DIS4220
This website contains an archive of files for the Acorn Electron, BBC Micro, Acorn Archimedes, Commodore 16 and Commodore 64 computers, which Dominic Ford has rescued from his private collection of floppy disks and cassettes.
Some of these files were originally commercial releases in the 1980s and 1990s, but they are now widely available online. I assume that copyright over them is no longer being asserted. If you own the copyright and would like files to be removed, please contact me.
| Tape/disk: | Home » Personal collection » Acorn tapes » Own_Work » box01_tape15a_d60_acorn_joystick_progs.wav |
| Filename: | DIS4220 |
| Read OK: | ✔ |
| File size: | 19CC bytes |
| Load address: | FFFF0E00 |
| Exec address: | FFFF8023 |
File contents
10MODE 6:HIMEM=&7000:LOMEM=&6400
20VDU 28,0,24,39,16
30OSBYTE=&FFF4:OSWORD=&FFF1:OSASCI=&FFE3:OSWRCH=&FFEE
40OSRDCH=&FFE0:CLI=&FFF7
50OUT=&70:PUT=&71:SP=&72:BPT=&74
60CONBLK=&76:HI=&81:LO=&80:DISP=&82:DH=&83
70UP=&85:STK=&86:ACR=&84
80OLO=&7B:OHI=&7C:OUMB=&88
90HA=&8D:HB=&8E:HC=&8F
100DLINES=&7D:NUMB=&7E:TEMPSTACK=&7F
110FOR OP=0 TO 3 STEP 3
120P%=&5400
450[OPT OP
460TSX:STX TEMPSTACK
480LDA#0:STA CONBLK:LDA#6:STA CONBLK+1
500LDA#ASC("D"):STA DISP
520LDX#(ST1 MOD 256)
530LDY#(ST1 DIV 256)
540JSR OUTPUT
560LDA#4:LDX#1:JSR OSBYTE
590.L5 JSR DISPLAY
610.L7 JSR KEYIN
630CMP#ASC("D"):BNE NOND
650.STD STA DISP:JMP L5
660.NOND CMP#ASC("L"):BEQ STD
690CMP #ASC("H"):BNE NONH
710.HGIN LDX#15:LDY#2:JSR SETAB
730LDA#4:LDX#ASC("0"):LDY#ASC("F"):JSR STRIN
750JSR DHEX:BCCHGIN:LDA DH:STA HI
770LDA&602:STA&600:LDA&603:STA&601:JSR DHEX
790BCC HGIN:LDA DH:STA LO:JMP L5
800.NONH CMP#ASC("F"):BNE NOF
820.FGIN LDX#15:LDY#3:JSR SETAB
830LDA#2:LDX#ASC("0"):LDY#ASC("F"):JSR STRIN
840JSR DHEX:BCC FGIN:LDA DISP:CMP#ASC("L"):BNE OVSWAP
850LDA OLO:SEC:SBC OUMP:STA LO:LDA OHI:SBC#0:STA HI
860.OVSWAP
870LDY#0:LDA DH:.FLOOP INC LO:BNE OVHI:INC HI:.OVHI CMP(LO),Y:BNE FLOOP
880JMP L5
910.NOF LDX DISP:CPX#ASC("L"):BNE NONF:JMP LCOM
950.NONF CMP#&88:BNE NLEFT
970LDA LO:BNE DE1:DEC HI:.DE1 DEC LO:JMP L5
990.NLEFT CMP#&89:BNE NRT
1010INC LO:BNE DE2:INC HI:.DE2 JMP L5
1050LDA LO:CLC:ADC#8:STA LO
1060LDA HI:ADC#0:STA HI:JMP L5
1100LDA LO:SEC:SBC#8:STA LO
1110LDA HI:SBC#0:STA HI:JMP L5
1140.NMOVE CMP#ASC("A"):BNE NONA
1160.AGIN LDY#14
1180LDA ACR:ASL A:CLC:ADC ACR:CLC:ADC#6
1200TAX:JSR SETAB
1220LDA#2:LDX#ASC("0"):LDY#ASC("F"):JSR STRIN
1240JSR DHEX:BCC AGIN:LDA DH:LDY#0:STA (LO),Y
1250JMP L5
1290.DHEX LDA&600:CMP #ASC("9")+1:BCS AL1
1300AND#&0F:BCC TIP
1310.AL1 CMP #ASC("A"):BCC ERHEX:SBC #ASC("A")-10
1330.TIP ASL A:ASL A:ASL A:ASL A:STA DH
1340LDA&601:CMP #ASC("9")+1:BCS AL2
1350AND#&0F:BCC BOT
1360.AL2 CMP #ASC("A"):BCC ERHEX:SBC #ASC("A")-10
1380.BOT ORA DH:STA DH:SEC
1400.ERHEX RTS
1440.NONA CMP #ASC("S")BNE NONS
1460.SGIN LDY#14:LDA ACR:CLC:ADC#30:TAX:JSR SETAB
1480LDA#255:LDX #ASC(" "):LDY #ASC("~"):JSR STRIN
1500LDX#0:LDY#0
1520.LOP LDA&600,X:CMP#&0D:BEQ FINLOP
1530STA (LO),Y:INY:INX:BNE LOP
1540.FINLOP JMP L5
1570.NONS
1580JMP L7
1620.LCOM CMP#&0D:BNE NONCR
1640LDA OLO:STA LO:LDA OHI:STA HI:JMP L5
1660.NONCR CMP#&8B:BNE NONS
1680LDA OLO:INC OUMB:SEC:SBC OUMB:STA LO
1690LDA OHI:SBC#0:STA HI:JMP L5
1720.DIS LDX#(ST2 MOD 256)
1730LDY#(ST2 DIV 256)
1750JSR OUTPUT
1770LDA#16:STA DLINES
1780.LINLOP
1800LDA HI:JSR HEX:LDA LO:JSR HEXSP
1830LDY#0:LDX#3
1840.HALOP LDA(LO),Y:STA HA,Y:INY:DEX:BNE HALOP
1860LDX HA:LDA TYPE,X:TAX:LDA NUM,X
1880STA NUMB:CLC:ADC LO:STA LO:LDA#0:ADC HI:STA HI
1900LDX NUMB:LDY#3:LDA HA:JSR HEXSP:DEY:DEX:BEQ PAD
1910LDA HB:JSR HEXSP:DEY:DEX:BEQ PAD
1920LDA HC:JSR HEXSP:DEX:BEQ MNEM
1940.PAD TYA:PHA
1950LDX#(ST4 MOD 256):LDY#(ST4 DIV 256):JSR OUTPUT
1960PLA:TAY:DEY:BNE PAD
1980.MNEM LDA #ASC(" "):JSR OSASCI
2000LDX HA:LDA HASH,X:ASL A:ASL A:STA OUT
2020LDA#(STRING DIV 256):STA PUT:LDX#4:LDY#0
2040.MNMLOP LDA (OUT),Y:JSR OSASCI:INY:DEX:BNE MNMLOP
2050LDA #ASC(" "):JSR OSASCI
2070LDX HA:LDA TYPE,X:CMP#1:BNE NOD1
2090LDA #ASC("#"):JSR OSASCI:LDA #ASC("&"):JSR OSASCI
2110LDA HB:JSR HEXSP:LDY#5:JMP NDLINE
2130.NOD1 CMP#2:BNE NOD2
2150LDA #ASC("&"):JSR OSASCI:LDA HC:JSR HEX
2160LDA HB:JSR HEXSP:LDY#4:JMP NDLNE
2180.NOD2 CMP#3:BNE NOD3
2200LDA #ASC("&"):JSR OSASCI:LDA HB:JSR HEXSP
2210LDY#6:JMP NDLINE
2230.NOD3 CMP#4:BNE NOD4
2250LDA #ASC("A"):JSR OSASCI:LDY#9:JMP NDLINE
2270.NOD4:CMP#5:BNE NOD5
2290LDY#10:JMP NDLINE
2310.NOD5 CMP#6:BNE NOD6
2330LDA #ASC("("):JSR OSASCI:LDA #ASC("&"):JSR OSASCI
2340LDA HB:JSR HEX:LDA #ASC(","):JSR OSASCI
2350LDA #ASC("X"):JSR OSASCI:LDA #ASC(")"):JSR OSASCI
2360LDY#3:JMP NDLINE
2380.NOD6 CMP#7:BNE NOD7
2400LDA#ASC("("):JSR OSASCI:LDA#ASC("&"):JSR OSASCI
2410LDA HB:JSR HEX:LDA#ASC(")"):JSR OSASCI
2420LDA#ASC(","):JSR OSASCI:LDA#ASC("Y"):JSR OSASCI
2430LDY#3:JMP NDLINE
2450.NOD7 CMP#8:BNE NOD8
2470LDA#ASC("&"):JSR OSASCI:LDA HB:JSR HEX
2480LDA#ASC(","):JSR OSASCI:LDA#ASC("X"):JSR OSASCI
2490LDY#5:JMP NDLINE
2510.NOD8 CMP#9:BNE NOD9
2530LDA#ASC("&"):JSR OSASCI:LDA HC:JSR HEX
2540LDA HB:JSR HEX:LDA#ASC(","):JSR OSASCI
2550LDA#ASC("X"):JSR OSASCI
2560LDY#3:JMP NDLINE
2580.NOD9 CMP#&A:BNE NODA
2600LDA#ASC("&"):JSR OSASCI:LDA HC:JSR HEX
2610LDA HB:JSR HEX:LDA#ASC(","):JSR OSASCI
2620LDA#ASC("Y"):JSR OSASCI
2630LDY#3:JMP NDLINE
2650.NODA CMP#&B:BNE NODB
2670LDA#ASC("&"):JSR OSASCI
2690LDA HB:CMP#&7F:BCS BACK
2710CLC:ADC LO:PHA LDA#0:ADC HI:CLC:BCC REL
2730.BACK EOR#255:ADC#0:STA&70:LDA LO:SEC:SBC&70
2740PHA:LDA HI:SBC#0
2760.REL JSR HEX:PLA:JSR HEXSP
2770LDY#4:JMP NDLINE
2790.NODB CMP#&C:BNE NODC
2810LDA#ASC("("):JSR OSASCI:LDA#ASC("&"):JSR OSASCI
2820LDA HC:JSR HEX:LDA HB:JSR HEX
2830LDA#ASC(")"):JSR OSASCI:LDY#3:JMP NDLINE
2850.NODC CMP#&D:BNE NODD
2870LDA#ASC("&"):JSR OSASCI:LDA HB:JSR HEX
2880LDA#ASC(","):JSR OSASCI:LDA#ASC("Y"):JSR OSASCI
2890LDY#5:JMP NDLINE
2910.NODD LDY#10
2930.NDLINE LDA#ASC(" "):JSR OSASCI:DEY:BPL NDLINE
2950LDX NUMB:LDY#0
2960.DISPLOP LDA HA,Y:JSR CHOUT:INY:DEX:BNE DISPLOP
2980LDA#ASC(" "):.PAD2 JSR OSASCI:INY:CPY#4:BNE PAD2
3000LDX#5:.PAD3 JSR OSASCI:DEX:BNE PAD3
3030LDA DLINES:CMP#16:BNE OVOLD
3050LDA LO:STA OLO:LDA HI:STA OHI
3060LDA NUMB:STA OUMB
3080.OVOLD DEC DLINES:BEQ FINLIN:JMP LINLOP
3090.FINLIN RTS
3130.DISPLAY LDY#2:LDX#15:JSR SETAB
3150LDA HI:JSR HEX:LDA LO:JSR HEXSP:
3170LDA DISP:CMP#ASC("L"):BEQ DDISP
3190JSR SHOW:RTS
3210.DDISP JSR DIS:RTS
3250.SHOW LDX#(ST2 MOD256)
3260LDY#(ST2 DIV256)
3280JSR OUTPUT
3300LDA LO:AND#&F8:SEC:SBC#64:STA UP
3310LDA HI:SBC#0:STA STK
3330LDA LO:AND#7:STA ACR
3350LDX#0:.L4 STX STK+1:LDA#8:CLC:ADC UP:STA UP
3360LDA #0:ADC STK:STA STK
3380JSR HEX:LDA UP:JSR HEXSP:LDA#ASC(" "):JSR OSASCI
3400LDX#0:.L2 STX STK+2:TXA
3410TAY
3430LDA(UP),Y:JSR HEXSP
3450LDX STK+2:INX:CPX#8:BNE L2
3470LDX#0:.L3 STX STK+2:TXA
3490TAY
3500LDA(UP),Y:JSR CHOUT
3520LDX STK+2:INX:CPX#8:BNE L3
3540LDA#ASC(" "):JSR OSASCI:JSR OSASCI
3560LDX STK+1:INX:CPX#16:BNE L4
3580LDY#14:LDA ACR:ASL A:CLC:ADC ACR
3590ADC#5:STA STK+1:TAX:JSR SETAB
3610LDA#ASC("["):JSR OSASCI
3620LDA STK+1:CLC:ADC#3:TAX:LDY#14:JSR SETAB
3640LDA#ASC("]"):JSR OSASCI
3650RTS
3690.CHOUT CMP#ASC(" "):BCC DUF
3710CMP#&7F:BCC OK
3740.DUF LDA#ASC(".")
3750.OK JSR OSASCI:RTS
3790.SETAB STY ST3+2:STX ST3+1
3800LDX#(ST3 MOD256):LDY#(ST3 DIV256)
3810JSR OUTPUT:RTS
3850.KEYIN LDX#0:LDA#21:JSR OSBYTE
3860JSR OSRDCH:BCS KEYERR:RTS
3880.KEYERR STA STK+1
3890LDX#(ST6 MOD256):LDY#(ST6 DIV256):JSR CLI
3900LDA STK+1:CMP#&1B:BNE KERR
3920LDA#&7E:JSR OSBYTE
3930.KERR
3950LDX#0:LDY#22:JSR SETAB:LDX TEMPSTACK:TXS
3980BRK:EQUB99
3990EQUS"END OF DIS"
4010BRK
4050.OUTPUT STX&70:STY&71
4060LDY#0
4070.LOOP LDA(&70),Y:CMP#&FF:BEQ OUTEND
4080JSR OSASCI:INY:BNE LOOP
4090.OUTEND RTS
4130.HEXSP JSR HEX:LDA#&20:JMP OSWRCH
4150.HEX
4170PHA:LSR A:LSR A:LSR A:LSR A
4180JSR HEXDIG:PLA:AND#&F
4190.HEXDIG CMP#&A:BCC HEXDIH:ADC#6
4200.HEXDIH ADC#&30:JMP OSWRCH
� 6:�=&7000:�=&6400
� 28,0,24,39,16
7OSBYTE=&FFF4:OSWORD=&FFF1:OSASCI=&FFE3:OSWRCH=&FFEE
(OSRDCH=&FFE0:CLI=&FFF7
2"OUT=&70:PUT=&71:SP=&72:BPT=&74
<,CONBLK=&76:HI=&81:LO=&80:DISP=&82:DH=&83
FUP=&85:STK=&86:ACR=&84
P OLO=&7B:OHI=&7C:OUMB=&88
ZHA=&8D:HB=&8E:HC=&8F
d%DLINES=&7D:NUMB=&7E:TEMPSTACK=&7F
n� OP=0 � 3 � 3
x P%=&5400
� [OPT OP
�TSX:STX TEMPSTACK
�'LDA#0:STA CONBLK:LDA#6:STA CONBLK+1
�LDA#�("D"):STA DISP
LDX#(ST1 � 256)
LDY#(ST1 � 256)
JSR OUTPUT
0LDA#4:LDX#1:JSR OSBYTE
N.L5 JSR DISPLAY
b.L7 JSR KEYIN
vCMP#�("D"):BNE NOND
�.STD STA DISP:JMP L5
� .NOND CMP#�("L"):BEQ STD
�CMP #�("H"):BNE NONH
� .HGIN LDX#15:LDY#2:JSR SETAB
�)LDA#4:LDX#�("0"):LDY#�("F"):JSR STRIN
�"JSR DHEX:BCCHGIN:LDA DH:STA HI
,LDA&602:STA&600:LDA&603:STA&601:JSR DHEX
!BCC HGIN:LDA DH:STA LO:JMP L5
.NONH CMP#�("F"):BNE NOF
4 .FGIN LDX#15:LDY#3:JSR SETAB
>)LDA#2:LDX#�("0"):LDY#�("F"):JSR STRIN
H4JSR DHEX:BCC FGIN:LDA DISP:CMP#�("L"):BNE OVSWAP
R4LDA OLO:SEC:SBC OUMP:STA LO:LDA OHI:SBC#0:STA HI
\ .OVSWAP
fHLDY#0:LDA DH:.FLOOP INC LO:BNE OVHI:INC HI:.OVHI CMP(LO),Y:BNE FLOOP
p
JMP L5
�..NOF LDX DISP:CPX#�("L"):BNE NONF:JMP LCOM
�.NONF CMP#&88:BNE NLEFT
�,LDA LO:BNE DE1:DEC HI:.DE1 DEC LO:JMP L5
�.NLEFT CMP#&89:BNE NRT
�%INC LO:BNE DE2:INC HI:.DE2 JMP L5
LDA LO:CLC:ADC#8:STA LO
$ LDA HI:ADC#0:STA HI:JMP L5
LLDA LO:SEC:SBC#8:STA LO
V LDA HI:SBC#0:STA HI:JMP L5
t .NMOVE CMP#�("A"):BNE NONA
�.AGIN LDY#14
�'LDA ACR:ASL A:CLC:ADC ACR:CLC:ADC#6
�TAX:JSR SETAB
�)LDA#2:LDX#�("0"):LDY#�("F"):JSR STRIN
�-JSR DHEX:BCC AGIN:LDA DH:LDY#0:STA (LO),Y
�
JMP L5
'.DHEX LDA&600:CMP #�("9")+1:BCS AL1
�#&0F:BCC TIP
-.AL1 CMP #�("A"):BCC ERHEX:SBC #�("A")-10
2'.TIP ASL A:ASL A:ASL A:ASL A:STA DH
<!LDA&601:CMP #�("9")+1:BCS AL2
F�#&0F:BCC BOT
P-.AL2 CMP #�("A"):BCC ERHEX:SBC #�("A")-10
d.BOT �A DH:STA DH:SEC
x.ERHEX RTS
� .NONA CMP #�("S")BNE NONS
�1.SGIN LDY#14:LDA ACR:CLC:ADC#30:TAX:JSR SETAB
�-LDA#255:LDX #�(" "):LDY #�("~"):JSR STRIN
�LDX#0:LDY#0
�%.LOP LDA&600,X:CMP#&0D:BEQ FINLOP
� STA (LO),Y:INY:INX:BNE LOP
.FINLOP JMP L5
" .NONS
,
JMP L7
T.LCOM CMP#&0D:BNE NONCR
h(LDA OLO:STA LO:LDA OHI:STA HI:JMP L5
|.NONCR CMP#&8B:BNE NONS
�(LDA OLO:INC OUMB:SEC:SBC OUMB:STA LO
� LDA OHI:SBC#0:STA HI:JMP L5
�.DIS LDX#(ST2 � 256)
�LDY#(ST2 � 256)
�JSR OUTPUT
�LDA#16:STA DLINES
� .LINLOP
#LDA HI:JSR HEX:LDA LO:JSR HEXSP
&LDY#0:LDX#3
0/.HALOP LDA(LO),Y:STA HA,Y:INY:DEX:BNE HALOP
D#LDX HA:LDA TYPE,X:TAX:LDA NUM,X
X2STA NUMB:CLC:ADC LO:STA LO:LDA#0:ADC HI:STA HI
l3LDX NUMB:LDY#3:LDA HA:JSR HEXSP:DEY:DEX:BEQ PAD
v$LDA HB:JSR HEXSP:DEY:DEX:BEQ PAD
�!LDA HC:JSR HEXSP:DEX:BEQ MNEM
�.PAD TYA:PHA
�.LDX#(ST4 � 256):LDY#(ST4 � 256):JSR OUTPUT
�PLA:TAY:DEY:BNE PAD
� .MNEM LDA #�(" "):JSR OSASCI
�)LDX HA:LDA HASH,X:ASL A:ASL A:STA OUT
�*LDA#(STRING � 256):STA PUT:LDX#4:LDY#0
�5.MNMLOP LDA (OUT),Y:JSR OSASCI:INY:DEX:BNE MNMLOP
LDA #�(" "):JSR OSASCI
$LDX HA:LDA TYPE,X:CMP#1:BNE NOD1
*1LDA #�("#"):JSR OSASCI:LDA #�("&"):JSR OSASCI
>%LDA HB:JSR HEXSP:LDY#5:JMP NDLINE
R.NOD1 CMP#2:BNE NOD2
f)LDA #�("&"):JSR OSASCI:LDA HC:JSR HEX
p$LDA HB:JSR HEXSP:LDY#4:JMP NDLNE
�.NOD2 CMP#3:BNE NOD3
�+LDA #�("&"):JSR OSASCI:LDA HB:JSR HEXSP
�LDY#6:JMP NDLINE
�.NOD3 CMP#4:BNE NOD4
�+LDA #�("A"):JSR OSASCI:LDY#9:JMP NDLINE
�.NOD4:CMP#5:BNE NOD5
�LDY#10:JMP NDLINE
.NOD5 CMP#6:BNE NOD6
1LDA #�("("):JSR OSASCI:LDA #�("&"):JSR OSASCI
$)LDA HB:JSR HEX:LDA #�(","):JSR OSASCI
.1LDA #�("X"):JSR OSASCI:LDA #�(")"):JSR OSASCI
8LDY#3:JMP NDLINE
L.NOD6 CMP#7:BNE NOD7
`/LDA#�("("):JSR OSASCI:LDA#�("&"):JSR OSASCI
j(LDA HB:JSR HEX:LDA#�(")"):JSR OSASCI
t/LDA#�(","):JSR OSASCI:LDA#�("Y"):JSR OSASCI
~LDY#3:JMP NDLINE
�.NOD7 CMP#8:BNE NOD8
�(LDA#�("&"):JSR OSASCI:LDA HB:JSR HEX
�/LDA#�(","):JSR OSASCI:LDA#�("X"):JSR OSASCI
�LDY#5:JMP NDLINE
�.NOD8 CMP#9:BNE NOD9
�(LDA#�("&"):JSR OSASCI:LDA HC:JSR HEX
�(LDA HB:JSR HEX:LDA#�(","):JSR OSASCI
�LDA#�("X"):JSR OSASCI
LDY#3:JMP NDLINE
.NOD9 CMP#&A:BNE NODA
((LDA#�("&"):JSR OSASCI:LDA HC:JSR HEX
2(LDA HB:JSR HEX:LDA#�(","):JSR OSASCI
<LDA#�("Y"):JSR OSASCI
FLDY#3:JMP NDLINE
Z.NODA CMP#&B:BNE NODB
nLDA#�("&"):JSR OSASCI
�LDA HB:CMP#&7F:BCS BACK
�+CLC:ADC LO:PHA LDA#0:ADC HI:CLC:BCC REL
�..BACK �#255:ADC#0:STA&70:LDA LO:SEC:SBC&70
�PHA:LDA HI:SBC#0
� .REL JSR HEX:PLA:JSR HEXSP
�LDY#4:JMP NDLINE
�.NODB CMP#&C:BNE NODC
�/LDA#�("("):JSR OSASCI:LDA#�("&"):JSR OSASCI
!LDA HC:JSR HEX:LDA HB:JSR HEX
*LDA#�(")"):JSR OSASCI:LDY#3:JMP NDLINE
".NODC CMP#&D:BNE NODD
6(LDA#�("&"):JSR OSASCI:LDA HB:JSR HEX
@/LDA#�(","):JSR OSASCI:LDA#�("Y"):JSR OSASCI
JLDY#5:JMP NDLINE
^.NODD LDY#10
r0.NDLINE LDA#�(" "):JSR OSASCI:DEY:BPL NDLINE
�LDX NUMB:LDY#0
�3.DISPLOP LDA HA,Y:JSR CHOUT:INY:DEX:BNE DISPLOP
�2LDA#�(" "):.PAD2 JSR OSASCI:INY:CPY#4:BNE PAD2
�'LDX#5:.PAD3 JSR OSASCI:DEX:BNE PAD3
� LDA DLINES:CMP#16:BNE OVOLD
�!LDA LO:STA OLO:LDA HI:STA OHI
�LDA NUMB:STA OUMB
+.OVOLD DEC DLINES:BEQ FINLIN:JMP LINLOP
.FINLIN RTS
:#.DISPLAY LDY#2:LDX#15:JSR SETAB
N$LDA HI:JSR HEX:LDA LO:JSR HEXSP:
b!LDA DISP:CMP#�("L"):BEQ DDISP
vJSR SHOW:RTS
�.DDISP JSR DIS:RTS
�.SHOW LDX#(ST2 �256)
�LDY#(ST2 �256)
�JSR OUTPUT
�"LDA LO:�#&F8:SEC:SBC#64:STA UP
�LDA HI:SBC#0:STA STK
LDA LO:�#7:STA ACR
/LDX#0:.L4 STX STK+1:LDA#8:CLC:ADC UP:STA UP
LDA #0:ADC STK:STA STK
42JSR HEX:LDA UP:JSR HEXSP:LDA#�(" "):JSR OSASCI
HLDX#0:.L2 STX STK+2:TXA
RTAY
fLDA(UP),Y:JSR HEXSP
z LDX STK+2:INX:CPX#8:BNE L2
�LDX#0:.L3 STX STK+2:TXA
�TAY
�LDA(UP),Y:JSR CHOUT
� LDX STK+2:INX:CPX#8:BNE L3
�$LDA#�(" "):JSR OSASCI:JSR OSASCI
� LDX STK+1:INX:CPX#16:BNE L4
�$LDY#14:LDA ACR:ASL A:CLC:ADC ACR
!ADC#5:STA STK+1:TAX:JSR SETAB
LDA#�("["):JSR OSASCI
$,LDA STK+1:CLC:ADC#3:TAX:LDY#14:JSR SETAB
8LDA#�("]"):JSR OSASCI
BRTS
j .CHOUT CMP#�(" "):BCC DUF
~CMP#&7F:BCC OK
�.DUF LDA#�(".")
�.OK JSR OSASCI:RTS
� .SETAB STY ST3+2:STX ST3+1
�!LDX#(ST3 �256):LDY#(ST3 �256)
�JSR OUTPUT:RTS
".KEYIN LDX#0:LDA#21:JSR OSBYTE
JSR OSRDCH:BCS KEYERR:RTS
(.KEYERR STA STK+1
2)LDX#(ST6 �256):LDY#(ST6 �256):JSR CLI
< LDA STK+1:CMP#&1B:BNE KERR
PLDA#&7E:JSR OSBYTE
Z .KERR
n,LDX#0:LDY#22:JSR SETAB:LDX TEMPSTACK:TXS
�BRK:EQUB99
�EQUS"END OF DIS"
�BRK
�.OUTPUT STX&70:STY&71
� LDY#0
�'.LOOP LDA(&70),Y:CMP#&FF:BEQ OUTEND
�JSR OSASCI:INY:BNE LOOP
�.OUTEND RTS
"%.HEXSP JSR HEX:LDA#&20:JMP OSWRCH
6.HEX
J PHA:LSR A:LSR A:LSR A:LSR A
TJSR HEXDIG:PLA:�#&F
^#.HEXDIG CMP#&A:BCC HEXDIH:ADC#6
h .HEXDIH ADC#&30:JMP OSWRCH
� 00000000 0d 00 0a 17 eb 20 36 3a d3 3d 26 37 30 30 30 3a |..... 6:.=&7000:|
00000010 d2 3d 26 36 34 30 30 0d 00 14 13 ef 20 32 38 2c |.=&6400..... 28,|
00000020 30 2c 32 34 2c 33 39 2c 31 36 0d 00 1e 37 4f 53 |0,24,39,16...7OS|
00000030 42 59 54 45 3d 26 46 46 46 34 3a 4f 53 57 4f 52 |BYTE=&FFF4:OSWOR|
00000040 44 3d 26 46 46 46 31 3a 4f 53 41 53 43 49 3d 26 |D=&FFF1:OSASCI=&|
00000050 46 46 45 33 3a 4f 53 57 52 43 48 3d 26 46 46 45 |FFE3:OSWRCH=&FFE|
00000060 45 0d 00 28 1a 4f 53 52 44 43 48 3d 26 46 46 45 |E..(.OSRDCH=&FFE|
00000070 30 3a 43 4c 49 3d 26 46 46 46 37 0d 00 32 22 4f |0:CLI=&FFF7..2"O|
00000080 55 54 3d 26 37 30 3a 50 55 54 3d 26 37 31 3a 53 |UT=&70:PUT=&71:S|
00000090 50 3d 26 37 32 3a 42 50 54 3d 26 37 34 0d 00 3c |P=&72:BPT=&74..<|
000000a0 2c 43 4f 4e 42 4c 4b 3d 26 37 36 3a 48 49 3d 26 |,CONBLK=&76:HI=&|
000000b0 38 31 3a 4c 4f 3d 26 38 30 3a 44 49 53 50 3d 26 |81:LO=&80:DISP=&|
000000c0 38 32 3a 44 48 3d 26 38 33 0d 00 46 1a 55 50 3d |82:DH=&83..F.UP=|
000000d0 26 38 35 3a 53 54 4b 3d 26 38 36 3a 41 43 52 3d |&85:STK=&86:ACR=|
000000e0 26 38 34 0d 00 50 1c 4f 4c 4f 3d 26 37 42 3a 4f |&84..P.OLO=&7B:O|
000000f0 48 49 3d 26 37 43 3a 4f 55 4d 42 3d 26 38 38 0d |HI=&7C:OUMB=&88.|
00000100 00 5a 18 48 41 3d 26 38 44 3a 48 42 3d 26 38 45 |.Z.HA=&8D:HB=&8E|
00000110 3a 48 43 3d 26 38 46 0d 00 64 25 44 4c 49 4e 45 |:HC=&8F..d%DLINE|
00000120 53 3d 26 37 44 3a 4e 55 4d 42 3d 26 37 45 3a 54 |S=&7D:NUMB=&7E:T|
00000130 45 4d 50 53 54 41 43 4b 3d 26 37 46 0d 00 6e 12 |EMPSTACK=&7F..n.|
00000140 e3 20 4f 50 3d 30 20 b8 20 33 20 88 20 33 0d 00 |. OP=0 . 3 . 3..|
00000150 78 0c 50 25 3d 26 35 34 30 30 0d 01 c2 0b 5b 4f |x.P%=&5400....[O|
00000160 50 54 20 4f 50 0d 01 cc 15 54 53 58 3a 53 54 58 |PT OP....TSX:STX|
00000170 20 54 45 4d 50 53 54 41 43 4b 0d 01 e0 27 4c 44 | TEMPSTACK...'LD|
00000180 41 23 30 3a 53 54 41 20 43 4f 4e 42 4c 4b 3a 4c |A#0:STA CONBLK:L|
00000190 44 41 23 36 3a 53 54 41 20 43 4f 4e 42 4c 4b 2b |DA#6:STA CONBLK+|
000001a0 31 0d 01 f4 17 4c 44 41 23 97 28 22 44 22 29 3a |1....LDA#.("D"):|
000001b0 53 54 41 20 44 49 53 50 0d 02 08 13 4c 44 58 23 |STA DISP....LDX#|
000001c0 28 53 54 31 20 83 20 32 35 36 29 0d 02 12 13 4c |(ST1 . 256)....L|
000001d0 44 59 23 28 53 54 31 20 81 20 32 35 36 29 0d 02 |DY#(ST1 . 256)..|
000001e0 1c 0e 4a 53 52 20 4f 55 54 50 55 54 0d 02 30 1a |..JSR OUTPUT..0.|
000001f0 4c 44 41 23 34 3a 4c 44 58 23 31 3a 4a 53 52 20 |LDA#4:LDX#1:JSR |
00000200 4f 53 42 59 54 45 0d 02 4e 13 2e 4c 35 20 4a 53 |OSBYTE..N..L5 JS|
00000210 52 20 44 49 53 50 4c 41 59 0d 02 62 11 2e 4c 37 |R DISPLAY..b..L7|
00000220 20 4a 53 52 20 4b 45 59 49 4e 0d 02 76 17 43 4d | JSR KEYIN..v.CM|
00000230 50 23 97 28 22 44 22 29 3a 42 4e 45 20 4e 4f 4e |P#.("D"):BNE NON|
00000240 44 0d 02 8a 18 2e 53 54 44 20 53 54 41 20 44 49 |D.....STD STA DI|
00000250 53 50 3a 4a 4d 50 20 4c 35 0d 02 94 1c 2e 4e 4f |SP:JMP L5.....NO|
00000260 4e 44 20 43 4d 50 23 97 28 22 4c 22 29 3a 42 45 |ND CMP#.("L"):BE|
00000270 51 20 53 54 44 0d 02 b2 18 43 4d 50 20 23 97 28 |Q STD....CMP #.(|
00000280 22 48 22 29 3a 42 4e 45 20 4e 4f 4e 48 0d 02 c6 |"H"):BNE NONH...|
00000290 20 2e 48 47 49 4e 20 4c 44 58 23 31 35 3a 4c 44 | .HGIN LDX#15:LD|
000002a0 59 23 32 3a 4a 53 52 20 53 45 54 41 42 0d 02 da |Y#2:JSR SETAB...|
000002b0 29 4c 44 41 23 34 3a 4c 44 58 23 97 28 22 30 22 |)LDA#4:LDX#.("0"|
000002c0 29 3a 4c 44 59 23 97 28 22 46 22 29 3a 4a 53 52 |):LDY#.("F"):JSR|
000002d0 20 53 54 52 49 4e 0d 02 ee 22 4a 53 52 20 44 48 | STRIN..."JSR DH|
000002e0 45 58 3a 42 43 43 48 47 49 4e 3a 4c 44 41 20 44 |EX:BCCHGIN:LDA D|
000002f0 48 3a 53 54 41 20 48 49 0d 03 02 2c 4c 44 41 26 |H:STA HI...,LDA&|
00000300 36 30 32 3a 53 54 41 26 36 30 30 3a 4c 44 41 26 |602:STA&600:LDA&|
00000310 36 30 33 3a 53 54 41 26 36 30 31 3a 4a 53 52 20 |603:STA&601:JSR |
00000320 44 48 45 58 0d 03 16 21 42 43 43 20 48 47 49 4e |DHEX...!BCC HGIN|
00000330 3a 4c 44 41 20 44 48 3a 53 54 41 20 4c 4f 3a 4a |:LDA DH:STA LO:J|
00000340 4d 50 20 4c 35 0d 03 20 1c 2e 4e 4f 4e 48 20 43 |MP L5.. ..NONH C|
00000350 4d 50 23 97 28 22 46 22 29 3a 42 4e 45 20 4e 4f |MP#.("F"):BNE NO|
00000360 46 0d 03 34 20 2e 46 47 49 4e 20 4c 44 58 23 31 |F..4 .FGIN LDX#1|
00000370 35 3a 4c 44 59 23 33 3a 4a 53 52 20 53 45 54 41 |5:LDY#3:JSR SETA|
00000380 42 0d 03 3e 29 4c 44 41 23 32 3a 4c 44 58 23 97 |B..>)LDA#2:LDX#.|
00000390 28 22 30 22 29 3a 4c 44 59 23 97 28 22 46 22 29 |("0"):LDY#.("F")|
000003a0 3a 4a 53 52 20 53 54 52 49 4e 0d 03 48 34 4a 53 |:JSR STRIN..H4JS|
000003b0 52 20 44 48 45 58 3a 42 43 43 20 46 47 49 4e 3a |R DHEX:BCC FGIN:|
000003c0 4c 44 41 20 44 49 53 50 3a 43 4d 50 23 97 28 22 |LDA DISP:CMP#.("|
000003d0 4c 22 29 3a 42 4e 45 20 4f 56 53 57 41 50 0d 03 |L"):BNE OVSWAP..|
000003e0 52 34 4c 44 41 20 4f 4c 4f 3a 53 45 43 3a 53 42 |R4LDA OLO:SEC:SB|
000003f0 43 20 4f 55 4d 50 3a 53 54 41 20 4c 4f 3a 4c 44 |C OUMP:STA LO:LD|
00000400 41 20 4f 48 49 3a 53 42 43 23 30 3a 53 54 41 20 |A OHI:SBC#0:STA |
00000410 48 49 0d 03 5c 0b 2e 4f 56 53 57 41 50 0d 03 66 |HI..\..OVSWAP..f|
00000420 48 4c 44 59 23 30 3a 4c 44 41 20 44 48 3a 2e 46 |HLDY#0:LDA DH:.F|
00000430 4c 4f 4f 50 20 49 4e 43 20 4c 4f 3a 42 4e 45 20 |LOOP INC LO:BNE |
00000440 4f 56 48 49 3a 49 4e 43 20 48 49 3a 2e 4f 56 48 |OVHI:INC HI:.OVH|
00000450 49 20 43 4d 50 28 4c 4f 29 2c 59 3a 42 4e 45 20 |I CMP(LO),Y:BNE |
00000460 46 4c 4f 4f 50 0d 03 70 0a 4a 4d 50 20 4c 35 0d |FLOOP..p.JMP L5.|
00000470 03 8e 2e 2e 4e 4f 46 20 4c 44 58 20 44 49 53 50 |....NOF LDX DISP|
00000480 3a 43 50 58 23 97 28 22 4c 22 29 3a 42 4e 45 20 |:CPX#.("L"):BNE |
00000490 4e 4f 4e 46 3a 4a 4d 50 20 4c 43 4f 4d 0d 03 b6 |NONF:JMP LCOM...|
000004a0 1b 2e 4e 4f 4e 46 20 43 4d 50 23 26 38 38 3a 42 |..NONF CMP#&88:B|
000004b0 4e 45 20 4e 4c 45 46 54 0d 03 ca 2c 4c 44 41 20 |NE NLEFT...,LDA |
000004c0 4c 4f 3a 42 4e 45 20 44 45 31 3a 44 45 43 20 48 |LO:BNE DE1:DEC H|
000004d0 49 3a 2e 44 45 31 20 44 45 43 20 4c 4f 3a 4a 4d |I:.DE1 DEC LO:JM|
000004e0 50 20 4c 35 0d 03 de 1a 2e 4e 4c 45 46 54 20 43 |P L5.....NLEFT C|
000004f0 4d 50 23 26 38 39 3a 42 4e 45 20 4e 52 54 0d 03 |MP#&89:BNE NRT..|
00000500 f2 25 49 4e 43 20 4c 4f 3a 42 4e 45 20 44 45 32 |.%INC LO:BNE DE2|
00000510 3a 49 4e 43 20 48 49 3a 2e 44 45 32 20 4a 4d 50 |:INC HI:.DE2 JMP|
00000520 20 4c 35 0d 04 1a 1b 4c 44 41 20 4c 4f 3a 43 4c | L5....LDA LO:CL|
00000530 43 3a 41 44 43 23 38 3a 53 54 41 20 4c 4f 0d 04 |C:ADC#8:STA LO..|
00000540 24 1e 4c 44 41 20 48 49 3a 41 44 43 23 30 3a 53 |$.LDA HI:ADC#0:S|
00000550 54 41 20 48 49 3a 4a 4d 50 20 4c 35 0d 04 4c 1b |TA HI:JMP L5..L.|
00000560 4c 44 41 20 4c 4f 3a 53 45 43 3a 53 42 43 23 38 |LDA LO:SEC:SBC#8|
00000570 3a 53 54 41 20 4c 4f 0d 04 56 1e 4c 44 41 20 48 |:STA LO..V.LDA H|
00000580 49 3a 53 42 43 23 30 3a 53 54 41 20 48 49 3a 4a |I:SBC#0:STA HI:J|
00000590 4d 50 20 4c 35 0d 04 74 1e 2e 4e 4d 4f 56 45 20 |MP L5..t..NMOVE |
000005a0 43 4d 50 23 97 28 22 41 22 29 3a 42 4e 45 20 4e |CMP#.("A"):BNE N|
000005b0 4f 4e 41 0d 04 88 10 2e 41 47 49 4e 20 4c 44 59 |ONA.....AGIN LDY|
000005c0 23 31 34 0d 04 9c 27 4c 44 41 20 41 43 52 3a 41 |#14...'LDA ACR:A|
000005d0 53 4c 20 41 3a 43 4c 43 3a 41 44 43 20 41 43 52 |SL A:CLC:ADC ACR|
000005e0 3a 43 4c 43 3a 41 44 43 23 36 0d 04 b0 11 54 41 |:CLC:ADC#6....TA|
000005f0 58 3a 4a 53 52 20 53 45 54 41 42 0d 04 c4 29 4c |X:JSR SETAB...)L|
00000600 44 41 23 32 3a 4c 44 58 23 97 28 22 30 22 29 3a |DA#2:LDX#.("0"):|
00000610 4c 44 59 23 97 28 22 46 22 29 3a 4a 53 52 20 53 |LDY#.("F"):JSR S|
00000620 54 52 49 4e 0d 04 d8 2d 4a 53 52 20 44 48 45 58 |TRIN...-JSR DHEX|
00000630 3a 42 43 43 20 41 47 49 4e 3a 4c 44 41 20 44 48 |:BCC AGIN:LDA DH|
00000640 3a 4c 44 59 23 30 3a 53 54 41 20 28 4c 4f 29 2c |:LDY#0:STA (LO),|
00000650 59 0d 04 e2 0a 4a 4d 50 20 4c 35 0d 05 0a 27 2e |Y....JMP L5...'.|
00000660 44 48 45 58 20 4c 44 41 26 36 30 30 3a 43 4d 50 |DHEX LDA&600:CMP|
00000670 20 23 97 28 22 39 22 29 2b 31 3a 42 43 53 20 41 | #.("9")+1:BCS A|
00000680 4c 31 0d 05 14 11 80 23 26 30 46 3a 42 43 43 20 |L1.....#&0F:BCC |
00000690 54 49 50 0d 05 1e 2d 2e 41 4c 31 20 43 4d 50 20 |TIP...-.AL1 CMP |
000006a0 23 97 28 22 41 22 29 3a 42 43 43 20 45 52 48 45 |#.("A"):BCC ERHE|
000006b0 58 3a 53 42 43 20 23 97 28 22 41 22 29 2d 31 30 |X:SBC #.("A")-10|
000006c0 0d 05 32 27 2e 54 49 50 20 41 53 4c 20 41 3a 41 |..2'.TIP ASL A:A|
000006d0 53 4c 20 41 3a 41 53 4c 20 41 3a 41 53 4c 20 41 |SL A:ASL A:ASL A|
000006e0 3a 53 54 41 20 44 48 0d 05 3c 21 4c 44 41 26 36 |:STA DH..<!LDA&6|
000006f0 30 31 3a 43 4d 50 20 23 97 28 22 39 22 29 2b 31 |01:CMP #.("9")+1|
00000700 3a 42 43 53 20 41 4c 32 0d 05 46 11 80 23 26 30 |:BCS AL2..F..#&0|
00000710 46 3a 42 43 43 20 42 4f 54 0d 05 50 2d 2e 41 4c |F:BCC BOT..P-.AL|
00000720 32 20 43 4d 50 20 23 97 28 22 41 22 29 3a 42 43 |2 CMP #.("A"):BC|
00000730 43 20 45 52 48 45 58 3a 53 42 43 20 23 97 28 22 |C ERHEX:SBC #.("|
00000740 41 22 29 2d 31 30 0d 05 64 19 2e 42 4f 54 20 84 |A")-10..d..BOT .|
00000750 41 20 44 48 3a 53 54 41 20 44 48 3a 53 45 43 0d |A DH:STA DH:SEC.|
00000760 05 78 0e 2e 45 52 48 45 58 20 52 54 53 0d 05 a0 |.x..ERHEX RTS...|
00000770 1d 2e 4e 4f 4e 41 20 43 4d 50 20 23 97 28 22 53 |..NONA CMP #.("S|
00000780 22 29 42 4e 45 20 4e 4f 4e 53 0d 05 b4 31 2e 53 |")BNE NONS...1.S|
00000790 47 49 4e 20 4c 44 59 23 31 34 3a 4c 44 41 20 41 |GIN LDY#14:LDA A|
000007a0 43 52 3a 43 4c 43 3a 41 44 43 23 33 30 3a 54 41 |CR:CLC:ADC#30:TA|
000007b0 58 3a 4a 53 52 20 53 45 54 41 42 0d 05 c8 2d 4c |X:JSR SETAB...-L|
000007c0 44 41 23 32 35 35 3a 4c 44 58 20 23 97 28 22 20 |DA#255:LDX #.(" |
000007d0 22 29 3a 4c 44 59 20 23 97 28 22 7e 22 29 3a 4a |"):LDY #.("~"):J|
000007e0 53 52 20 53 54 52 49 4e 0d 05 dc 0f 4c 44 58 23 |SR STRIN....LDX#|
000007f0 30 3a 4c 44 59 23 30 0d 05 f0 25 2e 4c 4f 50 20 |0:LDY#0...%.LOP |
00000800 4c 44 41 26 36 30 30 2c 58 3a 43 4d 50 23 26 30 |LDA&600,X:CMP#&0|
00000810 44 3a 42 45 51 20 46 49 4e 4c 4f 50 0d 05 fa 1e |D:BEQ FINLOP....|
00000820 53 54 41 20 28 4c 4f 29 2c 59 3a 49 4e 59 3a 49 |STA (LO),Y:INY:I|
00000830 4e 58 3a 42 4e 45 20 4c 4f 50 0d 06 04 12 2e 46 |NX:BNE LOP.....F|
00000840 49 4e 4c 4f 50 20 4a 4d 50 20 4c 35 0d 06 22 09 |INLOP JMP L5..".|
00000850 2e 4e 4f 4e 53 0d 06 2c 0a 4a 4d 50 20 4c 37 0d |.NONS..,.JMP L7.|
00000860 06 54 1b 2e 4c 43 4f 4d 20 43 4d 50 23 26 30 44 |.T..LCOM CMP#&0D|
00000870 3a 42 4e 45 20 4e 4f 4e 43 52 0d 06 68 28 4c 44 |:BNE NONCR..h(LD|
00000880 41 20 4f 4c 4f 3a 53 54 41 20 4c 4f 3a 4c 44 41 |A OLO:STA LO:LDA|
00000890 20 4f 48 49 3a 53 54 41 20 48 49 3a 4a 4d 50 20 | OHI:STA HI:JMP |
000008a0 4c 35 0d 06 7c 1b 2e 4e 4f 4e 43 52 20 43 4d 50 |L5..|..NONCR CMP|
000008b0 23 26 38 42 3a 42 4e 45 20 4e 4f 4e 53 0d 06 90 |#&8B:BNE NONS...|
000008c0 28 4c 44 41 20 4f 4c 4f 3a 49 4e 43 20 4f 55 4d |(LDA OLO:INC OUM|
000008d0 42 3a 53 45 43 3a 53 42 43 20 4f 55 4d 42 3a 53 |B:SEC:SBC OUMB:S|
000008e0 54 41 20 4c 4f 0d 06 9a 1f 4c 44 41 20 4f 48 49 |TA LO....LDA OHI|
000008f0 3a 53 42 43 23 30 3a 53 54 41 20 48 49 3a 4a 4d |:SBC#0:STA HI:JM|
00000900 50 20 4c 35 0d 06 b8 18 2e 44 49 53 20 4c 44 58 |P L5.....DIS LDX|
00000910 23 28 53 54 32 20 83 20 32 35 36 29 0d 06 c2 13 |#(ST2 . 256)....|
00000920 4c 44 59 23 28 53 54 32 20 81 20 32 35 36 29 0d |LDY#(ST2 . 256).|
00000930 06 d6 0e 4a 53 52 20 4f 55 54 50 55 54 0d 06 ea |...JSR OUTPUT...|
00000940 15 4c 44 41 23 31 36 3a 53 54 41 20 44 4c 49 4e |.LDA#16:STA DLIN|
00000950 45 53 0d 06 f4 0b 2e 4c 49 4e 4c 4f 50 0d 07 08 |ES.....LINLOP...|
00000960 23 4c 44 41 20 48 49 3a 4a 53 52 20 48 45 58 3a |#LDA HI:JSR HEX:|
00000970 4c 44 41 20 4c 4f 3a 4a 53 52 20 48 45 58 53 50 |LDA LO:JSR HEXSP|
00000980 0d 07 26 0f 4c 44 59 23 30 3a 4c 44 58 23 33 0d |..&.LDY#0:LDX#3.|
00000990 07 30 2f 2e 48 41 4c 4f 50 20 4c 44 41 28 4c 4f |.0/.HALOP LDA(LO|
000009a0 29 2c 59 3a 53 54 41 20 48 41 2c 59 3a 49 4e 59 |),Y:STA HA,Y:INY|
000009b0 3a 44 45 58 3a 42 4e 45 20 48 41 4c 4f 50 0d 07 |:DEX:BNE HALOP..|
000009c0 44 23 4c 44 58 20 48 41 3a 4c 44 41 20 54 59 50 |D#LDX HA:LDA TYP|
000009d0 45 2c 58 3a 54 41 58 3a 4c 44 41 20 4e 55 4d 2c |E,X:TAX:LDA NUM,|
000009e0 58 0d 07 58 32 53 54 41 20 4e 55 4d 42 3a 43 4c |X..X2STA NUMB:CL|
000009f0 43 3a 41 44 43 20 4c 4f 3a 53 54 41 20 4c 4f 3a |C:ADC LO:STA LO:|
00000a00 4c 44 41 23 30 3a 41 44 43 20 48 49 3a 53 54 41 |LDA#0:ADC HI:STA|
00000a10 20 48 49 0d 07 6c 33 4c 44 58 20 4e 55 4d 42 3a | HI..l3LDX NUMB:|
00000a20 4c 44 59 23 33 3a 4c 44 41 20 48 41 3a 4a 53 52 |LDY#3:LDA HA:JSR|
00000a30 20 48 45 58 53 50 3a 44 45 59 3a 44 45 58 3a 42 | HEXSP:DEY:DEX:B|
00000a40 45 51 20 50 41 44 0d 07 76 24 4c 44 41 20 48 42 |EQ PAD..v$LDA HB|
00000a50 3a 4a 53 52 20 48 45 58 53 50 3a 44 45 59 3a 44 |:JSR HEXSP:DEY:D|
00000a60 45 58 3a 42 45 51 20 50 41 44 0d 07 80 21 4c 44 |EX:BEQ PAD...!LD|
00000a70 41 20 48 43 3a 4a 53 52 20 48 45 58 53 50 3a 44 |A HC:JSR HEXSP:D|
00000a80 45 58 3a 42 45 51 20 4d 4e 45 4d 0d 07 94 10 2e |EX:BEQ MNEM.....|
00000a90 50 41 44 20 54 59 41 3a 50 48 41 0d 07 9e 2e 4c |PAD TYA:PHA....L|
00000aa0 44 58 23 28 53 54 34 20 83 20 32 35 36 29 3a 4c |DX#(ST4 . 256):L|
00000ab0 44 59 23 28 53 54 34 20 81 20 32 35 36 29 3a 4a |DY#(ST4 . 256):J|
00000ac0 53 52 20 4f 55 54 50 55 54 0d 07 a8 17 50 4c 41 |SR OUTPUT....PLA|
00000ad0 3a 54 41 59 3a 44 45 59 3a 42 4e 45 20 50 41 44 |:TAY:DEY:BNE PAD|
00000ae0 0d 07 bc 20 2e 4d 4e 45 4d 20 4c 44 41 20 23 97 |... .MNEM LDA #.|
00000af0 28 22 20 22 29 3a 4a 53 52 20 4f 53 41 53 43 49 |(" "):JSR OSASCI|
00000b00 0d 07 d0 29 4c 44 58 20 48 41 3a 4c 44 41 20 48 |...)LDX HA:LDA H|
00000b10 41 53 48 2c 58 3a 41 53 4c 20 41 3a 41 53 4c 20 |ASH,X:ASL A:ASL |
00000b20 41 3a 53 54 41 20 4f 55 54 0d 07 e4 2a 4c 44 41 |A:STA OUT...*LDA|
00000b30 23 28 53 54 52 49 4e 47 20 81 20 32 35 36 29 3a |#(STRING . 256):|
00000b40 53 54 41 20 50 55 54 3a 4c 44 58 23 34 3a 4c 44 |STA PUT:LDX#4:LD|
00000b50 59 23 30 0d 07 f8 35 2e 4d 4e 4d 4c 4f 50 20 4c |Y#0...5.MNMLOP L|
00000b60 44 41 20 28 4f 55 54 29 2c 59 3a 4a 53 52 20 4f |DA (OUT),Y:JSR O|
00000b70 53 41 53 43 49 3a 49 4e 59 3a 44 45 58 3a 42 4e |SASCI:INY:DEX:BN|
00000b80 45 20 4d 4e 4d 4c 4f 50 0d 08 02 1a 4c 44 41 20 |E MNMLOP....LDA |
00000b90 23 97 28 22 20 22 29 3a 4a 53 52 20 4f 53 41 53 |#.(" "):JSR OSAS|
00000ba0 43 49 0d 08 16 24 4c 44 58 20 48 41 3a 4c 44 41 |CI...$LDX HA:LDA|
00000bb0 20 54 59 50 45 2c 58 3a 43 4d 50 23 31 3a 42 4e | TYPE,X:CMP#1:BN|
00000bc0 45 20 4e 4f 44 31 0d 08 2a 31 4c 44 41 20 23 97 |E NOD1..*1LDA #.|
00000bd0 28 22 23 22 29 3a 4a 53 52 20 4f 53 41 53 43 49 |("#"):JSR OSASCI|
00000be0 3a 4c 44 41 20 23 97 28 22 26 22 29 3a 4a 53 52 |:LDA #.("&"):JSR|
00000bf0 20 4f 53 41 53 43 49 0d 08 3e 25 4c 44 41 20 48 | OSASCI..>%LDA H|
00000c00 42 3a 4a 53 52 20 48 45 58 53 50 3a 4c 44 59 23 |B:JSR HEXSP:LDY#|
00000c10 35 3a 4a 4d 50 20 4e 44 4c 49 4e 45 0d 08 52 18 |5:JMP NDLINE..R.|
00000c20 2e 4e 4f 44 31 20 43 4d 50 23 32 3a 42 4e 45 20 |.NOD1 CMP#2:BNE |
00000c30 4e 4f 44 32 0d 08 66 29 4c 44 41 20 23 97 28 22 |NOD2..f)LDA #.("|
00000c40 26 22 29 3a 4a 53 52 20 4f 53 41 53 43 49 3a 4c |&"):JSR OSASCI:L|
00000c50 44 41 20 48 43 3a 4a 53 52 20 48 45 58 0d 08 70 |DA HC:JSR HEX..p|
00000c60 24 4c 44 41 20 48 42 3a 4a 53 52 20 48 45 58 53 |$LDA HB:JSR HEXS|
00000c70 50 3a 4c 44 59 23 34 3a 4a 4d 50 20 4e 44 4c 4e |P:LDY#4:JMP NDLN|
00000c80 45 0d 08 84 18 2e 4e 4f 44 32 20 43 4d 50 23 33 |E.....NOD2 CMP#3|
00000c90 3a 42 4e 45 20 4e 4f 44 33 0d 08 98 2b 4c 44 41 |:BNE NOD3...+LDA|
00000ca0 20 23 97 28 22 26 22 29 3a 4a 53 52 20 4f 53 41 | #.("&"):JSR OSA|
00000cb0 53 43 49 3a 4c 44 41 20 48 42 3a 4a 53 52 20 48 |SCI:LDA HB:JSR H|
00000cc0 45 58 53 50 0d 08 a2 14 4c 44 59 23 36 3a 4a 4d |EXSP....LDY#6:JM|
00000cd0 50 20 4e 44 4c 49 4e 45 0d 08 b6 18 2e 4e 4f 44 |P NDLINE.....NOD|
00000ce0 33 20 43 4d 50 23 34 3a 42 4e 45 20 4e 4f 44 34 |3 CMP#4:BNE NOD4|
00000cf0 0d 08 ca 2b 4c 44 41 20 23 97 28 22 41 22 29 3a |...+LDA #.("A"):|
00000d00 4a 53 52 20 4f 53 41 53 43 49 3a 4c 44 59 23 39 |JSR OSASCI:LDY#9|
00000d10 3a 4a 4d 50 20 4e 44 4c 49 4e 45 0d 08 de 18 2e |:JMP NDLINE.....|
00000d20 4e 4f 44 34 3a 43 4d 50 23 35 3a 42 4e 45 20 4e |NOD4:CMP#5:BNE N|
00000d30 4f 44 35 0d 08 f2 15 4c 44 59 23 31 30 3a 4a 4d |OD5....LDY#10:JM|
00000d40 50 20 4e 44 4c 49 4e 45 0d 09 06 18 2e 4e 4f 44 |P NDLINE.....NOD|
00000d50 35 20 43 4d 50 23 36 3a 42 4e 45 20 4e 4f 44 36 |5 CMP#6:BNE NOD6|
00000d60 0d 09 1a 31 4c 44 41 20 23 97 28 22 28 22 29 3a |...1LDA #.("("):|
00000d70 4a 53 52 20 4f 53 41 53 43 49 3a 4c 44 41 20 23 |JSR OSASCI:LDA #|
00000d80 97 28 22 26 22 29 3a 4a 53 52 20 4f 53 41 53 43 |.("&"):JSR OSASC|
00000d90 49 0d 09 24 29 4c 44 41 20 48 42 3a 4a 53 52 20 |I..$)LDA HB:JSR |
00000da0 48 45 58 3a 4c 44 41 20 23 97 28 22 2c 22 29 3a |HEX:LDA #.(","):|
00000db0 4a 53 52 20 4f 53 41 53 43 49 0d 09 2e 31 4c 44 |JSR OSASCI...1LD|
00000dc0 41 20 23 97 28 22 58 22 29 3a 4a 53 52 20 4f 53 |A #.("X"):JSR OS|
00000dd0 41 53 43 49 3a 4c 44 41 20 23 97 28 22 29 22 29 |ASCI:LDA #.(")")|
00000de0 3a 4a 53 52 20 4f 53 41 53 43 49 0d 09 38 14 4c |:JSR OSASCI..8.L|
00000df0 44 59 23 33 3a 4a 4d 50 20 4e 44 4c 49 4e 45 0d |DY#3:JMP NDLINE.|
00000e00 09 4c 18 2e 4e 4f 44 36 20 43 4d 50 23 37 3a 42 |.L..NOD6 CMP#7:B|
00000e10 4e 45 20 4e 4f 44 37 0d 09 60 2f 4c 44 41 23 97 |NE NOD7..`/LDA#.|
00000e20 28 22 28 22 29 3a 4a 53 52 20 4f 53 41 53 43 49 |("("):JSR OSASCI|
00000e30 3a 4c 44 41 23 97 28 22 26 22 29 3a 4a 53 52 20 |:LDA#.("&"):JSR |
00000e40 4f 53 41 53 43 49 0d 09 6a 28 4c 44 41 20 48 42 |OSASCI..j(LDA HB|
00000e50 3a 4a 53 52 20 48 45 58 3a 4c 44 41 23 97 28 22 |:JSR HEX:LDA#.("|
00000e60 29 22 29 3a 4a 53 52 20 4f 53 41 53 43 49 0d 09 |)"):JSR OSASCI..|
00000e70 74 2f 4c 44 41 23 97 28 22 2c 22 29 3a 4a 53 52 |t/LDA#.(","):JSR|
00000e80 20 4f 53 41 53 43 49 3a 4c 44 41 23 97 28 22 59 | OSASCI:LDA#.("Y|
00000e90 22 29 3a 4a 53 52 20 4f 53 41 53 43 49 0d 09 7e |"):JSR OSASCI..~|
00000ea0 14 4c 44 59 23 33 3a 4a 4d 50 20 4e 44 4c 49 4e |.LDY#3:JMP NDLIN|
00000eb0 45 0d 09 92 18 2e 4e 4f 44 37 20 43 4d 50 23 38 |E.....NOD7 CMP#8|
00000ec0 3a 42 4e 45 20 4e 4f 44 38 0d 09 a6 28 4c 44 41 |:BNE NOD8...(LDA|
00000ed0 23 97 28 22 26 22 29 3a 4a 53 52 20 4f 53 41 53 |#.("&"):JSR OSAS|
00000ee0 43 49 3a 4c 44 41 20 48 42 3a 4a 53 52 20 48 45 |CI:LDA HB:JSR HE|
00000ef0 58 0d 09 b0 2f 4c 44 41 23 97 28 22 2c 22 29 3a |X.../LDA#.(","):|
00000f00 4a 53 52 20 4f 53 41 53 43 49 3a 4c 44 41 23 97 |JSR OSASCI:LDA#.|
00000f10 28 22 58 22 29 3a 4a 53 52 20 4f 53 41 53 43 49 |("X"):JSR OSASCI|
00000f20 0d 09 ba 14 4c 44 59 23 35 3a 4a 4d 50 20 4e 44 |....LDY#5:JMP ND|
00000f30 4c 49 4e 45 0d 09 ce 18 2e 4e 4f 44 38 20 43 4d |LINE.....NOD8 CM|
00000f40 50 23 39 3a 42 4e 45 20 4e 4f 44 39 0d 09 e2 28 |P#9:BNE NOD9...(|
00000f50 4c 44 41 23 97 28 22 26 22 29 3a 4a 53 52 20 4f |LDA#.("&"):JSR O|
00000f60 53 41 53 43 49 3a 4c 44 41 20 48 43 3a 4a 53 52 |SASCI:LDA HC:JSR|
00000f70 20 48 45 58 0d 09 ec 28 4c 44 41 20 48 42 3a 4a | HEX...(LDA HB:J|
00000f80 53 52 20 48 45 58 3a 4c 44 41 23 97 28 22 2c 22 |SR HEX:LDA#.(","|
00000f90 29 3a 4a 53 52 20 4f 53 41 53 43 49 0d 09 f6 19 |):JSR OSASCI....|
00000fa0 4c 44 41 23 97 28 22 58 22 29 3a 4a 53 52 20 4f |LDA#.("X"):JSR O|
00000fb0 53 41 53 43 49 0d 0a 00 14 4c 44 59 23 33 3a 4a |SASCI....LDY#3:J|
00000fc0 4d 50 20 4e 44 4c 49 4e 45 0d 0a 14 19 2e 4e 4f |MP NDLINE.....NO|
00000fd0 44 39 20 43 4d 50 23 26 41 3a 42 4e 45 20 4e 4f |D9 CMP#&A:BNE NO|
00000fe0 44 41 0d 0a 28 28 4c 44 41 23 97 28 22 26 22 29 |DA..((LDA#.("&")|
00000ff0 3a 4a 53 52 20 4f 53 41 53 43 49 3a 4c 44 41 20 |:JSR OSASCI:LDA |
00001000 48 43 3a 4a 53 52 20 48 45 58 0d 0a 32 28 4c 44 |HC:JSR HEX..2(LD|
00001010 41 20 48 42 3a 4a 53 52 20 48 45 58 3a 4c 44 41 |A HB:JSR HEX:LDA|
00001020 23 97 28 22 2c 22 29 3a 4a 53 52 20 4f 53 41 53 |#.(","):JSR OSAS|
00001030 43 49 0d 0a 3c 19 4c 44 41 23 97 28 22 59 22 29 |CI..<.LDA#.("Y")|
00001040 3a 4a 53 52 20 4f 53 41 53 43 49 0d 0a 46 14 4c |:JSR OSASCI..F.L|
00001050 44 59 23 33 3a 4a 4d 50 20 4e 44 4c 49 4e 45 0d |DY#3:JMP NDLINE.|
00001060 0a 5a 19 2e 4e 4f 44 41 20 43 4d 50 23 26 42 3a |.Z..NODA CMP#&B:|
00001070 42 4e 45 20 4e 4f 44 42 0d 0a 6e 19 4c 44 41 23 |BNE NODB..n.LDA#|
00001080 97 28 22 26 22 29 3a 4a 53 52 20 4f 53 41 53 43 |.("&"):JSR OSASC|
00001090 49 0d 0a 82 1b 4c 44 41 20 48 42 3a 43 4d 50 23 |I....LDA HB:CMP#|
000010a0 26 37 46 3a 42 43 53 20 42 41 43 4b 0d 0a 96 2b |&7F:BCS BACK...+|
000010b0 43 4c 43 3a 41 44 43 20 4c 4f 3a 50 48 41 20 4c |CLC:ADC LO:PHA L|
000010c0 44 41 23 30 3a 41 44 43 20 48 49 3a 43 4c 43 3a |DA#0:ADC HI:CLC:|
000010d0 42 43 43 20 52 45 4c 0d 0a aa 2e 2e 42 41 43 4b |BCC REL.....BACK|
000010e0 20 82 23 32 35 35 3a 41 44 43 23 30 3a 53 54 41 | .#255:ADC#0:STA|
000010f0 26 37 30 3a 4c 44 41 20 4c 4f 3a 53 45 43 3a 53 |&70:LDA LO:SEC:S|
00001100 42 43 26 37 30 0d 0a b4 14 50 48 41 3a 4c 44 41 |BC&70....PHA:LDA|
00001110 20 48 49 3a 53 42 43 23 30 0d 0a c8 1e 2e 52 45 | HI:SBC#0.....RE|
00001120 4c 20 4a 53 52 20 48 45 58 3a 50 4c 41 3a 4a 53 |L JSR HEX:PLA:JS|
00001130 52 20 48 45 58 53 50 0d 0a d2 14 4c 44 59 23 34 |R HEXSP....LDY#4|
00001140 3a 4a 4d 50 20 4e 44 4c 49 4e 45 0d 0a e6 19 2e |:JMP NDLINE.....|
00001150 4e 4f 44 42 20 43 4d 50 23 26 43 3a 42 4e 45 20 |NODB CMP#&C:BNE |
00001160 4e 4f 44 43 0d 0a fa 2f 4c 44 41 23 97 28 22 28 |NODC.../LDA#.("(|
00001170 22 29 3a 4a 53 52 20 4f 53 41 53 43 49 3a 4c 44 |"):JSR OSASCI:LD|
00001180 41 23 97 28 22 26 22 29 3a 4a 53 52 20 4f 53 41 |A#.("&"):JSR OSA|
00001190 53 43 49 0d 0b 04 21 4c 44 41 20 48 43 3a 4a 53 |SCI...!LDA HC:JS|
000011a0 52 20 48 45 58 3a 4c 44 41 20 48 42 3a 4a 53 52 |R HEX:LDA HB:JSR|
000011b0 20 48 45 58 0d 0b 0e 2a 4c 44 41 23 97 28 22 29 | HEX...*LDA#.(")|
000011c0 22 29 3a 4a 53 52 20 4f 53 41 53 43 49 3a 4c 44 |"):JSR OSASCI:LD|
000011d0 59 23 33 3a 4a 4d 50 20 4e 44 4c 49 4e 45 0d 0b |Y#3:JMP NDLINE..|
000011e0 22 19 2e 4e 4f 44 43 20 43 4d 50 23 26 44 3a 42 |"..NODC CMP#&D:B|
000011f0 4e 45 20 4e 4f 44 44 0d 0b 36 28 4c 44 41 23 97 |NE NODD..6(LDA#.|
00001200 28 22 26 22 29 3a 4a 53 52 20 4f 53 41 53 43 49 |("&"):JSR OSASCI|
00001210 3a 4c 44 41 20 48 42 3a 4a 53 52 20 48 45 58 0d |:LDA HB:JSR HEX.|
00001220 0b 40 2f 4c 44 41 23 97 28 22 2c 22 29 3a 4a 53 |.@/LDA#.(","):JS|
00001230 52 20 4f 53 41 53 43 49 3a 4c 44 41 23 97 28 22 |R OSASCI:LDA#.("|
00001240 59 22 29 3a 4a 53 52 20 4f 53 41 53 43 49 0d 0b |Y"):JSR OSASCI..|
00001250 4a 14 4c 44 59 23 35 3a 4a 4d 50 20 4e 44 4c 49 |J.LDY#5:JMP NDLI|
00001260 4e 45 0d 0b 5e 10 2e 4e 4f 44 44 20 4c 44 59 23 |NE..^..NODD LDY#|
00001270 31 30 0d 0b 72 30 2e 4e 44 4c 49 4e 45 20 4c 44 |10..r0.NDLINE LD|
00001280 41 23 97 28 22 20 22 29 3a 4a 53 52 20 4f 53 41 |A#.(" "):JSR OSA|
00001290 53 43 49 3a 44 45 59 3a 42 50 4c 20 4e 44 4c 49 |SCI:DEY:BPL NDLI|
000012a0 4e 45 0d 0b 86 12 4c 44 58 20 4e 55 4d 42 3a 4c |NE....LDX NUMB:L|
000012b0 44 59 23 30 0d 0b 90 33 2e 44 49 53 50 4c 4f 50 |DY#0...3.DISPLOP|
000012c0 20 4c 44 41 20 48 41 2c 59 3a 4a 53 52 20 43 48 | LDA HA,Y:JSR CH|
000012d0 4f 55 54 3a 49 4e 59 3a 44 45 58 3a 42 4e 45 20 |OUT:INY:DEX:BNE |
000012e0 44 49 53 50 4c 4f 50 0d 0b a4 32 4c 44 41 23 97 |DISPLOP...2LDA#.|
000012f0 28 22 20 22 29 3a 2e 50 41 44 32 20 4a 53 52 20 |(" "):.PAD2 JSR |
00001300 4f 53 41 53 43 49 3a 49 4e 59 3a 43 50 59 23 34 |OSASCI:INY:CPY#4|
00001310 3a 42 4e 45 20 50 41 44 32 0d 0b b8 27 4c 44 58 |:BNE PAD2...'LDX|
00001320 23 35 3a 2e 50 41 44 33 20 4a 53 52 20 4f 53 41 |#5:.PAD3 JSR OSA|
00001330 53 43 49 3a 44 45 58 3a 42 4e 45 20 50 41 44 33 |SCI:DEX:BNE PAD3|
00001340 0d 0b d6 1f 4c 44 41 20 44 4c 49 4e 45 53 3a 43 |....LDA DLINES:C|
00001350 4d 50 23 31 36 3a 42 4e 45 20 4f 56 4f 4c 44 0d |MP#16:BNE OVOLD.|
00001360 0b ea 21 4c 44 41 20 4c 4f 3a 53 54 41 20 4f 4c |..!LDA LO:STA OL|
00001370 4f 3a 4c 44 41 20 48 49 3a 53 54 41 20 4f 48 49 |O:LDA HI:STA OHI|
00001380 0d 0b f4 15 4c 44 41 20 4e 55 4d 42 3a 53 54 41 |....LDA NUMB:STA|
00001390 20 4f 55 4d 42 0d 0c 08 2b 2e 4f 56 4f 4c 44 20 | OUMB...+.OVOLD |
000013a0 44 45 43 20 44 4c 49 4e 45 53 3a 42 45 51 20 46 |DEC DLINES:BEQ F|
000013b0 49 4e 4c 49 4e 3a 4a 4d 50 20 4c 49 4e 4c 4f 50 |INLIN:JMP LINLOP|
000013c0 0d 0c 12 0f 2e 46 49 4e 4c 49 4e 20 52 54 53 0d |.....FINLIN RTS.|
000013d0 0c 3a 23 2e 44 49 53 50 4c 41 59 20 4c 44 59 23 |.:#.DISPLAY LDY#|
000013e0 32 3a 4c 44 58 23 31 35 3a 4a 53 52 20 53 45 54 |2:LDX#15:JSR SET|
000013f0 41 42 0d 0c 4e 24 4c 44 41 20 48 49 3a 4a 53 52 |AB..N$LDA HI:JSR|
00001400 20 48 45 58 3a 4c 44 41 20 4c 4f 3a 4a 53 52 20 | HEX:LDA LO:JSR |
00001410 48 45 58 53 50 3a 0d 0c 62 21 4c 44 41 20 44 49 |HEXSP:..b!LDA DI|
00001420 53 50 3a 43 4d 50 23 97 28 22 4c 22 29 3a 42 45 |SP:CMP#.("L"):BE|
00001430 51 20 44 44 49 53 50 0d 0c 76 10 4a 53 52 20 53 |Q DDISP..v.JSR S|
00001440 48 4f 57 3a 52 54 53 0d 0c 8a 16 2e 44 44 49 53 |HOW:RTS.....DDIS|
00001450 50 20 4a 53 52 20 44 49 53 3a 52 54 53 0d 0c b2 |P JSR DIS:RTS...|
00001460 18 2e 53 48 4f 57 20 4c 44 58 23 28 53 54 32 20 |..SHOW LDX#(ST2 |
00001470 83 32 35 36 29 0d 0c bc 12 4c 44 59 23 28 53 54 |.256)....LDY#(ST|
00001480 32 20 81 32 35 36 29 0d 0c d0 0e 4a 53 52 20 4f |2 .256)....JSR O|
00001490 55 54 50 55 54 0d 0c e4 22 4c 44 41 20 4c 4f 3a |UTPUT..."LDA LO:|
000014a0 80 23 26 46 38 3a 53 45 43 3a 53 42 43 23 36 34 |.#&F8:SEC:SBC#64|
000014b0 3a 53 54 41 20 55 50 0d 0c ee 18 4c 44 41 20 48 |:STA UP....LDA H|
000014c0 49 3a 53 42 43 23 30 3a 53 54 41 20 53 54 4b 0d |I:SBC#0:STA STK.|
000014d0 0d 02 16 4c 44 41 20 4c 4f 3a 80 23 37 3a 53 54 |...LDA LO:.#7:ST|
000014e0 41 20 41 43 52 0d 0d 16 2f 4c 44 58 23 30 3a 2e |A ACR.../LDX#0:.|
000014f0 4c 34 20 53 54 58 20 53 54 4b 2b 31 3a 4c 44 41 |L4 STX STK+1:LDA|
00001500 23 38 3a 43 4c 43 3a 41 44 43 20 55 50 3a 53 54 |#8:CLC:ADC UP:ST|
00001510 41 20 55 50 0d 0d 20 1a 4c 44 41 20 23 30 3a 41 |A UP.. .LDA #0:A|
00001520 44 43 20 53 54 4b 3a 53 54 41 20 53 54 4b 0d 0d |DC STK:STA STK..|
00001530 34 32 4a 53 52 20 48 45 58 3a 4c 44 41 20 55 50 |42JSR HEX:LDA UP|
00001540 3a 4a 53 52 20 48 45 58 53 50 3a 4c 44 41 23 97 |:JSR HEXSP:LDA#.|
00001550 28 22 20 22 29 3a 4a 53 52 20 4f 53 41 53 43 49 |(" "):JSR OSASCI|
00001560 0d 0d 48 1b 4c 44 58 23 30 3a 2e 4c 32 20 53 54 |..H.LDX#0:.L2 ST|
00001570 58 20 53 54 4b 2b 32 3a 54 58 41 0d 0d 52 07 54 |X STK+2:TXA..R.T|
00001580 41 59 0d 0d 66 17 4c 44 41 28 55 50 29 2c 59 3a |AY..f.LDA(UP),Y:|
00001590 4a 53 52 20 48 45 58 53 50 0d 0d 7a 1e 4c 44 58 |JSR HEXSP..z.LDX|
000015a0 20 53 54 4b 2b 32 3a 49 4e 58 3a 43 50 58 23 38 | STK+2:INX:CPX#8|
000015b0 3a 42 4e 45 20 4c 32 0d 0d 8e 1b 4c 44 58 23 30 |:BNE L2....LDX#0|
000015c0 3a 2e 4c 33 20 53 54 58 20 53 54 4b 2b 32 3a 54 |:.L3 STX STK+2:T|
000015d0 58 41 0d 0d a2 07 54 41 59 0d 0d ac 17 4c 44 41 |XA....TAY....LDA|
000015e0 28 55 50 29 2c 59 3a 4a 53 52 20 43 48 4f 55 54 |(UP),Y:JSR CHOUT|
000015f0 0d 0d c0 1e 4c 44 58 20 53 54 4b 2b 32 3a 49 4e |....LDX STK+2:IN|
00001600 58 3a 43 50 58 23 38 3a 42 4e 45 20 4c 33 0d 0d |X:CPX#8:BNE L3..|
00001610 d4 24 4c 44 41 23 97 28 22 20 22 29 3a 4a 53 52 |.$LDA#.(" "):JSR|
00001620 20 4f 53 41 53 43 49 3a 4a 53 52 20 4f 53 41 53 | OSASCI:JSR OSAS|
00001630 43 49 0d 0d e8 1f 4c 44 58 20 53 54 4b 2b 31 3a |CI....LDX STK+1:|
00001640 49 4e 58 3a 43 50 58 23 31 36 3a 42 4e 45 20 4c |INX:CPX#16:BNE L|
00001650 34 0d 0d fc 24 4c 44 59 23 31 34 3a 4c 44 41 20 |4...$LDY#14:LDA |
00001660 41 43 52 3a 41 53 4c 20 41 3a 43 4c 43 3a 41 44 |ACR:ASL A:CLC:AD|
00001670 43 20 41 43 52 0d 0e 06 21 41 44 43 23 35 3a 53 |C ACR...!ADC#5:S|
00001680 54 41 20 53 54 4b 2b 31 3a 54 41 58 3a 4a 53 52 |TA STK+1:TAX:JSR|
00001690 20 53 45 54 41 42 0d 0e 1a 19 4c 44 41 23 97 28 | SETAB....LDA#.(|
000016a0 22 5b 22 29 3a 4a 53 52 20 4f 53 41 53 43 49 0d |"["):JSR OSASCI.|
000016b0 0e 24 2c 4c 44 41 20 53 54 4b 2b 31 3a 43 4c 43 |.$,LDA STK+1:CLC|
000016c0 3a 41 44 43 23 33 3a 54 41 58 3a 4c 44 59 23 31 |:ADC#3:TAX:LDY#1|
000016d0 34 3a 4a 53 52 20 53 45 54 41 42 0d 0e 38 19 4c |4:JSR SETAB..8.L|
000016e0 44 41 23 97 28 22 5d 22 29 3a 4a 53 52 20 4f 53 |DA#.("]"):JSR OS|
000016f0 41 53 43 49 0d 0e 42 07 52 54 53 0d 0e 6a 1d 2e |ASCI..B.RTS..j..|
00001700 43 48 4f 55 54 20 43 4d 50 23 97 28 22 20 22 29 |CHOUT CMP#.(" ")|
00001710 3a 42 43 43 20 44 55 46 0d 0e 7e 12 43 4d 50 23 |:BCC DUF..~.CMP#|
00001720 26 37 46 3a 42 43 43 20 4f 4b 0d 0e 9c 13 2e 44 |&7F:BCC OK.....D|
00001730 55 46 20 4c 44 41 23 97 28 22 2e 22 29 0d 0e a6 |UF LDA#.(".")...|
00001740 16 2e 4f 4b 20 4a 53 52 20 4f 53 41 53 43 49 3a |..OK JSR OSASCI:|
00001750 52 54 53 0d 0e ce 1e 2e 53 45 54 41 42 20 53 54 |RTS.....SETAB ST|
00001760 59 20 53 54 33 2b 32 3a 53 54 58 20 53 54 33 2b |Y ST3+2:STX ST3+|
00001770 31 0d 0e d8 21 4c 44 58 23 28 53 54 33 20 83 32 |1...!LDX#(ST3 .2|
00001780 35 36 29 3a 4c 44 59 23 28 53 54 33 20 81 32 35 |56):LDY#(ST3 .25|
00001790 36 29 0d 0e e2 12 4a 53 52 20 4f 55 54 50 55 54 |6)....JSR OUTPUT|
000017a0 3a 52 54 53 0d 0f 0a 22 2e 4b 45 59 49 4e 20 4c |:RTS...".KEYIN L|
000017b0 44 58 23 30 3a 4c 44 41 23 32 31 3a 4a 53 52 20 |DX#0:LDA#21:JSR |
000017c0 4f 53 42 59 54 45 0d 0f 14 1d 4a 53 52 20 4f 53 |OSBYTE....JSR OS|
000017d0 52 44 43 48 3a 42 43 53 20 4b 45 59 45 52 52 3a |RDCH:BCS KEYERR:|
000017e0 52 54 53 0d 0f 28 15 2e 4b 45 59 45 52 52 20 53 |RTS..(..KEYERR S|
000017f0 54 41 20 53 54 4b 2b 31 0d 0f 32 29 4c 44 58 23 |TA STK+1..2)LDX#|
00001800 28 53 54 36 20 83 32 35 36 29 3a 4c 44 59 23 28 |(ST6 .256):LDY#(|
00001810 53 54 36 20 81 32 35 36 29 3a 4a 53 52 20 43 4c |ST6 .256):JSR CL|
00001820 49 0d 0f 3c 1e 4c 44 41 20 53 54 4b 2b 31 3a 43 |I..<.LDA STK+1:C|
00001830 4d 50 23 26 31 42 3a 42 4e 45 20 4b 45 52 52 0d |MP#&1B:BNE KERR.|
00001840 0f 50 16 4c 44 41 23 26 37 45 3a 4a 53 52 20 4f |.P.LDA#&7E:JSR O|
00001850 53 42 59 54 45 0d 0f 5a 09 2e 4b 45 52 52 0d 0f |SBYTE..Z..KERR..|
00001860 6e 2c 4c 44 58 23 30 3a 4c 44 59 23 32 32 3a 4a |n,LDX#0:LDY#22:J|
00001870 53 52 20 53 45 54 41 42 3a 4c 44 58 20 54 45 4d |SR SETAB:LDX TEM|
00001880 50 53 54 41 43 4b 3a 54 58 53 0d 0f 8c 0e 42 52 |PSTACK:TXS....BR|
00001890 4b 3a 45 51 55 42 39 39 0d 0f 96 14 45 51 55 53 |K:EQUB99....EQUS|
000018a0 22 45 4e 44 20 4f 46 20 44 49 53 22 0d 0f aa 07 |"END OF DIS"....|
000018b0 42 52 4b 0d 0f d2 19 2e 4f 55 54 50 55 54 20 53 |BRK.....OUTPUT S|
000018c0 54 58 26 37 30 3a 53 54 59 26 37 31 0d 0f dc 09 |TX&70:STY&71....|
000018d0 4c 44 59 23 30 0d 0f e6 27 2e 4c 4f 4f 50 20 4c |LDY#0...'.LOOP L|
000018e0 44 41 28 26 37 30 29 2c 59 3a 43 4d 50 23 26 46 |DA(&70),Y:CMP#&F|
000018f0 46 3a 42 45 51 20 4f 55 54 45 4e 44 0d 0f f0 1b |F:BEQ OUTEND....|
00001900 4a 53 52 20 4f 53 41 53 43 49 3a 49 4e 59 3a 42 |JSR OSASCI:INY:B|
00001910 4e 45 20 4c 4f 4f 50 0d 0f fa 0f 2e 4f 55 54 45 |NE LOOP.....OUTE|
00001920 4e 44 20 52 54 53 0d 10 22 25 2e 48 45 58 53 50 |ND RTS.."%.HEXSP|
00001930 20 4a 53 52 20 48 45 58 3a 4c 44 41 23 26 32 30 | JSR HEX:LDA#&20|
00001940 3a 4a 4d 50 20 4f 53 57 52 43 48 0d 10 36 08 2e |:JMP OSWRCH..6..|
00001950 48 45 58 0d 10 4a 1f 50 48 41 3a 4c 53 52 20 41 |HEX..J.PHA:LSR A|
00001960 3a 4c 53 52 20 41 3a 4c 53 52 20 41 3a 4c 53 52 |:LSR A:LSR A:LSR|
00001970 20 41 0d 10 54 17 4a 53 52 20 48 45 58 44 49 47 | A..T.JSR HEXDIG|
00001980 3a 50 4c 41 3a 80 23 26 46 0d 10 5e 23 2e 48 45 |:PLA:.#&F..^#.HE|
00001990 58 44 49 47 20 43 4d 50 23 26 41 3a 42 43 43 20 |XDIG CMP#&A:BCC |
000019a0 48 45 58 44 49 48 3a 41 44 43 23 36 0d 10 68 1e |HEXDIH:ADC#6..h.|
000019b0 2e 48 45 58 44 49 48 20 41 44 43 23 26 33 30 3a |.HEXDIH ADC#&30:|
000019c0 4a 4d 50 20 4f 53 57 52 43 48 0d ff |JMP OSWRCH..|
000019cc
DIS4220.m0
DIS4220.m1
DIS4220.m2
DIS4220.m4
DIS4220.m5
.
