MANUAL FOR 2ND SERIAL PORT (6502 ROM image)
By Robert Sprowson
This file describes the ROM image 2NDSERIAL, which drives the associated
second serial port card hardware which contains a 6850 serial chip so
the machine can have two ports in use simultaneously. The image requires
at least one 2k bank of Sideways RAM or to be put onto a ROM to work.
Instructions
At any command prompt, eg. the BASIC prompt ">", type
On a Master: *SRLOAD U.2NDSERI 8000 <socket#>
*INSERT <socket#>
where <socket#> may be 7, 6, 5 or 4
On a machine with SWRAM: *LOAD U.2NDSERI 8000
and press <CTRL><BREAK> to initialise.
On reset, the software will claim 3 pages of memory for its private use.
One page of this is for new buffer management software and the other two
are for serial input/output buffers, which means it cannot be in the
'hidden' workspace on a Master series machine.
You can control all the settings you would expect to be able to do
with the normal on-board serial port such as baud rates, data formats,
etc... Firstly, you must type *COM2 at the command line, so that changes
to settings you make refer to the new serial port, then simply issue any
*FX calls which you rewuire to set up the serial port (referring to the
BBC Micro User Guide).
To switch back to controlling the built-in serial port, issue a *COM1
command. So, for example, setting baud rates:
*COM1 <talk to the on-board serial port>
*FX 7,3 <sets receive speed of internal port to 300>
*FX 8,4 <sets transmit speed of internal port to 1200>
*COM2 <directs osbyte to the second serial port>
*FX 7,6 <sets receive speed of the 2nd port to 4800>
Technical Information
The following conditions prevail at power up:
OSBytes refer to: COM1, the internal port
Baud rate: 9600 transmit and receive
Parity: None
Stop bits: 1
Data bits: 8
The input buffer id is 9 and output buffer id is 10.
Events will be generated which may be of interest to the programmer
if an RS423 error occurs or a buffer becomes full or empty:
"RS423 error" .... the lost byte is passed in Y, the second serial
card's 6850 register is passed in X shifted right by
1 place
"Input buffer full" .... the unsuccessful byte is in Y and X=9
"Output buffer empty" .. enters with X=10
Known Problems/Future Enhancements:
No known problems.
Could implement the remaining three unimplemented OSBytes.
History:
v0.63 Modified test code to allow it to be run from ROM
v0.68 Added OSByte interface
See additional file (V.+2NDPO2) for Supported *FX Calls.
Manual and software (C) 2000 SPROW
First published EUG #56
