File contents

The result:
2000 PHP
2001 PHA
2002 TXA
2003 PHA
2004 LDX #&00
2006 LDA &2016,X
2009 JSR &FFEE
200C INX
200D CMP #&00
200F BNE &F5
2011 PLA
2012 TAX
2013 PLA
2014 PLP
2015 RTS
2016 EQUS "Hello"
201B EQUW &0D0A
201D EQUB &00 "."

Note that the disassembler does not assign labels or variable names.

The "." after an EQUB is the ASCII code as printed by *DUMP ("." if
<32 or >126), and is provided for password programs when one character
at a time is tested.  The character is also printed following an
opcode using the Immediate addressing mode (i.e. data byte after the
instruction), so that "LDA #&48" and "CMP #&65" demonstrate that the
program under scrutiny loads "H" into the accumulator and compares
the accumulator with "e" respectively.

Of course, using the disassembler requires some knowledge of 6502
machine code, in order that you can discern whether the current byte
is an opcode or a piece of data, and so that you can achieve speed in
disassembly by looking at the program and being able to type OOOOOOOOOO,
knowing that ten opcode instructions are on the screen.

Considering that it used to take me about an hour to disassemble a
256-byte *DUMP listing, the time saving is enormous, and I can now do
about four 256-byte pages in ten minutes.  Theoretically, a whole 16K
ROM could be done in about an hour and a half, though it is better to
split it into sections - it is best to end a section after an RTS or
JMP instruction.

The output file can also grow very fast, at the rate of about 10 bytes
per byte of machine code - decoding a ROM would take 160K of output
files.  I still intend to disassemble the MOS though, so that I can
unravel its mysteries.  I have decoded the part of the MOS which deals
with OSWORDs 14 and 15 - the real-time clock code, and found the
hardwired 1900-century code at &9881 in the Terminal ROM.

The disassembler has enabled hacking to go into warp drive!  Try it and
see for yourself!

Please feel free to request additional features, if they would be useful.
