2M/8M RAM DISK BOARD WITH 24bBC BUS
By Robert Sprowson
THIS hardware project consists of a ready made printed circuit board
(available separately) which, when populated by the following list of
parts forms a 24bBC address decoding board.
Building such a board from scratch on strip board makes quite a large
final board so by using surface-mounted parts, the physical six of the
board can be reduced to 3" by 3.5". Anyone wishing to build one from
scratch can do so by consulting the 24bBC document.
A 24 bit address bus has 16 million unique addresses, half of which
have been set aside for a fast RAM disk with associated RAM filing sys-
tem (available separately). So about a third of this 3" by 3.5" board is
occupied by sockets for RAM chips for this purpose.
Operation of this design is covered in the 24bBC article elsewhere on
this disk.
Parts
THE schematic shows an outline of the following parts and their relative
positions on the board:
3 x 74ALS990 in SOIC package (U5,6,7)
4 x 74HC02 in SOIC package (U11,12,13,9)
1 x 74HC139 in SOIC package (U8)
1 x 74HC00 in SOIC package (U14)
1 x 74HC138 in SOIC package (U3)
1 x 4075BE in SOIC package (U15)
1 x 470uF capacitor, radial leads (C1)
1 x 1.3mm PCB mount power socket (SK4)
8 x 100nF capacitor in 0805 outline (Grey shaded areas)
1 x 34 pin IDC header (SK2)
1 x Fuse holder plus 200mA fuse (FS1)
2 x Turned pin 32 pin DIL chip sockets (SK9,10 - can be omitted)
1 x 34 pin IDC plug
2 feet of 34 way ribbon cable
If there are known to be no other boxes on the 1MHz bus then the card
must be terminated with:
4 x 9 pin SIL array 2.2k resistor packs
If there are other devices daisy chained through the board then you will
need a socket for the next device to plug into:
1 x 34 pin board mount non locking IDC socket (SK1)
If there might be devices daisy chained on the 1MHz bus some of the time
and sometimes not, the terminating resistors should be socketed too:
4 x 9 pin SIL array 2.2k resistor packs
1 x 34 pin board mount non locking IDC socket (SK1)
4 x Turned pin 9 way SIL socket (SK5,6,7,8)
The amount of RAM fitted is entirely optional, and automatically detect-
ed by the RAM filing system software:
1 or 2 x KM681000 (128k x 8bit SRAM) or equivalent in a 32 pin DIL
package
1 or 2 x KM684000 (512k x 8bit SRAM) or equivalent in a 32 pin DIL
package
Optional parts not required by the RAM disk (see below)
1 x 74HC138 (U4)
1 x 7805 voltage regulator in TO220 case (U10)
Benefits
* Tiny design is even smaller than a 3.5" floppy disk
* Very low power, drawing only 125mA
* Special 21 pin expansion header gives the designer the option to add
other peripherals to the 24bBC bus or even more RAM
* Potentially up to 1 Megabyte of storage on board (or 8 Megabytes
using the expansion header)
See the accompanying article (V.+HARDW2) for how to build it.
