10 REM ***COPYRIGHT PILOT ONE LTD., 1984***
20 MODE 7
30 ARR$=CHR$136+CHR$91+CHR$137:NOA$=" "
40 *FX229,1
50 *KEY10 O.|M
60 *FX4,1
70 VDU 23,1,0;0;0;0;
80 DIM drive_index%(1,19),no_of_steps%(19)
90 DIM ctrbl% 4,buffer% 4
100 DIM dir$(2),code$(2)
110 dir$(0)="FORWARDS ":dir$(1)="BACKWARDS":dir$(2)="OFF "
120 code$(0)="01":code$(1)="10":code$(2)="00"
130 n%=10
140 PROCset_up_port
150 s%=0
160 REPEAT
170 PROCmenu
180 V=0:H=0:PROCfind(28,4,1,5,0,2)
190 IF V=0 AND s%>0 PROCdisplay:V=0
200 IF V=1 PROCclear_route:s%=0:PROCmake_route:V=1
210 IF V=2 AND s%>0 PROCedit_route:V=2
220 IF V=3 AND s%>0 PROCdrive_route:V=3
230 IF V=4 MODE 7:PROCend
240 UNTILFALSE
250 DEF PROCend
260 *FX229,0
270 *FX4,0
280 VDU 23,1,1;0;0;0;
290 END
300 DEF PROCclear_route
310 FOR I%=0 TO 19:drive_index%(0,I%)=0:drive_index%(1,I%)=0:no_of_steps%(I%)=0:NEXTI%
320 ENDPROC
330 DEF PROCmake_route
340 REPEAT
350 REPEAT
360 PROCget(s%)
370 PRINTTAB(0,23)"�RETURN TO CONFIRM, ESCAPE TO REENTER";:REPEAT:dummy=GET:UNTILdummy=13 OR dummy=27
380 UNTIL dummy=13
390 IF s%<=19 PRINTTAB(0,23)"� ANOTHER STEP? (Y/N) ";:REPEAT:dummy=GET:dummy=dummy AND 223:UNTILdummy=ASC"Y" OR dummy=ASC"N"
400 IF s%<=19 AND dummy=ASC"Y" s%=s%+1
410 UNTIL s%>19 OR dummy=ASC"N"
420 IF s%<=19 s%=s%+1
430 ENDPROC
440 DEF PROCget(stage%)
450 CLS:PROCmessage("STAGE NO."+STR$(stage%+1),"�","�"):PRINT''''
460 PRINTTAB(7);"LEFT MOTOR? ";:FOR I%=0TO2:PRINTTAB(22,I%+7)dir$(I%):NEXT
470 PROCinstruct
480 V=0:H=0:PROCfind(33,7,1,3,0,1)
490 drive_index%(0,stage%)=V
500 PRINT TAB(21,7)"�";dir$(V)TAB(22,8)SPC9TAB(22,9)SPC9
510 PRINT'''TAB(7);"RIGHT MOTOR? ";:FOR I%=0TO2:PRINTTAB(22,I%+13)dir$(I%):NEXT
520 V=0:H=0:PROCfind(33,13,1,3,0,1)
530 drive_index%(1,stage%)=V
540 PRINT TAB(21,13)"�";dir$(V)TAB(22,14)SPC9TAB(22,15)SPC9
550 PROCinstruct2
560 REPEAT:PRINTTAB(7,19)"STEPS? (1-100)� ";:VDU 8,8,8,8,8:PROCinput(48,57,3)
570 VDU7
580 IF LENut$>0 no_of_steps%=EVAL(ut$) ELSE no_of_steps%=0
590 VDU 11:UNTILno_of_steps%>0 AND no_of_steps%<=100
600 no_of_steps%(stage%)=no_of_steps%
610 ENDPROC
620 DEFPROCinstruct2
630 PRINT TAB(0,23)SPC7;"�ENTER AND PRESS RETURN"SPC9
640 ENDPROC
650 DEFPROCfind(X,Y,M,N,W,D)
660 REPEAT
670 REPEAT
680 PRINTTAB(X+(H*W),Y+(V*D));ARR$
690 A=GET
700 UNTIL(A>135ANDA<140)ORA=13
710 PRINTTAB(X+(H*W),Y+(V*D));NOA$
720 IFA=138ANDV<(N-1)THENV=V+1ELSEIFA=139ANDV>0V=V-1
730 IFA=137ANDH<(M-1)THENH=H+1ELSEIFA=136ANDH>0H=H-1
740 UNTILA=13:VDU7
750 ENDPROC
760 DEFPROCinput(minchar%,maxchar%,maxlen%)
770 VDU 23,1,1;0;0;0;
780 le%=0
790 ut$=""
800 REPEAT
810 REPEAT:A=GET:IF (A<minchar% OR A>maxchar%) AND A<>13 AND A<>127 VDU 7
820 UNTIL (A>=minchar% AND A<=maxchar%) OR A=13 OR A=127
830 IF (A=127 AND le%>0) VDU 127 ELSE IF A<>13 AND le%<maxlen% AND A<>127 PRINTCHR$(A);
840 IF (A<>13 AND le%=maxlen% AND A<>127) OR (A=127 AND le%=0) VDU 7
850 IF A=127 AND le%>0 ut$=LEFT$(ut$,le%-1):le%=le%-1 ELSE IF A<>13 AND A<>127 AND le%<maxlen% ut$=ut$+CHR$A:le%=le%+1
860 UNTIL A=13
870 VDU 23,1,0;0;0;0;
880 ENDPROC
890 DEFPROCmessage(M$,fo$,ba$)
900 FORI%=0TO1
910 IF ba$="":PRINT; ELSE PRINTba$;CHR$157;
920 PRINTfo$;CHR$141TAB(INT(40-LEN(M$))/2);M$
930 NEXT
940 ENDPROC
950 DEF PROCmenu
960 CLS:PROCmessage("PILOT ONE - INTCAR","�","�")
970 PRINTTAB(10,4)"DISPLAY SEQUENCE"TAB(10,6)"CREATE SEQUENCE"TAB(10,8)"EDIT SEQUENCE"TAB(10,10)"RUN SEQUENCE"TAB(9,12)"�EXIT FROM PROGRAM�"
980 PROCinstruct
990 ENDPROC
1000 DEFPROCinstruct
1010 PRINTTAB(2,23)CHR$131"USE ARROW KEYS AND RETURN TO SELECT"
1020 ENDPROC
1030 DEF PROCdrive_route
1040 FOR stage%=0 TO s%-1
1050 CLS:PROCmessage("STAGE NO."+STR$(stage%+1),"�","�")
1060 PRINT'''
1070 PROCmessage("LEFT MOTOR - "+dir$(drive_index%(0,stage%)),"�","")
1080 PRINT'''
1090 PROCmessage("RIGHT MOTOR - "+dir$(drive_index%(1,stage%)),"�","")
1100 PRINT'''
1110 PROCmessage(STR$(no_of_steps%(stage%))+" STEPS","�","")
1120 TIME=0:PROCmultiturn("ON",code$(drive_index%(1,stage%))+code$(drive_index%(0,stage%)))
1130 REPEAT:UNTILTIME>no_of_steps%(stage%)*n%
1140 PROCmultiturn("OFF","1111")
1150 NEXT stage%
1160 PRINTTAB(6,23)"�PRESS ANY KEY TO CONTINUE":dummy=GET
1170 ENDPROC
1180 DEF PROCedit_route
1190 REPEAT
1200 PROCedit_menu
1210 V=0:H=0:PROCfind(30,4,1,6,0,2)
1220 IF V=0 AND s%>0 PROCdisplay:V=0
1230 IF V=1 PROCdelete(FNwhich_stage):V=1
1240 IF V=2 AND s%<20 PROCinsert(FNwhich_stage):V=2
1250 IF V=3 PROCget(FNwhich_stage-1):V=3
1260 IF V=4 AND s%<20 PROCmake_route:V=4
1270 UNTILV=5 OR s%=0
1280 ENDPROC
1290 DEF PROCedit_menu
1300 CLS:PROCmessage("INTCAR - EDIT MENU","�","�")
1310 PRINTTAB(10,4)"DISPLAY SEQUENCE"TAB(10,6)"DELETE STAGE"TAB(10,8)"INSERT STAGE"TAB(10,10)"EDIT STAGE"TAB(10,12)"ADD TO SEQUENCE"TAB(9,14)"�RETURN TO MAIN MENU�"
1320 PROCinstruct
1330 ENDPROC
1340 DEF PROCdisplay
1350 CLS:PROCmessage("INTCAR - SEQUENCE DISPLAY","�","�")
1360 PRINT TAB(2,3)"�LEFT MOTOR"TAB(18,3)"RIGHT MOTOR"TAB(33,3)"STEPS"
1370 PRINTTAB(8,23)"�PRESS SHIFT TO SCROLL"
1380 VDU 28,0,21,39,5,14
1390 FOR I%=0 TO s%-1
1400 PRINTSPC(2-LEN(STR$(I%+1)))STR$(I%+1);
1410 PRINTTAB(4)dir$(drive_index%(0,I%))TAB(19)dir$(drive_index%(1,I%));
1420 PRINTTAB(34)SPC(3-LEN(STR$(no_of_steps%(I%))))STR$(no_of_steps%(I%))'
1430 NEXT
1440 VDU 26,15:PRINTTAB(6,23)"�PRESS ANY KEY TO CONTINUE"
1450 *FX21,0
1460 A=GET
1470 VDU7
1480 ENDPROC
1490 DEF FNwhich_stage
1500 IF s%=1 THEN =1
1510 CLS:PROCmessage("SELECT STAGE","�","�")
1520 REPEAT
1530 PROCinstruct2
1540 PRINTTAB(8,10)"�STAGE NUMBER (1-"STR$s%")... ";:VDU8,8
1550 PROCinput(48,57,2)
1560 IF LENut$>0 stage%=EVAL(ut$) ELSE stage%=0
1570 VDU 11:UNTILstage%>0 AND stage%<=s%
1580 =stage%
1590 DEF PROCdelete(stage%)
1600 IF stage%=20 s%=19:ENDPROC
1610 FOR I%=stage% TO s%-1
1620 drive_index%(0,I%-1)=drive_index%(0,I%):drive_index%(1,I%-1)=drive_index%(1,I%):no_of_steps%(I%-1)=no_of_steps%(I%)
1630 NEXT
1640 s%=s%-1
1650 ENDPROC
1660 DEF PROCinsert(stage%)
1670 FOR I%=s% TO stage% STEP -1
1680 drive_index%(0,I%)=drive_index%(0,I%-1):drive_index%(1,I%)=drive_index%(1,I%-1):no_of_steps%(I%)=no_of_steps%(I%-1)
1690 NEXT
1700 REPEAT
1710 PROCget(stage%-1)
1720 PRINTTAB(0,23)"�RETURN TO CONFIRM, ESCAPE TO REENTER";:REPEAT:dummy=GET:UNTILdummy=13 OR dummy=27
1730 UNTILdummy=13
1740 s%=s%+1
1750 ENDPROC
10000 REM ***USES OSBYTE/*FX150 TO EXAMINE VIA REGISTER. REQUIRES OFFSET OF REGISTER IN PAGE &FE AS PARAMETER.***
10010 DEF FNpeek(offset)
10020 LOCAL value
10030 A%=150:X%=offset:value=(USR(&FFF4) AND &FF0000) DIV &10000
10040 =value
11000 REM ***USES OSBYTE/*FX151 TO WRITE A VALUE TO A VIA REGISTER. REQUIRES OFFSET OF REGISTER IN PAGE &FE, AND VALUE TO BE WRITTEN AS PARAMETERS.***
11010 DEF PROCpoke(offset,value)
11020 A%=151:X%=offset:Y%=value:CALL &FFF4
11030 ENDPROC
12000 REM ***EXAMINES THE CURRENT STATE OF THE RELAY SPECIFIED AND SWAPS IT OVER.***
12010 DEF PROCtoggle(linenumber)
12020 IF (linenumber>3 OR linenumber<0) THEN *FX125
12030 LOCAL bitvalue,oldvalue,newvalue
12040 bitvalue=2^linenumber
12050 oldvalue=FNpeek(&60)
12060 newvalue=oldvalue EOR bitvalue
12070 PROCpoke(&60,newvalue)
12080 ENDPROC
13000 REM ***TURNS ON OR OFF A SPECIFIED RELAY. REQUIRES ACTION TO BE TAKEN ie. "ON" OR "OFF", AND RELAY NUMBER AS PARAMETERS***
13010 DEF PROCturn(onORoff$,linenumber)
13020 IF NOT(onORoff$="ON" OR onORoff$="OFF") THEN *FX125
13030 IF (linenumber>3 OR linenumber<0) THEN *FX125
13040 LOCAL bitvalue,oldvalue,newvalue
13050 bitvalue=2^linenumber
13060 oldvalue=FNpeek(&60)
13070 IF onORoff$="ON" THEN newvalue=oldvalue OR bitvalue ELSE newvalue=oldvalue AND (255-bitvalue)
13080 PROCpoke(&60,newvalue)
13090 ENDPROC
14000 REM ***TESTS THE CURRENT STATE OF THE SPECIFIED INPUT (4-7) AND RETURNS THE VALUE "ON" OR "OFF".***
14010 DEF FNtest(linenumber)
14020 IF (linenumber>7 OR linenumber<4) THEN *FX125
14030 LOCAL bitvalue
14040 bitvalue=2^linenumber
14050 result=((FNpeek(&60) AND bitvalue)=bitvalue)
14060 IF result THEN ="ON" ELSE ="OFF"
15000 REM ***TESTS THE STATE OF THE SPECIFIED RELAYS IN TURN AND SWAPS THEM. REQUIRES A STRING REPRESENTING THE RELAYS TO BE TOGGLED AS A BINARY PATTERN.***
15010 DEF PROCmultitoggle(pattern$)
15020 LOCAL L,L$,mask%,oldvalue,newvalue
15030 IF LEN(pattern$)<>4 THEN *FX125
15040 FOR L=1 TO 4:L$=MID$(pattern$,L,1):IF NOT(L$="1" OR L$="0") THEN *FX125
15050 NEXT
15060 mask%=0:FOR L=1 TO 4:IF (MID$(pattern$,L,1)="1") THEN mask%=mask%+2^(4-L)
15070 NEXT
15080 oldvalue=FNpeek(&60):newvalue=oldvalue EOR mask%
15090 PROCpoke(&60,newvalue)
15100 ENDPROC
16000 REM ***TURNS ON OR OFF THE SPECIFIED GROUP OF RELAYS. REQUIRES TWO PARAMETERS:-(i)THE ACTION TO BE TAKEN ie."ON" OR "OFF", (ii)A STRING REPRESENTING THE RELAYS TO BE SWITCHED AS A BINARY PATTERN.***
16010 DEF PROCmultiturn(onORoff$,pattern$)
16020 LOCAL L,L$,mask%,oldvalue,newvalue
16030 IF LEN(pattern$)<>4 OR NOT(onORoff$="ON" OR onORoff$="OFF") THEN *FX125
16040 FOR L=1 TO 4:L$=MID$(pattern$,L,1):IF NOT(L$="1" OR L$="0") THEN *FX125
16050 NEXT
16060 mask%=0:FOR L=1 TO 4:IF (MID$(pattern$,L,1)="1") THEN mask%=mask%+2^(4-L)
16070 NEXT
16080 oldvalue=FNpeek(&60):IF onORoff$="ON" THEN newvalue=oldvalue OR mask% ELSE newvalue=oldvalue AND (255-mask%)
16090 PROCpoke(&60,newvalue)
16100 ENDPROC
17000 REM ***TESTS THE SPECIFIED GROUP OF INPUTS AND RETURNS THE VALUE "ON" IF ALL OF THEM ARE ON AND "OFF" IF ANY ONE OF THEM IS OFF. REQUIRES A STRING REPRESENTING THE INPUTS TO BE TESTED AS A BINARY PATTERN.***
17010 DEF FNmultitest(pattern$)
17020 LOCAL L,L$,testmask%,result
17030 IF LEN(pattern$)<>4 THEN *FX125
17040 FOR L=1 TO 4:L$=MID$(pattern$,L,1):IF NOT(L$="1" OR L$="0") THEN *FX125
17050 NEXT
17060 testmask%=0:FOR L=1 TO 4:IF (MID$(pattern$,L,1)="1") THEN testmask%=testmask%+2^(8-L)
17070 NEXT
17080 result=((FNpeek(&60) AND testmask%)=testmask%)
17090 IF result THEN ="ON" ELSE ="OFF"
18000 REM ***INITIALISES USER PORT AS FOUR OUTPUTS ON PB0-3 AND FOUR INPUTS ON PB4-7. TURNS ALL OUTPUTS OFF.***
18010 DEF PROCset_up_port
18020 PROCpoke(&62,15)
18030 PROCpoke(&60,0)
18040 ENDPROC
+ � ***COPYRIGHT PILOT ONE LTD., 1984***
� 7
$ ARR$=�136+�91+�137:NOA$=" "
(
*FX229,1
2 *KEY10 O.|M
< *FX4,1
F � 23,1,0;0;0;0;
P* � drive_index%(1,19),no_of_steps%(19)
Z � ctrbl% 4,buffer% 4
d � dir$(2),code$(2)
n@ dir$(0)="FORWARDS ":dir$(1)="BACKWARDS":dir$(2)="OFF "
x. code$(0)="01":code$(1)="10":code$(2)="00"
�
n%=10
� �set_up_port
� s%=0
� �
�
�menu
�" V=0:H=0:�find(28,4,1,5,0,2)
� � V=0 � s%>0 �display:V=0
�, � V=1 �clear_route:s%=0:�make_route:V=1
�! � V=2 � s%>0 �edit_route:V=2
�# � V=3 � s%>0 �drive_route:V=3
� � V=4 � 7:�end
� ��
� � �end
*FX229,0
*FX4,0
� 23,1,1;0;0;0;
" �
, � �clear_route
6R � I%=0 � 19:drive_index%(0,I%)=0:drive_index%(1,I%)=0:no_of_steps%(I%)=0:�I%
@ �
J � �make_route
T �
^ �
h �get(s%)
rT �0,23)"�RETURN TO CONFIRM, ESCAPE TO REENTER";:�:dummy=�:�dummy=13 � dummy=27
| � dummy=13
�s � s%<=19 �0,23)"� ANOTHER STEP? (Y/N) ";:�:dummy=�:dummy=dummy � 223:�dummy=�"Y" � dummy=�"N"
�# � s%<=19 � dummy=�"Y" s%=s%+1
� � s%>19 � dummy=�"N"
� � s%<=19 s%=s%+1
� �
� � �get(stage%)
�7 �:�message("STAGE NO."+�(stage%+1),"�","�"):�''''
�9 �7);"LEFT MOTOR? ";:� I%=0�2:�22,I%+7)dir$(I%):�
� �instruct
� V=0:H=0:�find(33,7,1,3,0,1)
� drive_index%(0,stage%)=V
�( � �21,7)"�";dir$(V)�22,8)�9�22,9)�9
�? �'''�7);"RIGHT MOTOR? ";:� I%=0�2:�22,I%+13)dir$(I%):�
! V=0:H=0:�find(33,13,1,3,0,1)
drive_index%(1,stage%)=V
+ � �21,13)"�";dir$(V)�22,14)�9�22,15)�9
& �instruct2
0A �:�7,19)"STEPS? (1-100)� ";:� 8,8,8,8,8:�input(48,57,3)
: �7
D2 � �ut$>0 no_of_steps%=�(ut$) � no_of_steps%=0
N/ � 11:�no_of_steps%>0 � no_of_steps%<=100
X& no_of_steps%(stage%)=no_of_steps%
b �
l ��instruct2
v+ � �0,23)�7;"�ENTER AND PRESS RETURN"�9
� �
� ��find(X,Y,M,N,W,D)
� �
� �
� �X+(H*W),Y+(V*D));ARR$
� A=�
� �(A>135�A<140)�A=13
� �X+(H*W),Y+(V*D));NOA$
�* �A=138�V<(N-1)�V=V+1��A=139�V>0V=V-1
�) �A=137�H<(M-1)�H=H+1��A=136�H>0H=H-1
�
�A=13:�7
� �
�' ��input(minchar%,maxchar%,maxlen%)
� 23,1,1;0;0;0;
le%=0
ut$=""
�
*; �:A=�:� (A<minchar% � A>maxchar%) � A<>13 � A<>127 � 7
41 � (A>=minchar% � A<=maxchar%) � A=13 � A=127
>D � (A=127 � le%>0) � 127 � � A<>13 � le%<maxlen% � A<>127 �(A);
H; � (A<>13 � le%=maxlen% � A<>127) � (A=127 � le%=0) � 7
Rd � A=127 � le%>0 ut$=�ut$,le%-1):le%=le%-1 � � A<>13 � A<>127 � le%<maxlen% ut$=ut$+�A:le%=le%+1
\ � A=13
f � 23,1,0;0;0;0;
p �
z ��message(M$,fo$,ba$)
� �I%=0�1
� � ba$="":�; � �ba$;�157;
� �fo$;�141��(40-�(M$))/2);M$
� �
� �
� � �menu
�. �:�message("PILOT ONE - INTCAR","�","�")
�| �10,4)"DISPLAY SEQUENCE"�10,6)"CREATE SEQUENCE"�10,8)"EDIT SEQUENCE"�10,10)"RUN SEQUENCE"�9,12)"�EXIT FROM PROGRAM�"
� �instruct
� �
� ��instruct
�6 �2,23)�131"USE ARROW KEYS AND RETURN TO SELECT"
� �
� �drive_route
� stage%=0 � s%-1
0 �:�message("STAGE NO."+�(stage%+1),"�","�")
$ �'''
.C �message("LEFT MOTOR - "+dir$(drive_index%(0,stage%)),"�","")
8 �'''
BD �message("RIGHT MOTOR - "+dir$(drive_index%(1,stage%)),"�","")
L �'''
V6 �message(�(no_of_steps%(stage%))+" STEPS","�","")
`U �=0:�multiturn("ON",code$(drive_index%(1,stage%))+code$(drive_index%(0,stage%)))
j# �:��>no_of_steps%(stage%)*n%
t �multiturn("OFF","1111")
~
� stage%
�0 �6,23)"�PRESS ANY KEY TO CONTINUE":dummy=�
� �
� � �edit_route
� �
� �edit_menu
� V=0:H=0:�find(30,4,1,6,0,2)
� � V=0 � s%>0 �display:V=0
�$ � V=1 �delete(�which_stage):V=1
�- � V=2 � s%<20 �insert(�which_stage):V=2
�# � V=3 �get(�which_stage-1):V=3
�" � V=4 � s%<20 �make_route:V=4
� �V=5 � s%=0
�
� �edit_menu
. �:�message("INTCAR - EDIT MENU","�","�")
� �10,4)"DISPLAY SEQUENCE"�10,6)"DELETE STAGE"�10,8)"INSERT STAGE"�10,10)"EDIT STAGE"�10,12)"ADD TO SEQUENCE"�9,14)"�RETURN TO MAIN MENU�"
( �instruct
2 �
< � �display
F4 �:�message("INTCAR - SEQUENCE DISPLAY","�","�")
P: � �2,3)"�LEFT MOTOR"�18,3)"RIGHT MOTOR"�33,3)"STEPS"
Z% �8,23)"�PRESS SHIFT TO SCROLL"
d � 28,0,21,39,5,14
n � I%=0 � s%-1
x �(2-�(�(I%+1)))�(I%+1);
�> �4)dir$(drive_index%(0,I%))�19)dir$(drive_index%(1,I%));
�9 �34)�(3-�(�(no_of_steps%(I%))))�(no_of_steps%(I%))'
� �
�2 � 26,15:�6,23)"�PRESS ANY KEY TO CONTINUE"
� *FX21,0
� A=�
� �7
� �
� � �which_stage
� � s%=1 � =1
�' �:�message("SELECT STAGE","�","�")
� �
� �instruct2
0 �8,10)"�STAGE NUMBER (1-"�s%")... ";:�8,8
�input(48,57,2)
( � �ut$>0 stage%=�(ut$) � stage%=0
" � 11:�stage%>0 � stage%<=s%
, =stage%
6 � �delete(stage%)
@ � stage%=20 s%=19:�
J � I%=stage% � s%-1
Tx drive_index%(0,I%-1)=drive_index%(0,I%):drive_index%(1,I%-1)=drive_index%(1,I%):no_of_steps%(I%-1)=no_of_steps%(I%)
^ �
h s%=s%-1
r �
| � �insert(stage%)
� � I%=s% � stage% � -1
�x drive_index%(0,I%)=drive_index%(0,I%-1):drive_index%(1,I%)=drive_index%(1,I%-1):no_of_steps%(I%)=no_of_steps%(I%-1)
� �
� �
� �get(stage%-1)
�S �0,23)"�RETURN TO CONFIRM, ESCAPE TO REENTER";:�:dummy=�:�dummy=13 � dummy=27
� �dummy=13
� s%=s%+1
� �
'n � ***USES OSBYTE/*FX150 TO EXAMINE VIA REGISTER. REQUIRES OFFSET OF REGISTER IN PAGE &FE AS PARAMETER.***
' � �peek(offset)
'$ � value
'.: A%=150:X%=offset:value=(�(&FFF4) � &FF0000) � &10000
'8 =value
*�� � ***USES OSBYTE/*FX151 TO WRITE A VALUE TO A VIA REGISTER. REQUIRES OFFSET OF REGISTER IN PAGE &FE, AND VALUE TO BE WRITTEN AS PARAMETERS.***
+ � �poke(offset,value)
+ ' A%=151:X%=offset:Y%=value:� &FFF4
+ �
.�Q � ***EXAMINES THE CURRENT STATE OF THE RELAY SPECIFIED AND SWAPS IT OVER.***
.� � �toggle(linenumber)
.�. � (linenumber>3 � linenumber<0) � *FX125
.�! � bitvalue,oldvalue,newvalue
/ bitvalue=2^linenumber
/ oldvalue=�peek(&60)
/ ! newvalue=oldvalue � bitvalue
/& �poke(&60,newvalue)
/0 �
2�~ � ***TURNS ON OR OFF A SPECIFIED RELAY. REQUIRES ACTION TO BE TAKEN ie. "ON" OR "OFF", AND RELAY NUMBER AS PARAMETERS***
2�! � �turn(onORoff$,linenumber)
2�2 � �(onORoff$="ON" � onORoff$="OFF") � *FX125
2�. � (linenumber>3 � linenumber<0) � *FX125
2�! � bitvalue,oldvalue,newvalue
2� bitvalue=2^linenumber
3 oldvalue=�peek(&60)
3X � onORoff$="ON" � newvalue=oldvalue � bitvalue � newvalue=oldvalue � (255-bitvalue)
3 �poke(&60,newvalue)
3" �
6�f � ***TESTS THE CURRENT STATE OF THE SPECIFIED INPUT (4-7) AND RETURNS THE VALUE "ON" OR "OFF".***
6� � �test(linenumber)
6�/ � (linenumber>7 � linenumber<4) � *FX125
6� � bitvalue
6� bitvalue=2^linenumber
6�. result=((�peek(&60) � bitvalue)=bitvalue)
6� � result � ="ON" � ="OFF"
:�� � ***TESTS THE STATE OF THE SPECIFIED RELAYS IN TURN AND SWAPS THEM. REQUIRES A STRING REPRESENTING THE RELAYS TO BE TOGGLED AS A BINARY PATTERN.***
:� � �multitoggle(pattern$)
:�# � L,L$,mask%,oldvalue,newvalue
:� � �(pattern$)<>4 � *FX125
:�> � L=1 � 4:L$=�pattern$,L,1):� �(L$="1" � L$="0") � *FX125
:� �
:�E mask%=0:� L=1 � 4:� (�pattern$,L,1)="1") � mask%=mask%+2^(4-L)
:� �
:�2 oldvalue=�peek(&60):newvalue=oldvalue � mask%
:� �poke(&60,newvalue)
:� �
>�� � ***TURNS ON OR OFF THE SPECIFIED GROUP OF RELAYS. REQUIRES TWO PARAMETERS:-(i)THE ACTION TO BE TAKEN ie."ON" OR "OFF", (ii)A STRING REPRESENTING THE RELAYS TO BE SWITCHED AS A BINARY PATTERN.***
>�$ � �multiturn(onORoff$,pattern$)
>�# � L,L$,mask%,oldvalue,newvalue
>�B � �(pattern$)<>4 � �(onORoff$="ON" � onORoff$="OFF") � *FX125
>�> � L=1 � 4:L$=�pattern$,L,1):� �(L$="1" � L$="0") � *FX125
>� �
>�E mask%=0:� L=1 � 4:� (�pattern$,L,1)="1") � mask%=mask%+2^(4-L)
>� �
>�f oldvalue=�peek(&60):� onORoff$="ON" � newvalue=oldvalue � mask% � newvalue=oldvalue � (255-mask%)
>� �poke(&60,newvalue)
>� �
Bh� � ***TESTS THE SPECIFIED GROUP OF INPUTS AND RETURNS THE VALUE "ON" IF ALL OF THEM ARE ON AND "OFF" IF ANY ONE OF THEM IS OFF. REQUIRES A STRING REPRESENTING THE INPUTS TO BE TESTED AS A BINARY PATTERN.***
Br � �multitest(pattern$)
B| � L,L$,testmask%,result
B� � �(pattern$)<>4 � *FX125
B�> � L=1 � 4:L$=�pattern$,L,1):� �(L$="1" � L$="0") � *FX125
B� �
B�P testmask%=0:� L=1 � 4:� (�pattern$,L,1)="1") � testmask%=testmask%+2^(8-L)
B� �
B�1 result=((�peek(&60) � testmask%)=testmask%)
B� � result � ="ON" � ="OFF"
FPl � ***INITIALISES USER PORT AS FOUR OUTPUTS ON PB0-3 AND FOUR INPUTS ON PB4-7. TURNS ALL OUTPUTS OFF.***
FZ � �set_up_port
Fd �poke(&62,15)
Fn �poke(&60,0)
Fx �
� 00000000 0d 00 0a 2b 20 f4 20 2a 2a 2a 43 4f 50 59 52 49 |...+ . ***COPYRI|
00000010 47 48 54 20 50 49 4c 4f 54 20 4f 4e 45 20 4c 54 |GHT PILOT ONE LT|
00000020 44 2e 2c 20 31 39 38 34 2a 2a 2a 0d 00 14 08 20 |D., 1984***.... |
00000030 eb 20 37 0d 00 1e 24 20 41 52 52 24 3d bd 31 33 |. 7...$ ARR$=.13|
00000040 36 2b bd 39 31 2b bd 31 33 37 3a 4e 4f 41 24 3d |6+.91+.137:NOA$=|
00000050 22 20 20 20 22 20 20 0d 00 28 0d 20 2a 46 58 32 |" " ..(. *FX2|
00000060 32 39 2c 31 0d 00 32 10 20 2a 4b 45 59 31 30 20 |29,1..2. *KEY10 |
00000070 4f 2e 7c 4d 0d 00 3c 0b 20 2a 46 58 34 2c 31 0d |O.|M..<. *FX4,1.|
00000080 00 46 14 20 ef 20 32 33 2c 31 2c 30 3b 30 3b 30 |.F. . 23,1,0;0;0|
00000090 3b 30 3b 0d 00 50 2a 20 de 20 64 72 69 76 65 5f |;0;..P* . drive_|
000000a0 69 6e 64 65 78 25 28 31 2c 31 39 29 2c 6e 6f 5f |index%(1,19),no_|
000000b0 6f 66 5f 73 74 65 70 73 25 28 31 39 29 0d 00 5a |of_steps%(19)..Z|
000000c0 19 20 de 20 63 74 72 62 6c 25 20 34 2c 62 75 66 |. . ctrbl% 4,buf|
000000d0 66 65 72 25 20 34 0d 00 64 17 20 de 20 64 69 72 |fer% 4..d. . dir|
000000e0 24 28 32 29 2c 63 6f 64 65 24 28 32 29 0d 00 6e |$(2),code$(2)..n|
000000f0 40 20 64 69 72 24 28 30 29 3d 22 46 4f 52 57 41 |@ dir$(0)="FORWA|
00000100 52 44 53 20 22 3a 64 69 72 24 28 31 29 3d 22 42 |RDS ":dir$(1)="B|
00000110 41 43 4b 57 41 52 44 53 22 3a 64 69 72 24 28 32 |ACKWARDS":dir$(2|
00000120 29 3d 22 4f 46 46 20 20 20 20 20 20 22 0d 00 78 |)="OFF "..x|
00000130 2e 20 63 6f 64 65 24 28 30 29 3d 22 30 31 22 3a |. code$(0)="01":|
00000140 63 6f 64 65 24 28 31 29 3d 22 31 30 22 3a 63 6f |code$(1)="10":co|
00000150 64 65 24 28 32 29 3d 22 30 30 22 0d 00 82 0a 20 |de$(2)="00".... |
00000160 6e 25 3d 31 30 0d 00 8c 11 20 f2 73 65 74 5f 75 |n%=10.... .set_u|
00000170 70 5f 70 6f 72 74 0d 00 96 09 20 73 25 3d 30 0d |p_port.... s%=0.|
00000180 00 a0 06 20 f5 0d 00 aa 0a 20 f2 6d 65 6e 75 0d |... ..... .menu.|
00000190 00 b4 22 20 56 3d 30 3a 48 3d 30 3a f2 66 69 6e |.." V=0:H=0:.fin|
000001a0 64 28 32 38 2c 34 2c 31 2c 35 2c 30 2c 32 29 20 |d(28,4,1,5,0,2) |
000001b0 20 0d 00 be 1f 20 e7 20 56 3d 30 20 80 20 73 25 | .... . V=0 . s%|
000001c0 3e 30 20 f2 64 69 73 70 6c 61 79 3a 56 3d 30 20 |>0 .display:V=0 |
000001d0 0d 00 c8 2c 20 e7 20 56 3d 31 20 f2 63 6c 65 61 |..., . V=1 .clea|
000001e0 72 5f 72 6f 75 74 65 3a 73 25 3d 30 3a f2 6d 61 |r_route:s%=0:.ma|
000001f0 6b 65 5f 72 6f 75 74 65 3a 56 3d 31 0d 00 d2 21 |ke_route:V=1...!|
00000200 20 e7 20 56 3d 32 20 80 20 73 25 3e 30 20 f2 65 | . V=2 . s%>0 .e|
00000210 64 69 74 5f 72 6f 75 74 65 3a 56 3d 32 0d 00 dc |dit_route:V=2...|
00000220 23 20 e7 20 56 3d 33 20 80 20 73 25 3e 30 20 f2 |# . V=3 . s%>0 .|
00000230 64 72 69 76 65 5f 72 6f 75 74 65 3a 56 3d 33 20 |drive_route:V=3 |
00000240 0d 00 e6 13 20 e7 20 56 3d 34 20 eb 20 37 3a f2 |.... . V=4 . 7:.|
00000250 65 6e 64 0d 00 f0 07 20 fd a3 0d 00 fa 0b 20 dd |end.... ...... .|
00000260 20 f2 65 6e 64 0d 01 04 0d 20 2a 46 58 32 32 39 | .end.... *FX229|
00000270 2c 30 0d 01 0e 0b 20 2a 46 58 34 2c 30 0d 01 18 |,0.... *FX4,0...|
00000280 14 20 ef 20 32 33 2c 31 2c 31 3b 30 3b 30 3b 30 |. . 23,1,1;0;0;0|
00000290 3b 0d 01 22 06 20 e0 0d 01 2c 13 20 dd 20 f2 63 |;..". ...,. . .c|
000002a0 6c 65 61 72 5f 72 6f 75 74 65 0d 01 36 52 20 e3 |lear_route..6R .|
000002b0 20 49 25 3d 30 20 b8 20 31 39 3a 64 72 69 76 65 | I%=0 . 19:drive|
000002c0 5f 69 6e 64 65 78 25 28 30 2c 49 25 29 3d 30 3a |_index%(0,I%)=0:|
000002d0 64 72 69 76 65 5f 69 6e 64 65 78 25 28 31 2c 49 |drive_index%(1,I|
000002e0 25 29 3d 30 3a 6e 6f 5f 6f 66 5f 73 74 65 70 73 |%)=0:no_of_steps|
000002f0 25 28 49 25 29 3d 30 3a ed 49 25 20 0d 01 40 06 |%(I%)=0:.I% ..@.|
00000300 20 e1 0d 01 4a 12 20 dd 20 f2 6d 61 6b 65 5f 72 | ...J. . .make_r|
00000310 6f 75 74 65 0d 01 54 06 20 f5 0d 01 5e 06 20 f5 |oute..T. ...^. .|
00000320 0d 01 68 0e 20 f2 67 65 74 28 73 25 29 20 0d 01 |..h. .get(s%) ..|
00000330 72 54 20 f1 8a 30 2c 32 33 29 22 83 52 45 54 55 |rT ..0,23)".RETU|
00000340 52 4e 20 54 4f 20 43 4f 4e 46 49 52 4d 2c 20 45 |RN TO CONFIRM, E|
00000350 53 43 41 50 45 20 54 4f 20 52 45 45 4e 54 45 52 |SCAPE TO REENTER|
00000360 22 3b 3a f5 3a 64 75 6d 6d 79 3d a5 3a fd 64 75 |";:.:dummy=.:.du|
00000370 6d 6d 79 3d 31 33 20 84 20 64 75 6d 6d 79 3d 32 |mmy=13 . dummy=2|
00000380 37 20 0d 01 7c 0f 20 fd 20 64 75 6d 6d 79 3d 31 |7 ..|. . dummy=1|
00000390 33 0d 01 86 73 20 e7 20 73 25 3c 3d 31 39 20 f1 |3...s . s%<=19 .|
000003a0 8a 30 2c 32 33 29 22 83 20 20 20 20 20 20 20 20 |.0,23)". |
000003b0 41 4e 4f 54 48 45 52 20 53 54 45 50 3f 20 20 20 |ANOTHER STEP? |
000003c0 28 59 2f 4e 29 20 20 20 20 20 20 20 22 3b 3a f5 |(Y/N) ";:.|
000003d0 3a 64 75 6d 6d 79 3d a5 3a 64 75 6d 6d 79 3d 64 |:dummy=.:dummy=d|
000003e0 75 6d 6d 79 20 80 20 32 32 33 3a fd 64 75 6d 6d |ummy . 223:.dumm|
000003f0 79 3d 97 22 59 22 20 84 20 64 75 6d 6d 79 3d 97 |y=."Y" . dummy=.|
00000400 22 4e 22 20 0d 01 90 23 20 e7 20 73 25 3c 3d 31 |"N" ...# . s%<=1|
00000410 39 20 80 20 64 75 6d 6d 79 3d 97 22 59 22 20 73 |9 . dummy=."Y" s|
00000420 25 3d 73 25 2b 31 20 0d 01 9a 1b 20 fd 20 73 25 |%=s%+1 .... . s%|
00000430 3e 31 39 20 84 20 64 75 6d 6d 79 3d 97 22 4e 22 |>19 . dummy=."N"|
00000440 20 20 0d 01 a4 15 20 e7 20 73 25 3c 3d 31 39 20 | .... . s%<=19 |
00000450 73 25 3d 73 25 2b 31 0d 01 ae 06 20 e1 0d 01 b8 |s%=s%+1.... ....|
00000460 15 20 dd 20 f2 67 65 74 28 73 74 61 67 65 25 29 |. . .get(stage%)|
00000470 20 20 0d 01 c2 37 20 db 3a f2 6d 65 73 73 61 67 | ...7 .:.messag|
00000480 65 28 22 53 54 41 47 45 20 4e 4f 2e 22 2b c3 28 |e("STAGE NO."+.(|
00000490 73 74 61 67 65 25 2b 31 29 2c 22 84 22 2c 22 83 |stage%+1),".",".|
000004a0 22 29 3a f1 27 27 27 27 20 0d 01 cc 39 20 f1 8a |"):.'''' ...9 ..|
000004b0 37 29 3b 22 4c 45 46 54 20 20 4d 4f 54 4f 52 3f |7);"LEFT MOTOR?|
000004c0 20 22 3b 3a e3 20 49 25 3d 30 b8 32 3a f1 8a 32 | ";:. I%=0.2:..2|
000004d0 32 2c 49 25 2b 37 29 64 69 72 24 28 49 25 29 3a |2,I%+7)dir$(I%):|
000004e0 ed 20 0d 01 d6 0e 20 f2 69 6e 73 74 72 75 63 74 |. .... .instruct|
000004f0 0d 01 e0 20 20 56 3d 30 3a 48 3d 30 3a f2 66 69 |... V=0:H=0:.fi|
00000500 6e 64 28 33 33 2c 37 2c 31 2c 33 2c 30 2c 31 29 |nd(33,7,1,3,0,1)|
00000510 0d 01 ea 1d 20 64 72 69 76 65 5f 69 6e 64 65 78 |.... drive_index|
00000520 25 28 30 2c 73 74 61 67 65 25 29 3d 56 0d 01 f4 |%(0,stage%)=V...|
00000530 28 20 f1 20 8a 32 31 2c 37 29 22 81 22 3b 64 69 |( . .21,7)".";di|
00000540 72 24 28 56 29 8a 32 32 2c 38 29 89 39 8a 32 32 |r$(V).22,8).9.22|
00000550 2c 39 29 89 39 0d 01 fe 3f 20 f1 27 27 27 8a 37 |,9).9...? .'''.7|
00000560 29 3b 22 52 49 47 48 54 20 4d 4f 54 4f 52 3f 20 |);"RIGHT MOTOR? |
00000570 22 3b 3a e3 20 49 25 3d 30 b8 32 3a f1 8a 32 32 |";:. I%=0.2:..22|
00000580 2c 49 25 2b 31 33 29 64 69 72 24 28 49 25 29 3a |,I%+13)dir$(I%):|
00000590 ed 20 20 20 0d 02 08 21 20 56 3d 30 3a 48 3d 30 |. ...! V=0:H=0|
000005a0 3a f2 66 69 6e 64 28 33 33 2c 31 33 2c 31 2c 33 |:.find(33,13,1,3|
000005b0 2c 30 2c 31 29 0d 02 12 1d 20 64 72 69 76 65 5f |,0,1).... drive_|
000005c0 69 6e 64 65 78 25 28 31 2c 73 74 61 67 65 25 29 |index%(1,stage%)|
000005d0 3d 56 0d 02 1c 2b 20 f1 20 8a 32 31 2c 31 33 29 |=V...+ . .21,13)|
000005e0 22 81 22 3b 64 69 72 24 28 56 29 8a 32 32 2c 31 |".";dir$(V).22,1|
000005f0 34 29 89 39 8a 32 32 2c 31 35 29 89 39 0d 02 26 |4).9.22,15).9..&|
00000600 0f 20 f2 69 6e 73 74 72 75 63 74 32 0d 02 30 41 |. .instruct2..0A|
00000610 20 f5 3a f1 8a 37 2c 31 39 29 22 53 54 45 50 53 | .:..7,19)"STEPS|
00000620 3f 20 28 31 2d 31 30 30 29 81 20 20 20 20 20 22 |? (1-100). "|
00000630 3b 3a ef 20 38 2c 38 2c 38 2c 38 2c 38 3a f2 69 |;:. 8,8,8,8,8:.i|
00000640 6e 70 75 74 28 34 38 2c 35 37 2c 33 29 0d 02 3a |nput(48,57,3)..:|
00000650 07 20 ef 37 0d 02 44 32 20 e7 20 a9 75 74 24 3e |. .7..D2 . .ut$>|
00000660 30 20 6e 6f 5f 6f 66 5f 73 74 65 70 73 25 3d a0 |0 no_of_steps%=.|
00000670 28 75 74 24 29 20 8b 20 6e 6f 5f 6f 66 5f 73 74 |(ut$) . no_of_st|
00000680 65 70 73 25 3d 30 0d 02 4e 2f 20 ef 20 31 31 3a |eps%=0..N/ . 11:|
00000690 fd 6e 6f 5f 6f 66 5f 73 74 65 70 73 25 3e 30 20 |.no_of_steps%>0 |
000006a0 80 20 6e 6f 5f 6f 66 5f 73 74 65 70 73 25 3c 3d |. no_of_steps%<=|
000006b0 31 30 30 20 20 0d 02 58 26 20 6e 6f 5f 6f 66 5f |100 ..X& no_of_|
000006c0 73 74 65 70 73 25 28 73 74 61 67 65 25 29 3d 6e |steps%(stage%)=n|
000006d0 6f 5f 6f 66 5f 73 74 65 70 73 25 0d 02 62 06 20 |o_of_steps%..b. |
000006e0 e1 0d 02 6c 10 20 dd f2 69 6e 73 74 72 75 63 74 |...l. ..instruct|
000006f0 32 0d 02 76 2b 20 f1 20 8a 30 2c 32 33 29 89 37 |2..v+ . .0,23).7|
00000700 3b 22 83 45 4e 54 45 52 20 41 4e 44 20 50 52 45 |;".ENTER AND PRE|
00000710 53 53 20 52 45 54 55 52 4e 22 89 39 0d 02 80 06 |SS RETURN".9....|
00000720 20 e1 0d 02 8a 18 20 dd f2 66 69 6e 64 28 58 2c | ..... ..find(X,|
00000730 59 2c 4d 2c 4e 2c 57 2c 44 29 0d 02 94 07 20 f5 |Y,M,N,W,D).... .|
00000740 20 0d 02 9e 06 20 f5 0d 02 a8 1c 20 f1 8a 58 2b | .... ..... ..X+|
00000750 28 48 2a 57 29 2c 59 2b 28 56 2a 44 29 29 3b 41 |(H*W),Y+(V*D));A|
00000760 52 52 24 0d 02 b2 08 20 41 3d a5 0d 02 bc 18 20 |RR$.... A=..... |
00000770 fd 28 41 3e 31 33 35 80 41 3c 31 34 30 29 84 41 |.(A>135.A<140).A|
00000780 3d 31 33 0d 02 c6 1d 20 f1 8a 58 2b 28 48 2a 57 |=13.... ..X+(H*W|
00000790 29 2c 59 2b 28 56 2a 44 29 29 3b 4e 4f 41 24 20 |),Y+(V*D));NOA$ |
000007a0 0d 02 d0 2a 20 e7 41 3d 31 33 38 80 56 3c 28 4e |...* .A=138.V<(N|
000007b0 2d 31 29 8c 56 3d 56 2b 31 8b e7 41 3d 31 33 39 |-1).V=V+1..A=139|
000007c0 80 56 3e 30 56 3d 56 2d 31 20 0d 02 da 29 20 e7 |.V>0V=V-1 ...) .|
000007d0 41 3d 31 33 37 80 48 3c 28 4d 2d 31 29 8c 48 3d |A=137.H<(M-1).H=|
000007e0 48 2b 31 8b e7 41 3d 31 33 36 80 48 3e 30 48 3d |H+1..A=136.H>0H=|
000007f0 48 2d 31 0d 02 e4 0d 20 fd 41 3d 31 33 3a ef 37 |H-1.... .A=13:.7|
00000800 0d 02 ee 06 20 e1 0d 02 f8 27 20 dd f2 69 6e 70 |.... ....' ..inp|
00000810 75 74 28 6d 69 6e 63 68 61 72 25 2c 6d 61 78 63 |ut(minchar%,maxc|
00000820 68 61 72 25 2c 6d 61 78 6c 65 6e 25 29 0d 03 02 |har%,maxlen%)...|
00000830 14 20 ef 20 32 33 2c 31 2c 31 3b 30 3b 30 3b 30 |. . 23,1,1;0;0;0|
00000840 3b 0d 03 0c 0a 20 6c 65 25 3d 30 0d 03 16 0b 20 |;.... le%=0.... |
00000850 75 74 24 3d 22 22 0d 03 20 06 20 f5 0d 03 2a 3b |ut$="".. . ...*;|
00000860 20 f5 3a 41 3d a5 3a e7 20 28 41 3c 6d 69 6e 63 | .:A=.:. (A<minc|
00000870 68 61 72 25 20 84 20 41 3e 6d 61 78 63 68 61 72 |har% . A>maxchar|
00000880 25 29 20 80 20 41 3c 3e 31 33 20 80 20 41 3c 3e |%) . A<>13 . A<>|
00000890 31 32 37 20 ef 20 37 0d 03 34 31 20 fd 20 28 41 |127 . 7..41 . (A|
000008a0 3e 3d 6d 69 6e 63 68 61 72 25 20 80 20 41 3c 3d |>=minchar% . A<=|
000008b0 6d 61 78 63 68 61 72 25 29 20 84 20 41 3d 31 33 |maxchar%) . A=13|
000008c0 20 84 20 41 3d 31 32 37 0d 03 3e 44 20 e7 20 28 | . A=127..>D . (|
000008d0 41 3d 31 32 37 20 80 20 6c 65 25 3e 30 29 20 ef |A=127 . le%>0) .|
000008e0 20 31 32 37 20 8b 20 e7 20 41 3c 3e 31 33 20 80 | 127 . . A<>13 .|
000008f0 20 6c 65 25 3c 6d 61 78 6c 65 6e 25 20 80 20 41 | le%<maxlen% . A|
00000900 3c 3e 31 32 37 20 f1 bd 28 41 29 3b 0d 03 48 3b |<>127 ..(A);..H;|
00000910 20 e7 20 28 41 3c 3e 31 33 20 80 20 6c 65 25 3d | . (A<>13 . le%=|
00000920 6d 61 78 6c 65 6e 25 20 80 20 41 3c 3e 31 32 37 |maxlen% . A<>127|
00000930 29 20 84 20 28 41 3d 31 32 37 20 80 20 6c 65 25 |) . (A=127 . le%|
00000940 3d 30 29 20 ef 20 37 0d 03 52 64 20 e7 20 41 3d |=0) . 7..Rd . A=|
00000950 31 32 37 20 80 20 6c 65 25 3e 30 20 75 74 24 3d |127 . le%>0 ut$=|
00000960 c0 75 74 24 2c 6c 65 25 2d 31 29 3a 6c 65 25 3d |.ut$,le%-1):le%=|
00000970 6c 65 25 2d 31 20 8b 20 e7 20 41 3c 3e 31 33 20 |le%-1 . . A<>13 |
00000980 80 20 41 3c 3e 31 32 37 20 80 20 6c 65 25 3c 6d |. A<>127 . le%<m|
00000990 61 78 6c 65 6e 25 20 75 74 24 3d 75 74 24 2b bd |axlen% ut$=ut$+.|
000009a0 41 3a 6c 65 25 3d 6c 65 25 2b 31 0d 03 5c 0b 20 |A:le%=le%+1..\. |
000009b0 fd 20 41 3d 31 33 0d 03 66 14 20 ef 20 32 33 2c |. A=13..f. . 23,|
000009c0 31 2c 30 3b 30 3b 30 3b 30 3b 0d 03 70 06 20 e1 |1,0;0;0;0;..p. .|
000009d0 0d 03 7a 1b 20 dd f2 6d 65 73 73 61 67 65 28 4d |..z. ..message(M|
000009e0 24 2c 66 6f 24 2c 62 61 24 29 20 0d 03 84 0c 20 |$,fo$,ba$) .... |
000009f0 e3 49 25 3d 30 b8 31 0d 03 8e 1d 20 e7 20 62 61 |.I%=0.1.... . ba|
00000a00 24 3d 22 22 3a f1 3b 20 8b 20 f1 62 61 24 3b bd |$="":.; . .ba$;.|
00000a10 31 35 37 3b 0d 03 98 20 20 f1 66 6f 24 3b bd 31 |157;... .fo$;.1|
00000a20 34 31 8a a8 28 34 30 2d a9 28 4d 24 29 29 2f 32 |41..(40-.(M$))/2|
00000a30 29 3b 4d 24 0d 03 a2 06 20 ed 0d 03 ac 07 20 e1 |);M$.... ..... .|
00000a40 20 0d 03 b6 0e 20 dd 20 f2 6d 65 6e 75 20 20 0d | .... . .menu .|
00000a50 03 c0 2e 20 db 3a f2 6d 65 73 73 61 67 65 28 22 |... .:.message("|
00000a60 50 49 4c 4f 54 20 4f 4e 45 20 2d 20 49 4e 54 43 |PILOT ONE - INTC|
00000a70 41 52 22 2c 22 81 22 2c 22 83 22 29 20 0d 03 ca |AR",".",".") ...|
00000a80 7c 20 f1 8a 31 30 2c 34 29 22 44 49 53 50 4c 41 || ..10,4)"DISPLA|
00000a90 59 20 53 45 51 55 45 4e 43 45 22 8a 31 30 2c 36 |Y SEQUENCE".10,6|
00000aa0 29 22 43 52 45 41 54 45 20 53 45 51 55 45 4e 43 |)"CREATE SEQUENC|
00000ab0 45 22 8a 31 30 2c 38 29 22 45 44 49 54 20 53 45 |E".10,8)"EDIT SE|
00000ac0 51 55 45 4e 43 45 22 8a 31 30 2c 31 30 29 22 52 |QUENCE".10,10)"R|
00000ad0 55 4e 20 53 45 51 55 45 4e 43 45 22 8a 39 2c 31 |UN SEQUENCE".9,1|
00000ae0 32 29 22 85 45 58 49 54 20 46 52 4f 4d 20 50 52 |2)".EXIT FROM PR|
00000af0 4f 47 52 41 4d 87 22 20 20 0d 03 d4 0e 20 f2 69 |OGRAM." .... .i|
00000b00 6e 73 74 72 75 63 74 0d 03 de 06 20 e1 0d 03 e8 |nstruct.... ....|
00000b10 0f 20 dd f2 69 6e 73 74 72 75 63 74 0d 03 f2 36 |. ..instruct...6|
00000b20 20 f1 8a 32 2c 32 33 29 bd 31 33 31 22 55 53 45 | ..2,23).131"USE|
00000b30 20 41 52 52 4f 57 20 4b 45 59 53 20 41 4e 44 20 | ARROW KEYS AND |
00000b40 52 45 54 55 52 4e 20 54 4f 20 53 45 4c 45 43 54 |RETURN TO SELECT|
00000b50 22 20 0d 03 fc 06 20 e1 0d 04 06 13 20 dd 20 f2 |" .... ..... . .|
00000b60 64 72 69 76 65 5f 72 6f 75 74 65 0d 04 10 16 20 |drive_route.... |
00000b70 e3 20 73 74 61 67 65 25 3d 30 20 b8 20 73 25 2d |. stage%=0 . s%-|
00000b80 31 0d 04 1a 30 20 db 3a f2 6d 65 73 73 61 67 65 |1...0 .:.message|
00000b90 28 22 53 54 41 47 45 20 4e 4f 2e 22 2b c3 28 73 |("STAGE NO."+.(s|
00000ba0 74 61 67 65 25 2b 31 29 2c 22 84 22 2c 22 83 22 |tage%+1),".","."|
00000bb0 29 0d 04 24 09 20 f1 27 27 27 0d 04 2e 43 20 f2 |)..$. .'''...C .|
00000bc0 6d 65 73 73 61 67 65 28 22 4c 45 46 54 20 20 4d |message("LEFT M|
00000bd0 4f 54 4f 52 20 2d 20 22 2b 64 69 72 24 28 64 72 |OTOR - "+dir$(dr|
00000be0 69 76 65 5f 69 6e 64 65 78 25 28 30 2c 73 74 61 |ive_index%(0,sta|
00000bf0 67 65 25 29 29 2c 22 82 22 2c 22 22 29 0d 04 38 |ge%)),".","")..8|
00000c00 09 20 f1 27 27 27 0d 04 42 44 20 f2 6d 65 73 73 |. .'''..BD .mess|
00000c10 61 67 65 28 22 52 49 47 48 54 20 4d 4f 54 4f 52 |age("RIGHT MOTOR|
00000c20 20 2d 20 22 2b 64 69 72 24 28 64 72 69 76 65 5f | - "+dir$(drive_|
00000c30 69 6e 64 65 78 25 28 31 2c 73 74 61 67 65 25 29 |index%(1,stage%)|
00000c40 29 2c 22 82 22 2c 22 22 29 20 0d 04 4c 09 20 f1 |),".","") ..L. .|
00000c50 27 27 27 0d 04 56 36 20 f2 6d 65 73 73 61 67 65 |'''..V6 .message|
00000c60 28 c3 28 6e 6f 5f 6f 66 5f 73 74 65 70 73 25 28 |(.(no_of_steps%(|
00000c70 73 74 61 67 65 25 29 29 2b 22 20 53 54 45 50 53 |stage%))+" STEPS|
00000c80 22 2c 22 82 22 2c 22 22 29 0d 04 60 55 20 d1 3d |",".","")..`U .=|
00000c90 30 3a f2 6d 75 6c 74 69 74 75 72 6e 28 22 4f 4e |0:.multiturn("ON|
00000ca0 22 2c 63 6f 64 65 24 28 64 72 69 76 65 5f 69 6e |",code$(drive_in|
00000cb0 64 65 78 25 28 31 2c 73 74 61 67 65 25 29 29 2b |dex%(1,stage%))+|
00000cc0 63 6f 64 65 24 28 64 72 69 76 65 5f 69 6e 64 65 |code$(drive_inde|
00000cd0 78 25 28 30 2c 73 74 61 67 65 25 29 29 29 0d 04 |x%(0,stage%)))..|
00000ce0 6a 23 20 f5 3a fd 91 3e 6e 6f 5f 6f 66 5f 73 74 |j# .:..>no_of_st|
00000cf0 65 70 73 25 28 73 74 61 67 65 25 29 2a 6e 25 20 |eps%(stage%)*n% |
00000d00 20 0d 04 74 1f 20 f2 6d 75 6c 74 69 74 75 72 6e | ..t. .multiturn|
00000d10 28 22 4f 46 46 22 2c 22 31 31 31 31 22 29 20 20 |("OFF","1111") |
00000d20 0d 04 7e 0d 20 ed 20 73 74 61 67 65 25 0d 04 88 |..~. . stage%...|
00000d30 30 20 f1 8a 36 2c 32 33 29 22 83 50 52 45 53 53 |0 ..6,23)".PRESS|
00000d40 20 41 4e 59 20 4b 45 59 20 54 4f 20 43 4f 4e 54 | ANY KEY TO CONT|
00000d50 49 4e 55 45 22 3a 64 75 6d 6d 79 3d a5 0d 04 92 |INUE":dummy=....|
00000d60 06 20 e1 0d 04 9c 12 20 dd 20 f2 65 64 69 74 5f |. ..... . .edit_|
00000d70 72 6f 75 74 65 0d 04 a6 06 20 f5 0d 04 b0 0f 20 |route.... ..... |
00000d80 f2 65 64 69 74 5f 6d 65 6e 75 0d 04 ba 20 20 56 |.edit_menu... V|
00000d90 3d 30 3a 48 3d 30 3a f2 66 69 6e 64 28 33 30 2c |=0:H=0:.find(30,|
00000da0 34 2c 31 2c 36 2c 30 2c 32 29 0d 04 c4 1e 20 e7 |4,1,6,0,2).... .|
00000db0 20 56 3d 30 20 80 20 73 25 3e 30 20 f2 64 69 73 | V=0 . s%>0 .dis|
00000dc0 70 6c 61 79 3a 56 3d 30 0d 04 ce 24 20 e7 20 56 |play:V=0...$ . V|
00000dd0 3d 31 20 f2 64 65 6c 65 74 65 28 a4 77 68 69 63 |=1 .delete(.whic|
00000de0 68 5f 73 74 61 67 65 29 3a 56 3d 31 0d 04 d8 2d |h_stage):V=1...-|
00000df0 20 e7 20 56 3d 32 20 80 20 73 25 3c 32 30 20 f2 | . V=2 . s%<20 .|
00000e00 69 6e 73 65 72 74 28 a4 77 68 69 63 68 5f 73 74 |insert(.which_st|
00000e10 61 67 65 29 3a 56 3d 32 20 0d 04 e2 23 20 e7 20 |age):V=2 ...# . |
00000e20 56 3d 33 20 f2 67 65 74 28 a4 77 68 69 63 68 5f |V=3 .get(.which_|
00000e30 73 74 61 67 65 2d 31 29 3a 56 3d 33 0d 04 ec 22 |stage-1):V=3..."|
00000e40 20 e7 20 56 3d 34 20 80 20 73 25 3c 32 30 20 f2 | . V=4 . s%<20 .|
00000e50 6d 61 6b 65 5f 72 6f 75 74 65 3a 56 3d 34 0d 04 |make_route:V=4..|
00000e60 f6 11 20 fd 56 3d 35 20 84 20 73 25 3d 30 20 0d |.. .V=5 . s%=0 .|
00000e70 05 00 06 20 e1 0d 05 0a 11 20 dd 20 f2 65 64 69 |... ..... . .edi|
00000e80 74 5f 6d 65 6e 75 0d 05 14 2e 20 db 3a f2 6d 65 |t_menu.... .:.me|
00000e90 73 73 61 67 65 28 22 49 4e 54 43 41 52 20 2d 20 |ssage("INTCAR - |
00000ea0 45 44 49 54 20 4d 45 4e 55 22 2c 22 81 22 2c 22 |EDIT MENU",".","|
00000eb0 83 22 29 20 0d 05 1e 8e 20 f1 8a 31 30 2c 34 29 |.") .... ..10,4)|
00000ec0 22 44 49 53 50 4c 41 59 20 53 45 51 55 45 4e 43 |"DISPLAY SEQUENC|
00000ed0 45 22 8a 31 30 2c 36 29 22 44 45 4c 45 54 45 20 |E".10,6)"DELETE |
00000ee0 53 54 41 47 45 22 8a 31 30 2c 38 29 22 49 4e 53 |STAGE".10,8)"INS|
00000ef0 45 52 54 20 53 54 41 47 45 22 8a 31 30 2c 31 30 |ERT STAGE".10,10|
00000f00 29 22 45 44 49 54 20 53 54 41 47 45 22 8a 31 30 |)"EDIT STAGE".10|
00000f10 2c 31 32 29 22 41 44 44 20 54 4f 20 53 45 51 55 |,12)"ADD TO SEQU|
00000f20 45 4e 43 45 22 8a 39 2c 31 34 29 22 85 52 45 54 |ENCE".9,14)".RET|
00000f30 55 52 4e 20 54 4f 20 4d 41 49 4e 20 4d 45 4e 55 |URN TO MAIN MENU|
00000f40 87 22 0d 05 28 0e 20 f2 69 6e 73 74 72 75 63 74 |."..(. .instruct|
00000f50 0d 05 32 06 20 e1 0d 05 3c 0f 20 dd 20 f2 64 69 |..2. ...<. . .di|
00000f60 73 70 6c 61 79 0d 05 46 34 20 db 3a f2 6d 65 73 |splay..F4 .:.mes|
00000f70 73 61 67 65 28 22 49 4e 54 43 41 52 20 2d 20 53 |sage("INTCAR - S|
00000f80 45 51 55 45 4e 43 45 20 44 49 53 50 4c 41 59 22 |EQUENCE DISPLAY"|
00000f90 2c 22 81 22 2c 22 83 22 29 0d 05 50 3a 20 f1 20 |,".",".")..P: . |
00000fa0 8a 32 2c 33 29 22 81 4c 45 46 54 20 20 4d 4f 54 |.2,3)".LEFT MOT|
00000fb0 4f 52 22 8a 31 38 2c 33 29 22 52 49 47 48 54 20 |OR".18,3)"RIGHT |
00000fc0 4d 4f 54 4f 52 22 8a 33 33 2c 33 29 22 53 54 45 |MOTOR".33,3)"STE|
00000fd0 50 53 22 0d 05 5a 25 20 f1 8a 38 2c 32 33 29 22 |PS"..Z% ..8,23)"|
00000fe0 83 50 52 45 53 53 20 53 48 49 46 54 20 54 4f 20 |.PRESS SHIFT TO |
00000ff0 53 43 52 4f 4c 4c 22 20 0d 05 64 16 20 ef 20 32 |SCROLL" ..d. . 2|
00001000 38 2c 30 2c 32 31 2c 33 39 2c 35 2c 31 34 0d 05 |8,0,21,39,5,14..|
00001010 6e 12 20 e3 20 49 25 3d 30 20 b8 20 73 25 2d 31 |n. . I%=0 . s%-1|
00001020 0d 05 78 1d 20 f1 89 28 32 2d a9 28 c3 28 49 25 |..x. ..(2-.(.(I%|
00001030 2b 31 29 29 29 c3 28 49 25 2b 31 29 3b 0d 05 82 |+1))).(I%+1);...|
00001040 3e 20 f1 8a 34 29 64 69 72 24 28 64 72 69 76 65 |> ..4)dir$(drive|
00001050 5f 69 6e 64 65 78 25 28 30 2c 49 25 29 29 8a 31 |_index%(0,I%)).1|
00001060 39 29 64 69 72 24 28 64 72 69 76 65 5f 69 6e 64 |9)dir$(drive_ind|
00001070 65 78 25 28 31 2c 49 25 29 29 3b 0d 05 8c 39 20 |ex%(1,I%));...9 |
00001080 f1 8a 33 34 29 89 28 33 2d a9 28 c3 28 6e 6f 5f |..34).(3-.(.(no_|
00001090 6f 66 5f 73 74 65 70 73 25 28 49 25 29 29 29 29 |of_steps%(I%))))|
000010a0 c3 28 6e 6f 5f 6f 66 5f 73 74 65 70 73 25 28 49 |.(no_of_steps%(I|
000010b0 25 29 29 27 0d 05 96 06 20 ed 0d 05 a0 32 20 ef |%))'.... ....2 .|
000010c0 20 32 36 2c 31 35 3a f1 8a 36 2c 32 33 29 22 83 | 26,15:..6,23)".|
000010d0 50 52 45 53 53 20 41 4e 59 20 4b 45 59 20 54 4f |PRESS ANY KEY TO|
000010e0 20 43 4f 4e 54 49 4e 55 45 22 20 20 0d 05 aa 0c | CONTINUE" ....|
000010f0 20 2a 46 58 32 31 2c 30 0d 05 b4 08 20 41 3d a5 | *FX21,0.... A=.|
00001100 0d 05 be 07 20 ef 37 0d 05 c8 06 20 e1 0d 05 d2 |.... .7.... ....|
00001110 13 20 dd 20 a4 77 68 69 63 68 5f 73 74 61 67 65 |. . .which_stage|
00001120 0d 05 dc 10 20 e7 20 73 25 3d 31 20 8c 20 3d 31 |.... . s%=1 . =1|
00001130 0d 05 e6 27 20 db 3a f2 6d 65 73 73 61 67 65 28 |...' .:.message(|
00001140 22 53 45 4c 45 43 54 20 53 54 41 47 45 22 2c 22 |"SELECT STAGE","|
00001150 85 22 2c 22 83 22 29 0d 05 f0 06 20 f5 0d 05 fa |.",".").... ....|
00001160 0f 20 f2 69 6e 73 74 72 75 63 74 32 0d 06 04 30 |. .instruct2...0|
00001170 20 f1 8a 38 2c 31 30 29 22 81 53 54 41 47 45 20 | ..8,10)".STAGE |
00001180 4e 55 4d 42 45 52 20 28 31 2d 22 c3 73 25 22 29 |NUMBER (1-".s%")|
00001190 2e 2e 2e 20 20 22 3b 3a ef 38 2c 38 0d 06 0e 14 |... ";:.8,8....|
000011a0 20 f2 69 6e 70 75 74 28 34 38 2c 35 37 2c 32 29 | .input(48,57,2)|
000011b0 0d 06 18 28 20 e7 20 a9 75 74 24 3e 30 20 73 74 |...( . .ut$>0 st|
000011c0 61 67 65 25 3d a0 28 75 74 24 29 20 8b 20 73 74 |age%=.(ut$) . st|
000011d0 61 67 65 25 3d 30 20 20 0d 06 22 20 20 ef 20 31 |age%=0 .." . 1|
000011e0 31 3a fd 73 74 61 67 65 25 3e 30 20 80 20 73 74 |1:.stage%>0 . st|
000011f0 61 67 65 25 3c 3d 73 25 0d 06 2c 0c 20 3d 73 74 |age%<=s%..,. =st|
00001200 61 67 65 25 0d 06 36 16 20 dd 20 f2 64 65 6c 65 |age%..6. . .dele|
00001210 74 65 28 73 74 61 67 65 25 29 0d 06 40 18 20 e7 |te(stage%)..@. .|
00001220 20 73 74 61 67 65 25 3d 32 30 20 73 25 3d 31 39 | stage%=20 s%=19|
00001230 3a e1 0d 06 4a 17 20 e3 20 49 25 3d 73 74 61 67 |:...J. . I%=stag|
00001240 65 25 20 b8 20 73 25 2d 31 0d 06 54 78 20 64 72 |e% . s%-1..Tx dr|
00001250 69 76 65 5f 69 6e 64 65 78 25 28 30 2c 49 25 2d |ive_index%(0,I%-|
00001260 31 29 3d 64 72 69 76 65 5f 69 6e 64 65 78 25 28 |1)=drive_index%(|
00001270 30 2c 49 25 29 3a 64 72 69 76 65 5f 69 6e 64 65 |0,I%):drive_inde|
00001280 78 25 28 31 2c 49 25 2d 31 29 3d 64 72 69 76 65 |x%(1,I%-1)=drive|
00001290 5f 69 6e 64 65 78 25 28 31 2c 49 25 29 3a 6e 6f |_index%(1,I%):no|
000012a0 5f 6f 66 5f 73 74 65 70 73 25 28 49 25 2d 31 29 |_of_steps%(I%-1)|
000012b0 3d 6e 6f 5f 6f 66 5f 73 74 65 70 73 25 28 49 25 |=no_of_steps%(I%|
000012c0 29 0d 06 5e 06 20 ed 0d 06 68 0c 20 73 25 3d 73 |)..^. ...h. s%=s|
000012d0 25 2d 31 0d 06 72 06 20 e1 0d 06 7c 16 20 dd 20 |%-1..r. ...|. . |
000012e0 f2 69 6e 73 65 72 74 28 73 74 61 67 65 25 29 0d |.insert(stage%).|
000012f0 06 86 1a 20 e3 20 49 25 3d 73 25 20 b8 20 73 74 |... . I%=s% . st|
00001300 61 67 65 25 20 88 20 2d 31 0d 06 90 78 20 64 72 |age% . -1...x dr|
00001310 69 76 65 5f 69 6e 64 65 78 25 28 30 2c 49 25 29 |ive_index%(0,I%)|
00001320 3d 64 72 69 76 65 5f 69 6e 64 65 78 25 28 30 2c |=drive_index%(0,|
00001330 49 25 2d 31 29 3a 64 72 69 76 65 5f 69 6e 64 65 |I%-1):drive_inde|
00001340 78 25 28 31 2c 49 25 29 3d 64 72 69 76 65 5f 69 |x%(1,I%)=drive_i|
00001350 6e 64 65 78 25 28 31 2c 49 25 2d 31 29 3a 6e 6f |ndex%(1,I%-1):no|
00001360 5f 6f 66 5f 73 74 65 70 73 25 28 49 25 29 3d 6e |_of_steps%(I%)=n|
00001370 6f 5f 6f 66 5f 73 74 65 70 73 25 28 49 25 2d 31 |o_of_steps%(I%-1|
00001380 29 0d 06 9a 06 20 ed 0d 06 a4 06 20 f5 0d 06 ae |).... ..... ....|
00001390 13 20 f2 67 65 74 28 73 74 61 67 65 25 2d 31 29 |. .get(stage%-1)|
000013a0 0d 06 b8 53 20 f1 8a 30 2c 32 33 29 22 83 52 45 |...S ..0,23)".RE|
000013b0 54 55 52 4e 20 54 4f 20 43 4f 4e 46 49 52 4d 2c |TURN TO CONFIRM,|
000013c0 20 45 53 43 41 50 45 20 54 4f 20 52 45 45 4e 54 | ESCAPE TO REENT|
000013d0 45 52 22 3b 3a f5 3a 64 75 6d 6d 79 3d a5 3a fd |ER";:.:dummy=.:.|
000013e0 64 75 6d 6d 79 3d 31 33 20 84 20 64 75 6d 6d 79 |dummy=13 . dummy|
000013f0 3d 32 37 0d 06 c2 0e 20 fd 64 75 6d 6d 79 3d 31 |=27.... .dummy=1|
00001400 33 0d 06 cc 0c 20 73 25 3d 73 25 2b 31 0d 06 d6 |3.... s%=s%+1...|
00001410 06 20 e1 0d 27 10 6e 20 f4 20 2a 2a 2a 55 53 45 |. ..'.n . ***USE|
00001420 53 20 4f 53 42 59 54 45 2f 2a 46 58 31 35 30 20 |S OSBYTE/*FX150 |
00001430 54 4f 20 45 58 41 4d 49 4e 45 20 56 49 41 20 52 |TO EXAMINE VIA R|
00001440 45 47 49 53 54 45 52 2e 20 52 45 51 55 49 52 45 |EGISTER. REQUIRE|
00001450 53 20 4f 46 46 53 45 54 20 4f 46 20 52 45 47 49 |S OFFSET OF REGI|
00001460 53 54 45 52 20 49 4e 20 50 41 47 45 20 26 46 45 |STER IN PAGE &FE|
00001470 20 41 53 20 50 41 52 41 4d 45 54 45 52 2e 2a 2a | AS PARAMETER.**|
00001480 2a 0d 27 1a 15 20 dd 20 a4 70 65 65 6b 28 6f 66 |*.'.. . .peek(of|
00001490 66 73 65 74 29 20 0d 27 24 0c 20 ea 20 76 61 6c |fset) .'$. . val|
000014a0 75 65 0d 27 2e 3a 20 41 25 3d 31 35 30 3a 58 25 |ue.'.: A%=150:X%|
000014b0 3d 6f 66 66 73 65 74 3a 76 61 6c 75 65 3d 28 ba |=offset:value=(.|
000014c0 28 26 46 46 46 34 29 20 80 20 26 46 46 30 30 30 |(&FFF4) . &FF000|
000014d0 30 29 20 81 20 26 31 30 30 30 30 20 0d 27 38 0b |0) . &10000 .'8.|
000014e0 20 3d 76 61 6c 75 65 0d 2a f8 94 20 f4 20 2a 2a | =value.*.. . **|
000014f0 2a 55 53 45 53 20 4f 53 42 59 54 45 2f 2a 46 58 |*USES OSBYTE/*FX|
00001500 31 35 31 20 54 4f 20 57 52 49 54 45 20 41 20 56 |151 TO WRITE A V|
00001510 41 4c 55 45 20 54 4f 20 41 20 56 49 41 20 52 45 |ALUE TO A VIA RE|
00001520 47 49 53 54 45 52 2e 20 20 52 45 51 55 49 52 45 |GISTER. REQUIRE|
00001530 53 20 4f 46 46 53 45 54 20 4f 46 20 52 45 47 49 |S OFFSET OF REGI|
00001540 53 54 45 52 20 49 4e 20 50 41 47 45 20 26 46 45 |STER IN PAGE &FE|
00001550 2c 20 41 4e 44 20 56 41 4c 55 45 20 54 4f 20 42 |, AND VALUE TO B|
00001560 45 20 57 52 49 54 54 45 4e 20 41 53 20 50 41 52 |E WRITTEN AS PAR|
00001570 41 4d 45 54 45 52 53 2e 2a 2a 2a 0d 2b 02 1a 20 |AMETERS.***.+.. |
00001580 dd 20 f2 70 6f 6b 65 28 6f 66 66 73 65 74 2c 76 |. .poke(offset,v|
00001590 61 6c 75 65 29 0d 2b 0c 27 20 41 25 3d 31 35 31 |alue).+.' A%=151|
000015a0 3a 58 25 3d 6f 66 66 73 65 74 3a 59 25 3d 76 61 |:X%=offset:Y%=va|
000015b0 6c 75 65 3a d6 20 26 46 46 46 34 20 0d 2b 16 08 |lue:. &FFF4 .+..|
000015c0 20 e1 20 20 0d 2e e0 51 20 f4 20 2a 2a 2a 45 58 | . ...Q . ***EX|
000015d0 41 4d 49 4e 45 53 20 54 48 45 20 43 55 52 52 45 |AMINES THE CURRE|
000015e0 4e 54 20 53 54 41 54 45 20 4f 46 20 54 48 45 20 |NT STATE OF THE |
000015f0 52 45 4c 41 59 20 53 50 45 43 49 46 49 45 44 20 |RELAY SPECIFIED |
00001600 41 4e 44 20 53 57 41 50 53 20 49 54 20 4f 56 45 |AND SWAPS IT OVE|
00001610 52 2e 2a 2a 2a 0d 2e ea 1b 20 dd 20 f2 74 6f 67 |R.***.... . .tog|
00001620 67 6c 65 28 6c 69 6e 65 6e 75 6d 62 65 72 29 20 |gle(linenumber) |
00001630 0d 2e f4 2e 20 e7 20 28 6c 69 6e 65 6e 75 6d 62 |.... . (linenumb|
00001640 65 72 3e 33 20 84 20 6c 69 6e 65 6e 75 6d 62 65 |er>3 . linenumbe|
00001650 72 3c 30 29 20 8c 20 2a 46 58 31 32 35 20 0d 2e |r<0) . *FX125 ..|
00001660 fe 21 20 ea 20 62 69 74 76 61 6c 75 65 2c 6f 6c |.! . bitvalue,ol|
00001670 64 76 61 6c 75 65 2c 6e 65 77 76 61 6c 75 65 0d |dvalue,newvalue.|
00001680 2f 08 1a 20 62 69 74 76 61 6c 75 65 3d 32 5e 6c |/.. bitvalue=2^l|
00001690 69 6e 65 6e 75 6d 62 65 72 0d 2f 12 1a 20 6f 6c |inenumber./.. ol|
000016a0 64 76 61 6c 75 65 3d a4 70 65 65 6b 28 26 36 30 |dvalue=.peek(&60|
000016b0 29 20 20 0d 2f 1c 21 20 6e 65 77 76 61 6c 75 65 |) ./.! newvalue|
000016c0 3d 6f 6c 64 76 61 6c 75 65 20 82 20 62 69 74 76 |=oldvalue . bitv|
000016d0 61 6c 75 65 0d 2f 26 18 20 f2 70 6f 6b 65 28 26 |alue./&. .poke(&|
000016e0 36 30 2c 6e 65 77 76 61 6c 75 65 29 0d 2f 30 08 |60,newvalue)./0.|
000016f0 20 e1 20 20 0d 32 c8 7e 20 f4 20 2a 2a 2a 54 55 | . .2.~ . ***TU|
00001700 52 4e 53 20 4f 4e 20 4f 52 20 4f 46 46 20 41 20 |RNS ON OR OFF A |
00001710 53 50 45 43 49 46 49 45 44 20 52 45 4c 41 59 2e |SPECIFIED RELAY.|
00001720 20 20 52 45 51 55 49 52 45 53 20 41 43 54 49 4f | REQUIRES ACTIO|
00001730 4e 20 54 4f 20 42 45 20 54 41 4b 45 4e 20 69 65 |N TO BE TAKEN ie|
00001740 2e 20 22 4f 4e 22 20 4f 52 20 22 4f 46 46 22 2c |. "ON" OR "OFF",|
00001750 20 41 4e 44 20 52 45 4c 41 59 20 4e 55 4d 42 45 | AND RELAY NUMBE|
00001760 52 20 41 53 20 50 41 52 41 4d 45 54 45 52 53 2a |R AS PARAMETERS*|
00001770 2a 2a 0d 32 d2 21 20 dd 20 f2 74 75 72 6e 28 6f |**.2.! . .turn(o|
00001780 6e 4f 52 6f 66 66 24 2c 6c 69 6e 65 6e 75 6d 62 |nORoff$,linenumb|
00001790 65 72 29 0d 32 dc 32 20 e7 20 ac 28 6f 6e 4f 52 |er).2.2 . .(onOR|
000017a0 6f 66 66 24 3d 22 4f 4e 22 20 84 20 6f 6e 4f 52 |off$="ON" . onOR|
000017b0 6f 66 66 24 3d 22 4f 46 46 22 29 20 8c 20 2a 46 |off$="OFF") . *F|
000017c0 58 31 32 35 20 0d 32 e6 2e 20 e7 20 28 6c 69 6e |X125 .2.. . (lin|
000017d0 65 6e 75 6d 62 65 72 3e 33 20 84 20 6c 69 6e 65 |enumber>3 . line|
000017e0 6e 75 6d 62 65 72 3c 30 29 20 8c 20 2a 46 58 31 |number<0) . *FX1|
000017f0 32 35 20 0d 32 f0 21 20 ea 20 62 69 74 76 61 6c |25 .2.! . bitval|
00001800 75 65 2c 6f 6c 64 76 61 6c 75 65 2c 6e 65 77 76 |ue,oldvalue,newv|
00001810 61 6c 75 65 0d 32 fa 1a 20 62 69 74 76 61 6c 75 |alue.2.. bitvalu|
00001820 65 3d 32 5e 6c 69 6e 65 6e 75 6d 62 65 72 0d 33 |e=2^linenumber.3|
00001830 04 19 20 6f 6c 64 76 61 6c 75 65 3d a4 70 65 65 |.. oldvalue=.pee|
00001840 6b 28 26 36 30 29 20 0d 33 0e 58 20 e7 20 6f 6e |k(&60) .3.X . on|
00001850 4f 52 6f 66 66 24 3d 22 4f 4e 22 20 8c 20 6e 65 |ORoff$="ON" . ne|
00001860 77 76 61 6c 75 65 3d 6f 6c 64 76 61 6c 75 65 20 |wvalue=oldvalue |
00001870 84 20 62 69 74 76 61 6c 75 65 20 8b 20 6e 65 77 |. bitvalue . new|
00001880 76 61 6c 75 65 3d 6f 6c 64 76 61 6c 75 65 20 80 |value=oldvalue .|
00001890 20 28 32 35 35 2d 62 69 74 76 61 6c 75 65 29 0d | (255-bitvalue).|
000018a0 33 18 18 20 f2 70 6f 6b 65 28 26 36 30 2c 6e 65 |3.. .poke(&60,ne|
000018b0 77 76 61 6c 75 65 29 0d 33 22 06 20 e1 0d 36 b0 |wvalue).3". ..6.|
000018c0 66 20 f4 20 2a 2a 2a 54 45 53 54 53 20 54 48 45 |f . ***TESTS THE|
000018d0 20 43 55 52 52 45 4e 54 20 53 54 41 54 45 20 4f | CURRENT STATE O|
000018e0 46 20 54 48 45 20 53 50 45 43 49 46 49 45 44 20 |F THE SPECIFIED |
000018f0 49 4e 50 55 54 20 28 34 2d 37 29 20 41 4e 44 20 |INPUT (4-7) AND |
00001900 52 45 54 55 52 4e 53 20 54 48 45 20 56 41 4c 55 |RETURNS THE VALU|
00001910 45 20 22 4f 4e 22 20 4f 52 20 22 4f 46 46 22 2e |E "ON" OR "OFF".|
00001920 2a 2a 2a 0d 36 ba 19 20 dd 20 a4 74 65 73 74 28 |***.6.. . .test(|
00001930 6c 69 6e 65 6e 75 6d 62 65 72 29 20 0d 36 c4 2f |linenumber) .6./|
00001940 20 e7 20 28 6c 69 6e 65 6e 75 6d 62 65 72 3e 37 | . (linenumber>7|
00001950 20 84 20 6c 69 6e 65 6e 75 6d 62 65 72 3c 34 29 | . linenumber<4)|
00001960 20 8c 20 2a 46 58 31 32 35 20 20 0d 36 ce 0f 20 | . *FX125 .6.. |
00001970 ea 20 62 69 74 76 61 6c 75 65 0d 36 d8 1a 20 62 |. bitvalue.6.. b|
00001980 69 74 76 61 6c 75 65 3d 32 5e 6c 69 6e 65 6e 75 |itvalue=2^linenu|
00001990 6d 62 65 72 0d 36 e2 2e 20 72 65 73 75 6c 74 3d |mber.6.. result=|
000019a0 28 28 a4 70 65 65 6b 28 26 36 30 29 20 80 20 62 |((.peek(&60) . b|
000019b0 69 74 76 61 6c 75 65 29 3d 62 69 74 76 61 6c 75 |itvalue)=bitvalu|
000019c0 65 29 0d 36 ec 1e 20 e7 20 72 65 73 75 6c 74 20 |e).6.. . result |
000019d0 8c 20 3d 22 4f 4e 22 20 8b 20 3d 22 4f 46 46 22 |. ="ON" . ="OFF"|
000019e0 0d 3a 98 99 20 f4 20 2a 2a 2a 54 45 53 54 53 20 |.:.. . ***TESTS |
000019f0 54 48 45 20 53 54 41 54 45 20 4f 46 20 54 48 45 |THE STATE OF THE|
00001a00 20 53 50 45 43 49 46 49 45 44 20 52 45 4c 41 59 | SPECIFIED RELAY|
00001a10 53 20 49 4e 20 54 55 52 4e 20 41 4e 44 20 53 57 |S IN TURN AND SW|
00001a20 41 50 53 20 54 48 45 4d 2e 20 52 45 51 55 49 52 |APS THEM. REQUIR|
00001a30 45 53 20 41 20 53 54 52 49 4e 47 20 52 45 50 52 |ES A STRING REPR|
00001a40 45 53 45 4e 54 49 4e 47 20 54 48 45 20 52 45 4c |ESENTING THE REL|
00001a50 41 59 53 20 54 4f 20 42 45 20 54 4f 47 47 4c 45 |AYS TO BE TOGGLE|
00001a60 44 20 41 53 20 41 20 42 49 4e 41 52 59 20 50 41 |D AS A BINARY PA|
00001a70 54 54 45 52 4e 2e 2a 2a 2a 0d 3a a2 1e 20 dd 20 |TTERN.***.:.. . |
00001a80 f2 6d 75 6c 74 69 74 6f 67 67 6c 65 28 70 61 74 |.multitoggle(pat|
00001a90 74 65 72 6e 24 29 20 0d 3a ac 23 20 ea 20 4c 2c |tern$) .:.# . L,|
00001aa0 4c 24 2c 6d 61 73 6b 25 2c 6f 6c 64 76 61 6c 75 |L$,mask%,oldvalu|
00001ab0 65 2c 6e 65 77 76 61 6c 75 65 0d 3a b6 1e 20 e7 |e,newvalue.:.. .|
00001ac0 20 a9 28 70 61 74 74 65 72 6e 24 29 3c 3e 34 20 | .(pattern$)<>4 |
00001ad0 8c 20 2a 46 58 31 32 35 0d 3a c0 3e 20 e3 20 4c |. *FX125.:.> . L|
00001ae0 3d 31 20 b8 20 34 3a 4c 24 3d c1 70 61 74 74 65 |=1 . 4:L$=.patte|
00001af0 72 6e 24 2c 4c 2c 31 29 3a e7 20 ac 28 4c 24 3d |rn$,L,1):. .(L$=|
00001b00 22 31 22 20 84 20 4c 24 3d 22 30 22 29 20 8c 20 |"1" . L$="0") . |
00001b10 2a 46 58 31 32 35 0d 3a ca 06 20 ed 0d 3a d4 45 |*FX125.:.. ..:.E|
00001b20 20 6d 61 73 6b 25 3d 30 3a e3 20 4c 3d 31 20 b8 | mask%=0:. L=1 .|
00001b30 20 34 3a e7 20 28 c1 70 61 74 74 65 72 6e 24 2c | 4:. (.pattern$,|
00001b40 4c 2c 31 29 3d 22 31 22 29 20 8c 20 6d 61 73 6b |L,1)="1") . mask|
00001b50 25 3d 6d 61 73 6b 25 2b 32 5e 28 34 2d 4c 29 20 |%=mask%+2^(4-L) |
00001b60 20 0d 3a de 06 20 ed 0d 3a e8 32 20 6f 6c 64 76 | .:.. ..:.2 oldv|
00001b70 61 6c 75 65 3d a4 70 65 65 6b 28 26 36 30 29 3a |alue=.peek(&60):|
00001b80 6e 65 77 76 61 6c 75 65 3d 6f 6c 64 76 61 6c 75 |newvalue=oldvalu|
00001b90 65 20 82 20 6d 61 73 6b 25 0d 3a f2 18 20 f2 70 |e . mask%.:.. .p|
00001ba0 6f 6b 65 28 26 36 30 2c 6e 65 77 76 61 6c 75 65 |oke(&60,newvalue|
00001bb0 29 0d 3a fc 06 20 e1 0d 3e 80 ca 20 f4 20 2a 2a |).:.. ..>.. . **|
00001bc0 2a 54 55 52 4e 53 20 4f 4e 20 4f 52 20 4f 46 46 |*TURNS ON OR OFF|
00001bd0 20 54 48 45 20 53 50 45 43 49 46 49 45 44 20 47 | THE SPECIFIED G|
00001be0 52 4f 55 50 20 4f 46 20 52 45 4c 41 59 53 2e 20 |ROUP OF RELAYS. |
00001bf0 20 52 45 51 55 49 52 45 53 20 54 57 4f 20 50 41 | REQUIRES TWO PA|
00001c00 52 41 4d 45 54 45 52 53 3a 2d 28 69 29 54 48 45 |RAMETERS:-(i)THE|
00001c10 20 41 43 54 49 4f 4e 20 54 4f 20 42 45 20 54 41 | ACTION TO BE TA|
00001c20 4b 45 4e 20 69 65 2e 22 4f 4e 22 20 4f 52 20 22 |KEN ie."ON" OR "|
00001c30 4f 46 46 22 2c 20 28 69 69 29 41 20 53 54 52 49 |OFF", (ii)A STRI|
00001c40 4e 47 20 52 45 50 52 45 53 45 4e 54 49 4e 47 20 |NG REPRESENTING |
00001c50 54 48 45 20 52 45 4c 41 59 53 20 54 4f 20 42 45 |THE RELAYS TO BE|
00001c60 20 53 57 49 54 43 48 45 44 20 41 53 20 41 20 42 | SWITCHED AS A B|
00001c70 49 4e 41 52 59 20 50 41 54 54 45 52 4e 2e 2a 2a |INARY PATTERN.**|
00001c80 2a 0d 3e 8a 24 20 dd 20 f2 6d 75 6c 74 69 74 75 |*.>.$ . .multitu|
00001c90 72 6e 28 6f 6e 4f 52 6f 66 66 24 2c 70 61 74 74 |rn(onORoff$,patt|
00001ca0 65 72 6e 24 29 0d 3e 94 23 20 ea 20 4c 2c 4c 24 |ern$).>.# . L,L$|
00001cb0 2c 6d 61 73 6b 25 2c 6f 6c 64 76 61 6c 75 65 2c |,mask%,oldvalue,|
00001cc0 6e 65 77 76 61 6c 75 65 0d 3e 9e 42 20 e7 20 a9 |newvalue.>.B . .|
00001cd0 28 70 61 74 74 65 72 6e 24 29 3c 3e 34 20 84 20 |(pattern$)<>4 . |
00001ce0 ac 28 6f 6e 4f 52 6f 66 66 24 3d 22 4f 4e 22 20 |.(onORoff$="ON" |
00001cf0 84 20 6f 6e 4f 52 6f 66 66 24 3d 22 4f 46 46 22 |. onORoff$="OFF"|
00001d00 29 20 8c 20 2a 46 58 31 32 35 0d 3e a8 3e 20 e3 |) . *FX125.>.> .|
00001d10 20 4c 3d 31 20 b8 20 34 3a 4c 24 3d c1 70 61 74 | L=1 . 4:L$=.pat|
00001d20 74 65 72 6e 24 2c 4c 2c 31 29 3a e7 20 ac 28 4c |tern$,L,1):. .(L|
00001d30 24 3d 22 31 22 20 84 20 4c 24 3d 22 30 22 29 20 |$="1" . L$="0") |
00001d40 8c 20 2a 46 58 31 32 35 0d 3e b2 06 20 ed 0d 3e |. *FX125.>.. ..>|
00001d50 bc 45 20 6d 61 73 6b 25 3d 30 3a e3 20 4c 3d 31 |.E mask%=0:. L=1|
00001d60 20 b8 20 34 3a e7 20 28 c1 70 61 74 74 65 72 6e | . 4:. (.pattern|
00001d70 24 2c 4c 2c 31 29 3d 22 31 22 29 20 8c 20 6d 61 |$,L,1)="1") . ma|
00001d80 73 6b 25 3d 6d 61 73 6b 25 2b 32 5e 28 34 2d 4c |sk%=mask%+2^(4-L|
00001d90 29 20 20 0d 3e c6 06 20 ed 0d 3e d0 66 20 6f 6c |) .>.. ..>.f ol|
00001da0 64 76 61 6c 75 65 3d a4 70 65 65 6b 28 26 36 30 |dvalue=.peek(&60|
00001db0 29 3a e7 20 6f 6e 4f 52 6f 66 66 24 3d 22 4f 4e |):. onORoff$="ON|
00001dc0 22 20 8c 20 6e 65 77 76 61 6c 75 65 3d 6f 6c 64 |" . newvalue=old|
00001dd0 76 61 6c 75 65 20 84 20 6d 61 73 6b 25 20 8b 20 |value . mask% . |
00001de0 6e 65 77 76 61 6c 75 65 3d 6f 6c 64 76 61 6c 75 |newvalue=oldvalu|
00001df0 65 20 80 20 28 32 35 35 2d 6d 61 73 6b 25 29 0d |e . (255-mask%).|
00001e00 3e da 18 20 f2 70 6f 6b 65 28 26 36 30 2c 6e 65 |>.. .poke(&60,ne|
00001e10 77 76 61 6c 75 65 29 0d 3e e4 06 20 e1 0d 42 68 |wvalue).>.. ..Bh|
00001e20 d3 20 f4 20 2a 2a 2a 54 45 53 54 53 20 54 48 45 |. . ***TESTS THE|
00001e30 20 53 50 45 43 49 46 49 45 44 20 47 52 4f 55 50 | SPECIFIED GROUP|
00001e40 20 4f 46 20 49 4e 50 55 54 53 20 41 4e 44 20 52 | OF INPUTS AND R|
00001e50 45 54 55 52 4e 53 20 54 48 45 20 56 41 4c 55 45 |ETURNS THE VALUE|
00001e60 20 22 4f 4e 22 20 49 46 20 41 4c 4c 20 4f 46 20 | "ON" IF ALL OF |
00001e70 54 48 45 4d 20 41 52 45 20 4f 4e 20 41 4e 44 20 |THEM ARE ON AND |
00001e80 22 4f 46 46 22 20 49 46 20 41 4e 59 20 4f 4e 45 |"OFF" IF ANY ONE|
00001e90 20 4f 46 20 54 48 45 4d 20 49 53 20 4f 46 46 2e | OF THEM IS OFF.|
00001ea0 20 20 52 45 51 55 49 52 45 53 20 41 20 53 54 52 | REQUIRES A STR|
00001eb0 49 4e 47 20 52 45 50 52 45 53 45 4e 54 49 4e 47 |ING REPRESENTING|
00001ec0 20 54 48 45 20 49 4e 50 55 54 53 20 54 4f 20 42 | THE INPUTS TO B|
00001ed0 45 20 54 45 53 54 45 44 20 41 53 20 41 20 42 49 |E TESTED AS A BI|
00001ee0 4e 41 52 59 20 50 41 54 54 45 52 4e 2e 2a 2a 2a |NARY PATTERN.***|
00001ef0 0d 42 72 1c 20 dd 20 a4 6d 75 6c 74 69 74 65 73 |.Br. . .multites|
00001f00 74 28 70 61 74 74 65 72 6e 24 29 20 0d 42 7c 1c |t(pattern$) .B|.|
00001f10 20 ea 20 4c 2c 4c 24 2c 74 65 73 74 6d 61 73 6b | . L,L$,testmask|
00001f20 25 2c 72 65 73 75 6c 74 0d 42 86 1e 20 e7 20 a9 |%,result.B.. . .|
00001f30 28 70 61 74 74 65 72 6e 24 29 3c 3e 34 20 8c 20 |(pattern$)<>4 . |
00001f40 2a 46 58 31 32 35 0d 42 90 3e 20 e3 20 4c 3d 31 |*FX125.B.> . L=1|
00001f50 20 b8 20 34 3a 4c 24 3d c1 70 61 74 74 65 72 6e | . 4:L$=.pattern|
00001f60 24 2c 4c 2c 31 29 3a e7 20 ac 28 4c 24 3d 22 31 |$,L,1):. .(L$="1|
00001f70 22 20 84 20 4c 24 3d 22 30 22 29 20 8c 20 2a 46 |" . L$="0") . *F|
00001f80 58 31 32 35 0d 42 9a 06 20 ed 0d 42 a4 50 20 74 |X125.B.. ..B.P t|
00001f90 65 73 74 6d 61 73 6b 25 3d 30 3a e3 20 4c 3d 31 |estmask%=0:. L=1|
00001fa0 20 b8 20 34 3a e7 20 28 c1 70 61 74 74 65 72 6e | . 4:. (.pattern|
00001fb0 24 2c 4c 2c 31 29 3d 22 31 22 29 20 8c 20 74 65 |$,L,1)="1") . te|
00001fc0 73 74 6d 61 73 6b 25 3d 74 65 73 74 6d 61 73 6b |stmask%=testmask|
00001fd0 25 2b 32 5e 28 38 2d 4c 29 20 0d 42 ae 06 20 ed |%+2^(8-L) .B.. .|
00001fe0 0d 42 b8 31 20 72 65 73 75 6c 74 3d 28 28 a4 70 |.B.1 result=((.p|
00001ff0 65 65 6b 28 26 36 30 29 20 80 20 74 65 73 74 6d |eek(&60) . testm|
00002000 61 73 6b 25 29 3d 74 65 73 74 6d 61 73 6b 25 29 |ask%)=testmask%)|
00002010 20 0d 42 c2 1e 20 e7 20 72 65 73 75 6c 74 20 8c | .B.. . result .|
00002020 20 3d 22 4f 4e 22 20 8b 20 3d 22 4f 46 46 22 0d | ="ON" . ="OFF".|
00002030 46 50 6c 20 f4 20 2a 2a 2a 49 4e 49 54 49 41 4c |FPl . ***INITIAL|
00002040 49 53 45 53 20 55 53 45 52 20 50 4f 52 54 20 41 |ISES USER PORT A|
00002050 53 20 46 4f 55 52 20 4f 55 54 50 55 54 53 20 4f |S FOUR OUTPUTS O|
00002060 4e 20 50 42 30 2d 33 20 41 4e 44 20 46 4f 55 52 |N PB0-3 AND FOUR|
00002070 20 49 4e 50 55 54 53 20 4f 4e 20 50 42 34 2d 37 | INPUTS ON PB4-7|
00002080 2e 20 54 55 52 4e 53 20 41 4c 4c 20 4f 55 54 50 |. TURNS ALL OUTP|
00002090 55 54 53 20 4f 46 46 2e 2a 2a 2a 0d 46 5a 13 20 |UTS OFF.***.FZ. |
000020a0 dd 20 f2 73 65 74 5f 75 70 5f 70 6f 72 74 0d 46 |. .set_up_port.F|
000020b0 64 12 20 f2 70 6f 6b 65 28 26 36 32 2c 31 35 29 |d. .poke(&62,15)|
000020c0 0d 46 6e 11 20 f2 70 6f 6b 65 28 26 36 30 2c 30 |.Fn. .poke(&60,0|
000020d0 29 0d 46 78 06 20 e1 0d ff |).Fx. ...|
000020d9
INTCAR.m0
INTCAR.m1
INTCAR.m2
INTCAR.m4
INTCAR.m5
.
