SYNCHRONISING WORDS AND MUSIC
By Brian Boyde-Shaw
THE Electron's ability to play music whilst it is performing other
actions is very useful, but it can make it difficult to synchronise the
music with the appearance of words on the screen. Brian Boyde-Shaw gives
the low down on putting words to your music. Note that the demonstration
programs are stored in the U directory in the file "RHYME".
TRYING to print out the words of a song while it plays through your
Electron's speaker is no easy task. Because of the way in which sound
commands are handled by the Electron, there is a tendency for the words
and the music to become totally separated.
In the program in this article the sound is broken down into single
notes, and combined with text - words or part words - so that the text
is being written on the screen at the same time as you hear the corres-
ponding note.
The aim of the program is to play a simple nursery rhyme, one note at
at a time as the words are displayed on the screen.
The nursery rhyme we have chosen here is 'One, two, three, four,
five'. The methods used, however, can easily be adapted to any musical
piece.
Let's first look at a procedure to carry out this routine. As there
are twenty four notes in the rhyme, we can conveniently read in the word
or part word, the pitch of the note and the note's duration, from DATA
statements.
4000DATA one,88,8,two,88,8,three,80,4,four,72,4,five,72,8
4010DATA once,80,4,I,88,4,caught,92,4,a,100,4,fish,100,4,a,92,4,li
ve,92,8
4020DATA six,92,8,seven,92,8,eight,88,4,nine,80,4,ten,80,8
4030DATA then,72,4,I,68,4,let,60,4,it,68,4,go,80,4,a,72,4,gain,72,
8
We can then print the word in the centre of the screen, play the note,
and clear the screen. Then do it all again until we reach the end of the
rhyme.
1000DEF PROCwords
1010FOR R=1 TO 24
1020READ WORD$,PITCH,DUR
1030PRINT TAB(15,15)WORD$
1040SOUND 1,-15,PITCH,DUR
1050T%=TIME:REPEATUNTIL TIME>T%+5*DUR
1060CLS
1070NEXT R
1080ENDPROC
This procedure is designed to work in Mode 4, but could be adapted for
any other mode, providing that the parameters of the TAB statement (line
1030) are adjusted according to the appropriate line width.
Line 1050 will need some explanation. We need a delay loop to display
the word on the screen for the time that the note sounds. If we allowed
the program to continue without this delay loop, the screen would clear,
then the next word would be printed, and so on, and so on, until all the
words had been displayed, but the music would have hardly started. On
the Electron, sounds are placed in a queue ready for processing. This
takes up very little of the computer's time. Drawing and printing onto
the screen, however, does take a while, so the two can get out of step.
You can try this procedure without this line to see (and hear) this
effect.
We must delay the printing of the 'next' word until the note has
finished playing, and line 1050 does this. As the duration of the note
(DUR from the data statements) is in twentieths of a second - for the
SOUND statement - this delay must be converted to the units of hundredth
of a second - the units of TIME. Line 1050 makes the conversion and de-
lays the next word from appearing on the screen.
For the first note, for example, the SOUND statement requires, a
duration value of 8. The delay loop, however, requires a value of 40
hundredth of a second. Line 1050 makes the conversion with the formula:
DELAY=DUR*5
You could, of course, put both timing codes separately into the data
statements, but this would mean more effort typing in the music, and be
wasteful of memory into the bargain.
We now have a simple procedure to show how words and music can be
connected, but there are other more exciting ways of doing this. We can
allow the text to build up on the screen, word by word, until the com-
plete verse is displayed.
The same data statements can't be used because we need punctuation on
the screen now that we are to have the whole verse visible at once. When
we include punctuation in data we have to wrap the data in inverted
commas. Another snag is that we have to provide some means of telling
the computer to start a new line for each line of the verse and that
"alive" and "again" are two notes each but only one word. We need to
introduce a coding system into our data.
This article continued in the file V.+SYNCH2. First published ELBUG 2.1.
Reproduced EUG #54.
