The simplest way to demonstrate the simulation working is to select option 1 on the main menu (Real-Time Simulation), and you are given access to the virtual tennis court. Using the mouse, you can left click to place up to five tennis balls on the court, which BallBot must try to collect. These are yellow circles, and BallBot itself is represented by a red marker. Press the space bar when you have placed the balls roughly where you want them, and you can watch the robot attempt to collect the balls. You can continue to place balls on the court even after the robot has started looking for them, although the robot may stop before collecting them all if you do this, as it makes the assumption that areas of the court which it has already scanned will remain clear of balls. To restart the robot, press the space bar again.

In order to test the overall reliability of this system though, it would be very laborious to continually give the simulation different ball arrangements to try, to see if it cannot cope with any of them. Therefore I developed a new "Logged Continuous Runs" feature, which allows the computer to make up random ball arrangements, and then examines how well the robot collects them. After each run it produces a verdict, which is one of the following:

"PASS" - The run seemed to go OK.
"TIME" - The robot took longer than 5 minutes to collect the balls, which usually means that the software crashed and the robot came to a point of indecision.
"CRASH" - The robot drove into the net.
"FAIL" - The robot stopped, having verified that the court was clear of balls, when in fact there were still balls waiting for collection.

The simulation also reports the time taken for the balls to be collected, as well as the coordinates of where the tennis balls were placed on the court. These are saved to a large text file, whose filename you are requested at the start of the logged continuous runs.
