| Tape/disk: | Home » Personal collection » Acorn ADFS disks » Greaseweazled » adfs_RiscOs_Apps_1.adf |
| Filename: | !PrinterPS/PrData |
| Read OK: | ✔ |
| File size: | 10A2 bytes |
| Load address: | FFFFFF41 |
| Exec address: | A9EBE8AE |
Duplicates
There are 2 duplicate copies of this file in the archive:
- Personal collection » Acorn ADFS disks » Archimedes » RiscOs_Apps_1.ADF » !PrinterPS/PrData
- Personal collection » Acorn ADFS disks » Greaseweazled » adfs_RiscOs_Apps_1.adf » !PrinterPS/PrData
- Personal collection » Acorn hard disk » apps » Printers » RiscOs2/!PrinterPS/PrData
File contents
>PrData *** Postscript printer configuration ***
version: 1 ;Don't change this. It is used to detect
; incompatible old "PrData" files.
Defaults
========
Default resolutions
pxres: 300 ; dots per inch
pyres: 300
pxres_halftone: 300/8
pyres_halftone: 300/8
features: 16_02000000 ; supports arbitrary transformation
prologue2: PSprolog2
Define these next two as empty strings if the printer does not have the
appropriate facility.
auto_feed: %%BeginFeature: ManualFeed False|Jstatusdict begin /manualfeed false store end|J%%EndFeature
manual_feed: %%BeginFeature: ManualFeed True|Jstatusdict begin /manualfeed true store end|J%%EndFeature
Real printer definitions
========================
printer_name: Monochrome PostScript
;max 40 chars in name
printer_number: 0
printer_name: Colour PostScript
printer_number: 1
features: 16_02000001 ; produce colour PostScript please
Page size settings
==================
These are written back to this file when the "Save" entry is clicked;
therefore they are all fixed size fields.
page_number: 0 ; the number of the page size table entry we want to do
; don't need to write this back!
page_name: A4 paper;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;; pad names to 80 characters with ;
page_width: 0000595000; Pad (decimal) numbers to 10 chars with leading 0s
page_height: 0000842000
page_bottom: 0000023000
page_top: 0000819000
page_left: 0000018000
page_right: 0000577000
page_selection: %%BeginFeature: PageSize A4|Ja4|J%%EndFeature
page_number: 1
page_name: Letter;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;
page_width: 0000612000
page_height: 0000792000
page_bottom: 0000019000
page_top: 0000774000
page_left: 0000018000
page_right: 0000593000
page_selection: %%BeginFeature: PageSize Letter|Jletter|J%%EndFeature
page_number: 2
page_name: Legal;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;
page_width: 0000612000
page_height: 0001008000
page_bottom: 0000042000
page_top: 0000966000
page_left: 0000065000
page_right: 0000547000
page_selection: %%BeginFeature: PageSize Legal|Jlegal|J%%EndFeature
Configured options
==================
start_page_number: 00 ;page description - pad to two chars with 0
printer: 00 ; printer number - pad to two chars with 0
page: 00 ; page number - pad to two chars with 0
location: 2 ;1 - parallel, 2 - serial, 4 - net
baud: 6 ; 0 - 75, 1 - 150, 2 - 300 , 3 - 1200
; 4 - 2400, 5 - 4800, 6 - 9600 , 7 - 19200
; 8 - 50, 9 - 110, 10 - 134.5, 11 - 600
;12 - 1800, 13 - 3600, 14 - 7200
data: &20 ;serial data format - pad to two chars with 0
;b0-b1 0,1,2,3 => 8,7,6,5 bits
;b2 0=>1 stop bit, 1=>2 stop bits OR 1.5 stop bits if 5
;bits without parity, OR 1 stop bit if 8 bits with parity
;b3 0/1 => parity off/on
;b4-b5 0,1,2,3 => parity odd, even, 1 on Tx, 0 on Tx
xon: 1 ;XON/XOFF 0 off 1 on
server: 0.235;;; either [<net>.]<station> eg `235;;;;;` or `123.235;`
;or up to 6 char name eg `blue;;;;` or `yellow;;`
;must be padded to 8 chars with ; in either case
file: null:;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;filename to use, padded to 80 characters.
All the following fields may get written back by the printer driver, so must
be single character fixed length fields.
feed: 0 ;0 - automatic, 1 - manual
format: 0 ;0 - portrait, 1 - landscape
title: 0 ;0 - no title, 1 - title
columns: 1 ;1,2,3,4,5,6,7,8 or 9
line_numbers: 0 ;0 - don't number lines, 1 - number lines
line_term: 0 ;0 - only LF terminates lines, 1 - CR, LF, CR/LF and
LF/CR terminate lines
print_ccs: 1 ;0 - don't print control chars, 1 - print control chars
