This website contains an archive of files for the Acorn Electron, BBC Micro, Acorn Archimedes, Commodore 16 and Commodore 64 computers, which Dominic Ford has rescued from his private collection of floppy disks and cassettes.

Some of these files were originally commercial releases in the 1980s and 1990s, but they are now widely available online. I assume that copyright over them is no longer being asserted. If you own the copyright and would like files to be removed, please contact me.

Tape/disk: Home » Personal collection » Acorn ADFS disks » Greaseweazled » adfs_IJJOBS21.adf
Filename: Server1/OldMand/temp6
Read OK:
File size: 0EF7 bytes
Load address: FFFFFB46
Exec address: ED41AF47
Duplicates

There are 2 duplicate copies of this file in the archive:

File contents
   10REM temp5
   20ON ERROR REPORT:PRINT" @";ERL:END
   30PROCassemble
   40CALL setup
   50MODE 15
   60CALL plotter
   70REPEAT UNTIL FALSE
   80:
   90DEFPROCassemble
  100DIM space 1024
  110:
  120FOR p=0 TO 2 STEP 2
  130P%=space
  140[OPT p
  150\ MANDELBROT SET CALCULATION
  160\ R1=x |R2=y
  170:
  180\ F0=xpos
  190\ F1=ypos
  200\ F2=u
  210\ F3=v
  220:
  230.mandpix         STMFD R13!,{R14}
  240                 MOV R11,#0
  250                 ADR R0,xmin                    \ Get X co-ordinate
  260EQUD &ECF00100 \ LDFE F0,[R0]
  270                 ADR R0,xstep
  280EQUD &ECF01100 \ LDFE F1,[R0]
  290EQUD &EE0711D7 \ FLTE F7,R1
  300EQUD &EE192107 \ MLFE F2,F1,F7
  310EQUD &EE080102 \ ADFE F0,F0,F2
  320:
  330                 ADR R0,ymin                    \ Get Y co-ordinate
  340EQUD &ECF01100 \ LDFE F1,[R0]
  350                 ADR R0,ystep
  360EQUD &ECF02100 \ LDFE F2,[R0]
  370EQUD &EE0721D7 \ FLTE F7,R2
  380EQUD &EE1A3107 \ MLFE F3,F2,F7
  390EQUD &EE091103 \ ADFE F1,F1,F3
  400:
  410EQUD &EE08A100 \ MVFE F2,F0
  420EQUD &EE08B101\  MVFE F3,F1
  430.pixloop
  440EQUD &EE1A4102 \ MLFE F4,F2,F2        \ Finished?
  450EQUD &EE1B5103 \ MLFE F5,F3,F3
  460EQUD &EE0C6105 \ ADFE F6,F4,F5
  470EQUD &EED6F11C \ CMFE F6,#4           \ u^2+v^2>4 ?
  480                 BCS found
  490                 ADD R11,R11,#1
  500                 ADR R3,maxit
  510                 LDR R10,[R3]
  520                 CMP R11,R10
  530                 BEQ found
  540EQUD &EE2C6105 \ SBFE F6,F4,F5                \ u=u^2-v^2+x
  550EQUD &EE0E6100 \ ADFE F6,F6,F0
  560EQUD &EE1A4103 \ MLFE F4,F2,F3                \ v=2uv+y
  570EQUD &EE0C4104 \ ADFE F4,F4,F4
  580EQUD &EE0C4101 \ ADFE F4,F4,F1
  590EQUD &EE08A106 \ MVFE F2,F6
  600EQUD &EE08B104 \ MVFE F3,F4
  610                 B pixloop
  620:
  630.found
  640MOV R0,R11
  650LDMFD R13!,{PC}
  660:
  670.setup
  680EQUD &EE088108 \ MVFE F0,#0
  690EQUD &EE28010A \ SBFE F0,F0,#2
  700                 ADR R0,xmin
  710EQUD &ECE00100 \ STFE F0,[R0]
  720                 ADR R0,ymin
  730EQUD &ECE00100 \ STFE F0,[R0]
  740EQUD &EE08910A \ MVFE F0,#2
  750EQUD &EE49010C \ DVFE F0,F0,#4
  760EQUD &EE48110C \ DVFE F0,F0,#4
  770EQUD &EE49010C \ DVFE F0,F0,#4
  780EQUD &EE48110C \ DVFE F0,F0,#4
  790EQUD &EE49010A \ DVFE F0,F0,#2
  800                 ADR R0,ystep
  810EQUD &ECE00100 \ STFE F0,[R0]
  820                 ADR R0,xstep
  830EQUD &ECE00100 \ STFE F0,[R0]
  840                 MOV PC,R14
  850:
  860.plotter         STMFD R13!,{R14}
  870                 BL setup
  880                 MOV R0,#0
  890                 MOV R1,#0
  900.pltloop         ADR R2,xstr
  910                 STR R0,[R2]
  920                 ADR R2,ystr
  930                 STR R1,[R2]
  940                 MOV R2,R1
  950                 MOV R1,R0
  960                 BL mandpix
  970                 BL point
  980                 ADR R2,xstr
  990                 LDR R0,[R2]
 1000                 ADR R2,ystr
 1010                 LDR R1,[R2]
 1020                 ADD R0,R0,#2
 1030                 CMP R0,#1024
 1040                 BNE pltloop
 1050                 MOV R0,#0
 1060                 ADD R1,R1,#4
 1070                 CMP R1,#1024
 1080                 BNE pltloop
 1090                 LDMFD R13!,{PC}
 1100:
 1110.point           ADD R10,R0,#7
 1120                 MOV R11,#&280
 1130                 ADR R2,xstr
 1140                 LDR R0,[R2]
 1150                 MOV R0,R0,LSR #1
 1160                 ADR R2,ystr
 1170                 LDR R1,[R2]
 1180                 MOV R1,R1,LSR #2
 1190                 SUB R0,R11,R0
 1200                 MOV R11,#&2000000
 1210                 SUB R11,R11,R0
 1220                 MOV R12,#&280
 1230                 MUL R2,R1,R12
 1240                 SUB R11,R11,R2
 1250                 STRB R10,[R11]
 1260                 MOV PC,R14
 1270:
 1280.xmin EQUD 0:EQUD0:EQUD0
 1290.ymin EQUD 0:EQUD0:EQUD0
 1300.xstep EQUD 0:EQUD0:EQUD0
 1310.ystep EQUD 0:EQUD0:EQUD0
 1320.maxit EQUD 65536
 1330.xstr EQUD 0
 1340.ystr EQUD 0
 1350.stack
 1360]
 1370NEXT
 1380REM OSCLI ("MEMORYI "+STR$~space+" + 100"):END
 1390ENDPROC
