File contents
Data File Control
These routines give the utility access to the database data file, using the
current select file if required. It is only possible to read sequentially
through the data file using these calls, but the data will be returned in
sorted order if the selected data was sorted.
The utility should not close the intermediate file if it uses it. This is
done automatically when control is returned to the ROM.
INIIMF Initialise data sequence. Called to start the data
reading sequence.
MXTIMF Get next from data sequence. Each call returns the
next data record in the sequence.
INIIMF
This routine is called to initiate a sequence of data transfers. It opens
the main data file, and stores its handle in the location EFILE. According
to the state of the carry flag on entry, it asks the user if he wishes to
use a select file. The user responds with a yes or no, and ViewStore opens
the select file (S.database) accordingly. After this, the select file is
transparent to the utility; repeated calls to NXTIMF will either return all
the records in the data file if the select file is not being used, or the
subset of records in the select file, if specified.
On entry: CC Don't ask "Use select file (Y,N)?" question.
CS Ask select file question.
On exit: VC No error.
VS Error; error code in A.
NXTIME
After starting the sequence with a call to INIIMF, repeated calls to MXTIMF
return the records in the data file one by one.
On entry: A low byte of address to store record.
Y high byte of address to store
record.
TEMP13 address of the byte after the last
byte available to store the record.
On exit: VC No error.
VS Error; error code in A.
CC Not end of file.
CS End of file (returned on the call
after the last record has been
processed).
Errors
Many of the ROM routines can return an error status. An error is usually
indicated by either the Carry flag (C), or the Overflow flag (V). When an
error is indicated, the error code is in the A register. To report the
error to the user, call the routine REPERL with this code A. The various
error codes and messages are summarised later. A utility can use a ROM
error message by loading the appropriate code into A, and calling REPERL.
All file calls have the same error trapping system: after a call, V is set
to indicate an error, clear if there was no error. This includes errors
causing a BRK, that is control is returned to the calling routine even when
a BRK is occurred. When you call REPERL with the returned error code, the
BRK message will be reported as normal.
REPERL
Reports the error message for the error code in A:
On entry: A contains error code.
On exit: A,X,Y undefined.
Field and Record Control
Much of ViewStore's manipulation is on fields and records; accordingly,
there are several routines available to make this easier. There are some
routines to locate fields in the header, format file or current record;
routines to compare field values; and routines to find the size of a given
field.
Most of these routines use the two temporaries TEMP06 and TEMP07. TEMP06
points to either a field within the format file, or a field within the
current record. TEMP07 points to a field within the current record. The Y
indirect indexed addressing mode is used in conjunction with these
temporaries to access the field contents: the temporary points to the
beginning of the field, and the Y register gives the offset from there.
Remember that the format file itself is in the same format as a data file.
The same routines are used to process information in records of the database
as in the format file itself. For each field in the database, there is a
record in the format file, and this record details the characteristics of
its corresponding field in the database. The header record is the first
record in the format file.
Data Format
The data format is summarised in table 10 at the end of the document. All
fields in ViewStore are stored in ASCII, even numbers and dates; each field
ends with an end of field marker; each record ends with an end of record
marker; and the file ends with an end of file marker; after the end of file
marker, the file is padded up to the physical end of file with null
characters. If you are processing a field's contents, you should test for
the end of field using the CHKEOF and CHKEOR routines. These routines set
the flags according to the character that they find. Don't check for the
character value explicitly.
Generally, when you make a call to a routine that locates a field, the x
register indicates where the field is to be found:
X=0 Field in header; A has field number.
X=1 to 254 Field in format file; X gives format file record
number; A has field number. The field numbers of
the various format file fields are summarised below.
X=225 Field in current record; A has field number; Y has
record number.
Fields within a record are numbered from 1 to 254. If you ask for a field
which is not in the record, the routine will return with the Carry flag set.
Whereas ViewStore knows where the format file is located, the address of the
current record could be anywhere, and before fields within the current
record can be accessed, you must tell ViewStore its address with the SETDPS
routine.
