CODE 13 BARCODES...
Using the EAN (European article number) encoding the barcode consists of
1.Combination number.This is the first digit,in our example is 5.
It refers to how the next 6 digits are encrypted as
follows
COMB # PATTERN TO FOLLOW
0 A A A A A A
1 A A B A B B
2 A A B B A B
3 A A B B B A
4 A B A A B B
5 A B B A A B
6 A B B B A A
7 A B A B A B
8 A B A B B A
9 A B B A B A
2.The start bit.Two parallel bars
3.The following 6.Encrypted as above,then (taking '1' as black and '0' as
white) are converted onto 7 bit binary digits.
REPRESENTS... SET A SET B SET C
0 0001101 0100111 1110010
1 0011001 0110011 1100110
2 0010011 0011011 1101100
3 0111101 0100001 1000010
4 0100011 0011101 1011100 Notice that not C = A and that
5 0110001 0111001 1001110 reverse of C = B
6 0101111 0000101 1010000
7 0111011 0010001 1000100
8 0110111 0001001 1001000
9 0001011 0010111 1110100
4.The guard bit.Two parallel bars
5.The following 6.Encrypted in set C always,then (taking '1' as black and
white as '0') are converted onto 7 bit binary digits.
6.The end bit.Two parallel bars
7.The checksum.For the barcode 123456782093C where C is the check bit to be determined by the following calculation
1.Add up the alternate numbers starting at the 12th:
[3+0+8+6+4+2=23]
2.Times (1) by 3 => 69
3.Add up the alternate numbers starting at the 11th:
[9+2+7+5+3+1=27]
4.Add parts (2) and (3) => 96
5.Find the smallest number needed to make part (4) evenly divisible by ten
[100-96=4 so C=4 as 100x10 is even and 4 < 14 which would be the next]
FROM...
Robert Sprowson.
Happy soldering!
