This website contains an archive of files for the Acorn Electron, BBC Micro, Acorn Archimedes, Commodore 16 and Commodore 64 computers, which Dominic Ford has rescued from his private collection of floppy disks and cassettes.

Some of these files were originally commercial releases in the 1980s and 1990s, but they are now widely available online. I assume that copyright over them is no longer being asserted. If you own the copyright and would like files to be removed, please contact me.

Tape/disk:	Home » Personal collection » Acorn ADFS disks » Greaseweazled » dfs_box04_disk02b_eug_scripts.adf
Filename:	CAD/CADNew/CAD
Read OK:	✔
File size:	2E5A bytes
Load address:	FFFF0E00
Exec address:	FFFF802B

Duplicates

There are 2 duplicate copies of this file in the archive:

Personal collection » Acorn ADFS disks » Electron_User_Group » EUG_41.ADF » P/CAD
Personal collection » Acorn ADFS disks » Greaseweazled » dfs_box04_disk02b_eug_scripts.adf » CAD/CADNew/CAD
Personal collection » Acorn hard disk » zipped_disks » elk06 » eug41/P/CAD

File contents

   10REM Advanced CAD - Loader
   20REM (C) Dominic Ford 1998
   30MODE4:PRINT"Initialising...":VDU23,1,0;0;0;0;23,255,&C0,&F0,&FC,&FF,&FF,&FC,&F0,&C0:HIMEM=&5200
   40PROCass:*FX4,1
   50PRINTTAB(0,0)SPC(8);"Welcome to Advanced CAD"'SPC(6);"Written by Dominic Ford 1998"
   60PRINT''"Do you wish to use an AMX mouse with    this software? If you do, you will be   unable to use other input devices with  it. Do not answer yes if you do not havethe AMX ROM installed."
   70PRINT'"Please select: (M)ouse or (K)eyboard"
   80REPEAT k$=GET$:UNTILINSTR("mMkK",k$)>0:IFINSTR("mM",k$)=0THEN120
   90ONERRORGOTO110
  100SCLI"MOUSE ON":ONERROROFF:?mouse=1:GOTO150
  110ONERROROFF:PRINT''"Error: No AMX Mouse ROM detected"
  120PRINT''"Do you wish to use an analogue joystick?If you do, you will still be able to usethe keyboard, although any other devicesplugged into the analogue port may      interfere with this software."
  130PRINT'"Please select: (Y)es or (N)o"
  140REPEAT k$=GET$:UNTILINSTR("yYnN",k$)>0:IFINSTR("yY",k$)>0THEN?joyst=1
  150PRINT''"Loading main program..."
  160CHAIN"CAD2"
  170DEFPROCass
  180oswrch=&FFEE:chip=7:opamp=13:FORpass=0TO2STEP2:P%=&5200:[OPT pass
  190JMPdraw:JMPwhatover:JMPdelete:JMPgetlink:EQUDpinbase \ Jump table
  200.joyst EQUB0:.mouse EQUB0:EQUDrehair \ Input device select
  210.label LDY#0:JSRgetpos:LDA&76:CLC:ADC#64:STA&76:LDA&77:ADC#0:STA&77:LDX#4:JSRicline:LDA#5:JSRoswrch:LDY#8:.dolab LDA(&72),Y:JSRoswrch:INY:TYA:AND#3:BNEdolab
  220CPY#16:BEQendlab:LDA#10:JSRoswrch:LDA#8:JSRoswrch:JSRoswrch:JSRoswrch:JSRoswrch:JMPdolab:.endlab LDA#4:JMPoswrch
  230.draw LDA#&10:STA&72:LDA#&48:STA&73:LDA&4800:.dloop BEQdrend:PHA:JSRdrawcomp:JSRlabel:LDA&72:CLC:ADC#16:STA&72:LDA&73:ADC#0:STA&73:PLA:SEC:SBC#1:JMPdloop
  240.drend LDA#&F8:STA&72:LDA#&47:STA&73:LDA&47FC:STA&80:LDA&47FD:STA&81:.llop LDA&80:BNEnollnk:LDA&81:BEQlkend:.nollnk JSRdolink:LDA&72:SEC:SBC#4:STA&72:LDA&73:SBC#0:STA&73:LDA&80:SEC:SBC#1:STA&80:LDA&81:SBC#0:STA&81:JMPllop
  250.lkend RTS:.dolink LDY#0:JSRgetcoord:LDX#4:JSRicline:JSRgetcoord:LDX#5:JMPicline
  260.getcoord LDA(&72),Y:STA&78:LDA#0:STA&79:ASL&78:ROL&79:ASL&78:ROL&79:ASL&78:ROL&79:ASL&78:ROL&79:LDA&79:CLC:ADC#&48:STA&79:TYA:PHA
  270LDY#1:LDA(&78),Y:STA&74:INY:LDA(&78),Y:STA&75:INY:LDA(&78),Y:STA&76:INY:LDA(&78),Y:STA&77:LDY#0:LDA(&78),Y:JSRlinkic:ASLA:ASLA:STA&7A:PLA:TAY:INY:LDA(&72),Y:CLC:ADC&7A:TAX:LDAlinkpos,X:PHA
  280AND#15:ASLA:ASLA:STA&7A:LDA&76:SEC:SBC&7A:STA&76:LDA&77:SBC#0:STA&77:PLA:LSRA:LSRA:AND#&3C:CLC:ADC&74:STA&74:LDA&75:ADC#0:STA&75:INY:RTS
  290.getpos INY:LDA(&72),Y:STA&74:INY:LDA(&72),Y:STA&75:INY:LDA(&72),Y:STA&76:INY:LDA(&72),Y:STA&77:RTS:.ic JSRgetpos
  300LDX#4:JSRicline:LDA&74:CLC:ADC#&80:STA&74:LDA&75:ADC#0:STA&75:LDX#5:JSRicline:LDY#5:LDA(&72),Y:ASLA:ASLA:ASLA:STA&80:LDA#0:ROLA:STA&81:ASL&80:ROL&81:ASL&80:ROL&81
  310LDA&76:PHA:SEC:SBC&80:STA&76:LDA&77:PHA:SBC&81:STA&77:LDX#5:JSRicline:LDA&74:SEC:SBC#&80:STA&74:LDA&75:SBC#0:STA&75:LDX#5:JSRicline:PLA:STA&77:PLA:STA&76:LDX#5:JSRicline
  320LDA&74:CLC:ADC#&38:STA&74:LDA&75:ADC#0:STA&75:LDX#4:JSRicline:LDA&76:SEC:SBC#24:STA&76:LDA&77:SBC#0:STA&77:LDX#5:JSRicline:LDA&74:CLC:ADC#&10:STA&74:LDA&75:ADC#0:STA&75:JSRicline
  330LDA&76:CLC:ADC#24:STA&76:LDA&77:ADC#0:STA&77:JSRicline:LDA&74:SEC:SBC#&48:STA&74:LDA&75:SBC#0:STA&75:LDA&76:SEC:SBC#8:STA&76:LDA&77:SBC#0:STA&77:LDA(&72),Y:.pins PHA:JSRdrawpin:PLA:SEC:SBC#1:BNEpins:RTS
  340.drawpin LDX#4:JSRicline:LDA&74:SEC:SBC#&10:STA&74:LDA&75:SBC#0:STA&75:LDX#5:JSRicline:LDA&76:SEC:SBC#16:STA&76:LDA&77:SBC#0:STA&77:JSRicline:LDA&74:CLC:ADC#&10:STA&74:LDA&75:ADC#0:STA&75:JSRicline
  350LDA&74:CLC:ADC#&80:STA&74:LDA&75:ADC#0:STA&75:LDX#4:JSRicline:LDA&74:CLC:ADC#&10:STA&74:LDA&75:ADC#0:STA&75:LDX#5:JSRicline:LDA&76:CLC:ADC#16:STA&76:LDA&77:ADC#0:STA&77:JSRicline
  360LDA&74:SEC:SBC#&10:STA&74:LDA&75:SBC#0:STA&75:JSRicline:LDA&74:SEC:SBC#&80:STA&74:LDA&75:SBC#0:STA&75:LDA&76:SEC:SBC#&20:STA&76:LDA&77:SBC#0:STA&77:RTS
  370.icline LDA#25:JSRoswrch:TXA:JSRoswrch:LDA&74:JSRoswrch:LDA&75:JSRoswrch:LDA&76:JSRoswrch:LDA&77:JMPoswrch
  380.drawcomp LDY#0:LDA(&72),Y:CMP#chip:BNEnic:JMPic:.nic CMP#opamp:BNEnotoa:JSRnotoa:LDY#0:LDA#chip
  390.notoa ASL A:ASL A:ASL A:ASL A:STA&78:LDA#0:ROLA:STA&79:LDA&78:CLC:ADC#(comps MOD256):STA&78:LDA&79:ADC#(comps DIV256):STA&79:JSRgetpos:LDY#0
  400.drawline LDA(&78),Y:CMP#255:BEQendcomp:LDA#25:JSRoswrch:LDA#4:JSRoswrch:JSRplot:INY:LDA#25:JSRoswrch:LDA#5:JSRoswrch:JSRplot:INY:TYA:AND#15:BNEdrawline:.endcomp RTS
  410.plot LDA(&78),Y:LSRA:LSRA:AND#60:CLC:ADC&74:PHP:JSRoswrch:PLP:LDA&75:ADC#0:JSRoswrch:LDA(&78),Y:AND#15:ASLA:ASLA:STA&7A:LDA&76:SEC:SBC&7A:PHP:JSRoswrch:PLP:LDA&77:SBC#0:JMPoswrch
  420.whatover LDA#0:STA&76:STA&77:LDA#&10:STA&74:LDA#&48:STA&75:LDA&4800:.cloop BEQchend:INC&76:PHA:JSRcheckcomp:LDA&74:CLC:ADC#16:STA&74:LDA&75:ADC#0:STA&75:PLA:SEC:SBC#1:JMPcloop:.chend RTS
  430.checkcomp LDY#0:LDA(&74),Y:TAX:LDY#1:LDA&70:SEC:SBC(&74),Y:PHA:LDA&71:INY:SBC(&74),Y:BNEnohit:PLA:LSRA:LSRA:CMPxsize,X:BCSnohit2
  440INY:LDA(&74),Y:SEC:SBC&72:PHA:INY:LDA(&74),Y:SBC&73:BNEnohit:PLA:LSRA:LSRA:CMPysize,X:BCSnohit2:LDA&76:STA&77:LDA&74:STA&78:LDA&75:STA&79:RTS:.nohit PLA:.nohit2 RTS
  450.delete LDY#16:LDA(&78),Y:LDY#0:STA(&78),Y:LDA&78:CLC:ADC#1:STA&78:LDA&79:ADC#0:STA&79:CMP#&50:BNEdelete:DEC&4800
  460LDA#&F8:STA&72:STA&74:LDA#&47:STA&73:STA&75:LDA&47FC:STA&80:LDA&47FD:STA&81:LDA#0:STA&82:STA&83:.ldel LDA&80:BNEcdel:LDA&81:BEQdellk:.cdel JSRchelink
  470LDA&72:SEC:SBC#4:STA&72:LDA&73:SBC#0:STA&73:LDA&80:SEC:SBC#1:STA&80:LDA&81:SBC#0:STA&81:JMPldel:.dellk LDA&82:STA&47FC:LDA&83:STA&47FD:RTS
  480.chelink LDY#0:LDA(&72),Y:CMP&77:BEQcutlink:BCCnosubl:SBC#1:.nosubl STA(&74),Y:LDY#2:LDA(&72),Y:CMP&77:BEQcutlink:LDY#3:LDA(&72),Y:STA(&74),Y:LDY#1:LDA(&72),Y:STA(&74),Y:LDY#2:LDA(&72),Y:CMP&77:BCCnosubl2:SBC#1:.nosubl2 STA(&74),Y
  490LDA&74:SEC:SBC#4:STA&74:LDA&75:SBC#0:STA&75:LDA&82:CLC:ADC#1:STA&82:LDA&83:ADC#0:STA&83:.cutlink RTS
  500.getlink LDY#0:LDA#(links MOD256):STA&72:LDA#(links DIV256):STA&73:LDX&70:.findlnk BEQgotlnk:.fwd LDA(&72),Y:PHA:LDA&72:CLC:ADC#1:STA&72
  510LDA&73:ADC#0:STA&73:PLA:BNEfwd:DEX:JMPfindlnk:.gotlnk RTS
  520.comps EQUW&0444:EQUW&4048:EQUW&7078:EQUW&74A4:EQUW&FFFF:EQUW&FFFF:EQUW&FFFF:EQUW&FFFF
  530EQUW&0444:EQUW&4048:EQUW&7276:EQUW&8081:EQUW&8788:EQUW&74A4:EQUW&FFFF:EQUW&FFFF
  540EQUW&0646:EQUW&404C:EQUW&6369:EQUW&6686:EQUW&FFFF:EQUW&FFFF:EQUW&FFFF:EQUW&FFFF
  550EQUW&0636:EQUW&303C:EQUW&5359:EQUW&7676:EQUW&9696:EQUW&B0BC:EQUW&D3D9:EQUW&D6F6
  560EQUW&0646:EQUW&404C:EQUW&40A6:EQUW&4CA6:EQUW&A6F6:EQUW&A0AC:EQUW&FFFF:EQUW&FFFF
  570EQUW&0646:EQUW&404C:EQUW&40A6:EQUW&4CA6:EQUW&A6F6:EQUW&A2AA:EQUW&C0A2:EQUW&8CAA
  580EQUW&4044:EQUW&0484:EQUW&1676:EQUW&2868:EQUW&FFFF:EQUW&FFFF:EQUW&FFFF:EQUW&FFFF
  590EQUW&0444:EQUW&0C4C:EQUW&404F:EQUW&40C8:EQUW&5FC8:EQUW&C8F8:EQUW&8084:EQUW&8C8F \ OpAmp Part I
  600EQUW&0424:EQUW&2440:EQUW&4064:EQUW&6480:EQUW&80A4:EQUW&A4C0:EQUW&C0E4:EQUW&E4F4
  610EQUW&0444:EQUW&0C4C:EQUW&404F:EQUW&4082:EQUW&82C7:EQUW&C88D:EQUW&8D4F:EQUW&C7F7
  620EQUW&0646:EQUW&404C:EQUW&40A6:EQUW&4CA6:EQUW&B5C6:EQUW&B7C6:EQUW&C6F6:EQUW&FFFF
  630EQUW&0464:EQUW&0C6C:EQUW&616E:EQUW&4082:EQUW&82C7:EQUW&C88D:EQUW&8D4F:EQUW&C7F7
  640EQUW&0020:EQUW&2022:EQUW&2202:EQUW&0200:EQUW&FFFF:EQUW&FFFF:EQUW&FFFF:EQUW&FFFF
  650EQUW&5979:EQUW&5676:EQUW&6567:EQUW&FFFF:EQUW&FFFF:EQUW&FFFF:EQUW&FFFF:EQUW&FFFF \ OpAmp Part II
  660EQUW&0424:EQUW&2028:EQUW&20E0:EQUW&28E8:EQUW&E0E8:EQUW&E4F4:EQUW&FFFF:EQUW&FFFF
  670EQUW&0424:EQUW&2028:EQUW&20E0:EQUW&28E8:EQUW&E0E8:EQUW&E4F4:EQUW&888F:EQUW&7B9B
  680EQUW&0444:EQUW&44C0:EQUW&C4F4:EQUW&FFFF:EQUW&FFFF:EQUW&FFFF:EQUW&FFFF:EQUW&FFFF
  690EQUW&0848:EQUW&424E:EQUW&46A0:EQUW&49AF:EQUW&7C79:EQUW&7C5C:EQUW&FFFF:EQUW&FFFF
  700EQUW&0848:EQUW&424E:EQUW&46A0:EQUW&49AF:EQUW&6B8B:EQUW&6B6D:EQUW&FFFF:EQUW&FFFF
  710EQUW&0848:EQUW&444C:EQUW&727E:EQUW&74A4:EQUW&A4A0:EQUW&7CAC:EQUW&ACAF:EQUW&FFFF
  720.moucur2 PLA:STA&76:PLA:STA&75:PLA:STA&74:JMPnostick
  730]:P%=&A00:[OPTpass
  740.links EQUS"Capactr Left    Right  ":EQUB0:EQUS"Cap (E) Cathode Anode  ":EQUB0:EQUS"Cell    Cathode Anode  ":EQUB0:EQUS"Battery Cathode Anode  ":EQUB0
  750EQUS"Diode   Cathode Anode  ":EQUB0:EQUS"Zener   Cathode Anode  ":EQUB0:EQUS"Ground  Ground ":EQUB0:EQUS"IC     ":EQUB0:EQUS"Inductr Left    Right  ":EQUB0
  760EQUS"AND     Input1  Input2  Output ":EQUB0:EQUS"NOT     Input   Output ":EQUB0:EQUS"OR Gate Input1  Input2  Output ":EQUB0:EQUS"Node    Node   ":EQUB0
  770EQUS"OpAmp   V+      V-      Output  -Input  +Input ":EQUB0:EQUS"Resistr Left    Right  ":EQUB0:EQUS"Re(Var) Left    Centre  Right  ":EQUB0
  780EQUS"Switch  Left    Right  ":EQUB0:EQUS"Tr(NPN) Base    Colectr Emitter":EQUB0:EQUS"Tr(PNP) Base    Colectr Emitter":EQUB0:EQUS"Tr(FET) Gate    Drain   Source ":EQUB0
  790.linkpos EQUD&FFFFA404:EQUD&FFFF04A4:EQUD&FFFF0686:EQUD&FFFF06F6
  800EQUD&FFFF06F6:EQUD&FFFF06F6:EQUD&FFFFFF40:EQUD&FFFFFFFF
  810EQUD&FFFFF404:EQUD&FFF70C04:EQUD&FFFFF606:EQUD&FFF70C04
  820EQUD&FFFFFF11:EQUD&0CF88F80:EQUD&FFFFF404:EQUD&FFF48F04
  830EQUD&FFFFF404:EQUD&FFAFA008:EQUD&FFAFA008:EQUD&FFACA008
  840.pinbase EQUB3:EQUB4:EQUB7:EQUB8:EQUB9:EQUB10:EQUB12:EQUB14:EQUB16:EQUB20
  850.linkic CMP#chip:BEQeitheric:RTS:.eitheric PLA:PLA:PLA:TAY:INY:TYA:PHA:LDA(&72),Y:STA&7A:LDY#5:LDA(&78),Y:CMP&7A:BCCrightic:DEC&7A:.leftic LDA&74:SEC:SBC#16:STA&74:LDA&75:SBC#0:STA&75
  860LDA&76:SEC:SBC#16:STA&76:LDA&77:SBC#0:STA&77:LDX&7A:.icdl CPX#0:BEQgoticpin:LDA&76:SEC:SBC#32:STA&76:LDA&77:SBC#0:STA&77:DEX:JMPicdl:.goticpin PLA:TAY:INY:RTS
  870.rightic ASLA:SEC:SBC&7A:STA&7A:LDA&74:CLC:ADC#&A0:STA&74:LDA&75:ADC#0:STA&75:JMPleftic
  880.xsize EQUB11:EQUB11:EQUB9:EQUB16:EQUB16:EQUB16:EQUB9:EQUB32:EQUB16:EQUB16:EQUB16:EQUB16:EQUB3:EQUB16:EQUB16:EQUB16:EQUB16:EQUB11:EQUB11:EQUB11
  890.ysize EQUB9:EQUB9:EQUB13:EQUB13:EQUB13:EQUB13:EQUB9:EQUB24:EQUB5:EQUB16:EQUB13:EQUB16:EQUB3:EQUB16:EQUB9:EQUB16:EQUB5:EQUB16:EQUB16:EQUB16
  900]:P%=&5000:[OPTpass
  910JMPcursor:JMPhairpin:JMPbox:JSRcopy:JSRbox:JSRcursor:.box JSRcopy:LDX#4:JSRicline
  920LDA&76:SEC:SBC#64:STA&76:LDA&77:SBC#0:STA&77:LDX#5:JSRicline:LDA&74:CLC:ADC#64:STA&74:LDA&75:ADC#0:STA&75:LDX#5:JSRicline:LDA&76:CLC:ADC#64:STA&76:LDA&77:ADC#0:STA&77:LDX#5:JSRicline
  930LDA&74:SEC:SBC#64:STA&74:LDA&75:SBC#0:STA&75:LDX#5:JSRicline:.curend LDA#0:STA&74:STA&75:RTS
  940.moucur LDA&74:PHA:LDA&75:PHA:LDA&76:PHA:LDA#64:LDX#&70:LDY#0:JSR&FFF1:JMPmoucur2
  950.cursor JSRcopy:LDAmouse:BNEmoucur:JMPkeycur:.curback LDA&74:CMP&70:BNErehair:LDA&76:CMP&72:BNErehair:JMPcurend:.rehair NOP:JSRhairpin:JSRhairpin:JMPcurend
  960.hairpin LDA&76:SEC:SBC#20:STA&76:LDA&77:SBC#0:STA&77:LDX#4:JSRicline:LDA&76:CLC:ADC#40:STA&76:LDA&77:ADC#0:STA&77:LDX#5:JSRicline
  970LDA&76:SEC:SBC#20:STA&76:LDA&77:SBC#0:STA&77:LDA&74:SEC:SBC#20:STA&74:LDA&75:SBC#0:STA&75:LDX#4:JSRicline:LDA&74:CLC:ADC#40:STA&74:LDA&75:ADC#0:STA&75:LDX#5:JSRicline:JMPcopy
  980.keycur LDA#4:STA&78:LDX#&FF:JSRkeybyte:BCCnof:LDA#40:STA&78:.nof LDX#&9E:JSRkeybyte:BCCnokl:LDA&70:SBC&78:STA&70:LDA&71:SBC#0:STA&71
  990.nokl LDX#&BD:JSRkeybyte:BCCnokr:LDA&70:CLC:ADC&78:STA&70:LDA&71:ADC#0:STA&71:.nokr LDX#&B7:JSRkeybyte:BCCnoku:LDA&72:CLC:ADC&78:STA&72:LDA&73:ADC#0:STA&73:.noku LDX#&97:JSRkeybyte:BCCnokd:LDA&72:SEC:SBC&78:STA&72:LDA&73:SBC#0:STA&73
 1000.nokd LDAjoyst:BEQnostick:JSRjoycur:.nostick LDA&71:CMP#&FF:BNEnobot:LDA#0:STA&70:STA&71:.nobot LDA&73:CMP#&FF:BNEnolef:LDA#0:STA&72:STA&73
 1010.nolef LDA&71:CMP#5:BNEnorig:LDA#0:STA&70:.norig LDA&73:CMP#3:BCCnotop:LDA&72:CMP#115:BCCnotop:LDA#115:STA&72:.notop JMPcurback
 1020.keybyte LDY#255:LDA#&81:JMP&FFF4:.copy LDA&70:STA&74:LDA&71:STA&75:LDA&72:STA&76:LDA&73:STA&77:RTS
 1030]:P%=&100:[OPTpass
 1040.joycur LDX#1:LDA#&80:JSR&FFF4:CPY#94:BCSnorigj:LDA&70:ADC#4:STA&70:LDA&71:ADC#0:STA&71:.norigj CPY#39:BCSnorigjt:LDA&70:ADC#36:STA&70:LDA&71:ADC#0:STA&71
 1050.norigjt CPY#156:BCCnolefj:LDA&70:SBC#4:STA&70:LDA&71:SBC#0:STA&71:.nolefj CPY#215:BCCnolefjt:LDA&70:SBC#36:STA&70:LDA&71:SBC#0:STA&71:.nolefjt LDX#2:LDA#&80:JSR&FFF4:CPY#94:BCSnoupj
 1060LDA&72:SEC:SBC#4:STA&72:LDA&73:SBC#0:STA&73:.noupj CPY#39:BCSnoupjt:LDA&72:SEC:SBC#36:STA&72:LDA&73:SBC#0:STA&73:.noupjt CPY#156:BCCnodowj:LDA&72:CLC:ADC#4:STA&72:LDA&73:ADC#0:STA&73
 1070.nodowj CPY#215:BCCnodowjt:LDA&72:CLC:ADC#36:STA&72:LDA&73:ADC#0:STA&73:.nodowjt RTS
 1080]:NEXT:ENDPROC
