Filename: BioBot/BBNew
Read OK: ✔
File size: 2582 bytes
Load address: FFFFFB45
Exec address: C0917BF3
Duplicates

There are 5 duplicate copies of this file in the archive:

File contents
   10 REM BallBot V3.0
   20 REM Real-Time Version with Continuous Testing Option
   30 REM (C) Dominic Ford 1997
   40 :
   50 REM Welcome screen
   60 MODE6:@%=&905:PRINT" BallBot Artificial Intelligence Module"'"Simulation Tester V3.0 Real Time Version"''"Programmed and Designed by Dominic Ford"''SPC(16);"(C) 1997"
   70 PRINT'''"1. Real-Time Simulation"''"2. Logged Continuous Runs"''"3. Do specific run"
   80 REPEAT type$=GET$:UNTIL type$="1" OR type$="2" OR type$="3"
   90 :
  100 REM Setup variables
  105 ON ERROR OSCLI"CLOSE":REPORT:PRINT" at line ";ERL:END
  110 VOICE 1,"StringLib-Soft":*STEREO 1 0
  120 VOICE 2,"StringLib-Soft":*STEREO 2 -127
  130 VOICE 3,"StringLib-Soft":*STEREO 3 127
  140 current=0:DIMball(4,1):bbx=640:bby=950:dir=270:PROCsetupbb
  150 MODE15:IF type$="1" THEN MOUSE ON:PROCdrawfull
  155 IF type$="2" THEN start=TIME:stage=0:idle=FALSE:INPUT"Filename";f$:OSCLI"SPOOL "+f$
  157 IF type$="3" THEN PRINT"Enter Data:"':FORb=0TO4:PRINT"Ball ";b+1;:INPUTball(b,0),ball(b,1):NEXT:type$="1":MOUSE ON:PROCdrawfull
  160 :
  170 REM Start main loop
  180 REPEAT:T=TIME
  190 IF type$="1" THEN PROCuser ELSE PROCcompmon
  200 IF idle THEN UNTIL FALSE
  210 PROCsense
  220 mov=FNai(freqa,freqb,freqc)
  230 fwd=(mov AND 1)<>0
  240 reverse=(mov AND 2)<>0
  250 left=(mov AND 4)<>0
  260 right=(mov AND 8)<>0
  270 turbo=(mov AND 16)<>0
  280 open=(mov AND 32)<>0
  290 PROCmoveit
  300 REPEAT UNTIL TIME>(T+30)
  310 UNTIL FALSE
  320 :
  330 REM Graphic interface
  340 DEFPROCdrawfull
  350 REM Set up constants
  360 LOCALsx,sy,width
  370 sx=1:sy=2:width=10
  380 REM Draw green court area
  390 CLS:GCOL0,%000100:RECTANGLE FILL 0,0,1279,1023
  400 REM Mark out white lines onto court
  410 GCOL0,%111111:RECTANGLE FILL sx/(23.77+2*sx)*1280,sy/(10.97+2*sy)*1024,23.77/(23.77+2*sx)*1280,width:RECTANGLE FILL sx/(23.77+2*sx)*1280,(1.37+sy)/(10.97+2*sy)*1024,23.77/(23.77+2*sx)*1280,width
  420 RECTANGLE FILL sx/(23.77+2*sx)*1280,(9.6+sy)/(10.97+2*sy)*1024,23.77/(23.77+2*sx)*1280,width:RECTANGLE FILL sx/(23.77+2*sx)*1280,(10.97+sy)/(10.97+2*sy)*1024,23.77/(23.77+2*sx)*1280,width
  430 RECTANGLE FILL (sx+5.47)/(23.77+2*sx)*1280,(sy+5.49)/(10.97+2*sy)*1024,12.8/(23.77+2*sx)*1280,width
  440 RECTANGLE FILL sx/(23.77+2*sx)*1280,sy/(10.97+2*sy)*1024,width,10.97/(10.97+2*sy)*1024:RECTANGLE FILL (sx+23.77)/(23.77+2*sx)*1280,sy/(10.97+2*sy)*1024,width,10.97/(10.97+2*sy)*1024+width
  450 RECTANGLE FILL (sx+5.47)/(23.77+2*sx)*1280,(sy+1.37)/(10.97+2*sy)*1024,width,8.23/(10.97+2*sy)*1024:RECTANGLE FILL (sx+18.3)/(23.77+2*sx)*1280,(sy+1.37)/(10.97+2*sy)*1024,width,8.23/(10.97+2*sy)*1024
  460 :
  470 REM Draw net
  480 GCOL0,0:FORl=100TO924STEP10:MOVE 640,l:DRAW 680,l+50:NEXT:FORl=0TO40STEP10:MOVE 640+l,100+l:DRAW640+l,924+l:NEXT:FORl=0TO5:MOVE637+l,100:DRAW677+l,150:MOVE637+l,924:DRAW677+l,974:NEXT
  490 GCOL0,%111111:MOVE 682,142:DRAW682,966
  500 PROCdrawmini
  510 ENDPROC
  520 :
  530 REM Draw ballbot and balls
  540 DEFPROCdrawmini
  550 IF type$="2" THEN ENDPROC
  560 GCOL3,%001011:FORb=0TO4
  570 IF ball(b,0)<>0 OR ball(b,1)<>0 THEN RECTANGLE FILL ball(b,0),ball(b,1),5,5
  580 NEXT
  590 GCOL3,%000111:RECTANGLE FILL bbx,bby,5,5
  600 ENDPROC
  610 :
  620 REM User interface (putting balls down)
  630 DEFPROCuser
  640 MOUSE x,y,c
  650 IF c=0 THEN ENDPROC
  660 IF (c AND 4)<>0 THEN PROCdrawmini:ball(current,0)=x:ball(current,1)=y:current=(current+1)MOD5:PROCdrawmini
  670 IF (c AND 2)<>0 THEN idle=FALSE:stage=0:start=TIME
  680 REPEAT
  690 MOUSE x,y,c
  700 UNTIL c=0
  710 ENDPROC
  720 :
  730 REM Calculate ballbot's new position
  740 DEFPROCmoveit
  750 IF (left AND fwd) OR (right AND reverse) THEN dir=dir-2.5*(1-3*turbo)
  760 IF (right AND fwd) OR (left AND reverse) THEN dir=dir+2.5*(1-3*turbo)
  770 :
  780 REM Get direction in range 0<theta<360
  790 REPEAT IF dir<0 THEN dir=dir+360
  800 IF dir>=360 THEN dir=dir-360
  810 UNTIL dir>=0 AND dir<360
  820 :
  830 fr=0:IF fwd THEN fr=fr+0.25
  840 IF reverse THEN fr=fr-0.25
  850 IF turbo THEN fr=fr*4
  860 PROCdrawmini:bbx=bbx+16*SIN(PI*dir/180)*fr
  870 bby=bby+16*COS(PI*dir/180)*fr
  880 FORball=0TO4:IF open AND ABS(bbx-ball(ball,0))<10 AND ABS(bby-ball(ball,1))<10 THEN ball(ball,0)=0
  890 NEXT:PROCdrawmini
  900 ENDPROC
  910 :
  920 REM Calculate ballbot's background echo reading (-balls), using several points to check out where net posts are.
  930 DEFFNback(x,y,freq)
  940 LOCAL freqa,dummy
  950 freqa=FNback2(x,y,freq,100,923):ftype$=ft$
  960 IF ft$="U" THEN =freqa
  970 dummy=FNback2(x,y,freq,100,125):IF ft$="N" AND dummy<=freqa THEN ftype$="P"
  980 dummy=FNback2(x,y,freq,898,923):IF ft$="N" AND dummy<=freqa THEN ftype$="P"
  990 =freqa
 1000 :
 1010 REM Calculate reading from one point
 1020 DEFFNback2(x,y,freq,min,max)
 1030 ft$="U":REM Set up general value of frequency type (UNIDENTIFIED)
 1040 REM Calculate Angle of net as seen by Ballbot
 1050 LOCAL freqa
 1060 netlow=(FNangle(640,max,x,y)-dir) MOD 360
 1070 IF netlow<0 THEN netlow=netlow+360
 1080 IF netlow>180 THEN netlow=netlow-360
 1090 nethi=(FNangle(640,min,x,y)-dir) MOD 360
 1100 IF nethi<0 THEN nethi=nethi+360
 1110 IF nethi>180 THEN nethi=nethi-360
 1120 :
 1130 REM Calculate reading
 1140 freqa=freq+RND(6)-3
 1150 IF ABS(SIN(PI*dir/180))>0.01 THEN IF ((netlow<0 AND nethi>0) OR (nethi<0 AND netlow>0)) AND (640-x)/SIN(PI*dir/180)>0 THEN freqa=(640-x)/SIN(PI*dir/180):ft$="N"
 1160 =freqa
 1170 :
 1180 REM Calculate Ballbot's readings (MAIN ROUTINE)
 1190 :
 1200 DEFPROCsense
 1210 REM Get background readings from FNback
 1220 freq=RND(250)+1500
 1230 freqa=FNback(bbx,bby,freq):fa$=ftype$
 1240 dir=dir-30:freqb=FNback(bbx,bby,freq):fb$=ftype$
 1250 dir=dir+60:freqc=FNback(bbx,bby,freq):fc$=ftype$
 1260 dir=dir-105:freqd=FNback(bbx,bby,freq):dir=dir+75:fd$=ftype$
 1270 :
 1280 REM Add any relevant balls to readings (using hairy trigonometry)
 1290 :
 1300 FORball=0TO4
 1310 d%=SQR((ball(ball,0)-bbx)^2+(ball(ball,1)-bby)^2)
 1320 IF ball(ball,0)=0 THEN d%=9999
 1330 a=FNangle(ball(ball,0),ball(ball,1),bbx,bby)-dir:IFa>180 THEN a=a-360
 1340 IF ABS(a)<15 AND freqa>d% THEN freqa=d%:fa$="B"
 1350 IF a>-46 AND a<=-15 AND freqb>d% THEN freqb=d%:fb$="B"
 1360 IF a>=15 AND a<46 AND freqc>d% THEN freqc=d%:fc$="B"
 1370 IF a>-90 AND a<=-46 AND freqd>d% THEN freqd=d%:fd$="B"
 1380 NEXT
 1390 :
 1400 REM Update user displays
 1410 :
 1420 IF type$="2" THEN ENDPROC
 1430 PRINTTAB(0,0)INT((TIME-start)/12000);":";(INT((TIME-start)/200)MOD60);" "
 1440 PRINTTAB(0,31)fd$,fb$,fa$,fc$,stage,INT(searching),left,right,opencter;
 1450 SOUND 1,-1,freqa/4,5:SOUND 2,-1,freqb/4,5:SOUND 3,-1,freqc/4,5
 1460 ENDPROC
 1470:
 1480 REM Calculate bearing of B from A
 1490 DEFFNangle(x1,y1,x2,y2)
 1500 IF y2=y1 THEN ang=90 ELSE ang=180*ATN((x2-x1)/(y2-y1))/PI
 1510 IF (y2>y1) THEN ang=ang+180
 1520 IF ang<0 THEN ang=ang+360
 1530 =ang MOD 360
 1540 :
 1550 REM Computer Monitor of BallBot's progress
 1560 DEFPROCcompmon
 1565 IF idle AND (ball(0,0)<>0 OR ball(1,0)<>0 OR ball(2,0)<>0 OR ball(3,0)<>0 OR ball(4,0)<>0) THEN st$="Fail" ELSE st$="Pass"
 1570 IF idle THEN PRINTst$,INT((TIME-start)/12000);":";(INT((TIME-start)/200)MOD60)
 1580 IF TIME>start+48000 THEN idle=TRUE:PRINT"Time","****"
 1590 IFbbx>630ANDbbx<650ANDbby>100ANDbby<923THENidle=TRUE:PRINT"Crash","****"
 1600 IF idle THEN bbx=640:bby=950:dir=270:stage=0:PROCsetupbb:start=TIME:FORb=0TO4:ball(b,0)=RND(1280):ball(b,1)=RND(1024):NEXT
 1605 IF idle THEN PRINT"[";ball(0,0);",";ball(0,1);"] [";ball(1,0);",";ball(1,1);"] [";ball(2,0);",";ball(2,1);"] [";ball(3,0);",";ball(3,1);"] [";ball(4,0);",";ball(4,1);"]",;:idle=FALSE
 1610 ENDPROC
 1620 :
 1630 REM BALLBOT ROBOTIC INTELLIGENCE MODULE
 1640 :
 1650 DEFFNai(freqa,freqb,freqc)
 1660 REM Artificial intelligence routines (ie. What Next??)
 1670 LOCALfwd,reverse,left,right,turbo
 1680 fwd=TRUE:reverse=FALSE:left=FALSE:right=FALSE:turbo=FALSE
 1690 :
 1700 REM What stage are we in? Hunt for balls or move to new area?
 1710 IF near<>0 AND stage<8 THEN PROCdonearstuff
 1720 IF near=0 AND (stage=0 OR stage=2) THEN PROChunt
 1730 IF near=0 AND (stage=1 OR stage=3) THEN PROCmoveout
 1740 IF stage=4 THEN PROCreleaseb
 1750 :
 1760 REM Prepare output into binary for transmission
 1770 feed=0:IF fwd THEN feed=feed+1
 1780 IF reving THEN turbo=TRUE
 1790 IF reverse THEN feed=feed+2
 1800 IF left THEN feed=feed+4
 1810 IF right THEN feed=feed+8
 1820 IF turbo THEN feed=feed+16
 1830 IF opencter>0 THEN feed=feed+32
 1840 =feed
 1850 :
 1860 REM Perform a sweep to find any balls
 1870 DEFPROChunt
 1880 REM Watch out if too near to net
 1890 IF((freqa<20AND fa$<>"B")OR(freqb<20AND fb$<>"B")OR(freqc<20AND fc$<>"B"))OR(reving AND((freqa<150AND fa$<>"B")OR(freqb<150AND fb$<>"B")OR(freqc<150AND fc$<>"B")))THENreving=TRUE:reverse=TRUE:fwd=FALSE:left=FALSE:right=TRUE:ENDPROC
 1900 reving=FALSE
 1910 :
 1920 REM If Ball is out of reach in the "D" sector, reverse!
 1930 FDR=freqd*1.25:IFfreqd<150ANDfd$="B"ANDFDR<freqa ANDFDR<freqb ANDFDR<freqc AND(fa$<>"B"ORfreqa>100)AND(fb$<>"B"ORfreqb>100)AND(fc$<>"B"ORfreqc>100)THEN turbo=TRUE:reverse=TRUE:fwd=FALSE:right=TRUE:farleft=-6*(freqd>40):ENDPROC
 1940 IF farleft>0 THEN
 1950  farleft=farleft-1:reverse=TRUE:fwd=FALSE:right=TRUE:turbo=TRUE
 1960  IF fa$="B" OR (fd$<>"B" AND fb$<>"B") THEN farleft=0
 1970  ENDPROC
 1980 ENDIF
 1990 :
 2000 REM Rotate to face ball
 2002 IF (fb$="B" AND freqb>150) OR (fd$="B" AND freqd>150) THEN tending=0
 2003 IF fc$="B" AND freqc>150 THEN tending=1
 2005 IF opencter>0 THEN opencter=opencter-1:ENDPROC
 2010 opencter=-5*(((freqa<20)ANDfa$="B")OR((freqb<20)ANDfb$="B")OR((freqc<20)ANDfc$="B")OR((freqd<20)ANDfd$="B"))
 2020 IF fa$="B" THEN left=(steer=-1):right=(steer=1):steer=0:searching=searching/2:turbo=freqa>100:ENDPROC
 2030 IF fb$="B" OR fd$="B" THEN steer=-1:left=TRUE:ENDPROC
 2040 IF fc$="B" THEN steer=1:right=TRUE:ENDPROC
 2050 REM If no ball in sight, continue rotation...
 2060 align=FALSE:searching=searching+1
 2070 IF (tending AND 1)<>0 THEN right=TRUE ELSE left=TRUE
 2080 IF searching=5 THEN tending=(tending EOR 1)
 2100 IF searching>150 THEN stage=stage+1
 2110 ENDPROC
 2120 :
 2130 REM Find edge of net and aim for it to move to other side
 2140 DEFPROCmoveout
 2150 REM Watch out if too near to net
 2160 IF (freqa<30 OR freqb<30 OR freqc<30) OR (reving AND (freqa<250 OR freqb<250 OR freqc<250)) THEN reving=TRUE:farleft=0:reverse=TRUE:fwd=FALSE:right=FALSE:left=(freqa>230 AND freqb>230 AND freqc>230):ENDPROC
 2170 reving=FALSE
 2180 REM Align ballbot to face the net post...
 2190 IF fa$="N" OR fa$="P" THEN right=TRUE:ENDPROC
 2200 IF fb$<>"N" AND fb$<>"P" THEN left=TRUE:ENDPROC
 2210 IF fb$="P" AND freqb<150 THEN right=TRUE:near=1:ENDPROC
 2220 turbo=TRUE
 2260 ENDPROC
 2270 :
 2280 REM Nearly there... Just need a little nudge in the right direction.
 2290 DEFPROCdonearstuff
 2300 near=near+1
 2310 IF near<8 THEN right=TRUE:ENDPROC
 2320 left=TRUE
 2330 IF near>16 THEN near=0:stage=stage+1:searching=0:tending=1
 2340 ENDPROC
 2350 :
 2360 REM Initialise BallBot variables at the beginning of a run
 2370 DEFPROCsetupbb
 2380 reving=FALSE:left=FALSE:right=FALSE:fwd=FALSE:reverse=FALSE:searching=0:idle=TRUE
 2390 near=FALSE:farleft=0:opencter=0:tending=1:steer=0
 2400 ENDPROC
 2410 :
 2420 DEFPROCreleaseb
 2430 REM Got all the balls, now just dump them!
 2440 near=near+1:reverse=TRUE:fwd=FALSE
 2450 IF near>9 THEN idle=TRUE:near=FALSE
 2460 ENDPROC
 2470 REPEAT:FORX=1TO12:OSCLI"CHANNELVOICE 1 "+STR$X:SOUND1,-10,52,100:FORR=0TO10000:NEXT,:UNTIL FALSE
 2480 :
 2490 REM Whizz-back to line up with D - what if whizz back into net?
 2500 REM Reverse if BallBot knows that balls are behind it.


 � BallBot V3.0
7 � Real-Time Version with Continuous Testing Option
 � (C) Dominic Ford 1997
( :
2 � Welcome screen
<� �6:@%=&905:�" BallBot Artificial Intelligence Module"'"Simulation Tester V3.0 Real Time Version"''"Programmed and Designed by Dominic Ford"''�(16);"(C) 1997"
FU �'''"1. Real-Time Simulation"''"2. Logged Continuous Runs"''"3. Do specific run"
P2 � type$=�:� type$="1" � type$="2" � type$="3"
Z :
d � Setup variables
i$ � � �"CLOSE":�:�" at line ";�:�
n& ȡ 1,"StringLib-Soft":*STEREO 1 0
x) ȡ 2,"StringLib-Soft":*STEREO 2 -127
�( ȡ 3,"StringLib-Soft":*STEREO 3 127
�: current=0:�ball(4,1):bbx=640:bby=950:dir=270:�setupbb
�% �15:� type$="1" � ȗ �:�drawfull
�E � type$="2" � start=�:stage=0:idle=�:�"Filename";f$:�"SPOOL "+f$
�g � type$="3" � �"Enter Data:"':�b=0�4:�"Ball ";b+1;:�ball(b,0),ball(b,1):�:type$="1":ȗ �:�drawfull
� :
� � Start main loop
�
 �:T=�
�# � type$="1" � �user � �compmon
� � idle � � �
� �sense
� mov=�ai(freqa,freqb,freqc)
� fwd=(mov � 1)<>0
� reverse=(mov � 2)<>0
� left=(mov � 4)<>0
 right=(mov � 8)<>0
 turbo=(mov � 16)<>0
 open=(mov � 32)<>0
" �moveit
, � � �>(T+30)
6 � �
@ :
J � Graphic interface
T ��drawfull
^ � Set up constants
h �sx,sy,width
r sx=1:sy=2:width=10
| � Draw green court area
�% �:�0,%000100:ȓ Ȑ 0,0,1279,1023
�& � Mark out white lines onto court
�� �0,%111111:ȓ Ȑ sx/(23.77+2*sx)*1280,sy/(10.97+2*sy)*1024,23.77/(23.77+2*sx)*1280,width:ȓ Ȑ sx/(23.77+2*sx)*1280,(1.37+sy)/(10.97+2*sy)*1024,23.77/(23.77+2*sx)*1280,width
�� ȓ Ȑ sx/(23.77+2*sx)*1280,(9.6+sy)/(10.97+2*sy)*1024,23.77/(23.77+2*sx)*1280,width:ȓ Ȑ sx/(23.77+2*sx)*1280,(10.97+sy)/(10.97+2*sy)*1024,23.77/(23.77+2*sx)*1280,width
�_ ȓ Ȑ (sx+5.47)/(23.77+2*sx)*1280,(sy+5.49)/(10.97+2*sy)*1024,12.8/(23.77+2*sx)*1280,width
�� ȓ Ȑ sx/(23.77+2*sx)*1280,sy/(10.97+2*sy)*1024,width,10.97/(10.97+2*sy)*1024:ȓ Ȑ (sx+23.77)/(23.77+2*sx)*1280,sy/(10.97+2*sy)*1024,width,10.97/(10.97+2*sy)*1024+width
º ȓ Ȑ (sx+5.47)/(23.77+2*sx)*1280,(sy+1.37)/(10.97+2*sy)*1024,width,8.23/(10.97+2*sy)*1024:ȓ Ȑ (sx+18.3)/(23.77+2*sx)*1280,(sy+1.37)/(10.97+2*sy)*1024,width,8.23/(10.97+2*sy)*1024
� :
� � Draw net
� �0,0:�l=100�924�10:� 640,l:� 680,l+50:�:�l=0�40�10:� 640+l,100+l:�640+l,924+l:�:�l=0�5:�637+l,100:�677+l,150:�637+l,924:�677+l,974:�
�" �0,%111111:� 682,142:�682,966
� �drawmini
� �
 :
 � Draw ballbot and balls
 ��drawmini
& � type$="2" � �
0 �3,%001011:�b=0�4
:B � ball(b,0)<>0 � ball(b,1)<>0 � ȓ Ȑ ball(b,0),ball(b,1),5,5
D �
N! �3,%000111:ȓ Ȑ bbx,bby,5,5
X �
b :
l* � User interface (putting balls down)
v ��user
�
 ȗ x,y,c
� � c=0 � �
�a � (c � 4)<>0 � �drawmini:ball(current,0)=x:ball(current,1)=y:current=(current+1)�5:�drawmini
�* � (c � 2)<>0 � idle=�:stage=0:start=�
� �
�
 ȗ x,y,c
�
 � c=0
� �
� :
�' � Calculate ballbot's new position
�
 ��moveit
�A � (left � fwd) � (right � reverse) � dir=dir-2.5*(1-3*turbo)
�A � (right � fwd) � (left � reverse) � dir=dir+2.5*(1-3*turbo)
 :
) � Get direction in range 0<theta<360
 � � dir<0 � dir=dir+360
  � dir>=360 � dir=dir-360
* � dir>=0 � dir<360
4 :
> fr=0:� fwd � fr=fr+0.25
H � reverse � fr=fr-0.25
R � turbo � fr=fr*4
\) �drawmini:bbx=bbx+16*�(�*dir/180)*fr
f bby=bby+16*�(�*dir/180)*fr
pX �ball=0�4:� open � �(bbx-ball(ball,0))<10 � �(bby-ball(ball,1))<10 � ball(ball,0)=0
z �:�drawmini
� �
� :
�s � Calculate ballbot's background echo reading (-balls), using several points to check out where net posts are.
� ݤback(x,y,freq)
� � freqa,dummy
�. freqa=�back2(x,y,freq,100,923):ftype$=ft$
� � ft$="U" � =freqa
�I dummy=�back2(x,y,freq,100,125):� ft$="N" � dummy<=freqa � ftype$="P"
�I dummy=�back2(x,y,freq,898,923):� ft$="N" � dummy<=freqa � ftype$="P"
� =freqa
� :
�' � Calculate reading from one point
� ݤback2(x,y,freq,min,max)
D ft$="U":� Set up general value of frequency type (UNIDENTIFIED)
0 � Calculate Angle of net as seen by Ballbot
 � freqa
$+ netlow=(�angle(640,max,x,y)-dir) � 360
.# � netlow<0 � netlow=netlow+360
8% � netlow>180 � netlow=netlow-360
B* nethi=(�angle(640,min,x,y)-dir) � 360
L  � nethi<0 � nethi=nethi+360
V" � nethi>180 � nethi=nethi-360
` :
j � Calculate reading
t freqa=freq+�(6)-3
~� � �(�(�*dir/180))>0.01 � � ((netlow<0 � nethi>0) � (nethi<0 � netlow>0)) � (640-x)/�(�*dir/180)>0 � freqa=(640-x)/�(�*dir/180):ft$="N"
� =freqa
� :
�2 � Calculate Ballbot's readings (MAIN ROUTINE)
� :
� ��sense
�* � Get background readings from FNback
� freq=�(250)+1500
�) freqa=�back(bbx,bby,freq):fa$=ftype$
�4 dir=dir-30:freqb=�back(bbx,bby,freq):fb$=ftype$
�4 dir=dir+60:freqc=�back(bbx,bby,freq):fc$=ftype$
�@ dir=dir-105:freqd=�back(bbx,bby,freq):dir=dir+75:fd$=ftype$
� :
D � Add any relevant balls to readings (using hairy trigonometry)

 :
 �ball=0�4
4 d%=�((ball(ball,0)-bbx)^2+(ball(ball,1)-bby)^2)
( � ball(ball,0)=0 � d%=9999
2E a=�angle(ball(ball,0),ball(ball,1),bbx,bby)-dir:�a>180 � a=a-360
<, � �(a)<15 � freqa>d% � freqa=d%:fa$="B"
F3 � a>-46 � a<=-15 � freqb>d% � freqb=d%:fb$="B"
P1 � a>=15 � a<46 � freqc>d% � freqc=d%:fc$="B"
Z3 � a>-90 � a<=-46 � freqd>d% � freqd=d%:fd$="B"
d �
n :
x � Update user displays
� :
� � type$="2" � �
�; �0,0)�((�-start)/12000);":";(�((�-start)/200)�60);" "
�C �0,31)fd$,fb$,fa$,fc$,stage,�(searching),left,right,opencter;
�7 � 1,-1,freqa/4,5:� 2,-1,freqb/4,5:� 3,-1,freqc/4,5
� �
�:
�$ � Calculate bearing of B from A
� ݤangle(x1,y1,x2,y2)
�4 � y2=y1 � ang=90 � ang=180*�((x2-x1)/(y2-y1))/�
� � (y2>y1) � ang=ang+180
� � ang<0 � ang=ang+360
� =ang � 360
 :
- � Computer Monitor of BallBot's progress
 ��compmon
r � idle � (ball(0,0)<>0 � ball(1,0)<>0 � ball(2,0)<>0 � ball(3,0)<>0 � ball(4,0)<>0) � st$="Fail" � st$="Pass"
"? � idle � �st$,�((�-start)/12000);":";(�((�-start)/200)�60)
,, � �>start+48000 � idle=�:�"Time","****"
6< �bbx>630�bbx<650�bby>100�bby<923�idle=�:�"Crash","****"
@k � idle � bbx=640:bby=950:dir=270:stage=0:�setupbb:start=�:�b=0�4:ball(b,0)=�(1280):ball(b,1)=�(1024):�
E� � idle � �"[";ball(0,0);",";ball(0,1);"] [";ball(1,0);",";ball(1,1);"] [";ball(2,0);",";ball(2,1);"] [";ball(3,0);",";ball(3,1);"] [";ball(4,0);",";ball(4,1);"]",;:idle=�
J �
T :
^* � BALLBOT ROBOTIC INTELLIGENCE MODULE
h :
r ݤai(freqa,freqb,freqc)
|9 � Artificial intelligence routines (ie. What Next??)
�" �fwd,reverse,left,right,turbo
�+ fwd=�:reverse=�:left=�:right=�:turbo=�
� :
�@ � What stage are we in? Hunt for balls or move to new area?
�' � near<>0 � stage<8 � �donearstuff
�+ � near=0 � (stage=0 � stage=2) � �hunt
�. � near=0 � (stage=1 � stage=3) � �moveout
� � stage=4 � �releaseb
� :
�2 � Prepare output into binary for transmission
� feed=0:� fwd � feed=feed+1
� � reving � turbo=�
� � reverse � feed=feed+2
 � left � feed=feed+4
 � right � feed=feed+8
 � turbo � feed=feed+16
&  � opencter>0 � feed=feed+32
0
 =feed
: :
D( � Perform a sweep to find any balls
N ��hunt
X# � Watch out if too near to net
b� �((freqa<20� fa$<>"B")�(freqb<20� fb$<>"B")�(freqc<20� fc$<>"B"))�(reving �((freqa<150� fa$<>"B")�(freqb<150� fb$<>"B")�(freqc<150� fc$<>"B")))�reving=�:reverse=�:fwd=�:left=�:right=�:�
l
 reving=�
v :
�: � If Ball is out of reach in the "D" sector, reverse!
�� FDR=freqd*1.25:�freqd<150�fd$="B"�FDR<freqa �FDR<freqb �FDR<freqc �(fa$<>"B"�freqa>100)�(fb$<>"B"�freqb>100)�(fc$<>"B"�freqc>100)� turbo=�:reverse=�:fwd=�:right=�:farleft=-6*(freqd>40):�
� � farleft>0 �
�7  farleft=farleft-1:reverse=�:fwd=�:right=�:turbo=�
�3  � fa$="B" � (fd$<>"B" � fb$<>"B") � farleft=0
�  �
� �
� :
� � Rotate to face ball
�@ � (fb$="B" � freqb>150) � (fd$="B" � freqd>150) � tending=0
�& � fc$="B" � freqc>150 � tending=1
�) � opencter>0 � opencter=opencter-1:�
�f opencter=-5*(((freqa<20)�fa$="B")�((freqb<20)�fb$="B")�((freqc<20)�fc$="B")�((freqd<20)�fd$="B"))
�` � fa$="B" � left=(steer=-1):right=(steer=1):steer=0:searching=searching/2:turbo=freqa>100:�
�, � fb$="B" � fd$="B" � steer=-1:left=�:�
�" � fc$="B" � steer=1:right=�:�
0 � If no ball in sight, continue rotation...
" align=�:searching=searching+1
* � (tending � 1)<>0 � right=� � left=�
 * � searching=5 � tending=(tending � 1)
4$ � searching>150 � stage=stage+1
> �
H :
R< � Find edge of net and aim for it to move to other side
\ ��moveout
f# � Watch out if too near to net
p� � (freqa<30 � freqb<30 � freqc<30) � (reving � (freqa<250 � freqb<250 � freqc<250)) � reving=�:farleft=0:reverse=�:fwd=�:right=�:left=(freqa>230 � freqb>230 � freqc>230):�
z
 reving=�
�, � Align ballbot to face the net post...
�$ � fa$="N" � fa$="P" � right=�:�
�% � fb$<>"N" � fb$<>"P" � left=�:�
�- � fb$="P" � freqb<150 � right=�:near=1:�
� turbo=�
� �
� :
�G � Nearly there... Just need a little nudge in the right direction.
� ��donearstuff
� near=near+1
	 � near<8 � right=�:�
	 left=�
	; � near>16 � near=0:stage=stage+1:searching=0:tending=1
	$ �
	. :
	8= � Initialise BallBot variables at the beginning of a run
	B ��setupbb
	L? reving=�:left=�:right=�:fwd=�:reverse=�:searching=0:idle=�
	V2 near=�:farleft=0:opencter=0:tending=1:steer=0
	` �
	j :
	t ��releaseb
	~- � Got all the balls, now just dump them!
	�  near=near+1:reverse=�:fwd=�
	� � near>9 � idle=�:near=�
	� �
	�D �:�X=1�12:�"CHANNELVOICE 1 "+�X:�1,-10,52,100:�R=0�10000:�,:� �
	� :
	�B � Whizz-back to line up with D - what if whizz back into net?
	�9 � Reverse if BallBot knows that balls are behind it.
�
00000000  0d 00 0a 13 20 f4 20 42  61 6c 6c 42 6f 74 20 56  |.... . BallBot V|
00000010  33 2e 30 0d 00 14 37 20  f4 20 52 65 61 6c 2d 54  |3.0...7 . Real-T|
00000020  69 6d 65 20 56 65 72 73  69 6f 6e 20 77 69 74 68  |ime Version with|
00000030  20 43 6f 6e 74 69 6e 75  6f 75 73 20 54 65 73 74  | Continuous Test|
00000040  69 6e 67 20 4f 70 74 69  6f 6e 0d 00 1e 1c 20 f4  |ing Option.... .|
00000050  20 28 43 29 20 44 6f 6d  69 6e 69 63 20 46 6f 72  | (C) Dominic For|
00000060  64 20 31 39 39 37 0d 00  28 06 20 3a 0d 00 32 15  |d 1997..(. :..2.|
00000070  20 f4 20 57 65 6c 63 6f  6d 65 20 73 63 72 65 65  | . Welcome scree|
00000080  6e 0d 00 3c a2 20 eb 36  3a 40 25 3d 26 39 30 35  |n..<. .6:@%=&905|
00000090  3a f1 22 20 42 61 6c 6c  42 6f 74 20 41 72 74 69  |:." BallBot Arti|
000000a0  66 69 63 69 61 6c 20 49  6e 74 65 6c 6c 69 67 65  |ficial Intellige|
000000b0  6e 63 65 20 4d 6f 64 75  6c 65 22 27 22 53 69 6d  |nce Module"'"Sim|
000000c0  75 6c 61 74 69 6f 6e 20  54 65 73 74 65 72 20 56  |ulation Tester V|
000000d0  33 2e 30 20 52 65 61 6c  20 54 69 6d 65 20 56 65  |3.0 Real Time Ve|
000000e0  72 73 69 6f 6e 22 27 27  22 50 72 6f 67 72 61 6d  |rsion"''"Program|
000000f0  6d 65 64 20 61 6e 64 20  44 65 73 69 67 6e 65 64  |med and Designed|
00000100  20 62 79 20 44 6f 6d 69  6e 69 63 20 46 6f 72 64  | by Dominic Ford|
00000110  22 27 27 89 28 31 36 29  3b 22 28 43 29 20 31 39  |"''.(16);"(C) 19|
00000120  39 37 22 0d 00 46 55 20  f1 27 27 27 22 31 2e 20  |97"..FU .'''"1. |
00000130  52 65 61 6c 2d 54 69 6d  65 20 53 69 6d 75 6c 61  |Real-Time Simula|
00000140  74 69 6f 6e 22 27 27 22  32 2e 20 4c 6f 67 67 65  |tion"''"2. Logge|
00000150  64 20 43 6f 6e 74 69 6e  75 6f 75 73 20 52 75 6e  |d Continuous Run|
00000160  73 22 27 27 22 33 2e 20  44 6f 20 73 70 65 63 69  |s"''"3. Do speci|
00000170  66 69 63 20 72 75 6e 22  0d 00 50 32 20 f5 20 74  |fic run"..P2 . t|
00000180  79 70 65 24 3d be 3a fd  20 74 79 70 65 24 3d 22  |ype$=.:. type$="|
00000190  31 22 20 84 20 74 79 70  65 24 3d 22 32 22 20 84  |1" . type$="2" .|
000001a0  20 74 79 70 65 24 3d 22  33 22 0d 00 5a 06 20 3a  | type$="3"..Z. :|
000001b0  0d 00 64 16 20 f4 20 53  65 74 75 70 20 76 61 72  |..d. . Setup var|
000001c0  69 61 62 6c 65 73 0d 00  69 24 20 ee 20 85 20 ff  |iables..i$ . . .|
000001d0  22 43 4c 4f 53 45 22 3a  f6 3a f1 22 20 61 74 20  |"CLOSE":.:." at |
000001e0  6c 69 6e 65 20 22 3b 9e  3a e0 0d 00 6e 26 20 c8  |line ";.:...n& .|
000001f0  a1 20 31 2c 22 53 74 72  69 6e 67 4c 69 62 2d 53  |. 1,"StringLib-S|
00000200  6f 66 74 22 3a 2a 53 54  45 52 45 4f 20 31 20 30  |oft":*STEREO 1 0|
00000210  0d 00 78 29 20 c8 a1 20  32 2c 22 53 74 72 69 6e  |..x) .. 2,"Strin|
00000220  67 4c 69 62 2d 53 6f 66  74 22 3a 2a 53 54 45 52  |gLib-Soft":*STER|
00000230  45 4f 20 32 20 2d 31 32  37 0d 00 82 28 20 c8 a1  |EO 2 -127...( ..|
00000240  20 33 2c 22 53 74 72 69  6e 67 4c 69 62 2d 53 6f  | 3,"StringLib-So|
00000250  66 74 22 3a 2a 53 54 45  52 45 4f 20 33 20 31 32  |ft":*STEREO 3 12|
00000260  37 0d 00 8c 3a 20 63 75  72 72 65 6e 74 3d 30 3a  |7...: current=0:|
00000270  de 62 61 6c 6c 28 34 2c  31 29 3a 62 62 78 3d 36  |.ball(4,1):bbx=6|
00000280  34 30 3a 62 62 79 3d 39  35 30 3a 64 69 72 3d 32  |40:bby=950:dir=2|
00000290  37 30 3a f2 73 65 74 75  70 62 62 0d 00 96 25 20  |70:.setupbb...% |
000002a0  eb 31 35 3a e7 20 74 79  70 65 24 3d 22 31 22 20  |.15:. type$="1" |
000002b0  8c 20 c8 97 20 ee 3a f2  64 72 61 77 66 75 6c 6c  |. .. .:.drawfull|
000002c0  0d 00 9b 45 20 e7 20 74  79 70 65 24 3d 22 32 22  |...E . type$="2"|
000002d0  20 8c 20 73 74 61 72 74  3d 91 3a 73 74 61 67 65  | . start=.:stage|
000002e0  3d 30 3a 69 64 6c 65 3d  a3 3a e8 22 46 69 6c 65  |=0:idle=.:."File|
000002f0  6e 61 6d 65 22 3b 66 24  3a ff 22 53 50 4f 4f 4c  |name";f$:."SPOOL|
00000300  20 22 2b 66 24 0d 00 9d  67 20 e7 20 74 79 70 65  | "+f$...g . type|
00000310  24 3d 22 33 22 20 8c 20  f1 22 45 6e 74 65 72 20  |$="3" . ."Enter |
00000320  44 61 74 61 3a 22 27 3a  e3 62 3d 30 b8 34 3a f1  |Data:"':.b=0.4:.|
00000330  22 42 61 6c 6c 20 22 3b  62 2b 31 3b 3a e8 62 61  |"Ball ";b+1;:.ba|
00000340  6c 6c 28 62 2c 30 29 2c  62 61 6c 6c 28 62 2c 31  |ll(b,0),ball(b,1|
00000350  29 3a ed 3a 74 79 70 65  24 3d 22 31 22 3a c8 97  |):.:type$="1":..|
00000360  20 ee 3a f2 64 72 61 77  66 75 6c 6c 0d 00 a0 06  | .:.drawfull....|
00000370  20 3a 0d 00 aa 16 20 f4  20 53 74 61 72 74 20 6d  | :.... . Start m|
00000380  61 69 6e 20 6c 6f 6f 70  0d 00 b4 0a 20 f5 3a 54  |ain loop.... .:T|
00000390  3d 91 0d 00 be 23 20 e7  20 74 79 70 65 24 3d 22  |=....# . type$="|
000003a0  31 22 20 8c 20 f2 75 73  65 72 20 8b 20 f2 63 6f  |1" . .user . .co|
000003b0  6d 70 6d 6f 6e 0d 00 c8  11 20 e7 20 69 64 6c 65  |mpmon.... . idle|
000003c0  20 8c 20 fd 20 a3 0d 00  d2 0b 20 f2 73 65 6e 73  | . . ..... .sens|
000003d0  65 0d 00 dc 1f 20 6d 6f  76 3d a4 61 69 28 66 72  |e.... mov=.ai(fr|
000003e0  65 71 61 2c 66 72 65 71  62 2c 66 72 65 71 63 29  |eqa,freqb,freqc)|
000003f0  0d 00 e6 15 20 66 77 64  3d 28 6d 6f 76 20 80 20  |.... fwd=(mov . |
00000400  31 29 3c 3e 30 0d 00 f0  19 20 72 65 76 65 72 73  |1)<>0.... revers|
00000410  65 3d 28 6d 6f 76 20 80  20 32 29 3c 3e 30 0d 00  |e=(mov . 2)<>0..|
00000420  fa 16 20 6c 65 66 74 3d  28 6d 6f 76 20 80 20 34  |.. left=(mov . 4|
00000430  29 3c 3e 30 0d 01 04 17  20 72 69 67 68 74 3d 28  |)<>0.... right=(|
00000440  6d 6f 76 20 80 20 38 29  3c 3e 30 0d 01 0e 18 20  |mov . 8)<>0.... |
00000450  74 75 72 62 6f 3d 28 6d  6f 76 20 80 20 31 36 29  |turbo=(mov . 16)|
00000460  3c 3e 30 0d 01 18 17 20  6f 70 65 6e 3d 28 6d 6f  |<>0.... open=(mo|
00000470  76 20 80 20 33 32 29 3c  3e 30 0d 01 22 0c 20 f2  |v . 32)<>0..". .|
00000480  6d 6f 76 65 69 74 0d 01  2c 11 20 f5 20 fd 20 91  |moveit..,. . . .|
00000490  3e 28 54 2b 33 30 29 0d  01 36 08 20 fd 20 a3 0d  |>(T+30)..6. . ..|
000004a0  01 40 06 20 3a 0d 01 4a  18 20 f4 20 47 72 61 70  |.@. :..J. . Grap|
000004b0  68 69 63 20 69 6e 74 65  72 66 61 63 65 0d 01 54  |hic interface..T|
000004c0  0f 20 dd f2 64 72 61 77  66 75 6c 6c 0d 01 5e 17  |. ..drawfull..^.|
000004d0  20 f4 20 53 65 74 20 75  70 20 63 6f 6e 73 74 61  | . Set up consta|
000004e0  6e 74 73 0d 01 68 11 20  ea 73 78 2c 73 79 2c 77  |nts..h. .sx,sy,w|
000004f0  69 64 74 68 0d 01 72 17  20 73 78 3d 31 3a 73 79  |idth..r. sx=1:sy|
00000500  3d 32 3a 77 69 64 74 68  3d 31 30 0d 01 7c 1c 20  |=2:width=10..|. |
00000510  f4 20 44 72 61 77 20 67  72 65 65 6e 20 63 6f 75  |. Draw green cou|
00000520  72 74 20 61 72 65 61 0d  01 86 25 20 db 3a e6 30  |rt area...% .:.0|
00000530  2c 25 30 30 30 31 30 30  3a c8 93 20 c8 90 20 30  |,%000100:.. .. 0|
00000540  2c 30 2c 31 32 37 39 2c  31 30 32 33 0d 01 90 26  |,0,1279,1023...&|
00000550  20 f4 20 4d 61 72 6b 20  6f 75 74 20 77 68 69 74  | . Mark out whit|
00000560  65 20 6c 69 6e 65 73 20  6f 6e 74 6f 20 63 6f 75  |e lines onto cou|
00000570  72 74 0d 01 9a b2 20 e6  30 2c 25 31 31 31 31 31  |rt.... .0,%11111|
00000580  31 3a c8 93 20 c8 90 20  73 78 2f 28 32 33 2e 37  |1:.. .. sx/(23.7|
00000590  37 2b 32 2a 73 78 29 2a  31 32 38 30 2c 73 79 2f  |7+2*sx)*1280,sy/|
000005a0  28 31 30 2e 39 37 2b 32  2a 73 79 29 2a 31 30 32  |(10.97+2*sy)*102|
000005b0  34 2c 32 33 2e 37 37 2f  28 32 33 2e 37 37 2b 32  |4,23.77/(23.77+2|
000005c0  2a 73 78 29 2a 31 32 38  30 2c 77 69 64 74 68 3a  |*sx)*1280,width:|
000005d0  c8 93 20 c8 90 20 73 78  2f 28 32 33 2e 37 37 2b  |.. .. sx/(23.77+|
000005e0  32 2a 73 78 29 2a 31 32  38 30 2c 28 31 2e 33 37  |2*sx)*1280,(1.37|
000005f0  2b 73 79 29 2f 28 31 30  2e 39 37 2b 32 2a 73 79  |+sy)/(10.97+2*sy|
00000600  29 2a 31 30 32 34 2c 32  33 2e 37 37 2f 28 32 33  |)*1024,23.77/(23|
00000610  2e 37 37 2b 32 2a 73 78  29 2a 31 32 38 30 2c 77  |.77+2*sx)*1280,w|
00000620  69 64 74 68 0d 01 a4 ae  20 c8 93 20 c8 90 20 73  |idth.... .. .. s|
00000630  78 2f 28 32 33 2e 37 37  2b 32 2a 73 78 29 2a 31  |x/(23.77+2*sx)*1|
00000640  32 38 30 2c 28 39 2e 36  2b 73 79 29 2f 28 31 30  |280,(9.6+sy)/(10|
00000650  2e 39 37 2b 32 2a 73 79  29 2a 31 30 32 34 2c 32  |.97+2*sy)*1024,2|
00000660  33 2e 37 37 2f 28 32 33  2e 37 37 2b 32 2a 73 78  |3.77/(23.77+2*sx|
00000670  29 2a 31 32 38 30 2c 77  69 64 74 68 3a c8 93 20  |)*1280,width:.. |
00000680  c8 90 20 73 78 2f 28 32  33 2e 37 37 2b 32 2a 73  |.. sx/(23.77+2*s|
00000690  78 29 2a 31 32 38 30 2c  28 31 30 2e 39 37 2b 73  |x)*1280,(10.97+s|
000006a0  79 29 2f 28 31 30 2e 39  37 2b 32 2a 73 79 29 2a  |y)/(10.97+2*sy)*|
000006b0  31 30 32 34 2c 32 33 2e  37 37 2f 28 32 33 2e 37  |1024,23.77/(23.7|
000006c0  37 2b 32 2a 73 78 29 2a  31 32 38 30 2c 77 69 64  |7+2*sx)*1280,wid|
000006d0  74 68 0d 01 ae 5f 20 c8  93 20 c8 90 20 28 73 78  |th..._ .. .. (sx|
000006e0  2b 35 2e 34 37 29 2f 28  32 33 2e 37 37 2b 32 2a  |+5.47)/(23.77+2*|
000006f0  73 78 29 2a 31 32 38 30  2c 28 73 79 2b 35 2e 34  |sx)*1280,(sy+5.4|
00000700  39 29 2f 28 31 30 2e 39  37 2b 32 2a 73 79 29 2a  |9)/(10.97+2*sy)*|
00000710  31 30 32 34 2c 31 32 2e  38 2f 28 32 33 2e 37 37  |1024,12.8/(23.77|
00000720  2b 32 2a 73 78 29 2a 31  32 38 30 2c 77 69 64 74  |+2*sx)*1280,widt|
00000730  68 0d 01 b8 ae 20 c8 93  20 c8 90 20 73 78 2f 28  |h.... .. .. sx/(|
00000740  32 33 2e 37 37 2b 32 2a  73 78 29 2a 31 32 38 30  |23.77+2*sx)*1280|
00000750  2c 73 79 2f 28 31 30 2e  39 37 2b 32 2a 73 79 29  |,sy/(10.97+2*sy)|
00000760  2a 31 30 32 34 2c 77 69  64 74 68 2c 31 30 2e 39  |*1024,width,10.9|
00000770  37 2f 28 31 30 2e 39 37  2b 32 2a 73 79 29 2a 31  |7/(10.97+2*sy)*1|
00000780  30 32 34 3a c8 93 20 c8  90 20 28 73 78 2b 32 33  |024:.. .. (sx+23|
00000790  2e 37 37 29 2f 28 32 33  2e 37 37 2b 32 2a 73 78  |.77)/(23.77+2*sx|
000007a0  29 2a 31 32 38 30 2c 73  79 2f 28 31 30 2e 39 37  |)*1280,sy/(10.97|
000007b0  2b 32 2a 73 79 29 2a 31  30 32 34 2c 77 69 64 74  |+2*sy)*1024,widt|
000007c0  68 2c 31 30 2e 39 37 2f  28 31 30 2e 39 37 2b 32  |h,10.97/(10.97+2|
000007d0  2a 73 79 29 2a 31 30 32  34 2b 77 69 64 74 68 0d  |*sy)*1024+width.|
000007e0  01 c2 ba 20 c8 93 20 c8  90 20 28 73 78 2b 35 2e  |... .. .. (sx+5.|
000007f0  34 37 29 2f 28 32 33 2e  37 37 2b 32 2a 73 78 29  |47)/(23.77+2*sx)|
00000800  2a 31 32 38 30 2c 28 73  79 2b 31 2e 33 37 29 2f  |*1280,(sy+1.37)/|
00000810  28 31 30 2e 39 37 2b 32  2a 73 79 29 2a 31 30 32  |(10.97+2*sy)*102|
00000820  34 2c 77 69 64 74 68 2c  38 2e 32 33 2f 28 31 30  |4,width,8.23/(10|
00000830  2e 39 37 2b 32 2a 73 79  29 2a 31 30 32 34 3a c8  |.97+2*sy)*1024:.|
00000840  93 20 c8 90 20 28 73 78  2b 31 38 2e 33 29 2f 28  |. .. (sx+18.3)/(|
00000850  32 33 2e 37 37 2b 32 2a  73 78 29 2a 31 32 38 30  |23.77+2*sx)*1280|
00000860  2c 28 73 79 2b 31 2e 33  37 29 2f 28 31 30 2e 39  |,(sy+1.37)/(10.9|
00000870  37 2b 32 2a 73 79 29 2a  31 30 32 34 2c 77 69 64  |7+2*sy)*1024,wid|
00000880  74 68 2c 38 2e 32 33 2f  28 31 30 2e 39 37 2b 32  |th,8.23/(10.97+2|
00000890  2a 73 79 29 2a 31 30 32  34 0d 01 cc 06 20 3a 0d  |*sy)*1024.... :.|
000008a0  01 d6 0f 20 f4 20 44 72  61 77 20 6e 65 74 0d 01  |... . Draw net..|
000008b0  e0 89 20 e6 30 2c 30 3a  e3 6c 3d 31 30 30 b8 39  |.. .0,0:.l=100.9|
000008c0  32 34 88 31 30 3a ec 20  36 34 30 2c 6c 3a df 20  |24.10:. 640,l:. |
000008d0  36 38 30 2c 6c 2b 35 30  3a ed 3a e3 6c 3d 30 b8  |680,l+50:.:.l=0.|
000008e0  34 30 88 31 30 3a ec 20  36 34 30 2b 6c 2c 31 30  |40.10:. 640+l,10|
000008f0  30 2b 6c 3a df 36 34 30  2b 6c 2c 39 32 34 2b 6c  |0+l:.640+l,924+l|
00000900  3a ed 3a e3 6c 3d 30 b8  35 3a ec 36 33 37 2b 6c  |:.:.l=0.5:.637+l|
00000910  2c 31 30 30 3a df 36 37  37 2b 6c 2c 31 35 30 3a  |,100:.677+l,150:|
00000920  ec 36 33 37 2b 6c 2c 39  32 34 3a df 36 37 37 2b  |.637+l,924:.677+|
00000930  6c 2c 39 37 34 3a ed 0d  01 ea 22 20 e6 30 2c 25  |l,974:...." .0,%|
00000940  31 31 31 31 31 31 3a ec  20 36 38 32 2c 31 34 32  |111111:. 682,142|
00000950  3a df 36 38 32 2c 39 36  36 0d 01 f4 0e 20 f2 64  |:.682,966.... .d|
00000960  72 61 77 6d 69 6e 69 0d  01 fe 06 20 e1 0d 02 08  |rawmini.... ....|
00000970  06 20 3a 0d 02 12 1d 20  f4 20 44 72 61 77 20 62  |. :.... . Draw b|
00000980  61 6c 6c 62 6f 74 20 61  6e 64 20 62 61 6c 6c 73  |allbot and balls|
00000990  0d 02 1c 0f 20 dd f2 64  72 61 77 6d 69 6e 69 0d  |.... ..drawmini.|
000009a0  02 26 14 20 e7 20 74 79  70 65 24 3d 22 32 22 20  |.&. . type$="2" |
000009b0  8c 20 e1 0d 02 30 16 20  e6 33 2c 25 30 30 31 30  |. ...0. .3,%0010|
000009c0  31 31 3a e3 62 3d 30 b8  34 0d 02 3a 42 20 e7 20  |11:.b=0.4..:B . |
000009d0  62 61 6c 6c 28 62 2c 30  29 3c 3e 30 20 84 20 62  |ball(b,0)<>0 . b|
000009e0  61 6c 6c 28 62 2c 31 29  3c 3e 30 20 8c 20 c8 93  |all(b,1)<>0 . ..|
000009f0  20 c8 90 20 62 61 6c 6c  28 62 2c 30 29 2c 62 61  | .. ball(b,0),ba|
00000a00  6c 6c 28 62 2c 31 29 2c  35 2c 35 0d 02 44 06 20  |ll(b,1),5,5..D. |
00000a10  ed 0d 02 4e 21 20 e6 33  2c 25 30 30 30 31 31 31  |...N! .3,%000111|
00000a20  3a c8 93 20 c8 90 20 62  62 78 2c 62 62 79 2c 35  |:.. .. bbx,bby,5|
00000a30  2c 35 0d 02 58 06 20 e1  0d 02 62 06 20 3a 0d 02  |,5..X. ...b. :..|
00000a40  6c 2a 20 f4 20 55 73 65  72 20 69 6e 74 65 72 66  |l* . User interf|
00000a50  61 63 65 20 28 70 75 74  74 69 6e 67 20 62 61 6c  |ace (putting bal|
00000a60  6c 73 20 64 6f 77 6e 29  0d 02 76 0b 20 dd f2 75  |ls down)..v. ..u|
00000a70  73 65 72 0d 02 80 0d 20  c8 97 20 78 2c 79 2c 63  |ser.... .. x,y,c|
00000a80  0d 02 8a 0e 20 e7 20 63  3d 30 20 8c 20 e1 0d 02  |.... . c=0 . ...|
00000a90  94 61 20 e7 20 28 63 20  80 20 34 29 3c 3e 30 20  |.a . (c . 4)<>0 |
00000aa0  8c 20 f2 64 72 61 77 6d  69 6e 69 3a 62 61 6c 6c  |. .drawmini:ball|
00000ab0  28 63 75 72 72 65 6e 74  2c 30 29 3d 78 3a 62 61  |(current,0)=x:ba|
00000ac0  6c 6c 28 63 75 72 72 65  6e 74 2c 31 29 3d 79 3a  |ll(current,1)=y:|
00000ad0  63 75 72 72 65 6e 74 3d  28 63 75 72 72 65 6e 74  |current=(current|
00000ae0  2b 31 29 83 35 3a f2 64  72 61 77 6d 69 6e 69 0d  |+1).5:.drawmini.|
00000af0  02 9e 2a 20 e7 20 28 63  20 80 20 32 29 3c 3e 30  |..* . (c . 2)<>0|
00000b00  20 8c 20 69 64 6c 65 3d  a3 3a 73 74 61 67 65 3d  | . idle=.:stage=|
00000b10  30 3a 73 74 61 72 74 3d  91 0d 02 a8 06 20 f5 0d  |0:start=..... ..|
00000b20  02 b2 0d 20 c8 97 20 78  2c 79 2c 63 0d 02 bc 0a  |... .. x,y,c....|
00000b30  20 fd 20 63 3d 30 0d 02  c6 06 20 e1 0d 02 d0 06  | . c=0.... .....|
00000b40  20 3a 0d 02 da 27 20 f4  20 43 61 6c 63 75 6c 61  | :...' . Calcula|
00000b50  74 65 20 62 61 6c 6c 62  6f 74 27 73 20 6e 65 77  |te ballbot's new|
00000b60  20 70 6f 73 69 74 69 6f  6e 0d 02 e4 0d 20 dd f2  | position.... ..|
00000b70  6d 6f 76 65 69 74 0d 02  ee 41 20 e7 20 28 6c 65  |moveit...A . (le|
00000b80  66 74 20 80 20 66 77 64  29 20 84 20 28 72 69 67  |ft . fwd) . (rig|
00000b90  68 74 20 80 20 72 65 76  65 72 73 65 29 20 8c 20  |ht . reverse) . |
00000ba0  64 69 72 3d 64 69 72 2d  32 2e 35 2a 28 31 2d 33  |dir=dir-2.5*(1-3|
00000bb0  2a 74 75 72 62 6f 29 0d  02 f8 41 20 e7 20 28 72  |*turbo)...A . (r|
00000bc0  69 67 68 74 20 80 20 66  77 64 29 20 84 20 28 6c  |ight . fwd) . (l|
00000bd0  65 66 74 20 80 20 72 65  76 65 72 73 65 29 20 8c  |eft . reverse) .|
00000be0  20 64 69 72 3d 64 69 72  2b 32 2e 35 2a 28 31 2d  | dir=dir+2.5*(1-|
00000bf0  33 2a 74 75 72 62 6f 29  0d 03 02 06 20 3a 0d 03  |3*turbo).... :..|
00000c00  0c 29 20 f4 20 47 65 74  20 64 69 72 65 63 74 69  |.) . Get directi|
00000c10  6f 6e 20 69 6e 20 72 61  6e 67 65 20 30 3c 74 68  |on in range 0<th|
00000c20  65 74 61 3c 33 36 30 0d  03 16 1c 20 f5 20 e7 20  |eta<360.... . . |
00000c30  64 69 72 3c 30 20 8c 20  64 69 72 3d 64 69 72 2b  |dir<0 . dir=dir+|
00000c40  33 36 30 0d 03 20 1d 20  e7 20 64 69 72 3e 3d 33  |360.. . . dir>=3|
00000c50  36 30 20 8c 20 64 69 72  3d 64 69 72 2d 33 36 30  |60 . dir=dir-360|
00000c60  0d 03 2a 17 20 fd 20 64  69 72 3e 3d 30 20 80 20  |..*. . dir>=0 . |
00000c70  64 69 72 3c 33 36 30 0d  03 34 06 20 3a 0d 03 3e  |dir<360..4. :..>|
00000c80  1c 20 66 72 3d 30 3a e7  20 66 77 64 20 8c 20 66  |. fr=0:. fwd . f|
00000c90  72 3d 66 72 2b 30 2e 32  35 0d 03 48 1b 20 e7 20  |r=fr+0.25..H. . |
00000ca0  72 65 76 65 72 73 65 20  8c 20 66 72 3d 66 72 2d  |reverse . fr=fr-|
00000cb0  30 2e 32 35 0d 03 52 16  20 e7 20 74 75 72 62 6f  |0.25..R. . turbo|
00000cc0  20 8c 20 66 72 3d 66 72  2a 34 0d 03 5c 29 20 f2  | . fr=fr*4..\) .|
00000cd0  64 72 61 77 6d 69 6e 69  3a 62 62 78 3d 62 62 78  |drawmini:bbx=bbx|
00000ce0  2b 31 36 2a b5 28 af 2a  64 69 72 2f 31 38 30 29  |+16*.(.*dir/180)|
00000cf0  2a 66 72 0d 03 66 1f 20  62 62 79 3d 62 62 79 2b  |*fr..f. bby=bby+|
00000d00  31 36 2a 9b 28 af 2a 64  69 72 2f 31 38 30 29 2a  |16*.(.*dir/180)*|
00000d10  66 72 0d 03 70 58 20 e3  62 61 6c 6c 3d 30 b8 34  |fr..pX .ball=0.4|
00000d20  3a e7 20 6f 70 65 6e 20  80 20 94 28 62 62 78 2d  |:. open . .(bbx-|
00000d30  62 61 6c 6c 28 62 61 6c  6c 2c 30 29 29 3c 31 30  |ball(ball,0))<10|
00000d40  20 80 20 94 28 62 62 79  2d 62 61 6c 6c 28 62 61  | . .(bby-ball(ba|
00000d50  6c 6c 2c 31 29 29 3c 31  30 20 8c 20 62 61 6c 6c  |ll,1))<10 . ball|
00000d60  28 62 61 6c 6c 2c 30 29  3d 30 0d 03 7a 10 20 ed  |(ball,0)=0..z. .|
00000d70  3a f2 64 72 61 77 6d 69  6e 69 0d 03 84 06 20 e1  |:.drawmini.... .|
00000d80  0d 03 8e 06 20 3a 0d 03  98 73 20 f4 20 43 61 6c  |.... :...s . Cal|
00000d90  63 75 6c 61 74 65 20 62  61 6c 6c 62 6f 74 27 73  |culate ballbot's|
00000da0  20 62 61 63 6b 67 72 6f  75 6e 64 20 65 63 68 6f  | background echo|
00000db0  20 72 65 61 64 69 6e 67  20 28 2d 62 61 6c 6c 73  | reading (-balls|
00000dc0  29 2c 20 75 73 69 6e 67  20 73 65 76 65 72 61 6c  |), using several|
00000dd0  20 70 6f 69 6e 74 73 20  74 6f 20 63 68 65 63 6b  | points to check|
00000de0  20 6f 75 74 20 77 68 65  72 65 20 6e 65 74 20 70  | out where net p|
00000df0  6f 73 74 73 20 61 72 65  2e 0d 03 a2 15 20 dd a4  |osts are..... ..|
00000e00  62 61 63 6b 28 78 2c 79  2c 66 72 65 71 29 0d 03  |back(x,y,freq)..|
00000e10  ac 12 20 ea 20 66 72 65  71 61 2c 64 75 6d 6d 79  |.. . freqa,dummy|
00000e20  0d 03 b6 2e 20 66 72 65  71 61 3d a4 62 61 63 6b  |.... freqa=.back|
00000e30  32 28 78 2c 79 2c 66 72  65 71 2c 31 30 30 2c 39  |2(x,y,freq,100,9|
00000e40  32 33 29 3a 66 74 79 70  65 24 3d 66 74 24 0d 03  |23):ftype$=ft$..|
00000e50  c0 17 20 e7 20 66 74 24  3d 22 55 22 20 8c 20 3d  |.. . ft$="U" . =|
00000e60  66 72 65 71 61 0d 03 ca  49 20 64 75 6d 6d 79 3d  |freqa...I dummy=|
00000e70  a4 62 61 63 6b 32 28 78  2c 79 2c 66 72 65 71 2c  |.back2(x,y,freq,|
00000e80  31 30 30 2c 31 32 35 29  3a e7 20 66 74 24 3d 22  |100,125):. ft$="|
00000e90  4e 22 20 80 20 64 75 6d  6d 79 3c 3d 66 72 65 71  |N" . dummy<=freq|
00000ea0  61 20 8c 20 66 74 79 70  65 24 3d 22 50 22 0d 03  |a . ftype$="P"..|
00000eb0  d4 49 20 64 75 6d 6d 79  3d a4 62 61 63 6b 32 28  |.I dummy=.back2(|
00000ec0  78 2c 79 2c 66 72 65 71  2c 38 39 38 2c 39 32 33  |x,y,freq,898,923|
00000ed0  29 3a e7 20 66 74 24 3d  22 4e 22 20 80 20 64 75  |):. ft$="N" . du|
00000ee0  6d 6d 79 3c 3d 66 72 65  71 61 20 8c 20 66 74 79  |mmy<=freqa . fty|
00000ef0  70 65 24 3d 22 50 22 0d  03 de 0b 20 3d 66 72 65  |pe$="P".... =fre|
00000f00  71 61 0d 03 e8 06 20 3a  0d 03 f2 27 20 f4 20 43  |qa.... :...' . C|
00000f10  61 6c 63 75 6c 61 74 65  20 72 65 61 64 69 6e 67  |alculate reading|
00000f20  20 66 72 6f 6d 20 6f 6e  65 20 70 6f 69 6e 74 0d  | from one point.|
00000f30  03 fc 1e 20 dd a4 62 61  63 6b 32 28 78 2c 79 2c  |... ..back2(x,y,|
00000f40  66 72 65 71 2c 6d 69 6e  2c 6d 61 78 29 0d 04 06  |freq,min,max)...|
00000f50  44 20 66 74 24 3d 22 55  22 3a f4 20 53 65 74 20  |D ft$="U":. Set |
00000f60  75 70 20 67 65 6e 65 72  61 6c 20 76 61 6c 75 65  |up general value|
00000f70  20 6f 66 20 66 72 65 71  75 65 6e 63 79 20 74 79  | of frequency ty|
00000f80  70 65 20 28 55 4e 49 44  45 4e 54 49 46 49 45 44  |pe (UNIDENTIFIED|
00000f90  29 0d 04 10 30 20 f4 20  43 61 6c 63 75 6c 61 74  |)...0 . Calculat|
00000fa0  65 20 41 6e 67 6c 65 20  6f 66 20 6e 65 74 20 61  |e Angle of net a|
00000fb0  73 20 73 65 65 6e 20 62  79 20 42 61 6c 6c 62 6f  |s seen by Ballbo|
00000fc0  74 0d 04 1a 0c 20 ea 20  66 72 65 71 61 0d 04 24  |t.... . freqa..$|
00000fd0  2b 20 6e 65 74 6c 6f 77  3d 28 a4 61 6e 67 6c 65  |+ netlow=(.angle|
00000fe0  28 36 34 30 2c 6d 61 78  2c 78 2c 79 29 2d 64 69  |(640,max,x,y)-di|
00000ff0  72 29 20 83 20 33 36 30  0d 04 2e 23 20 e7 20 6e  |r) . 360...# . n|
00001000  65 74 6c 6f 77 3c 30 20  8c 20 6e 65 74 6c 6f 77  |etlow<0 . netlow|
00001010  3d 6e 65 74 6c 6f 77 2b  33 36 30 0d 04 38 25 20  |=netlow+360..8% |
00001020  e7 20 6e 65 74 6c 6f 77  3e 31 38 30 20 8c 20 6e  |. netlow>180 . n|
00001030  65 74 6c 6f 77 3d 6e 65  74 6c 6f 77 2d 33 36 30  |etlow=netlow-360|
00001040  0d 04 42 2a 20 6e 65 74  68 69 3d 28 a4 61 6e 67  |..B* nethi=(.ang|
00001050  6c 65 28 36 34 30 2c 6d  69 6e 2c 78 2c 79 29 2d  |le(640,min,x,y)-|
00001060  64 69 72 29 20 83 20 33  36 30 0d 04 4c 20 20 e7  |dir) . 360..L  .|
00001070  20 6e 65 74 68 69 3c 30  20 8c 20 6e 65 74 68 69  | nethi<0 . nethi|
00001080  3d 6e 65 74 68 69 2b 33  36 30 0d 04 56 22 20 e7  |=nethi+360..V" .|
00001090  20 6e 65 74 68 69 3e 31  38 30 20 8c 20 6e 65 74  | nethi>180 . net|
000010a0  68 69 3d 6e 65 74 68 69  2d 33 36 30 0d 04 60 06  |hi=nethi-360..`.|
000010b0  20 3a 0d 04 6a 18 20 f4  20 43 61 6c 63 75 6c 61  | :..j. . Calcula|
000010c0  74 65 20 72 65 61 64 69  6e 67 0d 04 74 16 20 66  |te reading..t. f|
000010d0  72 65 71 61 3d 66 72 65  71 2b b3 28 36 29 2d 33  |reqa=freq+.(6)-3|
000010e0  0d 04 7e 8b 20 e7 20 94  28 b5 28 af 2a 64 69 72  |..~. . .(.(.*dir|
000010f0  2f 31 38 30 29 29 3e 30  2e 30 31 20 8c 20 e7 20  |/180))>0.01 . . |
00001100  28 28 6e 65 74 6c 6f 77  3c 30 20 80 20 6e 65 74  |((netlow<0 . net|
00001110  68 69 3e 30 29 20 84 20  28 6e 65 74 68 69 3c 30  |hi>0) . (nethi<0|
00001120  20 80 20 6e 65 74 6c 6f  77 3e 30 29 29 20 80 20  | . netlow>0)) . |
00001130  28 36 34 30 2d 78 29 2f  b5 28 af 2a 64 69 72 2f  |(640-x)/.(.*dir/|
00001140  31 38 30 29 3e 30 20 8c  20 66 72 65 71 61 3d 28  |180)>0 . freqa=(|
00001150  36 34 30 2d 78 29 2f b5  28 af 2a 64 69 72 2f 31  |640-x)/.(.*dir/1|
00001160  38 30 29 3a 66 74 24 3d  22 4e 22 0d 04 88 0b 20  |80):ft$="N".... |
00001170  3d 66 72 65 71 61 0d 04  92 06 20 3a 0d 04 9c 32  |=freqa.... :...2|
00001180  20 f4 20 43 61 6c 63 75  6c 61 74 65 20 42 61 6c  | . Calculate Bal|
00001190  6c 62 6f 74 27 73 20 72  65 61 64 69 6e 67 73 20  |lbot's readings |
000011a0  28 4d 41 49 4e 20 52 4f  55 54 49 4e 45 29 0d 04  |(MAIN ROUTINE)..|
000011b0  a6 06 20 3a 0d 04 b0 0c  20 dd f2 73 65 6e 73 65  |.. :.... ..sense|
000011c0  0d 04 ba 2a 20 f4 20 47  65 74 20 62 61 63 6b 67  |...* . Get backg|
000011d0  72 6f 75 6e 64 20 72 65  61 64 69 6e 67 73 20 66  |round readings f|
000011e0  72 6f 6d 20 46 4e 62 61  63 6b 0d 04 c4 15 20 66  |rom FNback.... f|
000011f0  72 65 71 3d b3 28 32 35  30 29 2b 31 35 30 30 0d  |req=.(250)+1500.|
00001200  04 ce 29 20 66 72 65 71  61 3d a4 62 61 63 6b 28  |..) freqa=.back(|
00001210  62 62 78 2c 62 62 79 2c  66 72 65 71 29 3a 66 61  |bbx,bby,freq):fa|
00001220  24 3d 66 74 79 70 65 24  0d 04 d8 34 20 64 69 72  |$=ftype$...4 dir|
00001230  3d 64 69 72 2d 33 30 3a  66 72 65 71 62 3d a4 62  |=dir-30:freqb=.b|
00001240  61 63 6b 28 62 62 78 2c  62 62 79 2c 66 72 65 71  |ack(bbx,bby,freq|
00001250  29 3a 66 62 24 3d 66 74  79 70 65 24 0d 04 e2 34  |):fb$=ftype$...4|
00001260  20 64 69 72 3d 64 69 72  2b 36 30 3a 66 72 65 71  | dir=dir+60:freq|
00001270  63 3d a4 62 61 63 6b 28  62 62 78 2c 62 62 79 2c  |c=.back(bbx,bby,|
00001280  66 72 65 71 29 3a 66 63  24 3d 66 74 79 70 65 24  |freq):fc$=ftype$|
00001290  0d 04 ec 40 20 64 69 72  3d 64 69 72 2d 31 30 35  |...@ dir=dir-105|
000012a0  3a 66 72 65 71 64 3d a4  62 61 63 6b 28 62 62 78  |:freqd=.back(bbx|
000012b0  2c 62 62 79 2c 66 72 65  71 29 3a 64 69 72 3d 64  |,bby,freq):dir=d|
000012c0  69 72 2b 37 35 3a 66 64  24 3d 66 74 79 70 65 24  |ir+75:fd$=ftype$|
000012d0  0d 04 f6 06 20 3a 0d 05  00 44 20 f4 20 41 64 64  |.... :...D . Add|
000012e0  20 61 6e 79 20 72 65 6c  65 76 61 6e 74 20 62 61  | any relevant ba|
000012f0  6c 6c 73 20 74 6f 20 72  65 61 64 69 6e 67 73 20  |lls to readings |
00001300  28 75 73 69 6e 67 20 68  61 69 72 79 20 74 72 69  |(using hairy tri|
00001310  67 6f 6e 6f 6d 65 74 72  79 29 0d 05 0a 06 20 3a  |gonometry).... :|
00001320  0d 05 14 0e 20 e3 62 61  6c 6c 3d 30 b8 34 0d 05  |.... .ball=0.4..|
00001330  1e 34 20 64 25 3d b6 28  28 62 61 6c 6c 28 62 61  |.4 d%=.((ball(ba|
00001340  6c 6c 2c 30 29 2d 62 62  78 29 5e 32 2b 28 62 61  |ll,0)-bbx)^2+(ba|
00001350  6c 6c 28 62 61 6c 6c 2c  31 29 2d 62 62 79 29 5e  |ll(ball,1)-bby)^|
00001360  32 29 0d 05 28 1f 20 e7  20 62 61 6c 6c 28 62 61  |2)..(. . ball(ba|
00001370  6c 6c 2c 30 29 3d 30 20  8c 20 64 25 3d 39 39 39  |ll,0)=0 . d%=999|
00001380  39 0d 05 32 45 20 61 3d  a4 61 6e 67 6c 65 28 62  |9..2E a=.angle(b|
00001390  61 6c 6c 28 62 61 6c 6c  2c 30 29 2c 62 61 6c 6c  |all(ball,0),ball|
000013a0  28 62 61 6c 6c 2c 31 29  2c 62 62 78 2c 62 62 79  |(ball,1),bbx,bby|
000013b0  29 2d 64 69 72 3a e7 61  3e 31 38 30 20 8c 20 61  |)-dir:.a>180 . a|
000013c0  3d 61 2d 33 36 30 0d 05  3c 2c 20 e7 20 94 28 61  |=a-360..<, . .(a|
000013d0  29 3c 31 35 20 80 20 66  72 65 71 61 3e 64 25 20  |)<15 . freqa>d% |
000013e0  8c 20 66 72 65 71 61 3d  64 25 3a 66 61 24 3d 22  |. freqa=d%:fa$="|
000013f0  42 22 0d 05 46 33 20 e7  20 61 3e 2d 34 36 20 80  |B"..F3 . a>-46 .|
00001400  20 61 3c 3d 2d 31 35 20  80 20 66 72 65 71 62 3e  | a<=-15 . freqb>|
00001410  64 25 20 8c 20 66 72 65  71 62 3d 64 25 3a 66 62  |d% . freqb=d%:fb|
00001420  24 3d 22 42 22 0d 05 50  31 20 e7 20 61 3e 3d 31  |$="B"..P1 . a>=1|
00001430  35 20 80 20 61 3c 34 36  20 80 20 66 72 65 71 63  |5 . a<46 . freqc|
00001440  3e 64 25 20 8c 20 66 72  65 71 63 3d 64 25 3a 66  |>d% . freqc=d%:f|
00001450  63 24 3d 22 42 22 0d 05  5a 33 20 e7 20 61 3e 2d  |c$="B"..Z3 . a>-|
00001460  39 30 20 80 20 61 3c 3d  2d 34 36 20 80 20 66 72  |90 . a<=-46 . fr|
00001470  65 71 64 3e 64 25 20 8c  20 66 72 65 71 64 3d 64  |eqd>d% . freqd=d|
00001480  25 3a 66 64 24 3d 22 42  22 0d 05 64 06 20 ed 0d  |%:fd$="B"..d. ..|
00001490  05 6e 06 20 3a 0d 05 78  1b 20 f4 20 55 70 64 61  |.n. :..x. . Upda|
000014a0  74 65 20 75 73 65 72 20  64 69 73 70 6c 61 79 73  |te user displays|
000014b0  0d 05 82 06 20 3a 0d 05  8c 14 20 e7 20 74 79 70  |.... :.... . typ|
000014c0  65 24 3d 22 32 22 20 8c  20 e1 0d 05 96 3b 20 f1  |e$="2" . ....; .|
000014d0  8a 30 2c 30 29 a8 28 28  91 2d 73 74 61 72 74 29  |.0,0).((.-start)|
000014e0  2f 31 32 30 30 30 29 3b  22 3a 22 3b 28 a8 28 28  |/12000);":";(.((|
000014f0  91 2d 73 74 61 72 74 29  2f 32 30 30 29 83 36 30  |.-start)/200).60|
00001500  29 3b 22 20 22 0d 05 a0  43 20 f1 8a 30 2c 33 31  |);" "...C ..0,31|
00001510  29 66 64 24 2c 66 62 24  2c 66 61 24 2c 66 63 24  |)fd$,fb$,fa$,fc$|
00001520  2c 73 74 61 67 65 2c a8  28 73 65 61 72 63 68 69  |,stage,.(searchi|
00001530  6e 67 29 2c 6c 65 66 74  2c 72 69 67 68 74 2c 6f  |ng),left,right,o|
00001540  70 65 6e 63 74 65 72 3b  0d 05 aa 37 20 d4 20 31  |pencter;...7 . 1|
00001550  2c 2d 31 2c 66 72 65 71  61 2f 34 2c 35 3a d4 20  |,-1,freqa/4,5:. |
00001560  32 2c 2d 31 2c 66 72 65  71 62 2f 34 2c 35 3a d4  |2,-1,freqb/4,5:.|
00001570  20 33 2c 2d 31 2c 66 72  65 71 63 2f 34 2c 35 0d  | 3,-1,freqc/4,5.|
00001580  05 b4 06 20 e1 0d 05 be  05 3a 0d 05 c8 24 20 f4  |... .....:...$ .|
00001590  20 43 61 6c 63 75 6c 61  74 65 20 62 65 61 72 69  | Calculate beari|
000015a0  6e 67 20 6f 66 20 42 20  66 72 6f 6d 20 41 0d 05  |ng of B from A..|
000015b0  d2 19 20 dd a4 61 6e 67  6c 65 28 78 31 2c 79 31  |.. ..angle(x1,y1|
000015c0  2c 78 32 2c 79 32 29 0d  05 dc 34 20 e7 20 79 32  |,x2,y2)...4 . y2|
000015d0  3d 79 31 20 8c 20 61 6e  67 3d 39 30 20 8b 20 61  |=y1 . ang=90 . a|
000015e0  6e 67 3d 31 38 30 2a 99  28 28 78 32 2d 78 31 29  |ng=180*.((x2-x1)|
000015f0  2f 28 79 32 2d 79 31 29  29 2f af 0d 05 e6 1c 20  |/(y2-y1))/..... |
00001600  e7 20 28 79 32 3e 79 31  29 20 8c 20 61 6e 67 3d  |. (y2>y1) . ang=|
00001610  61 6e 67 2b 31 38 30 0d  05 f0 1a 20 e7 20 61 6e  |ang+180.... . an|
00001620  67 3c 30 20 8c 20 61 6e  67 3d 61 6e 67 2b 33 36  |g<0 . ang=ang+36|
00001630  30 0d 05 fa 0f 20 3d 61  6e 67 20 83 20 33 36 30  |0.... =ang . 360|
00001640  0d 06 04 06 20 3a 0d 06  0e 2d 20 f4 20 43 6f 6d  |.... :...- . Com|
00001650  70 75 74 65 72 20 4d 6f  6e 69 74 6f 72 20 6f 66  |puter Monitor of|
00001660  20 42 61 6c 6c 42 6f 74  27 73 20 70 72 6f 67 72  | BallBot's progr|
00001670  65 73 73 0d 06 18 0e 20  dd f2 63 6f 6d 70 6d 6f  |ess.... ..compmo|
00001680  6e 0d 06 1d 72 20 e7 20  69 64 6c 65 20 80 20 28  |n...r . idle . (|
00001690  62 61 6c 6c 28 30 2c 30  29 3c 3e 30 20 84 20 62  |ball(0,0)<>0 . b|
000016a0  61 6c 6c 28 31 2c 30 29  3c 3e 30 20 84 20 62 61  |all(1,0)<>0 . ba|
000016b0  6c 6c 28 32 2c 30 29 3c  3e 30 20 84 20 62 61 6c  |ll(2,0)<>0 . bal|
000016c0  6c 28 33 2c 30 29 3c 3e  30 20 84 20 62 61 6c 6c  |l(3,0)<>0 . ball|
000016d0  28 34 2c 30 29 3c 3e 30  29 20 8c 20 73 74 24 3d  |(4,0)<>0) . st$=|
000016e0  22 46 61 69 6c 22 20 8b  20 73 74 24 3d 22 50 61  |"Fail" . st$="Pa|
000016f0  73 73 22 0d 06 22 3f 20  e7 20 69 64 6c 65 20 8c  |ss".."? . idle .|
00001700  20 f1 73 74 24 2c a8 28  28 91 2d 73 74 61 72 74  | .st$,.((.-start|
00001710  29 2f 31 32 30 30 30 29  3b 22 3a 22 3b 28 a8 28  |)/12000);":";(.(|
00001720  28 91 2d 73 74 61 72 74  29 2f 32 30 30 29 83 36  |(.-start)/200).6|
00001730  30 29 0d 06 2c 2c 20 e7  20 91 3e 73 74 61 72 74  |0)..,, . .>start|
00001740  2b 34 38 30 30 30 20 8c  20 69 64 6c 65 3d b9 3a  |+48000 . idle=.:|
00001750  f1 22 54 69 6d 65 22 2c  22 2a 2a 2a 2a 22 0d 06  |."Time","****"..|
00001760  36 3c 20 e7 62 62 78 3e  36 33 30 80 62 62 78 3c  |6< .bbx>630.bbx<|
00001770  36 35 30 80 62 62 79 3e  31 30 30 80 62 62 79 3c  |650.bby>100.bby<|
00001780  39 32 33 8c 69 64 6c 65  3d b9 3a f1 22 43 72 61  |923.idle=.:."Cra|
00001790  73 68 22 2c 22 2a 2a 2a  2a 22 0d 06 40 6b 20 e7  |sh","****"..@k .|
000017a0  20 69 64 6c 65 20 8c 20  62 62 78 3d 36 34 30 3a  | idle . bbx=640:|
000017b0  62 62 79 3d 39 35 30 3a  64 69 72 3d 32 37 30 3a  |bby=950:dir=270:|
000017c0  73 74 61 67 65 3d 30 3a  f2 73 65 74 75 70 62 62  |stage=0:.setupbb|
000017d0  3a 73 74 61 72 74 3d 91  3a e3 62 3d 30 b8 34 3a  |:start=.:.b=0.4:|
000017e0  62 61 6c 6c 28 62 2c 30  29 3d b3 28 31 32 38 30  |ball(b,0)=.(1280|
000017f0  29 3a 62 61 6c 6c 28 62  2c 31 29 3d b3 28 31 30  |):ball(b,1)=.(10|
00001800  32 34 29 3a ed 0d 06 45  af 20 e7 20 69 64 6c 65  |24):...E. . idle|
00001810  20 8c 20 f1 22 5b 22 3b  62 61 6c 6c 28 30 2c 30  | . ."[";ball(0,0|
00001820  29 3b 22 2c 22 3b 62 61  6c 6c 28 30 2c 31 29 3b  |);",";ball(0,1);|
00001830  22 5d 20 5b 22 3b 62 61  6c 6c 28 31 2c 30 29 3b  |"] [";ball(1,0);|
00001840  22 2c 22 3b 62 61 6c 6c  28 31 2c 31 29 3b 22 5d  |",";ball(1,1);"]|
00001850  20 5b 22 3b 62 61 6c 6c  28 32 2c 30 29 3b 22 2c  | [";ball(2,0);",|
00001860  22 3b 62 61 6c 6c 28 32  2c 31 29 3b 22 5d 20 5b  |";ball(2,1);"] [|
00001870  22 3b 62 61 6c 6c 28 33  2c 30 29 3b 22 2c 22 3b  |";ball(3,0);",";|
00001880  62 61 6c 6c 28 33 2c 31  29 3b 22 5d 20 5b 22 3b  |ball(3,1);"] [";|
00001890  62 61 6c 6c 28 34 2c 30  29 3b 22 2c 22 3b 62 61  |ball(4,0);",";ba|
000018a0  6c 6c 28 34 2c 31 29 3b  22 5d 22 2c 3b 3a 69 64  |ll(4,1);"]",;:id|
000018b0  6c 65 3d a3 0d 06 4a 06  20 e1 0d 06 54 06 20 3a  |le=...J. ...T. :|
000018c0  0d 06 5e 2a 20 f4 20 42  41 4c 4c 42 4f 54 20 52  |..^* . BALLBOT R|
000018d0  4f 42 4f 54 49 43 20 49  4e 54 45 4c 4c 49 47 45  |OBOTIC INTELLIGE|
000018e0  4e 43 45 20 4d 4f 44 55  4c 45 0d 06 68 06 20 3a  |NCE MODULE..h. :|
000018f0  0d 06 72 1c 20 dd a4 61  69 28 66 72 65 71 61 2c  |..r. ..ai(freqa,|
00001900  66 72 65 71 62 2c 66 72  65 71 63 29 0d 06 7c 39  |freqb,freqc)..|9|
00001910  20 f4 20 41 72 74 69 66  69 63 69 61 6c 20 69 6e  | . Artificial in|
00001920  74 65 6c 6c 69 67 65 6e  63 65 20 72 6f 75 74 69  |telligence routi|
00001930  6e 65 73 20 28 69 65 2e  20 57 68 61 74 20 4e 65  |nes (ie. What Ne|
00001940  78 74 3f 3f 29 0d 06 86  22 20 ea 66 77 64 2c 72  |xt??)..." .fwd,r|
00001950  65 76 65 72 73 65 2c 6c  65 66 74 2c 72 69 67 68  |everse,left,righ|
00001960  74 2c 74 75 72 62 6f 0d  06 90 2b 20 66 77 64 3d  |t,turbo...+ fwd=|
00001970  b9 3a 72 65 76 65 72 73  65 3d a3 3a 6c 65 66 74  |.:reverse=.:left|
00001980  3d a3 3a 72 69 67 68 74  3d a3 3a 74 75 72 62 6f  |=.:right=.:turbo|
00001990  3d a3 0d 06 9a 06 20 3a  0d 06 a4 40 20 f4 20 57  |=..... :...@ . W|
000019a0  68 61 74 20 73 74 61 67  65 20 61 72 65 20 77 65  |hat stage are we|
000019b0  20 69 6e 3f 20 48 75 6e  74 20 66 6f 72 20 62 61  | in? Hunt for ba|
000019c0  6c 6c 73 20 6f 72 20 6d  6f 76 65 20 74 6f 20 6e  |lls or move to n|
000019d0  65 77 20 61 72 65 61 3f  0d 06 ae 27 20 e7 20 6e  |ew area?...' . n|
000019e0  65 61 72 3c 3e 30 20 80  20 73 74 61 67 65 3c 38  |ear<>0 . stage<8|
000019f0  20 8c 20 f2 64 6f 6e 65  61 72 73 74 75 66 66 0d  | . .donearstuff.|
00001a00  06 b8 2b 20 e7 20 6e 65  61 72 3d 30 20 80 20 28  |..+ . near=0 . (|
00001a10  73 74 61 67 65 3d 30 20  84 20 73 74 61 67 65 3d  |stage=0 . stage=|
00001a20  32 29 20 8c 20 f2 68 75  6e 74 0d 06 c2 2e 20 e7  |2) . .hunt.... .|
00001a30  20 6e 65 61 72 3d 30 20  80 20 28 73 74 61 67 65  | near=0 . (stage|
00001a40  3d 31 20 84 20 73 74 61  67 65 3d 33 29 20 8c 20  |=1 . stage=3) . |
00001a50  f2 6d 6f 76 65 6f 75 74  0d 06 cc 1a 20 e7 20 73  |.moveout.... . s|
00001a60  74 61 67 65 3d 34 20 8c  20 f2 72 65 6c 65 61 73  |tage=4 . .releas|
00001a70  65 62 0d 06 d6 06 20 3a  0d 06 e0 32 20 f4 20 50  |eb.... :...2 . P|
00001a80  72 65 70 61 72 65 20 6f  75 74 70 75 74 20 69 6e  |repare output in|
00001a90  74 6f 20 62 69 6e 61 72  79 20 66 6f 72 20 74 72  |to binary for tr|
00001aa0  61 6e 73 6d 69 73 73 69  6f 6e 0d 06 ea 1f 20 66  |ansmission.... f|
00001ab0  65 65 64 3d 30 3a e7 20  66 77 64 20 8c 20 66 65  |eed=0:. fwd . fe|
00001ac0  65 64 3d 66 65 65 64 2b  31 0d 06 f4 17 20 e7 20  |ed=feed+1.... . |
00001ad0  72 65 76 69 6e 67 20 8c  20 74 75 72 62 6f 3d b9  |reving . turbo=.|
00001ae0  0d 06 fe 1c 20 e7 20 72  65 76 65 72 73 65 20 8c  |.... . reverse .|
00001af0  20 66 65 65 64 3d 66 65  65 64 2b 32 0d 07 08 19  | feed=feed+2....|
00001b00  20 e7 20 6c 65 66 74 20  8c 20 66 65 65 64 3d 66  | . left . feed=f|
00001b10  65 65 64 2b 34 0d 07 12  1a 20 e7 20 72 69 67 68  |eed+4.... . righ|
00001b20  74 20 8c 20 66 65 65 64  3d 66 65 65 64 2b 38 0d  |t . feed=feed+8.|
00001b30  07 1c 1b 20 e7 20 74 75  72 62 6f 20 8c 20 66 65  |... . turbo . fe|
00001b40  65 64 3d 66 65 65 64 2b  31 36 0d 07 26 20 20 e7  |ed=feed+16..&  .|
00001b50  20 6f 70 65 6e 63 74 65  72 3e 30 20 8c 20 66 65  | opencter>0 . fe|
00001b60  65 64 3d 66 65 65 64 2b  33 32 0d 07 30 0a 20 3d  |ed=feed+32..0. =|
00001b70  66 65 65 64 0d 07 3a 06  20 3a 0d 07 44 28 20 f4  |feed..:. :..D( .|
00001b80  20 50 65 72 66 6f 72 6d  20 61 20 73 77 65 65 70  | Perform a sweep|
00001b90  20 74 6f 20 66 69 6e 64  20 61 6e 79 20 62 61 6c  | to find any bal|
00001ba0  6c 73 0d 07 4e 0b 20 dd  f2 68 75 6e 74 0d 07 58  |ls..N. ..hunt..X|
00001bb0  23 20 f4 20 57 61 74 63  68 20 6f 75 74 20 69 66  |# . Watch out if|
00001bc0  20 74 6f 6f 20 6e 65 61  72 20 74 6f 20 6e 65 74  | too near to net|
00001bd0  0d 07 62 be 20 e7 28 28  66 72 65 71 61 3c 32 30  |..b. .((freqa<20|
00001be0  80 20 66 61 24 3c 3e 22  42 22 29 84 28 66 72 65  |. fa$<>"B").(fre|
00001bf0  71 62 3c 32 30 80 20 66  62 24 3c 3e 22 42 22 29  |qb<20. fb$<>"B")|
00001c00  84 28 66 72 65 71 63 3c  32 30 80 20 66 63 24 3c  |.(freqc<20. fc$<|
00001c10  3e 22 42 22 29 29 84 28  72 65 76 69 6e 67 20 80  |>"B")).(reving .|
00001c20  28 28 66 72 65 71 61 3c  31 35 30 80 20 66 61 24  |((freqa<150. fa$|
00001c30  3c 3e 22 42 22 29 84 28  66 72 65 71 62 3c 31 35  |<>"B").(freqb<15|
00001c40  30 80 20 66 62 24 3c 3e  22 42 22 29 84 28 66 72  |0. fb$<>"B").(fr|
00001c50  65 71 63 3c 31 35 30 80  20 66 63 24 3c 3e 22 42  |eqc<150. fc$<>"B|
00001c60  22 29 29 29 8c 72 65 76  69 6e 67 3d b9 3a 72 65  |"))).reving=.:re|
00001c70  76 65 72 73 65 3d b9 3a  66 77 64 3d a3 3a 6c 65  |verse=.:fwd=.:le|
00001c80  66 74 3d a3 3a 72 69 67  68 74 3d b9 3a e1 0d 07  |ft=.:right=.:...|
00001c90  6c 0d 20 72 65 76 69 6e  67 3d a3 0d 07 76 06 20  |l. reving=...v. |
00001ca0  3a 0d 07 80 3a 20 f4 20  49 66 20 42 61 6c 6c 20  |:...: . If Ball |
00001cb0  69 73 20 6f 75 74 20 6f  66 20 72 65 61 63 68 20  |is out of reach |
00001cc0  69 6e 20 74 68 65 20 22  44 22 20 73 65 63 74 6f  |in the "D" secto|
00001cd0  72 2c 20 72 65 76 65 72  73 65 21 0d 07 8a bf 20  |r, reverse!.... |
00001ce0  46 44 52 3d 66 72 65 71  64 2a 31 2e 32 35 3a e7  |FDR=freqd*1.25:.|
00001cf0  66 72 65 71 64 3c 31 35  30 80 66 64 24 3d 22 42  |freqd<150.fd$="B|
00001d00  22 80 46 44 52 3c 66 72  65 71 61 20 80 46 44 52  |".FDR<freqa .FDR|
00001d10  3c 66 72 65 71 62 20 80  46 44 52 3c 66 72 65 71  |<freqb .FDR<freq|
00001d20  63 20 80 28 66 61 24 3c  3e 22 42 22 84 66 72 65  |c .(fa$<>"B".fre|
00001d30  71 61 3e 31 30 30 29 80  28 66 62 24 3c 3e 22 42  |qa>100).(fb$<>"B|
00001d40  22 84 66 72 65 71 62 3e  31 30 30 29 80 28 66 63  |".freqb>100).(fc|
00001d50  24 3c 3e 22 42 22 84 66  72 65 71 63 3e 31 30 30  |$<>"B".freqc>100|
00001d60  29 8c 20 74 75 72 62 6f  3d b9 3a 72 65 76 65 72  |). turbo=.:rever|
00001d70  73 65 3d b9 3a 66 77 64  3d a3 3a 72 69 67 68 74  |se=.:fwd=.:right|
00001d80  3d b9 3a 66 61 72 6c 65  66 74 3d 2d 36 2a 28 66  |=.:farleft=-6*(f|
00001d90  72 65 71 64 3e 34 30 29  3a e1 0d 07 94 12 20 e7  |reqd>40):..... .|
00001da0  20 66 61 72 6c 65 66 74  3e 30 20 8c 0d 07 9e 37  | farleft>0 ....7|
00001db0  20 20 66 61 72 6c 65 66  74 3d 66 61 72 6c 65 66  |  farleft=farlef|
00001dc0  74 2d 31 3a 72 65 76 65  72 73 65 3d b9 3a 66 77  |t-1:reverse=.:fw|
00001dd0  64 3d a3 3a 72 69 67 68  74 3d b9 3a 74 75 72 62  |d=.:right=.:turb|
00001de0  6f 3d b9 0d 07 a8 33 20  20 e7 20 66 61 24 3d 22  |o=....3  . fa$="|
00001df0  42 22 20 84 20 28 66 64  24 3c 3e 22 42 22 20 80  |B" . (fd$<>"B" .|
00001e00  20 66 62 24 3c 3e 22 42  22 29 20 8c 20 66 61 72  | fb$<>"B") . far|
00001e10  6c 65 66 74 3d 30 0d 07  b2 07 20 20 e1 0d 07 bc  |left=0....  ....|
00001e20  06 20 cd 0d 07 c6 06 20  3a 0d 07 d0 1a 20 f4 20  |. ..... :.... . |
00001e30  52 6f 74 61 74 65 20 74  6f 20 66 61 63 65 20 62  |Rotate to face b|
00001e40  61 6c 6c 0d 07 d2 40 20  e7 20 28 66 62 24 3d 22  |all...@ . (fb$="|
00001e50  42 22 20 80 20 66 72 65  71 62 3e 31 35 30 29 20  |B" . freqb>150) |
00001e60  84 20 28 66 64 24 3d 22  42 22 20 80 20 66 72 65  |. (fd$="B" . fre|
00001e70  71 64 3e 31 35 30 29 20  8c 20 74 65 6e 64 69 6e  |qd>150) . tendin|
00001e80  67 3d 30 0d 07 d3 26 20  e7 20 66 63 24 3d 22 42  |g=0...& . fc$="B|
00001e90  22 20 80 20 66 72 65 71  63 3e 31 35 30 20 8c 20  |" . freqc>150 . |
00001ea0  74 65 6e 64 69 6e 67 3d  31 0d 07 d5 29 20 e7 20  |tending=1...) . |
00001eb0  6f 70 65 6e 63 74 65 72  3e 30 20 8c 20 6f 70 65  |opencter>0 . ope|
00001ec0  6e 63 74 65 72 3d 6f 70  65 6e 63 74 65 72 2d 31  |ncter=opencter-1|
00001ed0  3a e1 0d 07 da 66 20 6f  70 65 6e 63 74 65 72 3d  |:....f opencter=|
00001ee0  2d 35 2a 28 28 28 66 72  65 71 61 3c 32 30 29 80  |-5*(((freqa<20).|
00001ef0  66 61 24 3d 22 42 22 29  84 28 28 66 72 65 71 62  |fa$="B").((freqb|
00001f00  3c 32 30 29 80 66 62 24  3d 22 42 22 29 84 28 28  |<20).fb$="B").((|
00001f10  66 72 65 71 63 3c 32 30  29 80 66 63 24 3d 22 42  |freqc<20).fc$="B|
00001f20  22 29 84 28 28 66 72 65  71 64 3c 32 30 29 80 66  |").((freqd<20).f|
00001f30  64 24 3d 22 42 22 29 29  0d 07 e4 60 20 e7 20 66  |d$="B"))...` . f|
00001f40  61 24 3d 22 42 22 20 8c  20 6c 65 66 74 3d 28 73  |a$="B" . left=(s|
00001f50  74 65 65 72 3d 2d 31 29  3a 72 69 67 68 74 3d 28  |teer=-1):right=(|
00001f60  73 74 65 65 72 3d 31 29  3a 73 74 65 65 72 3d 30  |steer=1):steer=0|
00001f70  3a 73 65 61 72 63 68 69  6e 67 3d 73 65 61 72 63  |:searching=searc|
00001f80  68 69 6e 67 2f 32 3a 74  75 72 62 6f 3d 66 72 65  |hing/2:turbo=fre|
00001f90  71 61 3e 31 30 30 3a e1  0d 07 ee 2c 20 e7 20 66  |qa>100:...., . f|
00001fa0  62 24 3d 22 42 22 20 84  20 66 64 24 3d 22 42 22  |b$="B" . fd$="B"|
00001fb0  20 8c 20 73 74 65 65 72  3d 2d 31 3a 6c 65 66 74  | . steer=-1:left|
00001fc0  3d b9 3a e1 0d 07 f8 22  20 e7 20 66 63 24 3d 22  |=.:...." . fc$="|
00001fd0  42 22 20 8c 20 73 74 65  65 72 3d 31 3a 72 69 67  |B" . steer=1:rig|
00001fe0  68 74 3d b9 3a e1 0d 08  02 30 20 f4 20 49 66 20  |ht=.:....0 . If |
00001ff0  6e 6f 20 62 61 6c 6c 20  69 6e 20 73 69 67 68 74  |no ball in sight|
00002000  2c 20 63 6f 6e 74 69 6e  75 65 20 72 6f 74 61 74  |, continue rotat|
00002010  69 6f 6e 2e 2e 2e 0d 08  0c 22 20 61 6c 69 67 6e  |ion......" align|
00002020  3d a3 3a 73 65 61 72 63  68 69 6e 67 3d 73 65 61  |=.:searching=sea|
00002030  72 63 68 69 6e 67 2b 31  0d 08 16 2a 20 e7 20 28  |rching+1...* . (|
00002040  74 65 6e 64 69 6e 67 20  80 20 31 29 3c 3e 30 20  |tending . 1)<>0 |
00002050  8c 20 72 69 67 68 74 3d  b9 20 8b 20 6c 65 66 74  |. right=. . left|
00002060  3d b9 0d 08 20 2a 20 e7  20 73 65 61 72 63 68 69  |=... * . searchi|
00002070  6e 67 3d 35 20 8c 20 74  65 6e 64 69 6e 67 3d 28  |ng=5 . tending=(|
00002080  74 65 6e 64 69 6e 67 20  82 20 31 29 0d 08 34 24  |tending . 1)..4$|
00002090  20 e7 20 73 65 61 72 63  68 69 6e 67 3e 31 35 30  | . searching>150|
000020a0  20 8c 20 73 74 61 67 65  3d 73 74 61 67 65 2b 31  | . stage=stage+1|
000020b0  0d 08 3e 06 20 e1 0d 08  48 06 20 3a 0d 08 52 3c  |..>. ...H. :..R<|
000020c0  20 f4 20 46 69 6e 64 20  65 64 67 65 20 6f 66 20  | . Find edge of |
000020d0  6e 65 74 20 61 6e 64 20  61 69 6d 20 66 6f 72 20  |net and aim for |
000020e0  69 74 20 74 6f 20 6d 6f  76 65 20 74 6f 20 6f 74  |it to move to ot|
000020f0  68 65 72 20 73 69 64 65  0d 08 5c 0e 20 dd f2 6d  |her side..\. ..m|
00002100  6f 76 65 6f 75 74 0d 08  66 23 20 f4 20 57 61 74  |oveout..f# . Wat|
00002110  63 68 20 6f 75 74 20 69  66 20 74 6f 6f 20 6e 65  |ch out if too ne|
00002120  61 72 20 74 6f 20 6e 65  74 0d 08 70 b0 20 e7 20  |ar to net..p. . |
00002130  28 66 72 65 71 61 3c 33  30 20 84 20 66 72 65 71  |(freqa<30 . freq|
00002140  62 3c 33 30 20 84 20 66  72 65 71 63 3c 33 30 29  |b<30 . freqc<30)|
00002150  20 84 20 28 72 65 76 69  6e 67 20 80 20 28 66 72  | . (reving . (fr|
00002160  65 71 61 3c 32 35 30 20  84 20 66 72 65 71 62 3c  |eqa<250 . freqb<|
00002170  32 35 30 20 84 20 66 72  65 71 63 3c 32 35 30 29  |250 . freqc<250)|
00002180  29 20 8c 20 72 65 76 69  6e 67 3d b9 3a 66 61 72  |) . reving=.:far|
00002190  6c 65 66 74 3d 30 3a 72  65 76 65 72 73 65 3d b9  |left=0:reverse=.|
000021a0  3a 66 77 64 3d a3 3a 72  69 67 68 74 3d a3 3a 6c  |:fwd=.:right=.:l|
000021b0  65 66 74 3d 28 66 72 65  71 61 3e 32 33 30 20 80  |eft=(freqa>230 .|
000021c0  20 66 72 65 71 62 3e 32  33 30 20 80 20 66 72 65  | freqb>230 . fre|
000021d0  71 63 3e 32 33 30 29 3a  e1 0d 08 7a 0d 20 72 65  |qc>230):...z. re|
000021e0  76 69 6e 67 3d a3 0d 08  84 2c 20 f4 20 41 6c 69  |ving=...., . Ali|
000021f0  67 6e 20 62 61 6c 6c 62  6f 74 20 74 6f 20 66 61  |gn ballbot to fa|
00002200  63 65 20 74 68 65 20 6e  65 74 20 70 6f 73 74 2e  |ce the net post.|
00002210  2e 2e 0d 08 8e 24 20 e7  20 66 61 24 3d 22 4e 22  |.....$ . fa$="N"|
00002220  20 84 20 66 61 24 3d 22  50 22 20 8c 20 72 69 67  | . fa$="P" . rig|
00002230  68 74 3d b9 3a e1 0d 08  98 25 20 e7 20 66 62 24  |ht=.:....% . fb$|
00002240  3c 3e 22 4e 22 20 80 20  66 62 24 3c 3e 22 50 22  |<>"N" . fb$<>"P"|
00002250  20 8c 20 6c 65 66 74 3d  b9 3a e1 0d 08 a2 2d 20  | . left=.:....- |
00002260  e7 20 66 62 24 3d 22 50  22 20 80 20 66 72 65 71  |. fb$="P" . freq|
00002270  62 3c 31 35 30 20 8c 20  72 69 67 68 74 3d b9 3a  |b<150 . right=.:|
00002280  6e 65 61 72 3d 31 3a e1  0d 08 ac 0c 20 74 75 72  |near=1:..... tur|
00002290  62 6f 3d b9 0d 08 d4 06  20 e1 0d 08 de 06 20 3a  |bo=..... ..... :|
000022a0  0d 08 e8 47 20 f4 20 4e  65 61 72 6c 79 20 74 68  |...G . Nearly th|
000022b0  65 72 65 2e 2e 2e 20 4a  75 73 74 20 6e 65 65 64  |ere... Just need|
000022c0  20 61 20 6c 69 74 74 6c  65 20 6e 75 64 67 65 20  | a little nudge |
000022d0  69 6e 20 74 68 65 20 72  69 67 68 74 20 64 69 72  |in the right dir|
000022e0  65 63 74 69 6f 6e 2e 0d  08 f2 12 20 dd f2 64 6f  |ection..... ..do|
000022f0  6e 65 61 72 73 74 75 66  66 0d 08 fc 10 20 6e 65  |nearstuff.... ne|
00002300  61 72 3d 6e 65 61 72 2b  31 0d 09 06 19 20 e7 20  |ar=near+1.... . |
00002310  6e 65 61 72 3c 38 20 8c  20 72 69 67 68 74 3d b9  |near<8 . right=.|
00002320  3a e1 0d 09 10 0b 20 6c  65 66 74 3d b9 0d 09 1a  |:..... left=....|
00002330  3b 20 e7 20 6e 65 61 72  3e 31 36 20 8c 20 6e 65  |; . near>16 . ne|
00002340  61 72 3d 30 3a 73 74 61  67 65 3d 73 74 61 67 65  |ar=0:stage=stage|
00002350  2b 31 3a 73 65 61 72 63  68 69 6e 67 3d 30 3a 74  |+1:searching=0:t|
00002360  65 6e 64 69 6e 67 3d 31  0d 09 24 06 20 e1 0d 09  |ending=1..$. ...|
00002370  2e 06 20 3a 0d 09 38 3d  20 f4 20 49 6e 69 74 69  |.. :..8= . Initi|
00002380  61 6c 69 73 65 20 42 61  6c 6c 42 6f 74 20 76 61  |alise BallBot va|
00002390  72 69 61 62 6c 65 73 20  61 74 20 74 68 65 20 62  |riables at the b|
000023a0  65 67 69 6e 6e 69 6e 67  20 6f 66 20 61 20 72 75  |eginning of a ru|
000023b0  6e 0d 09 42 0e 20 dd f2  73 65 74 75 70 62 62 0d  |n..B. ..setupbb.|
000023c0  09 4c 3f 20 72 65 76 69  6e 67 3d a3 3a 6c 65 66  |.L? reving=.:lef|
000023d0  74 3d a3 3a 72 69 67 68  74 3d a3 3a 66 77 64 3d  |t=.:right=.:fwd=|
000023e0  a3 3a 72 65 76 65 72 73  65 3d a3 3a 73 65 61 72  |.:reverse=.:sear|
000023f0  63 68 69 6e 67 3d 30 3a  69 64 6c 65 3d b9 0d 09  |ching=0:idle=...|
00002400  56 32 20 6e 65 61 72 3d  a3 3a 66 61 72 6c 65 66  |V2 near=.:farlef|
00002410  74 3d 30 3a 6f 70 65 6e  63 74 65 72 3d 30 3a 74  |t=0:opencter=0:t|
00002420  65 6e 64 69 6e 67 3d 31  3a 73 74 65 65 72 3d 30  |ending=1:steer=0|
00002430  0d 09 60 06 20 e1 0d 09  6a 06 20 3a 0d 09 74 0f  |..`. ...j. :..t.|
00002440  20 dd f2 72 65 6c 65 61  73 65 62 0d 09 7e 2d 20  | ..releaseb..~- |
00002450  f4 20 47 6f 74 20 61 6c  6c 20 74 68 65 20 62 61  |. Got all the ba|
00002460  6c 6c 73 2c 20 6e 6f 77  20 6a 75 73 74 20 64 75  |lls, now just du|
00002470  6d 70 20 74 68 65 6d 21  0d 09 88 20 20 6e 65 61  |mp them!...  nea|
00002480  72 3d 6e 65 61 72 2b 31  3a 72 65 76 65 72 73 65  |r=near+1:reverse|
00002490  3d b9 3a 66 77 64 3d a3  0d 09 92 1d 20 e7 20 6e  |=.:fwd=..... . n|
000024a0  65 61 72 3e 39 20 8c 20  69 64 6c 65 3d b9 3a 6e  |ear>9 . idle=.:n|
000024b0  65 61 72 3d a3 0d 09 9c  06 20 e1 0d 09 a6 44 20  |ear=..... ....D |
000024c0  f5 3a e3 58 3d 31 b8 31  32 3a ff 22 43 48 41 4e  |.:.X=1.12:."CHAN|
000024d0  4e 45 4c 56 4f 49 43 45  20 31 20 22 2b c3 58 3a  |NELVOICE 1 "+.X:|
000024e0  d4 31 2c 2d 31 30 2c 35  32 2c 31 30 30 3a e3 52  |.1,-10,52,100:.R|
000024f0  3d 30 b8 31 30 30 30 30  3a ed 2c 3a fd 20 a3 0d  |=0.10000:.,:. ..|
00002500  09 b0 06 20 3a 0d 09 ba  42 20 f4 20 57 68 69 7a  |... :...B . Whiz|
00002510  7a 2d 62 61 63 6b 20 74  6f 20 6c 69 6e 65 20 75  |z-back to line u|
00002520  70 20 77 69 74 68 20 44  20 2d 20 77 68 61 74 20  |p with D - what |
00002530  69 66 20 77 68 69 7a 7a  20 62 61 63 6b 20 69 6e  |if whizz back in|
00002540  74 6f 20 6e 65 74 3f 0d  09 c4 39 20 f4 20 52 65  |to net?...9 . Re|
00002550  76 65 72 73 65 20 69 66  20 42 61 6c 6c 42 6f 74  |verse if BallBot|
00002560  20 6b 6e 6f 77 73 20 74  68 61 74 20 62 61 6c 6c  | knows that ball|
00002570  73 20 61 72 65 20 62 65  68 69 6e 64 20 69 74 2e  |s are behind it.|
00002580  0d ff                                             |..|
00002582
BioBot/BBNew.m0
BioBot/BBNew.m1
BioBot/BBNew.m2
BioBot/BBNew.m4
BioBot/BBNew.m5

© Dominic Ford 2021–2024.

Our privacy policy is here.
Last updated: 28 Jul 2024, 23:31 UTC
Website designed by .
