To use the sprites in your program, you must use the program "UDCMod" on
this issue of EUG as a starting point. This file is in the "P" directory
of this EUG disc. The program consists of a couple of lines at the
beginning which set up your computer to use the module, by entering MODE
2, and assembling the machine code module into memory. Then there is the
assembly language of the module itself which comes after the body of your
program. Your program should be inserted between the line:

REM Put your program code here!

and the line:

END

Apart from adding your program code, there is one other alteration which
you need to make, and that is to insert the filename of sprite file I
mentioned earlier into line 1020. You should replace the string <Filename>
in quotes at the end of line 1020 with the relavant filename. For the
moment use 'B+B' - this will enable you to use the sprites used in the Bat
and Ball demonstration.

Whenever you want to display a sprite in your program, you need to set a
number of variables and then call the module. These variables must be set
with integer values in the ranges given:

?char - The number of the sprite you want to draw (0-31)

?xc - The x position of the sprite in characters (0-19)  } Use just like
?yc - The y position of the sprite in characters (0-31)  }  TAB(?xc,?yc)

?xoff - The offset of the x position from the left edge of the character
        position given, in pixels (0-3). This enables you to smoothly
        move your sprite from one character to another.

?yoff - The offset of the y position from the top edge of the character
        position given (0-7).

Having set these four variables, execute CALLdisplay to display your
sprite.

As an example we can try this now. Load up a copy of 'UDCMod' and replace
the filename in line 1020 with 'B+B' as described earlier. Now enter the
following line:

30 ?char=2:?xc=1:?yc=1:?xoff=2:?yoff=4:CALLdisplay

RUN the program, and a block will appear at the top left of the screen.
The top left of the block is in character square (1,1), and with offsets
of half a character both horizontally and vertically.

The SetPaint(col) function
--------------------------

You may remember that a couple of issues back I mentioned how the GCOL
command in BASIC can be used to set how graphics are drawn onto the
screen. For example, the pixels could be set to the colours defined in
your sprites regardless of their previous state. They could also have the
light from the pixels mixed with the light from your sprite. This would
mean, for example, that if a green sprite were plotted onto a blue
background, the result would be cyan. This effect can also be achieved
using this graphics module, using the SetPaint procedure:

PROCSetPaint(x)

Where: x = Parameter giving the type of painting you want to do.

0: Your sprite will replace any previous colours on the screen.
1: Your sprite will be used as a filter put over the light already on
   the screen.
2: Your sprite will be mixed with the light already on the screen.
3: EOR (described later)

The default setting is 0. The other paint modes obviously have
applications if you want to be able to see several sprites on top of each
other by mixing the light from them, or if you only want to see a sprite
when it is in a certain area of the screen. But the EOR mode also has
another very important use:

Suppose you want to create a moving sprite. Say, for example, the ball in
the Bat & Ball demonstration. If you just draw the sprite over and over
again slowly moving across the screen you will get a trail of all of the
old displays of the sprite behind your latest display. This is because
these are not being removed before the new image is being drawn. Let's say
our sprite has moved left from square 10 to square 9. Initially you would
have drawn the sprite in square 10. Then when the sprite moves into square
9 you would draw it again in its new position in square 9. The result is
that your sprite is now visible in both squares 9 and 10 - you need to
remove the image from square 10.

You could do this by allocating one of your program's 32 sprites as a
black square. But what happens if your sprite is in front of a complex
backdrop? If you start putting black blocks in front of that, you'll get
in a mess. The problem is illustrated by the 'Walking' demonstration which
is available at the end of this tutorial.
