SECTION "EXSPIRB"
// Example program to draw a spiral using the fast integer procedures.
// The fast integer procedures are
// copyright Richards Computer Products Ltd. (C) 1983
// Written by C Jobson 22/04/83
// The program is based on the program 'SPIRAL1' in the book 'Creative
// Graphics on the BBC Microcomputer' by J Cownie published by
// Acornsoft Ltd.
NEEDS "VDU"
NEEDS "TIME"
GET "LIBHDR"
GET "FPHDR"
MANIFEST $( PI = 31416 $)
// Draws a flat spiral with palette changes giving the effect of
// movement.
LET START() BE
$( LET C = 1 // used to keep track of palette
LET A = 0 // angle
// Enter screen mode 1, hide the cursor, set the graphics origin in
// the centre of the screen and move to the origin.
UNLESS MODE(1) DO
$( WRITES("Not enough free heap space to enter*N*
*screen mode 1. Please SHUFFLE and*N*
*try again.*N")
STOP(RESULT2)
$)
VDU("5,29,640;512;25,4,0;0;")
// Enter loop to calculate next point and draw a line to it. Loop
// is performed 1500 times and increments A by 2000 each time.
// Thus with scaling of 10000 this represents A going from 0 to 300
// radians in steps of 0.2 radians.
FOR I = 0 TO 1500
$(
// Choose logical colour 1, 2 or 3 using formula corresponding
// to '1+(3.8*A REM 3)'. Note that since A is incremented by
// 0.2 (i.e. 2000) each time I is incremented by 1, I is
// equivalent to 5*A and thus the formula becomes '1+(0.76*I REM
// 3)' and 0.76 = 19/25. The factor of 3.8 makes the arms
// reasonably straight.
VDU("18,0,%", 1+( ((19*I+12)/25) REM 3) )
// Draw to next point whose coordinates are 3*A*SIN(A) and
// 2*A*COS(A). Since SIN(A) and COS(A) are scaled by 10000 use
// MULDIV with I/5 instead of A in the multiplication.
VDU("25,5,%;%;", MULDIV(SIN(A), (3*I+2)/5, 10000),
MULDIV(COS(A), (2*I+2)/5, 10000) )
// Increment A by 2000 (representing 0.2) wrapping round from pi
// to -pi.
TEST A > PI-2000 THEN
A := A+2000-(2*PI)
ELSE
A := A+2000
// Change the palette every 4th point. Use actual colours 3, 4
// and 5 (yellow, blue and magenta).
IF (I & 3) = 0 DO
$( FOR J = 1 TO 3
VDU("19,%,%;%;", J, ((C+J) REM 3)+3, 0)
C := (C+1) REM 3 // so next palette change moves colours on one
// step
$)
$)
// Wait for 5 seconds then go back to mode 7.
$( LET T = TIME()+500
IF T < 0 THEN T := T+#X8000 // compensate for wrapround
UNTIL TIME() = T LOOP
MODE(7)
$)
$)
