This is the second part of my "buildit" series, where part one brought you
he handy 16k Eprom Emulator.
This time,I present a "BBC Slower owner".
As we all know the BBC is very fast in all that it does - but some things
are just better in slow motion.
ADVANTAGES: Watch games in slow motion See how the OS does things slowly
No software required so requires no RAM or ROM sockets Does not hog the
user port
DISADVANTAGES: Loss of 1MHz bus socket Requires external power source he
circuit - the main circuit is based around the easy to use (and cheap!)
555 timer chip.Other oscillators, such as push/pull transistors could have
been used, but the 555 gives most control over the time high to time low
ratio.
The values chosen in the diagram (see attached) are only rough values,
they happened to be the parts that I had in my bits 'n' bobs drawer at the
time. In general any NPN transistor will do, only its switching properties
are required. Because of the way a 555 charges its timing capacitor, the
low time is always shorter than the high time.This is not what I wanted,
so the transistor also acts to invert the 555's output. It also means that
I present EITHER a low pulse OR a high impedance to the IRQ line and NEVER
a logic high. This is required as the IRQ line is wire-ORed to all the
other IRQ sources. The ratio of resistances should be kept approximately
the same otherwise he ratio of time high to time low will alter and the
effect will be spoilt.
I suggest trying a logarithmic potentiometer so that all the action
doesn't happen in the first two or three degrees of turning the knob!
How it works
With the pot fully rotated there is zero resistance between its pinouts.
So the output of the 555 is permanently LOW and so the NPN transistor is
off. Increasing the pot's resistance makes he 555 oscillate, and the high
period is proportional to the pot's resistance and so the transistor is on
for longer and longer periods at a time. Then on, the transistor spikes
nIRQ to round and causes an interrupt. As the interrupt comes from the
1MHz bus, the OS isn't interested in it and passes it to the paged ROMs,
who also ignore it and send it through IRQ2V whereupon it returns to the
OS which simply does an RTI instruction. All of this handling and polling
takes a finite amount of time, so if the IRQ occurs often enough then the
BBC doesn't have time to do its other tasks such as updating the screen,
or running the game that is in memory.
Originally, my design ran at higher frequency, spiking nIRQ low for
shorter times, but more often. This seemed to have little effect on the
BBC. Clearly it's just too fast!
Now the interrupts come long and frequently - giving little time for
foreground activities. Try this - two things of particular amusement are
changing to MODE0 and typing COLOUR 29 then CLS. You can watch exactly how
he OS sets all the 20k of locations to 255. Also, if you have it, play
Hopper at low speed - you can hear the individual notes in the envelopes
used to create the tune and sound effects.
Warning - do not use this with the "SNAPIT" ROM that I sent a few issues
back as it monitors the 1MHz bus interrupt line and starts the disk drive
up every time nIRQ goes low! If you feel the need to press BREAK with the
slower downer plugged in then make sure you turn the pot down to zero
resistance otherwise an IRQ occurs during reset. Nasty! let me know how
you get on...
Robert Sprowson.
�
