         [ 2M/8M RAM DISK BOARD WITH 24bBC BUS - CONTINUATION ]

Build...
BECAUSE of the orientation of the surface mounted components they must
be assembled in a particular order so that there is plenty of room for
the soldering iron tip when placing neighbouring devices.
1. Fit U14,U9,U8,U13,U7,U12,U6,U11,U5,U3 (and U4 if required)
2. Fit the surface mount decoupling capacitors, some of which are on
   the reverse of the board
3. Fit U15 which is on the reverse of the board
4. Fit SK5,SK6,SK7,SK8 if required, or the 2.2k resistor arrays if the
   terminators are not to be socketed
5. Depending on which RAM configuration is being used, there are some
   option links to alter. By default the tracks are laid out for the
   512k devices, so LK1,LK2,LK3 are all made in the '4' position (this
   is marked on the PCB next to the links). For 128k devices, break
   these links with a knife and put a link made from an off cut of the
   capacitor's leads into the '1' position
6. Now fit SK9,SK10 if required
7. Fit C1,FS1,SK4 to complete the placement
8. If you are not running the board from a 5v supply there needs to be
   a regulator fitted in the place of U10. To enable the regulator you
   must first cut the 'U' shaped track on the rear of the board going
   between pins 1 and 3 of U10 which bypasses U10 when it is not
   required (the default)

Hints
*   Soldering surface mount components is easy - it requires a steady
    hand and a good soldering iron tip. Don't try to solder with one
    shaped like a marker pen or a chisel, you need a pointed one shaped
    like a very slim cone. Smear a little flux or solder paste onto the
    pads where the device is to go and sit the chip in place so that
    you're happy it lines up with the pads. Hold the chip still by
    pressing on the top with a flat head screwdriver, and dab a little
    solder on the diagonally opposite corner pins (eg. pin 1 & 14). This
    anchors the device.
       Make any minor adjustments by melting one of those two pins and
    nudging the chip into line, then when happy put solder on the re-
    maining pins. Now clean the excess flux off and inspect the joints.
*   To crimp the 34 pin IDC header without crushing the pins put the
    ribbon cable through the plug and satisfy yourself it is lined up
    straight. Put the assembly into a vice, and put a few matchsticks
    between the pins. Then, when closing the vice, the pressure is
    applied to the matchstick which transfers it to the plastic casing
    without bending any pins.
*   If only one of the possible two RAMs is installed, put it in the
    socket marked RAM0 first (not RAM1). Do not mix 128k & 512k devices.
*   If you need to cut links LK1 and LK2 are on the back of the board
    whereas LK3 is on the top side.

As always, happy soldering!
                                                Robert Sprowson, EUG #56
