Filename: GPlot
Read OK: ✔
File size: 123D bytes
Load address: FFFF1A00
Exec address: FFFF8023
Duplicates

There are 2 duplicate copies of this file in the archive:

File contents
   10REM > Graph Plotter
   20REM by Rafael Jay
   30REM (c) The Micro User
   40PROCinit:ONERRORPROCerror
   50MODE7:PROCoff
   60os%=INKEY-256=161:IFos%DIMZ%256,Q%256:ELSEZ%=&700:Q%=&70
   70C%=FNmenu:CLS:PROCt(d$(C%))
   80ON C% GOTO90,100,110,120,130,140,150,160
   90PROCedit:GOTO50
  100MODE1:PROCbar:GOTO50
  110MODE1:PROCpie:GOTO50
  120MODE1:PROCline:GOTO50
  130PROCload:GOTO50
  140PROCsave:GOTO50
  150PROCclear:GOTO50
  160PROCcli:GOTO50
  170DEFPROCoff:VDU23,1,0;0;0;0;0;:ENDPROC
  180DEFPROCon:VDU23,1,1;0;0;0;0;:ENDPROC
  190DEFFNmenu:PROCoff:VDU26
  200FORL%=0TO1:VDU31,0,L%,129,157,131,141
  210PRINT"Graph Plotter"SPC3CHR$156:NEXT
  220PRINTTAB(0,2)CHR$145STRING$(38,",")TAB(0,24)CHR$145STRING$(38,",");:PROCt("Main Menu"):PRINT
  230PRINTTAB(5)CHR$132CHR$157SPC(32-POS)CHR$156
  240FORI%=1TOD%:FORL%=0TO1
  250PRINTTAB(5)CHR$132CHR$157SPC(2)CHR$134CHR$141d$(I%)SPC(32-POS)CHR$156
  260NEXT:NEXT
  270PRINTTAB(5)CHR$132CHR$157SPC(32-POS)CHR$156:P%=1:OP%=1:PROCh
  280REPEATG$=GET$:OP%=P%
  290IFINSTR(":;""'",G$) IFP%>1 P%=P%-1:PROCh
  300IFINSTR("?/",G$) IFP%<8 P%=P%+1:PROCh
  310UNTILG$=CHR$13:=P%
  320DEFPROCt(T$)VDU26:FORL%=0TO1
  330PRINTTAB(23,L%)CHR$131CHR$141;T$
  340NEXT:VDU28,0,23,39,3:ENDPROC
  350DEFPROCh
  360VDU31,5,2+(OP%-1)*2,132,10,8,132
  370VDU31,9,2+(OP%-1)*2,134,10,8,134
  380VDU31,5,2+(P%-1)*2,134,10,8,134
  390VDU31,9,2+(P%-1)*2,132,10,8,132
  400ENDPROC
  410DEFPROCinit:READD%:mr%=17:*FX4,1
  420DIMdata$(mr%),data(mr%),d$(D%)
  430FORI%=1TOD%:READd$(I%):NEXT:ENDPROC
  440DATA 8,Edit data,Plot bar chart,Plot pie chart,Plot line graph,Load data,Save data,Clear data,* Command
  450DEFPROCedit
  460FORL%=1TO18:PRINTTAB(0,L%)CHR$129CHR$157CHR$131SPC(19-POS)CHR$156SPC(3)CHR$132CHR$157CHR$135SPC(13)CHR$156:NEXT:VDU30
  470PRINT" Fieldname"SPC(14);"Value"
  480FORL%=0TOmr%:IFdata$(L%)>""VDU31,3,L%+1:PRINTdata$(L%);:VDU31,26,L%+1:PRINT;data(L%) ELSEPRINT
  490NEXT:P%=1:REPEAT:B%=FALSE
  500VDU31,0,P%,134,9,132:PRINTTAB(1,20);"Enter fieldname ";P%;": "SPC(15);STRING$(15,CHR$8);:F$=FNii(14)
  510VDU31,0,P%,129,9,131:IFF$>""data$(P%-1)=F$:PRINTTAB(3,P%);F$+STRING$(14-LEN(F$)," ");
  520VDU31,23,P%,134,9,132:PRINTTAB(1,20);"Enter value ";P%;": "SPC(20);STRING$(20,CHR$8);:V$=FNii(10)
  530VDU31,23,P%,132,9,135:IFV$>""data(P%-1)=VALV$:PRINTTAB(26,P%);data(P%-1);STRING$(10-LEN(V$)," ")
  540P%=P%+1:IFP%>18 P%=1
  550UNTILFALSE:ENDPROC
  560DEFFNi(T$,N%)PRINT'" "T$;:IFT$<>"*"PRINT": ";
  570=FNii(N%)
  580DEFFNii(N%)PROCon:i$="":REPEAT:G%=GET
  590IFG%>31IFG%<127IFLENi$<N%i$=i$+CHR$G%:VDUG%
  600IFG%=127IFi$>""i$=LEFT$(i$,LENi$-1):VDUG%
  610UNTILG%=13:PROCoff:=i$
  620DEFPROCerror:IFERR=17 ENDPROC
  630IFos%e$=REPORT$ELSER%=(!&FD AND&FFFF)+1:e$="":REPEATe$=e$+CHR$?R%:R%=R%+1:UNTIL?R%=0
  640e$=CHR$135+e$+CHR$145:VDU26
  650PRINTTAB(20-LENe$/2,24)e$;
  660VDU7:REPEATUNTILINKEY-99
  670VDU28,0,23,39,3:ENDPROC
  680DEFPROCcli:REPEAT$Z%=FNi("*",240):VDU14:PRINT
  690X%=Z%:Y%=Z%DIV256:CALL&FFF7:VDU15:UNTIL$Z%="":ENDPROC
  700DEFPROCclear:IFNOTFNq("Are you sure")ENDPROC
  710FORL%=0TOmr%:data$(L%)="":data(L%)=0:NEXT:ENDPROC
  720DEFPROCsave:$Z%=FNi("Enter filename",60)
  730!Q%=Z%:A%=&05:X%=Q%:Y%=Q%DIV256
  740IFUSR(&FFDD)AND&FF IFNOTFNq("Overwrite existing file")ENDPROC
  750F%=OPENOUT($Z%):FORL%=0TOmr%
  760PRINT#F%,data$(L%),data(L%)
  770NEXT:CLOSE#F%:ENDPROC
  780DEFPROCload:$Z%=FNi("Enter filename",60)
  790F%=OPENIN($Z%):IFF%=0:VDU7:ENDPROC
  800FORL%=0TOmr%:INPUT#F%,data$(L%),data(L%)
  810NEXT:CLOSE#F%:ENDPROC
  820DEFFNq(T$)PRINT'" "T$" (y/n) ? ";
  830REPEATG$=GET$:I%=INSTR("YyNn",G$)
  840UNTILI%>0:PRINTG$:=I%<3
  850DEFPROCscale:T=0:B=0:FORL%=0TOmr%
  860IFdata(L%)>T T=data(L%)
  870IFdata(L%)<B B=data(L%)
  880NEXT:GCOL0,2:MOVE200,900
  890DRAW200,150:DRAW1200,150
  900B=INT(B):T=INT(T)+1
  910R=T-B:CV=750/R:TMS%=1
  920REPEAT:IFR>100 R=R/10:TMS%=TMS%*10
  930UNTILR<100:C=0
  940ST=R/10:FORL%=150TO900 STEP75
  950MOVE200,L%:DRAW220,L%
  960PLOT21,1200,L%:VDU5:MOVE0,L%+16
  970PRINT;C:C=C+ST:NEXT:GCOL0,1
  980MOVE0,75:@%=&90A:PRINT"x";TMS%
  990VDU4:@%=&20206:ENDPROC
 1000DEFFNcount(J%):C%=0:FORL%=0TOmr%
 1010IFdata$(L%)>""C%=C%+1
 1020NEXT:IFC%=0 =C%
 1030SZ=1000/(C%-J%):P=200:=C%
 1040DEFPROCbar:T$=FNi("Title",36):CLS
 1050N%=FNcount(0):IFN%=0 VDU7:ENDPROC
 1060@%=&20206:PROCscale:FORL%=0TOmr%
 1070Y=150+data(L%)*CV:IFdata$(L%)>""GCOL0,1:MOVEP,150:MOVEP,Y:PLOT85,P+SZ,150:PLOT85,P+SZ,Y:GCOL0,3:MOVEP,150:DRAWP,Y:DRAWP+SZ,Y:DRAWP+SZ,150:GCOL0,2
 1080DRAWP,150:PLOT21,P,20
 1090MOVEP+SZ,150:PLOT21,P+SZ,20
 1100PROClab(1):P=P+SZ:NEXT
 1110IFT$>""PROCtitle
 1120@%=&90A:PROCopts:ENDPROC
 1130DEFPROCtitle:COLOUR131:COLOUR0
 1140PRINTTAB(20-LENT$/2,1)SPC2T$SPC1
 1150ENDPROC
 1160DEFPROClab(O%)GCOL0,2
 1170A%=&0D:X%=Q%:Y%=&00:CALL&FFF1
 1180XP%=Q%!4 AND&FFFF
 1190YP%=Q%!6 AND&FFFF:VDU5
 1200IFO%=1K%=3:FORU%=62TO126 STEP32:MOVEP+(SZ-32)/2,U%:VDUASCMID$(data$(L%),K%):K%=K%-1:NEXT:VDU4
 1210IFO%=2K%=3:FORU%=62TO126 STEP32:MOVEP-16,U%:VDUASCMID$(data$(L%),K%):K%=K%-1:NEXT:VDU4
 1220MOVEXP%,YP%:ENDPROC
 1230DEFPROCline:T$=FNi("Title",36):CLS
 1240N%=FNcount(1):IFN%=0 VDU7:ENDPROC
 1250@%=&20206:PROCscale:MOVE200,150+data(0)*CV:FORL%=0TOmr%
 1260Y=150+data(L%)*CV:IFdata$(L%)>""GCOL0,3:DRAWP,Y
 1270GCOL0,2:MOVEP,150:DRAWP,170
 1280MOVEP,Y:PROClab(2):P=P+SZ:NEXT
 1290IFT$>""PROCtitle
 1300@%=&90A:PROCopts:ENDPROC
 1310DEFPROCpie:T$=FNi("Title",36):CLS
 1320T=0:FORL%=0TOmr%:IFdata$(L%)>""T=T+data(L%)
 1330NEXT:IFT=0 VDU7:ENDPROC
 1340O=360/T:VDU29,480;512;:MOVE0,400
 1350FORD=0TO360STEP4:MOVE0,0:GCOL0,1:PLOT85,SINRAD(D)*400,COSRAD(D)*400:NEXT
 1360GCOL0,2:MOVE0,0:DRAW0,400:N=0:F=0:GCOL0,2:FORD=0TO360
 1370DRAWSINRADD*400,COSRADD*400
 1380IFD>=F+data(N)*O MOVE0,0:DRAWSINRADD*400,COSRADD*400:PROCpl:F=D:N=N+1
 1390NEXT:PROCpl:GCOL0,2:FORL%=1TO(N+1)
 1400MOVE490,408-L%*40:DRAW799,408-L%*40:DRAW799,448-L%*40:DRAW490,448-L%*40:DRAW490,408-L%*40:NEXT
 1410MOVE536,408:DRAW536,408-(N+1)*40:IFT$>""PROCtitle
 1420PROCopts:ENDPROC
 1430DEFPROCpl
 1440A=SINRAD(F+data(N)*O/2)*430
 1450B=COSRAD(F+data(N)*O/2)*430
 1460VDU5:MOVEA,B
 1470GCOL0,3:MOVEA,B:IFD>180 VDU8
 1480VDU65+N:MOVE500,400-N*40
 1490VDU65+N,32:PRINTLEFT$(data$(N),7)
 1500VDU4:GCOL0,2
 1510MOVESINRADD*400,COSRADD*400
 1520ENDPROC
 1530DEFPROCopts:REPEATG%=GET
 1540IF G%=ASC"P" PROCdump
 1550IF G%=ASC"S" PROCsvg
 1560UNTILG%=32:ENDPROC
 1570DEFPROCdump
 1580REM
 1590REM Insert printer dump
 1600REM command here
 1610REM
 1620ENDPROC
 1630DEFPROCsvg
 1640IFNOTos%:*SAVE GRAPH 3000 8000
 1650IFos%:*SCREENSAVE GRAPH
 1660ENDPROC
