10REM ***************************
20REM Print Electron Memory Map
30REM by R.A.Dimond February 1993
40REM ***************************
50REM Page 2
60MODE6
70PRINTTAB(6,1)"Memory Map (Page 2)"
80PRINT'"Screen or Printer? (S/P)"
90REPEATUNTILINKEY-82 ORINKEY-56
100IFINKEY-82 MODE3:VDU14 ELSEMODE3:VDU15,2,1,27,1,54,1,27,1,116,1,1
110PRINTTAB(0);CHR$201;STRING$(68,CHR$205);CHR$187
120PROCprintct("ELECTRON MEMORY MAP - Page 2")
130PRINTCHR$199;STRING$(13,CHR$196);CHR$194;STRING$(54,CHR$196);CHR$182
140PROCprint(" Address","Use")
150PRINTCHR$199;STRING$(13,CHR$196);CHR$197;STRING$(54,CHR$196);CHR$182
160PROCprint(" &200/&201","USERV - *LINE and *CODE use this")
170PROCprint(" &202/&203","BRKV - the break vector, nothing to do with")
180PROCprint("","the Break key")
190PROCprint(" &204/&205","IRQ1V - the main inerrupt vector")
200PROCprint(" &206/&207","IRQ2V - not used on the Electron")
210PROCprint(" &208/&209","CLIV - used by the command line interpreter")
220PROCprint(" &20A/&20B","BYTEV - used by the osbyte (*FX) calls")
230PROCprint(" &20C/&20D","WORDV - used by the osword calls")
240PROCprint(" &20E/&20F","WRCHV - used by the oswrch (VDU) calls")
250PROCprint(" &210/&211","RDCHV - used when reading characters")
260PROCprint("","from input stream")
270PROCprint(" &212/&213","FILV - used when loading and saving")
280PROCprint(" &214/&215","ARGSV - read/write file arguments")
290PROCprint(" &216/&217","BGETV - read a byte from a file")
300PROCprint(" &218/&219","BPUTV - write one byte to a file")
310PROCprint(" &21A/&21B","GBPBV - get/put a block of bytes")
320PROCprint("","from/to a file")
330PROCprint(" &21C/&21D","FINDV - open or close a file")
340PROCprint(" &21E/&21F","FSCV - filing system control vector")
350PROCprint(" &220/&221","EVENTV - points to event handling routine")
360PROCprint(" &222/&223","UPTV - pointer to user print routine")
370PROCprint(" &224/&225","NETV - not used on the Electron")
380PROCprint(" &226/&227","VDUV - unrecognised VDU commands")
390PROCprint(" &228/&229","KEYV - used for reading the keyboard")
400PROCprint(" &22A/&22B","INSV - used for inserting characters")
410PROCprint("","into a buffer")
420PROCprint(" &22C/&22D","REMV - remove character from buffer")
430PROCprint(" &22E/&22F","CNPV - count/purge buffer vector")
440PROCprint(" &230/&231","INDV1 - not used")
450PROCprint(" &232/&233","INDV1 - not used")
460PROCprint(" &234/&235","INDV1 - not used")
470PROCprint(" &238/&239","Address of rom pointer table")
480PROCprint(" &23A/&23B","Address of rom table")
490PROCprint(" &23C/&23D","Address of key translation table")
500PROCprint(" &23E/&23F","Address of VDU variables")
510PROCprint(" &240","CFS timeout counter - frame flyback synchronised")
520PROCprint(" &241","Currently selected input buffer")
530PROCprint(" &246","Character definition explosion status")
540PROCprint(" &24A","Rom enabled before last BRK")
550PROCprint(" &24B","Number of Basic rom")
560PROCprint(" &24C","Current ADC channel number")
570PROCprint(" &24D","Maximum ADC channel number")
580PROCprint(" &251","Flashing colour countdown timer")
590PROCprint(" &252","Flashing colour mark period count")
600PROCprint(" &253","Flashing colour space period count")
610PROCprint(" &254","Keyboard auto-repeat delay set by *FX11")
620PROCprint(" &255","Keyboard auto-repeat rate set by *FX12")
630PROCprint(" &258","Break/Escape key options set by *FX200")
640PROCprint(" &25A","Caps Lk and Shift key state")
650PROCprint(" &262","Sound output supression flag set by *FX210")
660PROCprint(" &263","Bell (Control +G/VDU7) channel number")
670PROCprint(" &264","Bell amplitude/ENVELOPE number")
680PRINTCHR$200;STRING$(13,CHR$205);CHR$207;STRING$(54,CHR$205);CHR$188
690PRINT''
700PRINTCHR$201;STRING$(68,CHR$205);CHR$187
710PROCprintct("ELECTRON MEMORY MAP - Page 2 (contd)")
720PRINTCHR$199;STRING$(13,CHR$196);CHR$194;STRING$(54,CHR$196);CHR$182
730PROCprint(" Address","Use")
740PRINTCHR$199;STRING$(13,CHR$196);CHR$197;STRING$(54,CHR$196);CHR$182
750PROCprint(" &265","Bell frequency")
760PROCprint(" &266","Bell duration")
770PROCprint(" &26A","Number of items in VDU queue")
780PROCprint(" &26C","Current escape character")
790PROCprint(" &275","Escape key status set by *FX229")
800PROCprint(" &287","Break key interception flag - &4C=JMP")
810PROCprint(" &288/&289","Address to jump to when Break key is pressed")
820PROCprint(" &28C","Current language rom")
830PROCprint(" &28D","Last Break type - 0=soft, 1=power up, 2=hard")
840PROCprint(" &28F","Start up options set by *FX255")
850PROCprint(" &292-&296","System clock 1")
860PROCprint(" &297-&29B","System clock 2")
870PROCprint(" &2A0-&2AF","Rom table - complete list of currently")
880PROCprint("","active roms")
890PROCprint(" &2B1/&2B2","INKEY countdown timer")
900PROCprint(" &2B6-&2B9","Low bytes of last ADC conversions")
910PROCprint(" &2BA-&2BD","High bytes of last ADC conversions")
920PROCprint(" &2BE","Last ADC channel converted")
930PROCprint(" &2BF-&2C8","Event enable flags")
940PROCprint(" &2C9","Soft key expansion pointer")
950PROCprint(" &2CA","First auto-repeat count")
960PROCprint(" &2CB-&2CD","Keyboard workspace")
970PROCprint(" &2CE","Zero when envelope being processed")
980PROCprint(" &2CF-&2D7","Buffer busy flags")
990PROCprint(" &2D8-&2E0","Buffer start indices")
1000PROCprint(" &2E1-&2E9","Buffer end indices")
1010PROCprint(" &2EA/&2EB","Block size of current open cassette block")
1020PROCprint(" &2EC","Block flag of current open cassette block")
1030PROCprint(" &2ED","Last character of current open cassette block")
1040PROCprint(" &2EE/&2FF","Osfile control blocks")
1050PRINTCHR$200;STRING$(13,CHR$205);CHR$207;STRING$(54,CHR$205);CHR$188
1060PRINT
1070VDU3
1071PRINT''"PLEASE PRESS <F> FOR NEXT FILE, <M> FOR MAIN MENU"
1072REPEAT:UNTIL GET$="F" OR GET$="M"
1073IF GET$="F" THEN CHAIN"$.MM3"
1074IF GET$="M" THEN CHAIN"$.MENU"
1080END
1090DEFPROCprintct(t$):PRINTCHR$186;TAB(68/2-LENt$/2);t$;TAB(69);CHR$186:ENDPROC
1100DEFPROCprint(a$,b$):PRINTCHR$186;TAB(2)a$;TAB(14);CHR$179;TAB(16);b$;TAB(69);CHR$186:ENDPROC
!� ***************************
