        GETFLD          General field locate routine; can locate a field in                          the header, format file or curr
ent record.
        GETFRC          Find the address of a field in the current record.
        GETXFL          Return first non-space character of a field in the A
                        register, folded to upper case if applicable.
        SETDPS          Set the address of the beginning of the current
                        record.
        CHKEOF          Check the character in the A register for an end of
                        field character.
        CHKEOR          Check the character in the A register for an end of
                        record character.
        SIZFLD          Return the size of a given field.
        CMPFLD          Compare two fields of the same type and set the
                        flags.
        SCHFLD          Return the number of a field, given its name.
        SCHFLN          Return the next field number, given a name, for an
                        ambiguous name specification.

        GETWID          Return the display width for a particular field.
        GETKYW          Return the key width for a particular field.
        CALSBN          Calculate the number of spaces required to be output
                        before a numeric field to right justify it within
                        the display width.

GETFLD

This routine locates a field in either the database header, the format file
or the current record.  If the field is in the current record, the address
of the first character of the field is set into TEMP06 and also into TEMP07.
If the field is in the format file, TEMP07 is left unaltered, and the
address of the field is put into TEMP06.

If X is equal to 255, then the routine uses the value in the Y register to
locate a record in a list of current records.  The list of records is
numbered from 0 onwards.  The usual way to use this part of the routine will
be with Y set to zero, in order to locate a field within a single current
record.  If you are using a list of records, then you must not set Y to too
high a value, so that the routine runs off the end of the list, unless you
have an end of file marker after the last record.

Before you use this routine, you must have set the position of the first
record in the list by using the SETDPS call.

On entry:               A               field number of field to locate;
                                        field start at 1.
                        X=0             find field in header record.
                        X=1 to          find field in format file record; X
                        X=254           gives the number of the format file
                                        record.
                        X=255           find field in list of current
                                        records; Y has the number of the
                                        record to search, starting at zero.
                        Y               only significant if X=255.

On exit:                CS              field or record not found; TEMP06
                                        (and TEMP07 if X=255) point to the
                                        end of record marker if field not
                                        found, the end of file marker if
                                        record not found.
                        CC              field and record found; TEMP06
                                        points to the beginning of the
                                        field; if the call was made with
                                        X=255 then TEMP07 also points to the
                                        beginning of the field.
                        A,Y             undefined.
                        X               preserved.


GETFRC

This call first sets X to 255, and then calls the GETFLD routine.  The entry
and exit conditions are as for GETFLD when X-255, except that X will always
return set to 255.


GETXFL

GETXFL returns the first non-space character in a field, folded to upper
case if alphabetic.  It is intended primarily for reading the value of
single character fields in the format file, such as the "Field type" field.

GETXFL first calls the routine GETFLD.  The entry conditions are the same as
GETFLD.  If the call to GETFLD fails, ie the Carry flag is set, then the A
register is cleared, and the routine ends.  If the field is  found, then the
first character of the field is returned, folded to upper case if
alphabetic.  If the field is blank, then the end of field marker will be
returned.

On entry:               See GETFLD

On exit:                        TEMP06 and TEMP07 set as for GETFLD.
                        CS      field or record not found, as GETFLD; A set                                  to zero.
                        CC      field found; A contains first non-space
                                character, folded to upper case if
                                alphabetic.
                        X,Y     See GETFLD.

SETDPS

This routine stores the address of the records to be used when using one of
the field locate routines with X set to 255.  It should be called whenever
the address of one of the records in the list or of one of the fields in the
records has altered.  It need not be called if none of the fields has moved,
since ViewStore will keep track of its position in the list of records, and
move backwards or forwards as necessary to find the field you have asked
for.

If you are reading records one by one using the NXTIMF call, for example,
then you must call SETDPS with their address of the record for each record
that you read: the alignment of the fields will alter for each record.

On entry:       A               contains low byte of the address of the first
                                record in the list.
                Y               contains the high byte of the address of the
                                first record in the list.

On exit:        A,X,Y           undefined.
