[ BASIC ROM ROUTINES ARTICLE - CONTINUATION ]
6. Routine: Convert number in IWA to ASCII decimal or hexadecimal
Basic 2: &9EFF
Basic 4: &A138
Entry: IWA should contain number to be converted
location &15 = &FF for hexadecimal ASCII
or &15 = 0 for decimal ASCII
The previous routine only allowed 16-bit numbers (numbers in the range
0-65535) to be printed. This routine helps you print 32-bit numbers in
decimal or hex. When we speak of "hexadecimal" or "decimal ASCII", it
means that a string containing ASCII codes is made for the given number.
For example, the four ASCII decimal codes for &9EFF are 57, 69, 70, and
70 (ignoring the ampersand which Basic doesn't print anyway). Basic puts
these ASCII codes into the String Work Area, or SWA for short. We can
then use another routine to print out the contents of the SWA:
7. Routine: Print the SWA
Basic 2: &8E12
Basic 4: &921B
Entry: location &30 must contain the length of the string
the SWA must contain the string
location &A must = 0.
Ex.: LDX #&50 \copy integer at &50-3
JSR &AF56 \to SWA
LDA #&FF:STA &15 \number to be in hex
JSR &9EFF \convert IWA to ASCII codes
LDA #0:STA &A
JMP &8E12 \and print the number
8. Routine: Random number generator
Basic 2: &AF51
Basic 4: &AA7B
No entry requirements. On exit, the IWA contains a 4-byte random
integer.
Ex.: JSR &AF51
LDA &2A
JSR alien
I find this Rom routine extremely useful for getting random numbers in
games, and it's the only decent way of getting fairly unpredictable
numbers in machine code.
Conclusion
IF you use any of the above routines, don't forget to use the correct
address for your version of Basic. Now that you've seen what the Basic
Rom can do, hopefully you'll want to start exploring other parts. If you
find anything useful, do write in and let us know!
Christopher Dewhurst
24 September, 2000
EUG #55
