   10 REM BallBot V3.0
   20 REM Real-Time Version with Continuous Testing Option
   30 REM (C) Dominic Ford 1997
   40 :
   50 REM Welcome screen
   60 MODE6:@%=&905:PRINT" BallBot Artificial Intelligence Module"'"Simulation Tester V3.0 Real Time Version"''"Programmed and Designed by Dominic Ford"''SPC(16);"(C) 1997"
   70 PRINT'''"1. Real-Time Simulation"''"2. Logged Continuous Runs"''"3. Do specific run"
   80 REPEAT type$=GET$:UNTIL type$="1" OR type$="2" OR type$="3"
   90 :
  100 REM Setup variables
  110 ON ERROR OSCLI"CLOSE":REPORT:PRINT" at line ";ERL:END
  120 VOICE 1,"StringLib-Soft":*STEREO 1 0
  130 VOICE 2,"StringLib-Soft":*STEREO 2 -127
  140 VOICE 3,"StringLib-Soft":*STEREO 3 127
  150 current=0:DIMball(4,1):bbx=640:bby=950:dir=270:PROCsetupbb
  160 MODE12:IF type$="1" THEN MOUSE ON:PROCdrawfull
  170 IF type$="2" THEN start=TIME:stage=0:idle=FALSE:INPUT"Filename";f$:OSCLI"SPOOL "+f$
  180 IF type$="3" THEN PRINT"Enter Data:"':FORb=0TO4:PRINT"Ball ";b+1;:INPUTball(b,0),ball(b,1):NEXT:type$="1":MOUSE ON:PROCdrawfull
  190 :
  200 REM Start main loop
  210 REPEAT:T=TIME
  220 IF type$="1" THEN PROCuser ELSE PROCcompmon
  230 IF idle THEN UNTIL FALSE
  240 PROCsense
  250 mov=FNai(freqa,freqb,freqc)
  260 fwd=(mov AND 1)<>0
  270 reverse=(mov AND 2)<>0
  280 left=(mov AND 4)<>0
  290 right=(mov AND 8)<>0
  300 turbo=(mov AND 16)<>0
  310 open=(mov AND 32)<>0
  320 PROCmoveit
  330 REPEAT UNTIL TIME>(T+15)
  340 UNTIL FALSE
  350 :
  360 REM Graphic interface
  370 DEFPROCdrawfull
  380 REM Set up constants
  390 LOCALsx,sy,width
  400 sx=1:sy=2:width=10
  410 REM Setup Colours
  420 COLOUR0,0,64,0:COLOUR1,255,0,0:COLOUR2,255,255,255:COLOUR3,255,0,0:COLOUR4,255,255,0:COLOUR5,0,0,0:COLOUR6,255,255,0
  430 :
  440 REM Draw green court area
  450 CLS:GCOL0,0:RECTANGLE FILL 0,0,1279,1023
  460 REM Mark out white lines onto court
  470 GCOL0,2:RECTANGLE FILL sx/(23.77+2*sx)*1280,sy/(10.97+2*sy)*1024,23.77/(23.77+2*sx)*1280,width:RECTANGLE FILL sx/(23.77+2*sx)*1280,(1.37+sy)/(10.97+2*sy)*1024,23.77/(23.77+2*sx)*1280,width
  480 RECTANGLE FILL sx/(23.77+2*sx)*1280,(9.6+sy)/(10.97+2*sy)*1024,23.77/(23.77+2*sx)*1280,width:RECTANGLE FILL sx/(23.77+2*sx)*1280,(10.97+sy)/(10.97+2*sy)*1024,23.77/(23.77+2*sx)*1280,width
  490 RECTANGLE FILL (sx+5.47)/(23.77+2*sx)*1280,(sy+5.49)/(10.97+2*sy)*1024,12.8/(23.77+2*sx)*1280,width
  500 RECTANGLE FILL sx/(23.77+2*sx)*1280,sy/(10.97+2*sy)*1024,width,10.97/(10.97+2*sy)*1024:RECTANGLE FILL (sx+23.77)/(23.77+2*sx)*1280,sy/(10.97+2*sy)*1024,width,10.97/(10.97+2*sy)*1024+width
  510 RECTANGLE FILL (sx+5.47)/(23.77+2*sx)*1280,(sy+1.37)/(10.97+2*sy)*1024,width,8.23/(10.97+2*sy)*1024:RECTANGLE FILL (sx+18.3)/(23.77+2*sx)*1280,(sy+1.37)/(10.97+2*sy)*1024,width,8.23/(10.97+2*sy)*1024
  520 :
  530 REM Draw net
  540 GCOL0,5:FORl=100TO924STEP10:MOVE 640,l:DRAW 680,l+50:NEXT:FORl=0TO40STEP10:MOVE 640+l,100+l:DRAW640+l,924+l:NEXT:FORl=0TO5:MOVE637+l,100:DRAW677+l,150:MOVE637+l,924:DRAW677+l,974:NEXT
  550 GCOL0,2:MOVE 682,142:DRAW682,966
  560 PROCdrawmini
  570 ENDPROC
  580 :
  590 REM Draw ballbot and balls
  600 DEFPROCdrawmini
  610 IF type$="2" THEN ENDPROC
  620 GCOL3,4:FORb=0TO4
  630 IF ball(b,0)<>0 OR ball(b,1)<>0 THEN RECTANGLE FILL ball(b,0),ball(b,1),5,5
  640 NEXT
  650 GCOL3,3:RECTANGLE FILL bbx,bby,5,5
  660 ENDPROC
  670 :
  680 REM User interface (putting balls down)
  690 DEFPROCuser
  700 MOUSE x,y,c
  710 IF c=0 THEN ENDPROC
  720 IF (c AND 4)<>0 THEN PROCdrawmini:ball(current,0)=x:ball(current,1)=y:current=(current+1)MOD5:PROCdrawmini
  730 IF (c AND 2)<>0 THEN idle=FALSE:stage=0:start=TIME
  740 REPEAT
  750 MOUSE x,y,c
  760 UNTIL c=0
  770 ENDPROC
  780 :
  790 REM Calculate ballbot's new position
  800 DEFPROCmoveit
  810 IF (left AND fwd) OR (right AND reverse) THEN dir=dir-2.5*(1-3*turbo)
  820 IF (right AND fwd) OR (left AND reverse) THEN dir=dir+2.5*(1-3*turbo)
  830 :
  840 REM Get direction in range 0<theta<360
  850 REPEAT IF dir<0 THEN dir=dir+360
  860 IF dir>=360 THEN dir=dir-360
  870 UNTIL dir>=0 AND dir<360
  880 :
  890 fr=0:IF fwd THEN fr=fr+0.25
  900 IF reverse THEN fr=fr-0.25
  910 IF turbo THEN fr=fr*4
  920 PROCdrawmini:bbx=bbx+16*SIN(PI*dir/180)*fr
  930 bby=bby+16*COS(PI*dir/180)*fr
  940 FORball=0TO4:IF open AND ABS(bbx-ball(ball,0))<10 AND ABS(bby-ball(ball,1))<10 THEN ball(ball,0)=0
  950 NEXT:PROCdrawmini
  960 ENDPROC
  970 :
  980 REM Calculate ballbot's background echo reading (-balls)
  990 DEFFNback(freq,min,max)
 1000 IF min<0 THEN min=min+360 ELSE IF min>360 THEN min=min-360
 1010 IF max<0 THEN max=max+360 ELSE IF max>360 THEN max=max-360
 1020 LOCAL hit,dist:hit=0:dist=0
 1030 IF (bbx<640 AND (min<=90 AND max>=90 AND min<max)OR(max<=90 AND min>=90 AND max<min)) OR (bbx>640 AND (min<=270 AND max>=270 AND min<max)OR(max<=270 AND min>=270 AND max<min)) THEN hit=bby:dist=ABS(bbx-640)
 1040 IF hit=0 AND ABS((min+180*(bbx>640))-90)<ABS((max+180*(bbx>640))-90) AND SIN(PI*min/180)<>0 THEN dist=(640-bbx)/SIN(PI*min/180):hit=(640-bbx)/TAN(PI*min/180)+bby
 1050 IF hit=0 AND ABS((min+180*(bbx>640))-90)>ABS((max+180*(bbx>640))-90) AND SIN(PI*min/180)<>0 THEN dist=(640-bbx)/SIN(PI*max/180):hit=(640-bbx)/TAN(PI*max/180)+bby
 1060 IF hit>923 OR hit<100 OR dist<0 THEN ftype$="U":=freq+RND(6)-3
 1070 IF hit>900 OR hit<123 THEN ftype$="P":=dist
 1080 ftype$="N"
 1090 =dist
 1100 :
 1110 REM Calculate Ballbot's readings (MAIN ROUTINE)
 1120 :
 1130 DEFPROCsense
 1140 REM Get background readings from FNback
 1150 freq=RND(250)+1500
 1160 freqa=FNback(freq,dir-15,dir+15):fa$=ftype$
 1170 freqb=FNback(freq,dir-45,dir-15):fb$=ftype$
 1180 freqc=FNback(freq,dir+15,dir+45):fc$=ftype$
 1190 freqd=FNback(freq,dir-90,dir-45):fd$=ftype$
 1200 :
 1210 REM Add any relevant balls to readings (using hairy trigonometry)
 1220 :
 1230 FORball=0TO4
 1240 d%=SQR((ball(ball,0)-bbx)^2+(ball(ball,1)-bby)^2)
 1250 IF ball(ball,0)=0 THEN d%=9999
 1260 a=FNangle(ball(ball,0),ball(ball,1),bbx,bby)-dir:IFa>180 THEN a=a-360
 1270 IF ABS(a)<15 AND freqa>d% THEN freqa=d%:fa$="B"
 1280 IF a>-46 AND a<=-15 AND freqb>d% THEN freqb=d%:fb$="B"
 1290 IF a>=15 AND a<46 AND freqc>d% THEN freqc=d%:fc$="B"
 1300 IF a>-90 AND a<=-46 AND freqd>d% THEN freqd=d%:fd$="B"
 1310 NEXT
 1320 :
 1330 REM Update user displays
 1340 :
 1350 IF type$="2" THEN ENDPROC
 1360 PRINTTAB(0,0)INT((TIME-start)/6000);":";(INT((TIME-start)/100)MOD60);" "
 1370 PRINTTAB(0,31)fd$,fb$,fa$,fc$,stage,INT(searching),left,right,opencter;
 1380 SOUND 1,-1,freqa/4,5:SOUND 2,-1,freqb/4,5:SOUND 3,-1,freqc/4,5
 1390 ENDPROC
 1400:
 1410 REM Calculate bearing of B from A
 1420 DEFFNangle(x1,y1,x2,y2)
 1430 IF y2=y1 THEN ang=90 ELSE ang=180*ATN((x2-x1)/(y2-y1))/PI
 1440 IF (y2>y1) THEN ang=ang+180
 1450 IF ang<0 THEN ang=ang+360
 1460 =ang MOD 360
 1470 :
 1480 REM Computer Monitor of BallBot's progress
 1490 DEFPROCcompmon
 1500 IF idle AND (ball(0,0)<>0 OR ball(1,0)<>0 OR ball(2,0)<>0 OR ball(3,0)<>0 OR ball(4,0)<>0) THEN st$="Fail" ELSE st$="Pass"
 1510 IF idle THEN PRINTst$,INT((TIME-start)/6000);":";(INT((TIME-start)/100)MOD60)
 1520 IF TIME>start+36000 THEN idle=TRUE:PRINT"Time","****"
 1530 IFbbx>630ANDbbx<650ANDbby>100ANDbby<923THENidle=TRUE:PRINT"Crash","****"
 1540 IF idle THEN bbx=640:bby=950:dir=270:stage=0:PROCsetupbb:start=TIME:FORb=0TO4:ball(b,0)=RND(1280):ball(b,1)=RND(1024):NEXT
 1550 IF idle THEN PRINT"[";ball(0,0);",";ball(0,1);"] [";ball(1,0);",";ball(1,1);"] [";ball(2,0);",";ball(2,1);"] [";ball(3,0);",";ball(3,1);"] [";ball(4,0);",";ball(4,1);"]",;:idle=FALSE
 1560 ENDPROC
 1570 :
 1580 REM BALLBOT ROBOTIC INTELLIGENCE MODULE
 1590 :
 1600 DEFFNai(freqa,freqb,freqc)
 1610 REM Artificial intelligence routines (ie. What Next??)
 1620 LOCALfwd,reverse,left,right,turbo
 1630 fwd=TRUE:reverse=FALSE:left=FALSE:right=FALSE:turbo=FALSE
 1640 :
 1650 REM What stage are we in? Hunt for balls or move to new area?
 1660 IF near<>0 AND stage<8 THEN PROCdonearstuff
 1670 IF near=0 AND (stage=0 OR stage=2) THEN PROChunt
 1680 IF near=0 AND (stage=1 OR stage=3) THEN PROCmoveout
 1690 IF stage=4 THEN PROCreleaseb
 1700 :
 1710 REM Prepare output into binary for transmission
 1720 feed=0:IF fwd THEN feed=feed+1
 1730 IF reving THEN turbo=TRUE
 1740 IF reverse THEN feed=feed+2
 1750 IF left THEN feed=feed+4
 1760 IF right THEN feed=feed+8
 1770 IF turbo THEN feed=feed+16
 1780 IF opencter>0 THEN feed=feed+32
 1790 =feed
 1800 :
 1810 REM Perform a sweep to find any balls
 1820 DEFPROChunt
 1830 REM Watch out if too near to net
 1840 IF((freqa<20AND fa$<>"B")OR(freqb<20AND fb$<>"B")OR(freqc<20AND fc$<>"B"))OR(reving AND((freqa<150AND fa$<>"B")OR(freqb<150AND fb$<>"B")OR(freqc<150AND fc$<>"B")))THENreving=TRUE:reverse=TRUE:fwd=FALSE:left=FALSE:right=FALSE:ENDPROC
 1850 reving=FALSE
 1860 :
 1870 REM If Ball is out of reach in the "D" sector, reverse!
 1880 FDR=freqd*1.25:IFfreqd<150ANDfd$="B"ANDFDR<freqa ANDFDR<freqb ANDFDR<freqc AND(fa$<>"B"ORfreqa>100)AND(fb$<>"B"ORfreqb>100)AND(fc$<>"B"ORfreqc>100)THEN turbo=TRUE:reverse=TRUE:fwd=FALSE:right=TRUE:farleft=-6*(freqd>40):ENDPROC
 1890 IF farleft>0 THEN
 1900  farleft=farleft-1:reverse=TRUE:fwd=FALSE:right=TRUE:turbo=TRUE
 1910  IF fa$="B" OR (fd$<>"B" AND fb$<>"B") THEN farleft=0
 1920  ENDPROC
 1930 ENDIF
 1940 :
 1950 REM Rotate to face ball
 1960 IF (fb$="B" AND freqb>150) OR (fd$="B" AND freqd>150) THEN tending=0
 1970 IF fc$="B" AND freqc>150 THEN tending=1
 1980 IF opencter>0 THEN opencter=opencter-1:ENDPROC
 1990 opencter=-5*(((freqa<20)ANDfa$="B")OR((freqb<20)ANDfb$="B")OR((freqc<20)ANDfc$="B")OR((freqd<20)ANDfd$="B"))
 2000 IF fa$="B" THEN left=(steer=-1):right=(steer=1):steer=0:searching=searching/2:turbo=freqa>100:ENDPROC
 2010 IF fb$="B" OR fd$="B" THEN steer=-1:left=TRUE:ENDPROC
 2020 IF fc$="B" THEN steer=1:right=TRUE:ENDPROC
 2030 REM If no ball in sight, continue rotation...
 2040 align=FALSE:searching=searching+1
 2050 IF (tending AND 1)<>0 THEN right=TRUE ELSE left=TRUE
 2060 IF searching=5 THEN tending=(tending EOR 1)
 2070 IF searching>150 THEN stage=stage+1
 2080 ENDPROC
 2090 :
 2100 REM Find edge of net and aim for it to move to other side
 2110 DEFPROCmoveout
 2120 REM Watch out if too near to net
 2130 IF (freqa<30 OR freqb<30 OR freqc<30) OR (reving AND (freqa<250 OR freqb<250 OR freqc<250)) THEN reving=TRUE:farleft=0:reverse=TRUE:fwd=FALSE:right=FALSE:left=(freqa>230 AND freqb>230 AND freqc>230):ENDPROC
 2140 reving=FALSE
 2150 REM Align ballbot to face the net post...
 2160 IF fa$="N" OR fa$="P" THEN right=TRUE:ENDPROC
 2170 IF fb$<>"N" AND fb$<>"P" THEN left=TRUE:ENDPROC
 2180 IF fb$="P" AND freqb<150 THEN right=TRUE:near=1:ENDPROC
 2190 turbo=TRUE
 2200 ENDPROC
 2210 :
 2220 REM Nearly there... Just need a little nudge in the right direction.
 2230 DEFPROCdonearstuff
 2240 near=near+1
 2250 IF near<16 THEN right=TRUE:ENDPROC
 2260 left=TRUE
 2270 IF near>32 THEN near=0:stage=stage+1:searching=0:tending=1
 2280 ENDPROC
 2290 :
 2300 REM Initialise BallBot variables at the beginning of a run
 2310 DEFPROCsetupbb
 2320 reving=FALSE:left=FALSE:right=FALSE:fwd=FALSE:reverse=FALSE:searching=0:idle=TRUE
 2330 near=FALSE:farleft=0:opencter=0:tending=1:steer=0
 2340 ENDPROC
 2350 :
 2360 DEFPROCreleaseb
 2370 REM Got all the balls, now just dump them!
 2380 near=near+1:reverse=TRUE:fwd=FALSE
 2390 IF near>9 THEN idle=TRUE:near=FALSE
 2400 ENDPROC
 2410 REPEAT:FORX=1TO12:OSCLI"CHANNELVOICE 1 "+STR$X:SOUND1,-10,52,100:FORR=0TO10000:NEXT,:UNTIL FALSE
 2420 :
 2430 REM Whizz-back to line up with D - what if whizz back into net?
 2440 REM Reverse if BallBot knows that balls are behind it.


 � BallBot V3.0
7 � Real-Time Version with Continuous Testing Option
 � (C) Dominic Ford 1997
( :
2 � Welcome screen
<� �6:@%=&905:�" BallBot Artificial Intelligence Module"'"Simulation Tester V3.0 Real Time Version"''"Programmed and Designed by Dominic Ford"''�(16);"(C) 1997"
FU �'''"1. Real-Time Simulation"''"2. Logged Continuous Runs"''"3. Do specific run"
P2 � type$=�:� type$="1" � type$="2" � type$="3"
Z :
d � Setup variables
n$ � � �"CLOSE":�:�" at line ";�:�
x& ȡ 1,"StringLib-Soft":*STEREO 1 0
�) ȡ 2,"StringLib-Soft":*STEREO 2 -127
�( ȡ 3,"StringLib-Soft":*STEREO 3 127
�: current=0:�ball(4,1):bbx=640:bby=950:dir=270:�setupbb
�% �12:� type$="1" � ȗ �:�drawfull
�E � type$="2" � start=�:stage=0:idle=�:�"Filename";f$:�"SPOOL "+f$
�g � type$="3" � �"Enter Data:"':�b=0�4:�"Ball ";b+1;:�ball(b,0),ball(b,1):�:type$="1":ȗ �:�drawfull
� :
� � Start main loop
�
 �:T=�
�# � type$="1" � �user � �compmon
� � idle � � �
� �sense
� mov=�ai(freqa,freqb,freqc)
 fwd=(mov � 1)<>0
 reverse=(mov � 2)<>0
 left=(mov � 4)<>0
" right=(mov � 8)<>0
, turbo=(mov � 16)<>0
6 open=(mov � 32)<>0
@ �moveit
J � � �>(T+15)
T � �
^ :
h � Graphic interface
r ��drawfull
| � Set up constants
� �sx,sy,width
� sx=1:sy=2:width=10
� � Setup Colours
�V �0,0,64,0:�1,255,0,0:�2,255,255,255:�3,255,0,0:�4,255,255,0:�5,0,0,0:�6,255,255,0
� :
� � Draw green court area
� �:�0,0:ȓ Ȑ 0,0,1279,1023
�& � Mark out white lines onto court
֬ �0,2:ȓ Ȑ sx/(23.77+2*sx)*1280,sy/(10.97+2*sy)*1024,23.77/(23.77+2*sx)*1280,width:ȓ Ȑ sx/(23.77+2*sx)*1280,(1.37+sy)/(10.97+2*sy)*1024,23.77/(23.77+2*sx)*1280,width
� ȓ Ȑ sx/(23.77+2*sx)*1280,(9.6+sy)/(10.97+2*sy)*1024,23.77/(23.77+2*sx)*1280,width:ȓ Ȑ sx/(23.77+2*sx)*1280,(10.97+sy)/(10.97+2*sy)*1024,23.77/(23.77+2*sx)*1280,width
�_ ȓ Ȑ (sx+5.47)/(23.77+2*sx)*1280,(sy+5.49)/(10.97+2*sy)*1024,12.8/(23.77+2*sx)*1280,width
� ȓ Ȑ sx/(23.77+2*sx)*1280,sy/(10.97+2*sy)*1024,width,10.97/(10.97+2*sy)*1024:ȓ Ȑ (sx+23.77)/(23.77+2*sx)*1280,sy/(10.97+2*sy)*1024,width,10.97/(10.97+2*sy)*1024+width
�� ȓ Ȑ (sx+5.47)/(23.77+2*sx)*1280,(sy+1.37)/(10.97+2*sy)*1024,width,8.23/(10.97+2*sy)*1024:ȓ Ȑ (sx+18.3)/(23.77+2*sx)*1280,(sy+1.37)/(10.97+2*sy)*1024,width,8.23/(10.97+2*sy)*1024
 :
 � Draw net
� �0,5:�l=100�924�10:� 640,l:� 680,l+50:�:�l=0�40�10:� 640+l,100+l:�640+l,924+l:�:�l=0�5:�637+l,100:�677+l,150:�637+l,924:�677+l,974:�
& �0,2:� 682,142:�682,966
0 �drawmini
: �
D :
N � Draw ballbot and balls
X ��drawmini
b � type$="2" � �
l �3,4:�b=0�4
vB � ball(b,0)<>0 � ball(b,1)<>0 � ȓ Ȑ ball(b,0),ball(b,1),5,5
� �
� �3,3:ȓ Ȑ bbx,bby,5,5
� �
� :
�* � User interface (putting balls down)
� ��user
�
 ȗ x,y,c
� � c=0 � �
�a � (c � 4)<>0 � �drawmini:ball(current,0)=x:ball(current,1)=y:current=(current+1)�5:�drawmini
�* � (c � 2)<>0 � idle=�:stage=0:start=�
� �
�
 ȗ x,y,c
�
 � c=0
 �
 :
' � Calculate ballbot's new position

 ��moveit
*A � (left � fwd) � (right � reverse) � dir=dir-2.5*(1-3*turbo)
4A � (right � fwd) � (left � reverse) � dir=dir+2.5*(1-3*turbo)
> :
H) � Get direction in range 0<theta<360
R � � dir<0 � dir=dir+360
\ � dir>=360 � dir=dir-360
f � dir>=0 � dir<360
p :
z fr=0:� fwd � fr=fr+0.25
� � reverse � fr=fr-0.25
� � turbo � fr=fr*4
�) �drawmini:bbx=bbx+16*�(�*dir/180)*fr
� bby=bby+16*�(�*dir/180)*fr
�X �ball=0�4:� open � �(bbx-ball(ball,0))<10 � �(bby-ball(ball,1))<10 � ball(ball,0)=0
� �:�drawmini
� �
� :
�; � Calculate ballbot's background echo reading (-balls)
� ݤback(freq,min,max)
�4 � min<0 � min=min+360 � � min>360 � min=min-360
�4 � max<0 � max=max+360 � � max>360 � max=max-360
� � hit,dist:hit=0:dist=0
� � (bbx<640 � (min<=90 � max>=90 � min<max)�(max<=90 � min>=90 � max<min)) � (bbx>640 � (min<=270 � max>=270 � min<max)�(max<=270 � min>=270 � max<min)) � hit=bby:dist=�(bbx-640)
� � hit=0 � �((min+180*(bbx>640))-90)<�((max+180*(bbx>640))-90) � �(�*min/180)<>0 � dist=(640-bbx)/�(�*min/180):hit=(640-bbx)/�(�*min/180)+bby
� � hit=0 � �((min+180*(bbx>640))-90)>�((max+180*(bbx>640))-90) � �(�*min/180)<>0 � dist=(640-bbx)/�(�*max/180):hit=(640-bbx)/�(�*max/180)+bby
$; � hit>923 � hit<100 � dist<0 � ftype$="U":=freq+�(6)-3
.+ � hit>900 � hit<123 � ftype$="P":=dist
8 ftype$="N"
B
 =dist
L :
V2 � Calculate Ballbot's readings (MAIN ROUTINE)
` :
j ��sense
t* � Get background readings from FNback
~ freq=�(250)+1500
�/ freqa=�back(freq,dir-15,dir+15):fa$=ftype$
�/ freqb=�back(freq,dir-45,dir-15):fb$=ftype$
�/ freqc=�back(freq,dir+15,dir+45):fc$=ftype$
�/ freqd=�back(freq,dir-90,dir-45):fd$=ftype$
� :
�D � Add any relevant balls to readings (using hairy trigonometry)
� :
� �ball=0�4
�4 d%=�((ball(ball,0)-bbx)^2+(ball(ball,1)-bby)^2)
� � ball(ball,0)=0 � d%=9999
�E a=�angle(ball(ball,0),ball(ball,1),bbx,bby)-dir:�a>180 � a=a-360
�, � �(a)<15 � freqa>d% � freqa=d%:fa$="B"
3 � a>-46 � a<=-15 � freqb>d% � freqb=d%:fb$="B"

1 � a>=15 � a<46 � freqc>d% � freqc=d%:fc$="B"
3 � a>-90 � a<=-46 � freqd>d% � freqd=d%:fd$="B"
 �
( :
2 � Update user displays
< :
F � type$="2" � �
P: �0,0)�((�-start)/6000);":";(�((�-start)/100)�60);" "
ZC �0,31)fd$,fb$,fa$,fc$,stage,�(searching),left,right,opencter;
d7 � 1,-1,freqa/4,5:� 2,-1,freqb/4,5:� 3,-1,freqc/4,5
n �
x:
�$ � Calculate bearing of B from A
� ݤangle(x1,y1,x2,y2)
�4 � y2=y1 � ang=90 � ang=180*�((x2-x1)/(y2-y1))/�
� � (y2>y1) � ang=ang+180
� � ang<0 � ang=ang+360
� =ang � 360
� :
�- � Computer Monitor of BallBot's progress
� ��compmon
�r � idle � (ball(0,0)<>0 � ball(1,0)<>0 � ball(2,0)<>0 � ball(3,0)<>0 � ball(4,0)<>0) � st$="Fail" � st$="Pass"
�> � idle � �st$,�((�-start)/6000);":";(�((�-start)/100)�60)
�, � �>start+36000 � idle=�:�"Time","****"
�< �bbx>630�bbx<650�bby>100�bby<923�idle=�:�"Crash","****"
k � idle � bbx=640:bby=950:dir=270:stage=0:�setupbb:start=�:�b=0�4:ball(b,0)=�(1280):ball(b,1)=�(1024):�
� � idle � �"[";ball(0,0);",";ball(0,1);"] [";ball(1,0);",";ball(1,1);"] [";ball(2,0);",";ball(2,1);"] [";ball(3,0);",";ball(3,1);"] [";ball(4,0);",";ball(4,1);"]",;:idle=�
 �
" :
,* � BALLBOT ROBOTIC INTELLIGENCE MODULE
6 :
@ ݤai(freqa,freqb,freqc)
J9 � Artificial intelligence routines (ie. What Next??)
T" �fwd,reverse,left,right,turbo
^+ fwd=�:reverse=�:left=�:right=�:turbo=�
h :
r@ � What stage are we in? Hunt for balls or move to new area?
|' � near<>0 � stage<8 � �donearstuff
�+ � near=0 � (stage=0 � stage=2) � �hunt
�. � near=0 � (stage=1 � stage=3) � �moveout
� � stage=4 � �releaseb
� :
�2 � Prepare output into binary for transmission
� feed=0:� fwd � feed=feed+1
� � reving � turbo=�
� � reverse � feed=feed+2
� � left � feed=feed+4
� � right � feed=feed+8
� � turbo � feed=feed+16
�  � opencter>0 � feed=feed+32
�
 =feed
 :
( � Perform a sweep to find any balls
 ��hunt
&# � Watch out if too near to net
0� �((freqa<20� fa$<>"B")�(freqb<20� fb$<>"B")�(freqc<20� fc$<>"B"))�(reving �((freqa<150� fa$<>"B")�(freqb<150� fb$<>"B")�(freqc<150� fc$<>"B")))�reving=�:reverse=�:fwd=�:left=�:right=�:�
:
 reving=�
D :
N: � If Ball is out of reach in the "D" sector, reverse!
X� FDR=freqd*1.25:�freqd<150�fd$="B"�FDR<freqa �FDR<freqb �FDR<freqc �(fa$<>"B"�freqa>100)�(fb$<>"B"�freqb>100)�(fc$<>"B"�freqc>100)� turbo=�:reverse=�:fwd=�:right=�:farleft=-6*(freqd>40):�
b � farleft>0 �
l7  farleft=farleft-1:reverse=�:fwd=�:right=�:turbo=�
v3  � fa$="B" � (fd$<>"B" � fb$<>"B") � farleft=0
�  �
� �
� :
� � Rotate to face ball
�@ � (fb$="B" � freqb>150) � (fd$="B" � freqd>150) � tending=0
�& � fc$="B" � freqc>150 � tending=1
�) � opencter>0 � opencter=opencter-1:�
�f opencter=-5*(((freqa<20)�fa$="B")�((freqb<20)�fb$="B")�((freqc<20)�fc$="B")�((freqd<20)�fd$="B"))
�` � fa$="B" � left=(steer=-1):right=(steer=1):steer=0:searching=searching/2:turbo=freqa>100:�
�, � fb$="B" � fd$="B" � steer=-1:left=�:�
�" � fc$="B" � steer=1:right=�:�
�0 � If no ball in sight, continue rotation...
�" align=�:searching=searching+1
* � (tending � 1)<>0 � right=� � left=�
* � searching=5 � tending=(tending � 1)
$ � searching>150 � stage=stage+1
  �
* :
4< � Find edge of net and aim for it to move to other side
> ��moveout
H# � Watch out if too near to net
R� � (freqa<30 � freqb<30 � freqc<30) � (reving � (freqa<250 � freqb<250 � freqc<250)) � reving=�:farleft=0:reverse=�:fwd=�:right=�:left=(freqa>230 � freqb>230 � freqc>230):�
\
 reving=�
f, � Align ballbot to face the net post...
p$ � fa$="N" � fa$="P" � right=�:�
z% � fb$<>"N" � fb$<>"P" � left=�:�
�- � fb$="P" � freqb<150 � right=�:near=1:�
� turbo=�
� �
� :
�G � Nearly there... Just need a little nudge in the right direction.
� ��donearstuff
� near=near+1
� � near<16 � right=�:�
� left=�
�; � near>32 � near=0:stage=stage+1:searching=0:tending=1
� �
� :
�= � Initialise BallBot variables at the beginning of a run
	 ��setupbb
	? reving=�:left=�:right=�:fwd=�:reverse=�:searching=0:idle=�
	2 near=�:farleft=0:opencter=0:tending=1:steer=0
	$ �
	. :
	8 ��releaseb
	B- � Got all the balls, now just dump them!
	L  near=near+1:reverse=�:fwd=�
	V � near>9 � idle=�:near=�
	` �
	jD �:�X=1�12:�"CHANNELVOICE 1 "+�X:�1,-10,52,100:�R=0�10000:�,:� �
	t :
	~B � Whizz-back to line up with D - what if whizz back into net?
	�9 � Reverse if BallBot knows that balls are behind it.
�
00000000  0d 00 0a 13 20 f4 20 42  61 6c 6c 42 6f 74 20 56  |.... . BallBot V|
00000010  33 2e 30 0d 00 14 37 20  f4 20 52 65 61 6c 2d 54  |3.0...7 . Real-T|
00000020  69 6d 65 20 56 65 72 73  69 6f 6e 20 77 69 74 68  |ime Version with|
00000030  20 43 6f 6e 74 69 6e 75  6f 75 73 20 54 65 73 74  | Continuous Test|
00000040  69 6e 67 20 4f 70 74 69  6f 6e 0d 00 1e 1c 20 f4  |ing Option.... .|
00000050  20 28 43 29 20 44 6f 6d  69 6e 69 63 20 46 6f 72  | (C) Dominic For|
00000060  64 20 31 39 39 37 0d 00  28 06 20 3a 0d 00 32 15  |d 1997..(. :..2.|
00000070  20 f4 20 57 65 6c 63 6f  6d 65 20 73 63 72 65 65  | . Welcome scree|
00000080  6e 0d 00 3c a2 20 eb 36  3a 40 25 3d 26 39 30 35  |n..<. .6:@%=&905|
00000090  3a f1 22 20 42 61 6c 6c  42 6f 74 20 41 72 74 69  |:." BallBot Arti|
000000a0  66 69 63 69 61 6c 20 49  6e 74 65 6c 6c 69 67 65  |ficial Intellige|
000000b0  6e 63 65 20 4d 6f 64 75  6c 65 22 27 22 53 69 6d  |nce Module"'"Sim|
000000c0  75 6c 61 74 69 6f 6e 20  54 65 73 74 65 72 20 56  |ulation Tester V|
000000d0  33 2e 30 20 52 65 61 6c  20 54 69 6d 65 20 56 65  |3.0 Real Time Ve|
000000e0  72 73 69 6f 6e 22 27 27  22 50 72 6f 67 72 61 6d  |rsion"''"Program|
000000f0  6d 65 64 20 61 6e 64 20  44 65 73 69 67 6e 65 64  |med and Designed|
00000100  20 62 79 20 44 6f 6d 69  6e 69 63 20 46 6f 72 64  | by Dominic Ford|
00000110  22 27 27 89 28 31 36 29  3b 22 28 43 29 20 31 39  |"''.(16);"(C) 19|
00000120  39 37 22 0d 00 46 55 20  f1 27 27 27 22 31 2e 20  |97"..FU .'''"1. |
00000130  52 65 61 6c 2d 54 69 6d  65 20 53 69 6d 75 6c 61  |Real-Time Simula|
00000140  74 69 6f 6e 22 27 27 22  32 2e 20 4c 6f 67 67 65  |tion"''"2. Logge|
00000150  64 20 43 6f 6e 74 69 6e  75 6f 75 73 20 52 75 6e  |d Continuous Run|
00000160  73 22 27 27 22 33 2e 20  44 6f 20 73 70 65 63 69  |s"''"3. Do speci|
00000170  66 69 63 20 72 75 6e 22  0d 00 50 32 20 f5 20 74  |fic run"..P2 . t|
00000180  79 70 65 24 3d be 3a fd  20 74 79 70 65 24 3d 22  |ype$=.:. type$="|
00000190  31 22 20 84 20 74 79 70  65 24 3d 22 32 22 20 84  |1" . type$="2" .|
000001a0  20 74 79 70 65 24 3d 22  33 22 0d 00 5a 06 20 3a  | type$="3"..Z. :|
000001b0  0d 00 64 16 20 f4 20 53  65 74 75 70 20 76 61 72  |..d. . Setup var|
000001c0  69 61 62 6c 65 73 0d 00  6e 24 20 ee 20 85 20 ff  |iables..n$ . . .|
000001d0  22 43 4c 4f 53 45 22 3a  f6 3a f1 22 20 61 74 20  |"CLOSE":.:." at |
000001e0  6c 69 6e 65 20 22 3b 9e  3a e0 0d 00 78 26 20 c8  |line ";.:...x& .|
000001f0  a1 20 31 2c 22 53 74 72  69 6e 67 4c 69 62 2d 53  |. 1,"StringLib-S|
00000200  6f 66 74 22 3a 2a 53 54  45 52 45 4f 20 31 20 30  |oft":*STEREO 1 0|
00000210  0d 00 82 29 20 c8 a1 20  32 2c 22 53 74 72 69 6e  |...) .. 2,"Strin|
00000220  67 4c 69 62 2d 53 6f 66  74 22 3a 2a 53 54 45 52  |gLib-Soft":*STER|
00000230  45 4f 20 32 20 2d 31 32  37 0d 00 8c 28 20 c8 a1  |EO 2 -127...( ..|
00000240  20 33 2c 22 53 74 72 69  6e 67 4c 69 62 2d 53 6f  | 3,"StringLib-So|
00000250  66 74 22 3a 2a 53 54 45  52 45 4f 20 33 20 31 32  |ft":*STEREO 3 12|
00000260  37 0d 00 96 3a 20 63 75  72 72 65 6e 74 3d 30 3a  |7...: current=0:|
00000270  de 62 61 6c 6c 28 34 2c  31 29 3a 62 62 78 3d 36  |.ball(4,1):bbx=6|
00000280  34 30 3a 62 62 79 3d 39  35 30 3a 64 69 72 3d 32  |40:bby=950:dir=2|
00000290  37 30 3a f2 73 65 74 75  70 62 62 0d 00 a0 25 20  |70:.setupbb...% |
000002a0  eb 31 32 3a e7 20 74 79  70 65 24 3d 22 31 22 20  |.12:. type$="1" |
000002b0  8c 20 c8 97 20 ee 3a f2  64 72 61 77 66 75 6c 6c  |. .. .:.drawfull|
000002c0  0d 00 aa 45 20 e7 20 74  79 70 65 24 3d 22 32 22  |...E . type$="2"|
000002d0  20 8c 20 73 74 61 72 74  3d 91 3a 73 74 61 67 65  | . start=.:stage|
000002e0  3d 30 3a 69 64 6c 65 3d  a3 3a e8 22 46 69 6c 65  |=0:idle=.:."File|
000002f0  6e 61 6d 65 22 3b 66 24  3a ff 22 53 50 4f 4f 4c  |name";f$:."SPOOL|
00000300  20 22 2b 66 24 0d 00 b4  67 20 e7 20 74 79 70 65  | "+f$...g . type|
00000310  24 3d 22 33 22 20 8c 20  f1 22 45 6e 74 65 72 20  |$="3" . ."Enter |
00000320  44 61 74 61 3a 22 27 3a  e3 62 3d 30 b8 34 3a f1  |Data:"':.b=0.4:.|
00000330  22 42 61 6c 6c 20 22 3b  62 2b 31 3b 3a e8 62 61  |"Ball ";b+1;:.ba|
00000340  6c 6c 28 62 2c 30 29 2c  62 61 6c 6c 28 62 2c 31  |ll(b,0),ball(b,1|
00000350  29 3a ed 3a 74 79 70 65  24 3d 22 31 22 3a c8 97  |):.:type$="1":..|
00000360  20 ee 3a f2 64 72 61 77  66 75 6c 6c 0d 00 be 06  | .:.drawfull....|
00000370  20 3a 0d 00 c8 16 20 f4  20 53 74 61 72 74 20 6d  | :.... . Start m|
00000380  61 69 6e 20 6c 6f 6f 70  0d 00 d2 0a 20 f5 3a 54  |ain loop.... .:T|
00000390  3d 91 0d 00 dc 23 20 e7  20 74 79 70 65 24 3d 22  |=....# . type$="|
000003a0  31 22 20 8c 20 f2 75 73  65 72 20 8b 20 f2 63 6f  |1" . .user . .co|
000003b0  6d 70 6d 6f 6e 0d 00 e6  11 20 e7 20 69 64 6c 65  |mpmon.... . idle|
000003c0  20 8c 20 fd 20 a3 0d 00  f0 0b 20 f2 73 65 6e 73  | . . ..... .sens|
000003d0  65 0d 00 fa 1f 20 6d 6f  76 3d a4 61 69 28 66 72  |e.... mov=.ai(fr|
000003e0  65 71 61 2c 66 72 65 71  62 2c 66 72 65 71 63 29  |eqa,freqb,freqc)|
000003f0  0d 01 04 15 20 66 77 64  3d 28 6d 6f 76 20 80 20  |.... fwd=(mov . |
00000400  31 29 3c 3e 30 0d 01 0e  19 20 72 65 76 65 72 73  |1)<>0.... revers|
00000410  65 3d 28 6d 6f 76 20 80  20 32 29 3c 3e 30 0d 01  |e=(mov . 2)<>0..|
00000420  18 16 20 6c 65 66 74 3d  28 6d 6f 76 20 80 20 34  |.. left=(mov . 4|
00000430  29 3c 3e 30 0d 01 22 17  20 72 69 67 68 74 3d 28  |)<>0..". right=(|
00000440  6d 6f 76 20 80 20 38 29  3c 3e 30 0d 01 2c 18 20  |mov . 8)<>0..,. |
00000450  74 75 72 62 6f 3d 28 6d  6f 76 20 80 20 31 36 29  |turbo=(mov . 16)|
00000460  3c 3e 30 0d 01 36 17 20  6f 70 65 6e 3d 28 6d 6f  |<>0..6. open=(mo|
00000470  76 20 80 20 33 32 29 3c  3e 30 0d 01 40 0c 20 f2  |v . 32)<>0..@. .|
00000480  6d 6f 76 65 69 74 0d 01  4a 11 20 f5 20 fd 20 91  |moveit..J. . . .|
00000490  3e 28 54 2b 31 35 29 0d  01 54 08 20 fd 20 a3 0d  |>(T+15)..T. . ..|
000004a0  01 5e 06 20 3a 0d 01 68  18 20 f4 20 47 72 61 70  |.^. :..h. . Grap|
000004b0  68 69 63 20 69 6e 74 65  72 66 61 63 65 0d 01 72  |hic interface..r|
000004c0  0f 20 dd f2 64 72 61 77  66 75 6c 6c 0d 01 7c 17  |. ..drawfull..|.|
000004d0  20 f4 20 53 65 74 20 75  70 20 63 6f 6e 73 74 61  | . Set up consta|
000004e0  6e 74 73 0d 01 86 11 20  ea 73 78 2c 73 79 2c 77  |nts.... .sx,sy,w|
000004f0  69 64 74 68 0d 01 90 17  20 73 78 3d 31 3a 73 79  |idth.... sx=1:sy|
00000500  3d 32 3a 77 69 64 74 68  3d 31 30 0d 01 9a 14 20  |=2:width=10.... |
00000510  f4 20 53 65 74 75 70 20  43 6f 6c 6f 75 72 73 0d  |. Setup Colours.|
00000520  01 a4 56 20 fb 30 2c 30  2c 36 34 2c 30 3a fb 31  |..V .0,0,64,0:.1|
00000530  2c 32 35 35 2c 30 2c 30  3a fb 32 2c 32 35 35 2c  |,255,0,0:.2,255,|
00000540  32 35 35 2c 32 35 35 3a  fb 33 2c 32 35 35 2c 30  |255,255:.3,255,0|
00000550  2c 30 3a fb 34 2c 32 35  35 2c 32 35 35 2c 30 3a  |,0:.4,255,255,0:|
00000560  fb 35 2c 30 2c 30 2c 30  3a fb 36 2c 32 35 35 2c  |.5,0,0,0:.6,255,|
00000570  32 35 35 2c 30 0d 01 ae  06 20 3a 0d 01 b8 1c 20  |255,0.... :.... |
00000580  f4 20 44 72 61 77 20 67  72 65 65 6e 20 63 6f 75  |. Draw green cou|
00000590  72 74 20 61 72 65 61 0d  01 c2 1f 20 db 3a e6 30  |rt area.... .:.0|
000005a0  2c 30 3a c8 93 20 c8 90  20 30 2c 30 2c 31 32 37  |,0:.. .. 0,0,127|
000005b0  39 2c 31 30 32 33 0d 01  cc 26 20 f4 20 4d 61 72  |9,1023...& . Mar|
000005c0  6b 20 6f 75 74 20 77 68  69 74 65 20 6c 69 6e 65  |k out white line|
000005d0  73 20 6f 6e 74 6f 20 63  6f 75 72 74 0d 01 d6 ac  |s onto court....|
000005e0  20 e6 30 2c 32 3a c8 93  20 c8 90 20 73 78 2f 28  | .0,2:.. .. sx/(|
000005f0  32 33 2e 37 37 2b 32 2a  73 78 29 2a 31 32 38 30  |23.77+2*sx)*1280|
00000600  2c 73 79 2f 28 31 30 2e  39 37 2b 32 2a 73 79 29  |,sy/(10.97+2*sy)|
00000610  2a 31 30 32 34 2c 32 33  2e 37 37 2f 28 32 33 2e  |*1024,23.77/(23.|
00000620  37 37 2b 32 2a 73 78 29  2a 31 32 38 30 2c 77 69  |77+2*sx)*1280,wi|
00000630  64 74 68 3a c8 93 20 c8  90 20 73 78 2f 28 32 33  |dth:.. .. sx/(23|
00000640  2e 37 37 2b 32 2a 73 78  29 2a 31 32 38 30 2c 28  |.77+2*sx)*1280,(|
00000650  31 2e 33 37 2b 73 79 29  2f 28 31 30 2e 39 37 2b  |1.37+sy)/(10.97+|
00000660  32 2a 73 79 29 2a 31 30  32 34 2c 32 33 2e 37 37  |2*sy)*1024,23.77|
00000670  2f 28 32 33 2e 37 37 2b  32 2a 73 78 29 2a 31 32  |/(23.77+2*sx)*12|
00000680  38 30 2c 77 69 64 74 68  0d 01 e0 ae 20 c8 93 20  |80,width.... .. |
00000690  c8 90 20 73 78 2f 28 32  33 2e 37 37 2b 32 2a 73  |.. sx/(23.77+2*s|
000006a0  78 29 2a 31 32 38 30 2c  28 39 2e 36 2b 73 79 29  |x)*1280,(9.6+sy)|
000006b0  2f 28 31 30 2e 39 37 2b  32 2a 73 79 29 2a 31 30  |/(10.97+2*sy)*10|
000006c0  32 34 2c 32 33 2e 37 37  2f 28 32 33 2e 37 37 2b  |24,23.77/(23.77+|
000006d0  32 2a 73 78 29 2a 31 32  38 30 2c 77 69 64 74 68  |2*sx)*1280,width|
000006e0  3a c8 93 20 c8 90 20 73  78 2f 28 32 33 2e 37 37  |:.. .. sx/(23.77|
000006f0  2b 32 2a 73 78 29 2a 31  32 38 30 2c 28 31 30 2e  |+2*sx)*1280,(10.|
00000700  39 37 2b 73 79 29 2f 28  31 30 2e 39 37 2b 32 2a  |97+sy)/(10.97+2*|
00000710  73 79 29 2a 31 30 32 34  2c 32 33 2e 37 37 2f 28  |sy)*1024,23.77/(|
00000720  32 33 2e 37 37 2b 32 2a  73 78 29 2a 31 32 38 30  |23.77+2*sx)*1280|
00000730  2c 77 69 64 74 68 0d 01  ea 5f 20 c8 93 20 c8 90  |,width..._ .. ..|
00000740  20 28 73 78 2b 35 2e 34  37 29 2f 28 32 33 2e 37  | (sx+5.47)/(23.7|
00000750  37 2b 32 2a 73 78 29 2a  31 32 38 30 2c 28 73 79  |7+2*sx)*1280,(sy|
00000760  2b 35 2e 34 39 29 2f 28  31 30 2e 39 37 2b 32 2a  |+5.49)/(10.97+2*|
00000770  73 79 29 2a 31 30 32 34  2c 31 32 2e 38 2f 28 32  |sy)*1024,12.8/(2|
00000780  33 2e 37 37 2b 32 2a 73  78 29 2a 31 32 38 30 2c  |3.77+2*sx)*1280,|
00000790  77 69 64 74 68 0d 01 f4  ae 20 c8 93 20 c8 90 20  |width.... .. .. |
000007a0  73 78 2f 28 32 33 2e 37  37 2b 32 2a 73 78 29 2a  |sx/(23.77+2*sx)*|
000007b0  31 32 38 30 2c 73 79 2f  28 31 30 2e 39 37 2b 32  |1280,sy/(10.97+2|
000007c0  2a 73 79 29 2a 31 30 32  34 2c 77 69 64 74 68 2c  |*sy)*1024,width,|
000007d0  31 30 2e 39 37 2f 28 31  30 2e 39 37 2b 32 2a 73  |10.97/(10.97+2*s|
000007e0  79 29 2a 31 30 32 34 3a  c8 93 20 c8 90 20 28 73  |y)*1024:.. .. (s|
000007f0  78 2b 32 33 2e 37 37 29  2f 28 32 33 2e 37 37 2b  |x+23.77)/(23.77+|
00000800  32 2a 73 78 29 2a 31 32  38 30 2c 73 79 2f 28 31  |2*sx)*1280,sy/(1|
00000810  30 2e 39 37 2b 32 2a 73  79 29 2a 31 30 32 34 2c  |0.97+2*sy)*1024,|
00000820  77 69 64 74 68 2c 31 30  2e 39 37 2f 28 31 30 2e  |width,10.97/(10.|
00000830  39 37 2b 32 2a 73 79 29  2a 31 30 32 34 2b 77 69  |97+2*sy)*1024+wi|
00000840  64 74 68 0d 01 fe ba 20  c8 93 20 c8 90 20 28 73  |dth.... .. .. (s|
00000850  78 2b 35 2e 34 37 29 2f  28 32 33 2e 37 37 2b 32  |x+5.47)/(23.77+2|
00000860  2a 73 78 29 2a 31 32 38  30 2c 28 73 79 2b 31 2e  |*sx)*1280,(sy+1.|
00000870  33 37 29 2f 28 31 30 2e  39 37 2b 32 2a 73 79 29  |37)/(10.97+2*sy)|
00000880  2a 31 30 32 34 2c 77 69  64 74 68 2c 38 2e 32 33  |*1024,width,8.23|
00000890  2f 28 31 30 2e 39 37 2b  32 2a 73 79 29 2a 31 30  |/(10.97+2*sy)*10|
000008a0  32 34 3a c8 93 20 c8 90  20 28 73 78 2b 31 38 2e  |24:.. .. (sx+18.|
000008b0  33 29 2f 28 32 33 2e 37  37 2b 32 2a 73 78 29 2a  |3)/(23.77+2*sx)*|
000008c0  31 32 38 30 2c 28 73 79  2b 31 2e 33 37 29 2f 28  |1280,(sy+1.37)/(|
000008d0  31 30 2e 39 37 2b 32 2a  73 79 29 2a 31 30 32 34  |10.97+2*sy)*1024|
000008e0  2c 77 69 64 74 68 2c 38  2e 32 33 2f 28 31 30 2e  |,width,8.23/(10.|
000008f0  39 37 2b 32 2a 73 79 29  2a 31 30 32 34 0d 02 08  |97+2*sy)*1024...|
00000900  06 20 3a 0d 02 12 0f 20  f4 20 44 72 61 77 20 6e  |. :.... . Draw n|
00000910  65 74 0d 02 1c 89 20 e6  30 2c 35 3a e3 6c 3d 31  |et.... .0,5:.l=1|
00000920  30 30 b8 39 32 34 88 31  30 3a ec 20 36 34 30 2c  |00.924.10:. 640,|
00000930  6c 3a df 20 36 38 30 2c  6c 2b 35 30 3a ed 3a e3  |l:. 680,l+50:.:.|
00000940  6c 3d 30 b8 34 30 88 31  30 3a ec 20 36 34 30 2b  |l=0.40.10:. 640+|
00000950  6c 2c 31 30 30 2b 6c 3a  df 36 34 30 2b 6c 2c 39  |l,100+l:.640+l,9|
00000960  32 34 2b 6c 3a ed 3a e3  6c 3d 30 b8 35 3a ec 36  |24+l:.:.l=0.5:.6|
00000970  33 37 2b 6c 2c 31 30 30  3a df 36 37 37 2b 6c 2c  |37+l,100:.677+l,|
00000980  31 35 30 3a ec 36 33 37  2b 6c 2c 39 32 34 3a df  |150:.637+l,924:.|
00000990  36 37 37 2b 6c 2c 39 37  34 3a ed 0d 02 26 1c 20  |677+l,974:...&. |
000009a0  e6 30 2c 32 3a ec 20 36  38 32 2c 31 34 32 3a df  |.0,2:. 682,142:.|
000009b0  36 38 32 2c 39 36 36 0d  02 30 0e 20 f2 64 72 61  |682,966..0. .dra|
000009c0  77 6d 69 6e 69 0d 02 3a  06 20 e1 0d 02 44 06 20  |wmini..:. ...D. |
000009d0  3a 0d 02 4e 1d 20 f4 20  44 72 61 77 20 62 61 6c  |:..N. . Draw bal|
000009e0  6c 62 6f 74 20 61 6e 64  20 62 61 6c 6c 73 0d 02  |lbot and balls..|
000009f0  58 0f 20 dd f2 64 72 61  77 6d 69 6e 69 0d 02 62  |X. ..drawmini..b|
00000a00  14 20 e7 20 74 79 70 65  24 3d 22 32 22 20 8c 20  |. . type$="2" . |
00000a10  e1 0d 02 6c 10 20 e6 33  2c 34 3a e3 62 3d 30 b8  |...l. .3,4:.b=0.|
00000a20  34 0d 02 76 42 20 e7 20  62 61 6c 6c 28 62 2c 30  |4..vB . ball(b,0|
00000a30  29 3c 3e 30 20 84 20 62  61 6c 6c 28 62 2c 31 29  |)<>0 . ball(b,1)|
00000a40  3c 3e 30 20 8c 20 c8 93  20 c8 90 20 62 61 6c 6c  |<>0 . .. .. ball|
00000a50  28 62 2c 30 29 2c 62 61  6c 6c 28 62 2c 31 29 2c  |(b,0),ball(b,1),|
00000a60  35 2c 35 0d 02 80 06 20  ed 0d 02 8a 1b 20 e6 33  |5,5.... ..... .3|
00000a70  2c 33 3a c8 93 20 c8 90  20 62 62 78 2c 62 62 79  |,3:.. .. bbx,bby|
00000a80  2c 35 2c 35 0d 02 94 06  20 e1 0d 02 9e 06 20 3a  |,5,5.... ..... :|
00000a90  0d 02 a8 2a 20 f4 20 55  73 65 72 20 69 6e 74 65  |...* . User inte|
00000aa0  72 66 61 63 65 20 28 70  75 74 74 69 6e 67 20 62  |rface (putting b|
00000ab0  61 6c 6c 73 20 64 6f 77  6e 29 0d 02 b2 0b 20 dd  |alls down).... .|
00000ac0  f2 75 73 65 72 0d 02 bc  0d 20 c8 97 20 78 2c 79  |.user.... .. x,y|
00000ad0  2c 63 0d 02 c6 0e 20 e7  20 63 3d 30 20 8c 20 e1  |,c.... . c=0 . .|
00000ae0  0d 02 d0 61 20 e7 20 28  63 20 80 20 34 29 3c 3e  |...a . (c . 4)<>|
00000af0  30 20 8c 20 f2 64 72 61  77 6d 69 6e 69 3a 62 61  |0 . .drawmini:ba|
00000b00  6c 6c 28 63 75 72 72 65  6e 74 2c 30 29 3d 78 3a  |ll(current,0)=x:|
00000b10  62 61 6c 6c 28 63 75 72  72 65 6e 74 2c 31 29 3d  |ball(current,1)=|
00000b20  79 3a 63 75 72 72 65 6e  74 3d 28 63 75 72 72 65  |y:current=(curre|
00000b30  6e 74 2b 31 29 83 35 3a  f2 64 72 61 77 6d 69 6e  |nt+1).5:.drawmin|
00000b40  69 0d 02 da 2a 20 e7 20  28 63 20 80 20 32 29 3c  |i...* . (c . 2)<|
00000b50  3e 30 20 8c 20 69 64 6c  65 3d a3 3a 73 74 61 67  |>0 . idle=.:stag|
00000b60  65 3d 30 3a 73 74 61 72  74 3d 91 0d 02 e4 06 20  |e=0:start=..... |
00000b70  f5 0d 02 ee 0d 20 c8 97  20 78 2c 79 2c 63 0d 02  |..... .. x,y,c..|
00000b80  f8 0a 20 fd 20 63 3d 30  0d 03 02 06 20 e1 0d 03  |.. . c=0.... ...|
00000b90  0c 06 20 3a 0d 03 16 27  20 f4 20 43 61 6c 63 75  |.. :...' . Calcu|
00000ba0  6c 61 74 65 20 62 61 6c  6c 62 6f 74 27 73 20 6e  |late ballbot's n|
00000bb0  65 77 20 70 6f 73 69 74  69 6f 6e 0d 03 20 0d 20  |ew position.. . |
00000bc0  dd f2 6d 6f 76 65 69 74  0d 03 2a 41 20 e7 20 28  |..moveit..*A . (|
00000bd0  6c 65 66 74 20 80 20 66  77 64 29 20 84 20 28 72  |left . fwd) . (r|
00000be0  69 67 68 74 20 80 20 72  65 76 65 72 73 65 29 20  |ight . reverse) |
00000bf0  8c 20 64 69 72 3d 64 69  72 2d 32 2e 35 2a 28 31  |. dir=dir-2.5*(1|
00000c00  2d 33 2a 74 75 72 62 6f  29 0d 03 34 41 20 e7 20  |-3*turbo)..4A . |
00000c10  28 72 69 67 68 74 20 80  20 66 77 64 29 20 84 20  |(right . fwd) . |
00000c20  28 6c 65 66 74 20 80 20  72 65 76 65 72 73 65 29  |(left . reverse)|
00000c30  20 8c 20 64 69 72 3d 64  69 72 2b 32 2e 35 2a 28  | . dir=dir+2.5*(|
00000c40  31 2d 33 2a 74 75 72 62  6f 29 0d 03 3e 06 20 3a  |1-3*turbo)..>. :|
00000c50  0d 03 48 29 20 f4 20 47  65 74 20 64 69 72 65 63  |..H) . Get direc|
00000c60  74 69 6f 6e 20 69 6e 20  72 61 6e 67 65 20 30 3c  |tion in range 0<|
00000c70  74 68 65 74 61 3c 33 36  30 0d 03 52 1c 20 f5 20  |theta<360..R. . |
00000c80  e7 20 64 69 72 3c 30 20  8c 20 64 69 72 3d 64 69  |. dir<0 . dir=di|
00000c90  72 2b 33 36 30 0d 03 5c  1d 20 e7 20 64 69 72 3e  |r+360..\. . dir>|
00000ca0  3d 33 36 30 20 8c 20 64  69 72 3d 64 69 72 2d 33  |=360 . dir=dir-3|
00000cb0  36 30 0d 03 66 17 20 fd  20 64 69 72 3e 3d 30 20  |60..f. . dir>=0 |
00000cc0  80 20 64 69 72 3c 33 36  30 0d 03 70 06 20 3a 0d  |. dir<360..p. :.|
00000cd0  03 7a 1c 20 66 72 3d 30  3a e7 20 66 77 64 20 8c  |.z. fr=0:. fwd .|
00000ce0  20 66 72 3d 66 72 2b 30  2e 32 35 0d 03 84 1b 20  | fr=fr+0.25.... |
00000cf0  e7 20 72 65 76 65 72 73  65 20 8c 20 66 72 3d 66  |. reverse . fr=f|
00000d00  72 2d 30 2e 32 35 0d 03  8e 16 20 e7 20 74 75 72  |r-0.25.... . tur|
00000d10  62 6f 20 8c 20 66 72 3d  66 72 2a 34 0d 03 98 29  |bo . fr=fr*4...)|
00000d20  20 f2 64 72 61 77 6d 69  6e 69 3a 62 62 78 3d 62  | .drawmini:bbx=b|
00000d30  62 78 2b 31 36 2a b5 28  af 2a 64 69 72 2f 31 38  |bx+16*.(.*dir/18|
00000d40  30 29 2a 66 72 0d 03 a2  1f 20 62 62 79 3d 62 62  |0)*fr.... bby=bb|
00000d50  79 2b 31 36 2a 9b 28 af  2a 64 69 72 2f 31 38 30  |y+16*.(.*dir/180|
00000d60  29 2a 66 72 0d 03 ac 58  20 e3 62 61 6c 6c 3d 30  |)*fr...X .ball=0|
00000d70  b8 34 3a e7 20 6f 70 65  6e 20 80 20 94 28 62 62  |.4:. open . .(bb|
00000d80  78 2d 62 61 6c 6c 28 62  61 6c 6c 2c 30 29 29 3c  |x-ball(ball,0))<|
00000d90  31 30 20 80 20 94 28 62  62 79 2d 62 61 6c 6c 28  |10 . .(bby-ball(|
00000da0  62 61 6c 6c 2c 31 29 29  3c 31 30 20 8c 20 62 61  |ball,1))<10 . ba|
00000db0  6c 6c 28 62 61 6c 6c 2c  30 29 3d 30 0d 03 b6 10  |ll(ball,0)=0....|
00000dc0  20 ed 3a f2 64 72 61 77  6d 69 6e 69 0d 03 c0 06  | .:.drawmini....|
00000dd0  20 e1 0d 03 ca 06 20 3a  0d 03 d4 3b 20 f4 20 43  | ..... :...; . C|
00000de0  61 6c 63 75 6c 61 74 65  20 62 61 6c 6c 62 6f 74  |alculate ballbot|
00000df0  27 73 20 62 61 63 6b 67  72 6f 75 6e 64 20 65 63  |'s background ec|
00000e00  68 6f 20 72 65 61 64 69  6e 67 20 28 2d 62 61 6c  |ho reading (-bal|
00000e10  6c 73 29 0d 03 de 19 20  dd a4 62 61 63 6b 28 66  |ls).... ..back(f|
00000e20  72 65 71 2c 6d 69 6e 2c  6d 61 78 29 0d 03 e8 34  |req,min,max)...4|
00000e30  20 e7 20 6d 69 6e 3c 30  20 8c 20 6d 69 6e 3d 6d  | . min<0 . min=m|
00000e40  69 6e 2b 33 36 30 20 8b  20 e7 20 6d 69 6e 3e 33  |in+360 . . min>3|
00000e50  36 30 20 8c 20 6d 69 6e  3d 6d 69 6e 2d 33 36 30  |60 . min=min-360|
00000e60  0d 03 f2 34 20 e7 20 6d  61 78 3c 30 20 8c 20 6d  |...4 . max<0 . m|
00000e70  61 78 3d 6d 61 78 2b 33  36 30 20 8b 20 e7 20 6d  |ax=max+360 . . m|
00000e80  61 78 3e 33 36 30 20 8c  20 6d 61 78 3d 6d 61 78  |ax>360 . max=max|
00000e90  2d 33 36 30 0d 03 fc 1c  20 ea 20 68 69 74 2c 64  |-360.... . hit,d|
00000ea0  69 73 74 3a 68 69 74 3d  30 3a 64 69 73 74 3d 30  |ist:hit=0:dist=0|
00000eb0  0d 04 06 b6 20 e7 20 28  62 62 78 3c 36 34 30 20  |.... . (bbx<640 |
00000ec0  80 20 28 6d 69 6e 3c 3d  39 30 20 80 20 6d 61 78  |. (min<=90 . max|
00000ed0  3e 3d 39 30 20 80 20 6d  69 6e 3c 6d 61 78 29 84  |>=90 . min<max).|
00000ee0  28 6d 61 78 3c 3d 39 30  20 80 20 6d 69 6e 3e 3d  |(max<=90 . min>=|
00000ef0  39 30 20 80 20 6d 61 78  3c 6d 69 6e 29 29 20 84  |90 . max<min)) .|
00000f00  20 28 62 62 78 3e 36 34  30 20 80 20 28 6d 69 6e  | (bbx>640 . (min|
00000f10  3c 3d 32 37 30 20 80 20  6d 61 78 3e 3d 32 37 30  |<=270 . max>=270|
00000f20  20 80 20 6d 69 6e 3c 6d  61 78 29 84 28 6d 61 78  | . min<max).(max|
00000f30  3c 3d 32 37 30 20 80 20  6d 69 6e 3e 3d 32 37 30  |<=270 . min>=270|
00000f40  20 80 20 6d 61 78 3c 6d  69 6e 29 29 20 8c 20 68  | . max<min)) . h|
00000f50  69 74 3d 62 62 79 3a 64  69 73 74 3d 94 28 62 62  |it=bby:dist=.(bb|
00000f60  78 2d 36 34 30 29 0d 04  10 91 20 e7 20 68 69 74  |x-640).... . hit|
00000f70  3d 30 20 80 20 94 28 28  6d 69 6e 2b 31 38 30 2a  |=0 . .((min+180*|
00000f80  28 62 62 78 3e 36 34 30  29 29 2d 39 30 29 3c 94  |(bbx>640))-90)<.|
00000f90  28 28 6d 61 78 2b 31 38  30 2a 28 62 62 78 3e 36  |((max+180*(bbx>6|
00000fa0  34 30 29 29 2d 39 30 29  20 80 20 b5 28 af 2a 6d  |40))-90) . .(.*m|
00000fb0  69 6e 2f 31 38 30 29 3c  3e 30 20 8c 20 64 69 73  |in/180)<>0 . dis|
00000fc0  74 3d 28 36 34 30 2d 62  62 78 29 2f b5 28 af 2a  |t=(640-bbx)/.(.*|
00000fd0  6d 69 6e 2f 31 38 30 29  3a 68 69 74 3d 28 36 34  |min/180):hit=(64|
00000fe0  30 2d 62 62 78 29 2f b7  28 af 2a 6d 69 6e 2f 31  |0-bbx)/.(.*min/1|
00000ff0  38 30 29 2b 62 62 79 0d  04 1a 91 20 e7 20 68 69  |80)+bby.... . hi|
00001000  74 3d 30 20 80 20 94 28  28 6d 69 6e 2b 31 38 30  |t=0 . .((min+180|
00001010  2a 28 62 62 78 3e 36 34  30 29 29 2d 39 30 29 3e  |*(bbx>640))-90)>|
00001020  94 28 28 6d 61 78 2b 31  38 30 2a 28 62 62 78 3e  |.((max+180*(bbx>|
00001030  36 34 30 29 29 2d 39 30  29 20 80 20 b5 28 af 2a  |640))-90) . .(.*|
00001040  6d 69 6e 2f 31 38 30 29  3c 3e 30 20 8c 20 64 69  |min/180)<>0 . di|
00001050  73 74 3d 28 36 34 30 2d  62 62 78 29 2f b5 28 af  |st=(640-bbx)/.(.|
00001060  2a 6d 61 78 2f 31 38 30  29 3a 68 69 74 3d 28 36  |*max/180):hit=(6|
00001070  34 30 2d 62 62 78 29 2f  b7 28 af 2a 6d 61 78 2f  |40-bbx)/.(.*max/|
00001080  31 38 30 29 2b 62 62 79  0d 04 24 3b 20 e7 20 68  |180)+bby..$; . h|
00001090  69 74 3e 39 32 33 20 84  20 68 69 74 3c 31 30 30  |it>923 . hit<100|
000010a0  20 84 20 64 69 73 74 3c  30 20 8c 20 66 74 79 70  | . dist<0 . ftyp|
000010b0  65 24 3d 22 55 22 3a 3d  66 72 65 71 2b b3 28 36  |e$="U":=freq+.(6|
000010c0  29 2d 33 0d 04 2e 2b 20  e7 20 68 69 74 3e 39 30  |)-3...+ . hit>90|
000010d0  30 20 84 20 68 69 74 3c  31 32 33 20 8c 20 66 74  |0 . hit<123 . ft|
000010e0  79 70 65 24 3d 22 50 22  3a 3d 64 69 73 74 0d 04  |ype$="P":=dist..|
000010f0  38 0f 20 66 74 79 70 65  24 3d 22 4e 22 0d 04 42  |8. ftype$="N"..B|
00001100  0a 20 3d 64 69 73 74 0d  04 4c 06 20 3a 0d 04 56  |. =dist..L. :..V|
00001110  32 20 f4 20 43 61 6c 63  75 6c 61 74 65 20 42 61  |2 . Calculate Ba|
00001120  6c 6c 62 6f 74 27 73 20  72 65 61 64 69 6e 67 73  |llbot's readings|
00001130  20 28 4d 41 49 4e 20 52  4f 55 54 49 4e 45 29 0d  | (MAIN ROUTINE).|
00001140  04 60 06 20 3a 0d 04 6a  0c 20 dd f2 73 65 6e 73  |.`. :..j. ..sens|
00001150  65 0d 04 74 2a 20 f4 20  47 65 74 20 62 61 63 6b  |e..t* . Get back|
00001160  67 72 6f 75 6e 64 20 72  65 61 64 69 6e 67 73 20  |ground readings |
00001170  66 72 6f 6d 20 46 4e 62  61 63 6b 0d 04 7e 15 20  |from FNback..~. |
00001180  66 72 65 71 3d b3 28 32  35 30 29 2b 31 35 30 30  |freq=.(250)+1500|
00001190  0d 04 88 2f 20 66 72 65  71 61 3d a4 62 61 63 6b  |.../ freqa=.back|
000011a0  28 66 72 65 71 2c 64 69  72 2d 31 35 2c 64 69 72  |(freq,dir-15,dir|
000011b0  2b 31 35 29 3a 66 61 24  3d 66 74 79 70 65 24 0d  |+15):fa$=ftype$.|
000011c0  04 92 2f 20 66 72 65 71  62 3d a4 62 61 63 6b 28  |../ freqb=.back(|
000011d0  66 72 65 71 2c 64 69 72  2d 34 35 2c 64 69 72 2d  |freq,dir-45,dir-|
000011e0  31 35 29 3a 66 62 24 3d  66 74 79 70 65 24 0d 04  |15):fb$=ftype$..|
000011f0  9c 2f 20 66 72 65 71 63  3d a4 62 61 63 6b 28 66  |./ freqc=.back(f|
00001200  72 65 71 2c 64 69 72 2b  31 35 2c 64 69 72 2b 34  |req,dir+15,dir+4|
00001210  35 29 3a 66 63 24 3d 66  74 79 70 65 24 0d 04 a6  |5):fc$=ftype$...|
00001220  2f 20 66 72 65 71 64 3d  a4 62 61 63 6b 28 66 72  |/ freqd=.back(fr|
00001230  65 71 2c 64 69 72 2d 39  30 2c 64 69 72 2d 34 35  |eq,dir-90,dir-45|
00001240  29 3a 66 64 24 3d 66 74  79 70 65 24 0d 04 b0 06  |):fd$=ftype$....|
00001250  20 3a 0d 04 ba 44 20 f4  20 41 64 64 20 61 6e 79  | :...D . Add any|
00001260  20 72 65 6c 65 76 61 6e  74 20 62 61 6c 6c 73 20  | relevant balls |
00001270  74 6f 20 72 65 61 64 69  6e 67 73 20 28 75 73 69  |to readings (usi|
00001280  6e 67 20 68 61 69 72 79  20 74 72 69 67 6f 6e 6f  |ng hairy trigono|
00001290  6d 65 74 72 79 29 0d 04  c4 06 20 3a 0d 04 ce 0e  |metry).... :....|
000012a0  20 e3 62 61 6c 6c 3d 30  b8 34 0d 04 d8 34 20 64  | .ball=0.4...4 d|
000012b0  25 3d b6 28 28 62 61 6c  6c 28 62 61 6c 6c 2c 30  |%=.((ball(ball,0|
000012c0  29 2d 62 62 78 29 5e 32  2b 28 62 61 6c 6c 28 62  |)-bbx)^2+(ball(b|
000012d0  61 6c 6c 2c 31 29 2d 62  62 79 29 5e 32 29 0d 04  |all,1)-bby)^2)..|
000012e0  e2 1f 20 e7 20 62 61 6c  6c 28 62 61 6c 6c 2c 30  |.. . ball(ball,0|
000012f0  29 3d 30 20 8c 20 64 25  3d 39 39 39 39 0d 04 ec  |)=0 . d%=9999...|
00001300  45 20 61 3d a4 61 6e 67  6c 65 28 62 61 6c 6c 28  |E a=.angle(ball(|
00001310  62 61 6c 6c 2c 30 29 2c  62 61 6c 6c 28 62 61 6c  |ball,0),ball(bal|
00001320  6c 2c 31 29 2c 62 62 78  2c 62 62 79 29 2d 64 69  |l,1),bbx,bby)-di|
00001330  72 3a e7 61 3e 31 38 30  20 8c 20 61 3d 61 2d 33  |r:.a>180 . a=a-3|
00001340  36 30 0d 04 f6 2c 20 e7  20 94 28 61 29 3c 31 35  |60..., . .(a)<15|
00001350  20 80 20 66 72 65 71 61  3e 64 25 20 8c 20 66 72  | . freqa>d% . fr|
00001360  65 71 61 3d 64 25 3a 66  61 24 3d 22 42 22 0d 05  |eqa=d%:fa$="B"..|
00001370  00 33 20 e7 20 61 3e 2d  34 36 20 80 20 61 3c 3d  |.3 . a>-46 . a<=|
00001380  2d 31 35 20 80 20 66 72  65 71 62 3e 64 25 20 8c  |-15 . freqb>d% .|
00001390  20 66 72 65 71 62 3d 64  25 3a 66 62 24 3d 22 42  | freqb=d%:fb$="B|
000013a0  22 0d 05 0a 31 20 e7 20  61 3e 3d 31 35 20 80 20  |"...1 . a>=15 . |
000013b0  61 3c 34 36 20 80 20 66  72 65 71 63 3e 64 25 20  |a<46 . freqc>d% |
000013c0  8c 20 66 72 65 71 63 3d  64 25 3a 66 63 24 3d 22  |. freqc=d%:fc$="|
000013d0  42 22 0d 05 14 33 20 e7  20 61 3e 2d 39 30 20 80  |B"...3 . a>-90 .|
000013e0  20 61 3c 3d 2d 34 36 20  80 20 66 72 65 71 64 3e  | a<=-46 . freqd>|
000013f0  64 25 20 8c 20 66 72 65  71 64 3d 64 25 3a 66 64  |d% . freqd=d%:fd|
00001400  24 3d 22 42 22 0d 05 1e  06 20 ed 0d 05 28 06 20  |$="B".... ...(. |
00001410  3a 0d 05 32 1b 20 f4 20  55 70 64 61 74 65 20 75  |:..2. . Update u|
00001420  73 65 72 20 64 69 73 70  6c 61 79 73 0d 05 3c 06  |ser displays..<.|
00001430  20 3a 0d 05 46 14 20 e7  20 74 79 70 65 24 3d 22  | :..F. . type$="|
00001440  32 22 20 8c 20 e1 0d 05  50 3a 20 f1 8a 30 2c 30  |2" . ...P: ..0,0|
00001450  29 a8 28 28 91 2d 73 74  61 72 74 29 2f 36 30 30  |).((.-start)/600|
00001460  30 29 3b 22 3a 22 3b 28  a8 28 28 91 2d 73 74 61  |0);":";(.((.-sta|
00001470  72 74 29 2f 31 30 30 29  83 36 30 29 3b 22 20 22  |rt)/100).60);" "|
00001480  0d 05 5a 43 20 f1 8a 30  2c 33 31 29 66 64 24 2c  |..ZC ..0,31)fd$,|
00001490  66 62 24 2c 66 61 24 2c  66 63 24 2c 73 74 61 67  |fb$,fa$,fc$,stag|
000014a0  65 2c a8 28 73 65 61 72  63 68 69 6e 67 29 2c 6c  |e,.(searching),l|
000014b0  65 66 74 2c 72 69 67 68  74 2c 6f 70 65 6e 63 74  |eft,right,openct|
000014c0  65 72 3b 0d 05 64 37 20  d4 20 31 2c 2d 31 2c 66  |er;..d7 . 1,-1,f|
000014d0  72 65 71 61 2f 34 2c 35  3a d4 20 32 2c 2d 31 2c  |reqa/4,5:. 2,-1,|
000014e0  66 72 65 71 62 2f 34 2c  35 3a d4 20 33 2c 2d 31  |freqb/4,5:. 3,-1|
000014f0  2c 66 72 65 71 63 2f 34  2c 35 0d 05 6e 06 20 e1  |,freqc/4,5..n. .|
00001500  0d 05 78 05 3a 0d 05 82  24 20 f4 20 43 61 6c 63  |..x.:...$ . Calc|
00001510  75 6c 61 74 65 20 62 65  61 72 69 6e 67 20 6f 66  |ulate bearing of|
00001520  20 42 20 66 72 6f 6d 20  41 0d 05 8c 19 20 dd a4  | B from A.... ..|
00001530  61 6e 67 6c 65 28 78 31  2c 79 31 2c 78 32 2c 79  |angle(x1,y1,x2,y|
00001540  32 29 0d 05 96 34 20 e7  20 79 32 3d 79 31 20 8c  |2)...4 . y2=y1 .|
00001550  20 61 6e 67 3d 39 30 20  8b 20 61 6e 67 3d 31 38  | ang=90 . ang=18|
00001560  30 2a 99 28 28 78 32 2d  78 31 29 2f 28 79 32 2d  |0*.((x2-x1)/(y2-|
00001570  79 31 29 29 2f af 0d 05  a0 1c 20 e7 20 28 79 32  |y1))/..... . (y2|
00001580  3e 79 31 29 20 8c 20 61  6e 67 3d 61 6e 67 2b 31  |>y1) . ang=ang+1|
00001590  38 30 0d 05 aa 1a 20 e7  20 61 6e 67 3c 30 20 8c  |80.... . ang<0 .|
000015a0  20 61 6e 67 3d 61 6e 67  2b 33 36 30 0d 05 b4 0f  | ang=ang+360....|
000015b0  20 3d 61 6e 67 20 83 20  33 36 30 0d 05 be 06 20  | =ang . 360.... |
000015c0  3a 0d 05 c8 2d 20 f4 20  43 6f 6d 70 75 74 65 72  |:...- . Computer|
000015d0  20 4d 6f 6e 69 74 6f 72  20 6f 66 20 42 61 6c 6c  | Monitor of Ball|
000015e0  42 6f 74 27 73 20 70 72  6f 67 72 65 73 73 0d 05  |Bot's progress..|
000015f0  d2 0e 20 dd f2 63 6f 6d  70 6d 6f 6e 0d 05 dc 72  |.. ..compmon...r|
00001600  20 e7 20 69 64 6c 65 20  80 20 28 62 61 6c 6c 28  | . idle . (ball(|
00001610  30 2c 30 29 3c 3e 30 20  84 20 62 61 6c 6c 28 31  |0,0)<>0 . ball(1|
00001620  2c 30 29 3c 3e 30 20 84  20 62 61 6c 6c 28 32 2c  |,0)<>0 . ball(2,|
00001630  30 29 3c 3e 30 20 84 20  62 61 6c 6c 28 33 2c 30  |0)<>0 . ball(3,0|
00001640  29 3c 3e 30 20 84 20 62  61 6c 6c 28 34 2c 30 29  |)<>0 . ball(4,0)|
00001650  3c 3e 30 29 20 8c 20 73  74 24 3d 22 46 61 69 6c  |<>0) . st$="Fail|
00001660  22 20 8b 20 73 74 24 3d  22 50 61 73 73 22 0d 05  |" . st$="Pass"..|
00001670  e6 3e 20 e7 20 69 64 6c  65 20 8c 20 f1 73 74 24  |.> . idle . .st$|
00001680  2c a8 28 28 91 2d 73 74  61 72 74 29 2f 36 30 30  |,.((.-start)/600|
00001690  30 29 3b 22 3a 22 3b 28  a8 28 28 91 2d 73 74 61  |0);":";(.((.-sta|
000016a0  72 74 29 2f 31 30 30 29  83 36 30 29 0d 05 f0 2c  |rt)/100).60)...,|
000016b0  20 e7 20 91 3e 73 74 61  72 74 2b 33 36 30 30 30  | . .>start+36000|
000016c0  20 8c 20 69 64 6c 65 3d  b9 3a f1 22 54 69 6d 65  | . idle=.:."Time|
000016d0  22 2c 22 2a 2a 2a 2a 22  0d 05 fa 3c 20 e7 62 62  |","****"...< .bb|
000016e0  78 3e 36 33 30 80 62 62  78 3c 36 35 30 80 62 62  |x>630.bbx<650.bb|
000016f0  79 3e 31 30 30 80 62 62  79 3c 39 32 33 8c 69 64  |y>100.bby<923.id|
00001700  6c 65 3d b9 3a f1 22 43  72 61 73 68 22 2c 22 2a  |le=.:."Crash","*|
00001710  2a 2a 2a 22 0d 06 04 6b  20 e7 20 69 64 6c 65 20  |***"...k . idle |
00001720  8c 20 62 62 78 3d 36 34  30 3a 62 62 79 3d 39 35  |. bbx=640:bby=95|
00001730  30 3a 64 69 72 3d 32 37  30 3a 73 74 61 67 65 3d  |0:dir=270:stage=|
00001740  30 3a f2 73 65 74 75 70  62 62 3a 73 74 61 72 74  |0:.setupbb:start|
00001750  3d 91 3a e3 62 3d 30 b8  34 3a 62 61 6c 6c 28 62  |=.:.b=0.4:ball(b|
00001760  2c 30 29 3d b3 28 31 32  38 30 29 3a 62 61 6c 6c  |,0)=.(1280):ball|
00001770  28 62 2c 31 29 3d b3 28  31 30 32 34 29 3a ed 0d  |(b,1)=.(1024):..|
00001780  06 0e af 20 e7 20 69 64  6c 65 20 8c 20 f1 22 5b  |... . idle . ."[|
00001790  22 3b 62 61 6c 6c 28 30  2c 30 29 3b 22 2c 22 3b  |";ball(0,0);",";|
000017a0  62 61 6c 6c 28 30 2c 31  29 3b 22 5d 20 5b 22 3b  |ball(0,1);"] [";|
000017b0  62 61 6c 6c 28 31 2c 30  29 3b 22 2c 22 3b 62 61  |ball(1,0);",";ba|
000017c0  6c 6c 28 31 2c 31 29 3b  22 5d 20 5b 22 3b 62 61  |ll(1,1);"] [";ba|
000017d0  6c 6c 28 32 2c 30 29 3b  22 2c 22 3b 62 61 6c 6c  |ll(2,0);",";ball|
000017e0  28 32 2c 31 29 3b 22 5d  20 5b 22 3b 62 61 6c 6c  |(2,1);"] [";ball|
000017f0  28 33 2c 30 29 3b 22 2c  22 3b 62 61 6c 6c 28 33  |(3,0);",";ball(3|
00001800  2c 31 29 3b 22 5d 20 5b  22 3b 62 61 6c 6c 28 34  |,1);"] [";ball(4|
00001810  2c 30 29 3b 22 2c 22 3b  62 61 6c 6c 28 34 2c 31  |,0);",";ball(4,1|
00001820  29 3b 22 5d 22 2c 3b 3a  69 64 6c 65 3d a3 0d 06  |);"]",;:idle=...|
00001830  18 06 20 e1 0d 06 22 06  20 3a 0d 06 2c 2a 20 f4  |.. ...". :..,* .|
00001840  20 42 41 4c 4c 42 4f 54  20 52 4f 42 4f 54 49 43  | BALLBOT ROBOTIC|
00001850  20 49 4e 54 45 4c 4c 49  47 45 4e 43 45 20 4d 4f  | INTELLIGENCE MO|
00001860  44 55 4c 45 0d 06 36 06  20 3a 0d 06 40 1c 20 dd  |DULE..6. :..@. .|
00001870  a4 61 69 28 66 72 65 71  61 2c 66 72 65 71 62 2c  |.ai(freqa,freqb,|
00001880  66 72 65 71 63 29 0d 06  4a 39 20 f4 20 41 72 74  |freqc)..J9 . Art|
00001890  69 66 69 63 69 61 6c 20  69 6e 74 65 6c 6c 69 67  |ificial intellig|
000018a0  65 6e 63 65 20 72 6f 75  74 69 6e 65 73 20 28 69  |ence routines (i|
000018b0  65 2e 20 57 68 61 74 20  4e 65 78 74 3f 3f 29 0d  |e. What Next??).|
000018c0  06 54 22 20 ea 66 77 64  2c 72 65 76 65 72 73 65  |.T" .fwd,reverse|
000018d0  2c 6c 65 66 74 2c 72 69  67 68 74 2c 74 75 72 62  |,left,right,turb|
000018e0  6f 0d 06 5e 2b 20 66 77  64 3d b9 3a 72 65 76 65  |o..^+ fwd=.:reve|
000018f0  72 73 65 3d a3 3a 6c 65  66 74 3d a3 3a 72 69 67  |rse=.:left=.:rig|
00001900  68 74 3d a3 3a 74 75 72  62 6f 3d a3 0d 06 68 06  |ht=.:turbo=...h.|
00001910  20 3a 0d 06 72 40 20 f4  20 57 68 61 74 20 73 74  | :..r@ . What st|
00001920  61 67 65 20 61 72 65 20  77 65 20 69 6e 3f 20 48  |age are we in? H|
00001930  75 6e 74 20 66 6f 72 20  62 61 6c 6c 73 20 6f 72  |unt for balls or|
00001940  20 6d 6f 76 65 20 74 6f  20 6e 65 77 20 61 72 65  | move to new are|
00001950  61 3f 0d 06 7c 27 20 e7  20 6e 65 61 72 3c 3e 30  |a?..|' . near<>0|
00001960  20 80 20 73 74 61 67 65  3c 38 20 8c 20 f2 64 6f  | . stage<8 . .do|
00001970  6e 65 61 72 73 74 75 66  66 0d 06 86 2b 20 e7 20  |nearstuff...+ . |
00001980  6e 65 61 72 3d 30 20 80  20 28 73 74 61 67 65 3d  |near=0 . (stage=|
00001990  30 20 84 20 73 74 61 67  65 3d 32 29 20 8c 20 f2  |0 . stage=2) . .|
000019a0  68 75 6e 74 0d 06 90 2e  20 e7 20 6e 65 61 72 3d  |hunt.... . near=|
000019b0  30 20 80 20 28 73 74 61  67 65 3d 31 20 84 20 73  |0 . (stage=1 . s|
000019c0  74 61 67 65 3d 33 29 20  8c 20 f2 6d 6f 76 65 6f  |tage=3) . .moveo|
000019d0  75 74 0d 06 9a 1a 20 e7  20 73 74 61 67 65 3d 34  |ut.... . stage=4|
000019e0  20 8c 20 f2 72 65 6c 65  61 73 65 62 0d 06 a4 06  | . .releaseb....|
000019f0  20 3a 0d 06 ae 32 20 f4  20 50 72 65 70 61 72 65  | :...2 . Prepare|
00001a00  20 6f 75 74 70 75 74 20  69 6e 74 6f 20 62 69 6e  | output into bin|
00001a10  61 72 79 20 66 6f 72 20  74 72 61 6e 73 6d 69 73  |ary for transmis|
00001a20  73 69 6f 6e 0d 06 b8 1f  20 66 65 65 64 3d 30 3a  |sion.... feed=0:|
00001a30  e7 20 66 77 64 20 8c 20  66 65 65 64 3d 66 65 65  |. fwd . feed=fee|
00001a40  64 2b 31 0d 06 c2 17 20  e7 20 72 65 76 69 6e 67  |d+1.... . reving|
00001a50  20 8c 20 74 75 72 62 6f  3d b9 0d 06 cc 1c 20 e7  | . turbo=..... .|
00001a60  20 72 65 76 65 72 73 65  20 8c 20 66 65 65 64 3d  | reverse . feed=|
00001a70  66 65 65 64 2b 32 0d 06  d6 19 20 e7 20 6c 65 66  |feed+2.... . lef|
00001a80  74 20 8c 20 66 65 65 64  3d 66 65 65 64 2b 34 0d  |t . feed=feed+4.|
00001a90  06 e0 1a 20 e7 20 72 69  67 68 74 20 8c 20 66 65  |... . right . fe|
00001aa0  65 64 3d 66 65 65 64 2b  38 0d 06 ea 1b 20 e7 20  |ed=feed+8.... . |
00001ab0  74 75 72 62 6f 20 8c 20  66 65 65 64 3d 66 65 65  |turbo . feed=fee|
00001ac0  64 2b 31 36 0d 06 f4 20  20 e7 20 6f 70 65 6e 63  |d+16...  . openc|
00001ad0  74 65 72 3e 30 20 8c 20  66 65 65 64 3d 66 65 65  |ter>0 . feed=fee|
00001ae0  64 2b 33 32 0d 06 fe 0a  20 3d 66 65 65 64 0d 07  |d+32.... =feed..|
00001af0  08 06 20 3a 0d 07 12 28  20 f4 20 50 65 72 66 6f  |.. :...( . Perfo|
00001b00  72 6d 20 61 20 73 77 65  65 70 20 74 6f 20 66 69  |rm a sweep to fi|
00001b10  6e 64 20 61 6e 79 20 62  61 6c 6c 73 0d 07 1c 0b  |nd any balls....|
00001b20  20 dd f2 68 75 6e 74 0d  07 26 23 20 f4 20 57 61  | ..hunt..&# . Wa|
00001b30  74 63 68 20 6f 75 74 20  69 66 20 74 6f 6f 20 6e  |tch out if too n|
00001b40  65 61 72 20 74 6f 20 6e  65 74 0d 07 30 be 20 e7  |ear to net..0. .|
00001b50  28 28 66 72 65 71 61 3c  32 30 80 20 66 61 24 3c  |((freqa<20. fa$<|
00001b60  3e 22 42 22 29 84 28 66  72 65 71 62 3c 32 30 80  |>"B").(freqb<20.|
00001b70  20 66 62 24 3c 3e 22 42  22 29 84 28 66 72 65 71  | fb$<>"B").(freq|
00001b80  63 3c 32 30 80 20 66 63  24 3c 3e 22 42 22 29 29  |c<20. fc$<>"B"))|
00001b90  84 28 72 65 76 69 6e 67  20 80 28 28 66 72 65 71  |.(reving .((freq|
00001ba0  61 3c 31 35 30 80 20 66  61 24 3c 3e 22 42 22 29  |a<150. fa$<>"B")|
00001bb0  84 28 66 72 65 71 62 3c  31 35 30 80 20 66 62 24  |.(freqb<150. fb$|
00001bc0  3c 3e 22 42 22 29 84 28  66 72 65 71 63 3c 31 35  |<>"B").(freqc<15|
00001bd0  30 80 20 66 63 24 3c 3e  22 42 22 29 29 29 8c 72  |0. fc$<>"B"))).r|
00001be0  65 76 69 6e 67 3d b9 3a  72 65 76 65 72 73 65 3d  |eving=.:reverse=|
00001bf0  b9 3a 66 77 64 3d a3 3a  6c 65 66 74 3d a3 3a 72  |.:fwd=.:left=.:r|
00001c00  69 67 68 74 3d a3 3a e1  0d 07 3a 0d 20 72 65 76  |ight=.:...:. rev|
00001c10  69 6e 67 3d a3 0d 07 44  06 20 3a 0d 07 4e 3a 20  |ing=...D. :..N: |
00001c20  f4 20 49 66 20 42 61 6c  6c 20 69 73 20 6f 75 74  |. If Ball is out|
00001c30  20 6f 66 20 72 65 61 63  68 20 69 6e 20 74 68 65  | of reach in the|
00001c40  20 22 44 22 20 73 65 63  74 6f 72 2c 20 72 65 76  | "D" sector, rev|
00001c50  65 72 73 65 21 0d 07 58  bf 20 46 44 52 3d 66 72  |erse!..X. FDR=fr|
00001c60  65 71 64 2a 31 2e 32 35  3a e7 66 72 65 71 64 3c  |eqd*1.25:.freqd<|
00001c70  31 35 30 80 66 64 24 3d  22 42 22 80 46 44 52 3c  |150.fd$="B".FDR<|
00001c80  66 72 65 71 61 20 80 46  44 52 3c 66 72 65 71 62  |freqa .FDR<freqb|
00001c90  20 80 46 44 52 3c 66 72  65 71 63 20 80 28 66 61  | .FDR<freqc .(fa|
00001ca0  24 3c 3e 22 42 22 84 66  72 65 71 61 3e 31 30 30  |$<>"B".freqa>100|
00001cb0  29 80 28 66 62 24 3c 3e  22 42 22 84 66 72 65 71  |).(fb$<>"B".freq|
00001cc0  62 3e 31 30 30 29 80 28  66 63 24 3c 3e 22 42 22  |b>100).(fc$<>"B"|
00001cd0  84 66 72 65 71 63 3e 31  30 30 29 8c 20 74 75 72  |.freqc>100). tur|
00001ce0  62 6f 3d b9 3a 72 65 76  65 72 73 65 3d b9 3a 66  |bo=.:reverse=.:f|
00001cf0  77 64 3d a3 3a 72 69 67  68 74 3d b9 3a 66 61 72  |wd=.:right=.:far|
00001d00  6c 65 66 74 3d 2d 36 2a  28 66 72 65 71 64 3e 34  |left=-6*(freqd>4|
00001d10  30 29 3a e1 0d 07 62 12  20 e7 20 66 61 72 6c 65  |0):...b. . farle|
00001d20  66 74 3e 30 20 8c 0d 07  6c 37 20 20 66 61 72 6c  |ft>0 ...l7  farl|
00001d30  65 66 74 3d 66 61 72 6c  65 66 74 2d 31 3a 72 65  |eft=farleft-1:re|
00001d40  76 65 72 73 65 3d b9 3a  66 77 64 3d a3 3a 72 69  |verse=.:fwd=.:ri|
00001d50  67 68 74 3d b9 3a 74 75  72 62 6f 3d b9 0d 07 76  |ght=.:turbo=...v|
00001d60  33 20 20 e7 20 66 61 24  3d 22 42 22 20 84 20 28  |3  . fa$="B" . (|
00001d70  66 64 24 3c 3e 22 42 22  20 80 20 66 62 24 3c 3e  |fd$<>"B" . fb$<>|
00001d80  22 42 22 29 20 8c 20 66  61 72 6c 65 66 74 3d 30  |"B") . farleft=0|
00001d90  0d 07 80 07 20 20 e1 0d  07 8a 06 20 cd 0d 07 94  |....  ..... ....|
00001da0  06 20 3a 0d 07 9e 1a 20  f4 20 52 6f 74 61 74 65  |. :.... . Rotate|
00001db0  20 74 6f 20 66 61 63 65  20 62 61 6c 6c 0d 07 a8  | to face ball...|
00001dc0  40 20 e7 20 28 66 62 24  3d 22 42 22 20 80 20 66  |@ . (fb$="B" . f|
00001dd0  72 65 71 62 3e 31 35 30  29 20 84 20 28 66 64 24  |reqb>150) . (fd$|
00001de0  3d 22 42 22 20 80 20 66  72 65 71 64 3e 31 35 30  |="B" . freqd>150|
00001df0  29 20 8c 20 74 65 6e 64  69 6e 67 3d 30 0d 07 b2  |) . tending=0...|
00001e00  26 20 e7 20 66 63 24 3d  22 42 22 20 80 20 66 72  |& . fc$="B" . fr|
00001e10  65 71 63 3e 31 35 30 20  8c 20 74 65 6e 64 69 6e  |eqc>150 . tendin|
00001e20  67 3d 31 0d 07 bc 29 20  e7 20 6f 70 65 6e 63 74  |g=1...) . openct|
00001e30  65 72 3e 30 20 8c 20 6f  70 65 6e 63 74 65 72 3d  |er>0 . opencter=|
00001e40  6f 70 65 6e 63 74 65 72  2d 31 3a e1 0d 07 c6 66  |opencter-1:....f|
00001e50  20 6f 70 65 6e 63 74 65  72 3d 2d 35 2a 28 28 28  | opencter=-5*(((|
00001e60  66 72 65 71 61 3c 32 30  29 80 66 61 24 3d 22 42  |freqa<20).fa$="B|
00001e70  22 29 84 28 28 66 72 65  71 62 3c 32 30 29 80 66  |").((freqb<20).f|
00001e80  62 24 3d 22 42 22 29 84  28 28 66 72 65 71 63 3c  |b$="B").((freqc<|
00001e90  32 30 29 80 66 63 24 3d  22 42 22 29 84 28 28 66  |20).fc$="B").((f|
00001ea0  72 65 71 64 3c 32 30 29  80 66 64 24 3d 22 42 22  |reqd<20).fd$="B"|
00001eb0  29 29 0d 07 d0 60 20 e7  20 66 61 24 3d 22 42 22  |))...` . fa$="B"|
00001ec0  20 8c 20 6c 65 66 74 3d  28 73 74 65 65 72 3d 2d  | . left=(steer=-|
00001ed0  31 29 3a 72 69 67 68 74  3d 28 73 74 65 65 72 3d  |1):right=(steer=|
00001ee0  31 29 3a 73 74 65 65 72  3d 30 3a 73 65 61 72 63  |1):steer=0:searc|
00001ef0  68 69 6e 67 3d 73 65 61  72 63 68 69 6e 67 2f 32  |hing=searching/2|
00001f00  3a 74 75 72 62 6f 3d 66  72 65 71 61 3e 31 30 30  |:turbo=freqa>100|
00001f10  3a e1 0d 07 da 2c 20 e7  20 66 62 24 3d 22 42 22  |:...., . fb$="B"|
00001f20  20 84 20 66 64 24 3d 22  42 22 20 8c 20 73 74 65  | . fd$="B" . ste|
00001f30  65 72 3d 2d 31 3a 6c 65  66 74 3d b9 3a e1 0d 07  |er=-1:left=.:...|
00001f40  e4 22 20 e7 20 66 63 24  3d 22 42 22 20 8c 20 73  |." . fc$="B" . s|
00001f50  74 65 65 72 3d 31 3a 72  69 67 68 74 3d b9 3a e1  |teer=1:right=.:.|
00001f60  0d 07 ee 30 20 f4 20 49  66 20 6e 6f 20 62 61 6c  |...0 . If no bal|
00001f70  6c 20 69 6e 20 73 69 67  68 74 2c 20 63 6f 6e 74  |l in sight, cont|
00001f80  69 6e 75 65 20 72 6f 74  61 74 69 6f 6e 2e 2e 2e  |inue rotation...|
00001f90  0d 07 f8 22 20 61 6c 69  67 6e 3d a3 3a 73 65 61  |..." align=.:sea|
00001fa0  72 63 68 69 6e 67 3d 73  65 61 72 63 68 69 6e 67  |rching=searching|
00001fb0  2b 31 0d 08 02 2a 20 e7  20 28 74 65 6e 64 69 6e  |+1...* . (tendin|
00001fc0  67 20 80 20 31 29 3c 3e  30 20 8c 20 72 69 67 68  |g . 1)<>0 . righ|
00001fd0  74 3d b9 20 8b 20 6c 65  66 74 3d b9 0d 08 0c 2a  |t=. . left=....*|
00001fe0  20 e7 20 73 65 61 72 63  68 69 6e 67 3d 35 20 8c  | . searching=5 .|
00001ff0  20 74 65 6e 64 69 6e 67  3d 28 74 65 6e 64 69 6e  | tending=(tendin|
00002000  67 20 82 20 31 29 0d 08  16 24 20 e7 20 73 65 61  |g . 1)...$ . sea|
00002010  72 63 68 69 6e 67 3e 31  35 30 20 8c 20 73 74 61  |rching>150 . sta|
00002020  67 65 3d 73 74 61 67 65  2b 31 0d 08 20 06 20 e1  |ge=stage+1.. . .|
00002030  0d 08 2a 06 20 3a 0d 08  34 3c 20 f4 20 46 69 6e  |..*. :..4< . Fin|
00002040  64 20 65 64 67 65 20 6f  66 20 6e 65 74 20 61 6e  |d edge of net an|
00002050  64 20 61 69 6d 20 66 6f  72 20 69 74 20 74 6f 20  |d aim for it to |
00002060  6d 6f 76 65 20 74 6f 20  6f 74 68 65 72 20 73 69  |move to other si|
00002070  64 65 0d 08 3e 0e 20 dd  f2 6d 6f 76 65 6f 75 74  |de..>. ..moveout|
00002080  0d 08 48 23 20 f4 20 57  61 74 63 68 20 6f 75 74  |..H# . Watch out|
00002090  20 69 66 20 74 6f 6f 20  6e 65 61 72 20 74 6f 20  | if too near to |
000020a0  6e 65 74 0d 08 52 b0 20  e7 20 28 66 72 65 71 61  |net..R. . (freqa|
000020b0  3c 33 30 20 84 20 66 72  65 71 62 3c 33 30 20 84  |<30 . freqb<30 .|
000020c0  20 66 72 65 71 63 3c 33  30 29 20 84 20 28 72 65  | freqc<30) . (re|
000020d0  76 69 6e 67 20 80 20 28  66 72 65 71 61 3c 32 35  |ving . (freqa<25|
000020e0  30 20 84 20 66 72 65 71  62 3c 32 35 30 20 84 20  |0 . freqb<250 . |
000020f0  66 72 65 71 63 3c 32 35  30 29 29 20 8c 20 72 65  |freqc<250)) . re|
00002100  76 69 6e 67 3d b9 3a 66  61 72 6c 65 66 74 3d 30  |ving=.:farleft=0|
00002110  3a 72 65 76 65 72 73 65  3d b9 3a 66 77 64 3d a3  |:reverse=.:fwd=.|
00002120  3a 72 69 67 68 74 3d a3  3a 6c 65 66 74 3d 28 66  |:right=.:left=(f|
00002130  72 65 71 61 3e 32 33 30  20 80 20 66 72 65 71 62  |reqa>230 . freqb|
00002140  3e 32 33 30 20 80 20 66  72 65 71 63 3e 32 33 30  |>230 . freqc>230|
00002150  29 3a e1 0d 08 5c 0d 20  72 65 76 69 6e 67 3d a3  |):...\. reving=.|
00002160  0d 08 66 2c 20 f4 20 41  6c 69 67 6e 20 62 61 6c  |..f, . Align bal|
00002170  6c 62 6f 74 20 74 6f 20  66 61 63 65 20 74 68 65  |lbot to face the|
00002180  20 6e 65 74 20 70 6f 73  74 2e 2e 2e 0d 08 70 24  | net post.....p$|
00002190  20 e7 20 66 61 24 3d 22  4e 22 20 84 20 66 61 24  | . fa$="N" . fa$|
000021a0  3d 22 50 22 20 8c 20 72  69 67 68 74 3d b9 3a e1  |="P" . right=.:.|
000021b0  0d 08 7a 25 20 e7 20 66  62 24 3c 3e 22 4e 22 20  |..z% . fb$<>"N" |
000021c0  80 20 66 62 24 3c 3e 22  50 22 20 8c 20 6c 65 66  |. fb$<>"P" . lef|
000021d0  74 3d b9 3a e1 0d 08 84  2d 20 e7 20 66 62 24 3d  |t=.:....- . fb$=|
000021e0  22 50 22 20 80 20 66 72  65 71 62 3c 31 35 30 20  |"P" . freqb<150 |
000021f0  8c 20 72 69 67 68 74 3d  b9 3a 6e 65 61 72 3d 31  |. right=.:near=1|
00002200  3a e1 0d 08 8e 0c 20 74  75 72 62 6f 3d b9 0d 08  |:..... turbo=...|
00002210  98 06 20 e1 0d 08 a2 06  20 3a 0d 08 ac 47 20 f4  |.. ..... :...G .|
00002220  20 4e 65 61 72 6c 79 20  74 68 65 72 65 2e 2e 2e  | Nearly there...|
00002230  20 4a 75 73 74 20 6e 65  65 64 20 61 20 6c 69 74  | Just need a lit|
00002240  74 6c 65 20 6e 75 64 67  65 20 69 6e 20 74 68 65  |tle nudge in the|
00002250  20 72 69 67 68 74 20 64  69 72 65 63 74 69 6f 6e  | right direction|
00002260  2e 0d 08 b6 12 20 dd f2  64 6f 6e 65 61 72 73 74  |..... ..donearst|
00002270  75 66 66 0d 08 c0 10 20  6e 65 61 72 3d 6e 65 61  |uff.... near=nea|
00002280  72 2b 31 0d 08 ca 1a 20  e7 20 6e 65 61 72 3c 31  |r+1.... . near<1|
00002290  36 20 8c 20 72 69 67 68  74 3d b9 3a e1 0d 08 d4  |6 . right=.:....|
000022a0  0b 20 6c 65 66 74 3d b9  0d 08 de 3b 20 e7 20 6e  |. left=....; . n|
000022b0  65 61 72 3e 33 32 20 8c  20 6e 65 61 72 3d 30 3a  |ear>32 . near=0:|
000022c0  73 74 61 67 65 3d 73 74  61 67 65 2b 31 3a 73 65  |stage=stage+1:se|
000022d0  61 72 63 68 69 6e 67 3d  30 3a 74 65 6e 64 69 6e  |arching=0:tendin|
000022e0  67 3d 31 0d 08 e8 06 20  e1 0d 08 f2 06 20 3a 0d  |g=1.... ..... :.|
000022f0  08 fc 3d 20 f4 20 49 6e  69 74 69 61 6c 69 73 65  |..= . Initialise|
00002300  20 42 61 6c 6c 42 6f 74  20 76 61 72 69 61 62 6c  | BallBot variabl|
00002310  65 73 20 61 74 20 74 68  65 20 62 65 67 69 6e 6e  |es at the beginn|
00002320  69 6e 67 20 6f 66 20 61  20 72 75 6e 0d 09 06 0e  |ing of a run....|
00002330  20 dd f2 73 65 74 75 70  62 62 0d 09 10 3f 20 72  | ..setupbb...? r|
00002340  65 76 69 6e 67 3d a3 3a  6c 65 66 74 3d a3 3a 72  |eving=.:left=.:r|
00002350  69 67 68 74 3d a3 3a 66  77 64 3d a3 3a 72 65 76  |ight=.:fwd=.:rev|
00002360  65 72 73 65 3d a3 3a 73  65 61 72 63 68 69 6e 67  |erse=.:searching|
00002370  3d 30 3a 69 64 6c 65 3d  b9 0d 09 1a 32 20 6e 65  |=0:idle=....2 ne|
00002380  61 72 3d a3 3a 66 61 72  6c 65 66 74 3d 30 3a 6f  |ar=.:farleft=0:o|
00002390  70 65 6e 63 74 65 72 3d  30 3a 74 65 6e 64 69 6e  |pencter=0:tendin|
000023a0  67 3d 31 3a 73 74 65 65  72 3d 30 0d 09 24 06 20  |g=1:steer=0..$. |
000023b0  e1 0d 09 2e 06 20 3a 0d  09 38 0f 20 dd f2 72 65  |..... :..8. ..re|
000023c0  6c 65 61 73 65 62 0d 09  42 2d 20 f4 20 47 6f 74  |leaseb..B- . Got|
000023d0  20 61 6c 6c 20 74 68 65  20 62 61 6c 6c 73 2c 20  | all the balls, |
000023e0  6e 6f 77 20 6a 75 73 74  20 64 75 6d 70 20 74 68  |now just dump th|
000023f0  65 6d 21 0d 09 4c 20 20  6e 65 61 72 3d 6e 65 61  |em!..L  near=nea|
00002400  72 2b 31 3a 72 65 76 65  72 73 65 3d b9 3a 66 77  |r+1:reverse=.:fw|
00002410  64 3d a3 0d 09 56 1d 20  e7 20 6e 65 61 72 3e 39  |d=...V. . near>9|
00002420  20 8c 20 69 64 6c 65 3d  b9 3a 6e 65 61 72 3d a3  | . idle=.:near=.|
00002430  0d 09 60 06 20 e1 0d 09  6a 44 20 f5 3a e3 58 3d  |..`. ...jD .:.X=|
00002440  31 b8 31 32 3a ff 22 43  48 41 4e 4e 45 4c 56 4f  |1.12:."CHANNELVO|
00002450  49 43 45 20 31 20 22 2b  c3 58 3a d4 31 2c 2d 31  |ICE 1 "+.X:.1,-1|
00002460  30 2c 35 32 2c 31 30 30  3a e3 52 3d 30 b8 31 30  |0,52,100:.R=0.10|
00002470  30 30 30 3a ed 2c 3a fd  20 a3 0d 09 74 06 20 3a  |000:.,:. ...t. :|
00002480  0d 09 7e 42 20 f4 20 57  68 69 7a 7a 2d 62 61 63  |..~B . Whizz-bac|
00002490  6b 20 74 6f 20 6c 69 6e  65 20 75 70 20 77 69 74  |k to line up wit|
000024a0  68 20 44 20 2d 20 77 68  61 74 20 69 66 20 77 68  |h D - what if wh|
000024b0  69 7a 7a 20 62 61 63 6b  20 69 6e 74 6f 20 6e 65  |izz back into ne|
000024c0  74 3f 0d 09 88 39 20 f4  20 52 65 76 65 72 73 65  |t?...9 . Reverse|
000024d0  20 69 66 20 42 61 6c 6c  42 6f 74 20 6b 6e 6f 77  | if BallBot know|
000024e0  73 20 74 68 61 74 20 62  61 6c 6c 73 20 61 72 65  |s that balls are|
000024f0  20 62 65 68 69 6e 64 20  69 74 2e 0d ff           | behind it...|
000024fd
BioBot/BBNew2.m0
BioBot/BBNew2.m1
BioBot/BBNew2.m2
BioBot/BBNew2.m4
BioBot/BBNew2.m5

© Dominic Ford 2021–2024.

Our privacy policy is here.
Last updated: 10 Jun 2024, 13:20 UTC
Website designed by .
