* Mark Bellis, 118, The Lawns, Rolleston-on-Dove, Burton-on Trent, *
* Staffs, DE13 9DE. *
* 6502 / 65C12 disassembler for EUG, March 1998 *
*************************************************************************
With experience, 6502 code is simple to disassemble, resorting only
occasionally to the reference manual for the table of opcodes.
However, disassembling a *DUMP listing is time consuming, especially when
you want to decode a whole 16K ROM full.
In answer to this problem, I have written a disassembler in BASIC, with an
attempt to make it compatible with Elks by using Mode 6. (I'm not sure if
it uses any BASIC IV statements which earlier ones don't understand)
The program will disassemble a machine code file on disk, for which you
can specify a pathname of up to 39 characters.
You will require a filename for the output, again up to 39 characters.
The program asks for the input file's load address, for two reasons:
1. Some games relocate themselves once loaded, as they use filing system
RAM (&E00 to &1900 or more in a BBC B). You may specify the
start address as the relocation address, so that the JSRs match up.
2. If you are hacking a ROM, it is likely that you will have copied it
to &3000 before *SAVEing it, as the filing system would get in the
way otherwise, and this facility allows you to enter the original
address.
The program then asks for the address to begin disassembly. To start
&1000 bytes into the file, simply make the start address &1000 bigger than
the load address. For the address inputs, the program weeds out non-hex
characters. I don't know if Elks can use the INSTR instruction which does
this though.
The program lastly asks for a P, E or W, to indicate whether you are
outputting to the Printer, EXEC file or Wordprocessor.Specifying W causes
the program to leave out the line feedswhen it sends lines to the file,
so that you can directly load the resultant file into a Wordprocessor,
in order to add your own comments to the code.
Specifying P leaves the line feeds in. To print the file, type:
CTRL-B
*PRINT <filename>
<RETURN>
CTRL-C
Specifying E activates the following features:
o Top and tail code is added to the EXEC file to enable the resultant
program to be run, provided the assembly address is suitable.
The possible addition of a relocation feature would enable this
address to be changed to be in user RAM, for reassembly.
The lines added are:
10 FOR pass% = 0 TO 3 STEP 3 2-pass assembly is assumed, with listing
on for error checking
20 P%= &<address> <address> is the disassembly start address
30 [OPT pass%
xx ] at the end of the file
yy NEXT pass%
o The treatment of branch instructions changes:
Instead of printing just the offset from the current address, the
destination address is output as P%-254+&xx for backward branches,
and P%+2+&xx for forward branches.
The result of this is that the branch instructions will reassemble.
Therefore relocatable code (with no JMPs or absolute data) will be
able to be recreated exactly.
If the relocation feature were added, it would still not be able to
recalculate indirect addresses for pointers, which are often initialised
by LDA#&xx : STAptr : LDA#&yy : STAptr+1, to point to &yyxx.
You will also have to recreate your own variable names.
The program now begins disassembly.
Four lines at a time of *DUMP listing are displayed, the current byte
being the top left one. The ASCII characters keep up with the hex bytes,
to help you to find strings in the file.
The memory location is in the left column. Location addresses are sent
to the output file for each instruction decoded.
You are prompted to choose what to do with the current byte:
N.B. do not press return after the O,B,W,D,S or E.
O - Opcode The program will disassemble one instruction, according
to its data file (OpcData).
The Rockwell 65C02 BBR and BBS are not yet supported. I
might add them on request.
The program finds out from the data filewhich
addressing mode the instruction uses, and decodes any
extra bytes accordingly.
The display is then updated by the number of bytes of
the instruction, and the decoded instruction is
displayed.
B - Byte The program decodes one byte as data, and prints
EQUB &<byte>.
W - Word Decoded as EQUW &<2 bytes, highest first>. Therefore
an address look-up table will allow addresses to be
read normally in the printout.
D - Double Word Decoded as EQUD &<4 bytes in reverse order>. As above.
S - String The program prompts for the length of the string.
look for the next return character, 00 byte or 0A
byte, and type in the number of characters, including
spaces, in the string, pressing RETURN.
See example below.
The display updates by the length of the string, and
EQUS "<string>" is sent to the file and displayed.
E - End End the program. The program closes the files and
terminates.
Demo Program, DADEMO:
Typing "*DADEMO" from the BASIC prompt will cause "Hello" to be printed.
Name of program to disassemble: DADEMO
Name of output file: DEMODA
Load address: &2000
Start address: &2000
Printer or WP: P
2000 08 48 8A 48 A2 00 BD 16 .H.H....
2008 20 20 EE FF E8 C9 00 D0 ......
2010 F5 68 AA 68 28 60 48 65 .h.h(`He
2018 6C 6C 6F 0A 0D 00 ** ** llo...
Key sequence for the above program:
OOOOOOOOOOOOOOOS5<RETURN>WB
(no E on the end, as the program terminates automatically when it sees
the end of the input file)
