                        Autostereogram Generator

       An autostereogram is a repeating pattern of dots which reveals a
convincing 3-dimensional illusion if viewed correctly. They have become
popularly known as "Magic Eye" pictures after the recent series of books,
and can also be found on posters in art shops. They are generated using
computer programs, so I set about writing a program to produce them on the
Electron.
       I found a simple routine to do this, in the New Scientist magazine
last year, written in the "C" programming language, and understood enough
of it to write a version in BASIC. Unfortunately, this took over 4 hours
to run, and was only capable of producing images of very simple shapes, so
it soon became evident that a machine code version was needed. I have now
written a version which can produce virtually any image, and  never takes
more than 45 minutes to run (it will often run in under 10). I admit this
is still slow - the program is held up by needing to use BASIC's  RND
function to generate random numbers.
       To produce an autostereogram, you will need a picture, to supply
the 3-D image that you will see. This can be a screen file in any graphics
mode (0,1,2,4,5), but must have a very clear outline, particularly on the
first one you try. The colours of the picture are used to tell the program
how far in front of the page each part of the image will appear - so don't
use them to make the picture look pretty or realistic. There is no concept
of colour in the illusions themselves.
       If the picture is fairly simple, you can draw it just using BASIC's
grapics commands, and PLOT 85 to fill areas with colour, then save it
using "*SAVE <filename> 3000 8000" for a MODE 0,1 or 2 screen, or "*SAVE
<filename> 5800 8000" for a MODE 4 or 5 screen. However, it is probably
easier to use an art program such as Elkpaint (Electon User, October
1989). You will find a copy of this on the disc, with a couple of minor
improvements made to the load/save routine. The keys are as follows:
       Z,X,*,? : Move cursor        S : Store screen in memory
           0-3 : Choose colour      U : Swap to stored screen
   SHIFT + 1-6 : Choose speed       T : Text
             B : Rubberband       Q+W : Clear screen
             C : Circle             K : Save screen
             E : Ellipse            L : Load screen
             R : Rectangle          M : Magnify (cursors scroll view)
    A then 1-5 : Brush mode         F : Fill
             P : Cut + paste ( use space bar to fix area to cut, drag box
                                to new position, press Return, then:
                               Space for a normal copy
                               H for a horizontal flip
                               V for a vertical flip
                               R to rotate (Z and X rotate about bottom
                                left corner, then space to fix)
         Space : Confirm/fix/draw in brush and magnify modes
        Return : Exit brush/magnify modes

       When you have a picture ready, run the autostereogram generator.
You will first need to enter the filename of the source picture, and its
mode (this will be 5 if you used Elkpaint). Next, enter the filename you
wish to save the autostereogram under, and its mode (0 or 4). The dot
resolution in mode 0 is twice that in mode 4, but in my opinion, the
images are easier to see in mode 4. They are also much quicker to produce
in mode 4.
      Next you must enter the "eye separation". This will be the distance
between the repeating patterns on the page, and hence relates to the
amount you have to cross your eyes to see the illusion (if you use my
small screen dump, this will be in millimetres). I find it easiest to see
the images if I use an eye separation of about 20, though this is much
less than in most commercial autostereograms.
      Next, you will be asked to enter an "elevation number" for each
logical colour used in the source picture. This is a measure of how far in
front of the page each part of the image will appear. The higher the
number, the more the illusion stands out, so you should enter 0 for the
background colour. I use a value of 4 for most images, though you can vary
this from about 2 to 10 to get a good 3-D effect. It is important that you
remember which logical colours you used for which parts of the picture. If
you use mode 0, you should double the values mentioned above (which refer
to mode 4). Similarly, if you alter the eye separation, you should change
the elevation numbers in approximately the same ratio.
       Finally, you will be asked if you want a printed copy. I have
written my own single-shade screen dump for this purpose. This must be
saved in the same directory as the autostereogram generator, under the
filename "ScrDump" (sorry about the total lack of meaningful labels and
variable names in this program!). You may prefer to use the dump from
"Diagram", which I have also improved. This is twice as fast as mine, and
the same shape, but is 50% wider, filling the full width of the carriage.
This machine code program is saved as  "UCODE". There is an option to
select between these two dumps (small and large respectively).
       Now just sit back and wait for the result. This could take up to 45
minutes if you are using mode 0, so be patient if the computer appears to
be doing nothing for a long period.
       All these parameters will sound rather complicated if you have
never actually seen an autostereogram before, but don't worry - just use
my suggested values to get you started. Then you can try varying them
later, one at a time, to see the effects.
       You may be able to see the effect on your TV/monitor screen if it
is not too flickery, though it is generally easier on paper. My preferred
method is to stare blankly at the page, and slowly refocus my eyes until
two columns of the repeating pattern appear to merge into one. Then, if
you can hold your focus long enough on the merged pattern, the image
should lift out.
       Other people prefer the following method: Hold the paper against
your face, and stare through it blankly. Slowly move the paper away from
your face without altering your focus, until the image appears, then wait
until it becomes clear. You will have to concentrate very hard to prevent
yourself from refocusing on the image as it appears.
       Another method is to place a reflective surface over  the page, and
focus on your reflection (a TV/monitor screen might also work). I have
never found this method useful myself.
       You will probably find that you have to stare at them for a long
time before you see the effect for the first time (it took me several
hours), but it is well worth the wait. If you still can't see them, don't
worry - apparently an estimated 10% of the population can never see them.
       The autostereograms produced by this program are not as effective
as the commercial ones (though they may be easier to see). This is partly
because they are black and white, and the patterns are not attractive in
themselves, as they are generated randomly. However, another serious
limitation is that the images you see are always parallel to the paper -
they can never slope towards or away from you. I have tried to make
sloping surfaces using a "staircase" effect - several narrow bands of mode
2 colours, with consecutive elevation numbers. However, the resolution of
mode 0 graphics was not really enough to make this successful.
       You may wish to produce an autostereogram of a word, or short
phrase. If so, I have sent in a  program to print large text on the
screen. This is based on the Banner Printing program from Electron User
(June 1989), and is described elsewhere on the disc.
       If you produce an impressive image, send it in! Perhaps this could
be the basis of a future competition, (i.e "What object is shown in this
autostereogram?", with the source picture included on the following disc)
       I have included an example of an autostereogram on the disc. The
source picture is also there, but you may prefer not to see this until you
have had a go at seeing the image. Good luck!
                                                   Matthew Ford.
