THE RUBIK CUBE
~~~~~~~~~~~~~~
By John McHugh
(Notes by Richard from info from John)
John sent in this excellent program many moons ago to include in my
Programs section. It seems that since then I have been involved in many
other things - I have often thought that the problem with the Elk is
that it gives me too many ideas!!! I am sorry for the late delivery!!
When I asked for some notes on the way the program works and on solving
the cube, as I thought that this would be of interest to members, back
came a 'wad' of notes including six MODE 2 screen dumps showing
routines for solving it!! I think this would have to be serialised
if anyone is interested. In the the meantime, here are some notes on
the program.
The program runs in MODE 2 and the screen is loaded as separate file. This
shows an 'exploded' view of the cube so that you can see all sides of it.
This also shows the keys to use for the two rotating cursors.
John has used a DATA file rather than arrays for the data on colours
and the x,y coordiates and VDU23 numbers for the two cursors so as to
save memory. I give the details of the data as he has listed it -
DATA FILE &900 -&96B
~~~~~~~~~~~~~~~~~~~~
VARIABLE. ADDRESS. COLOURS. (POINTERS - ABCDEFGHIJKL)
V 0900 05 05 05 05 05 05 05 05 05 TOP
. 0909 06 06 06 06 06 06 06 06 06 REAR
. 0912 02 02 02 02 02 02 02 02 02 LEFT
. 091B 03 03 03 03 03 03 03 03 03 RIGHT
. 0924 07 07 07 07 07 07 07 07 07 FRONT
. 092D 01 01 01 01 01 01 01 01 01 BOTTOM
. CYAN CURSOR. (POINTER W%)
J% 0936 04 05 06 07 07 07 06 05 04 03 03 03 X% TAB
K% 0942 0E 0E 0E 0F 10 11 12 12 12 11 10 0F Y% TAB
L% 094E E6 E6 E6 E8 E8 E8 E7 E7 E7 E9 E9 E9 CHAR
. GREEN CURSOR. (POINTER E%)
M%(+1) 095A 0D 0E 0F 0F 0E 0D O% TAB
N%(+1) 0960 0B 0A 09 0D 0E 0F P% TAB
Q%(+1) 0966 E6 E6 E6 E7 E7 E7 CHAR
The main program uses multi-statement lines to save memory and to make
the program run quicker.
The lines 40 & 50 alter the auto repeat values and I found with my fumble
fingers that this made the cursors too fast!! These lines can be deleted
if anyone finds them difficult to control.
Line 70 sets up the characters-
CHR$ 225 to 227 for the cube colours
CHR$ 230 to 233 for the cursors
Line 100 allocates names to frequently used variable values.
Lines 110 to 200 are the main loop -
lines 130 to 160 vary the values of W% and E% to select the section
to move and PROC X (cyan) and PROC Y (green) move the cursors.
Lines 170 and 180 select PROC M (cyan) and PROC N (green)
These 'move' the the section of the cube, by swapping the colours, through
PROC C and, where the top, bottom or sides move, through PROC B or PROC D
depending on which way the side moves.
The cube is printed using -
VDU31,X,Y,col,char,....
and the procedures swap the colours using the indirection operator (?) -
eg VDUa,Y,Z,b,V?A,c,b,V?B,c,..
becomes VDU31,Y,Z,17,col,char,17,col,char,..
B%,C%,D% are used to hold three of the colours while the twelve colours of
the four sides are swapped. In PROC B and PROC D only B% and C% are
needed as only eight colours are swapped as the centre remains the same.
I hope this brief explanation is of interest and gives some idea of how
the program works.
Have fun shuffling the cube and trying to solve it. I will try to give
some clues on how to do this if there is sufficient interest.
