Support Group Application Note Number: 014
------------------------------------------
Copyright (C) Acorn Computers Limited 1992
Acorn Computers Limited
Acorn House
Vision Park
Histon
Cambridge CB4 4AE
Acorn Electron Cartridge Interface Specification
Applicable Hardware: Acorn Electron
This specification details the characteristics of the Cartridge interface
as fitted to the Acorn Electron and BBC Master 128 compute rs.
The specification details the physical and electrical characteristics and
software environment of the cartridges.
1.0 Terminology
CMOS - Complementary metal-oxide-silicon technology
CPU - The microprocessor in the host computer
TTL - Transistor/Transistor Logic
& - As a number prefix means a hexadecimal number follows
n - As a signal prefix means the signal is active low
2.0 Host Computer Connection
Cartridges plug into a 44 way gold plated edge connector arranged on each
side of a 0.05 inch slot as 22 ways of 0.05" x 0.5" on 0.1 " centres. The
connectors are parallel to the front of the computer with the front and
rear facing sides designated 'B' and 'A' res pectively. Pin 1 of each
side is on the far right.
This is shown in Diagram 1.
Cartridges are aligned and polarised by the case; they are plugged
vertically into the host. All cartridges constructed to the time of
writing have the components mounted on the pcb 'A' side.
2.1 Pinout
The pins are described as seen from the cartridges; ie an input to the
cartridge.
SIDE 'A'
1 +5V - Power supply
This is the system logic supply rail. No more than 150mA should be
drawn by a cartridge in a fully configured Master 128 computer, ie
with internal co-processor fitted. No more than 50mA should be
drawn by a cartridge fitted to the Electron.
2 nOE - Output Enable : Input with CMOS levels
This is an active low signal during the PH12 period of the system
clock. It is intended to switch on the output buffers of memory
devices in cartridges. It is not guaranteed to be high at other
times.
The front cartridge slot is allocated to system ROM positions 0 and
1. The rear slot is allocated to positions 2 and 3.
3 nRST - System Reset : Input with CMOS levels
This signal is active low during system reset. It is not
synchronised to any internal clock.
4 CSRW - Chip Select / Read/Write : Input with CMOS levels
On the Electron: This pin is the CPU read/write line.
On the Master 128: This pin changes function according to the
memory region that the CPU is addressing. During accesses to
devices in the region &FC00 to &FEFF it is equivalent to the CPU
read/write line during nPH12. For all other accesses it is an
active high chip select for memory devices. It is not guaranteed
to be low at other times.
This approach is necessary for compatibility with the Electron.
5 A8 - Address line 8 : Input with TTL levels
6 A13 - Address line 13 : Input with TTL levels
7 A12 - Address line 12 : Input with TTL levels
8 PH12 - CPU clock : Input with CMOS levels
This input is the host computer PH12out.
9 -5V - The negative supply voltage
No more than 20mA per cartridge should be drawn from this supply.
10 CSYNC/MADET
On the Electron: This is a "no connect" on the Electron.
On the Master 128: This pin has two functions dependant on the
position of a link in the host computer:-
E/nB: this is the default function. It allows hardware in
cartridges to "know" which into which type of computer it is
plugged. It is a direct connection to+0V in the Master 128
and a floating node in the Electron.
CSYNC - Composite Synchronisation: Input with TTL levels
The system composite vertical and horizontal
synchronisation is made available. It is intended to be
used in genlock applications.
