USING THE ASSEMBLER 5
~~~~~~~~~~~~~~~~~~~~~
By Richard Dimond
I promised to discuss the making up of screens as I had in mind a program
from EU which I had converted to a completely M/code game and I hope to
publish this in the next issue together with some explanation of what I
have doe.
First, however, are some routines which I have not yet covered and which
can be used to make up screens for simple games.
In my first article I gave a simple routine (uline) for printing a line of
the same character. If we use the 'tab' subroutine also given in that
article we can print horizontal or vertical lines of the same character
anywhere on the screen. Add these two routines to those already entered -
.horiz JSRtab
INX
CPXlimit
BNEhoriz
RTS
.vert JSTtab
INY
CPYlimit
BNEvert
RTS
Add limit=&86 to the variables at line 40. Then to use the routines enter
in the main loop -
For a horizontal line -
LDA# <end col> :STAlimit
LDX# <start col>
LDY# <line>
LDA# <char>
JSR horiz ) or JMPhoriz
RTS )
For a vertical line -
LDA# <end line> :STAlimit
LDX# <column>
LDY# <start line>
LDA# char
JMP vert
Blocks of characters can be printed as in BASIC by entering the data -
EQUS CHR$224+CHR$225+CHR$8+CHR$8+CHR$10+CHR$226+CHR$227
and using the loop -
.comms2 STX addr
STY addr+1
TAX
LDY#0
.clp LDA (addr),Y
JSR oswrch
INY
DEX
BNE clp
RTS
While the loop (cooms) is a little more economical in memory and perhaps
better programming, this loop is easier to use as it avoids the necessity
to reverse all the data. It is used as before -
LDA# <number of commands>
LDX# <data> MOD256
LDY# <data> DIV256
JMP comms2
Windows can be made up using the data -
Text window -
EQUB28:EQUB <left>:EQUB (bottom>:EQUB <right>:EQUB <top>
Graphics window -
EQUB24:EQUW <left>:EQUW <bottom>:EQUW <riht>:EQUW <top>
Double height lettering can be printed with this routine -
.dh STX db: STY db+1
LDA#0:STA &70
.b1 LDY &70:LDA (db),Y
CMP #13:BEQ b3
STA &71:INY:STY &70
LDX #&71:LDY #0
LDA #10:JSR &fff1
LDX #1:LDY #0
.b2 LDA &71,X:STA &CF0,Y
INY:STA &CF0,Y
INY:INX
CPX #9:BNE b2
LDA #254:JSR oswrch
LDA #8:JSR oswrch:LDA #10:JSR oswrch
LDA #255:JSR oswrch
LDA #11:JSR oswrch
JMP b1
.b3 RTS
The variable db=&80 must be added to the variables in line 40. This
will hold the address of the STRING to be printed which must have the CR
character &0D at the end. The routine is used in the same way as the
print routine by -
LDX # <label> MOD256
LDY # <label> DIV256
JMP dh
Note - &70 holds the position in the string of the character being printed
and &71 holds the character. The character codes are then split to &72 to
&79. These are doubled loaded to &CF0 to &CFF for characters 254 and 255.
The routines given so far should enable you to make up screens for simple
games where a clash may be detected by comparing co-ordinates where these
are held at say &74 (x,y) and &76 (x1,y1) -
LDAx:CMPx1:BNE no_clash
LDAx+1:CMPx12+1:BNE no_clash
.clash
<clash routine>
.no_clash RTS
For arcade games of the Reptonm type a map is needed as in BASIC and this
should be entered to a suitabla address for the M/code. The data can be
saved separately with other similar files so they can be looded into the
game.
To load these we use the OS routine OSCLI (&FFF7). This is used for all
* commands. It needs the X and Y registers to be loaded with the address
of the command data as for other routines before being called -
LDX# comm MOD256
LDY# comm DIV256
JMP &FFF7
.comm EQUS "LOAD map <address>"
While it may not be necessary to add the address if it is saved to the
correct address, it can be put in.
I shall be explaining more about maps and other routines next time.
**************************************************************************
