Filename: GeogDT3
Read OK:
File size: 07A1 bytes
Load address: FFFF1A00
Exec address: FFFF8023
Duplicates

There are 2 duplicate copies of this file in the archive:

File contents
   10REM >GEOGDT3
   20REM PLOTTER PROGRAM FOR DXY-1200
   30REM 1 PLOT FOR EACH QUESTION
   40REM by R.T.POET MAY 1990 Version 1
   50REM (c) The Micro User
   60Q$="WHAT IS THE DATAFILE NAME"
   70PRINT Q$;:INPUT "",datafile$
   80fileref= OPENIN datafile$
   90INPUT#  fileref, number
  100INPUT#  fileref, areas
  110barsize = 9000/areas
  120DIM question$(number)
  130DIM ans(number,areas)
  140FOR question = 1 TO number
  150INPUT# fileref,question$(question)
  160FOR area = 1 TO areas
  170INPUT# fileref,ans(question,area)
  180NEXT area
  190NEXT question
  200CLOSE# fileref
  210D$="Data from datafile "
  220PRINT D$;datafile$
  230FOR question = 1 TO number
  240REM Check paper / pen / speed:-
  250REPEAT
  260INPUT "Paper ready? (Y)",B$
  270UNTIL ((B$="Y") OR (B$="y"))
  280REPEAT
  290INPUT"WHICH PEN? (1 to 8) ", pen
  300UNTIL ((pen<9) AND (pen>0))
  310REPEAT
  320INPUT "SPEED? (1to 42) ",speed
  330UNTIL((speed<43)AND(speed>0))
  340VDU 2:REM TURN ON OUTPUT
  350PRINT"IN;SP";pen;";VS";speed;";"
  360REM SET TEXT TERMINATOR (DEFAULT)
  370PRINT "DT":VDU1,3
  380REM ADJUST FOR A4 PAPER
  390PRINT "IP1000,0,6000,5000;"
  400REM PLOT VALUE RANGE 10000:-
  410PRINT "SC0,10000,0,10000;"
  420PRINT "PU;PA2000,9500;"
  430PRINT "SR3,3;"
  440Q$=question$(question)
  450PRINT "DI1,0;LB";Q$:VDU1,3
  460PRINT "DI1,0;"
  470PRINT "SR1,1;"
  480PRINT "PU;PA250,3500"
  490PRINT "SR1.5,1.5;"
  500L1$="ENVIRONMENTAL QUALITY"
  510PRINT "DI0,1;LB";L1$:VDU1,3
  520PRINT "PU;PA750,3500"
  530L2$=" CLASSIFICATION SCORE"
  540PRINT "DI0,1;LB";L2$:VDU1,3
  550PRINT "SR1,1;"
  560PRINT "DI1,0;"
  570PRINT "PU;PA0,2900"
  580PRINT "SR2,2;"
  590PRINT "LB0%":VDU1,3
  600PRINT "SR1,1;"
  610PRINT "PU;PA0,8900"
  620PRINT "SR2,2;"
  630PRINT "LB100":VDU1,3
  640PRINT "SR1,1;"
  650PRINT "PA;"
  660PRINT "PU1000,9000;"
  670PRINT "PD1000,3000;"
  680X=1000+barsize*areas
  690PRINT "PD";STR$(X)",3000;"
  700FOR area = 1 TO areas
  710X=1000+barsize*(area-1)
  720Y=3000+(60*ans(question,area))
  730PRINT "PU";STR$(X);",3000;"
  740PRINT "PD";STR$(X);",";STR$(Y);";"
  750X=1000+barsize*(area)
  760PRINT "PD";STR$(X);",";STR$(Y);";"
  770PRINT "PD";STR$(X);",3000;"
  780X0=1000 +barsize/2
  790X=X0++barsize*(area-1)
  800PRINT "PU";STR$(X);",500;"
  810PRINT "SR2,2;"
  820PRINT "DI0,1;LB AREA ";
  830PRINTSTR$(area):VDU1,3
  840PRINT "SR1,1;"
  850PRINT "DI1,0;"
  860NEXT area
  870PRINT "SP0;":VDU 3
  880NEXT question
  890VDU 3
  900END

� >GEOGDT3
"� PLOTTER PROGRAM FOR DXY-1200
� 1 PLOT FOR EACH QUESTION
($� by R.T.POET MAY 1990 Version 1
2� (c) The Micro User
<"Q$="WHAT IS THE DATAFILE NAME"
F� Q$;:� "",datafile$
Pfileref= � datafile$
Z�#  fileref, number
d�#  fileref, areas
nbarsize = 9000/areas
x� question$(number)
�� ans(number,areas)
�� question = 1 � number
�"�# fileref,question$(question)
�� area = 1 � areas
�!�# fileref,ans(question,area)
�
� area
�� question
��# fileref
�D$="Data from datafile "
�� D$;datafile$
�� question = 1 � number
�!� Check paper / pen / speed:-
��
� "Paper ready? (Y)",B$
� ((B$="Y") � (B$="y"))
�
" �"WHICH PEN? (1 to 8) ", pen
,� ((pen<9) � (pen>0))
6�
@� "SPEED? (1to 42) ",speed
J�((speed<43)�(speed>0))
T� 2:� TURN ON OUTPUT
^ �"IN;SP";pen;";VS";speed;";"
h#� SET TEXT TERMINATOR (DEFAULT)
r� "DT":�1,3
|� ADJUST FOR A4 PAPER
�� "IP1000,0,6000,5000;"
�� PLOT VALUE RANGE 10000:-
�� "SC0,10000,0,10000;"
�� "PU;PA2000,9500;"
�� "SR3,3;"
�Q$=question$(question)
�� "DI1,0;LB";Q$:�1,3
�� "DI1,0;"
�� "SR1,1;"
�� "PU;PA250,3500"
�� "SR1.5,1.5;"
�L1$="ENVIRONMENTAL QUALITY"
�� "DI0,1;LB";L1$:�1,3
� "PU;PA750,3500"
L2$=" CLASSIFICATION SCORE"
� "DI0,1;LB";L2$:�1,3
&� "SR1,1;"
0� "DI1,0;"
:� "PU;PA0,2900"
D� "SR2,2;"
N� "LB0%":�1,3
X� "SR1,1;"
b� "PU;PA0,8900"
l� "SR2,2;"
v� "LB100":�1,3
�� "SR1,1;"
�� "PA;"
�� "PU1000,9000;"
�� "PD1000,3000;"
�X=1000+barsize*areas
�� "PD";�(X)",3000;"
�� area = 1 � areas
�X=1000+barsize*(area-1)
�"Y=3000+(60*ans(question,area))
�� "PU";�(X);",3000;"
�� "PD";�(X);",";�(Y);";"
�X=1000+barsize*(area)
�� "PD";�(X);",";�(Y);";"
� "PD";�(X);",3000;"
X0=1000 +barsize/2
X=X0++barsize*(area-1)
 � "PU";�(X);",500;"
*� "SR2,2;"
4� "DI0,1;LB AREA ";
>��(area):�1,3
H� "SR1,1;"
R� "DI1,0;"
\
� area
f� "SP0;":� 3
p� question
z� 3
��
�
