Examples:

Suppose you are in mode 2, and want to store the screen to a floppy. From
the table above, nnnn is 3000 and mmmm is 7FFF for mode 2. Therefore, to
save the screen under the filename "Screen", you would type:

*SAVE Screen 3000 7FFF

Now, if you want to restore the screen again, and put your graphics back
on the screen again, you would use *LOAD. Notice that this time only a
value for nnnn is required, and not for mmmm:

*LOAD Screen 3000

You can try this out now, if you switch on your Electron, and insert a work
disc into your floppy drive. If you use ADFS, you may need to use *MOUNT
to select the floppy disc, and be able to write to it. Now enter mode 2
by typing:

MODE 2

Now type some text on the screen which will represent the graphics which
you want to save. When you have finished, save the contents of screen memory
to floppy disk as shown above, by typing:

*SAVE Screen 3000 7FFF

When the disk drive has finished, clear the text off the screen by typing:

CLS

The text which you typed onto the screen has now been wiped from the
computer's memory, but should still be stored on the floppy disc. We can
show that this is so by typing:

*LOAD Screen 3000

Your text should now reappear on the screen. You can repeat this with any
kind of complex graphics on screen, and it will still work. The same can
be done in any other graphics mode, simply by changing the values of nnnn
and mmmm to those given in the table above. For example in mode 5 you
would use:

*SAVE Screen 5800 7FFF

followed by:

*LOAD Screen 5800 7FFF

There are, however, a few precautionary points which should be mentioned
about this technique of saving screen memory:

- As you probably realise, in four colour modes, the four colours you
can use can be changed from the default black, red, yellow and white by
using VDU 19 to change the palette. The colours in the palette are not
saved when this technique is used, and must be restored by repeating the
VDU 19 commands again. If you define the palette to, for example, black,
blue, cyan and white, and create a picture which looks good in this colour
scheme, you must remember that unless you define the palette to these four
colours before performing *LOAD to restore the picture, it may appear
rather odd when reloaded, as it will appear in black, red, yellow and
white - the default colour scheme.

- The exact reason why this happens is rather complicated, but if you
allow the cursor to go down off the bottom line of the screen, and allow
the screen to scroll up one line, this technique stops working until you
perform a MODE command, or clear the screen using CLS. Basically what
happens is that the computer does not physically move every line of text
on the screen up one line, but instead makes a note that every line in
screen memory is stored one line lower than it should be. When you reload
from disk, this note is lost, and the computer draws every line lower than
it should be. Each time that CLS or MODE is executed, screen memory is
cleared and reinitiated, so that every line is stored in memory where you
would expect it to be. Simply remember not to allow the screen to scroll
between clearing it, and saving the contents of screen memory to disc.

- The files created when you save the contents of screen memory to disk
are fairly large - so large, in fact, that you can often only fit around
15 such files onto each disk that you use (the exact number depends upon
what modes the images are in). Therefore this technique is not feasable
for a large number of images. Each screen in a game like Shipwrecked cannot
be stored in this way - if I had stored every screen of the game like this,
it would have required six floppy disks to store the data for the game!
This means that saved screens must be reserved for the purposes of title
screens only.
