There are, however, a few precautionary points which should be mentioned
about this technique of saving screen memory:

- As you probably realise, in four colour modes, the four colours you
can use can be changed from the default black, red, yellow and white by
using VDU 19 to change the palette. The colours in the palette are not
saved when this technique is used, and must be restored by repeating the
VDU 19 commands again. If you define the palette to, for example, black,
blue, cyan and white, and create a picture which looks good in this colour
scheme, you must remember that unless you define the palette to these four
colours before performing *LOAD to restore the picture, it may appear
rather odd when reloaded, as it will appear in black, red, yellow and
white - the default colour scheme.

- The exact reason why this happens is rather complicated, but if you allow
the cursor to go down off the bottom line of the screen, and allow the screen
to scroll up one line, this technique stops working until you perform a
MODE command, or clear the screen using CLS. Basically what happens is that
the computer does not physically move every line of text on the screen up
one line, but instead makes a note that every line in screen memory is stored
one line lower than it should be. When you reload from disk, this note is
lost, and the computer draws every line lower than it should be. Each time
that CLS or MODE is executed, screen memory is cleared and reinitiated, so
that every line is stored in memory where you would expect it to be. Simply
remember not to allow the screen to scroll between clearing it, and saving
the contents of screen memory to disc.

- The files created when you save the contents of screen memory to disk
are fairly large - so large, in fact, that you can often only fit around
15 such files onto each disk that you use (the exact number depends upon
what modes the images are in). Therefore this technique is not feasable
for a large number of images. Each screen in a game like Shipwrecked cannot
be stored in this way - if I had stored every screen of the game like this,
it would have required six floppy disks to store the data for the game!
This means that saved screens must be reserved for the purposes of title
screens only.

Earlier in the article, I mentioned several examples of screens which I have
done for EUG using saved screens using this technique. These included the
title screens for both Shipwrecked games, and also several EUG title
screens. You may have noticed that these were actually animated (see the
starfield in Jupiter 3 and the EUG 35 title). This was achieved by palette
switching as used in the previous article. If you look again at the
programming technique demonstration from this article (on EUG 36), and
select option 5, the same effect will appear on your screen. The same
principal was applied in both animated screens mentioned above - the only
difference is that in these title screens the pattern on screen which is
being palette switched is rather more complex. Shipwreck's title screen
(with the animated water scene) was also created in this way, except that
for this screen there was also a machine code program altering the contents
of screen memory as well, to enhance the effect.

So, we have a technique which allows us to store a small number of very
detailed screens on floppy, and recall then at very great speed. But what if
we want to use this method for a large number of screens? And what if we
want a situation like a game, where the user can move sprites on the screen
around. This can also be done by altering the values in screen memory
directly, but in a different way...

2. Editing screen memory

The basic idea is this: in any program, you only usually require a certain,
small number of little 'blocks' to make up a whole picture. In a word
processor, for example, you only need the letters of the alphabet to appear
on the screen. These letters are small blocks of graphics which appear on
your screen (called characters). Because only these 26 blocks are required,
the word processor does not need to store every letter as all of the pixels
which make it up (ie. as a bitmap), but just as a code for that particular
letter. When the word processor wants to display a letter on the screen, it
looks up the letter code, and then copies the graphic data for what that
letter looks like onto the screen. Therefore, the graphic data for what
colour all of the pixels should be for that particular letter (which might
take several bytes) need only be stored once, and that letter can be stored
in your script in just one byte, for the letter code. Thus, the memory
taken up by your script is reduced dramatically.

The same principal can be used in graphics. Look at two brick walls in
an arcade adventure such as Shipwrecked - can you see the difference
between them? If they are the same, surely you only need to store the
graphic data for a brick wall once, and then copy it onto the screen
whenever you want a brick wall. In Shipwrecked, for example, the graphic
data to describe what a brick wall looks like took 128 bytes. Yet every
time I wanted that brick wall (which was over a hundred times) I could
simply use one byte to say "Put a brick wall here!".

The easiest way to use this block idea, as you may already have realised,
is using user defined characters. You redefine the letters of the alphabet
as different pictures, and then use the standard BASIC PRINT command to
output these pictures to the screen, as and when they are required. But,
as we already realised in the last article, this only allows you to use
one colour in each character. Even so, this is a reasonable technique if
you don't mind the lack of colour. Many commercial games actually never
addressed this problem, and had graphics which lacked colour somewhat.
Even Dizzy (for those who have never heard of it, a great arcade adventure
of the 1980s, which caused quite a cult following at the time on the
Spectrum and C64, but never quite reached the Elk) did not have more than
one colour (other than black) per block. Different blocks were, however,
different colours - trees were green and the ground was red - but there
was never any overlap between the two colour areas.

There is, however, a way of creating an effect just like user defined
characters, but in full colour, and the principal is very similar to
that used before in saving screen memory. Basically, you design you small
block on the screen, using whatever technique you like to draw it, and then
save the small part of screen memory which contains your design. This time,
however, you will not save it to floppy disc, but to another area of memory.
You can then copy this block back to screen memory whenever and wherever you
want it. If you want it, say, in the fifth row down, and twelve characters
along, you can calculate where abouts this corresponds to in screen memory,
and copy the block to this location. As the block is stored in your
computer's RAM, as opposed to on floppy, this transfer can be done by
machine code at very great speed (taking only a small fraction of a second).
For those programmers who are not familiar with machine code, a module
is included with this tutorial allowing you to do this. The program code
for this module is actually taken directly from Shipwrecked.
