   10MODE1
   20PRINT"BEEB BODY BUILDING COURSE"
   30PRINT"SOUND SAMPLER"
   40PRINT"MACHINE CODE INITILISER"
   50PRINT"FOR SOUND MANAPULATOR"
   60PRINT"By Mike Cook"
   70PRINT
   80HIMEM=&2E00
   90LOOK%=&2E00
  100PROC_INT
  110PROC_INT2
  120PROC_INSTRUCTIONS
  130CHAIN"MapB"
  140DEF PROC_INT
  160BA=&FE61
  180?&86=&80:?&80=00:?&81=00
  190M%=LOOK%
  200FOR A%=0 TO 31
  210FOR B%=0 TO 7
  220T%=A%*&140+B%+&5800
  230?M%=T% MOD 256
  240M%?&100=T% DIV 256
  250M%=M%+1
  260NEXT:NEXT
  270FOR PASS=0 TO 2 STEP 2
  280P%=&A00
  290[
  300OPT PASS
  310.SETUP \ INITILISE
  320SEI \ DISABLE INTERRUPTS
  330LDA #6:STA &FE62
  340LDA #&40
  350LDY #0
  360STA &FE6B \ ENABLE TIMER 1
  370LDA #&C0
  380STA &FE6E \ ENABLE INTERRUPT
  390LDA #0
  400STA &FE65 \ START IT OFF
  410RTS
  420.G% \ GET SAMPLE INTO MEMORY
  430JSR SETUP
  440.HOLD
  450LDA &FE6D \ GET INTERRUPT FLAG
  460BPL HOLD \ LOOP UNTIL TIME OUT
  470STA &FE6D \ CLEAR INTERRUPT
  480JSR sin \ GET SAMPLE
  500STA (&70),Y
  510INY
  520BNE HOLD \ GET ANOTHER
  530INC &71 \ INCREASE MS POINTER
  540LDA #&70
  550CMP &71 \ REACHED LIMIT ?
  560BNE HOLD \ BRANCH IF NOT
  570.FIN LDA #&40
  580STA &FE6E \ DISABLE T1 INTERRUPT
  590STA &FE6D \ CLEAR ANY INTERRUPTS
  600CLI \ ENABLE SYSTEM INTERRUPTS
  610LDA #&80
  620STA BA \ LEAVE AT DC LEVEL ZERO
  630RTS
  640.U% \ PLAY A SAMPLE
  650JSR SETUP
  660LDA #&80
  670STA BA \ SET DC LEVEL
  680.PAUSE
  690LDA &72 \ TRANSFER START ADDRESS
  700STA &70
  710LDA &73
  720STA &71
  730.HOUT
  740LDA &FE6D \ GET INTERRUPT FLAG
  750BPL HOUT \ LOOP UNTIL TIME OUT
  760STA &FE6D \ CLEAR INTERRUPT
  770LDA (&70),Y \ GET A SAMPLE
  780STA BA \ OUTPUT IT
  790INY
  800BNE HOUT \ GET ANOTHER
  810INC &71 \ INCREASE MS POINTER
  820LDA &80
  830CMP &71 \ REACHED LIMIT ?
  840BNE HOUT \ BRANCH IF NOT
  850JMP FIN
  860\DISPLAY SAMPLES
  870.L% LDX #0
  880STX &87
  890STX &80
  900.LOOP LDY &80
  910LDA (&70),Y  \GET VALUE TO PLOT
  920ROR A \ SCALE IT
  930ROR A
  940ROR A
  950ROR A
  960AND #&F
  970CLC
  980ADC &74 \ POSITION IT
  990TAY
 1000LDA LOOK%,Y  \LOOK UP LSB OF FIRST COLOUM
 1010CLC
 1020ADC &87     \ADD X VALUE
 1030STA &84     \STORE MSB OF PLOT ADDRESS
 1040LDA LOOK%+&100,Y  \LOOK UP MSB OF FIRST COLOUM
 1050ADC #0      \ADD X VALUE
 1060STA &85   \STORE MSB OF PLOT ADDRESS
 1070LDX #0
 1080\PLOT OF POINT ON THE SCREEN
 1090LDA (&84,X)   \GET DISPLAY BYTE
 1100ORA &86       \SET APPROPRIATE BIT
 1110STA (&84,X)   \WRITE TO SCREEN
 1120\MOVE POINTERS TO NEXT X POSITION
 1130INC &80  \X POINTER
 1140ROR &86  \PIXEL MASK
 1150BCC LOOP
 1160LDA #&80      \RESTORE MASK BIT
 1170STA &86
 1180LDA #7   \ADD 8 TO X VALUE
 1190ADC &87 \IT IS 8 AS CARRY IS SET
 1200STA &87
 1210BNE LOOP  \LOOP IF NOT FINISHED ALL POINTS
 1220RTS        \FINISH WHEN SPACE PRESSED
 1230.J% \ MERGE TO SOUND SAMPLES
 1240LDY #0
 1250.LOOP
 1260LDA (&70),Y \ GET SAMPLE OF ONE SOUND
 1270CLC
 1280ROR A
 1290STA &74 \ TEMP STORE
 1300LDA (&72),Y \ GET SAMPLE OF OTHER SOUND
 1310CLC
 1320ROR A
 1330ADC &74 \ ADD THE TWO
 1340STA (&70),Y \ PUT IT BACK
 1350INY
 1360BNE LOOP \ DO NEXT SAMPLE
 1370INC &71 \ MOVE ON MOST SIG BITS
 1380INC &73 \ OF POINTERS
 1390LDA #&50
 1400CMP &71 \ SEE IF WE HAVE DONE ALL
 1410BNE LOOP \ BRANCH IF NOT
 1420RTS
 1421.sin \ Sample In
 1422LDX #10:LDA #0
 1423STA &FE60
 1424.SLOOP
 1425LDA &FE60
 1426LSR A:ROL &7D
 1427LDA #2:STA &FE60
 1428LDA #0:STA &FE60
 1429DEX : BNE SLOOP
 1430LDA #6:STA &FE60
 1431LDA &7D
 1432RTS
 1433]
 1440NEXT
 1450ENDPROC
 1460DEF PROC_INSTRUCTIONS
 1470CLS
 1480PRINT
 1490PRINT"BEEB BODY BUILDING COURSE"
 1500PRINT"SOUND SAMPLE MANAPULATOR"
 1510PRINT"MARCH 1985"
 1520PRINT"By Mike Cook"
 1530PRINT
 1540PRINT"Options are:-"
 1550PRINT"S  - Sample input"
 1560PRINT"sp - Play back sample"
 1570PRINT"8  - Play back 8K of sample"
 1580PRINT"R  - Rate of digitising"
 1590PRINT"P  - Plot the waveform"
 1600PRINT"C  - Clear a section of waveform"
 1610PRINT"F  - Fraction of waveform section"
 1620PRINT"M  - Mark a waveform section"
 1630PRINT"V  - Varie between pointer and mark"
 1640PRINT"L  - Load in a waveform"
 1650PRINT"D  - Dump out a waveform"
 1660PRINT"J  - Join this waveform to a stored one"
 1670PRINT"T  - Tune playd with sample"
 1680PRINT"K  - Keyboard playing of sample"
 1690PRINT
 1700PRINT"Use cursor keys to move pointer"
 1710PRINT
 1720PRINT"Press any key to load the main file"
 1730A$=GET$
 1740ENDPROC
 1750DEF PROC_INT2
 1760?&78=8
 1770FOR A%=0 TO 2 STEP 2
 1780P%=&C00
 1790[
 1800OPT A%
 1810.Q% \ SYNTHESISE A NOTE
 1820LDX &78 \ SET UP NUMBER OF TABLES TO USE
 1830LDA &79 \ SET UP ADDRESS OF
 1840STA &72 \ START OF WAVEFORM TABLES
 1850LDA &7A
 1860STA &73
 1870SEI \ DISABLE INTERRUPTS FROM THE SYSTEM
 1880LDA #&E0 \ ENABLE THE TWO TIMERS
 1890STA &FE6E
 1900LDA #&70 \ INITIALISE T1
 1910STA &FE64 \ LOW ORDER COUNT
 1920STA &FE66 \ LOW ORDER LATCH
 1930LDA #0
 1940STA &FE67 \ HIGH ORDER LATCH
 1950STA &FE65 \ START T1 RUNNING
 1960.ST2 \ START T2
 1970LDA #&FF
 1980STA &FE68
 1990LDA &76 \ VALUE FROM MEMORY
 2000STA &FE69
 2010.HOLD1 \ LOOP UNTIL T1 TIMEOUT
 2020LDA #&40
 2030.HOLD2 BIT &FE6D \ SEE IF T1 IS READY
 2040BEQ HOLD2
 2050STA &FE6D \CLEAR INTERRUPT FLAG
 2060\ MOVE ON THE ENTRY POINTER
 2070CLC
 2080LDA &74 \ INCREMENT VALUE
 2090ADC &70
 2100STA &70
 2110LDA &75
 2120ADC &71
 2130STA &71
 2140LDY &71 \ NUMBER OF ENTRY TO GET
 2150LDA (&72),Y \ GET ENTRY IN TABLE GIVEN BY &72,&73
 2160STA BA \ OUTPUT IT TO D/A
 2170BCC HOLD1
 2180LDA #&20 \ LOOK FOR T2 TIMEOUT
 2190BIT &FE6D
 2200BEQ HOLD1 \ NEXT ENTRY IF NOT TIMED OUT
 2210STA &FE6D \ RESET INTERRUPT FLAG
 2220INC &73 \ MOVE TABLE ONTO THE NEXT ONE
 2230DEX \ TABLES TO GO VALUE
 2240BNE ST2 \ BACK TO START T2 AGAIN
 2250LDA #&60 \ DISABLE THE TWO TIMERS
 2260STA &FE6E
 2270LDA #128 \ SET OUTPUT TO MID POINT
 2280STA BA
 2290CLI \ ENABLE SYSTEM INTERRUPTS
 2300RTS
 2310]
 2320NEXT
 2330?&79=&00
 2340?&7A=&30
 2350ENDPROC
