> PrData *** LaserJet printer configuration ***

Header   must appear first, with items in correct order
======

version:               2  ;  Don't change this. It is used to detect
                          ;  incompatible old "PrData" files.

total_printers:        4  ; printers in file including default
total_text_printers:   1  ; distinct text definitions including default

Default printer definition
==========================

Default graphics resolutions
----------------------------
pxres:          150             ; dots per inch
pyres:          150
pxres_halftone: 150/8
pyres_halftone: 150/8

Graphics job control
--------------------
features:       16_00000000     ; doesn`t support arbitrary transformation

manual_feed:    <27>&l2H        ; escape sequence limited to 20 chars
auto_feed:      <27>&l1H

Printable character translations
--------------------------------
; text_char163:      "<163>"    ; any printable character can be
                                ; translated to a different one
Text font selection
-------------------
text_pica:           ""         ; these defaults do nothing - do not change them
text_elite:          ""         ; to use different font sizes, or line-wrapping
text_condensed:      ""         ; will go wrong - you could change to use different
text_expanded:       ""         ; typefaces if additional ones are available at both
                                ; 12 point and 8.5 point, e.g "<27>(s5T" for Tms Rmn

General text highlights
-----------------------
text_bold_on:        "<27>(s+3B"
text_bold_off:       "<27>(s0B"
text_italic_on:      "<27>(s1S"
text_italic_off:     "<27>(s0S"
text_light_on:       "<27>(s-3B"
text_light_off:      "<27>(s0B"
text_superscript_on: "<27>&a-0.3R"
text_superscript_off:"<27>&a+0.3R"
text_subscript_on:   "<27>&a+0.3R"
text_subscript_off:  "<27>&a-0.3R"
text_underline_on:   "<27>&d0D"
text_underline_off:  "<27>&d@"

Real printer definitions
========================

After 'printer_name:' and 'printer_number:', either 'text_alias:'
is used to indicate that all text entries are the same as a
previously defined printer or default (-1); or 'text_noalias:'
is used (without a value) to indicate that the printer has its
own text definition, in which case any subsequent "text..." values
override the default ones.  If you change/add printers, alter the
'total...' values at start of the file too.
.............................................................
; 300 by 300 dpi output
printer_name:    HP LaserJet (High)
printer_number:  0
text_alias:      -1 ; => text same as default

pxres:          300                     ; dots per inch
pyres:          300
pxres_halftone: 300/8
pyres_halftone: 300/8

.............................................................
; 150 by 150 dpi output
printer_name:    HP LaserJet (Medium)
printer_number:  1
text_alias:      -1 ; => text same as default

pxres:          150                     ; dots per inch
pyres:          150
pxres_halftone: 150/8
pyres_halftone: 150/8

.............................................................
; 75 by 75 dpi output
printer_name:    HP LaserJet (Low)
printer_number:  2
text_alias:      -1 ; => text same as default

pxres:          75                     ; dots per inch
pyres:          75
pxres_halftone: 75/4
pyres_halftone: 75/4

.............................................................
; 100 by 100 dpi output
;printer_name:    HP LaserJet (Low)
;printer_number:  3
;text_alias:      -1 ; => text same as default
;
;pxres:          100                     ; dots per inch
;pyres:          100
;pxres_halftone: 100/6
;pyres_halftone: 100/6

.............................................................


Page size settings
==================

These are written back to this file when the "Save" entry is clicked;
therefore they are all fixed size fields.

page_number:    0 ; the number of the page size table entry we want to do
                  ; don't need to write this back!
page_name:      A4 paper;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;; pad names to 80 characters with ;
page_width:     0000595350; Pad (decimal) numbers to 10 chars with leading 0s
page_height:    0000841995
page_bottom:    0000013891
page_top:       0000806558
page_left:      0000014175
page_right:     0000575505
text_top:       0000000000
text_bottom:    0000000000
text_left:      0000000000
text_right:     0000000000
page_selection: <27>&l26A   ; escape sequence to select A4 paper in the printer

page_number:    1
page_name:      Letter;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;
page_width:     0000612076
page_height:    0000792099
page_bottom:    0000014458
page_top:       0000777641
page_left:      0000011906
page_right:     0000587979
text_top:       0000000000
text_bottom:    0000000000
text_left:      0000000000
text_right:     0000000000
page_selection: <27>&l2A

page_number:    2
page_name:      Legal;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;
page_width:     0000612076
page_height:    0001008126
page_bottom:    0000014458
page_top:       0000993668
page_left:      0000011906
page_right:     0000587979
text_top:       0000000000
text_bottom:    0000000000
text_left:      0000000000
text_right:     0000000000
page_selection: <27>&l3A

page_number:    3
page_name:      User;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;
page_width:     0000595350
page_height:    0000841995
page_bottom:    0000013891
page_top:       0000806558
page_left:      0000014175
page_right:     0000575505
text_top:       0000000000
text_bottom:    0000000000
text_left:      0000000000
text_right:     0000000000
page_selection: <27>&l26A   ; Note that this selects A4 paper - the user may have to change this by hand

Configured options    (also written back to file on "Save")
==================
start_page_number: 00  ;page description - pad to two chars with 0
printer:       01 ;printer number - pad to two chars with 0
location:       1 ;1 - parallel, 2 - serial, 4 - net
baud:          03 ; 0 -   75,  1 -  150,  2 -  300  ,  3 -  1200
                  ; 4 - 2400,  5 - 4800,  6 - 9600  ,  7 - 19200
                  ; 8 -   50,  9 -  110, 10 -  134.5, 11 -   600
                  ;12 - 1800, 13 - 3600, 14 - 7200
data:         &24 ;serial data format - pad to two chars with 0
                  ;b0-b1 0,1,2,3 => 8,7,6,5 bits
                  ;b2 0=>1 stop bit, 1=>2 stop bits OR 1.5 stop bits if 5 bits
                  ;without parity, OR 1 stop bit if 8 bits with parity
                  ;b3 0/1 => parity off/on
                  ;b4-b5 0,1,2,3 => parity odd, even, 1 on Tx, 0 on Tx
xon:            0 ;XON/XOFF 0 off 1 on
server:   0.235;;; either [<net>.]<station>   eg `235;;;;;` or `123.235;`
                  ;or up to 6 char name       eg `blue;;;;` or `yellow;;`
                  ;must be padded to 8 chars with ; in either case
file: null:;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;filename to use, padded to 80 characters.
nfserver: ;;;;;;;;;;;;;;;;NFS printer server, padded to 16 characters
nfprinter: lp;;;;;;;;;;;;;;NFS printer name, padded to 16 characters
nfuser: nobody;;;;;;;;;;NFS username, padded to 16 characters
nfoption: ;;;;;;;;NFS printer options, padded to 8 characters

mono:           0 ;0/1 1 => use monochrome output buffer. Sprites/fonts will
                  ; not be greyscaled.
title:          0 ;0/1 1 => title text pages
number:         0 ;0/1 1 => number text lines
wrap_bar:       1 ;0/1 1 => indicate wrapped lines with a bar character
map:            1 ;0/1 0 => text input newline is lf, 1=> cr, lf, cr/lf or lf/cr
line:           1 ;0/1 0 => text printer newline is cr, 1=>lf+cr
feed:           0 ;0/1 1 => text manual paper tray
format:         0 ;0/1 0 => portrait, 1=>landscape
controls:       0 ;0-2 0 => text standard, 1=>display, 2=>ignore
