These are the notes which I have on adding a hard disc. I have the circuit diagram for the host adaptor. I will try to put it into a future EUG. The following notes were written some time ago and so prices and any sources named will be out of date. Winchester disk systems - background Unlike a floppy disk a Winchester disk drive is much faster (it spins at 3600rpm instead of 360rpm) and can store from ten to hundreds/thousands of times more data. In addition to being faster is also has more heads (from 2 to 16 heads), the data transfer rate from the disk to the controller is 5Mb/s. As a trade off a Winchester disk is permanently sealed in it's housing and cannot be removed, extra controller circuitry is also needed to interface it. Most Winchester drives are the same physical size as a 5.25" full height or half height floppy drive and come in numerous storage capacities ranging from 5Mb to around 140Mb (10Mb is most common and usually affordable). The drive will have three connectors, power, data and control. The SASI (Shugart Associates Standard Interface) ST406/506 applies to the data and control connectors, basically the control connector is a 34 way edge connector carrying similar control functions to those found on a standard floppy disk, and the data connector is a 20 way edge connector that carries the data to/from the head(s). The Winchester disk cannot be connected to a micro computer directly, instead an intelligent (microprocessor based) controller has to used. The Winchester controller is a vital part of the system, it is operated under software control of the host and performs all the read/write/seek/format operations on the Winchester - the host has only to send high level "commands" to the controller to be able to use the winchester. About controllers and all that... To the host, the Winchester just looks like a large number of sectors (or blocks), the host is not concerned with the track/cylinder/head/sector number, it simply uses a Disk Address (DA) which uniquely refers to each sector (the Disk Address ranges from zero to the maximum which is number of cylinders * number of heads * number of sectors per track - 1). The Disk Address is represented by a 24 bit number (3 hex bytes), so drive 0 head 0 track 0 is DA 000000, sector 1 is 000001 etc. to the end of the disk. This notation is very convenient as it allows media independence in the filing system, for example a floppy disk can be addressed in the same way, it just has less sectors so it has a correspondingly lower maximum DA. Again there is a SASI standard for controllers, originally it defined only the electrical interface signals, but a defacto standard emerged for the majority of high level commands, so in most applications controllers are interchangeable. Most controllers can support two winchester drives (connected by the 34 way and 20 way sockets) and provide a 50 way socket to the host. This socket provides a bi directional 8 bit parallel data port and a number of input and output hand shaking signals, these TTL level signals have to be interfaced to the host and software provided for data I/O. To be more precise the Disk Address is actually a 21 bit number which represents the sector number, and a 3 bit number which represents the device on the controller (or Logical Unit Number, the LUN has a range from 0-7). Most SASI controllers support more than one device, for example SASI controllers to support 2 Winchesters only, 2 winchesters + 2 floppies, or 1 Winchester and 1 tape streamer are common. Each connection port on a controller has a LUN related to it such that requests for I/O to a LUN are channeled to a particular port. Some controllers can be daisy chained on the SASI bus to make use of all 8 LUNs (the controller can be configured, by links or software, to map particular LUNs to particular devices). As an example, the DTC 520A controller board supports 2 Winchesters and 2 floppies, accesses are as follows: LUN = 0 First Winchester (Winchester port 0) LUN = 1 Second Winchester (Winchester port 1) LUN = 2 First floppy (Floppy port 0) LUN = 3 Second floppy (Floppy port 1) Usually a controller can support two Winchesters (all the ones I have met do), but some only allow this if the two devices are of the same type and capacity others allow the size/capacity of each drive to be specified to the controller - it's safer to use one Winchester or two of the same size (a friend nearly ruined a 20Mb Rodime when using it in conjunction with a 10Mb Rodime). There are two distinct types of formatting a controller can use on a Winchester: MFM (Modified Frequency Modulation) and RLL (Run Length Limiting - sometimes known as 2,7 RLL). Basically RLL is the newer technique which uses a type of data compression to get more data onto the disk (a bit like using double density on floppy disks) but requires a disk capable of supporting RLL (the transfer rate is increased to approximately 7.5Mb/s). Also the controller has to be able to support RLL (eg. Adaptec ACB4070). Most controllers on the second hand market support only MFM and most drives were intended for use with MFM. My advice is to stick with MFM unless you really need the extra space - also it's probably cheaper to use a bigger drive with MFM than to purchase a RLL controller. Controllers are not, unfortunately, interchangeable. That is a Winchester that has been formatted by one controller cannot be read or written to by a different make of controller. This is because the different controller manufacturers use slightly different methods of putting the data onto the disk, different numbers of sectors per track etc. Another compatibility "problem" with controllers is how they are informed about the size/shape of the Winchester attached. All controllers have a "default" drive configuration at power up (usually a Shugart 5Mb drive) which is not much use unless you happen to be using this type of drive... 3 ways around this problem are used:
