Mark Bellis, 118, The Lawns, Rolleston-on-Dove, Burton-on-Trent,
Staffs, DE13 9DE.
Second submission to EUG, March 1998
*************************************************************************
Greetings!
I note with interest Ron Goad's request for a database for addresses and
phone numbers. This database system, which I began last December, can
handle international phone numbers, and 522 addreses on a Master 128!
Unfortunately it's not finished yet, but with me having had very little
time in the last two months, I thought I would submit what I'd done.
Even using shadow RAM for the screen on a Master 128 or BBC B+, you can
only usually use about 20K for strings by the time you have a program
to manipulate them.
This program uses main RAM, shadow RAM and all four banks of sideways
RAM, allowing almost 96K for strings. For demo purposes I have divided
the RAM into 522 strings of 188 characters in 6 banks of 87.
The idea is that each string is a database record, and, for sorting
purposes, the records could be sorted by a sequence of offsets within
the string record. My address, including phone number, takes 104 bytes,
so perhaps 188 bytes is enough for the longest address.
I don't know how long your Christmas card list is, but I think 522
addresses should be adequate for anyone's address book.
Two functions access the strings:
FNputs(A$,I%) puts the 188-character string A$ into the string indexed
by I%, a number from 0 to 521. To increase the integrity of the
system, the machine code routine saves A$ into pigeon hole I%, but also
reads it back, returning it as the result of the function. Therefore
to verify a correct string storage:
xyz IF FNputs(A$,I%) <> A$ THEN PROCerror("Bad string push")
would report a storage error.
FNgets(I%) returns the string in pigeon hole I%, and is called by:
xyz A$ = FNgets(I%)
Two other functions load and save the banks of strings as six files of
16K each. You may choose the filenames - I would suggest ABBANK0 to
ABBANK5 for an address book.
In order to use sideways RAM, I have not used *SRDATA 4,5,6, and 7, but
rather loaded a 16-byte header into each of the 4 banks, so that they
look "legal" to the MOS. The headers would still have been there if I
had used *SRDATA, as explained by paragaph 2 on page G7-2 of the Master
Reference Manual, so this removed any advantage of using *SRDATA.
Other reasons for not using *SRDATA are as follows:
I considered it easier and quicker to page in RAM banks by changing
?&FE30 (the ROM select register), rather than using *SRREAD and
*SRWRITE, which have to page in the DFS ROM. Those two commands would
also have used up more RAM with parameter blocks, and as it is, the
PUTS and GETS routines use only one page of RAM at &900. Page &A is
used as the string buffer.
Also, the memory conveniently divides into 6 equal banks, with the same
amount of memory (&3FF0 or 65472 bytes) used in each. This would have
required multiplication of &3FEF in assembler every time a sideways RAM
bank was accessed, in order to move to another abolutely-addressed bank.
No multiplication is required if the banks are paged in and out, even
though all bank accesses require the multiplication of 188 by (I% MOD
87) to calculate the address within the bank.
For convenience, the banks are loaded and saved as 16K blocks (using
&4000, rather than &3FEF as the length), because it is more convenient to
keep the ROM header attached to the data, rather than explicitly writing
it each time.
HIMEM is set to &3C00, but in theory only two strings, A$ and B$, will be
required by a database program, since that is all that is needed for
sorting purposes.
Even at 96K, you can still fit six sets of data on a large format ADFS
disk. I have decided not to save just the amount of data in memory,
because if the data expands, large gaps will be created on the disk when
the data is next saved.
Since the system uses absolute pigeon-holes, no string headers are stored,
as all the length and address information is inherent to the program.
The maximum length of a conventional string is 238 characters, according
to the entry for INPUT on page N5-3 of the Master Reference Manual, so
this will fit in page &A quite easily, if the data format were changed to
use 238-character strings (408 of them, 68 per bank).
The calculated absolute string address within the bank is stored at
&70-71, and these are the only zero-page locations used. I% MOD 87 is
stored at &A00-1, and the bank number (top bit set for PUTS, clear for
GETS) is stored in &A02.
$&A03 is the string buffer, terminated by CHR$13. With a 238
character string, this will leave 14 free bytes in page &A.
Summary of the files:
ABTEXT VIEW This file. Description of STRING program system.
?BLANK data Empty ROM header, with pun title to satisfy Gus' short
filename request ;-).
ABOOK1 BASIC IV Demo of string system.
Loads ?BLANK into each of the four SRAM banks.
Loads ?ABOOK into page &9.
Saves up to 5 banks of 16K - user-defined filenames.
?ABOOK 6502 M/C Put, Get and absolute string address calculation.
The sort routine will probably be in a page of machine code, and the
printing routine in BASIC - eventually!
Please feel free to suggest additional features etc...
